IP Camera (M series)
manual 2013-01 V1.0
Statement If the manual can not help you to solve the problem, please call our technology center for solutions. We will update the content for the new functions without notice.
Notice 1、
Installation Environment
Keep away from the places for high-temperature, heat source and direct sunlight;
Keep away from water and when it gets wet, cut off the power immediately.
Avoid using at damp environment; the reference range for operation humidity is below 85%RH. Avoid using in overheating and too cold environment, the reference range for operation
temperature is -10℃~ +50℃ Please install it horizontally or wall mounting, avoid strenuous vibration place and not
put other equipments onto the item
2、
Transport and Handling
The package is well-designed to ensure the security during the delivery, so please do not change the package at random.
1 ， Do not move the ip cameras from overheated to supercooled condition frequently, otherwise it will frost and shorten the service life. 2 ， Do not move the item when it is on, otherwise the main board might be damaged.
Notice:
1.
Please check the power supply before it is working.
2.
Be careful not to bang the camera or subject it to strong impacts or shocks.
3.
Do not directly touch the optical components for the image sensor, if necessary, please place a clean and moistened cloth with alcohol and wipe the dirt gently; When not in use, please place the dust cover on to the item to protect the image sensor.
4.
Do not aim the camera directly into the sun or at other intense light sources that could affect the image quality (it is not the problem for the ip camera), also shorten the service life for the image sensor.
5.
Keep away from laser when it is working, otherwise the image sensor can be damaged.
6.
If the equipment is not working properly, please the store or the service center, do not disassemble or modify the equipment in any way. ( Problems caused by unauthorized modification or repair should be at your own risk. ）
Index 1.
2.
3.
PRODUCT INTRODUCTION.................................................................................................. 1.1.
PRODUCT SUMMARY............................................................................................................... 4
1.2.
PACKAGE FOR TYPICAL PRODUCTION..................................................................................
4
INSTALLATION GUIDE...........................................................................................................
6
2.1.
WIRED CONNECTION TO LAN..............................................................................................
2.2.
WIFI CONNECTION TO LAN.................................................................................................. 7
2.3.
CONNECTION TO WAN........................................................................................................... 8
6
OPERATION OF USING IE BROWSER.................................................................................. 10 3.1.
VIEW VIDEO............................................................................................................................ 10
3.2.
VIDEO SETTING....................................................................................................................... 11
3.2.1.
Video parameters........................................................................................................... 11
3.2.2.
Audio parameters........................................................................................................... 12
3.2.3.
Image parameters...........................................................................................................12
3.3.
WEB SETTING....................................................................................................................... 13
3.3.1.
Basic web setting........................................................................................................... 13
3.3.2.
WIFI setting................................................................................................................... 13
3.3.3.
WAN access setting....................................................................................................... 13
3.3.4.
ONVIF setting............................................................................................................... 14
3.4.
ALARM SETTING................................................................................................................... 14
3.4.1.
External Alarm Input.................................................................................................. 14
3.4.2.
Motion Detection Setting.............................................................................................. 15
3.4.3.
Alarm mode setting....................................................................................................... 15
3.4.4.
Alarm time setting.......................................................................................................
3.5.
16
ADVANCE SETTING............................................................................................................... 16
3.5.1.
management...........................................................................................................16
3.5.2.
Auto Capture Setting..................................................................................................
3.5.3.
Timer recording........................................................................................................... 17
3.5.4.
E-mail Setting............................................................................................................... 18
3.5.5.
FTP setting................................................................................................................... 18
3.5.6.
Multiple settings........................................................................................................... 19
3.6.
4.
4
17
SYSTEM SETTING................................................................................................................... 19
3.6.1.
Device information....................................................................................................... 19
3.6.2.
Date and time setting.................................................................................................. 20
3.6.3.
Initialize setting........................................................................................................... 20
3.6.4.
System Log................................................................................................................... 20
VISITING DEVICE BY OTHER SOFTWARE......................................................................... 21 4.1.
OTHER WEB BROWSER........................................................................................................... 21
4.2.
MOBILE PHONE SOFTWARE.................................................................................................. 21
4.3.
PC CLIENT SOFTWARE........................................................................................................... 22
2
4.4. 5.
OTHER COMMON SOFTWARE.................................................................................................. 22
PRODUCT FAMILY FOR M SERIES...................................................................................... 23 5.1.
HD CUBE CAMERA............................................................................................................... 23
5.2.
HD PTZ CAMERA................................................................................................................... 23
5.3.
HD WATERPROOF CAMERA.................................................................................................. 25
APPENDIX：M SERIES IP CAMERA PARAMETERS COMPARISION LIST.......................
1
3
1.
Product introduction
1.1. Product summary Thank you for choosing our company’s M series IP camera, which has several models, including indoor HD PTZ camera, indoor HD cube camera, outdoor HD waterproof camera etc. It is very suitable for family, shops, office building and so on.
Main features for M series ：
3 kinds of H.264 video stream and 1 way MJPEG video stream simultaneously, suitable for Local, Internet and Cross-platform view; resolution for 1280*720/640*360/320*180; 4 ways view in a video stream; two-way intercom function, and G.711 and G.726 audio encoding; 802.11b/g/n protocol, build-in WiFi module to perform wireless monitoring; max. 32G SD/TF card for storing the alarm video and pictures, timing snapshot and recording; Built-in web server, use one port to send all the data, s can facilitates network setting; ONVIF and RTSP protocol, easy to integrate it to NVR or large client software; WPS/QSS function; POE function for some cameras, optional; multi-languages web interface, 1/4/9 split screen to perform several view at same time; Manufacturer puts a label of DDNS at the bottom of each IP Camera. When IP Camera is connected to the internet, this URL can be used to visit the device; Provide free client software, Multi-view, Long time recording, video replay etc; Provide free software viewed by mobile phone.
1.2. Package for typical production Accessory
Power
C
Cabl
Bracke
Stan
Antenn 4
Type
adapto r
D
e
t
d of
a
plasti c
HD Cube camera
HD PTZ camera （ Model A ）
5V
√
√
√
√
Built in
5V
√
√
√
√
Optiona l
5V
√
√
√
√
√
5V
√
√
√
√
Optiona l
5V
√
√
√
√
Optiona l
12V
√
√
√
√
Optiona l
HD PTZ camera (Model B）
HD PTZ camera （ Model C ）
HD PTZ camera （ Model D ）
HD waterproof camera Notice: 5
If you choose IP camera with wireless function, so it includes wifi module inside the camera and antenna in package.
Please check carefully if all listed items are included in the package, if anything missing, please vendor in time.
2.
Installation guide
2.1. Wired connection to LAN Power on the IP camera （ please check carefully the voltage of power adaptor, don’t insert incorrect power, otherwise it will be damaged ）, connect IP camera to router by network cable and connect computer to the same router, example of figure 1.
Figure 1 Insert attached CD to computer driver, double click “H&MSearch_en.exe” in the CD, will pop up the interface as figure 2, please operate as the following steps:
6
1) 2) 3)
4) 5) 6)
Figure 2 Click “Search” （ Please make sure your firewall will not block up the item to be searched ） Choose a camera; Change the ip address of the ip camera according to the information in the red frame on the left. The numbers in the red circle should not be the same. The Http port should be a number between 80~65535; Enter name and for the device, the default is “” and “123456”; Click “update”; After updating successfully, click “Search (F3)”, choose the device again and click “Browse (F4)”. Then you can run the web browser, enter name and and IP camera to view the video, example of figure 3. （please use IE browser at first time）
7
Figure 3 Notice: Need to ActiveX when first use, click “ ActiveX( when first use)” in figure 3, will display prompt as figure 4, click ‘run’ will and install the ActiveX automatically.
Figure 4 Tips: You can hold on reset button on the camera for 10 seconds to restore factory default if you forget name and , or not sure the device parameters.
2.2. WiFi connection to LAN After finishing the wired connection as chapter 2.1, you can connect the camera by WiFi. camera in wired connection and enter wifi setting, and then operate as the following step, example of figure 5.
Figure 5 Select ‘On’ and click ‘Search’, and then select wireless router in pop up menu, click ‘OK’ and enter its , click ‘apply’ to save the wireless settings. And you can click 8
‘check’ to check if the wireless setting is successful. After setting successfully, please pull out network cable and reboot the camera to use the wireless function. Because the camera s WPS/QSS, so you can set wireless by simple way as below. 1) Please confirm if the router connected to camera s WPS/QSS (you can check manual of the router or get the from router factory); 2) Press WPS/QSS button on the router, it will launch the function. 3) Press and hold on reset button for 2~5 seconds after it ran normally （ not need connect cable ） , it will launch the WPS/QSS function, then match the setting with the router, the status LED always on when it was matching, and it will flash after matching successfully. 4) Unplug power adaptor and reboot the camera, then you can use the wireless connect function. Note: The camera will automatically stop the function when the matching is unsuccessful after continuing 50 seconds. Due to different kinds of the router, we don’t sure our camera can be connected to all routers successfully.
2.3. Connection to WAN You should connect it to LAN network and do the port forwarding at first, and then connect the LAN network to WAN, connect as figure 6.
Figure 6 For example: operation step of port forwarding as figure 7.
9
1) 2) 3) 4)
Figure 7 Please go to the setting interface of Router, and choose “Port Forwarding”; Choose “Add custom Service” ; Input IP camera http port; Input LAN IP Address of the camera, click “Apply” (port number and IP address as you set in figure 2）
After finishing the port forwarding, you can use WAN IP address of router and http port of camera to visit the camera by remote computer as figure 6. Notice: because the routers are different, so the interface and setting method of router are also different, how to do the port forwarding for various routers, please refer to the manual of your router or consult with router manufacturer.
10
3.
Operation of using IE browser
3.1. View video
Figure 8 1)
Status bar
Figure 9 1 2 3 4 5 6
Display connection status; Display record status: if click “Record”, it will show “REC” which stands for recording; click record button again, it will stop; Zoom out, zoom in and restore digital zoom; Set saving file path: set the location for recording and capturing file storage; Talk button: Click this button to hear what the person at the side of computer talks. Click it again, it will stop playing; Audio monitor button: Click this button to hear what people talking about at the side of IP Cameras,
2) Choose video stream You can choose primary stream or second stream, third stream to view the video. Recommend to view by primary stream in LAN, by second stream in WAN and by third stream in mobile phone.
11
You can view the video by four, nine pictures in same screen, but need to set the camera in 3.6.6 multiple setting. 3) PTZ control If the camera s PTZ function, you can click up, down, left, right arrow to control the camera moving, click
button to center and stop the camera.
When you set camera to a preset position, and then click ‘ changed to other direction, click
, after the camera is
can move the camera to the position you have
set. 4)
Snap /record / SD card/playback Click “Snap” button, to save the picture to the specified file. Click “Record” button to start record. Click again to stop record. Click “Check TF/SD card” can browse the files in the SD card (If the SD card already inside the camera), you can select file to it; Click “Playback” button, it will show a player which can play the record video. For these buttons means: play; stop; open video file; slow play; quick play.
12
3.2. Video setting 3.2.1.
Video parameters
Figure 10 JPEG stream is for some views by non windows platform, for example, click ‘mobile view’ in first page, it will transmit JPEG stream actually.
13
3.2.2.
Audio parameters
Figure 11 The camera s G.711 and G.726 audio encoding format. The sound of the G.711 is better, but it occupies more bandwidth. If you click “On” of the audio capture, so it will transmit audio in corresponding video stream. Please open the audio here, should you hear the sound when clicking audio play button in figure 9.
3.2.3.
Image parameters
Figure 12 You can select “close” to disable IR LED when you don’t need it. It will cut frame rate automatically to enhance night vision at night when select “on”.
14
3.3. Web setting 3.3.1.
Basic web setting
Figure 13 The cameras RTSP protocol, if select “on” of “RTSP authority verification”, you need to enter name and when invoke video by RTSP protocol.
3.3.2.
WIFI setting
Please refer to chapter 2.2.
3.3.3.
WAN access setting
In chapter 2.3, you have known how to do port forwarding. After the success of the port forwarding, you can also visit camera by DDNS. The manufacturer has established a DDNS system, and allotted a DDNS to every device, the can view it from remote PC, example of figure 14.
Figure 14 can also use third party DDNS, such as www.dyndns.com. applies a free domain name from this website and fills the info into below blanks (Figure 15) and saves the settings. Then the domain name can be used.
15
Figure 15 Notice: Using the third party DDNS, if the http port is not 80, the port number should be adding to the domain name with colon. Example: http://mydomain.dyndns.org:81.
3.3.4.
ONVIF setting
Figure 16 The camera s ONVIF protocol, so it can be interconnected with other factory camera with ONVIF.
3.4. Alarm setting 3.4.1.
External Alarm Input
Figure 17 The camera should have external alarm input port for enable this functions. Connect external alarm detector to the input port, the detector will output switching signal when it detects any abnormal, input port of the camera will detect the level change, so it will detect the alarm, therefore the detector should be switching sensor (same as switch) 16
3.4.2.
Motion Detection Setting
Figure 18 Please click “apply” after the settings are done, and motion detection takes effect. The higher value, the higher sensitivity. The camera will trigger corresponding alarm when any change occurs in the detection area.
3.4.3.
Alarm mode setting
After camera detects any change, it will alarm as several mode, example of figure 18.
Figure 19
17
3.4.4.
Alarm time setting
Figure 20 The device will trigger the alarm only during the scheduled time period, you can select the scheduled time according to your request. Example of figure 20, set armed time from Mon 8:30 to 9:00, you only need to click the corresponding time block to set them, the time block will become green when you selected. Note: Please make sure your system time is correct before you set the alarm time period. Please refer to chapter 3.6.2 to set system time.
3.5. Advance setting 3.5.1.
management
Figure 21 There are 3 levels of authorization in it. : “” has the highest authority. It can do any settings. The factory default : 123456. : can only operate the device but can’t do any settings. The default is . Guest: can view the video, but can’t operate the device. The default is guest. Note: Please change these 3 level s when your first use to ensure your safety.
18
3.5.2.
Auto Capture Setting
Figure 22 Tick “Save Images to the TF/SD card”, the snap pictures will be stored into SD card during the setting time.
3.5.3.
Timer recording
Figure 23 Example of figure 23, set recording time from Mon 8:30 to 9:00.
19
3.5.4.
E-mail Setting
Figure 24 The SMTP server name: It is mailbox server, for example of SOHU mailbox, it is “smtp.sohu.com”. Please fill all blanks which we filled above in figure 24 as example. Otherwise, the settings will fail. Please click “Test” to test if the E-mail setting is successful.
3.5.5.
FTP setting
Figure 25 Before to use FTP function, please get the following ready. 1) FTP name and 2) FTP storage space and the authority 3) Create sub-category to store the video or pictures. Notice: The should not be special character; otherwise the camera can’t 20
identify it.
3.5.6.
Multiple settings
Figure 26 Please set multiple devices here first to view 4 or 9 split screen at chapter 3.1 browse interface.
3.6. System setting 3.6.1.
Device information
Figure 27 SD status shows the free capacity if SD card is installed. Notice: the device s max 32G SD card. Please format the SD card to FAT32 before use the card on camera. Please check if the SD Card matches the camera or not 21
before purchasing the SD Card.
3.6.2.
Date and time setting
Figure 28 Example of figure 28, please select the time zone at first and then select a NTP server and obtain time from network time server.
3.6.3.
Initialize setting
Figure 29 If you click “Confirm” of Backup setting data, the camera will create a file, you can store it to your computer, and you can directly call this file to restore the settings. The function helps to manage the cameras and no need to do all the settings again. The firmware upgrade is for updating system firmware and web UI.
22
3.6.4.
System Log
Figure 30
4.
Visiting device by other software
4.1. Other web browser In the Windows OS, for using browser with IE kernel, must the ActiveX. While for Safari and Firefox browsers, please “QuickTime” plug-in and install it to access the IP camera. After installation, please run the QuickTime program to access the QuickTime Preferences dialog box from Edit Menu, example as figure 31. Click “Advanced”, select “custom.” in the Transport Setup. It pops up the Streaming Transport dialog box. Please select “HTTP” for transport protocol and “80” as port ID, click “ok”, and then return to Transport Setup to change “Custom..” to “Auto”. Finally, click “ok” at the bottom. After finishing these settings, run the Firefox or Safari browser to view the video.
23
Figure 31 In Mac computer, the Quicktime is installed by default, so the simply accesses setting tool folder at application folder and run the command program, enter command by command line mode: qtdefaults write TransportSettings HTTP 80 And then run the Safari browser to view the video. Note: Please select the G.711 audio code format for hearing sound in Quicktime plug-in.
4.2. Mobile phone software For more information, please see the manual for mobile phone in attached CD, or the latest software and manual in our website.
4.3. PC Client software IPCMonitor is a free software offered by factory, several devices on LAN and WAN can be browsed at the same time. The software also real time recording, schedule recording, alarm, snap, and so on. The interface is as Figure 32.
24
Figure 32 For more information, pls. refer the <
> in CD.
4.4. Other common software As the device s RTSP protocol, you can use VLC player to play IP Camera video. It is compatible with VLC 1.1.12 version or above. Please use below URL to visit: rtsp://ip:port/11 （ View the video by first stream ） rtsp://ip:port/12 (View video by second stream ） rtsp://ip:port/13 (View video by third stream ） The port is RTSP port; please refer to the settings of Figure 13.
25
5.
Product family for M series
5.1. HD Cube Camera
Figure 33 HD Cube Camera Mega pixels CMOS sensor, IR-CUT, 3.6mm lens, built in MIC, TF card, 12pcs IR LED, audio out interface. It uses 5V power adaptor.
26
5.2. HD PTZ Camera
Figure 34 Model A Mega pixels CMOS sensor, IR-CUT, 3.6mm lens, built in PTZ, MIC, TF card, 11pcs IR LED, audio out interface. It uses 5V power adaptor.
Figure 35 Model B Mega pixels CMOS sensor, IR-CUT, 3.6mm lens, built-in PTZ, MIC, speaker, TF card, 11pcs IR LED, audio out interface. It uses 5V power adaptor.
27
Figure 36 Model C Mega pixels CMOS sensor, IR-CUT, 3.6mm lens, built in PTZ, MIC, SD card, 8pcs IR LED, audio in/out interface, alarm in/out interface. It uses 5V power adaptor.
Figure 37 Model D Mega pixels CMOS sensor, IR-CUT, 3.6mm lens, built in PTZ, MIC, SD card, 10pcs IR LED, audio in/out interface, alarm in/out interface. It uses 5V power adaptor.
5.3. HD waterproof camera
Figure 38 Waterproof camera Mega pixels CMOS sensor, IR-CUT, 8mm lens, 36pcs IR LED, POE function optional, it uses 12V power adaptor. 28
Statement ： 1. 2.
This manual may be different with your using camera, if you have any questions of the manual, please our technical . This manual will be updated periodically; the company reserved the right without prior notice.
29
Appendix：M series IP camera parameters comparision list Product
Function
IP Camera (M series)
manual 2013-01 V1.0
Statement If the manual can not help you to solve the problem, please call our technology center for solutions. We will update the content for the new functions without notice.
Notice 1、
Installation Environment
Keep away from the places for high-temperature, heat source and direct sunlight;
Keep away from water and when it gets wet, cut off the power immediately.
Avoid using at damp environment; the reference range for operation humidity is below 85%RH. Avoid using in overheating and too cold environment, the reference range for operation
temperature is -10℃~ +50℃ Please install it horizontally or wall mounting, avoid strenuous vibration place and not
put other equipments onto the item
2、
Transport and Handling
The package is well-designed to ensure the security during the delivery, so please do not change the package at random.
1 ， Do not move the ip cameras from overheated to supercooled condition frequently, otherwise it will frost and shorten the service life. 2 ， Do not move the item when it is on, otherwise the main board might be damaged.
Notice:
1.
Please check the power supply before it is working.
2.
Be careful not to bang the camera or subject it to strong impacts or shocks.
3.
Do not directly touch the optical components for the image sensor, if necessary, please place a clean and moistened cloth with alcohol and wipe the dirt gently; When not in use, please place the dust cover on to the item to protect the image sensor.
4.
Do not aim the camera directly into the sun or at other intense light sources that could affect the image quality (it is not the problem for the ip camera), also shorten the service life for the image sensor.
5.
Keep away from laser when it is working, otherwise the image sensor can be damaged.
6.
If the equipment is not working properly, please the store or the service center, do not disassemble or modify the equipment in any way. ( Problems caused by unauthorized modification or repair should be at your own risk. ）
Index 1.
2.
3.
PRODUCT INTRODUCTION.................................................................................................. 1.1.
PRODUCT SUMMARY............................................................................................................... 4
1.2.
PACKAGE FOR TYPICAL PRODUCTION..................................................................................
4
INSTALLATION GUIDE...........................................................................................................
6
2.1.
WIRED CONNECTION TO LAN..............................................................................................
2.2.
WIFI CONNECTION TO LAN.................................................................................................. 7
2.3.
CONNECTION TO WAN........................................................................................................... 8
6
OPERATION OF USING IE BROWSER.................................................................................. 10 3.1.
VIEW VIDEO............................................................................................................................ 10
3.2.
VIDEO SETTING....................................................................................................................... 11
3.2.1.
Video parameters........................................................................................................... 11
3.2.2.
Audio parameters........................................................................................................... 12
3.2.3.
Image parameters...........................................................................................................12
3.3.
WEB SETTING....................................................................................................................... 13
3.3.1.
Basic web setting........................................................................................................... 13
3.3.2.
WIFI setting................................................................................................................... 13
3.3.3.
WAN access setting....................................................................................................... 13
3.3.4.
ONVIF setting............................................................................................................... 14
3.4.
ALARM SETTING................................................................................................................... 14
3.4.1.
External Alarm Input.................................................................................................. 14
3.4.2.
Motion Detection Setting.............................................................................................. 15
3.4.3.
Alarm mode setting....................................................................................................... 15
3.4.4.
Alarm time setting.......................................................................................................
3.5.
16
ADVANCE SETTING............................................................................................................... 16
3.5.1.
management...........................................................................................................16
3.5.2.
Auto Capture Setting..................................................................................................
3.5.3.
Timer recording........................................................................................................... 17
3.5.4.
E-mail Setting............................................................................................................... 18
3.5.5.
FTP setting................................................................................................................... 18
3.5.6.
Multiple settings........................................................................................................... 19
3.6.
4.
4
17
SYSTEM SETTING................................................................................................................... 19
3.6.1.
Device information....................................................................................................... 19
3.6.2.
Date and time setting.................................................................................................. 20
3.6.3.
Initialize setting........................................................................................................... 20
3.6.4.
System Log................................................................................................................... 20
VISITING DEVICE BY OTHER SOFTWARE......................................................................... 21 4.1.
OTHER WEB BROWSER........................................................................................................... 21
4.2.
MOBILE PHONE SOFTWARE.................................................................................................. 21
4.3.
PC CLIENT SOFTWARE........................................................................................................... 22
2
4.4. 5.
OTHER COMMON SOFTWARE.................................................................................................. 22
PRODUCT FAMILY FOR M SERIES...................................................................................... 23 5.1.
HD CUBE CAMERA............................................................................................................... 23
5.2.
HD PTZ CAMERA................................................................................................................... 23
5.3.
HD WATERPROOF CAMERA.................................................................................................. 25
APPENDIX：M SERIES IP CAMERA PARAMETERS COMPARISION LIST.......................
1
3
1.
Product introduction
1.1. Product summary Thank you for choosing our company’s M series IP camera, which has several models, including indoor HD PTZ camera, indoor HD cube camera, outdoor HD waterproof camera etc. It is very suitable for family, shops, office building and so on.
Main features for M series ：
3 kinds of H.264 video stream and 1 way MJPEG video stream simultaneously, suitable for Local, Internet and Cross-platform view; resolution for 1280*720/640*360/320*180; 4 ways view in a video stream; two-way intercom function, and G.711 and G.726 audio encoding; 802.11b/g/n protocol, build-in WiFi module to perform wireless monitoring; max. 32G SD/TF card for storing the alarm video and pictures, timing snapshot and recording; Built-in web server, use one port to send all the data, s can facilitates network setting; ONVIF and RTSP protocol, easy to integrate it to NVR or large client software; WPS/QSS function; POE function for some cameras, optional; multi-languages web interface, 1/4/9 split screen to perform several view at same time; Manufacturer puts a label of DDNS at the bottom of each IP Camera. When IP Camera is connected to the internet, this URL can be used to visit the device; Provide free client software, Multi-view, Long time recording, video replay etc; Provide free software viewed by mobile phone.
1.2. Package for typical production Accessory
Power
C
Cabl
Bracke
Stan
Antenn 4
Type
adapto r
D
e
t
d of
a
plasti c
HD Cube camera
HD PTZ camera （ Model A ）
5V
√
√
√
√
Built in
5V
√
√
√
√
Optiona l
5V
√
√
√
√
√
5V
√
√
√
√
Optiona l
5V
√
√
√
√
Optiona l
12V
√
√
√
√
Optiona l
HD PTZ camera (Model B）
HD PTZ camera （ Model C ）
HD PTZ camera （ Model D ）
HD waterproof camera Notice: 5
If you choose IP camera with wireless function, so it includes wifi module inside the camera and antenna in package.
Please check carefully if all listed items are included in the package, if anything missing, please vendor in time.
2.
Installation guide
2.1. Wired connection to LAN Power on the IP camera （ please check carefully the voltage of power adaptor, don’t insert incorrect power, otherwise it will be damaged ）, connect IP camera to router by network cable and connect computer to the same router, example of figure 1.
Figure 1 Insert attached CD to computer driver, double click “H&MSearch_en.exe” in the CD, will pop up the interface as figure 2, please operate as the following steps:
6
1) 2) 3)
4) 5) 6)
Figure 2 Click “Search” （ Please make sure your firewall will not block up the item to be searched ） Choose a camera; Change the ip address of the ip camera according to the information in the red frame on the left. The numbers in the red circle should not be the same. The Http port should be a number between 80~65535; Enter name and for the device, the default is “” and “123456”; Click “update”; After updating successfully, click “Search (F3)”, choose the device again and click “Browse (F4)”. Then you can run the web browser, enter name and and IP camera to view the video, example of figure 3. （please use IE browser at first time）
7
Figure 3 Notice: Need to ActiveX when first use, click “ ActiveX( when first use)” in figure 3, will display prompt as figure 4, click ‘run’ will and install the ActiveX automatically.
Figure 4 Tips: You can hold on reset button on the camera for 10 seconds to restore factory default if you forget name and , or not sure the device parameters.
2.2. WiFi connection to LAN After finishing the wired connection as chapter 2.1, you can connect the camera by WiFi. camera in wired connection and enter wifi setting, and then operate as the following step, example of figure 5.
Figure 5 Select ‘On’ and click ‘Search’, and then select wireless router in pop up menu, click ‘OK’ and enter its , click ‘apply’ to save the wireless settings. And you can click 8
‘check’ to check if the wireless setting is successful. After setting successfully, please pull out network cable and reboot the camera to use the wireless function. Because the camera s WPS/QSS, so you can set wireless by simple way as below. 1) Please confirm if the router connected to camera s WPS/QSS (you can check manual of the router or get the from router factory); 2) Press WPS/QSS button on the router, it will launch the function. 3) Press and hold on reset button for 2~5 seconds after it ran normally （ not need connect cable ） , it will launch the WPS/QSS function, then match the setting with the router, the status LED always on when it was matching, and it will flash after matching successfully. 4) Unplug power adaptor and reboot the camera, then you can use the wireless connect function. Note: The camera will automatically stop the function when the matching is unsuccessful after continuing 50 seconds. Due to different kinds of the router, we don’t sure our camera can be connected to all routers successfully.
2.3. Connection to WAN You should connect it to LAN network and do the port forwarding at first, and then connect the LAN network to WAN, connect as figure 6.
Figure 6 For example: operation step of port forwarding as figure 7.
9
1) 2) 3) 4)
Figure 7 Please go to the setting interface of Router, and choose “Port Forwarding”; Choose “Add custom Service” ; Input IP camera http port; Input LAN IP Address of the camera, click “Apply” (port number and IP address as you set in figure 2）
After finishing the port forwarding, you can use WAN IP address of router and http port of camera to visit the camera by remote computer as figure 6. Notice: because the routers are different, so the interface and setting method of router are also different, how to do the port forwarding for various routers, please refer to the manual of your router or consult with router manufacturer.
10
3.
Operation of using IE browser
3.1. View video
Figure 8 1)
Status bar
Figure 9 1 2 3 4 5 6
Display connection status; Display record status: if click “Record”, it will show “REC” which stands for recording; click record button again, it will stop; Zoom out, zoom in and restore digital zoom; Set saving file path: set the location for recording and capturing file storage; Talk button: Click this button to hear what the person at the side of computer talks. Click it again, it will stop playing; Audio monitor button: Click this button to hear what people talking about at the side of IP Cameras,
2) Choose video stream You can choose primary stream or second stream, third stream to view the video. Recommend to view by primary stream in LAN, by second stream in WAN and by third stream in mobile phone.
11
You can view the video by four, nine pictures in same screen, but need to set the camera in 3.6.6 multiple setting. 3) PTZ control If the camera s PTZ function, you can click up, down, left, right arrow to control the camera moving, click
button to center and stop the camera.
When you set camera to a preset position, and then click ‘ changed to other direction, click
, after the camera is
can move the camera to the position you have
set. 4)
Snap /record / SD card/playback Click “Snap” button, to save the picture to the specified file. Click “Record” button to start record. Click again to stop record. Click “Check TF/SD card” can browse the files in the SD card (If the SD card already inside the camera), you can select file to it; Click “Playback” button, it will show a player which can play the record video. For these buttons means: play; stop; open video file; slow play; quick play.
12
3.2. Video setting 3.2.1.
Video parameters
Figure 10 JPEG stream is for some views by non windows platform, for example, click ‘mobile view’ in first page, it will transmit JPEG stream actually.
13
3.2.2.
Audio parameters
Figure 11 The camera s G.711 and G.726 audio encoding format. The sound of the G.711 is better, but it occupies more bandwidth. If you click “On” of the audio capture, so it will transmit audio in corresponding video stream. Please open the audio here, should you hear the sound when clicking audio play button in figure 9.
3.2.3.
Image parameters
Figure 12 You can select “close” to disable IR LED when you don’t need it. It will cut frame rate automatically to enhance night vision at night when select “on”.
14
3.3. Web setting 3.3.1.
Basic web setting
Figure 13 The cameras RTSP protocol, if select “on” of “RTSP authority verification”, you need to enter name and when invoke video by RTSP protocol.
3.3.2.
WIFI setting
Please refer to chapter 2.2.
3.3.3.
WAN access setting
In chapter 2.3, you have known how to do port forwarding. After the success of the port forwarding, you can also visit camera by DDNS. The manufacturer has established a DDNS system, and allotted a DDNS to every device, the can view it from remote PC, example of figure 14.
Figure 14 can also use third party DDNS, such as www.dyndns.com. applies a free domain name from this website and fills the info into below blanks (Figure 15) and saves the settings. Then the domain name can be used.
15
Figure 15 Notice: Using the third party DDNS, if the http port is not 80, the port number should be adding to the domain name with colon. Example: http://mydomain.dyndns.org:81.
3.3.4.
ONVIF setting
Figure 16 The camera s ONVIF protocol, so it can be interconnected with other factory camera with ONVIF.
3.4. Alarm setting 3.4.1.
External Alarm Input
Figure 17 The camera should have external alarm input port for enable this functions. Connect external alarm detector to the input port, the detector will output switching signal when it detects any abnormal, input port of the camera will detect the level change, so it will detect the alarm, therefore the detector should be switching sensor (same as switch) 16
3.4.2.
Motion Detection Setting
Figure 18 Please click “apply” after the settings are done, and motion detection takes effect. The higher value, the higher sensitivity. The camera will trigger corresponding alarm when any change occurs in the detection area.
3.4.3.
Alarm mode setting
After camera detects any change, it will alarm as several mode, example of figure 18.
Figure 19
17
3.4.4.
Alarm time setting
Figure 20 The device will trigger the alarm only during the scheduled time period, you can select the scheduled time according to your request. Example of figure 20, set armed time from Mon 8:30 to 9:00, you only need to click the corresponding time block to set them, the time block will become green when you selected. Note: Please make sure your system time is correct before you set the alarm time period. Please refer to chapter 3.6.2 to set system time.
3.5. Advance setting 3.5.1.
management
Figure 21 There are 3 levels of authorization in it. : “” has the highest authority. It can do any settings. The factory default : 123456. : can only operate the device but can’t do any settings. The default is . Guest: can view the video, but can’t operate the device. The default is guest. Note: Please change these 3 level s when your first use to ensure your safety.
18
3.5.2.
Auto Capture Setting
Figure 22 Tick “Save Images to the TF/SD card”, the snap pictures will be stored into SD card during the setting time.
3.5.3.
Timer recording
Figure 23 Example of figure 23, set recording time from Mon 8:30 to 9:00.
19
3.5.4.
E-mail Setting
Figure 24 The SMTP server name: It is mailbox server, for example of SOHU mailbox, it is “smtp.sohu.com”. Please fill all blanks which we filled above in figure 24 as example. Otherwise, the settings will fail. Please click “Test” to test if the E-mail setting is successful.
3.5.5.
FTP setting
Figure 25 Before to use FTP function, please get the following ready. 1) FTP name and 2) FTP storage space and the authority 3) Create sub-category to store the video or pictures. Notice: The should not be special character; otherwise the camera can’t 20
identify it.
3.5.6.
Multiple settings
Figure 26 Please set multiple devices here first to view 4 or 9 split screen at chapter 3.1 browse interface.
3.6. System setting 3.6.1.
Device information
Figure 27 SD status shows the free capacity if SD card is installed. Notice: the device s max 32G SD card. Please format the SD card to FAT32 before use the card on camera. Please check if the SD Card matches the camera or not 21
before purchasing the SD Card.
3.6.2.
Date and time setting
Figure 28 Example of figure 28, please select the time zone at first and then select a NTP server and obtain time from network time server.
3.6.3.
Initialize setting
Figure 29 If you click “Confirm” of Backup setting data, the camera will create a file, you can store it to your computer, and you can directly call this file to restore the settings. The function helps to manage the cameras and no need to do all the settings again. The firmware upgrade is for updating system firmware and web UI.
22
3.6.4.
System Log
Figure 30
4.
Visiting device by other software
4.1. Other web browser In the Windows OS, for using browser with IE kernel, must the ActiveX. While for Safari and Firefox browsers, please “QuickTime” plug-in and install it to access the IP camera. After installation, please run the QuickTime program to access the QuickTime Preferences dialog box from Edit Menu, example as figure 31. Click “Advanced”, select “custom.” in the Transport Setup. It pops up the Streaming Transport dialog box. Please select “HTTP” for transport protocol and “80” as port ID, click “ok”, and then return to Transport Setup to change “Custom..” to “Auto”. Finally, click “ok” at the bottom. After finishing these settings, run the Firefox or Safari browser to view the video.
23
Figure 31 In Mac computer, the Quicktime is installed by default, so the simply accesses setting tool folder at application folder and run the command program, enter command by command line mode: qtdefaults write TransportSettings HTTP 80 And then run the Safari browser to view the video. Note: Please select the G.711 audio code format for hearing sound in Quicktime plug-in.
4.2. Mobile phone software For more information, please see the manual for mobile phone in attached CD, or the latest software and manual in our website.
4.3. PC Client software IPCMonitor is a free software offered by factory, several devices on LAN and WAN can be browsed at the same time. The software also real time recording, schedule recording, alarm, snap, and so on. The interface is as Figure 32.
24
Figure 32 For more information, pls. refer the <
4.4. Other common software As the device s RTSP protocol, you can use VLC player to play IP Camera video. It is compatible with VLC 1.1.12 version or above. Please use below URL to visit: rtsp://ip:port/11 （ View the video by first stream ） rtsp://ip:port/12 (View video by second stream ） rtsp://ip:port/13 (View video by third stream ） The port is RTSP port; please refer to the settings of Figure 13.
25
5.
Product family for M series
5.1. HD Cube Camera
Figure 33 HD Cube Camera Mega pixels CMOS sensor, IR-CUT, 3.6mm lens, built in MIC, TF card, 12pcs IR LED, audio out interface. It uses 5V power adaptor.
26
5.2. HD PTZ Camera
Figure 34 Model A Mega pixels CMOS sensor, IR-CUT, 3.6mm lens, built in PTZ, MIC, TF card, 11pcs IR LED, audio out interface. It uses 5V power adaptor.
Figure 35 Model B Mega pixels CMOS sensor, IR-CUT, 3.6mm lens, built-in PTZ, MIC, speaker, TF card, 11pcs IR LED, audio out interface. It uses 5V power adaptor.
27
Figure 36 Model C Mega pixels CMOS sensor, IR-CUT, 3.6mm lens, built in PTZ, MIC, SD card, 8pcs IR LED, audio in/out interface, alarm in/out interface. It uses 5V power adaptor.
Figure 37 Model D Mega pixels CMOS sensor, IR-CUT, 3.6mm lens, built in PTZ, MIC, SD card, 10pcs IR LED, audio in/out interface, alarm in/out interface. It uses 5V power adaptor.
5.3. HD waterproof camera
Figure 38 Waterproof camera Mega pixels CMOS sensor, IR-CUT, 8mm lens, 36pcs IR LED, POE function optional, it uses 12V power adaptor. 28
Statement ： 1. 2.
This manual may be different with your using camera, if you have any questions of the manual, please our technical . This manual will be updated periodically; the company reserved the right without prior notice.
29
Appendix：M series IP camera parameters comparision list Product
Function
Related Documents g842
M Series Ip Camera Manual 6y4q6d
October 2019 56
Ip Camera Manual 1l4u1n
November 2019 67
B Series Ip Camera Manual 6o5f12
October 2019 78
Aj Series Ip Camera Manual 485t6c
December 2021 0
L Series Ip Camera Manual q624w
December 2019 36
Wansview Nc Series Ip Camera Manual V1.0 5ph6k
December 2021 0More Documents from "Justo Javier Erazo Yuco" 224573
929
November 2019 34
M Series Ip Camera Manual 6y4q6d
October 2019 56
Ejemplo De Liquidacion De Obra fm4x
August 2020 0
Termo King 1n55g
October 2020 0
Auxiliar Por Procesos 496f3
April 2020 15
