//voice If the has been set for the , the browser prompts for authentication. The name and the name cannot be changed. When browsing pages with the privilege, you can switch to privilege by clicking the link. If the is set, the browser prompts for authentication when you click the link. From the , you can switch to the by clicking the link. Authentication is required if the has been set.

NOTE Switching between and s or between basic and

advanced views discards any uncommitted changes on the web pages.

Using the istration Web Server This section describes how to use the istration web server to configure the advanced settings of the ATA device. It includes the following topics: •

“Connecting to the istration Web Server” section on page 35

•

“Setting Up the WAN Configuration for Your ATA Device” section on page 35

•

“ing to the Service Provider” section on page 37

Cisco Small Business ATA istration Guide

34

Basic istration and Configuration Using the istration Web Server

•

2

“Advanced Configurations” section on page 38

Connecting to the istration Web Server To access the ATA istration web server, perform the following steps. STEP 1 Start Internet Explorer on a computer that is connected to the same network as the

ATA device. STEP 2 Determine the address of the ATA device.

a. Connect an analog telephone to the Phone 1 port of the ATA device. (You may not hear a dial tone. Continue to step b.) b. Press **** on the keypad to access the IVR menu. c. Press 110# to determine the Internet (WAN) IP address.

NOTE For more information on the IVR menu, see your Quick Installation Guide or

Guide for your device, or the LVS istration Guide. STEP 3 Direct the browser to the IP address of the ATA device. STEP 4 The Router > Status page appears. By default, the page is in Basic mode. Log

on to the view by clicking , near the top right corner of the page. Then click Advanced.

NOTE By default, no is required. You can assign an istrative

later, but it is convenient not to use a during the initial configuration.

Setting Up the WAN Configuration for Your ATA Device STEP 1 Start Internet Explorer, connect to the istration web server, and choose

access with Advanced settings. STEP 2 Click Network tab > WAN Setup.


35


2

STEP 3 Complete the WAN configuration for DH, static IP addressing, or PPPoE.

For DH: a. Select DH from the Connection Type drop-down menu. b. If you use a cable modem, you may need to configure the MAC Clone Settings. ( your ISP for more information.) c. If your service uses a specific PC MAC address, then select yes from the Enable MAC Clone Service setting. d. Then enter the PC’s MAC address in the Cloned MAC Address field. For Static IP Addressing: a. Select Static IP from the Connection Type drop-down menu. b. In the Static IP Settings section, enter the IP address in the Static IP field, the subnet mask in the NetMask field, and the default gateway IP address in the Gateway field. c. In the Optional Settings section, enter the DNS server address(es) in the Primary DNS and optional Secondary DNS fields. For PPPoE: a. Select PPPoE from the Connection Type drop-down menu. This is the correct setting for most DSL s. b. Enter the values provided by the ITSP in the following fields: •

PPPoE Name

•

PPPoE

•

PPPoE Service Name

STEP 4 Click Submit All Changes. The ATA device reboots. STEP 5 To your progress, click the Router tab and then click Status. Under System

Status, confirm the WAN Connection Type, Current IP, Current Netmask , Current Gateway, and Primary DNS.


36


2

ing to the Service Provider To use VoIP phone service, you must configure your ATA device to the Service Provider. STEP 1 Start Internet Explorer, connect to the istration web server, and choose

access with Advanced settings. STEP 2 Click Voice tab > Line N, where N is the line number that you want to configure. STEP 3 Enter the information for your ITSP. The following is the minimum required

configuration to connect the ATA device to an ITSP: •

ID: The number or logon name for your ITSP (Subscriber Information section)

•

: The for your ITSP (Subscriber Information section)

•

Proxy: The proxy server for your ITSP (Proxy and Registration section)

STEP 4 After making any necessary changes, click the Submit All Changes button. STEP 5 To your progress, perform the following tasks:

•

After the devices reboot, click Voice tab > Info. Scroll down to the Line 1 Status section of the page. that the line is ed.

•

Use an external phone to place an inbound call to the telephone number that was assigned by your ITSP. Assuming that you have left the default settings in place, the phone should ring and you can pick up the phone to get two-way audio.

•

If the line is not ed, you may need to refresh the browser several times because it can take a few seconds for the registration to succeed. Also that your DNS is configured properly.

NOTE If the device has more than one Line tab, each line tab must be configured

separately. Each line tab can be configured for a different ITSP.


37

Basic istration and Configuration Upgrading, Rebooting, and Resyncing Your ATA Device

2

Advanced Configurations Other parameters may need to be changed from the defaults, depending on the requirements of a specific ITSP. Some of the commonly configured parameters include the following: •

Streaming Audio Server—You can enable an external music source for music on hold. See the “Configuring the Streaming Audio Server,” on page 85 for further information.

•

NAT Settings—You can adjust these settings to resolve issues that arise when using a ATA on a network behind a Network Address Translation (NAT) device. See the “Network Address Translation (NAT) and Voice over IP (VoIP),” on page 42 for further information.

•

Subscriber Information—You can configure security parameters. See the “Secure Call Implementation,” on page 66 for further information.

•

Dial Plan—You can configure a dial plan for a specific line. See the “Configuring Dial Plans,” on page 56 for further information.

Upgrading, Rebooting, and Resyncing Your ATA Device The istration web server s upgrading, rebooting, and resyncing functions through special URLs. privilege is needed for these functions.

Upgrade URL The Upgrade URL lets you upgrade the ATA device to the firmware specified by the URL, which can identify either a TFTP or HTTP server.

NOTE If the value of the Upgrade Enable parameter in the Provisioning page is No, you

cannot upgrade the ATA device even if the web page indicates otherwise. The syntax of the Upgrade URL is as follows: http://spa-ip-addr//upgrade?[protocol://][server-name[:port]][/ firmware-pathname]

Both HTTP and TFTP are ed for the upgrade operation.


38

Basic istration and Configuration Upgrading, Rebooting, and Resyncing Your ATA Device

2

If no protocol is specified, TFTP is assumed. If no server-name is specified, the host that requests the URL is used as server-name. If no port specified, the default port of the protocol is used. (69 for TFTP or 80 for HTTP) The firmware-pathname is typically the file name of the binary located in a directory on the TFTP or HTTP server. If no firmware-pathname is specified, / spa.bin is assumed, as in the following example: http://192.168.2.217//upgrade?tftp://192.168.2.251/spa.bin

Resync URL The Resync URL lets you force the ATA device to do a resync to a profile specified in the URL, which can identify either a TFTP, HTTP, or HTTPS server. The syntax of the Resync URL is as follows: http://spa-ip-addr//resync?[[protocol://][server-name[:port]]/profilepathname]

NOTE The SPA resyncs only when it is idle.

If no parameter follows /resync?, the Profile Rule setting from the Provisioning page is used. If no protocol is specified, TFTP is assumed. If no server-name is specified, the host that requests the URL is used as server-name. If no port is specified, the default port is used (69 for TFTP, 80 for HTTP, and 443 for HTTPS). The profile-path is the path to the new profile with which to resync, for example: http://192.168.2.217/resync?tftp://192.168.2.251/spaconf.cfg

Reboot URL The Reboot URL lets you reboot the ATA device. The Reboot URL is as follows: http://spa-ip-addr//reboot

NOTE The ATA device reboots only when it is idle.


39

Basic istration and Configuration Provisioning Your ATA Device

2

Provisioning Your ATA Device This section describes the provisioning functionality of the ATA device. This section includes the following topics: •

“Provisioning Capabilities” section on page 40

•

“Configuration Profile” section on page 41

For detailed information about provisioning your ATA device, refer to the SPA Provisioning Guide.

Provisioning Capabilities The ATA device provides for secure provisioning and remote upgrade. Provisioning is achieved through configuration profiles transferred to the device via TFTP, HTTP, or HTTPS. To configure Provisioning, go to Provisioning tab in the istration web server. The ATA device can be configured to automatically resync its internal configuration state to a remote profile periodically and on power up. The automatic resyncs are controlled by configuring the desired profile URL into the device. The ATA device accepts profiles in XML format, or alternatively in a proprietary binary format, which is generated by a profile compiler tool available from Cisco. Find the Profiler Compiler for your ATA at http://www.cisco.com/web/partners/ sell/smb/products/voice_and_conferencing.html#~vc_technical_resources. The ATA device s up to 256-bit symmetric key encryption of profiles. For the initial transfer of the profile encryption key (initial provisioning stage), the ATA device can receive a profile from an encrypted channel (HTTPS), or it can resync to a binary profile generated by the Cisco-supplied profile compiler. In the latter case, the profile compiler can encrypt the profile specifically for the target ATA device, without requiring an explicit key exchange. Remote firmware upgrade is achieved via TFTP or HTTP (firmware upgrades using HTTPS are not ed). Remote upgrades are controlled by configuring the desired firmware image URL into the ATA device via a remote profile resync. For further information about remote provisioning refer to the SPA Provisioning Guide.


40

Basic istration and Configuration Provisioning Your ATA Device

2

Configuration Profile The ATA configuration profile can be either an XML file or a binary file with a proprietary format. The XML file consists of a series of elements (one per configuration parameter), encapsulated within the element tags … . The encapsulated elements specify values for individual parameters. Here is an example of a valid XML profile: <_wd rel="nofollow"> some secret Yes

Binary format profiles contain ATA parameter values and access permissions for the parameters. By convention, the profile uses the extension .cfg (for example, spa2102.cfg). The Profile Compiler (SPC) tool compiles a plain-text file containing parameter-value pairs into a properly formatted and encrypted .cfg file. The SPC tool is available for the Win32 environment and Linux-i386-elf environment. Requests for SPC tools compiled on other platforms are evaluated on a case-bycase basis. Please your sales representative for further information about obtaining the SPC tool. The syntax of the plain-text file accepted by the profile compiler is a series of parameter-value pairs, with the value in double quotes. Each parameter-value pair is followed by a semicolon. Here is an example of a valid text source profile for input to the SPC tool: _wd “some secret”; Upgrade_Enable “Yes”;

Refer to the SPA Provisioning Guide for further details. The names of parameters in XML profiles can generally be inferred from the ATA configuration Web pages, by substituting underscores (_) for spaces and other control characters. Further, to distinguish between Lines 1, 2, 3, and 4, corresponding parameter names are augmented by the strings _1_, _2_, _3_, and _4_. For example, Line 1 Proxy is named Proxy_1_ in XML profiles. Parameters in the case of source text files for the SPC tool are similarly named, except that to differentiate Line 1, 2, 3, and 4, the appended strings ([1], [2], [3], or [4]) are used. For example, the Line 1 Proxy is named Proxy[1] in source text profiles for input to the SPC.


41

3 Configuring Your System for ITSP Interoperability

This chapter provides configuration details to help you to ensure that your infrastructure properly s voice services.

•

“Network Address Translation (NAT) and Voice over IP (VoIP),” on page 42

•

“Firewalls and SIP,” on page 48

•

“Configuring SIP Timer Values,” on page 48

Network Address Translation (NAT) and Voice over IP (VoIP) NAT is a function that allows multiple devices to share the same public, routable, IP address to establish connections over the Internet. NAT is present in many broadband access devices to translate public and private IP addresses. To enable VoIP to co-exist with NAT, some form of NAT traversal is required. Some ITSPs provide NAT traversal, but some do not. If your ITSP does not provide NAT traversal, you have several options.

•

“NAT Mapping with Session Border Controller,” on page 43

•

“NAT Mapping with SIP-ALG Router,” on page 43

•

“Configuring NAT Mapping with a Static IP Address,” on page 43

•

“Configuring NAT Mapping with STUN,” on page 45


42

Configuring Your System for ITSP Interoperability Network Address Translation (NAT) and Voice over IP (VoIP)

3

NAT Mapping with Session Border Controller It is strongly recommended that you choose an ITSP that s NAT mapping through a Session Border Controller. With NAT mapping provided by the ITSP, you have more choices in selecting a router.

NAT Mapping with SIP-ALG Router If the ITSP network does not provide a Session Border Controller functionality, you can achieve NAT mapping by using a router that has a SIP ALG (Application Layer Gateway). The WRV200 router is recommended for this purpose, although any router with a SIP-ALG can be used. By using a SIP-ALG router, you have more choices in selecting an ITSP.

Configuring NAT Mapping with a Static IP Address If the ITSP network does not provide a Session Border Controller functionality, and if other requirements are met, you can configure NAT mapping to ensure interoperability with the ITSP. Requirements:

•

You must have an external (public) IP address that is static.

•

The NAT mechanism used in the router must be symmetric. See “Determining the Router’s NAT Mechanism,” on page 47.

•

The LAN switch must be configured to enable Spanning Tree Protocol and Port Fast on the ports to which the SPA devices are connected.

NOTE Use NAT mapping only if the ITSP network does not provide a Session Border

Controller functionality. STEP 1 Connect to the istration web server, and choose access with

Advanced settings. STEP 2 Click Voice tab > SIP.


43


3

STEP 3 Scroll down to the NAT Parameters section, and then enter the following

settings to static mapping to your public IP address:

•

Handle VIA received, Insert VIA received, Substitute VIA Addr: yes

•

Handle VIA rport, Insert VIA rport, Send Resp To Src Port: yes

•

EXT IP: Enter the public IP address for your router. Voice tab > SIP: NAT Parameters

STEP 4 Click Voice tab > Line N, where N represents the line interface number. STEP 5 Scroll down to the NAT Settings section.

•

NAT Mapping Enable: Choose YES.

•

NAT Keep Alive Enable: Choose YES (optional). Voice tab > Line N > NAT Settings

STEP 6 Click Submit All Changes.

NOTE You also need to configure the firewall settings on your router to allow SIP

traffic. See “Firewalls and SIP,” on page 48.


44


3

Configuring NAT Mapping with STUN If the ITSP network does not provide a Session Border Controller functionality, and if other requirements are met, it is possible to use STUN as a mechanism to discover the NAT mapping. This option is considered a practice of last resort and should be used only if the other methods are unavailable. Requirements:

•

STUN is a viable option only if your router uses asymmetric NAT. See “Determining the Router’s NAT Mechanism,” on page 47.

•

You must have a computer running STUN server software.

•

The LAN switch must be configured to enable Spanning Tree Protocol and Port Fast on the ports to which the SPA devices are connected.

NOTE Use NAT mapping only if the ITSP network does not provide a Session Border

Controller functionality. STEP 1 Connect to the istration web server, and choose access with

Advanced settings. STEP 2 Click Voice tab > SIP. STEP 3 Scroll down to the NAT Parameters section, and then enter the following

settings to enable and the STUN server settings:

•

Handle VIA received: yes

•

Handle VIA rport: yes

•

Insert VIA received: yes

•

Insert VIA rport: yes

•

Substitute VIA Addr: yes

•

Send Resp To Src Port: yes

•

STUN Enable: Choose yes.

•

STUN Server: Enter the IP address for your STUN server.


45


3

Voice tab > SIP > NAT Parameters

STEP 4 Click Voice tab > Line N, where N is the number of the line interface. STEP 5 Scroll down to the NAT Settings section.

•

NAT Mapping Enable: Choose yes.

•

NAT Keep Alive Enable: Choose yes (optional). Voice tab > Line N > NAT Settings

NOTE Your ITSP may require the SPA device to send NAT keep alive messages to

keep the NAT ports open permanently. Check with your ITSP to determine the requirements. STEP 6 Click Submit All Changes.

NOTE You also need to configure the firewall settings on your router to allow SIP

traffic. See “Firewalls and SIP,” on page 48.


46


3

Determining the Router’s NAT Mechanism STUN does not work on routers with symmetric NAT. With symmetric NAT, IP addresses are mapped from one internal IP address and port to one external, routable destination IP address and port. If another packet is sent from the same source IP address and port to a different destination, then a different IP address and port number combination is used. This method is restrictive because an external host can send a packet to a particular port on the internal host only if the internal host first sent a packet from that port to the external host.

NOTE This procedure assumes that a syslog server is configured and is ready to receive

syslog messages. STEP 1 Make sure you do not have firewall running on your PC that could block the syslog

port (port 514 by default). STEP 2 Connect to the istration web server, and choose access with

Advanced settings. STEP 3 To enable debugging, complete the following tasks:

a. Click Voice tab > System. b. In the Debug Server field, enter the IP address of your syslog server. This address and port number must be reachable from the SPA9000. c. From the Debug level drop-down list, choose 3. STEP 4 To collect information about the type of NAT your router is using, complete the

following tasks: a. Click Voice tab > SIP. b. Scroll down to the NAT Parameters section. c. From the STUN Test Enable field, choose yes. STEP 5 To enable SIP signalling, complete the following task:

a. Click Voice tab > Line N, where N represents the line interface number. b. In the SIP Settings section, choose full from the SIP Debug Option field.


47

Configuring Your System for ITSP Interoperability Firewalls and SIP

3

STEP 6 Click Submit All Changes. STEP 7 View the syslog messages to determine whether your network uses symmetric

NAT. Look for a warning header in the messages, such as Warning: 399 spa "Full Cone NAT Detected.”

Firewalls and SIP To enable SIP requests and responses to be exchanged with the SIP proxy at the ITSP, you must ensure that your firewall allows both SIP and RTP unimpeded access to the Internet.

•

•

Make sure that the following ports are not blocked: •

SIP ports—UDP port 5060 through 5063, which are used for the ITSP line interfaces

•

RTP ports—16384 to 16482

Also disable SPI (Stateful Packet Inspection) if this function exists on your firewall.

Configuring SIP Timer Values The default timer values should be adequate in most circumstances. However, you can adjust the SIP timer values as needed to ensure interoperability with your ISTP. For example, if SIP requests are returned with an “invalid certificate” message, you may need to enter a longer SIP T1 retry value. To view the default settings or to make changes, open the Voice > SIP page, and scroll down to the SIP Timer Values section. For field descriptions, see ”SIP Timer Values (sec) section,” on page 124 of Appendix B.


48

4 Configuring Voice Services

This chapter describes how to configure your ATA device to meet the customer’s requirements for voice services.

•

“ed Codecs,” on page 49

•

“Using a FAX Machine,” on page 50

•

“Managing Caller ID Service,” on page 53

•

“Silence Suppression and Comfort Noise Generation,” on page 55

•

“Configuring Dial Plans,” on page 56

•

“Secure Call Implementation,” on page 66

•

“SIP Trunking and Hunt Groups on the SPA8000,” on page 70

ed Codecs The following list shows the current ed codecs for each ATA device. If you need to change the G711u codec which is configured by default, set your preferred codecs in the FXS Line tab(s); Audio Configuration. You may set your first, second, and third preferred codec. See “ATA Routing Field Reference,” on page 100. PAP2T / SPA2102 / SPA3102 / SPA8000 / SPA8800

•

G.711u (configured by default)

•

G.711a

•

G.726-16

•

G.726-24

•

G.726-32


49

Configuring Voice Services Using a FAX Machine

•

G.726-40

•

G.729a

•

G.723

4

Using a FAX Machine You can connect a fax machine to an FXS port on the SPA2102, SPA3102, SPA8000, and SPA8800. T.38 Fax is ed on these devices, for fax transmission over an IP network. The SPA2102 and SPA3102 a single connection, while the SPA8000 and SPA8800 one connection for each pair of FXS ports (1/2, 3/4, 5/6, and 7/8) for a maximum of four connections. Follow this procedure to optimize fax completion rates. STEP 1 Upgrade the ATA firmware to the latest version STEP 2 Ensure that you have enough bandwidth for uplink and downlink.

•

For G.711 fallback, it is recommend to have approximately 100Kbps.

•

For T.38, allocate at least 50 kbps.

STEP 3 To optimize G.711 fallback fax completion rates, set the following on the Line tab

of your ATA device:

•

Network Jitter Buffer: very high

•

Jitter buffer adjustment: disable

•

Call Waiting: no

•

3 Way Calling: no

•

Echo Canceller: no

•

Silence suppression: no

•

Preferred Codec: G.711

•

Use pref. codec only: yes

STEP 4 If you are using a Cisco media gateway for PSTN termination, disable T.38 (fax

relay) and enable fax using modem through.


50

4


For example: modem through nse payload-type 110 codec g711ulaw fax rate disable fax protocol -through g711ulaw

STEP 5 Enable T.38 fax on the SPA 2102 by configuring the following parameter on the

Line tab for the FXS port to which the FAX machine is connected: FAX_thru_Method: ReINVITE

NOTE If a T.38 call cannot be set-up, then the call should automatically revert to

G.711 fallback. STEP 6 If you are using a Cisco media gateway use the following settings:

Make sure the Cisco gateway is correctly configured for T.38 with the SPA dial peer. For example: fax protocol T38 fax rate voice fax-relay ecm disable fax nsf 000000 no vad

Fax Troubleshooting If have problems sending or receiving faxes, complete the following steps: STEP 1 that your fax machine is set to a speed between 7200 and 14400. STEP 2 Send a test fax in a controlled environment between two ATAs. STEP 3 Determine the success rate. STEP 4 Monitor the network and record the following statistics:

•

Jitter

•

Loss

•

Delay


51


4

STEP 5 If faxes fail consistently, capture a copy of the web interface settings by selecting

Save As > Web page, complete from the istration web server page. You can send this configuration file to Technical . STEP 6 Enable and capture the debug log. For instructions, refer to Appendix C,

“Troubleshooting.”.

NOTE You may also capture data using a sniffer trace. STEP 7 Identify the type of fax machine connected to the ATA device. STEP 8 technical :

•

If you are an end of VoIP products, the reseller or Internet telephony service provider (ITSP) that supplied the equipment.

•

If you are an authorized Cisco partner, Cisco technical .


52

4

Configuring Voice Services Managing Caller ID Service

Managing Caller ID Service The choice of caller ID (CID) method is dependent on your area/region. To configure CID, use the following parameters: Parameter

Tab

Description and Value

Caller ID Method

Regional

The following choices are available: •

Bellcore (N.Amer,China)—CID, CIDCW, and VMWI. FSK sent after first ring (same as ETSI FSK sent after first ring) (no polarity reversal or DTAS).

•

DTMF (Finland, Sweden)—CID only. DTMF sent after polarity reversal (and no DTAS) and before first ring.

•

DTMF (Denmark)—CID only. DTMF sentbefore first ring with no polarity reversal and no DTAS.

•

ETSI DTMF—CID only. DTMF sent after DTAS (and no polarity reversal) and before first ring.

•

ETSI DTMF With PR—CID only. DTMF sent after polarity reversal and DTAS and before first ring.

•

ETSI DTMF After Ring—CID only. DTMF sent after first ring (no polarity reversal or DTAS).

•

ETSI FSK—CID, CIDCW, and VMWI. FSK sent after DTAS (but no polarity reversal) and before first ring. Waits for ACK from E after DTAS for CIDCW.

•

ETSI FSK With PR (UK)—CID, CIDCW, and VMWI. FSK is sent after polarity reversal and DTAS and before first ring. Waits for ACK from E after DTAS for CIDCW. Polarity reversal is applied only if equipment is on hook.

•

DTMF (Denmark) With PR—CID only. DTMF sent after polarity reversal (and no DTAS) and before first ring.

The default is Bellcore(N.Amer, China). Caller ID FSK Standard

Regional

The ATA device s bell 202 and v.23 standards for caller ID generation. Select the FSK standard you want to use, bell 202 or v.23. The default is bell 202. This field is not found in the PAP2T.


53

4

Configuring Voice Services Managing Caller ID Service

There are three types of Caller ID: •

On Hook Caller ID Associated with Ringing — This type of Caller ID is used for incoming calls when the attached phone is on hook. See the following figure (a) – (c). All CID methods can be applied for this type of CID.

•

On Hook Caller ID Not Associated with Ringing — This feature is used to send VMWI signal to the phone to turn the message waiting light on and off (see Figure 1 (d) and (e)). This is available only for FSK-based CID methods: (Bellcore, ETSI FSK, and ETSI FSK With PR).

•

Off Hook Caller ID — This is used to delivery caller-id on incoming calls when the attached phone is off hook (see the following figure). This can be call waiting caller ID (CIDCW) or to notify the that the far end party identity has changed or updated (such as due to a call transfer). This is available only for FSK-based CID methods: (Bellcore, ETSI FSK, and ETSI FSK With PR). a) Bellcore/ETSI Onhook Post-Ring FSK First Ring

FSK

b) ETSI Onhook Post-Ring DTMF First Ring

DTMF

c) ETSI Onhook Pre-Ring FSK/DTMF Polarity Reversal

CAS (DTAS)

DTMF/ FSK

First Ring

d) Bellcore Onhook FSK w/o Ring OSI

FSK

e) ETSI Onhook FSK w/o Ring Polarity Reversal

CAS (DTAS)

FSK

f) Bellcore/ETSI Offhook FSK CAS (DTAS)


Wait For ACK

FSK

54

Configuring Voice Services Silence Suppression and Comfort Noise Generation

4

Silence Suppression and Comfort Noise Generation Voice Activity Detection (VAD) with Silence Suppression is a means of increasing the number of calls ed by the network by reducing the required bandwidth for a single call. VAD uses a sophisticated algorithm to distinguish between speech and non-speech signals. Based on the current and past statistics, the VAD algorithm decides whether or not speech is present. If the VAD algorithm decides speech is not present, the silence suppression and comfort noise generation is activated. This is accomplished by removing and not transmitting the natural silence that occurs in normal two-way connection. The IP bandwidth is used only when someone is speaking. During the silent periods of a telephone call, additional bandwidth is available for other voice calls or data traffic because the silence packets are not being transmitted across the network. Comfort Noise Generation provides artificially-generated background white noise (sounds), designed to reassure callers that their calls are still connected during silent periods. If Comfort Noise Generation is not used, the caller may think the call has been disconnected because of the “dead silence” periods created by the VAD and Silence Suppression feature. Silence suppression is configured in the Line and PSTN Line tabs. See “ATA Routing Field Reference,” on page 100.


55

4

Configuring Dial Plans

Configuring Dial Plans Dial plans determine how the digits are interpreted and transmitted. They also determine whether the dialed number is accepted or rejected. You can use a dial plan to facilitate dialing or to block certain types of calls such as long distance or international. This section includes information that you need to understand dial plans, as well as procedures for configuring your own dial plans. This section includes the following topics:

•

“About Dial Plans,” on page 56

•

“Editing Dial Plans,” on page 65

About Dial Plans This section provides information to help you understand how dial plans are implemented. Refer to the following topics:

•

“Digit Sequences,” on page 56

•

“Digit Sequence Examples,” on page 59

•

“Acceptance and Transmission the Dialed Digits,” on page 61

•

“Dial Plan Timer (Off-Hook Timer),” on page 62

•

“Interdigit Long Timer (Incomplete Entry Timer),” on page 63

•

“Interdigit Short Timer (Complete Entry Timer),” on page 63

Digit Sequences A dial plan contains a series of digit sequences, separated by the | character. The entire collection of sequences is enclosed within parentheses. Each digit sequence within the dial plan consists of a series of elements, which are individually matched to the keys that the presses.

NOTE White space is ignored, but may be used for readability.


56

4


Digit Sequence

Function

0 1 2 3 4 5 6 7 8 9 0 * #

Enter any of these characters to represent a key that the must press on the phone keypad.

x

Enter x to represent any character on the phone keypad.

[sequence]

Enter characters within square brackets to create a list of accepted key presses. The can press any one of the keys in the list.

. (period)

•

Numeric range For example, you would enter [2-9] to allow the to press any one digit from 2 through 9.

•

Numeric range with other characters For example, you would enter [35-8*] to allow the to press 3, 5, 6, 7, 8, or *.

Enter a period for element repetition. The dial plan accepts 0 or more entries of the digit. For example, 01. allows s to enter 0, 01, 011, 0111, and so on. For sequence substitution, use this format to indicate that certain dialed digits are replaced by other characters when the sequence is transmitted. The dialed digits can be zero or more characters. EXAMPLE 1: <8:1650>xxxxxxx When the presses 8 followed by a sevendigit number, the system automatically replaces the dialed 8 with 1650. If the dials 85550112, the system transmits 16505550112. EXAMPLE 2: <:1>xxxxxxxxxx In this example, no digits are replaced. When the enters a 10-digit string of numbers, the number 1 is added at the beginning of the sequence. If the dials 9725550112, the system transmits 19725550112


57

4


Digit Sequence

Function

,

For an intersequence tone, enter a comma between digits to play an “outside line” dial tone after a -entered sequence.

(comma)

EXAMPLE: 9, 1xxxxxxxxxx An “outside line” dial tone is sounded after the presses 9, and the tone continues until the presses 1. ! (exclamation point)

For number barring, enter an exclamation point to prohibit a dial sequence pattern. EXAMPLE: 1900xxxxxxx! The system rejects any 11-digit sequence that begins with 1900.

*xx

Enter an asterisk to allow the to enter a 2digit star code.

S0 or L0

For Interdigit Timer Master Override, enter S0 to reduce the short inter-digit timer to 0 seconds, or enter L0 to reduce the long inter-digit timer to 0 seconds.

P

For a pause, enter P followed by a number and a space. The duration of the pause is the specified number of seconds. This feature is typically used for implementation of a hot line and warm line, with 0 delay for the hot line and a non-zero delay for a warm line. EXAMPLE: P5

NOTE The SPA implicitly appends the vertical code sequences entered in the regional

parameter settings to the end of the dial plan. Likewise, if Enable_IP_Dialing is enabled, then IP dialing is also accepted on the associated line.


58

4


Digit Sequence Examples The following examples show digit sequences that you can enter in a dial plan. In a complete dial plan entry, sequences are separated by a pipe character (|), and the entire set of sequences is enclosed within parentheses. EXAMPLE: ( [1-8]xx | 9, xxxxxxx | 9, <:1>[2-9]xxxxxxxxx | 8, <:1212>xxxxxxx | 9, 1 [2-9] xxxxxxxxx | 9, 1 900 xxxxxxx ! | 9, 011xxxxxx. | 0 | [49]11 )

•

Extensions on your system EXAMPLE: ( [1-8]xx | 9, xxxxxxx | 9, <:1>[2-9]xxxxxxxxx | 8, <:1212>xxxxxxx | 9, 1 [2-9] xxxxxxxxx | 9, 1 900 xxxxxxx ! | 9, 011xxxxxx. | 0 | [49]11 ) [1-8]xx Allows a dial any three-digit number that starts with the digits 1

through 8. If your system uses four-digit extensions, you would instead enter the following string: [1-8]xxx

•

Local dialing with seven-digit number EXAMPLE: ( [1-8]xx | 9, xxxxxxx | 9, <:1>[2-9]xxxxxxxxx | 8, <:1212>xxxxxxx | 9, 1 [2-9] xxxxxxxxx | 9, 1 900 xxxxxxx ! | 9, 011xxxxxx. | 0 | [49]111) 9, xxxxxxx After a presses 9, an external dial tone sounds. The can enter any seven-digit number, as in a local call.

•

Local dialing with 3-digit area code and a 7-digit local number EXAMPLE: ( [1-8]xx | 9, xxxxxxx | 9, <:1>[2-9]xxxxxxxxx | 8, <:1212>xxxxxxx | 9, 1 [2-9] xxxxxxxxx | 9, 1 900 xxxxxxx ! | 9, 011xxxxxx. | 0 | [49]11 ) 9, <:1>[2-9]xxxxxxxxx This example is useful where a local area code is required.

After a presses 9, an external dial tone sounds. The must enter a 10digit number that begins with a digit 2 through 9. The system automatically inserts the 1 prefix before transmitting the number to the carrier.

•

Local dialing with an automatically inserted 3-digit area code EXAMPLE: ( [1-8]xx | 9, xxxxxxx | 9, <:1>[2-9]xxxxxxxxx | 8, <:1212>xxxxxxx | 9, 1 [2-9] xxxxxxxxx | 9, 1 900 xxxxxxx ! | 9, 011xxxxxx. | 0 | [49]11 )


59

4


8, <:1212>xxxxxxx This is example is useful where a local area code is required

by the carrier but the majority of calls go to one area code. After the presses 8, an external dial tone sounds. The can enter any seven-digit number. The system automatically inserts the 1 prefix and the 212 area code before transmitting the number to the carrier.

•

U.S. long distance dialing EXAMPLE: ( [1-8]xx | 9, xxxxxxx | 9, <:1>[2-9]xxxxxxxxx | 8, <:1212>xxxxxxx | 9, 1 [2-9] xxxxxxxxx | 9, 1 900 xxxxxxx ! | 9, 011xxxxxx. | 0 | [49]11 ) 9, 1 [2-9] xxxxxxxxx After the presses 9, an external dial tone sounds. The can enter any 11-digit number that starts with 1 and is followed by a digit 2 through 9.

•

Blocked number EXAMPLE: ( [1-8]xx | 9, xxxxxxx | 9, <:1>[2-9]xxxxxxxxx | 8, <:1212>xxxxxxx | 9, 1 [2-9] xxxxxxxxx | 9, 1 900 xxxxxxx ! | 9, 011xxxxxx. | 0 | [49]11 ) 9, 1 900 xxxxxxx ! This digit sequence is useful if you want to prevent s from

dialing numbers that are associated with high tolls or inappropriate content, such as 1-900 numbers in the U.S.. After the press 9, an external dial tone sounds. If the enters an 11-digit number that starts with the digits 1900, the call is rejected.

•

U.S. international dialing EXAMPLE: ( [1-8]xx | 9, xxxxxxx | 9, <:1>[2-9]xxxxxxxxx | 8, <:1212>xxxxxxx | 9, 1 [2-9] xxxxxxxxx | 9, 1 900 xxxxxxx ! | 9, 011xxxxxx. | 0 | [49]11 ) 9, 011xxxxxx. After the presses 9, an external dial tone sounds. The can

enter any number that starts with 011, as in an international call from the U.S.

•

Informational numbers EXAMPLE: ( [1-8]xx | 9, xxxxxxx | 9, <:1>[2-9]xxxxxxxxx | 8, <:1212>xxxxxxx | 9, 1 [2-9] xxxxxxxxx | 9, 1 900 xxxxxxx ! | 9, 011xxxxxx. | 0 | [49]11 ) 0 | [49]11 This example includes two digit sequences, separated by the pipe character. The first sequence allows a to dial 0 for an operator. The second sequence allows the to enter 411 for local information or 911 for emergency services.


60

4


Acceptance and Transmission the Dialed Digits When a dials a series of digits, each sequence in the dial plan is tested as a possible match. The matching sequences form a set of candidate digit sequences. As more digits are entered by the , the set of candidates diminishes until only one or none are valid. When a terminating event occurs, the SPA9000 either accepts the -dialed sequence and initiates a call, or else rejects the sequence as invalid. The hears the reorder (fast busy) tone if the dialed sequence is invalid. The following table explains how terminating events are processed. Terminating Event

Processing

The dialed digits do not match any sequence in the dial plan.

The number is rejected.

The dialed digits exactly match one sequence in the dial plan.

•

If the sequence is allowed by the dial plan, the number is accepted and is transmitted according to the dial plan.

•

If the sequence is blocked by the dial plan, the number is rejected.

A timeout occurs.

The presses the # key or the dial softkey on the phone display.


The number is rejected if the dialed digits are not matched to a digit sequence in the dial plan within the time specified by the applicable interdigit timer. •

The Interdigit Long Timer applies when the dialed digits do not match any digit sequence in the dial plan. The default value is 10 seconds.

•

The Interdigit Short Timer applies when the dialed digits match one or more candidate sequences in the dial plan. The default value is 3 seconds.

•

If the sequence is complete and is allowed by the dial plan, the number is accepted and is transmitted according to the dial plan.

•

If the sequence is incomplete or is blocked by the dial plan, the number is rejected.

61

4


Dial Plan Timer (Off-Hook Timer) You can think of the Dial Plan Timer as “the off-hook timer.” This timer starts counting when the phone goes off hook. If no digits are dialed within the specified number of seconds, the timer expires and the null entry is evaluated. Unless you have a special dial plan string to allow a null entry, the call is rejected. The default value is 5.

Syntax for the Dial Plan Timer SYNTAX: (Ps<:n> | dial plan )

•

s: The number of seconds; if no number is entered after P, the default timer of 5 seconds applies.

•

n: (optional): The number to transmit automatically when the timer expires; you can enter an extension number or a DID number. No wildcard characters are allowed because the number will be transmitted as shown. If you omit the number substitution, <:n>, then the hears a reorder (fast busy) tone after the specified number of seconds.

Examples for the Dial Plan Timer

•

Allow more time for s to start dialing after taking a phone off hook. EXAMPLE: (P9 | (9,8<:1408>[2-9]xxxxxx | 9,8,1[2-9]xxxxxxxxx | 9,8,011xx. | 9,8,xx.|[1-8]xx) P9 After taking a phone off hook, a has 9 seconds to begin dialing. If no

digits are pressed within 9 seconds, the hears a reorder (fast busy) tone. By setting a longer timer, you allow more time for s to enter the digits.

•

Create a hotline for all sequences on the System Dial Plan EXAMPLE: (P9<:23> | (9,8<:1408>[2-9]xxxxxx | 9,8,1[29]xxxxxxxxx | 9,8,011xx. | 9,8,xx.|[1-8]xx) P9<:23> After taking the phone off hook, a has 9 seconds to begin dialing. If no digits are pressed within 9 seconds, the call is transmitted automatically to extension 23.

•

Create a hotline on a line button for an extension EXAMPLE: ( P0 <:1000>) With the timer set to 0 seconds, the call is transmitted automatically to the specified extension when the phone goes off hook. Enter this sequence in the Phone Dial Plan for Ext 2 or higher on a client station.


62

4


Interdigit Long Timer (Incomplete Entry Timer) You can think of this timer as the “incomplete entry” timer. This timer measures the interval between dialed digits. It applies as long as the dialed digits do not match any digit sequences in the dial plan. Unless the enters another digit within the specified number of seconds, the entry is evaluated as incomplete, and the call is rejected. The default value is 10 seconds.

NOTE This section explains how to edit a timer as part of a dial plan. Alternatively, you can

modify the Control Timer that controls the default interdigit timers for all calls. See “Resetting the Control Timers,” on page 65.

Syntax for the Interdigit Long Timer SYNTAX: L:s, ( dial plan )

•

s: The number of seconds; if no number is entered after L:, the default timer of 5 seconds applies.

•

Note that the timer sequence appears to the left of the initial parenthesis for the dial plan.

Example for the Interdigit Long Timer EXAMPLE: L:15, (9,8<:1408>[2-9]xxxxxx | 9,8,1[2-9]xxxxxxxxx | 9,8,011xx. | 9,8,xx.|[1-8]xx) L:15, This dial plan allows the to pause for up to 15 seconds between digits

before the Interdigit Long Timer expires. This setting is especially helpful to s such as sales people, who are reading the numbers from business cards and other printed materials while dialing.

Interdigit Short Timer (Complete Entry Timer) You can think of this timer as the “complete entry” timer. This timer measures the interval between dialed digits. It applies when the dialed digits match at least one digit sequence in the dial plan. Unless the enters another digit within the specified number of seconds, the entry is evaluated. If it is valid, the call proceeds. If it is invalid, the call is rejected. The default value is 3 seconds.


63

4


Syntax for the Interdigit Short Timer

•

SYNTAX 1: S:s, ( dial plan ) Use this syntax to apply the new setting to the entire dial plan within the parentheses.

•

SYNTAX 2: sequence Ss Use this syntax to apply the new setting to a particular dialing sequence. s: The number of seconds; if no number is entered after S, the default timer of 5 seconds applies.

Examples for the Interdigit Short Timer

•

Set the timer for the entire dial plan. EXAMPLE: S:6, (9,8<:1408>[2-9]xxxxxx | 9,8,1[2-9]xxxxxxxxx | 9,8,011xx. | 9,8,xx.|[1-8]xx) S:6, While entering a number with the phone off hook, a can pause for up

to 15 seconds between digits before the Interdigit Short Timer expires. This setting is especially helpful to s such as sales people, who are reading the numbers from business cards and other printed materials while dialing.

•

Set an instant timer for a particular sequence within the dial plan. EXAMPLE: (9,8<:1408>[2-9]xxxxxx | 9,8,1[2-9]xxxxxxxxxS0 | 9,8,011xx. | 9,8,xx.|[1-8]xx) 9,8,1[2-9]xxxxxxxxxS0 With the timer set to 0, the call is transmitted automatically

when the dials the final digit in the sequence.


64

4


Editing Dial Plans You can edit dial plans and can modify the control timers. STEP 1 Start Internet Explorer, and then enter the IP address of the SPA9000. Click

and then click Advanced.

Entering the Line Interface Dial Plan This dial plan is used to strip steering digits from a dialed number before it is transmitted out to the carrier. STEP 1 Connect to the istration web server, and choose access with

Advanced settings. STEP 2 Click Voice tab > Line N, where N represents the line interface number. STEP 3 Scroll down to the Dial Plan section. STEP 4 Enter the digit sequences in the Dial Plan field. For more information, see “About

Dial Plans,” on page 56. STEP 5 Click Submit All Changes.

Resetting the Control Timers You can use the following procedure to reset the default timer settings for all calls.

NOTE If you need to edit a timer setting only for a particular digit sequence or type of call,

you can edit the dial plan. See “About Dial Plans,” on page 56.

STEP 1 Connect to the istration web server, and choose access with

Advanced settings. STEP 2 Click Voice tab > Regional. STEP 3 Scroll down to the Control Timer Values section. STEP 4 Enter the desired values in the Interdigit Long Timer field and the Interdigit Short

Timer field. Refer to the definitions at the beginning of this section.


65

4

Secure Call Implementation

Secure Call Implementation This section describes secure call implementation with the ATA device . It includes the following topics:

•

“Enabling Secure Calls” section on page 66

•

“Secure Call Details” section on page 67

•

“Using a Mini-Certificate” section on page 68

•

“Generating a Mini Certificate” section on page 68

NOTE This is an advanced topic meant for experience installers. See also the LVS

Provisioning Guide.

Enabling Secure Calls A secure call is established in two stages. The first stage is no different from normal call setup. The second stage starts after the call is established in the normal way with both sides ready to stream RTP packets. In the second stage, the two parties exchange information to determine if the current call can switch over to the secure mode. The information is transported by base64 encoding embedded in the message body of SIP INFO requests, and responses using a proprietary format. If the second stage is successful, the ATA device plays a special Secure Call Indication Tone for a short time to indicate to both parties that the call is secured and that RTP traffic in both directions is being encrypted. If the has a phone that s call waiting caller ID (CIDCW) and that service is enabled, the CID will be updated with the information extracted from the Mini-Certificate received from the remote party. The Name field of the CID will be prepended with a ‘$’ symbol. Both parties can the name and number to ensure the identity of the remote party. The g agent is implicit and must be the same for all ATAs that communicate securely with each other. The public key of the g agent is pre-configured into the ATA device by the and is used by the ATA device to the Mini-Certificate of its peer. The Mini-Certificate is valid if it has not expired, and it has a valid signature.


66

4


The ATA device can be configured so that, by default, all outbound calls are either secure or not secure. If secure by default, the has the option to disable security when making a call by dialing *19 before dialing the target number. If not secure by default, the can make a secure outbound call by dialing *18 before dialing the target number. However, the cannot force inbound calls to be secure or not secure; that depends on whether the caller has security enabled or not. The ATA device will not switch to secure mode if the CID of the called party from its Mini-Certificate does not agree with the -id used in making the outbound call. The ATA device performs this check after receiving the Mini-Certificate of the called party

Secure Call Details Looking at the second stage of setting up a secure call in greater detail, this stage can be further divided into two steps. STEP 1 The caller sends a “Caller Hello” message (base64 encoded and embedded in the

message body of a SIP INFO request) to the called party with the following information:

•

Message ID (4B)

•

Version and flags (4B)

•

SSRC of the encrypted stream (4B)

•

Mini-Certificate (252B)

Upon receiving the Caller Hello, the called party responds with a Callee Hello message (base64 encoded and embedded in the message body of a SIP response to the caller’s INFO request) with similar information, if the Caller Hello message is valid. The caller then examines the Callee Hello and proceeds to the next step if the message is valid. STEP 2 The caller sends the “Caller Final” message to the called party with the following

information:

•

Message ID (4B)

•

Encrypted Master Key (16B or 128b)

•

Encrypted Master Salt (16B or 128b)


67

4


Using a Mini-Certificate The Master Key and Master Salt are encrypted with the public key from the called party mini-certificate. The Master Key and Master Salt are used by both ends for deriving session keys to encrypt subsequent RTP packets. The called party then responds with a Callee Final message (which is an empty message). The Mini-Certificate (MC) contains the following information:

•

Name (32B)

•

ID or Phone Number (16B)

•

Expiration Date (12B)

•

Public Key (512b or 64B)

•

Signature (1024b or 512B)

The MC has a 512-bit public key used for establishing secure calls. The must provision each subscriber of the secure call service with an MC and the corresponding 512-bit private key. The MC is signed with a 1024-bit private key of the service provider, which acts as the CA of the MC. The 1024-bit public key of the CA g the MC must also be provisioned for each subscriber. The CA public key is used to the MC received from the other end. If the MC is invalid, the call will not switch to secure mode. The MC and the 1024-bit CA public key are concatenated and base64 encoded into the single parameter Mini Certificate. The 512-bit private key is base64 encoded into the SRTP Private Key parameter, which should be kept secret, like a . (Mini Certificate and SRTP Private Key are configured in the Line tabs.) Because the secure call establishment relies on exchange of information embedded in message bodies of SIP INFO requests/responses, the service provider must ensure that the network infrastructure allows the SIP INFO messages to through with the message body unmodified.

Generating a Mini Certificate Cisco provides a Mini Certificate Generator for the generation of mini certificates and private keys. Partners can the Mini Certificate Generator by going to Cisco Partner Central, Voice & Conferencing page, Technical Resources section. Use the following URL: http://www.cisco.com/web/partners/sell/smb/products/ voice_and_conferencing.html#~vc_technical_resources


68

4


NOTE The partner sites require a logon.

The Mini Certificate Generator uses the following syntax: gen_mc

ca-key -name -id expire-date

Where:

•

ca-key is a text file with the base64 encoded 1024-bit CA private/public key pairs for g/ing the MC, such as the following:

9CC9aYU1X5lJuU+EBZmi3AmcqE9U1LxEOGwopaGyGOh3VyhKgi6JaVtQZt87PiJINKW8XQj3B9Qq e3VgYxWCQNa335YCnDsenASeBxuMIEaBCYd1l1fVEodJZOGwXwfAde0MhcbD0kj7LVlzcsTyk2TZ YTccnZ75TuTjj13qvYs=5nEtOrkCa84/mEwl3D9tSvVLyliwQ+u/ Hd+C8u5SNk7hsAUZaA9TqH8Iw0J/ IqSrsf6scsmundY5j7Z5mK5J9uBxSB8t8vamFGD0pF4zhNtbrVvIXKI9kmp4vph1C5jzO9gDfs3M F+zjyYrVUFdM+pXtDBxmM+fGUfrpAuXb7/k=

•

-name is the name of the subscriber, such as “Joe Smith”. Maximum length is 32 characters

•

-id is the ID of the subscriber, which must match exactly the -id used in the INVITE when making the call, such as “14083331234”. The maximum length is 16 characters.

•

expire-date is the expiration date of the MC, such as “00:00:00 1/1/34” (34=2034). Internally the date is encoded as a fixed 12B string: 000000010134

The tool generates the Mini Certificate and SRTP Private Key parameters that can be provisioned. EXAMPLE: gen_mc ca_key “Joe Smith” 14085551234 “00:00:00 1/1/34”

This example produces the following Mini Certificate and SRTP Private Key: <Mini Certificate> Sm9lIFNtaXRoAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAxNDA4NTU1MTIzNAAAAAAAMDAwMDAwMDEw MTM00OvJakde2vVMF3Rw4pPXL7lAgIagMpbLSAG2+++YlSqt1989rP/ xMGFfoPmDKGx6JFtkQ5sxLcuwgxpxpxkeXvpZKlYlpsb28L4Rhg5qZA+Gqj1hDFCmG6dffZ9SJhx ES767G0JIS+N8lQBLr0AuemotknSjjjOy8c+1lTCd2t44Mh0vmwNg4fDck2YdmTMBR516xJt4/ uQ/ LJQlni2kwqlm7scDvll5k232EvvvVtCK0AYa4eWd6fQOpiESCO9CC9aYU1X5lJuU+EBZmi3AmcqE 9U1LxEOGwopaGyGOh3VyhKgi6JaVtQZt87PiJINKW8XQj3B9Qqe3VgYxWCQNa335YCnDsenASeBx uMIEaBCYd1l1fVEodJZOGwXwfAde0MhcbD0kj7LVlzcsTyk2TZYTccnZ75TuTjj13qvYs= <SRTP Private Key> b/DWc96X4YQraCnYzl5en1CIUhVQQqrvcr6Qd/8R52IEvJjOw/ e+Klm4XiiFEPaKmU8UbooxKG36SEdKusp0AQ==


69

SIP Trunking and Hunt Groups on the SPA8000

4

SIP Trunking and Hunt Groups on the SPA8000 The SPA8000 s SIP Trunking, which allows you to connect a traditional PBX to VoIP services. In this configuration, calls go through the ITSP rather than the PSTN, yet the call routing functionality is similar to that of traditional PSTN lines. You can configure up to four trunk groups for the purpose of inbound call routing and outbound caller identification. You can configure a trunk number on the SPA8000, such that an incoming call automatically rings the grouped lines simultaneously or in a specified order. For outbound calls, SIP Trunking ensures that all calls on a trunk line can be identified by the trunk number and a common caller ID. This feature helps you to ensure that calls are directed to available lines and that work groups such as sales teams can work together to answer calls. In addition, teams can project a common identity when placing outbound calls on a trunk. This section provides information about SIP trunking and explains how to configure your trunk groups. Refer to the following topics:

•

“About SIP Trunking,” on page 71

•

“Setting the Trunk Group Call Capacity,” on page 73

•

“Inbound Call Routing for a Trunk Group,” on page 73

•

“ List for a Trunk Group,” on page 74

•

“Outgoing Call Routing for a Trunk Group,” on page 76

•

“Configuring a Trunk Group,” on page 77

•

“Additional Notes About Trunk Groups,” on page 80

•

“Setting the Hunt Policy,” on page 80

•

“Trunk Group Management,” on page 78


70

4


About SIP Trunking The SIP Trunking feature allows a traditional PBX to seamlessly migrate from PSTN service to VoIP service over a broadband link. The SPA8000 offers up to eight telephone lines to the PBX.

Fax

PBX System

Fax

PBX System

Integrated Access Device

Internet

ITSP 194488

SPA8000

The SPA8000 offers four trunk groups, numbered T1, T2, T3, and T4. A SIP-based voice service with an ITSP can be configured on each trunk group with a distinct phone number. Each of the eight SPA8000 lines can be configured either as a standalone line, as in a classic ATA FXS port, or as a trunk line that is associated with a trunk group.

•

Inbound calling: A trunk group offers a single number for callers to call into the small business, with the capability to programmatically ring one or more trunk lines.

•

Outbound calling: When a PBX phone makes a call, the PBX selects one of the available trunk lines. The trunk line assumes the Caller ID of the trunk group.


71

4


The following figure shows a simplified logical block diagram of the SPA8000 with the SIP Trunking feature. Figure 1 Logical Block Diagram of SIP Trunking

Phone 1 Phone 2 Phone 3 Phone 4

L1 L2 L3 L4

Phone 5

L5

Phone 6

L6

Phone 7 Phone 8

ITSP

L7 L8 T1 Internal Proxy Server

RTP Path SIP Path

T2 T3 T4

•

SIP Path: As a standalone line, the SIP Agent (SIP UA) exchanges signaling directly with the ITSP equipment. As a trunk line, the Line UA exchanges signaling with the internal proxy server only. The Internal Proxy Server handles all SIP signalling between both ends of the call, from call establishment to termination.

•

RTP Path: Whether the line is standalone or a member of a trunk group, the Line UA exchanges RTP packets directly with the ITSP equipment.


72


4

NOTE Although the figure shows only one ITSP , each standalone line and each

Trunk Group can be configured with a different ITSP (with some limitations applied).

Setting the Trunk Group Call Capacity The ITSP may set a limit to the number of calls that can be made on a trunk group. You can configure a trunk group’s call capacity parameter to meet the requirements of the ITSP. Both incoming call and outgoing calls are counted towards this limit. The call capacity has the following impact on call handling: •

Inbound calls: When the limit is reached, the Trunk UA replies 486 to the caller.

•

Outbound calls: When the limit is reached, the Line UA plays a fast busy tone to the caller. Note that a trunk line can make an outgoing call only through its own trunk. If that trunk reaches full capacity, it will not attempt to failover to use other trunks.

You can configure this setting in the Voice tab > Trunk (T1 ... T4) page, Subscriber Information section, Call Capacity field. For more information, see “Configuring a Trunk Group,” on page 77.

Inbound Call Routing for a Trunk Group An incoming call is handled as follows: STEP 1 When an incoming call is detected by the Trunk UA, the UA first checks if there is

capacity to handle the call. If there is insufficient capacity, the UA rejects the call with a 486 response. STEP 2 If there is spare call capacity, the UA consults the List to determine which

line or lines to ring (that is, for the proxy to send SIP INVITE to), and starts “hunting.” (See “Configuring a Trunk Group,” on page 77) STEP 3 When a line is selected to ring, one or more PBX phones may be alerted, according

to the PBX features and configuration. STEP 4 The Caller ID of the external Caller is signaled by the Line UA out to the FXS port

using the configured Caller ID method (FSK, DTMF, etc.). The PBX must be able to detect Caller ID signal in order for the proper Caller ID to show.


73


4

STEP 5 If the call is picked up by the PBX, the Line UA replies 200 OK with SDP to the

internal Proxy. The Trunk UA in turn replies 200 OK to the ITSP and relay the Line SDP in the 200 OK message also. If all goes well, the Line UA and the ITSP equipment start exchanging RTP packets afterwards.

List for a Trunk Group The hunting process for incoming calls is controlled by the List. The List specifies the lines to ring, the order in which to ring them, the duration to ring one line before trying another line, and the maximum period to hunt. Below, the syntax is described and examples are provided to help you to configure the List for each trunk group. SYNTAX: line[,line[,line[…]]],hunt=hrule[,cfwd=target]

•

•

line: The line numbers (1 - 8), or a wildcard * or ? to represent all lines. •

The Trunk UA rings only trunk lines, that is, lines that are assigned to a trunk group through the Voice tab > Line page, Trunk Group field. The Trunk UA does not ring any standalone lines that are included in the List. The Trunk UA rings any trunk line that is included in the list, even if it is not assigned to the particular trunk group for this List.

•

You can instruct the SPA8000 to hunt only the phones that are on-hook, through the Voice tab > SIP page, Trunking Parameters section, Hunt Policy field. See “Setting the Hunt Policy,” on page 80.

hunt=hrule: The hunt order, ring interval, and maximum duration, in the following format: hunt=algo;interval;max •

algo: The hunt order. -

re: Restart. Hunting starts at the beginning of the list. If the first line does not answer within the specified interval (see below), the hunt proceeds through the lines in sequential order.

-

ne: Next. The Trunk UA determines the line that was chosen in the previous hunt, and hunting starts with the next line in the list. If that line does not answer within the specified interval (see below), the hunt proceeds through the lines in sequential order.

-

ra: Random order. The Trunk UA randomly chooses a line from the list. If the selected line does not answer within the specified interval (see


74


4

below), the hunt proceeds randomly through the unchosen lines until each line is tried. -

•

al: All. The Trunk UA rings all the lines at the same time.

•

interval: The number of seconds to wait for one line to answer, before choosing another line. If interval is *, the hunt is stopped at the first line that starts ringing, and rings the line until it answers, or the caller hangs up, or the line's ringer times out.

•

max: The maximum duration of the hunt, either in seconds or cycles. When this limit is reached, the call is rejected or is forwarded to the specified call forward number (see below). -

If max is greater than interval, it represents the total time in seconds to hunt.

-

If max is less than interval, it represents the maximum number of times to cycle through the hunt group. If max is 0, hunting continues indefinitely until the caller either hangs up or the call is answered. Exceptions: This value is ignored if algo = all, or interval = * (but it must be present and should be set to 1).

cfwd=target: If the call is unanswered and the maximum hunting duration has been met, the call is forwarded to the specified number. When forwarding the call, the SPA8000 sends a 302 response to the ITSP.

NOTE The call forward settings for the individual lines are ignored during hunting. Instead,

the cfwd settings in the List are used. EXAMPLES:

•

1,2,3,4,5,6,7,8,hunt=re;*;1 Lines 1 through 8 are included (1,2,3,4,5,6,7,8). The hunt starts at the beginning of the list (hunt=re). When an available line is found, the call stays with the line until the call is either answered, rejected, or cancelled by the caller (* is entered for interval).

•

?,hunt=al;30;1,cfwd=14085550100 A wildcard character (?) is used to represent “all trunk lines.” All lines ring simultaneously (hunt=al). If there is no answer after 30 seconds (30), the call is forwarded to the specified number (cfwd=14085550100).


75


4

•

?,hunt=ra;12;1,cfwd=14085550123 A wildcard character is used to represent “all trunk lines.” The Trunk UA chooses lines in random order (hunt=ra). If a selected line does not answer within 12 seconds (12), the Trunk UA chooses another line at random. If there is no answer after 1 cycle (1), the call is forwarded to forwarded to the specified number (cfwd=14085550123).

•

?,hunt=ra;*;1,cfwd=14085550155 A wildcard character is used to represent “all trunk lines.” The Trunk UA chooses lines in random order (hunt=ra). The interval is *, meaning the hunt stops when a selected line starts ringing, and will ring the line until it answers, or the caller hangs up, or the line's ringer times out. If the ringer times out, the call is automatically forwarded to the specified number (cfwd=14085550155).

Outgoing Call Routing for a Trunk Group Outbound calls on a trunk line are handled as follows: STEP 1 When a PBX phone selects an outside line, the PBX looks for an open line. If the

PBX finds an open line, it takes the line off hook and bridges the audio between the PBX phone and the line. On detecting the off hook signal, the SPA8000 Line UA plays dial tone and ready to collect digits from the PBX phone. STEP 2 As the PBX phone dials the number, the Line UA applies its dial plan to the

number. If the Line UA detects an invalid number, it rejects the all by playing reorder tone, then howling tone, then silence. If a valid number is received, it sends a SIP INVITE message to the internal Proxy. STEP 3 The Proxy routes the call to the trunk group UA for the line, and the trunk group UA

will attempt to place the call to the ITSP if there is available capacity on the trunk. If there is no call capacity left on the trunk, the internal Proxy will reject the INVITE from the Line UA, which in turn terminates the call and plays reorder tone out to the FXS port.

NOTE The SPA8000 will also apply the Trunk Dial Plan on the number before sending out

INVITE to the ITSP. This Trunk Dial Plan typically is redundant since the trunk should trust the number sent by the Line UA. By default the trunk dial plan allows any nonempty number: ([*#0-9A-D][*#0-9A-D].)


76

4


Configuring a Trunk Group To configure a hunt group, you must first specify the trunk lines by asg lines to trunk groups. Then you enter the information, specify the call capacity, and configure the List. Before you begin this procedure, determine which lines you want to associate with each trunk group that you are configuring. Refer to the following example:

Line

Trunk Group

1, 3, 5

T1

4, 6, 8

T2

2

None

STEP 1 Connect to the istration web server, and choose access with

Advanced settings. STEP 2 Assign each line to a trunk group, as needed:

a. Click Voice tab > Ln, where n represents the number of the line interface. b. In the Trunk Group field, near the top of the line configuration page, choose a trunk number or choose none for a standalone line (the default setting). c. Repeat this step for each line that you want to add to a trunk group. Voice > Ln > Trunk Group field


77


4

STEP 3 Enter the settings for each trunk group, as needed:

a. Click Voice tab > Tn, where n represents the trunk group number (T1 ... T4). b. Enter the information in the Subscriber Information section. •

Display Name: The Caller ID that you want to use for outbound calls on this line

•

ID: Your number with the ITSP (usually the telephone number)

•

: Your for this ITSP

c. In the Call Capacity field, enter the maximum number of concurrent calls allowed by your ITSP, or leave the default setting, unlimited (16 calls). d. In the List field, modify the list as needed. See “ List for a Trunk Group,” on page 74. e. Repeat this step for each trunk group that you need to configure. STEP 4 Click Submit All Changes.

Trunk Group Management You can check the status of the trunks by clicking the Trunk Status link, which appears both at the top right corner of the web page and at the lower left corner.

You also can connect directly to the Trunk Status Page by entering the following URL: http://spa8000-ip-addr/status. This page is available with the or the .


78

4


Trunk Status page

The Trunk Status page shows all calls that are currently active on each trunk group. This page shows a snapshot of the trunk activity. You can refresh the data at any time by clicking the Refresh button on the web browser toolbar. The page shows the following information:

•

External: The called number

•

Station: The SPA8000 line that is in use for this call

•

Direction: The direction of the call, either Outbound or Inbound

•

State: The state of the call

•

•

Calling: An outbound call was initiated but is not ringing at the other end.

•

Proceeding: The outbound call is ringing at the other end.

•

Ringing: An inbound call is ringing.

•

Connected: The call is connected.

Duration: The duration of the call

In the case of a hung call, you can select the check box for the call and then click the Delete button to cancel the call.


79


4

Setting the Hunt Policy You can configure the SPA8000 so that the hunt rule applies to all phone or only to the phones that are on hook. STEP 1 Connect to the istration web server, and choose access with

Advanced settings. STEP 2 Click Voice tab > SIP. STEP 3 Scroll down to the Trunking Parameters section. STEP 4 In the Hunt Policy field, choose the desired option:

•

onhook only: The hunt includes only the phones that are on hook.

•

any state: The hunt includes all phones regardless of the state.

STEP 5 Click Submit All Changes.

Additional Notes About Trunk Groups This section includes information about other topics that may be of interest when you are configuring trunk groups:

•

Voice mail: There is no individual mail box for a trunk line. For example, if lines 1, 2, 3, and 4 belong the trunk group T1, then the four lines implicitly share the same voice mail box from the ITSP. When there is new voice mail waiting in the trunk mail box, the UAs for all four lines will be notified by the ITSP via the internal Proxy, and all four lines will show the message waiting indicator, such as by playing stutter dial tone, if enabled by the .

•

Supplementary features: Supplementary features are offered at the line level only, not at the trunk level. Via the PBX, the phone can trigger/control supplementary service and settings by signaling to the line port or configuring the line parameters. For more information, refer to the Appendix B, “ATA Voice Field Reference.”


80

5 Configuring Music on Hold

This chapter explains how to configure Music on Hold using either a music file or streaming audio. This chapter includes the following topics:

•

“Using the Internal Music Source for Music On Hold,” on page 81

•

“Configuring a Streaming Audio Server,” on page 83

Using the Internal Music Source for Music On Hold An internal music source with the ID imusic is available. It plays an internally stored music file repeatedly. The unit ships with a default music file (Romance de Amor). You can override this file by ing a new file into the unit by using TFTP. Refer to the following topics:

•

“Using the Internal Music Source,” on page 81

•

“Changing the Music File for the Internal Music Source,” on page 82

Using the Internal Music Source To use the internal music source, simply identify imusic as the MOH server for each IP phone. STEP 1 Use the phone menu to find the IP address of the phone:

a. Press the Setup button on the phone keypad. b. Press 9 - Network, and then scroll down to 2- Current IP Address.


81

Configuring Music on Hold Using the Internal Music Source for Music On Hold

5

STEP 2 Start Internet Explorer, and then enter the IP address of the telephone. The

Telephone Configuration page appears in a separate browser window. STEP 3 Click , and then click Advanced. STEP 4 Click the Ext 1 tab. STEP 5 Scroll down to the Call Feature Settings section. STEP 6 Enter the following value in the MOH Server field: imusic STEP 7 Click Submit All Changes. STEP 8 To , place a test call to the extension. When the call is answered and put on

hold, the caller should hear the default music file (Romance de Amor).

Changing the Music File for the Internal Music Source The following resources are required to change the music file for the internal music source:

•

TFTP server software

•

The IP address of the istration computer that is connected to the SPA9000

•

A music source in G.711u format, sampled at 8000 samples/sec, up to 65.5 seconds in length, with no header information

STEP 1 Before you begin, make sure that you have TFTP server software running on your

computer. STEP 2 Start Internet Explorer, connect to the istration web server, and choose

access with Advanced settings. STEP 3 Click Voice tab > SIP. STEP 4 Scroll down to the Internal Music Source Parameters section. STEP 5 Enter the following URL in the Internal Music URL field:

tftp://server_IPaddress:portpath

•

server_IPaddress: The local IP address of the computer you are using as the TFTP server

•

port: The port number used by the TFTP server (default 69)


82

Configuring Music on Hold Configuring a Streaming Audio Server

5

•

path: The location and name of a music file in the correct format

•

For example, if the computer local IP address is 192.168.0.5, the directory is named musicdir, and the converted music file is named jazzmusic.dat , then you would enter the following URL: tftp://192.168.0.5:69/musicdir/ jazzmusic.dat

STEP 6 Click Submit All Changes. The unit reboots. Then the unit s the file and

stores it in flash memory.

Configuring a Streaming Audio Server This section describes how to use and configure a streaming audio server (SAS). It includes the following topics:

•

“About the Streaming Audio Server,” on page 83

•

“Configuring the Streaming Audio Server,” on page 85

•

“Using the IVR with an SAS Line,” on page 86

About the Streaming Audio Server The Streaming Audio Server (SAS) feature lets you attach an audio source to an FXS port and use it as a streaming audio source device. If the unit has multiple FXS ports, either or both of the associated lines can be configured as an SAS server. Use a media signal adapter or “music coupler” to connect an Ethernet cable from a media source to the FXS port. For example, the MC-9700 Music Coupler has been tested with ATA devices and is available at the following URL: www.neogadgets.com/cart/ cart.php?target=product&product_id=17&substring=music+coupler


83

5


After you complete the required configuration, the FXS port is ready to stream audio. The functionality depends on the hook state of the FXS port:

•

If the FXS port is off hook, an incoming call is answered automatically and audio is streamed to the calling party.

NOTE Each SAS server can maintain up to five simultaneous calls. If the

second line on the unit is disabled, then the SAS line can maintain up to 10 simultaneous calls. Further incoming calls receive a busy signal (SIP 486 Response).

•

If the FXS port is on-hook when the incoming call arrives, a SIP 503 response code is transmitted to indicate “Service Not Available.”

•

If an incoming call is auto-answered, but later the FXS port changes to on-hook, the call is not terminated but continues to stream silence packets to the caller.

•

The SAS line can be set up to refresh each streaming audio session periodically using a SIP re-INVITE message, which detects if the connection to the caller is down. If the caller does not respond to the refresh message, the SAS line terminates the call so that the streaming resource can be used for other callers.

Additional information:

•

The SAS line does not ring for incoming calls even if the attached equipment is on-hook.

•

If no calls are in session, battery is removed from tip-and-ring of the FXS port. Some audio source devices have an LED to indicate the battery status. This can be used as a visual indication as to whether audio streaming is in progress.

•

Call Forwarding, Call Screening, Call Blocking, DND, and Caller-ID Delivery features are not available on an SAS line.


84


5

Configuring the Streaming Audio Server Use the following procedure to configure an SAS with an external music source. STEP 1 Connect an RJ-11 adapter between the music source (a CD player or iPod, for

example) and an FXS port. STEP 2 Start Internet Explorer, connect to the istration web server, and choose

access with Advanced settings. STEP 3 Configure the FXS port:

a. Click Voice tab > FXS N, where N represents the number of the FXS port where you connected the cable from the external music source. b. In the Subscriber Infomation section, enter the following settings: •

Display Name: Enter an extension number of name for the FXS 1 port, such as Receptionist Area Fax Machine.

•

ID: Enter a three- to four-digit extension number that is not is use by another extension.

c. In the Streaming Audio Server (SAS) section, choose yes from the SAS Enable drop-down list. STEP 4 Click Submit All Changes. STEP 5 Configure each phone to use this audio source as the MOH server:

a. Click the PBX Status link to view the list of phones. b. In the list, find the phone that you want to configure, and then click the hyperlink in the IP Address column. The Telephone Configuration page appears in a separate window. c. Click the Ext 1 tab. d. Scroll down to the Call Feature Settings section. e. In the MOH Server field, enter the extension number that you assigned to the FXS port for the streaming audio server. f.

Click Submit All Changes.


85


5

g. Close the window for the Telephone Configuration page. h. Repeat this step to configure each phone, as needed.

Using the IVR with an SAS Line The IVR can still be used on an SAS line, but the needs to follow the following steps: STEP 1 Power off the ATA device. STEP 2 Connect a phone to the port and make sure the phone is on-hook. STEP 3 Power on the ATA device. STEP 4 Pick up handset and press * * * * to invoke IVR in the usual way.

If the ATA device boots and finds that the SAS line is on-hook, it does not remove battery from the line so that IVR may be used. But if the ATA device boots up and finds that the SAS line is off-hook, it removes battery from the line because no audio session is in progress.


86

6 Configuring the PSTN (FXO) Gateway on the SPA3102

This chapter describes how to configure the PSTN gateway on the SPA3102 and the SPA8800.

•

“Connecting to PSTN and VoIP Services” section on page 87

•

“How VoIP-To-PSTN Calls Work” section on page 88

•

“How PSTN-To-VoIP Calls Work” section on page 90

•

“Configuring VoIP Failover to PSTN” section on page 93

•

“Sharing One VoIP Between the FXS and PSTN Lines (SPA3102)” section on page 93

•

“Other Options” section on page 94

•

“Call Scenarios” section on page 95

Connecting to PSTN and VoIP Services Both the SPA3102 and the SPA8800 allow your analog and IP phones to participate in calls over the VoIP network and the PSTN. Both devices provide a VoIP-To-PSTN calling function, which is referred to as a PSTN gateway, as well as a PSTN-To-VoIP calling function, which is referred to as a VoIP gateway. These ATAs function somewhat differently because they are designed to meet different business needs. •

The SPA3102 is designed to work independently as a PSTN gateway and VoIP gateway, without relying on a PBX for call control. -

FXS Port: The SPA3102 has 1 FXS port that you can connect to a standard analog telephone or fax machine. Configure the FXS settings by using the SPA3102 Line page.


87

Configuring the PSTN (FXO) Gateway on the SPA3102 How VoIP-To-PSTN Calls Work

-

•

6

FXO Port: The SPA3102 has 1 FXO port that you can connect to the PSTN. Configure the FXO settings by using the SPA3102 PSTN Line page.

The SPA8800 is designed to work with your PBX as a PSTN gateway and a VoIP gateway. Call control is provided by a standard PBX, an Asteriskbased IP PBX, the SPA9000 Voice System, or an Internet-based call control system. -

FXS Port: The SPA8800 has 4 FXS ports that you can connect to standard analog telephones or fax machines. Configure the FXS settings by using the SPA8800 Phone 1-4 pages.

-

FXO Port: The SPA8800 has 4 FXO port sthat you can connect to the PSTN. Configure the FXO settings by using the SPA8800 Line 1-4 pages.

How VoIP-To-PSTN Calls Work To obtain PSTN services through the SPA3102 or the SPA8800, the VoIP caller establishes a connection with the PSTN Line by way of a standard SIP INVITE request addressed to the PSTN Line.

One-Stage Dialing (SPA3102 and SPA8800) One-stage dialing allows a call to be started over VoIP and then immediately get a dial tone on the PSTN. When you take a phone off hook and dial a number, the call is automatically routed to the VoIP or the PSTN, based on the dial plan. On the SPA3102, you can enable HTTP Digest Authentication. In this case, the SPA3102 challenges the INVITE with a 401 response if it does not have a valid Authorization header. The Authorization header should include a < ID n> parameter, where n refers to one of eight VoIP s that can be configured on the ATA device. The credentials are computed based on the corresponding using Message Digest 5 (MD5). The < ID n> parameter must match one of the VoIP s stored on the ATA device. You can configure these settings on the Voice tab > PSTN Line page. For more information, see “VoIP s and s (HTTP Authentication) section,” on page 208.


88

Configuring the PSTN (FXO) Gateway on the SPA3102 How VoIP-To-PSTN Calls Work

6

Two-Stage Dialing (SPA3102) In two-stage dialing, the SPA3102 takes the FXO port off-hook but does not automatically dial any digits after accepting the call. To invoke two-stage dialing, the VoIP caller should INVITE the PSTN Line without the -id in the Request-URI or with a -id that matches exactly the < ID n> of the PSTN Line. A different -id in the Request-URI is treated as a request for one-stage dialing if onestage dialing is enabled, or dropped by the SPA3102 (as if no -id is given) if one-stage dialing is disabled. HTTP Digest Authentication can be also used for two-stage dialing, as in onestage dialing. If using HTTP Digest Authentication or Authentication is disabled, the VoIP caller should hear the PSTN dial tone right after the call is answered (by a SIP 200 response). You also can enable PIN authentication. In this case, the VoIP caller is prompted to enter a PIN number after the SPA3102 answers the call. The PIN number must end with a # key. The inter-PIN-digit timeout is 10 seconds (not configurable). Up to eight VoIP caller PIN numbers can be configured on the SPA3102. A dial plan can be selected for each PIN number. If the caller enters a wrong PIN or the SPA3102 times out waiting for more PIN digits, the SPA3102 tears down the call immediately with a BYE request. The call scenarios may involve the following types of callers:

•

VoIP caller—Someone who calls the ATA device via VoIP to obtain PSTN service

•

VoIP —A VoIP caller that has a (-id and ) on the SPA3102

•

PSTN caller—Someone who calls the ATA device from the PSTN to obtain VoIP service

VoIP callers can be authenticated by one of the following methods:

•

No Authentication—All callers are accepted for service.

•

PIN—Caller is prompted to enter a PIN right after the call is answered.

•

HTTP digest—SIP INVITE must contain a valid authorization header.

PSTN callers can be authenticated by one of the following methods:

•

No authentication—All callers are accepted for service.

•

PIN—Caller is prompted to enter a PIN right after the call is answered.


89

Configuring the PSTN (FXO) Gateway on the SPA3102 How PSTN-To-VoIP Calls Work

6

NOTE When the source address of the INVITE is 127.0.0.1, authentication is automatically

disabled because this is a call by the local . This applies to both one-stage and two-stage dialing. These settings can be configured on the SPA3102 PSTN Line page. See “VoIPTo-PSTN Gateway Setup section,” on page 206.

How PSTN-To-VoIP Calls Work For PSTN-to-VoIP calls, the basic PSTN-to-VoIP call flow is as follows: 1. When a PSTN call comes in to the ATA device and is unanswered (after a configurable number of rings), then the ATA device takes the FXO port off hook. 2. The ATA device plays dial tone. 3. The PSTN caller enters the target telephone number. The collected digits are processed by the default dial plan. On the SPA3102, you can add PIN authentication to the basic flow: 1. When a PSTN call comes in to the ATA device and is unanswered (after a configurable number of rings), then the ATA device takes the FXO port off hook. 2. The SPA3102 prompts the caller to enter the PIN number followed by the # key. 3. The SPA3102 compares the PIN to the configured PSTN PIN values. •

If the PIN matches one of the configured PSTN PIN values, then the SPA3102 plays dial tone. The caller enters the telephone number and the collected digits are processed by the dial plan associated with the PIN number. (These dial plans are configured on the Voice Voice tab > PSTN Line page, Dial Plans section.)

•

If the PIN does not match one of the configured PSTN PIN values, then the ATA device plays the reorder tone and then takes the FXO port on-hook.


90

Configuring the PSTN (FXO) Gateway on the SPA3102 How PSTN-To-VoIP Calls Work

6

NOTE For information about configuring the timer values for the above scenarios, see

“FXO (PSTN) Timer Values (sec) section,” on page 209. For information about configuring caller authentication on the SPA3102, see “VoIPTo-PSTN Gateway Setup section,” on page 206.

Terminating Gateway Calls There are two call legs in a PSTN gateway call: the PSTN call leg and the VoIP call leg. A gateway call is terminated when either call leg is ended. When the call terminates, the FXO port goes on-hook so the PSTN line is available for use. The ATA device detects that the PSTN call leg is ended when one of the following conditions occurs during a call: •

The PSTN Line voltage drops to a very low value (this occurs if the line is disconnected from the PSTN service or if the PSTN switch provides a C signal).

•

A polarity reversal or disconnect tone is detected at the FXO port.

•

There is no voice activity for a configurable period of time in either direction at the FXO port.

When any of the above conditions occur, the ATA device takes the FXO port on hook and sends a BYE request to end the VoIP call leg. On the other hand, when the ATA device receives a SIP BYE from the VoIP during a call, it takes the FXO port on hook to end the PSTN call leg. In addition, the ATA device can also send a refresh signal periodically to the VoIP call leg to determine whether the call leg is still up. If a refresh operation fails, the ATA device ends both call legs. On the SPA3102, these settings can be configured on the Voice tab > PSTN Line page. For more information, see “PSTN Disconnect Detection section,” on page 211. On the SPA8800, these settings can be configured on the Voice tab > Phone page. For more information, see “FXS Port Polarity Configuration section,” on page 177.


91

6

Configuring the PSTN (FXO) Gateway on the SPA3102 VoIP Outbound Call Routing (SPA3102)

VoIP Outbound Call Routing (SPA3102) On the SPA3102, calls made from Line 1 are routed through the configured Line 1 service provider, by default. You can override this behavior by IP dialing, through which the calls can be routed to any IP address that the enters. The SPA3102 allows flexible call routing with four sets of gateway parameters and configurable dial plans. These settings are configured on the SPA3102 Voice tab > Line page. See “Gateway s section (SPA3102),” on page 174.

NOTE The PBX handles outbound call routing for the SPA8800.

You can specify Gateways 1 to 4 in a dial plan by using the identifiers gw1, gw2, gw3, or gw4. Also, gw0 represents the internal PSTN gateway via the FXO port. You can specify in the dial plan to use gwx (x = 0,1,2,3,4) when making certain calls. In general, you can specify any gateway address in the dial plan. In addition, three parameters are added that can be used with call routing:

•

usr: -id used for authentication with the given gateway

•

pwd: used for authentication with the given gateway

•

nat: Enable or disable NAT mapping when calling the gateway

The following table lists some examples. Example

Description

<9,:>xx.<:@gw1

Dial 9 to start outside dial tone, followed by one or more digits, and route the call to Gateway 1.

[93]11<:@gw0>

Route 911 and 311 calls to the local PSTN gateway

<8,:1408>xxxxxxx<:@pstn. cisco.com:5061;usr=joe; pwd=joe_pwd;nat>

Dial 8 to start outside dial tone, prepend 1408 followed by seven digits, and route the call to pstn.cisco.com:5061, with -id = joe, and pwd = bell_pwd, and enable NAT mapping

<8,:1408>xxxxxxx<:@gw2:5061; usr=”Alex Bell”;pwd= ”anything”;nat=no>

Dial 8 to start outside dial tone, prepend 1408 followed by seven digits, and route the call to Gateway 2, but use the given port, -id, and , and no pstn.cisco.com:5061, and with -id = “Alex Bell” and pwd = bell_pwd, and disable NAT mapping


92

Configuring the PSTN (FXO) Gateway on the SPA3102 Configuring VoIP Failover to PSTN

6

You can set up multiple PSTN gateways at different locations and configure Line 1 to use a different gateway when dialing specific numbers.

Configuring VoIP Failover to PSTN When power is disconnected from the ATA, the FXS port is connected to the FXO port. In this case, the telephone attached to the FXS port is electrically connected to the PSTN service via the FXO port. When power is applied to the ATA device, the FXS port is disconnected from the FXO port. However, if the PSTN line is in use when the power is applied to the ATA device, the relay is not flipped until the PSTN line is released. This feature ensures that the ATA device does not interrupt any call in progress on the PSTN line. When Line 1 VoIP service is down (because of registration failure or loss of network link), the ATA device can be configured to automatically route all outbound calls to the internal gateway using the parameter listed below. For SPA3102, you can configure this setting on the Voice tab > Line page. For SPA8800, you can configure this setting on the Voice tab > Phone page. For more information, see “VoIP Fallback to PSTN section (SPA3102 and SPA8800),” on page 175.

Sharing One VoIP Between the FXS and PSTN Lines (SPA3102) On the SPA3102, both the FXS (Line 1) and FXO (PSTN Line) can receive incoming calls for a single VoIP if they are different ports. Consider the following points: •

If the service provider allows multiple registration s and simultaneous ringing, both lines can periodically with the service provider. In this case, both lines receive inbound calls to this VoIP . The PSTN Line should be configured with a sufficiently long answer delay before the call is automatically answered to allow for the function of the PSTN gateway.

•

If the service provider does not allow more than one , the PSTN Line should not . In this case, only Line 1 rings on the inbound call to this VoIP because it is the only line ed with the service provider.


93

Configuring the PSTN (FXO) Gateway on the SPA3102 Other Options

6

•

Line 1 can have the call forwarded to the PSTN Line after a few seconds using the Call-Forward-On-No-Answer feature with gw0 as the forward destination. Similarly, Line 1 can apply Call-Forward-All, Call-Forward-OnBusy, and Call-Forward-Selective feature, and direct the caller to the PSTNGateway.

•

Only PIN authentication is allowed when a VoIP caller is forwarded to the PSTN-gateway from Line 1. If HTTP Authentication is used, the caller is not authenticated.

•

When using the Forward-To-GW0 feature, you can forward the caller to a specific PSTN number, using the syntax @gw0 in the forward destination. When using this with Call-Forward-Selective, you can develop some interesting applications. For example, you can forward all callers with 408 area code to 14081234567, or all callers with 800 area code to 18005558355 (This is the number for Tell Me). When this syntax is used, authentication is not used and the target PSTN number is automatically dialed by the ATA device after the caller is forwarded to gw0.

Other Options This section describes other options provided by the SPA3102 and the SPA8800:

•

“PSTN Call to Ring Line 1 (SPA3102)” section on page 94

•

“Symmetric RTP (SPA3102 and SPA8800)” section on page 94

•

“Call Progress Tones (SPA3102 and SPA8800)” section on page 95

PSTN Call to Ring Line 1 (SPA3102) On the SPA3102, this feature allows a PSTN caller to ring Line 1. When the PSTN line rings, the PSTN Line makes a local VoIP call to Line 1. If Line 1 is busy, it stops. After a given number of rings, the VoIP gateway picks up the call.

Symmetric RTP (SPA3102 and SPA8800) The Symmetric RTP parameter is used to send audio RTP to the source IP and port of the inbound RTP packets. This facilitates NAT traversal. See “SIP Parameters section,” on page 122.


94

Configuring the PSTN (FXO) Gateway on the SPA3102 Call Scenarios

6

Call Progress Tones (SPA3102 and SPA8800) The SPA3102 and the SPA8800 have configurable call progress tones. Call progress tones are generated locally on the ATA, so an end is advised of status (such as ringback). Parameters for each type of tone (for instance a dial tone played back to an end ) may include the following specifications:

•

Number of frequency components

•

Frequency and amplitude of each component

•

Cadence information

When one VoIP is shared between the FXS and PSTN Lines, the following parameters are recommended to be set. For more information, see the Regional page in the “ATA Voice Field Reference,” on page 110.

Call Progress Tone

Description

VoIP PIN Tone

This tone is played to prompt a VoIP caller to enter a PIN number.

PSTN PIN Tone

This tone is played to prompt a PSTN caller to enter a PIN number.

Outside Dial Tone

During two-stage PSTN-gateway dialing and with a dial plan assigned, the ATA device collects digits from the VoIP caller and processes the number using the dial plan. The ATA device plays the Outside Dial Tone to prompt the VoIP caller to enter the PSTN number. This tone should be specified to sound different from the PSTN dial tone.

Call Scenarios This section describes some typical scenarios where the ATA device can be applied. Some are introduced in the first few sections and reused in later sections. This section includes the following topics:

•

“PSTN to VoIP Call with and Without Ring-Thru” section on page 96

•

“VoIP to PSTN Call With and Without Authentication” section on page 96

•

“Call Forwarding to PSTN Gateway (SPA3102 and SPA8800)” section on page 98


95


6

PSTN to VoIP Call with and Without Ring-Thru The PSTN caller calls the PSTN line connected to the FXO port. Ring-Thru is disabled. After the call rings for a delay equal to the value in PSTN Answer Delay, the VoIP gateway answers the call and prompts the PSTN caller to enter a PIN number (assuming PIN authentication is enabled). After a valid PIN is entered, the caller is prompted to dial the VoIP number. A dial plan is selected according to the PIN number entered by the caller. If authentication is disabled, the default PSTN dial plan is used. Note than the dial plan choice cannot be 0 for a PSTN caller.

NOTE A PSTN Access List in of Caller ID (ANI) patterns can be configured into the

ATA device to automatically grant access to the PSTN caller without entering the PIN. In this case, the default PSTN dial plan is also used. The same scenario can be implemented using Ring-Thru. When the PSTN line rings, Line 1 rings also. This feature is called Ring-Thru. If Line1 is picked up before the VoIP gateway auto-answers, it is connected to the PSTN call. Line 1 hears a call waiting tone if it is already connected to another call.

VoIP to PSTN Call With and Without Authentication This section describes three scenarios with and without authentication and includes the following topics:

•

“Using PIN Authentication (SPA3102)” section on page 96

•

“Using HTTP Digest Authentication (SPA3102)” section on page 97

•

“Without Authentication (SPA3102 and SPA8800)” section on page 98

Using PIN Authentication (SPA3102) This scenario assumes that the PSTN Line has a different VoIP than the Line 1 . The VoIP caller calls the FXO number, which auto-answers after VoIP Answer Delay. The ATA device then prompts the VoIP caller for a PIN. When a valid PIN is entered, the ATA plays the Outside Dial Tone and prompts the caller to dial the PSTN number.


96


6

The number dialed is processed by the dial plan corresponding to the VoIP caller. If the dial plan choice is 0, no dial plan is needed and the hears the PSTN dial tone right after the PIN is entered. If the dial plan choice is not 0, the final number returned from the dial plan after the complete number is dialed by the caller is dialed to the PSTN. The caller does not hear the PSTN dial tone (except for a little leakage before the first digit of the final number is auto-dialed by the ATA device). If the PSTN Line is busy (off-hook, ringing, or PSTN line not connected) when the VoIP caller calls, the ATA device replies with 503. If the PIN number is invalid or entered after the VoIP call leg is connected, the ATA device plays the reorder tone to the VoIP caller and eventually ends the call when the reorder tone times out.

NOTE If VoIP Caller ID Pattern is specified and the VoIP caller ID does not match any of the

given patterns, the ATA device rejects the call with a 403. This rule applies regardless of the authentication method, even when the source IP address of the INVITE request is in the VoIP Access List .

Using HTTP Digest Authentication (SPA3102) The same scenario can be implemented with HTTP digest authentication when the calling device s the configuration of a auth-ID and to access the ATA device PSTN gateway. When the VoIP caller calls the PSTN Line, the ATA device challenges the INVITE request with a 401 response. The calling device should then provide the correct credentials in a subsequent retry of the INVITE, computed with the auth-ID and using MD5. If the credentials are correct, the target number specified in the -id field of the INVITE Request-URI is processed by the dial plan corresponding to the VoIP (assuming the dial plan choice is not 0). The final number is then auto-dialed by the ATA device. If the credentials are incorrect, the ATA device challenges the INVITE again. If the auth-ID does not exist in the ATA device configuration, the ATA device replies 403 to the INVITE. If the target number is invalid according to the corresponding dial plan, the ATA device also replies 403 to the INVITE. Again, if the PSTN Line is busy at the time of the call, the ATA device replies 503.


97


6

NOTE HTTP Digest Authentication is one way to perform one-stage dialing of a VoIP-To-

PSTN call. The other way is with no authentication require. However, if the target number is not specified in the Request-URI or the number matches the -id of the PSTN Line, the call reverts to two-stage dialing.

Without Authentication (SPA3102 and SPA8800) This scenario can also be implemented without authentication, using one-stage or two-stage dialing, as in the HTTP Authentication case. The default VoIP caller dial plan is used in this scenario. Authentication is performed when the method is none or when the source IP address of the inbound INVITE matches one of the VoIP Access List patterns.

Call Forwarding to PSTN Gateway (SPA3102 and SPA8800) This section describes a number of scenarios that forward calls to the PSTN gateway. It includes the following topics:

•

“Forward-On-No-Answer to the PSTN Gateway” section on page 98

•

“Forward-All to the PSTN gateway” section on page 99

•

“Forward to a Particular PSTN Number” section on page 99

•

“Forward-On-Busy to PSTN Gateway or Number” section on page 99

On the SPA3102, you can configure Call Forward settings on the page. On SPA8800, the same parameters are set on the Phone page. For field descriptions, see Call Forward Settings section.

Forward-On-No-Answer to the PSTN Gateway In this scenario, Line 1 is configured to Cfwd No Ans Dest to the PSTN Gateway. The scenario is implemented by setting 1 to forward to gw0 on no answer, with Cfwd No Ans Delay set to six seconds. The caller calls Line 1 and if Line 1 is not picked up after six seconds, the PSTN Line picks up the call and the call reverts to a PSTN-Gateway call, as described above. In this case, HTTP authentication is not allowed because Line 1 does not authenticate inbound INVITE requests. If you need to authenticate the VoIP caller in this case, you must select the PIN authentication method, or else the caller is not authenticated.


98


6

NOTE If the PSTN Line is busy at the moment of the forward, it does not answer the VoIP

call. The call forward rule is ignored and Line 1 continues to ring.

Forward-All to the PSTN gateway In this scenario, Line 1 is configured with Cfwd All Dest parameter to the PSTN gateway.This scenario is the same the previous case, except the FXO picks up the Line 1 call immediately. If the PSTN Line is busy at the moment of the call, the PSTN Line does not pick up the call, the call forward rule is ignored, and Line 1 continues to ring.

Forward to a Particular PSTN Number In this scenario, the forward destination is set to @gw0>. This is the same as in the previous examples, except that the ATA device automatically dials the given target number on the PSTN line right after it answers the VoIP call leg. This is a special case of one-stage dialing where the target number is specified in the configuration. The caller is not authenticated in this case regardless of the authentication method. However, the caller is still limited by the VoIP Caller ID Pattern parameter

Forward-On-Busy to PSTN Gateway or Number This scenario is similar to the previous cases of call forwarding to gw0, but this applies when Line 1 is active.


99

A ATA Routing Field Reference

This chapter describes the settings that you can configure under the Router and Network tabs in the istration web server pages.

NOTE This information applies to the SPA2102, SPA3102, SPA8000, and SPA8800

models. To configure router settings for the PAP2T, see the guide for the router. After you click the Router tab on the SPA2102, SPA3102, or the Network tab on the SPA8000 and SPA8800, you can choose the following pages:

•

“Router Status page,” on page 100

•

“WAN Status page,” on page 102

•

“LAN Status page,” on page 106

•

“Application page,” on page 107

NOTE Not all fields listed may be applicable to your ATA device or your setup.

Router Status page You can use the Router tab > Status page to view information about the Router. The Status page includes the following sections:

•

“Product Information section,” on page 101

•

“System Status section,” on page 101


100

A

ATA Routing Field Reference Router Status page

Router tab > Status page >

Product Information section

Product Name

Model number of the ATA device.

Serial Number

Serial number of the ATA device.

Software Version

Version number of the ATA software.

Hardware Version

Version number of the ATA hardware.

MAC Address

MAC address of the ATA device.

Client Certificate

Status of the client certificate, which authenticates the ATA device for use in the ITSP network.

Customization

For a Remote Configuration (RC) unit, this field indicates whether the unit has been customized or not. Pending indicates a new RC unit that is ready for provisioning. If the unit has already retrieved its customized profile, this field displays the name of the company that provisioned the unit.

Router tab > Status page >

System Status section Current Time

Current date and time of the system; for example, 10/3/ 2003 16:43:00.

Elapsed Time

Total time elapsed since the last reboot of the system; for example, 25 days and 18:12:36.

WAN Connection Type The connection type: DH or Static IP. Current IP

The current IP address assigned to the ATA device.

Host Name

The current IP address assigned to the ATA device.

Domain

The network domain name of the ATA device.

Current Netmask

The network mask assigned to the ATA device.

Current Gateway

The default router assigned to the ATA device.

Primary DNS

The primary DNS server assigned to the ATA device.

Secondary DNS

The secondary DNS server assigned to the ATA device.

LAN IP Address

The address of the router.


101

A

ATA Routing Field Reference WAN Status page

Current Time


Broadcast Pkts Sent

Total number of broadcast packets sent.

Broadcast Bytes Sent

Total number of broadcast packets received.

Broadcast Pkts Recv

Total number of broadcast bytes sent.

Broadcast Bytes Recv

Total number of broadcast bytes received and processed.

Broadcast Pkts Dropped

Total number of broadcast packets received but not processed.

Broadcast Bytes Dropped

Total number of broadcast bytes received but not processed.

WAN Status page You can use the WAN Status page to enter the WAN connection settings. This page includes the following sections:

•

“Internet Connection Settings section,” on page 102

•

“Static IP Settings section,” on page 103

•

“PPPoE Settings section,” on page 103

•

“Optional Settings section,” on page 104

•

“MAC Clone Settings section,” on page 105

•

“Remote Management section,” on page 105

•

“QOS Settings section,” on page 105

•

“VLAN Settings section,” on page 106

Router tab > WAN Setup page >

Internet Connection Settings section Connection Type


The type of WAN connection. Options are: DH, Static IP, PPPoE, PPPoE / DH (tries PPPoE then DH), or DH/ PPPoE (tries DH then PPPoE).

102

A



Static IP Settings section Static IP

Static IP address of ATA device, which takes effect if DH is disabled. The default is 0.0.0.0.

NetMask

The NetMask used by ATA device when DH is disabled. The default is 255.255.255.0.

Gateway

The default gateway used by ATA device when DH is disabled. The default is 0.0.0.0.


PPPoE Settings section

PPPoE Name

The name assigned by the ISP for connecting on a Point-to-Point Protocol over Ethernet (PPPoE) link.

PPPoE

The assigned by the ISP for connecting on a Point-to-Point Protocol over Ethernet (PPPoE) link.

PPPoE Service Name

The service name assigned by the ISP for connecting on a Point-to-Point Protocol over Ethernet (PPPoE) link.


103

A



Optional Settings section HostName

The host name of the ATA device.

Domain

The network domain of the ATA device.

Primary DNS

The DNS server that is used by the ATA device. NOTE: When DH is enabled, you can enter the IP address of a DNS server in addition to DH-supplied DNS servers. When DH is disabled, enter the primary DNS server. The default is 0.0.0.0.

Secondary DNS

Sets the secondary DNS server to take over if problems are discovered with the Primary DNS server. NOTE: When DH is enabled, you can enter the IP address of a primary or secondary DNS server in addition to DH-supplied DNS servers. When DH is disabled, enter the primary and secondary DNS server. The default is 0.0.0.0.

DNS Service Order

The method for selecting the DNS server: Manual (enter the IP address of the DNS server manually; that is do not look at the DH-supplied DNS table), Manual/ DH, and DH/Manual.

DNS Query Mode

The mode of DNS query: parallel or sequential. NOTE: With parallel DNS query mode, the ATA device sends the same DNS lookup request to all the DNS servers at the same time, and the first incoming reply is accepted by the ATA device. The default is parallel.

Primary NTP Server

The IP address or name of the primary NTP server.

Secondary NTP Server The IP address or name of the secondary NTP server.


104

A



MAC Clone Settings section A MAC address is a 12-digit code assigned to a unique piece of hardware for identification, like a social security number. Some ISPs require you to a MAC address in order to access the Internet. If you do not wish to re- the MAC address with your ISP, you may assign the MAC address you have currently ed with your ISP to the router with the MAC Address Clone feature. Enable MAC Clone Service

To use MAC Address cloning, select Yes. Default is No.

Cloned MAC Address

Use when your ISP requires a certain MAC address. It’s usually the address for your PC.


Remote Management section Enable WAN Web Server

Allows or prevents access to the istration web server from a computer that is not directly connected to the ATA device. Options are Yes or No. The default value is Yes.

WAN Web Server Port

The port that is used for WAN access to the ATA device. The default value is 80.


QOS Settings section Use Quality of Service (QoS) to assign different priority levels to different types of data transmissions. QOS Policy

Enable when you want to use QoS. Options are: Always On or On when Phone is Use (default).

QOS QDisc

Allow QoS Queuing. Options are None or TBF (token bucket filter). Information can be found at about TBF at: http://lartc.org/howto/lartc.qdisc.classless.html


105

A

ATA Routing Field Reference LAN Status page

Maximum Uplink Speed

The maximum bandwidth for LAN to WAN throughput. The default is 128 kbps.


VLAN Settings section Enable VLAN

Allows (yes) or prevents (no) VLAN access. NOTE: Choose yes if your ATA device is connected to a switch that uses VLAN tagging.

VLAN ID

The VLAN tag for the VLAN to which the ATA device is assigned.

LAN Status page You can use the LAN Status page to view the LAN settings. This page includes the following sections:

•

“Networking Service section,” on page 106

•

“LAN Networking Settings section,” on page 107

•

“Static DH Lease Settings section,” on page 107

Router tab > LAN Setup page >

Networking Service section Networking Service

NAT—the unit acts as a router and provides IP addresses to PCs attached to the LAN port. Bridge—The unit acts as a switch, a through, and does not give IP addresses.


106

A

ATA Routing Field Reference Application page


LAN Networking Settings section Use these network settings when using NAT. LAN IP Address

IP address of the ATA device on the LAN side.

LAN Subnet Mask

IP address for subnet mask.

Enable DH Server

The status of the DH server where Yes is enabled and No is disabled.

DH Lease Time

Provided by the DH Server. IP renewal process begins when the time expires.

DH Client Starting IP Initial IP address the DH Server provides for PCs Address attached to the LAN port. Number of Client IP Addresses

Number IP addresses available for the DH Server to provide.


Static DH Lease Settings section Use these settings when using a static IP address. Enable

Options are Yes or No. Default is No.

Host Mac Address

The device’s MAC address

Host IP Address

The device’s IP address

Application page You can use the Application page to view the port forward settings and to update the DMZ settings, multicast thru setting, and system reserved ports range. This page includes the following sections:

•

“Port Forwarding Settings section,” on page 108

•

“DMZ Settings section,” on page 108

•

“Miscellaneous Settings section,” on page 109


107

A


•

“System Reserved Ports Range section,” on page 109

Router tab > Application page >

Port Forwarding Settings section This feature allows you to set up specialized Internet applications that require port forwarding on a range of ports. Enable

Options are Yes or No.

Service Name

Any name to call the port forwarding starting port.

Starting Port

The starting port of the port range you wish to forward.

Ending Port

The ending port of the port range you wish to forward.

Protocol

The protocol that is used: T, UDP, or BOTH.

Server IP Address

The LAN address of the computer to receive port forwarding.


DMZ Settings section The DMZ feature allows one network computer to be exposed to the Internet for use of a special-purpose service such as Internet gaming or video conferencing. DMZ hosting forwards all the ports at the same time to one PC. The Port Forwarding feature is more secure because it only opens the ports you want to have opened, while DMZ hosting opens all the ports of one computer, exposing the computer to the Internet.

Enable DMZ

Any PC whose port is forwarded must have its DH client function disabled and should have a new static IP address assigned to it because its address may change when using the DH function. To expose one PC, select Yes. The default is No.

DMZ Host IP Address

Specify the host computer’s IP address.


108

A



Miscellaneous Settings section

Multicast thru

Used for ing multicast traffic. Options are disabled, inbound, outbound, inbound and outbound.


System Reserved Ports Range section Starting Port

A port identified as a reserve port and that is not used for NAT translation. That is, if there is a conflict — if port forwarding is set on the same port — then the port forwarding is cancelled. Default is 50000.

Num of Ports Reserved Total number of ports reserved. Options are: 256, 512, and 1024.


109

B ATA Voice Field Reference

This chapter describes the settings that you can configure under the Voice tab in the istration web server pages.

NOTE For information about the Voice > Provisioning tab, see the SPA Provisioning

Guide. After you click the Voice tab, you can choose the following pages: •

“Info page,” on page 111

•

“System page,” on page 119

•

“SIP page,” on page 122

•

“Regional page,” on page 134

•

“Line page,” on page 155

•

“Trunk Group page (SPA8000),” on page 185

•

“PSTN Line page (SPA3102),” on page 194

•

“ page,” on page 216

•

“PSTN page (SPA3102),” on page 222

NOTE Not all fields listed may be applicable to your ATA device or your setup.


110

B

ATA Voice Field Reference Info page

Info page You can use the Voice tab > Info page to view information about the ATA device. With some variations, depending on the model, this page includes the following sections: •

“Product Information section,” on page 111

•

“System Status section,” on page 112

•

“Line Status section,” on page 112

•

“System Information section (PAP2T),” on page 115

•

“PSTN Line Status section (SPA3102),” on page 115

•

“Trunk Status section (SPA8000),” on page 118

NOTE The fields on the Info page are read-only and cannot be edited.

Voice tab > Info page >

Product Information section

Product Name

Model number/name.

Serial Number

Serial number.

Software Version

Software version number.

Hardware Version

Hardware version number.

MAC Address

MAC address.

Client Certificate

Status of the client certificate, which can indicate if the ATA device has been authorized by your ITSP.

Customization

For a Remote Configuration (RC) unit, this field indicates whether the unit has been customized or not. Pending indicates a new RC unit that is ready for provisioning. If the unit has already retrieved its customized profile, this field displays the name of the company that provisioned the unit.


111

B



System Status section

Current Time


Elapsed Time

Total time elapsed since the last reboot of the system; for example, 25 days and 18:12:36.

RTP Packets Sent

Total number of RTP packets sent (including redundant packets).

RTP Bytes Sent

Total number of RTP bytes sent.

RTP Packets Recv

Total number of RTP packets received (including redundant packets).

RTP Bytes Recv

Total number of RTP bytes received.

SIP Messages Sent Total number of SIP messages sent (including retransmissions). SIP Bytes Sent

Total number of bytes of SIP messages sent (including retransmissions).

SIP Messages Recv

Total number of SIP messages received (including retransmissions).

SIP Bytes Recv

Total number of bytes of SIP messages received (including retransmissions).

External IP

External IP address used for NAT mapping.


Line Status section

(PSTN) Hook State

Hook state of the FXO port. Options are either On or Off.

Registration State

Indicates if the line has ed with the SIP proxy.

Last Registration At Last date and time the line was ed. Next Registration In Number of seconds before the next registration renewal.


112

B


Message Waiting

Indicates whether you have new voice mail waiting. Options are either Yes or No. The value automatically is set to Yes when a message is received. You also can clear or set the flag manually. Setting this value to Yes can activate stutter tone and VMWI signal. This parameter is stored in long term memory and survives after reboot or power cycle.

Call Back Active

Indicates whether a call back request is in progress. Options are either Yes or No.

Last Called Number The last number called from the FXO Line. Last Caller Number Number of the last caller. Mapped SIP Port

Port number of the SIP port mapped by NAT.

Call 1 and 2 State

May take one of the following values: •

Idle

•

Collecting PSTN Pin

•

Invalid PSTN PIN

•

PSTN Caller Accepted

•

Connected to PSTN

Call 1 and 2 Tone

Type of tone used by the call.

Call 1 and 2 Encoder

Codec used for encoding.

Call 1 and 2 Decoder

Codec used for decoding.

Call 1 and 2 FAX

Status of the fax -through mode.

Call 1 and 2 Type

Direction of the call. May take one of the following values:


•

PSTN Gateway Call = VoIP-To-PSTN Call

•

VoIP Gateway Call = PSTN-To-VoIP Call

•

PSTN To Line 1 = PSTN call ring through and answered by Line 1

•

Line 1 Forward to PSTN Gateway = VoIP calls Line 1 then forwarded to PSTN GW

•

Line 1 Forward to PSTN Number =VoIP calls Line 1 then forwarded to PSTN number

•

Line 1 To PSTN Gateway

•

Line 1 Fallback To PSTN Gateway

113

B


Call 1 and 2 Remote Hold

Indicates whether the far end has placed the call on hold.

Call 1 and 2 Callback

Indicates whether the call was triggered by a call back request.

Call 1 and 2 Peer Name

Name of the internal phone.

Call 1 and 2 Peer Phone

Phone number of the internal phone.

Call 1 and 2 Call Duration

Duration of the call.

Call 1 and 2 Packets Sent

Number of packets sent.

Call 1 and 2 Packets Recv

Number of packets received.

Call 1 and 2 Bytes Sent

Number of bytes sent.

Call 1 and 2 Bytes Recv

Number of bytes received.

Call 1 and 2 Decode Latency

Number of milliseconds for decoder latency.

Call 1 and 2 Jitter

Number of milliseconds for receiver jitter.

Call 1 and 2 Round Trip Delay

Number of milliseconds for delay.

Call 1 and 2 Packets Lost

Number of packets lost.

Call 1 and 2 Packet Error

Number of invalid packets received.

Call 1 and 2 Mapped RTP Port

The port mapped for Real Time Protocol traffic for Call 1/2.

Call 1 and 2 Media Loopback

Media loopback is used to quantitatively and qualitatively measure the voice quality experienced by the end .


114

B



System Information section (PAP2T)

DH

Indicates if DH is enabled.

Current IP

Displays the current IP address assigned to the ATA device.

Host Name

Displays the current IP address assigned to the ATA device.

Domain

Displays the network domain name of the ATA device.

Current Netmask

Displays the network mask assigned to the ATA device.

Current Gateway

Displays the default router assigned to the ATA device.

Primary DNS

Displays the primary DNS server assigned to the ATA device.

Secondary DNS

Displays the secondary DNS server assigned to the ATA device.


PSTN Line Status section (SPA3102)

(PSTN) Hook State

Hook state of the FXO port. Either On or Off.

(PSTN) Line Voltage

The voltage existing on the PSTN line.

(PSTN) Loop Current

The current (milliamperes) existing on the local loop.

Registration State


Last Registration At Last date and time the line was ed. Next Registration In Number of seconds before the next registration renewal. Last Called VoIP Number

The last VoIP number called from the FXO Line.

Last Called PSTN Number

The PSTN number dialed by the SPA (logged only if a nontrivial dial plan is used).

Last VoIP Caller

The last VoIP caller to the FXO Line.

Last PSTN Caller

Name and number of the last PSTN caller.


115

B


Last PSTN Reason for SPA hanging up the FXO port. Can be one of the Disconnect Reason following: •

PSTN Disconnect Tone

•

PSTN Activity Timeout

•

C Signal

•

Polarity Reversal

•

VoIP Call Failed

•

VoIP Call Ended

•

Invalid VoIP Destination

•

Invalid PIN

•

PIN Digit Timeout

•

VoIP Dialing Timeout

•

PSTN Gateway Call Timeout

•

VoIP Gateway Call Timeout

PSTN Activity Timer

Shows the time (ms) before the SPA disconnects the current gateway unless the PSTN side has some audio activity.

Mapped SIP Port


Call Type

May take one of the following values:


•

PSTN Gateway Call = VoIP-To-PSTN Call

•

VoIP Gateway Call = PSTN-To-VoIP Call

•

PSTN To Line 1 = PSTN call ring through and answered by Line 1

•

Line 1 Forward to PSTN Gateway = VoIP calls Line 1 then forwarded to PSTN GW

•

Line 1 Forward to PSTN Number =VoIP calls Line 1 then forwarded to PSTN number

•

Line 1 To PSTN Gateway

•

Line 1 Fallback To PSTN Gateway

116

B


VoIP State

PSTN State


Idle

•

Collecting PSTN Pin

•

Invalid PSTN PIN

•


•

Connected to PSTN


Idle

•

Collecting PSTN Pin

•

Invalid PSTN PIN

•


•

Connected to PSTN

VoIP Tone

Indicates what tone is being played to the VoIP call leg.

PSTN Tone

Indicate what tone is being played to the PSTN call leg.

VoIP Peer Name

Name of the party at the VoIP call leg.

PSTN Peer Name

Name of the party at the PSTN call leg.

VoIP Peer Number

Phone number of the party at the VoIP call leg.

PSTN Peer Number Phone number of the party at the PSTN call leg. VoIP Call Encoder

Audio encoder being used for the VoIP call leg.

VoIP Call Decoder

Audio decoder being used for the VoIP call leg.

VoIP Call FAX

Status of the fax -through mode.

VoIP Call Remote Hold

Indicates whether the far end has placed the call on hold.

VoIP Call Duration

Duration of the call.

VoIP Call Packets Sent

Number of packets sent.

VoIP Call Packets Recv

Number of packets received.

VoIP Call Bytes Sent

Number of bytes sent.

VoIP Call Bytes Recv

Number of bytes received.


117

B


VoIP Call Decode Latency

Number of milliseconds for decoder latency.

VoIP Call Jitter

Number of milliseconds for receiver jitter.

VoIP Call Round Trip Delay

Number of milliseconds for delay.

VoIP Call Packets Lost

Number of packets lost.

VoIP Call Packet Error

Number of invalid packets received.

VoIP Call Mapped RTP Port

The port mapped for Real Time Protocol traffic for Call 1/2.


Trunk Status section (SPA8000)

Registration State


Last Registration At Last date and time the line was ed. Next Registration In Number of seconds before the next registration renewal. Message Waiting

Indicates whether you have new voice mail waiting. Options are either Yes or No. This value is updated when voice mail notification is received. You can also manually modify it to clear or set the flag. Setting this value to Yes can activate stutter tone and VMWI signal. This parameter is stored in long term memory and survives after reboot or power cycle.

Mapped SIP Port



118

B

ATA Voice Field Reference System page

System page You can use the Voice tab > System page to configure your system and network connections. With some variations, depending on the model, this page includes the following sections: •

“System Configuration section” section on page 119

•

“Internet Connection Type section (PAP2T)” section on page 120

•

“Optional Network Configuration section (PAP2T)” section on page 120

•

“Miscellaneous Settings section (not used with PAP2T)” section on page 121

Voice tab > System page >

System Configuration section

Restricted Access Domains

This feature is used when implementing software customization.

Enable Web Server Enable/disable web server of the ATA device. This feature should only be used on firmware version 1.0.9 or later. The default is yes. This field is only found in the PAP2T. Web Server Port

Port number of the ATA device istration web server. The default is 80. This field is only found in the PAP2T.

Enable Web Access

Lets you enable or disable local access to the istration web server. Select yes or no from the dropdown menu. The default is yes.

for the . The default is no .

for the . The default is no .


119

B



Internet Connection Type section (PAP2T)

DH

Enable or disable DH. The default is yes.

Static IP

Static IP address of ATA device, which takes effect if DH is disabled. The default is 0.0.0.0.

NetMask

The NetMask used by ATA device when DH is disabled. The default is 255.255.255.0.

Gateway

The default gateway used by ATA device when DH is disabled. The default is 0.0.0.0.


Optional Network Configuration section (PAP2T)

Host Name

The host name of the ATA device.

Domain

The network domain of the ATA device.

Primary DNS

DNS server used by ATA device in addition to DH supplied DNS servers if DH is enabled; when DH is disabled, this is the primary DNS server. The default is 0.0.0.0.

Secondary DNS

Sets the secondary DNS server to take over if problems are discovered with the Primary DNS server. This is in addition to DH-supplied DNS servers if DH is enabled; when DH is disabled, this is the secondary DNS server. The default is 0.0.0.0.


120

B


DNS Server Order

Specifies the method for selecting the DNS server. The options are Manual (enter the IP address of the DNS server manually; that is do not look at the DH-supplied DNS table), Manual/DH, and DH/Manual.

DNS Query Mode

Do parallel or sequential DNS Query. With parallel DNS query mode, the ATA device sends the same request to all the DNS servers at the same time when doing a DNS lookup, the first incoming reply is accepted by the ATA device. The default is parallel.

Syslog Server

Specify the syslog server name and port. This feature specifies the server for logging ATA device system information and critical events. If both Debug Server and Syslog Server are specified, Syslog messages are also logged to the Debug Server.

Debug Server

The debug server name and port. This feature specifies the server for logging ATA device debug information. The level of detailed output depends on the debug level parameter setting.

Debug Level

The higher the debug level, the more debug information is generated. Zero (0) means no debug information is generated. To log SIP messages, Debug Level must be set to at least 2. The default is 0.

Primary NTP Server

IP address or name of primary NTP server.

Secondary NTP Server

IP address or name of secondary NTP server.


Miscellaneous Settings section (not used with PAP2T)

Syslog Server

Specifies the IP address of the syslog server.

Debug Server

Specifies the IP address of the debug server, which logs debug information. The level of detailed output depends on the debug level parameter setting.


121

B

ATA Voice Field Reference SIP page

Debug Level

Determines the level of debug information that is generated. Select 0, 1, 2, or 3 from the drop-down menu. The higher the debug level, the more debug information is generated. The default is 0, which indicates that no debug information is generated.

SIP page You can use the Voice tab > SIP page to configure the SIP settings. With some variations, depending on the model, this page includes the following sections: •

“SIP Parameters section” section on page 122

•

“SIP Timer Values (sec) section” section on page 124

•

“Response Status Code Handling section” section on page 126

•

“RTP Parameters section” section on page 127

•

“SDP Payload Types section” section on page 129

•

“NAT Parameters section” section on page 130

•

“Trunking Parameters section (SPA8000)” section on page 133

Voice tab > SIP page >

SIP Parameters section

Max Forward

SIP Max Forward value, which can range from 1 to 255. The default is 70.

Max Redirection

Number of times an invite can be redirected to avoid an infinite loop. The default is 5.

Max Auth

Maximum number of times (from 0 to 255) a request may be challenged. The default is 2.


122

B


SIP Agent Name

-Agent header used in outbound requests.

SIP Server Name

Server header used in responses to inbound responses.

The default is $VERSION. If empty, the header is not included. Macro expansion of $A to $D corresponding to GPP_A to GPP_D allowed.

The default is $VERSION. SIP Reg Agent -Agent name to be used in a request. If this Name value is not specified, the SIP Agent Name parameter is also used for the request. The default is blank. SIP Accept Language

Accept-Language header used. There is no default (this indicates ATA device does not include this header). If empty, the header is not included.

DTMF Relay MIME Type

MIME Type used in a SIP INFO message to signal a DTMF event. The default is application/dtmf-relay.

Hook Flash MIME Type

MIME Type used in a SIP INFO message to signal a hook flash event. The default is application/hook-flash.

Remove Last Reg

Lets you remove the last registration before ing a new one if the value is different. Select yes or no from the drop-down menu. The default is no.

Use Compact Header

Lets you use compact SIP headers in outbound SIP messages. Select yes or no from the drop-down menu. If set to yes, the ATA device uses compact SIP headers in outbound SIP messages. If set to no, the ATA device uses normal SIP headers. If inbound SIP requests contain compact headers, ATA device reuses the same compact headers when generating the response regardless the settings of the Use Compact Header parameter. If inbound SIP requests contain normal headers, ATA device substitutes those headers with compact headers (if defined by RFC 261) if Use Compact Header parameter is set to yes. The default is no.


123

B


Escape Display Name

Lets you keep the Display Name private. Select yes if you want the ATA device to enclose the string (configured in the Display Name) in a pair of double quotes for outbound SIP messages. Any occurrences of or \ in the string is escaped with \ and \\ inside the pair of double quotes. Otherwise, select no. The default is no.

RFC 2543 Call Hold Configures the type of call hold: a:sendonly or 0.0.0.0. The default is no; do not use the 0.0.0.0 syntax in a HOLD SDP; use the a:sendonly syntax. Mark All AVT Packets

If set to yes, all AVT tone packets (encoded for redundancy) have the marker bit set. If set to no, only the first packet has the marker bit set for each DTMF event. The default is yes.

SIP T Port Min

Specifies the lowest T port number that can be used for SIP sessions. This field is not found in the PAP2T.

SIP T Port Max

Specifies the highest T port number that can be used for SIP sessions. This field is not found in the PAP2T.


SIP Timer Values (sec) section

SIP T1

RFC 3261 T1 value (RTT estimate), which can range from 0 to 64 seconds. The default is.5.

SIP T2

RFC 3261 T2 value (maximum retransmit interval for nonINVITE requests and INVITE responses), which can range from 0 to 64 seconds. The default is 4.

SIP T4

RFC 3261 T4 value (maximum duration a message remains in the network), which can range from 0 to 64 seconds. The default is 5.


124

B


SIP Timer B

INVITE time-out value, which can range from 0 to 64 seconds. The default is 32.

SIP Timer F

Non-INVITE time-out value, which can range from 0 to 64 seconds. The default is 32.

SIP Timer H

INVITE final response, time-out value, which can range from 0 to 64 seconds. The default is 32.

SIP Timer D

ACK hang-around time, which can range from 0 to 64 seconds. The default is 32.

SIP Timer J

Non-INVITE response hang-around time, which can range from 0 to 64 seconds. The default is 32.

INVITE Expires

INVITE request Expires header value. If you enter 0, the Expires header is not included in the request. The default is 240. Range: 0–(231–1).

ReINVITE Expires

ReINVITE request Expires header value. If you enter 0, the Expires header is not included in the request. The default is 30. Range: 0–(231–1).

Reg Min Expires

Minimum registration expiration time allowed from the proxy in the Expires header or as a header parameter. If the proxy returns a value less than this setting, the minimum value is used. The default is 1.

Reg Max Expires

Maximum registration expiration time allowed from the proxy in the Min-Expires header. If the value is larger than this setting, the maximum value is used. The default is 7200.

Reg Retry Intvl

Interval to wait before the ATA device retries registration after failing during the last registration. The default is 30.


125

B


Reg Retry Long Intvl

When registration fails with a SIP response code that does not match Retry Reg RSC, the ATA device waits for the specified length of time before retrying. If this interval is 0, the ATA device stops trying. This value should be much larger than the Reg Retry Intvl value, which should not be 0. The default is 1200.

Reg Retry Random Delay

Random delay range (in seconds) to add to Retry Intvl when retrying after a failure. The default is 0, which disables this feature.

Reg Retry Long Random Delay

Random delay range (in seconds) to add to Retry Long Intvl when retrying after a failure. The default is 0, which disables this feature.

Reg Retry Intvl Cap The maximum value to cap the exponential back-off retry delay (which starts at Retry Intvl and doubles on every retry after a failure). In other words, the retry interval is always at Retry Intvl seconds after a failure. If this feature is enabled, Reg Retry Random Delay is added on top of the exponential back-off adjusted delay value. The default value is 0, which disables the exponential backoff feature. Voice tab > SIP page >

Response Status Code Handling section

SIT1 RSC

SIP response status code for the appropriate Special Information Tone (SIT). For example, if you set the SIT1 RSC to 404, when the makes a call and a failure code of 404 is returned, the SIT1 tone is played. Reorder or Busy tone is played by default for all unsuccessful response status code for SIT 1 RSC through SIT 4 RSC.

SIT2 RSC

SIP response status code to INVITE on which to play the SIT2 Tone.

SIT3 RSC



126

B


SIT4 RSC


Try Backup RSC

SIP response code that retries a backup server for the current request.

Retry Reg RSC

Interval to wait before the ATA device retries registration after failing during the last registration. The default is 30.


RTP Parameters section

RTP Port Min

Minimum port number for RTP transmission and reception. The RTP Port Min and RTP Port Max parameters should define a range that contains at least 4 even number ports, such as 100 – 106. The default is 16384.

RTP Port Max

Maximum port number for RTP transmission and reception. The default is 16482.

RTP Packet Size

Packet size in seconds, which can range from 0.01 to 0.16. Valid values must be a multiple of 0.01 seconds. The default is 0.030.

Max RTP ICMP Err

Number of successive ICMP errors allowed when transmitting RTP packets to the peer before the ATA device terminates the call. If value is set to 0, the ATA device ignores the limit on ICMP errors. The default is 0.


127

B


RT Tx Interval

Interval for sending out RT sender reports on an active connection. It can range from 0 to 255 seconds. During an active connection, the ATA device can be programmed to send out compound RT packet on the connection. Each compound RTP packet except the last one contains a SR (Sender Report) and a SDES.(Source Description). The last RT packet contains an additional BYE packet. Each SR except the last one contains exactly 1 RR (Receiver Report); the last SR carries no RR. The SDES contains CNAME, NAME, and TOOL identifiers. The CNAME is set to < ID>@ , NAME is set to (or Anonymous if blocks caller ID), and TOOL is set to the Vendor/Hardware-platform-software-version (such as Cisco/ATA device-1.0.31(b)). The NTP timestamp used in the SR is a snapshot of the ATA device’s local time, not the time reported by an NTP server. If the ATA device receives a RR from the peer, it attempts to compute the round trip delay and show it as the value (ms) in the Info section of ATA device web page. The default is 0.

No UDP Checksum

Select yes if you want the ATA device to calculate the UDP header checksum for SIP messages. Otherwise, select no. The default is no.

Stats In BYE

Determines whether the ATA device includes the P-RTPStat header or response to a BYE message. The header contains the RTP statistics of the current call. Select yes or no from the drop-down menu. The format of the P-RTP-Stat header is: P-RTP-State: PS=<packets sent>,OS= ,PR=<packets received>,OR= ,PL=<packets lost>,JI=<jitter in ms>,LA=<delay in ms>,DU= ,EN=<encoder>,DE=<decoder>. The default is no.


128

B



SDP Payload Types section

NSE Dynamic Payload

NSE dynamic payload type. The valid range is 96-127.

AVT Dynamic Payload

AVT dynamic payload type. The valid range is 96-127.

INFOREQ Dynamic Payload

INFOREQ dynamic payload type.

G726r16 Dynamic Payload

G.726-16 dynamic payload type. The valid range is 96-127.





G729b Dynamic Payload

G.729b dynamic payload type. The valid range is 96-127.

NSE Codec Name

NSE codec name used in SDP.

The default is 100.

The default is 101.

There is no default.

The default is 98.

The default is 97.

The default is 96.

The default is 99.

The default is NSE. AVT Codec Name

AVT codec name used in SDP. The default is telephone-event.

G711u Codec Name

G.711u codec name used in SDP.

G711a Codec Name

G.711a codec name used in SDP.

G726r16 Codec Name

G.726-16 codec name used in SDP.

G726r24 Codec Name



The default is PCMU.

The default is PCMA.

The default is G726-16.


129

B


G726r32 Codec Name


G726r40 Codec Name


G729a Codec Name

G.729a codec name used in SDP.

G729b Codec Name

G.729b codec name used in SDP.



The default is G729a.

The default is G729ab.

G723 Codec Name G.723 codec name used in SDP. The default is G723. EncapRTP Codec Name

EncapRTP codec name used in SDP. The default is EncapRTP.


NAT Parameters section

Handle VIA received

If you select yes, the ATA device processes the received parameter in the VIA header (this value is inserted by the server in a response to anyone of its requests). If you select no, the parameter is ignored. Select yes or no from the drop-down menu. The default is no.

Handle VIA rport

If you select yes, the ATA device processes the rport parameter in the VIA header (this value is inserted by the server in a response to anyone of its requests). If you select no, the parameter is ignored. Select yes or no from the drop-down menu. The default is no.

Insert VIA received

Inserts the received parameter into the VIA header of SIP responses if the received-from IP and VIA sent-by IP values differ. Select yes or no from the drop-down menu. The default is no.


130

B


Insert VIA rport

Inserts the parameter into the VIA header of SIP responses if the received-from IP and VIA sent-by IP values differ. Select yes or no from the drop-down menu. The default is no.

Substitute VIA Addr Lets you use NAT-mapped IP:port values in the VIA header. Select yes or no from the drop-down menu. The default is no. Send Resp To Src Port

Sends responses to the request source port instead of the VIA sent-by port. Select yes or no from the drop-down menu. The default is no.

STUN Enable

Enables the use of STUN to discover NAT mapping. Select yes or no from the drop-down menu. The default is no.

STUN Test Enable

If the STUN Enable feature is enabled and a valid STUN server is available, the ATA device can perform a NAT-type discovery operation when it powers on. It s the configured STUN server, and the result of the discovery is reported in a Warning header in all subsequent requests. If the ATA device detects symmetric NAT or a symmetric firewall, NAT mapping is disabled. The default is no.

STUN Server

IP address or fully-qualified domain name of the STUN server to for NAT mapping discovery.

EXT IP

External IP address to substitute for the actual IP address of the ATA device in all outgoing SIP messages. If 0.0.0.0 is specified, no IP address substitution is performed. If this parameter is specified, the ATA device assumes this IP address when generating SIP messages and SDP (if NAT Mapping is enabled for that line). However, the results of STUN and VIA received parameter processing, if available, supersede this statically configured value. The default is 0.0.0.0.


131

B


EXT RTP Port Min

External port mapping number of the RTP Port Min. number. If this value is not zero, the RTP port number in all outgoing SIP messages is substituted for the corresponding port value in the external RTP port range. The default is 0.

NAT Keep Alive Intvl


Interval between NAT-mapping keep alive messages. The default is 15.

132

B



Trunking Parameters section (SPA8000) The trunking parameters apply to the Trunk Groups that you configure on the Trunk Group pages. SIP Trunking is available on the SPA8000 only.

Proxy Debug Option

This feature controls which proxy debuy messages to log. The choices are as follows: •

none—No logging.

•

1-line—Logs the start-line only for all messages.

•

1-line excl. OPT—Logs the start-line only for all messages except OPTIONS requests/responses.

•

1-line excl. NTFY—Logs the start-line only for all messages except NOTIFY requests/responses.

•

1-line excl. REG—Logs the start-line only for all messages except requests/responses.

•

1-line excl. OPT|NTFY|REG—Logs the start-line only for all messages except OPTIONS, NOTIFY, and requests/responses.

•

full—Logs all SIP messages in full text.

•

full excl. OPT—Logs all SIP messages in full text except OPTIONS requests/responses.

•

full excl. NTFY—Logs all SIP messages in full text except NOTIFY requests/responses.

•

full excl. REG—Logs all SIP messages in full text except requests/responses.

•

full excl. OPT|NTFY|REG—Logs all SIP messages in full text except for OPTIONS, NOTIFY, and requests/ responses.

The default is none.


133

B

ATA Voice Field Reference Regional page

Hunt Policy

This parameter can be used to modify the hunting behavior for trunk lines, based on the call state of the trunk lines that are specified in the Voice tab > Trunk page, List field. The following options are available: •

onhook only: An incoming call is directed to a specified trunk line only if the call state is onhook.

•

any state: An incoming call is directed to any specified trunk line without regard to the call state.

Regional page You can use the Voice tab > Regional page to localize your system with the appropriate regional settings. With some variations, depending on the model, this page includes the following sections: •

“Call Progress Tones section” section on page 135

•

“Distinctive Ring Patterns section” section on page 137

•

“Distinctive Call Waiting Tone Patterns section” section on page 138

•

“Distinctive Ring/CWT Pattern Names section” section on page 139

•

“Ring and Call Waiting Tone Spec section” section on page 140

•

“Control Timer Values (sec) section” section on page 141

•

“Vertical Service Activation Codes section” section on page 143

•

“Vertical Service Announcement Codes section (SPA2102, SPA8000)” section on page 149

•

“Outbound Call Codec Selection Codes section” section on page 149

•

“Miscellaneous section” section on page 151


134

B


Voice tab > Regional page >

Call Progress Tones section

Dial Tone

Prompts the to enter a phone number. Reorder Tone is played automatically when Dial Tone or any of its alternatives times out. The default is 350@-19,440@-19;10(*/0/1+2).

Second Dial Tone

Alternative to the Dial Tone when the dials a three-way call. The default is 420@-19,520@-19;10(*/0/1+2).

Outside Dial Tone

Alternative to the Dial Tone. It prompts the to enter an external phone number, as opposed to an internal extension. It is triggered by a, (comma) character encountered in the dial plan. The default is 420@-19;10(*/0/1).

Prompt Tone

Prompts the to enter a call forwarding phone number. The default is 520@-19,620@-19;10(*/0/1+2).

Busy Tone

Played when a 486 RSC is received for an outbound call. The default is 480@-19,620@-19;10(.5/.5/1+2).

Reorder Tone

Played when an outbound call has failed or after the far end hangs up during an established call. Reorder Tone is played automatically when Dial Tone or any of its alternatives times out. The default is 480@-19,620@-19;10(.25/.25/1+2).

Off Hook Warning Tone

Played when the caller has not properly placed the handset on the cradle. Off Hook Warning Tone is played when Reorder Tone times out. The default is 480@10,620@0;10(.125/.125/1+2).

Ring Back Tone

Played during an outbound call when the far end is ringing. The default is 440@-19,480@-19;*(2/4/1+2).


135

B


Ring Back 2 Tone

Your ATA device plays this ringback tone instead of Ring Back Tone if the called party replies with a SIP 182 response without SDP to its outbound INVITE request. The default value is the same as Ring Back Tone, except the cadence is 1s on and 1s off. The default is 440@-19,480@-19;*(1/1/1+2).

Confirm Tone

Brief tone to notify the that the last input value has been accepted. The default is 600@-16; 1(.25/.25/1).

SIT1 Tone

Alternative to the Reorder Tone played when an error occurs as a caller makes an outbound call. The RSC to trigger this tone is configurable on the SIP screen. The default is 985@-16,1428@-16,1777@-16;20(.380/0/ 1,.380/0/2,.380/0/3,0/4/0).

SIT2 Tone


SIT3 Tone


SIT4 Tone


MWI Dial Tone

Played instead of the Dial Tone when there are unheard messages in the caller’s mailbox. The default is 350@-19,440@-19;2(.1/.1/1+2);10(*/0/ 1+2).

Cfwd Dial Tone

Played when all calls are forwarded. The default is 350@-19,440@-19;2(.2/.2/1+2);10(*/0/ 1+2).


136

B


Holding Tone

Informs the local caller that the far end has placed the call on hold. The default is 600@-19*(.1/.1/1,.1/.1/1,.1/9.5/1).

Conference Tone

Played to all parties when a three-way conference call is in progress. The default is 350@-19;20(.1/.1/1,.1/9.7/1).

Secure Call Indication Tone

Played when a call has been successfully switched to secure mode. It should be played only for a short while (less than 30 seconds) and at a reduced level (less than -19 dBm) so it does not interfere with the conversation. The default is 397@-19,507@-19;15(0/2/0,.2/.1/1,.1/2.1/ 2).

VoIP PIN Tone

Specification of the tone played to prompt a VoIP caller for a PIN number (if PIN authentication is selected and the caller requires authentication to use the PSTN gateway). This setting applies to the SPA3102 only. The default is 600@-10;*(0/1/1,.1/.1/1,.1/.1/1,.1/.5/1).

PSTN PIN Tone

Specification of the tone played to prompt a PSTN caller for a PIN number (if PIN authentication is selected and the caller requires authentication to use the VoIP gateway). This setting applies to the SPA3102 only. The default is 600@-10;*(0/.7/1,.2/.1/1,.2/.1/1,.2/.5/1).

Feature Invocation Tone

Played when a feature is implemented. The default is 350@-16;*(.1/.1/1). This field is not found in the PAP2T.


Distinctive Ring Patterns section

Ring1 Cadence

Cadence script for distinctive ring 1. The default is 60(2/4).

Ring2 Cadence

Cadence script for distinctive ring 2. The default is 60(.3/.2, 1/.2,.3/4).


137

B


Ring3 Cadence

Cadence script for distinctive ring 3. The default is 60(.8/.4,.8/4).

Ring4 Cadence

Cadence script for distinctive ring 4. The default is 60(.4/.2,.3/.2,.8/4).

Ring5 Cadence

Cadence script for distinctive ring 5. The default is 60(.2/.2,.2/.2,.2/.2,1/4).

Ring6 Cadence


Ring7 Cadence


Ring8 Cadence

Cadence script for distinctive ring 8. The default is 60(0.25/9.75).

Ring9 Cadence

Cadence script for distinctive ring 9. This field is for the SPA2102 and SPA8000 only. The default is 60(.4/.2,.4/2).


Distinctive Call Waiting Tone Patterns section

CWT1 Cadence

Cadence script for distinctive CWT 1. The default is 30(.3/9.7).

CWT2 Cadence

Cadence script for distinctive CWT 2. The default is 30(.1/.1, .1/9.7).

CWT3 Cadence

Cadence script for distinctive CWT 3. The default is 30(.1/.1, .1/.1, .1/9.3).

CWT4 Cadence


CWT5 Cadence

Cadence script for distinctive CWT 5. The default is 30(.3/.1,.1/.1,.3/9.1).


138

B


CWT6 Cadence

Cadence script for distinctive CWT 6. The default is 30(.3/.1,.3/.1,.1/9.1).

CWT7 Cadence


CWT8 Cadence

Cadence script for distinctive CWT 8. The default is 2.3(.3/2).

CWT9 Cadence

Cadence script for distinctive CWT 9. This field is for the SPA2102 only. The default is 30(.3/9.7).


Distinctive Ring/CWT Pattern Names section

Ring1 Name

Name in an INVITE’s Alert-Info Header to pick distinctive ring/CWT 1 for the inbound call. The default is Bellcore-r1.

Ring2 Name


Ring3 Name


Ring4 Name


Ring5 Name


Ring6 Name



139

B


Ring7 Name


Ring8 Name


Ring9 Name

Name in an INVITE’s Alert-Info Header to pick distinctive ring/CWT 9 for the inbound call. This field is for the SPA2102 only. The default is Bellcore-r9.


Ring and Call Waiting Tone Spec section IMPORTANT: Ring and Call Waiting tones don’t work the same way on all phones. When setting ring tones, consider the following recommendations: •

Begin with the default Ring Waveform, Ring Frequency, and Ring Voltage.

•

If your ring cadence doesn’t sound right, or your phone doesn’t ring, change your Ring Waveform, Ring Frequency, and Ring Voltage to the following: -

Ring Waveform: Sinusoid

-

Ring Frequency: 25

-

Ring Voltage: 80V

Field

Description

Ring Waveform

Waveform for the ringing signal. Choices are Sinusoid or Trapezoid. The default is Trapezoid.

Ring Frequency

Frequency of the ringing signal. Valid values are 10–100 (Hz). The default is 20.

Ring Voltage

Ringing voltage. Choices are 60–90 (V). The default is 85.


140

B


CWT Frequency

Frequency script of the call waiting tone. All distinctive CWTs are based on this tone. The default is 440@-10.

Synchronized Ring

If this is set to Yes, when a device calls the Linksys ATA, both lines ring at the same time (similar to a regular PSTN line). After one line answers, the other stops ringing. This field is only found in the PAP2T. No is the default.


Control Timer Values (sec) section

Hook Flash Timer Min

Minimum on-hook time before off-hook qualifies as hookflash. Less than this the on-hook event is ignored. Range: 0.1–0.4 seconds. The default is 0.1.

Hook Flash Timer Max

Maximum on-hook time before off-hook qualifies as hookflash. More than this the on-hook event is treated as onhook (no hook-flash event). Range: 0.4–1.6 seconds. The default is 0.9.

Callee On Hook Delay

Phone must be on-hook for at this time in sec before the ATA device will tear down the current inbound call. It does not apply to outbound calls. Range: 0–255 seconds. The default is 0.

Reorder Delay

Delay after far end hangs up before reorder tone is played. 0 = plays immediately, inf = never plays. Range: 0–255 seconds. The default is 5.

Call Back Expires

Expiration time in seconds of a call back activation. Range: 0–65535 seconds. The default is 1800.

Call Back Retry Intvl


Call back retry interval in seconds. Range: 0–255 seconds. The default is 30.

141

B


Call Back Delay

Delay after receiving the first SIP 18x response before declaring the remote end is ringing. If a busy response is received during this time, the ATA device still considers the call as failed and keeps on retrying. The default is 0.5.

VMWI Refresh Intvl

Interval between VMWI refresh to the E. The default is 0.5.

Interdigit Long Timer

Long timeout between entering digits when dialing. The interdigit timer values are used as defaults when dialing. The Interdigit_Long_Timer is used after any one digit, if all valid matching sequences in the dial plan are incomplete as dialed. Range: 0–64 seconds. The default is 10.

Interdigit Short Timer

Short timeout between entering digits when dialing. The Interdigit_Short_Timer is used after any one digit, if at least one matching sequence is complete as dialed, but more dialed digits would match other as yet incomplete sequences. Range: 0–64 seconds. The default is 3.

C Delay

Delay in seconds after caller hangs up when the ATA device starts removing the tip-and-ring voltage to the attached equipment of the called party. Range: 0–255 seconds. ATA device has had polarity reversal feature since release 1.0 which can be applied to both the caller and the callee end. This feature is generally used for answer supervision on the caller side to signal to the attached equipment when the call has been connected (remote end has answered) or disconnected (remote end has hung up). This feature should be disabled for the called party (in other words, by using the same polarity for connected and idle state) and the C feature should be used instead. Without C enabled, reorder tone will is played after a configurable delay. If C is enabled, dial tone will be played when tip-to-ring voltage is restored Resolution is 1 second. The default is 2.


142

B


C Duration

Duration in seconds for which the tip-to-ring voltage is removed after the caller hangs up. After that, tip-to-ring voltage is restored and dial tone applies if the attached equipment is still off-hook. C is disabled if this value is set to 0. Range: 0 to 1.000 second. Resolution is 0.001 second. The default is 0 (C disabled).


Vertical Service Activation Codes section Vertical Service Activation Codes are automatically appended to the dial-plan. There is no need to include them in dial-plan, although no harm is done if they are included.

Call Return Code

This code calls the last caller. The default is *69.

Call Redial Code

Redials the last number called. This field is not found in the PAP2T. The default is *07.

Blind Transfer Code Begins a blind transfer of the current call to the extension specified after the activation code. The default is *98. Call Back Act Code Starts a callback when the last outbound call is not busy. The default is *66. Call Back Deact Code

Cancels a callback.

Call Back Busy Act Code

Starts a callback when the last outbound call is busy. This field is only found in the PAP2T.

The default is *86.

The default is *05 Cfwd All Act Code

Forwards all calls to the extension specified after the activation code. The default is *72.


143

B


Cfwd All Deact Code

Cancels call forwarding of all calls.

Cfwd Busy Act Code

Forwards busy calls to the extension specified after the activation code.

The default is *73.

The default is *90. Cfwd Busy Deact Code

Cancels call forwarding of busy calls.

Cfwd No Ans Act Code

Forwards no-answer calls to the extension specified after the activation code.

The default is *91.

The default is *92. Cfwd No Ans Deact Cancels call forwarding of no-answer calls. Code The default is *93. Cfwd Last Act Code

Forwards the last inbound or outbound calls to the extension specified after the activation code. The default is *63.

Cfwd Last Deact Code

Cancels call forwarding of the last inbound or outbound calls. The default is *83.

Block Last Act Code

Blocks the last inbound call.

Block Last Deact Code

Cancels blocking of the last inbound call.

Accept Last Act Code

Accepts the last outbound call. It lets the call ring through when do not disturb or call forwarding of all calls are enabled.

The default is *60.

The default is *80.

The default is *64. Accept Last Deact Code

Cancels the code to accept the last outbound call.

CW Act Code

Enables call waiting on all calls.

The default is *84.

The default is *56. CW Deact Code

Disables call waiting on all calls. The default is *57.


144

B


CW Per Call Act Code

Enables call waiting for the next call.

CW Per Call Deact Code

Disables call waiting for the next call.

The default is *71.

The default is *70.

Block CID Act Code Blocks caller ID on all outbound calls. The default is *67. Block CID Deact Code

Removes caller ID blocking on all outbound calls.

Block CID Per Call Act Code

Blocks caller ID on the next outbound call.

Block CID Per Call Deact Code

Removes caller ID blocking on the next inbound call.

Block ANC Act Code

Blocks all anonymous calls.

Block ANC Deact Code

Removes blocking of all anonymous calls.

DND Act Code

Enables the do not disturb feature.

The default is *68.

The default is *81.

The default is *82.

The default is *77.

The default is *87.

The default is *78. DND Deact Code

Disables the do not disturb feature. The default is *79.

CID Act Code

Enables caller ID generation. The default is *65.

CID Deact Code

Disables caller ID generation. The default is *85.

CWCID Act Code

Enables call waiting, caller ID generation. The default is *25.

CWCID Deact Code


Disables call waiting, caller ID generation. The default is *45.

145

B


Dist Ring Act Code

Enables the distinctive ringing feature. The default is *26

Dist Ring Deact Code

Disables the distinctive ringing feature.

Speed Dial Act Code

Assigns a speed dial number.

Secure All Call Act Code

Makes all outbound calls secure.

Secure No Call Act Code

Makes all outbound calls not secure.

Secure One Call Act Code

Makes the next outbound call secure. (It is redundant if all outbound calls are secure by default.)

The default is *46.

The default is *74.

The default is *16.

The default is *17.

The default is *18. Secure One Call Deact Code

Makes the next outbound call not secure. (It is redundant if all outbound calls are not secure by default.) The default is *19.

Conference Act Code

If this code is specified, the must enter it before dialing the third party for a conference call. Enter the code for a conference call.

Attn-Xfer Act Code

If the code is specified, the must enter it before dialing the third party for a call transfer. Enter the code for a call transfer.

Modem Line Toggle Toggles the line to a modem. Code The default is *99. Modem -through mode can be triggered only by pre-dialing this code. FAX Line Toggle Code

Toggles the line to a fax machine. This field is not found in the PAP2T. The default is #99.


146


Referral Services Codes

B These codes tell the ATA device what to do when the places the current call on hold and is listening to the second dial tone. One or more *code can be configured into this parameter, such as *98, or *97|*98|*123, etc. Max total length is 79 chars. This parameter applies when the places the current call on hold (by Hook Flash) and is listening to second dial tone. Each *code (and the following valid target number according to current dial plan) entered on the second dial-tone triggers the ATA device to perform a blind transfer to a target number that is prepended by the service *code. For example, after the dials *98, the ATA device plays a special dial tone called the Prompt Tone while waiting for the the enter a target number (which is checked according to dial plan as in normal dialing). When a complete number is entered, the ATA device sends a blind REFER to the holding party with the Refer-To target equals to *98 target_number. This feature allows the ATA device to hand off a call to an application server to perform further processing, such as call park. The *codes should not conflict with any of the other vertical service codes internally processed by the ATA device. You can empty the corresponding *code that you do not want to ATA device to process.


147

B


Feature Dial Services Codes

These codes tell the ATA device what to do when the is listening to the first or second dial tone. One or more *code can be configured into this parameter, such as *72, or *72|*74|*67|*82, etc. Max total length is 79 chars. This parameter applies when the has a dial tone (first or second dial tone). Enter *code (and the following target number according to current dial plan) entered at the dial tone triggers the ATA device to call the target number prepended by the *code. For example, after dials *72, the ATA device plays a special tone called a Prompt tone while awaiting the to enter a valid target number. When a complete number is entered, the ATA device sends a INVITE to *72 target_number as in a normal call. This feature allows the proxy to process features like call forward (*72) or BLock Caller ID (*67). The *codes should not conflict with any of the other vertical service codes internally processed by the ATA device. You can empty the corresponding *code that you do not want to ATA device to process. You can add a parameter to each *code in Features Dial Services Codes to indicate what tone to play after the *code is entered, such as *72‘c‘|*67‘p‘. Below are a list of allowed tone parameters (note the use of back quotes surrounding the parameter w/o spaces) ‘c‘ = ‘d‘ = ‘m‘ = <MWI Dial Tone> ‘o‘ = ‘p‘ = ‘s‘ = <Second Dial Tone> ‘x‘ = No tones are place, x is any digit not used above If no tone parameter is specified, the ATA device plays Prompt tone by default. If the *code is not to be followed by a phone number, such as *73 to cancel call forwarding, do not include it in this parameter. In that case, simple add that *code in the dial plan and the ATA device send INVITE *73@..... as usual when dials *73.


148

B



Vertical Service Announcement Codes section (SPA2102, SPA8000)

Service Annc Base Number

Base number for service announcements.

Service Annc Extension Codes

Extension codes for service announcements.


Outbound Call Codec Selection Codes section These codes automatically appended to the dial-plan. So no need to include them in dial-plan (although no harm to do so either).

Prefer G711u Code Makes this codec the preferred codec for the associated call. The default is *017110. Force G711u Code

Makes this codec the only codec that can be used for the associated call. The default is *027110.

Prefer G711a Code Makes this codec the preferred codec for the associated call. The default is *017111 Force G711a Code


Prefer G723 Code

Makes this codec the preferred codec for the associated call. The default is *01723.


149

B


Force G723 Code


Prefer G726r16 Code


Force G726r16 Code


Prefer G726r24 Code


Force G726r24 Code


Prefer G726r32 Code


Force G726r32 Code


Prefer G726r40 Code


Force G726r40 Code


Prefer G729a Code Makes this codec the preferred codec for the associated call. The default is *01729. Force G729a Code



150

B



Miscellaneous section

Set Local Date (mm/dd)

Sets the local date (mm stands for months and dd stands for days). The year is optional and uses two or four digits.

Set Local Time (HH/ Sets the local time (hh stands for hours and mm stands for mm) minutes). Seconds are optional. Time Zone

Selects the number of hours to add to GMT to generate the local time for caller ID generation. Choices are GMT-12:00, GMT-11:00,…, GMT, GMT+01:00, GMT+02:00, …, GMT+13:00. The default is GMT-08:00.

FXS Port Impedance

Sets the electrical impedance of the FXS port. Choices are 600, 900, 600+2.16uF, 900+2.16uF, 270+750||150nF, 220+850||120nF, 220+820||115nF, or 200+600||100nF. The default is 600. NOTE For New Zealand impedance (370+620||310nF), use 270+750||150nF.


151

B


Daylight Saving Time Rule

Enter the rule for calculating daylight saving time; it should include the start, end, and save values. This rule is comprised of three fields. Each field is separated by ; (a semicolon) as shown below. Optional values inside [ ] (the brackets) are assumed to be 0 if they are not specified. Midnight is represented by 0:0:0 of the given date. SYNTAX: Start = <start-time>; end=<end-time>; save = <save-time>. The <start-time> and <end-time> values specify the start and end dates and times of daylight saving time. Each value is in this format: <month> / / <weekday>[/ HH:[mm[:ss]]] The <save-time> value is the number of hours, minutes, and/or seconds to add to the current time during daylight saving time. The <save-time> value can be preceded by a negative (-) sign if subtraction is desired instead of addition. The <save-time> value is in this format: [/[+|-]HH:[mm[:ss]]] The <month> value equals any value in the range 1-12 (January-December). The value equals [+|-] any value in the range 1-31. If is 1, it means the <weekday> on or before the end of the month (in other words the last occurrence of < weekday> in that month). The <weekday> value equals any value in the range 1-7 (Monday-Sunday). It can also equal 0. If the <weekday> value is 0, this means that the date to start or end daylight saving is exactly the date given. In that case, the value must not be negative. If the <weekday> value is not 0 and the value is positive, then daylight saving starts or ends on the <weekday> value on or after the date given. If the <weekday> value is not 0 and the value is negative, then daylight saving starts or ends on the <weekday> value on or before the date given. The abbreviation HH stands for hours (0-23). The abbreviation mm stands for minutes (0-59). The abbreviation ss stands for seconds (0-59). The default Daylight Saving Time Rule is start=4/1/ 7;end=10/-1/7;save=1.


152

B


Daylight Saving Time Enable

Daylight Saving Time can be turned on or off. This option affects the time stamp on CallerID and affects all the lines and extensions of the phone. Default is Yes (on).

FXS Port Input Gain Input gain in dB, up to three decimal places. The range is 6.000 to -12.000. The default is -3. FXS Port Output Gain

Output gain in dB, up to three decimal places. The range is 6.000 to -12.000. The Call Progress Tones and DTMF playback level are not affected by the FXS Port Output Gain parameter. The default is -3.

DTMF Playback Level

Local DTMF playback level in dBm, up to one decimal place. The default is -16.0.

DTMF Playback Length

Local DTMF playback duration in milliseconds.

Detect ABCD

To enable local detection of DTMF ABCD, select yes. Otherwise, select no.

The default is .1.

The default is yes. Setting has no effect if DTMF Tx Method is INFO; ABCD is always sent OOB regardless in this setting. Playback ABCD

To enable local playback of OOB DTMF ABCD, select yes. Otherwise, select no. The default is yes.


153

B


Caller ID Method

The following choices are available: •

Bellcore (N.Amer,China)—CID, CIDCW, and VMWI. FSK sent after first ring (same as ETSI FSK sent after first ring) (no polarity reversal or DTAS).

•

DTMF (Finland, Sweden)—CID only. DTMF sent after polarity reversal (and no DTAS) and before first ring.

•

DTMF (Denmark)—CID only. DTMF sentbefore first ring with no polarity reversal and no DTAS.

•

ETSI DTMF—CID only. DTMF sent after DTAS (and no polarity reversal) and before first ring.

•

ETSI DTMF With PR—CID only. DTMF sent after polarity reversal and DTAS and before first ring.

•

ETSI DTMF After Ring—CID only. DTMF sent after first ring (no polarity reversal or DTAS).

•

ETSI FSK—CID, CIDCW, and VMWI. FSK sent after DTAS (but no polarity reversal) and before first ring. Waits for ACK from E after DTAS for CIDCW.

•

ETSI FSK With PR (UK)—CID, CIDCW, and VMWI. FSK is sent after polarity reversal and DTAS and before first ring. Waits for ACK from E after DTAS for CIDCW. Polarity reversal is applied only if equipment is on hook.

•

DTMF (Denmark) With PR—CID only. DTMF sent after polarity reversal (and no DTAS) and before first ring.

The default is Bellcore(N.Amer, China). Caller ID FSK Standard

The ATA device s bell 202 and v.23 standards for caller ID generation. Select the FSK standard you want to use, bell 202 or v.23. The default is bell 202. This field is not found in the PAP2T.

FXS Port Power Limit

The choices are from 1 to 8. This field is only found in the PAP2T. The default is 3.

Feature Invocation Method

Select the method you want to use, Default or Sweden default. This field is not found in the PAP2T. The default is Default.


154

B

ATA Voice Field Reference Line page

More Echo Suppression

Enable or disable more echo suppresion. The default is no. This field is not found in the PAP2T.

Line page Depending on the ATA device, there may be one or more Line pages (L1, L2, and so on). You can use the Voice tab > Line page to configure the lines for voice service.

NOTE Depending on the ATA model, some of the described settings may appear on

pages other than the Line page. •

On the SPA2102, refer to the Line pages and the corresponding pages.

•

On the SPA8800, refer to the Phone pages 1 to 4 to configure the settings for the Phone (FXS) ports 1 to 4. Refer to the Line pages to configure the settings for the Line (FXO) ports 1 to 4.

With some variations, depending on the model, this page includes the following sections: •

“Line Enable section” section on page 156

•

“Streaming Audio Server (SAS) section” section on page 157

•

“NAT Settings section” section on page 158

•

“Network Settings section” section on page 159

•

“SIP Settings section” section on page 160

•

“Call Feature Settings section” section on page 163

•

“Proxy and Registration section” section on page 192

•

“Subscriber Information section” section on page 166

•

“Supplementary Service Subscription section” section on page 167

•

“Audio Configuration section” section on page 169

•

“VoIP Fallback to PSTN section (SPA3102 and SPA8800)” section on page 175


155

B


•

“Gateway s section (SPA3102)” section on page 174

•

“Dial Plan section” section on page 175

•

“FXS Port Polarity Configuration section” section on page 177

•

“VoIP-to-PSTN Gateway Setup section (SPA8800),” on page 177

•

“PSTN-To-VoIP Gateway Setup section (SPA8800),” on page 178

•

“Call Forward, Speed Dial, Supplementary Services, and Ring Settings (SPA8000 and SPA8800),” on page 184

In a configuration profile, the Line parameters must be appended with the appropriate numeral (for example, [1] or [2]) to identify the line to which the setting applies. The number of lines varies with the model of the ATA device. For example, the SPA2102 provides two Line tabs (Line 1 and Line 2), while the SPA8000 provides eight tabs (Line1 through Line 8). Voice tab > Line page >

Line Enable section

Line Enable

To enable this line for service, select yes. Otherwise, select no. The default is yes.

Trunk Enable

To add this line to a trunk group, choose the trunk group number. Otherwise, choose none. This feature is available on the SPA8000 only. The default is none.


156

B


Voice tab > Line page >

Streaming Audio Server (SAS) section On the SPA8800, these settings are configured on the Phone pages only.

SAS Enable

To enable the use of the line as a streaming audio source, select yes. Otherwise, select no. If enabled, the line cannot be used for outgoing calls. Instead, it auto-answers incoming calls and streams audio RTP packets to the caller. The default is no.

SAS DLG Refresh Intvl

If this value is not zero, it is the interval at which the streaming audio server sends out session refresh (SIP reINVITE) messages to determine whether the connection to the caller is still active. If the caller does not respond to the refresh message, the ATA device ends this call with a SIP BYE message. The range is 0 to 255 seconds (0 means that the session refresh is disabled). The default is 30.


157

B


SAS Inbound RTP Sink

This setting works around devices that do not play inbound RTP if the streaming audio server line declares itself as a send-only device and tells the client not to stream out audio. Enter a Fully Qualified Domain Name (FQDN) or IP address of an RTP sink; this value is used by the streaming audio server line in the SDP of its 200 response to an inbound INVITE message from a client. The purpose of this parameter is to work around devices that do not play inbound RTP if the SAS line declares itself as a send-only device and tells the client not to stream out audio. This parameter is a FQDN or IP address of a RTP sink to be used by the SPA SAS line in the SDP of its 200 response to inbound INVITE from a client. It will appear in the c = line and the port number and, if specified, in the m = line of the SDP. If this value is not specified or equal to 0, then c = 0.0.0.0 and a=sendonly will be used in the SDP to tell the SAS client to not to send any RTP to this SAS line. If a non-zero value is specified, then a=sendrecv and the SAS client will stream audio to the given address. Special case: If the value is $IP, then the SAS line’s own IP address is used in the c = line and a=sendrecv. In that case the SAS client will stream RTP packets to the SAS line. The default value is empty.


NAT Settings section

NAT Mapping Enable

To use externally mapped IP addresses and SIP/RTP ports in SIP messages, select yes. Otherwise, select no. The default is no.

NAT Keep Alive Enable

To send the configured NAT keep alive message periodically, select yes. Otherwise, select no. The default is no.

NAT Keep Alive Msg

Enter the keep alive message that should be sent periodically to maintain the current NAT mapping. If the value is $NOTIFY, a NOTIFY message is sent. If the value is $, a message without is sent. The default is $NOTIFY.


158

B


NAT Keep Alive Dest

Destination that should receive NAT keep alive messages. If the value is $PROXY, the messages are sent to the current proxy server or outbound proxy server. The default is $PROXY.


Network Settings section

SIP ToS/DiffServ Value

TOS/DiffServ field value in UDP IP packets carrying a SIP message. The default is 0x68.

SIP CoS Value [0-7] CoS value for SIP messages. The default is 3. RTP ToS/DiffServ Value

ToS/DiffServ field value in UDP IP packets carrying RTP data. The default is 0xb8.

RTP CoS Value [07]

CoS value for RTP data.

Network Jitter Level

Determines how jitter buffer size is adjusted by the ATA device. Jitter buffer size is adjusted dynamically. The minimum jitter buffer size is 30 milliseconds or (10 milliseconds + current RTP frame size), whichever is larger, for all jitter level settings. However, the starting jitter buffer size value is larger for higher jitter levels. This setting controls the rate at which the jitter buffer size is adjusted to reach the minimum. Select the appropriate setting: low, medium, high, very high, or extremely high.

The default is 6.

The default is high. Jitter Buffer Adjustment

Controls how the jitter buffer should be adjusted. Select the appropriate setting: up and down, up only, down only, or disable. The default is up and down.


159

B



SIP Settings section

Field

Description

SIP Transport

The T choice provides “guaranteed delivery,” which assures that lost packets are retransmitted. T also guarantees that the SIP packages are received in the same order that they were sent. As a result, T overcomes the main disadvantages of UDP. In addition, for security reasons, most corporate firewalls block UDP ports. With T, new ports do not need to be opened or packets dropped, because T is already in use for basic activities such as Internet browsing or e-commerce. Options are: UDP, T, TLS. The default is UDP. Applies to SPA2102, SPA3102, and SPA8800.

SIP Port

Port number of the SIP message listening and transmission port. The default is 5060.

SIP 100REL Enable

To enable the of 100REL SIP extension for reliable transmission of provisional responses (18x) and use of PRACK requests, select yes. Otherwise, select no. The default is no.

EXT SIP Port

The external SIP port number.

Auth ResyncReboot

If this feature is enabled, the ATA device authenticates the sender when it receives the NOTIFY resync reboot (RFC 2617) message. To use this feature, select yes. Otherwise, select no. The default is yes.

SIP Proxy-Require

The SIP proxy can a specific extension or behavior when it sees this header from the agent. If this field is configured and the proxy does not it, it responds with the message, uned. Enter the appropriate header in the field provided.

SIP Remote-PartyID

To use the Remote-Party-ID header instead of the From header, select yes. Otherwise, select no. The default is yes.


160

B


SIP GUID

This field is not found in the PAP2T. The Global Unique ID is generated for each line for each device. When it is enabled, the ATA device adds a GUID header in the SIP request. The GUID is generated the first time the unit boots up and stays with the unit through rebooting and even factory reset. This feature was requested by Bell Canada (Nortel) to limit the registration of SIP s. The default is yes.

SIP Debug Option

RTP tvl


SIP messages are received at or sent from the proxy listen port. This feature controls which SIP messages to log. Choices are as follows: •

none—No logging.

•


•


•


•


•


•


•


•


•


•


•


The interval for the RTP log.

161

B


Restrict Source IP

If Lines 1 and 2 use the same SIP Port value and the Restrict Source IP feature is enabled, the proxy IP address for Lines 1 and 2 is treated as an acceptable IP address for both lines. To enable the Restrict Source IP feature, select yes. Otherwise, select no. If configured, the PAP2T will drop all packets sent to its SIP Ports originated from an untrusted IP address. A source IP address is untrusted if it does not match any of the IP addresses resolved from the configured Proxy (or Outbound Proxy if Use Outbound Proxy is yes). The default is no.

Referor Bye Delay

Controls when the ATA device sends BYE to terminate stale call legs upon completion of call transfers. Multiple delay settings (Referor, Refer Target, Referee, and Refer-To Target) are configured on this screen. For the Referor Bye Delay, enter the appropriate period of time in seconds. The default is 4.

Refer Target Bye Delay

For the Refer Target Bye Delay, enter the appropriate period of time in seconds. The default is 0.

Referee Bye Delay

For the Referee Bye Delay, enter the appropriate period of time in seconds. The default is 0.

Refer-To Target

To the refer-to target, select yes. Otherwise, select no. The default is no.

Sticky 183

If this feature is enabled, the IP telephony ignores further 180 SIP responses after receiving the first 183 SIP response for an outbound INVITE. To enable this feature, select yes. Otherwise, select no. The default is no.

Auth INVITE


When enabled, authorization is required for initial incoming INVITE requests from the SIP proxy.

162

B


Reply 182 On Call Waiting

When this feature is enabled, your ATA device replies with a SIP 182 response to the caller if it is already in a call and the phone is off-hook. To use this feature, select yes. Otherwise, keep the default, no. This field is found on the SPA2102, SPA3102, SPA8800 only.

Use Anonymous with RPID

When set to yes, use “anonymous” in the SIP message when remote party ID is requested in the SIP message. This field is found on the SPA2102 only. Default is yes.

Use Local Addr in FROM

The IP address of the local address enclosed in the FROM of the SIP message. This field is found on the SPA2102 only. Default is no.


Call Feature Settings section On the SPA8800, these settings are configured on the Phone pages only.

Blind Attn-Xfer Enable

Enables the ATA device to perform an attended transfer operation by ending the current call leg and performing a blind transfer of the other call leg. If this feature is disabled, the ATA device performs an attended transfer operation by referring the other call leg to the current call leg while maintaining both call legs. To use this feature, select yes. Otherwise, select no. The default is no.

MOH Server

ID or URL of the auto-answering streaming audio server. When only a ID is specified, the current or outbound proxy is ed. Music-on-hold is disabled if the MOH Server is not specified.

Conference Bridge URL

This feature s external conference bridging for nway conference calls (n > 2), instead of mixing audio locally. To use this feature, set this parameter to that of the server’s name, for example, [email protected]:12345 or conf (which uses the Proxy value as the domain). This field is found on the SPA2102 and PAP2T only.


163

B


Conference Bridge Ports

Select the maximum number of conference call participants. The range is 3 to 10. The default is 3. This field is found on the SPA2102 and PAP2T only.

Voice tab > Line page or Phone page>

Proxy and Registration section

Proxy

SIP proxy server for all outbound requests.

Outbound Proxy

SIP Outbound Proxy Server where all outbound requests are sent as the first hop.

Use Outbound Proxy

Enablse the use of an Outbound Proxy. If set to no, the Outbound Proxy and Use OB Proxy in Dialog parameters are ignored. The default is no.

Use OB Proxy In Dialog

Whether to force SIP requests to be sent to the outbound proxy within a dialog. Ignored if the parameter Use Outbound Proxy is no, or the Outbound Proxy parameter is empty. The default is yes.

Enable periodic registration with the Proxy parameter. This parameter is ignored if Proxy is not specified. The default is yes.

Make Call Without Reg

Allow making outbound calls without successful (dynamic) registration by the unit. If No, dial tone will not play unless registration is successful. The default is no.

Expires

Allow answering inbound calls without successful (dynamic) registration by the unit. If proxy responded to with a smaller Expires value, the PAP2T will renew registration based on this smaller value instead of the configured value. If registration failed with an Expires too brief error response, the PAP2T will retry with the value given in the Min-Expires header in the error response. The default is 3600.


164

B


Ans Call Without Reg

Expires value in sec in a request. The PAP2T will periodically renew registration shortly before the current registration expired. This parameter is ignored if the parameter is no. Range: 0 – (231 – 1) sec

Use DNS SRV

Whether to use DNS SRV lookup for Proxy and Outbound Proxy. The default is no.

DNS SRV Auto Prefix

If enabled, the PAP2T will automatically prepend the Proxy or Outbound Proxy name with _sip._udp when performing a DNS SRV lookup on that name. The default is no.

Proxy Fallback Intvl This parameter sets the delay (sec) after which the PAP2T will retry from the highest priority proxy (or outbound proxy) servers after it has failed over to a lower priority server. This parameter is useful only if the primary and backup proxy server list is provided to the PAP2T via DNS SRV record lookup on the server name. (Using multiple DNS A record per server name does not allow the notion of priority and so all hosts will be considered at the same priority and the PAP2T will not attempt to fall back after a fail over). The default is 3600 Proxy Redundancy Method

PAP2T will make an internal list of proxies returned in DNS SRV records. In normal mode, this list will contain proxies ranked by weight and priority. if Based on SRV port is configured the PAP2T does normal first, and also inspect the port number based on 1st proxy’s port on the list. The default is Normal.

Voice Mail Server

Enter the URL or IP address of the server.

Mailbox Subscribe Expires

Expiry time to the voice mail server. The time to send another subscribe message to the voice mail server.


165

B



Subscriber Information section

Display Name

Display name for caller ID.

ID

Extension number to identify this line.

for this line.

Use Auth ID

To use the authentication ID and for SIP authentication, select yes. Otherwise, select no to use the ID and . The default is no.

Auth ID

Authentication ID for SIP authentication.

Directory Number

Enter the number for this line.

Call Capacity

Maximum number of calls allowed on this line interface. Choices: {unlimited,1,2,3,…25 }. Default is 16. Note that the the ATA device does not distinguish between incoming and outgoing calls when talking about call capacity. NOTE: unlimited = 16

Cfwd No Ans Delay Delay, in seconds, before the call forwarding of no-answer calls feature is triggered. The default is 20. Mini Certificate

Base64 encoded of Mini-Certificate concatenated with the 1024-bit public key of the CA g the MC of all subscribers in the group. The default is empty.

SRTP Private Key

Base64 encoded of the 512-bit private key per subscriber for establishment of a secure call. The default is empty.


166

B



Supplementary Service Subscription section The ATA device provides native of a large set of enhanced or supplementary services. All of these services are optional. The parameters listed in the following table are used to enable or disable a specific supplementary service. A supplementary service should be disabled if a) the has not subscribed for it, or b) the Service Provider intends to similar service using other means than relying on the ATA device. On the SPA8800, these settings are configured on the Phone pages only.

Call Waiting Serv

Enable Call Waiting Service. The default is yes.

Block CID Serv

Enable Block Caller ID Service. The default is yes.

Block ANC Serv

Enable Block Anonymous Calls Service The default is yes.

Dist Ring Serv

Enable Distinctive Ringing Service The default is yes.

Cfwd All Serv

Enable Call Forward All Service The default is yes.

Cfwd Busy Serv

Enable Call Forward Busy Service The default is yes.

Cfwd No Ans Serv

Enable Call Forward No Answer Service The default is yes.

Cfwd Sel Serv

Enable Call Forward Selective Service The default is yes.

Cfwd Last Serv

Enable Forward Last Call Service The default is yes.

Block Last Serv

Enable Block Last Call Service The default is yes.


167

B


Accept Last Serv

Enable Accept Last Call Service The default is yes.

DND Serv

Enable Do Not Disturb Service The default is yes.

CID_Serv

Enable Caller ID Service The default is yes.

CWCID Serv

Enable Call Waiting Caller ID Service The default is yes.

Call Return Serv

Enable Call Return Service The default is yes.

Call Redial Serv

Enable Call Redial Service. This field is not found in the PAP2T.

Call Back Serv

Enable Call Back Service.

Three Way Call Serv

Enable Three Way Calling Service. Three Way Calling is required for Three Way Conference and Attended Transfer. The default is yes.

Three Way Conf Serv

Enable Three Way Conference Service. Three Way Conference is required for Attended Transfer. The default is yes.

Attn Transfer Serv

Enable Attended Call Transfer Service. Three Way Conference is required for Attended Transfer. The default is yes.

Unattn Transfer Serv

Enable Unattended (Blind) Call Transfer Service.

MWI Serv

Enable MWI Service. MWI is available only if a Voice Mail Service is set-up in the deployment.

The default is yes.

The default is yes. VMWI Serv

Enable VMWI Service (FSK). The default is yes.

Speed Dial Serv

Enable Speed Dial Service. The default is yes.


168

B


Secure Call Serv

Enable Secure Call Service. The default is yes.

Referral Serv

Enable Referral Service. See the Referral Services Codes parameter for more details. The default is yes.

Feature Dial Serv

Enable Feature Dial Service. See the Feature Dial Services

Codes parameter for more details. The default is yes. Service Announcement Serv

Enable Service Announcement Service. The default is yes.


Audio Configuration section A codec resource is considered as allocated if it has been included in the SDP codec list of an active call, even though it eventually may not be the one chosen for the connection. So, if the G.729a codec is enabled and included in the codec list, that resource is tied up until the end of the call whether or not the call actually uses G.729a. If the G.729a resource is already allocated and since only one G.729a resource is allowed per device, no other low-bit-rate codec may be allocated for subsequent calls; the only choices are G711a and G711u. On the other hand, two G.723.1/G.726 resources are available per device. Therefore it is important to disable the use of G.729a in order to guarantee the of two simultaneous G.723/G.726 codec.

Preferred Codec

Preferred codec for all calls. (The actual codec used in a call still depends on the outcome of the codec negotiation protocol.) Select one of the following: G711u, G711a, G726-16, G726-24, G726-32, G726-40, G729a, or G723. The default is G711u.


169

B


Second Preferred Codec

Second preferred codec for all calls. (The actual codec used in a call still depends on the outcome of the codec negotiation protocol.) Select one of the following: Unspecified, G711u, G711a, G726-16, G726-24, G72632, G726-40, G729a, or G723. The default is Unspecified.

Third Preferred Codec

Third preferred codec for all calls. (The actual codec used in a call still depends on the outcome of the codec negotiation protocol.) Select one of the following: Unspecified, G711u, G711a, G726-16, G726-24, G72632, G726-40, G729a, or G723. The default is Unspecified.

Use Pref Codec Only

To use only the preferred codec for all calls, select yes. (The call fails if the far end does not this codec.) Otherwise, select no. The default is no.

Silence Supp Enable

To enable silence suppression so that silent audio frames are not transmitted, select yes. Otherwise, select no. The default is no.

Silence Threshold

Select the appropriate setting for the threshold: high, medium, or low. The default is medium.

G729a Enable

To enable the use of the G.729a codec at 8 kbps, select yes. Otherwise, select no. The default is yes.

Echo Canc Enable

To enable the use of the echo canceller, select yes. Otherwise, select no. The default is yes.

G723 Enable

To enable the use of the G.723a codec at 6.3 kbps, select yes. Otherwise, select no. The default is yes.

Echo Canc Adapt Enable

To enable the echo canceller to adapt, select yes. Otherwise, select no. The default is yes.


170

B


G726-16 Enable

To enable the use of the G.726 codec at 16 kbps, select yes. Otherwise, select no. The default is yes.

Echo Supp Enable

To enable the use of the echo suppressor, select yes. Otherwise, select no. The default is yes.

G726-24 Enable


FAX CED Detect Enable

To enable detection of the fax Caller-Entered Digits (CED) tone, select yes. Otherwise, select no. The default is yes.

G726-32 Enable


FAX CNG Detect Enable

To enable detection of the fax Calling Tone (CNG), select yes. Otherwise, select no. The default is yes.

G726-40 Enable


FAX thru Codec

Select the codec for fax through, G711u or G711a.

DTMF Process INFO

To use the DTMF process info feature, select yes. Otherwise, select no.

The default is G711u.

The default is yes. FAX Codec Symmetric

To force the ATA to use a symmetric codec during fax through, select yes. Otherwise, select no. The default is yes.

DTMF Process AVT To use the DTMF process AVT feature, select yes. Otherwise, select no. This field is not available for the PAP2T. The default is yes.


171

B


FAX thru Method

Select the fax through method: None, NSE, or ReINVITE. The default is NSE.

DTMF Tx Method

Select the method to transmit DTMF signals to the far end: InBand, AVT, INFO, Auto, InBand+INFO, or AVT+INFO. InBand sends DTMF using the audio path. AVT sends DTMF as eypents. INFO uses the SIP INFO method. Auto uses InBand or AVT based on the outcome of codec negotiation. The default is Auto.

DTMF Tx Mode

DTMF Detection Tx Mode is available for SIP information and AVT . Options are: Strict or Normal. The default is Strict for which the following are true: •

A DTMF digit requires an extra hold time after detection.

•

The DTMF level threshold is raised to -20 dBm.

•

The minimum and maximum duration thresholds are: • • • •

strict mode for AVT: 70 ms normal mode for AVT: 40 ms strict mode for SIP info: 90 ms normal mode for SIP info: 50 ms

DTMF Tx Strict Hold Off Time:

This parameter is in effect only when "DTMF Tx Mode" is set to "strict," and when"DTMF Tx Method" is set to out-ofband; i.e. either AVT or SIP-INFO. The value can be set as low as 40 ms. There is no maximum limit. A larger value will reduce the chance of talk-off (beeping) during conversation, at the expense of reduced performance of DTMF detection, which is needed for interactive voice response systems (IVR). Default: 90 ms

FAX Process NSE

To use the fax process NSE feature, select yes. Otherwise, select no. The default is yes.

Hook Flash Tx Method

Select the method for signaling hook flash events: None, AVT, or INFO. None does not signal hook flash events. AVT uses RFC2833 AVT (event = 16). INFO uses SIP INFO with the single line signal=hf in the message body. The MIME type for this message body is taken from the Hook Flash MIME Type setting. The default is None.


172

B


FAX Disable ECAN

If enabled, this feature automatically disables the echo canceller when a fax tone is detected. To use this feature, select yes. Otherwise, select no. The default is no.

Release Unused Codec

This feature allows the release of codecs not used after codec negotiation on the first call, so that other codecs can be used for the second line. To use this feature, select yes. Otherwise, select no. The default is yes.

FAX Enable T38

To enable the use of the ITU-T T.38 standard for faxing, select yes. Otherwise, select no. T.38 is ed by the SPA2102 and the SPA8000. The SPA2102 s a single T.38 connection. The SPA8000 s one T.38 connection for each of its four modules (Line 1-2, 3-4, 5-6, and 7-8). The SPA8000 s a maximum of four connections, but it does not two fax devices connected to the same module. The default is yes.

FAX T38 Redundancy

Select the appropriate number.

Fax Tone Detect Mode

If you want the Gateway to detect the fax tone whether the Gateway is a caller or callee, then select caller or callee. If you want the Gateway to detect the fax tone only if the Gateway is the caller, then select caller only. If you want the Gateway to detect the fax tone only if the Gateway is the callee, then select callee only.

FAX Tone Detect Mode

This parameter has three possible values:

The default is 1.

•

caller or callee - SPA will detect FAX tone whether it is callee or caller

•

caller only - SPA will detect FAX tone only if it is the caller

•

callee only - SPA will detect FAX tone only if it is the callee

The default is caller or callee.


173

B


Symmetric RTP

(SPA3102 and AG310only) Enable symmetric RTP operation. If enabled, the SPA3102 sends RTP packets to the source address and port of the last received valid inbound RTP packet. If disabled (or before the first RTP packet arrives) the SPA3102 sends RTP to the destination as indicated in the inbound SDP. The default is yes.

Gateway s section (SPA3102)

Gateway1/2/3/4

The first of 4 gateways that can be specified to be used in the to facilitate call routing specification (that overrides the given proxy information). This gateway is represented by gw1 in the . For example, the rule 1408xxxxxxx<:@gw1> can be added to the dial plan such that when the dials 1408+7digits, the call will be routed to Gateway 1. Without the <:@gw1> syntax, all calls are routed to the given proxy by default (except IP dialing). The default is blank.

GW1/2/3/4 NAT Mapping Enable

If enabled, the ATA device uses NAT mapping when ing Gateway 1. The default is no.

GW1/2/3/4 Auth ID

This value is the authentication -id to be used by the SPA to authenticate itself to Gateway 1. The default is blank.

GW1/2/3/4

This value is the to be used by the SPA to authenticate itself to Gateway 1. The default is blank.


174

B



VoIP Fallback to PSTN section (SPA3102 and SPA8800) On the SPA8800, these settings are configured on the Phone pages only.

Auto PSTN Fallback If enabled, the ATA device automatically routes all calls to the PSTN gateway when the Line 1 proxy is down (registration failure or network link down). The default is yes.


Dial Plan section The dial plan determines how the entered digits are processed. On the SPA8800, the Line page includes the dial plan fields as described below. However, on the Phone page, the Dial Plans section provides eight spaces where you can enter up to eight dial plans. The dial plans in this pool can be associated with a VoIP Caller or a PSTN Caller. The dial plan syntax is consistent for all fields. The default dial plan script for each line is as follows: (*xx|[3469]11|0|00|[29]xxxxxx|1xxx[2-9]xxxxxx|x xxxxxxxxxxx.). The syntax for a dial plan expression is as follows:

Dial Plan Entry

Functionality

*xx

Allow arbitrary 2 digit star code

[3469]11

Allow x11 sequences

0

Operator

00

Int’l Operator

[2-9]xxxxxx

US local number

1xxx[2-9]xxxxxx

US 1 + 10-digit long distance number

xxxxxxxxxxxx.

Everything else (Int’l long distance, FWD, ...)


175

B


Dial Plan

Dial plan script for this line. The default is (*xx|[3469]11|0|00|[2-9]xxxxxx|1xxx[29]xxxxxxS0|xxxxxxxxxxxx.) The dial plan syntax is expanded in the SPA3102 to allow the designation of three parameters to be used with a specific gateway: •

uid – the authentication -id

•

pwd – the authentication

•

nat – if this parameter is present, use NAT mapping

Each parameter is separated by a semi-colon (;). Furthermore, it recognizes gw0, gw1, …, gw4 as the locally configured gateways, where gw0 represents the local PSTN gateway in the same SPA3102. Example 1: *1xxxxxxxxxx<:@fwdnat.pulver.com:5082;uid=jsmith;pwd=xy z

Example 2: *1xxxxxxxxxx<:@fwd.pulver.com;nat;uid=jsmith;pwd=xyz

Example 3: [39]11<:@gw0>

Enable IP Dialing

Enable or disable IP dialing. If IP dialing is enabled, one can dial [-id@]a.b.c.d[:port], where ‘@’, ‘.’, and ‘:’ are dialed by entering *, -id must be numeric (like a phone number) and a, b, c, d must be between 0 and 255, and port must be larger than 255. If port is not given, 5060 is used. Port and -Id are optional. If the -id portion matches a pattern in the dial plan, then it is interpreted as a regular phone number according to the dial plan. The INVITE message, however, is still sent to the outbound proxy if it is enabled. The default is no.


176

B


Emergency Number

Comma separated list of emergency number patterns. If outbound call matches one of the pattern, SPA will disable hook flash event handling. The condition is restored to normal after the phone is on-hook. Blank signifies no emergency number. Maximum number length is 63 characters. The default is blank.


FXS Port Polarity Configuration section On the SPA8800, these settings are configured on the Phone pages only.

Idle Polarity

Polarity before a call is connected: Forward or Reverse. The default is Forward.

Caller Conn Polarity Polarity after an outbound call is connected: Forward or Reverse. The default is Forward. Callee Conn Polarity

Polarity after an inbound call is connected: Forward or Reverse. The default is Forward.


VoIP-to-PSTN Gateway Setup section (SPA8800)

Line 1 VoIP Caller DP

Index of the dial plan in the dial plan pool to be used when the VoIP Caller is calling from Line 1 of the same SPA8800 unit during normal operation (in other words, not due to fallback to PSTN service when Line 1 VoIP service is down). Choose from {none, 1, 2, 3, 4, 5, 6, 7, 8} Authentication is skipped for Line 1 VoIP caller. The default is 1.


177

B


VoIP Caller Default DP

Index of the dial plan in the dial plan pool to be used as the default. Choose from {none, 1, 2, 3, 4, 5, 6, 7, 8}. The default is 1.

Line 1 Fallback DP

Index of the dial plan in the dial plan pool to be used when the VoIP Caller is calling from Line 1 of the same SPA8800 unit due to fallback to PSTN service when Line 1 VoIP service is down. Choose from {none, 1, 2, 3, 4, 5, 6, 7, 8}. The default is 1.

PSTN-To-VoIP Gateway Setup section (SPA8800)

PSTN CID for VoIP CID

Choose yes or no.

PSTN CID Number Prefix

The prefix to add to the caller ID number on the PBX to ensure that a callback goes to the correct number.

The default is no.

Enter the digits. PSTN caller Default Index of the dial plan in the dial plan pool to be used when DP the PSTN Caller is not authenticated. Choose from {1, 2, 3, 4, 5, 6, 7, 8}. The default is 1. Line 1 Signal Hook Flash to PSTN

The operation of the hook flash on the analog phone when a PSTN-to-VoIP call is active. Choose Disabled or Double Hook Flash. The default is Disabled.

PSTN CID Name Prefix

The prefix to add to the caller ID name that is sent to the PBX. Enter the characters to add to the caller ID name.


178

B



FXO Timer Values (sec) section (SPA8800)

PSTN Answer Delay

Delay in seconds before auto-answering inbound PSTN calls after the PSTN starts ringing. The range is 0-255. The default is 16.

PSTN-To-VoIP Call Max Dur

Limit on the duration of a PSTN-To-VoIP Gateway Call. Unit is in seconds. 0 means unlimited. The range is 02147483647. The default is 0.

VoIP-To-PSTN Call Max Dur

Limit on the duration of a VoIP-To-PSTN Gateway Call. Unit is in seconds. 0 means unlimited. The range is 02147483647. The default is 0.

VoIP DLG Refresh Intvl

Interval between (SIP) Dialog refresh messages sent by the SPA to detect if the VoIP call-leg is still up. If value is set to 0, SPA will not send refresh messages and VoIP call-leg status is not checked by the SPA. The refresh message is a SIP ReINVITE and the VoIP peer must response with a 2xx response. If VoIP peer does not reply or response is not greater than 2xx, the SPA will disconnect both PSTN and VoIP call legs automatically. The range is 0-255. The default is 30.

PSTN Ring Timeout Delay after a ring burst before the SPA decides that PSTN ring has ceased. The range is 0-255. The default is 5. PSTN Dialing Delay Delay after hook before the SPA dials a PSTN number. The range is 0-255. The default is 1. PSTN Dial Digit Len Determines the on/off time when transmitting digits through the FXO port. The syntax is on-time/off-time, where on-time and off-time are expressed in seconds with up to two decimal places, within the permitted range, which is from .05 to 3.00. The default is .1/.1. If this value is blank, the default is used.


179

B


PSTN Hook Flash Len

The length of the hook flash in seconds. During a PSTN-toVoIP gateway call, the ATA device processes the out-ofband hook flash signal sent from the VoIP peer through a hook-flash (momentary on-hook signal) on the FXO port. This allows the VoIP peer to initiate a three-way conference call and subsequent call transfer. The duration of the on-hook signal can be configured using this parameter. The default is 0.25. The permitted range is limited to 0.02 to 1.6 seconds.

PSTN Dial Digit Len Specify the on/off time when the Gateway transmits digits through the Line (FXO) port. The syntax is on-time/off-time, expressed in seconds with up to two decimal places. The permitted range is 0.05 to 3.00. The default is .1/.1. PSTN Hook Flash Len

Default is .25.


PSTN Disconnect Detection section (SPA8800) On the SPA8800, these settings are configured on the Phone pages only.

Detect C

C is a brief removal of tip-and-ring voltage. If enabled, the SPA will disconnect both call legs when this signal is detected during a gateway call. The default is yes.

Detect Polarity Reversal

If enabled, SPA will disconnect both call legs when this signal is detected during a gateway call. If it is a PSTN gateway call, the 1st polarity reversal is ignored and the 2nd one triggers the disconnection. For VoIP gateway call, the 1st polarity reversal triggers the disconnection. The default is yes.

Detect PSTN Long Silence

If enabled, SPA will disconnect both call legs when the PSTN side has no voice activity for a duration longer than the length specified in the PSTN Long Silence Duration parameter during a gateway call. The default is yes.


180

B


Detect VoIP Long Silence

If enabled, SPA will disconnect both call legs when the VoIP side has no voice activity for a duration longer than the length specified in the VoIP Long Silence Duration parameter during a gateway call. The default is no.

PSTN Long Silence This value is minimum length of PSTN silence (or inactivity) Duration in seconds to trigger a gateway call disconnection if Detect PSTN Long Silence is yes. The default is 30. VoIP Long Silence Duration

This value is minimum length of VoIP silence (or inactivity) in seconds to trigger a gateway call disconnection if Detect VoIP Long Silence is yes. The default is 30.

PSTN Silence Threshold

This parameter adjusts the sensitivity of PSTN silence detection. Choose from {very low, low, medium, high, very high}. The higher the setting, the easier to detect silence and hence easier to trigger a disconnection. The default is medium.

Min C Duration

Specify the minimum duration of a low tip-and-ring voltage (below 1V) for the Gateway to recognize it as a C signal or PSTN line removal. The default is 0.2.

Detect Disconnect Tone

If enabled, SPA will disconnect both call legs when it detects the disconnect tone from the PSTN side during a gateway call. Disconnect tone is specified in the Disconnect Tone parameter, which depends on the region of the PSTN service. The default is yes.


181

B


Disconnect Tone

This value is the tone script which describes to the SPA the tone to detect as a disconnect tone. The syntax follows a standard Tone Script with some restrictions. Default value is standard US reorder (fast busy) tone, for 4 seconds. Restrictions:

Disconnect Tone continued

•

2 frequency components must be given. If single frequency is desired, the same frequency is used for both

•

The tone level value is not used. –30 (dBm) should be used for now.

•

Only 1 segment set is allowed

•

Total duration of the segment set is interpreted as the minimum duration of the tone to trigger detection

•

6 segments of on/off time (seconds) can be specified. A 10% margin is used to validated cadence characteristics of the tone.

The Disconnect Tone Script values for various countries follow: US—480@-30,620@-30;4(.25/.25/1+2) UK—400@-30,400@-30; 2(3/0/1+2) —440@-30,440@-30; 2(0.5/0.5/1+2) —425@-10; 10(0.48/0.48/1) Netherlands—425@-30,425@-30; 2(0.5/0.5/1+2) Sweden—425@-10; 10(0.25/0.25/1) Norway—425@-10; 10(0.5/0.5/1) Italy—425@-30,425@-30; 2(0.2/0.2/1+2) Spain—425@-10; 10(0.2/0.2/1,0.2/0.2/1,0.2/0.6/1) Portugal—425@-10; 10(0.5/0.5/1) Poland—425@-10; 10(0.5/0.5/1) Denmark—425@-10; 10(0.25/0.25/1) New Zealand—400@-15; 10(0.25/0.25/1) Australia—425@-13; 10(0.375/0.375/1)


182

B



International Control section (SPA8800)

FXO Port Impedance

Desired impedance of the FXO Port. Choose from {600, 900, 370+620, 270+750||150nF, 220+820||120nF, 370 + 620 || 310nf, 320 + 1050 || 230nf, 370 + 820 || 110 nf, 275 + 780 || 115nf, 120 + 820 || 110nf, 350 + 1000 || 210nf, 0 + 900 || 130nf} The default is 600. The impedance values for various countries follows: US—600 EU (UK, , Netherlands, Sweden, Norway, Italy, Spain, Portugal, Poland, and Denmark)—270+750||150nF —270+750||150nF Australia—220+820||120nF New Zealand—370+620||310nF

Ring Frequency Min The lower limit of the ring frequency used to detect the ring signal. The default is 10. SPA To PSTN Gain

dB of digital gain (or attenuation if negative) to be applied to the signal sent from the SPA to the PSTN side. The range is -15 to 12. The default is 0.

Ring Frequency Max

The higher limit of the ring frequency used to detect the ring signal. The default is 90.

PSTN To SPA Gain

dB of digital gain (or attenuation if negative) to be applied to the signal sent from the PSTN side to the SPA. The range is -15 to 12. The default is 0.

Ring Validation Time


Specify the minimum signal duration required by the Gateway for recognition as a ring signal. The default is 256 ms.

183

B


Tip/Ring Voltage Adjust

Choices are {3.1, 3.2, 3.35, 3.5} (V).

Ring Indication Delay

Choose from {0, 256, 512, 768, 1024, 1280, 1536, 1792} (ms).

The default is 3.5 V.

The default is 512ms. Operational Loop Current Min

Choices for mA are: {10, 12, 14, 16).

Ring Timeout

Choose from {0, 128, 256, 384, 512, 640, 768, 896, 1024, 1152, 1280, 1408, 1536, 1664, 1792, 1920} (ms).

The default is 10 mA.

The default is 640 ms. On-Hook Speed

Choose from {Less than 0.5ms, 3ms (ETSI), 26ms (Australia)}. The default is Less than 0.5ms.

Ring Threshold

Choose from {13.5–16.5, 19.35–2.65, 40.5–49.5} (Vrms). The default is 13.5-16.5 Vrms.

Current Limiting Enable

Enable or disable current limiting.

Ringer Impedance

Choose from {High (Normal), Synthesized (Poland, S.Africa, Slovenia)}.

The default is no.

The default is High (Normal). Line-In-Use Voltage Determines the voltage threshold at which the SPA-3000 assumes the PSTN is in use by another handset sharing the same line (and will declare PSTN gateway service not available to incoming VoIP callers). The default value is 30.

Call Forward, Speed Dial, Supplementary Services, and Ring Settings (SPA8000 and SPA8800) On the SPA8000 and the SPA8800, you can configure settings for call forward, speed dial, and supplementary services, as well as ring settings. For field descriptions, see “ page,” on page 216.


184

B

ATA Voice Field Reference Trunk Group page (SPA8000)

Trunk Group page (SPA8000) On the SPA8000, you can use the Voice tab > Trunk Group pages (T1 ... T4) to configure the Trunk Groups. This page includes the following sections:

•


•


•


•


•


•

“Dial Plan section” section on page 191

•


Voice tab > Trunk Group page (SPA8000)>

Line Enable section

Line Enable






SIP CoS Value [0-7] CoS value for SIP messages. The default is 3.


185

B




SIP Transport

The T choice provides “guaranteed delivery”, which assures that lost packets are retransmitted. T also guarantees that the SIP packages are received in the same order that they were sent. As a result, T overcomes the main disadvantages of UDP. In addition, for security reasons, most corporate firewalls block UDP ports. With T, new ports do not need to be opened or packets dropped, because T is already in use for basic activities such as Internet browsing or e-commerce. Options are: UDP, T, TLS. The default is UDP.

SIP Port


SIP 100REL Enable


Auth ResyncReboot


SIP Proxy-Require


SIP Remote-PartyID



186

B


SIP GUID

This field is not found in the PAP2T. The Global Unique ID is generated for each line for each device. When it is enabled, the ATA device adds a GUID header in the SIP request. The GUID is generated the first time the unit boots up and stays with the unit through rebooting and even factory reset. This feature was requested by Bell Canada (Nortel) to limit the registration of SIP s. The default is yes.

SIP Debug Option


none—No logging.

•


•


•


•


•


•


•


•


•


•




187

B


Restrict Source IP


Referor Bye Delay




Referee Bye Delay


Refer-To Target


Auth INVITE


When enabled, authorization is required for initial incoming INVITE requests from the SIP proxy.

188

B


Voice tab > Trunk Group page > (SPA8000) >


Display Name


ID

Extension number for this line.

for this line.

Use Auth ID


Auth ID


Call Capacity

Maximum number of calls allowed on this trunk group. Choices: 1-15 or unlimited (16 calls). Default is unlimited. Both incoming call and outgoing call are counted towards this limit. The call capacity has the following impact on call handling:


•

Inbound calls: When the limit is reached, the Trunk SUA replies 486 to the caller.

•

Outbound calls: When the limit is reached, the Line SUA plays a fast busy tone to the caller. Note that a trunk line can make an outgoing call only through its own trunk. If that trunk reaches full capacity, it will not attempt to failover to use other trunks

189

B


List

This parameter determines which trunk lines to ring on an incoming call. When an incoming call is detected by the Trunk SUA (SIP Agent), the SUA first checks if there is capacity to handle the call. If not, the SUA rejects the call with a 486 response. If there is spare capacity, the SUA consults the List to determine which lines to ring (that is, for the proxy to send SIP INVITE to), and starts "hunting." The List specifies the lines, the hunt method, and other options. EXAMPLES: •

1,2,3,4,5,6,7,8,hunt=re;*;1 Lines 1 through 8 are participating (1,2,3,4,5,6,7,8). The Trunk SUA will hunt to each specified line in the specified order (hunt=re). The call stays with a selected line until the call is either answered, rejected, or cancelled by the caller (*). The Trunk SUA replies 486 right away if no line is available to ring at the moment (1).

•

?,hunt=al;30;0,cfwd=14089993326 A wildcard character is used to represent “all trunk lines.” All lines ring simultaneously (hunt=al). If there is no answer after 30 seconds (30), the call is forwarded to the specified number (cfwd=14089993326) .

•

?,hunt=ra;12;1,cfwd=14089993326 A wildcard character is used to represent “all trunk lines.” The Trunk SUA hunts in random order (hunt=ra). If there is no answer within 12 seconds (12), the Trunk SUA chooses another line at random. If there is no answer after 1 round (1), the call is forwarded to forwarded to the specified number (cfwd=14089993326).

List (continued)

NOTES: •

The Trunk SUA rings only trunk lines (lines that are assigned to a trunk group through the Voice tab > Line page, Trunk Group field). • •

•


The Trunk SUA will not ring any standalone lines that are included in the List. The Trunk SUA will ring any trunk line that is included in the list, even if it is not assigned to this particular trunk.

You can instruct the SPA8000 to hunt only the phones that are on-hook, through the Voice tab > SIP page, Trunking Parameters section, Hunt Policy field. See “Trunking Parameters section (SPA8000),” on page 133.

190

B


Voice tab > Trunk Group page (SPA8000) >

Dial Plan section

Field

Description

Dial Plan

Dial plan script for this trunk. NOTE: The trunk SUA will also apply the Trunk Dial Plan on the number before sending out INVITE to the ITSP. This Trunk Dial Plan typically is redundant since the trunk should trust the number sent by the Line SUA. By default the trunk dial plan allows any non-empty number: ([*#0-9AD][*#0-9A-D].)



NAT Mapping Enable




NAT Keep Alive Msg

Enter the keep alive message that should be sent periodically to maintain the current NAT mapping. If the value is $NOTIFY, a NOTIFY message is sent. If the value is $, a message without is sent. The default is $NOTIFY.

NAT Keep Alive Dest

Destination that should receive NAT keep alive messages. If the value is $PROXY, the messages are sent to the current proxy server or outbound proxy server. The default is $PROXY.


191

B




Proxy


Use Outbound Proxy

Enablse the use of an Outbound Proxy. If set to no, the Outbound Proxy and Use OB Proxy in Dialog parameters are ignored. The default is no.

Outbound Proxy



Whether to force SIP requests to be sent to the outbound proxy within a dialog. Ignored if the parameter Use Outbound Proxy is no, or the Outbound Proxy parameter is empty. The default is yes.

Enable periodic registration with the Proxy parameter. This parameter is ignored if Proxy is not specified. The default is yes.



Expires




Expires value in sec in a request. The PAP2T will periodically renew registration shortly before the current registration expired. This parameter is ignored if the parameter is no. Range: 0 – (231 – 1) sec

192

B


Use DNS SRV


DNS SRV Auto Prefix


Proxy Fallback Intvl This parameter sets the delay (sec) after which the PAP2T will retry from the highest priority proxy (or outbound proxy) servers after it has failed over to a lower priority server. This parameter is useful only if the primary and backup proxy server list is provided to the PAP2T via DNS SRV record lookup on the server name. (Using multiple DNS A record per server name does not allow the notion of priority and so all hosts will be considered at the same priority and the PAP2T will not attempt to fall back after a fail over). The default is 3600. Proxy Redundancy Method

PAP2T will make an internal list of proxies returned in DNS SRV records. In normal mode, this list will contain proxies ranked by weight and priority. if Based on SRV port is configured the PAP2T does normal first, and also inspect the port number based on 1st proxy’s port on the list. The default is Normal.

Voice Mail Server

Enter the URL or IP address of the server.

Mailbox Subscribe Expires

Expiry time to the voice mail server. The time to send another subscribe message to the voice mail server.


193

B

ATA Voice Field Reference PSTN Line page (SPA3102)

PSTN Line page (SPA3102) On the SPA3102, you can use the Voice tab > PSTN Line page to configure your PSTN line. This page includes the following sections: •


•


•


•


•


•


•

“Audio Configuration section” section on page 202

•

“Dial Plans section” section on page 205

•

“VoIP-To-PSTN Gateway Setup section” section on page 206

•

“VoIP s and s (HTTP Authentication) section” section on page 208

•

“FXO (PSTN) Timer Values (sec) section” section on page 209

•

“PSTN Disconnect Detection section” section on page 211

•

“International Control (Settings) section” section on page 214

Voice tab > PSTN Line page (SPA3102) >

Line Enable section

Line Enable


PSTN List


Select the appropriate list: None, Phone 1+2, Phone 1, or Phone 2. The default is Phone1+2.

194

B




NAT Mapping Enable




NAT Keep Alive Msg

Enter the keep alive message that should be sent periodically to maintain the current NAT mapping. If the value is $NOTIFY, a NOTIFY message is sent. If the value is $, a message without is sent. Escape sequence of %xx is also accepted. For example, %0d%0a is unescaped into \r\n (CRLF). The default is $NOTIFY.

NAT Keep Alive Dest

Destination that should receive NAT keep alive messages. If the value is $PROXY, the messages are sent to the current or outbound proxy. The default is $PROXY.





SIP CoS Value [0-7] CoS value for SIP messages. The default is 3.


195

B


RTP ToS/DiffServ Value

ToS/DiffServ field value in UDP IP packets carrying RTP data. The default is 0xb8.

RTP CoS Value [07]

CoS value for RTP data.

Network Jitter Level

Determines how jitter buffer size is adjusted by the ATA device. Jitter buffer size is adjusted dynamically. The minimum jitter buffer size is 30 milliseconds or (10 milliseconds + current RTP frame size), whichever is larger, for all jitter level settings. However, the starting jitter buffer size value is larger for higher jitter levels. This setting controls the rate at which the jitter buffer size is adjusted to reach the minimum. Select the appropriate setting: low, medium, high, very high, or extremely high.

The default is 6.

The default is high. Jitter Buffer Adjustment

Controls how the jitter buffer should be adjusted. Select the appropriate setting: up and down, up only, down only, or disable. The default is up and down.



SIP Port


SIP 100REL Enable


EXT SIP Port


The external SIP port number.

196

B


Auth ResyncReboot


SIP Proxy-Require


SIP Remote-PartyID


SIP GUID

This field is not available with the PAP2T. The Global Unique ID is generated for each line for each device. When it is enabled, the ATA device adds a GUID header in the SIP request. The GUID is generated the first time the unit boots up and stays with the unit through rebooting and even factory reset. This feature was requested by Bell Canada (Nortel) to limit the registration of SIP s. The default is yes.


197

B


SIP Debug Option


none—No logging.

•


•


•


•


•


•


•


•


•


•


The default is none. RTP tvl

The interval for the RTP log.

Restrict Source IP



198

B


Referor Bye Delay




Referee Bye Delay


Refer-To Target


Sticky 183

If this feature is enabled, the IP telephony ignores further 180 SIP responses after receiving the first 183 SIP response for an outbound INVITE. To enable this feature, select yes. Otherwise, select no. The default is no.



Proxy


Use Outbound Proxy

Enable the use of Outbound Proxy. If set to no, the Outbound Proxy parameter and Use OB Proxy in Dialog is ignored. The default is no.

Outbound Proxy



199

B



Whether to force SIP requests to be sent to the outbound proxy within a dialog. Ignored if the Use Outbound Proxy parameter is no, or if the Outbound Proxy parameter is empty. The default is yes.

Enable periodic registration with the Proxy. This parameter is ignored if the Proxy parameter is not specified. The default is yes.



Expires



Expires value in sec in a request. PAP2T will periodically renew registration shortly before the current registration expired. This parameter is ignored if the parameter is no. Range: 0 – (231 – 1) sec

Use DNS SRV


DNS SRV Auto Prefix



200

B


Proxy Fallback Intvl This parameter sets the delay (sec) after which the PAP2T will retry from the highest priority proxy (or outbound proxy) servers after it has failed over to a lower priority server. This parameter is useful only if the primary and backup proxy server list is provided to the PAP2T via DNS SRV record lookup on the server name. (Using multiple DNS A record per server name does not allow the notion of priority and so all hosts will be considered at the same priority and the PAP2T will not attempt to fall back after a fail over). The default is 3600 Proxy Redundancy Method

The PAP2T makes an internal list of proxies returned in DNS SRV records. In normal mode this list will contain proxies ranked by weight and priority. If the parameter Based on SRV port is configured, the PAP2T creates a list in normal mode first, and then inspects the port numbers based on the 1st proxy’s port on the list. The default is Normal.



Display Name


ID

Extension number for this line.

for this line.

Use Auth ID


Auth ID


Call Capacity

Maximum number of calls allowed on this line interface. Choices: {unlimited,1,2,3,…25 }. Default is 16. Note that the ATA device does not distinguish between incoming and outgoing calls when talking about call capacity. NOTE: unlimited = 16


201

B



Audio Configuration section A codec resource is considered as allocated if it has been included in the SDP codec list of an active call, even though it eventually may not be the one chosen for the connection. So, if the G.729a codec is enabled and included in the codec list, that resource is tied up until the end of the call whether or not the call actually uses G.729a. If the G729a resource is already allocated and since only one G.729a resource is allowed per device, no other low-bit-rate codec may be allocated for subsequent calls; the only choices are G711a and G711u. On the other hand, two G.723.1/G.726 resources are available per device. Therefore it is important to disable the use of G.729a in order to guarantee the of two simultaneous G.723/G.726 codec.

Preferred Codec

Preferred codec for all calls. (The actual codec used in a call still depends on the outcome of the codec negotiation protocol.) Select one of the following: G711u, G711a, G726-16, G726-24, G726-32, G726-40, G729a, or G723. The default is G711u.

Silence Supp Enable

To enable silence suppression so that silent audio frames are not transmitted, select yes. Otherwise, select no. The default is no.

Use Pref Codec Only

To use only the preferred codec for all calls, select yes. (The call fails if the far end does not this codec.) Otherwise, select no. The default is no.

Silence Threshold

Select the appropriate setting for the threshold: high, medium, or low. The default is medium.

G729a Enable

To enable the use of the G729a codec at 8 kbps, select yes. Otherwise, select no. The default is yes.

Echo Canc Enable

To enable the use of the echo canceller, select yes. Otherwise, select no. The default is yes.


202

B


G723 Enable

To enable the use of the G723a codec at 6.3 kbps, select yes. Otherwise, select no. The default is yes.

Echo Canc Adapt Enable

To enable the echo canceller to adapt, select yes. Otherwise, select no. The default is yes.

G726-16 Enable

To enable the use of the G726 codec at 16 kbps, select yes. Otherwise, select no. The default is yes.

Echo Supp Enable

To enable the use of the echo suppressor, select yes. Otherwise, select no. The default is yes.

G726-24 Enable


FAX CED Detect Enable

To enable detection of the fax Caller-Entered Digits (CED) tone, select yes. Otherwise, select no. The default is yes.

G726-32 Enable


FAX CNG Detect Enable

To enable detection of the fax Calling Tone (CNG), select yes. Otherwise, select no. The default is yes.

G726-40 Enable


FAX thru Codec

Select the codec for fax through, G711u or G711a.

DTMF Process INFO

This field is not available for the PAP2T. To use the DTMF process info feature, select yes. Otherwise, select no.

The default is G711u.

The default is yes.


203

B


FAX Codec Symmetric

To force the ATA device to use a symmetric codec during fax through, select yes. Otherwise, select no. The default is yes.

DTMF Process AVT This field is not available for the PAP2T. To use the DTMF process AVT feature, select yes. Otherwise, select no. The default is yes. FAX thru Method

Select the fax through method: None, NSE, or ReINVITE. The default is NSE.

DTMF Tx Method

Select the method to transmit DTMF signals to the far end: InBand, AVT, INFO, Auto, InBand+INFO, or AVT+INFO. InBand sends DTMF using the audio path. AVT sends DTMF as AVT events. INFO uses the SIP INFO method. Auto uses InBand or AVT based on the outcome of codec negotiation. The default is Auto.

FAX Process NSE

To use the fax process NSE feature, select yes. Otherwise, select no. The default is yes.

Hook Flash Tx Method

Select the method for signaling hook flash events: None, AVT, or INFO. None does not signal hook flash events. AVT uses RFC2833 AVT (event = 16). INFO uses SIP INFO with the single line signal=hf in the message body. The MIME type for this message body is taken from the Hook Flash MIME Type setting. The default is None.

FAX Disable ECAN

If enabled, this feature automatically disables the echo canceller when a fax tone is detected. To use this feature, select yes. Otherwise, select no. The default is no.

Release Unused Codec

This feature allows the release of codecs not used after codec negotiation on the first call, so that other codecs can be used for the second line. To use this feature, select yes. Otherwise, select no. The default is yes.


204

B


FAX Enable T38

To enable the use of the ITU-T T.38 standard for faxing, select yes. Otherwise, select no. The default is yes.

FAX Tone Detect Mode

This parameter has three possible values: caller or callee - SPA will detect FAX tone whether it is callee or caller caller only - SPA will detect FAX tone only if it is the caller callee only - SPA will detect FAX tone only if it is the callee The default is caller or callee.

Symmetric RTP

(SPA3102 and SPA8800 only) Enable symmetric RTP operation. If enabled, the ATA sends RTP packets to the source address and port of the last received valid inbound RTP packet. If disabled (or before the first RTP packet arrives) the ATA sends RTP to the destination as indicated in the inbound SDP. The default is yes.


Dial Plans section

Dial Plan 1/2/3/4/5/ Dial plan script for this line. 6/7/8 The default is (xx.) Dial plans in the dial plan pool to be associated with a VoIP Caller or a PSTN Caller. Each dial plan in the pool is referenced by a index 1 to 8 corresponding to Dial Plan 1 to 8. The dial plan syntax is the same as that used for Line 1. See “Dial Plan section,” on page 175.


205

B



VoIP-To-PSTN Gateway Setup section

VoIP-To-PSTN Gateway Enable

Enable or disable VoIP-To-PSTN Gateway functionality.

VoIP Caller Authentication Method

Method to be used to authenticate a VoIP Caller to access the PSTN gateway. Choose from {none, PIN, HTTP Digest.

The default is yes.


VoIP PIN Max Retry Number of trials to allow VoIP caller to enter a PIN number (used only if authentication method is set to PIN). The default is 3. One Stage Dialing

Enable one-stage dialing (applicable if authentication method is none, or HTTP Digest, or caller is in the Access List). The default is yes.

Line 1 VoIP Caller DP

Index of the dial plan in the dial plan pool to be used when the VoIP Caller is calling from Line 1 of the same SPA3102 unit during normal operation (in other words, not due to fallback to PSTN service when Line 1 VoIP service is down). Choose from {none, 1, 2, 3, 4, 5, 6, 7, 8} Authentication is skipped for Line 1 VoIP caller. The default is 1.

Default VoIP Caller DP

Index of the dial plan in the dial plan pool to be used when the VoIP Caller is not authenticated. Choose from {none, 1, 2, 3, 4, 5, 6, 7, 8}. The default is 1.

Line 1 Fallback DP

Index of the dial plan in the dial plan pool to be used when the VoIP Caller is calling from Line 1 of the same SPA3102 unit due to fallback to PSTN service when Line 1 VoIP service is down. Choose from {none, 1, 2, 3, 4, 5, 6, 7, 8}. The default is 1.


206

B


VoIP Caller ID Pattern

A comma-separated list of caller number templates such that callers with numbers not matching any of these templates are rejected for PSTN gateway service, regardless of the setting of the authentication method. The comparison is applied before the access list is applied. If this parameter is blank (not specified), all callers are considered for PSTN gateway service. For example: 1408*, 1512???1234. NOTE: ‘?’ matches any single digit; ‘*’ matches any number of digits. The default is blank.

VoIP Access List

A comma separated list of IP address templates, such that callers with source IP address matching any of the templates will be accepted for PSTN gateway service without further authentication. For example: 192.168.*.*, 66.43.12.1??. The default is blank.

VoIP Caller 1/2/3/4/ One of 8 PIN numbers that can be specified to control 5/6/7/8 PIN access to the PSTN gateway by a VoIP Caller, when the VoIP Caller Authentication Method parameter is set to PIN. The default is blank. VoIP Caller 1/2/3/4/ Index of the dial plan in the dial plan pool to be associated 5/6/7/8 DP with the VoIP caller who enters the PIN that matches VoIP Caller 1/2/3/4/5/6/7/8 PIN. The default is 1.


207

B



VoIP s and s (HTTP Authentication) section

VoIP 1/2/3/4/ 5/6/7/8 Auth ID

The first of 8 -id’s that a VoIP Caller can use to authenticate itself to the SPA using the HTTP Digest method (in other words, by embedding an Authorization header in the SIP INVITE message sent to the SPA. If the credentials are missing or incorrect, the SPA will challenge the caller with a 401 response). The VoIP caller whose authentication -id equals to this ID is referred to VoIP 1 of this SPA. NOTE: If the caller specifies an authentication -id that does not match any of the VoIP Auth ID’s, the INVITE will be rejected with a 403 response. The default is blank.

VoIP 1/2/3/4/ 5/6/7/8 DP

Index of the dial plan in the dial plan pool to be used with VoIP 1. If Authentication is disabled, the default dial plan is used for all unknown VoIP s. The default is 1.

VoIP 1/2/3/4/ 5/6/7/8

The to be used with VoIP 1. The assumes the identity of VoIP 1 must therefore compute the credentials using this , or the INVITE will be challenged with a 401 response The default is blank.


208

B



Ring Settings section

Default Ring

1-8, Follow Line Cfg


FXO (PSTN) Timer Values (sec) section

VoIP Answer Delay

Delay in seconds before auto-answering inbound VoIP calls for the FXO . The range is 0-255. The default is 3.

PSTN Answer Delay

Delay in seconds before auto-answering inbound PSTN calls after the PSTN starts ringing. The range is 0-255. The default is 16.

VoIP PIN Digit Timeout

Timeout to wait for the 1st or subsequent PIN digits from a VoIP caller. The range is 0-255. The default is 10.

PSTN PIN Digit Timeout

Timeout to wait for the 1st or subsequent PIN digits from a PSTN caller. The range is 0-255. The default is 10.

VoIP DLG Refresh Intvl

Interval between (SIP) Dialog refresh messages sent by the SPA to detect if the VoIP call-leg is still up. If value is set to 0, SPA will not send refresh messages and VoIP call-leg status is not checked by the SPA. The refresh message is a SIP ReINVITE and the VoIP peer must response with a 2xx response. If VoIP peer does not reply or response is not greater than 2xx, the SPA will disconnect both PSTN and VoIP call legs automatically. The range is 0-255. The default is 30.


209

B


PSTN Ring Thru Delay

Delay in seconds before starting to ring thru Line 1 after the PSTN starts ringing. In order for Line 1 to have the caller-id information, the delay should be set to larger than the delay required to complete the PSTN caller-id delivery (such as 5s). The range is 0-255. The default is 5.

PSTN-To-VoIP Call Max Dur

Limit on the duration of a PSTN-To-VoIP Gateway Call. Unit is in seconds. 0 means unlimited. The range is 02147483647. The default is 0.

VoIP-To-PSTN Call Max Dur

Limit on the duration of a VoIP-To-PSTN Gateway Call. Unit is in seconds. 0 means unlimited. The range is 02147483647. The default is 0.

PSTN Dialing Delay Delay after hook before the SPA dials a PSTN number. The range is 0-255. The default is 1. PSTN Ring Timeout Delay after a ring burst before the SPA decides that PSTN ring has ceased. The range is 0-255. The default is 5. PSTN Dial Digit Len Determines the on/off time when transmitting digits through the FXO port. The syntax is on-time/off-time, where on-time and off-time are expressed in seconds with up to two decimal places, within the permitted range, which is from .05 to 3.00. The default is .1/.1. If this value is blank, the default is used. PSTN Hook Flash Len

The length of the hook flash in seconds. During a PSTN-toVoIP gateway call, the ATA device processes the out-ofband hook flash signal sent from the VoIP peer through a hook-flash (momentary on-hook signal) on the FXO port. This allows the VoIP peer to initiate a three-way conference call and subsequent call transfer. The duration of the on-hook signal can be configured using this parameter. The default is 0.25. The permitted range is limited to 0.02 to 1.6 seconds.


210

B


PSTN Ring Thru CWT Delay

Specify the delay before incoming PSTN calls will ring Line 1 using a Call Waiting Tone. The default is 3.

PSTN Ring Timeout Specify the delay after a ring burst before the Gateway decides that the PSTN ring has ended. The default is 5. PSTN Dialing Delay Specify the delay after the PSTN phone line is on-hook before the Gateway dials a PSTN number. The default is 1. PSTN Dial Digit Len Specify the on/off time when the Gateway transmits digits through the Line (FXO) port. The syntax is on-time/off-time, expressed in seconds with up to two decimal places. The permitted range is 0.05 to 3.00. The default is .1/.1. PSTN Hook Flash Len

Default is .25.


PSTN Disconnect Detection section

Detect C

C is a brief removal of tip-and-ring voltage. If enabled, the SPA will disconnect both call legs when this signal is detected during a gateway call. The default is yes.

Detect Polarity Reversal

If enabled, SPA will disconnect both call legs when this signal is detected during a gateway call. If it is a PSTN gateway call, the 1st polarity reversal is ignored and the 2nd one triggers the disconnection. For VoIP gateway call, the 1st polarity reversal triggers the disconnection. The default is yes.

Detect (PSTN) Long If enabled, SPA will disconnect both call legs when the Silence PSTN side has no voice activity for a duration longer than the length specified in the Long Silence Duration parameter during a gateway call The default is yes. Min C Duration


Specify the minimum duration of a low tip-and-ring voltage (below 1V) for the Gateway to recognize it as a C signal or PSTN line removal. The default is 0.2.

211

B


Detect Disconnect Tone

If enabled, SPA will disconnect both call legs when it detects the disconnect tone from the PSTN side during a gateway call. Disconnect tone is specified in the Disconnect Tone parameter, which depends on the region of the PSTN service. The default is yes.

(PSTN) Long Silence Duration

This value is minimum length of PSTN silence (or inactivity) in seconds to trigger a gateway call disconnection if Detect Long Silence is yes. The default is 30.

Silence Threshold

This parameter adjusts the sensitivity of PSTN silence detection. Choose from {very low, low, medium, high, very high}. The higher the setting, the easier to detect silence and hence easier to trigger a disconnection. The default is medium.


212

B


Disconnect Tone

This value is the tone script which describes to the SPA the tone to detect as a disconnect tone. The syntax follows a standard Tone Script with some restrictions. Default value is standard US reorder (fast busy) tone, for 4 seconds. Restrictions: •

2 frequency components must be given. If single frequency is desired, the same frequency is used for both

•

The tone level value is not used. –30 (dBm) should be used for now.

•

Only 1 segment set is allowed

•

Total duration of the segment set is interpreted as the minimum duration of the tone to trigger detection

•

6 segments of on/off time (seconds) can be specified. A 10% margin is used to validated cadence characteristics of the tone.

The Disconnect Tone Script values for various countries follow: US—480@-30,620@-30;4(.25/.25/1+2) UK—400@-30,400@-30; 2(3/0/1+2) —440@-30,440@-30; 2(0.5/0.5/1+2) —440@-30,440@-30; 2(0.5/0.5/1+2) Netherlands—425@-30,425@-30; 2(0.5/0.5/1+2) Sweden—425@-10; 10(0.25/0.25/1) Norway—425@-10; 10(0.5/0.5/1) Italy—425@-30,425@-30; 2(0.2/0.2/1+2) Spain—425@-10; 10(0.2/0.2/1,0.2/0.2/1,0.2/0.6/1) Portugal—425@-10; 10(0.5/0.5/1) Poland—425@-10; 10(0.5/0.5/1) Denmark—425@-10; 10(0.25/0.25/1) New Zealand—400@-15; 10(0.25/0.25/1) Australia—425@-13; 10(0.375/0.375/1)


213

B



International Control (Settings) section

FXO Port Impedance

Desired impedance of the FXO Port. Choose from {600, 900, 370+620, 270+750||150nF, 220+820||120nF, 370 + 620 || 310nf, 320 + 1050 || 230nf, 370 + 820 || 110 nf, 275 + 780 || 115nf, 120 + 820 || 110nf, 350 + 1000 || 210nf, 0 + 900 || 130nf} The default is 600. The impedance values for various countries follows: US—600 EU (UK, , Netherlands, Sweden, Norway, Italy, Spain, Portugal, Poland, and Denmark)—270+750||150nF —270+750||150nF Australia—220+820||120nF New Zealand—370+620||310nF

Ring Frequency Min Specify the lower limit of the ring frequency used to detect the ring signal. The default is 10. SPA To PSTN Gain

dB of digital gain (or attenuation if negative) to be applied to the signal sent from the SPA to the PSTN side. The range is -15 to 12. The default is 0.

Ring Frequency Max

Specify the higher limit of the ring frequency used to detect the ring signal. The default is 100.

PSTN To SPA Gain

dB of digital gain (or attenuation if negative) to be applied to the signal sent from the PSTN side to the SPA. The range is -15 to 12. The default is 0.


Specify the minimum signal duration required by the Gateway for recognition as a ring signal. The default is 256 ms.

Tip/Ring Voltage Adjust

Choices are {3.1, 3.2, 3.35, 3.5}.


The default is 3.5.

214

B


Operational Loop Current Min

Choices for mA are: {10, 12, 14, 16).

On-Hook Speed

Choose from {Less than 0.5ms, 3ms (ETSI), 26ms (Australia)}.

The default is 10.

The default is Less than 0.5ms. Current Limiting Enable

Enable or disable current limiting. The default is no.

Ring Frequency Min Minimum ring frequency to detect. The range is 5-100. The default is 10. Ring Frequency Max

Maximum ring frequency to detect. The range is 5-100.


Choose from {100, 150, 200, 256, 384, 512, 640, 1024} (ms).

Ring Indication Delay

Choose from {0, 512, 768, 1024, 1280, 1536, 1792} (ms).

Ring Timeout

Choose from {0, 128, 256, 384, 512, 640, 768, 896, 1024, 1152, 1280, 1408, 1536, 1664, 1792, 1920} (ms).

The default is 100.

The default is 256ms.

The default is 512ms.

The default is 640 ms. Ring Threshold

Choose from {13.5–16.5, 19.35–2.65, 40.5–49.5} (Vrms). The default is 13.5-16.5 Vrms.

Ringer Impedance

Choose from {High, Synthesized(Poland, S.Africa, Slovenia)}. The default is high.

Line-In-Use Voltage Determines the voltage threshold at which the SPA-3000 assumes the PSTN is in use by another handset sharing the same line (and will declare PSTN gateway service not available to incoming VoIP callers). The default value is 40v.


215

B

ATA Voice Field Reference page

page Depending on the model of ATA device, there may be one or more pages. You can use this page to configure the settings. On the SPA8000, these settings can be configured on the Line pages (Line 1, Line 2, and so on). On the SPA8800, theses settings can be configured on the Phone pages (Phone 1, Phone 2, and so on). This page includes the following sections: •

“Call Forward Settings section” section on page 217

•

“Selective Call Forward Settings section” section on page 218

•

“Speed Dial Settings section” section on page 218

•

“Supplementary Service Settings section” section on page 219

•

“Distinctive Ring Settings section” section on page 220

•

“Ring Settings section” section on page 221

NOTE When a call is made from Line 1 or Line 2, the ATA device shall use the and line

settings for that line; there is no . Per parameter tags must be appended with [1] or [2] (corresponding to line 1 or 2) in the configuration profile. It is omitted below for readability.


216

B


Voice tab > page >

Call Forward Settings section

Cfwd All Dest

Forward number for Call Forward All Service In addition to normal call forward destination as used in the other ATAs, on the SPA3102, you can specify the following additional parameters: gw0 – forward the caller to use the PSTN gateway @gw0 – forward to caller to the PSTN number (dialed automatically by the SPlocalA through the PSTN gateway) The default is blank.

Cfwd Busy Dest

Forward number for Call Forward Busy Service. Same as Cfwd All Dest. The default is blank.

Cfwd No Ans Dest

Forward number for Call Forward No Answer Service. Same as Cfwd All Dest. In addition to normal call forward destination as used in the other ATAs, on the SPA3102, you can specify the following additional parameters: gw0 – forward the caller to use the PSTN gateway @gw0 – forward to caller to the PSTN number (dialed automatically by the SPA through the PSTN gateway) The default is blank.

Cfwd No Ans Delay Delay in sec before Call Forward No Answer triggers. Same as Cfwd All Dest. The default is 20.


217

B


Voice tab > page >

Selective Call Forward Settings section

Cfwd Sel1- 8 Caller Caller number pattern to trigger Call Forward Selective 1, 2, 3, 4, 5, 6, 7, or 8. The default is blank. Cfwd Sel1 - 8 Dest

Forward number for Call Forward Selective 1, 2, 3, 4, 5, 6, 7, or 8. Same as Cfwd All Dest. The default is blank.

Block Last Caller

ID of caller blocked via the Block Last Caller service. The default is blank.

Accept Last Caller

ID of caller accepted via the Accept Last Caller service. The default is blank.

Cfwd Last Caller

The Caller number that is actively forwarded to Cfwd Last Dest by using the Call Forward Last activation code The default is blank.

Cfwd Last Dest

Forward number for the Cfwd Last Caller parameter. Same as Cfwd All Dest. The default is blank.

Voice tab > page >

Speed Dial Settings section This section does not apply to the WIP310 wireless phone.

Speed Dial 2-9

Target phone number (or URL) assigned to speed dial 2, 3, 4, 5, 6, 7, 8, or 9. The default is blank.


218

B


Voice tab > page >

Supplementary Service Settings section The ATA device provides native of a large set of enhanced or supplementary services. All of these services are optional. The parameters listed in the following table are used to enable or disable a specific supplementary service. A supplementary service should be disabled if a) the has not subscribed for it, or b) the Service Provider intends to similar service using other means than relying on the ATA device.

CW Setting

Call Waiting on/off for all calls. The default is yes.

Block CID Setting

Block Caller ID on/off for all calls. The default is no.

Block ANC Setting

Block Anonymous Calls on or off. The default is no.

DND Setting

DND on or off. The default is no.

CID Setting

Caller ID Generation on or off. The default is yes.

CWCID Setting

Call Waiting Caller ID Generation on or off. The default is yes.

Dist Ring Setting

Distinctive Ring on or off. The default is yes.

Secure Call Setting If yes, all outbound calls are secure calls by default. The default is no. Message Waiting

This value is updated when there is voice mail notification received by the ATA device. The can also manually modify it to clear or set the flag. Setting this value to yes can activate stutter tone and VMWI signal. This parameter is stored in long term memory and will survive after reboot or power cycle. The default is no.


219

B


Accept Media Loopback Request

Controls how to handle incoming requests for loopback operation. Choices are: Never, Automatic, and Manual, where: •

never—never accepts loopback calls; reply 486 to the caller

•

automatic—automatically accepts the call without ringing

•

manual —rings the phone first, and the call must be picked up manually before loopback starts.

The default is Automatic. Media Loopback Mode

The loopback mode to assume locally when making call to request media loopback. Choices are: Source and Mirror. Default is Source. Note that if the ATA device answers the call, the mode is determined by the caller.

Media Loopback Type

The loopback type to use when making call to request media loopback operation. Choices are Media and Packet. Default is Media. Note that if the ATA device answers the call, then the loopback type is determined by the caller (the ATA device always picks the first loopback type in the offer if it contains multiple types.)

Voice tab > page >

Distinctive Ring Settings section Caller number patterns are matched from Ring 1 to Ring 8. The first match (not the closest match) will be used for alerting the subscriber.

Ring1 - 9 Caller

Caller number pattern to play Distinctive Ring/CWT 1, 2, 3, 4, 5, 6, 7, 8, or 9. The default is blank.


220

B


Voice tab > page >

Ring Settings section

Default Ring

Default ringing pattern, 1 – 8, for all callers. The default is 1.

Default CWT

Default CWT pattern, 1 – 8, for all callers. The default is 2.

Hold Reminder Ring

Ring pattern for reminder of a holding call when the phone is on-hook. The default is None.

Call Back Ring

Ring pattern for call back notification. The default is None.

Cfwd Ring Splash Len

Duration of ring splash when a call is forwarded (0 – 10.0s). The default is 0.

Cblk Ring Splash Len

Duration of ring splash when a call is blocked (0 – 10.0s).

VMWI Ring Splash Len

Duration of ring splash when new messages arrive before the VMWI signal is applied (0 – 10.0s).

The default is 0.

The default is .5. VMWI Ring Policy

The parameter controls when a ring splash is played when a the VM server sends a SIP NOTIFY message to the ATA device indicating the status of the subscriber’s mail box. 3 settings are available: •

New VM Available—ring as long as there is 1 or more unread voice mail

•

New VM Becomes Available—ring when the number of unread voice mail changes from 0 to non-zero

•

New VM Arrives—ring when the number of unread voice mail increases.

The default is New VM Available.


221

B

ATA Voice Field Reference PSTN page (SPA3102)

Ring On No New VM

If enabled, the ATA device will play a ring splash when the VM server sends SIP NOTIFY message to the ATA device indicating that there are no more unread voice mails. Some equipment requires a short ring to precede the FSK signal to turn off VMWI lamp. The default is no.

PSTN page (SPA3102) On the SPA3102, you can use the Voice tab > PSTN page to configure the PSTN settings. This page includes the following sections: •

“PSTN-To-VoIP Selective Call Forward Settings section” section on page 222

•

“PSTN-To-VoIP Speed Dial Settings section” section on page 223

•

“PSTN Ring Thru Line 1 Distinctive Ring Settings section” section on page 223

•

“PSTN Ring Thru Line 1 Ring Settings section” section on page 223

Voice tab > PSTN page (SPA3102) >

PSTN-To-VoIP Selective Call Forward Settings section

Cfwd Sel1-8 Caller

Eight PSTN Caller Number Patterns to be blocked for VoIP gateway services or forwarded to a certain VoIP number. If the caller is blocked, the SPA will not auto-answers the call.

Cfwd Sel1-8 Dest

Eight VoIP destinations to forward a PSTN caller matching the Cfwd Sel x Caller parameter. If this entry is blank, the PSTN caller is blocked for VoIP service.


222

B

ATA Voice Field Reference PSTN page (SPA3102)


PSTN-To-VoIP Speed Dial Settings section

Speed Dial 1-9

The VoIP number to call when the PSTN caller dials a single digit ‘2’


PSTN Ring Thru Line 1 Distinctive Ring Settings section

Ring1-8 Caller

Eight PSTN Caller Number Patterns such that the corresponding ring will be used to ring through Line 1 if the PSTN caller matches this pattern.


PSTN Ring Thru Line 1 Ring Settings section

Default Ring

The default ring to be used to ring through Line 1. Choose from {1,2,3,4,5,6,7,8,Follow Line 1}. If Follow Line 1 is selected, the ring to be used is determined by Line 1’s distinctive ring settings. The default is 1.


223

C Troubleshooting

This appendix provides solutions to problems that may occur during the installation and operation of the ATA devices.

NOTE If you can't find an answer here, visit www.cisco.com/en/US/products/ps10024/

tsd_products__series_home.html

Q. I want to use a different computer to access the istration web server. The address I entered did not work. A. Use the Interactive Voice Response Menu to find out the Internet IP address. Follow these steps: 1. Use a telephone connected to the Phone 1 port of the ATA device. 2. Press **** (in other words, press the star key four times). 3. After the greeting plays, press 110#. 4. Write down the IP address as it is announced. 5. Press 7932#. 6. Press 1 to enable WAN access to the istration web server. 7. Open the web browser on a networked computer. 8. Start Internet Explorer and enter the IP address of the ATA device.


224

C

Troubleshooting

Q. I’m trying to access the ATA istration web server, but I do not see the screen. Instead, I see a screen saying, “404 Forbidden.” A. If you are using Windows Explorer, perform the following steps until you see the istration web server screen (Mozilla requires similar steps). 1. Click File. Make sure Work Offline is NOT checked. 2. Press CTRL + F5. This is a hard refresh, which forces Windows Explorer to load new webpages, not cached ones. 3. Click Tools. Click Internet Options. Click the Security tab. Click the Default level button. Make sure the security level is Medium or lower. Then click the OK button. Q. How do I save my current configuration? A. Currently, the only way is to do HTTPGET from an HTTP client, from which you get the entire HTML page. Alternatively, from your browser you can select File > Save as > HTML from any of the istration web server pages. Do this in , Advanced mode. This saves all the tabs into one HTML file. This HTML file is helpful to provide to our team when you have a problem or technical question. Q. How do I debug my ATA device? Is there a syslog? A. The ATA devices send out debug information via syslog to a syslog server. The ports can be configured (by default the port is 514). 1. Make sure you do not have firewall running on your PC that could block port 514. 2. On the istration web server System tab, set Debug Server as the IP address and port number of your syslog server. Note that this address has to be reachable from the ATA device. 3. Also, set Debug level to 3. You do not need to change the value of the syslog server parameter. 4. To capture SIP signaling messages, under the Line tab, set SIP Debug Option to Full. The file output is syslog.<portnum>.log (for the default port setting, syslog.514.log).


225

C

Troubleshooting

Q. How do I access the ATA device if I forget my ? A. By default, the and s have no . If the ITSP set the for either and you do not know what it is, you need to the ITSP. If the for the was configured after you received the ATA device, you can reset the device to the factory default, which preserves any provisioning completed by the ITSP. If the needs to be reset, you have to perform a full factory reset, which also erases any provisioning. To reset the ATA device to the factory defaults, perform the following steps: 1. Connect an analog phone to the ATA device and access the IVR by pressing the asterisk key four times: **** Press the appropriate code to reset the unit: •

Press 877778# to reset the unit to the defaults as it shipped from the ITSP. This will reset the to the default of blank.

•

Press 73738# to perform a full reset of unit to the factory default settings. The will be reset to the default of blank.

2. Press 1 to confirm the operation. Press * to cancel the operation. 3. to the unit using the or without a and reconfigure the unit as necessary. Q. My ATA device is behind a NAT device or firewall and I’m unable to make a call or I’m only receiving a one-way connection. What should I do? A. Complete the following steps. 1. Configure your router to port forward “T port 80" to the IP address currently being used by your ATA device. If you do this often, we suggest that you use static IP address for the ATA device, instead of DH. (For help with port forwarding, consult your router documentation) 2. On the Line tab of the istration web server, change the value of Nat Mapping Enable to yes. On the SIP tab; change Substitute VIA Addr to yes, and the EXT IP parameter to the IP address of your router. 3. Make sure you are not blocking the UDP PORT 5060,5061 and port for UDP packets in the range of 16384-16482. Also, disable “SPI” if this feature is provided by your firewall. Identify the SIP server to which the ATA device is ing, if it s NAT, using the Outbound Proxy parameter.


226

C

Troubleshooting

4. Add a STUN server to allow traversal of UDP packets through the NAT device. On the SIP tab of the istration web server, set STUN Enable to yes, and enter the IP address of the STUN server in STUN Server. STUN (Simple Traversal of UDP through NATs) is a protocol defined by RFC 3489, that allows a client behind a NAT device to find out its public address, the type of NAT it is behind, and the port associated on the Internet connection with a particular local port. This information is used to set up UDP communication between two hosts that are both behind NAT routers. Open source STUN software can be obtained at the following website: http://www.voip-info.org/wiki-Open+Source+VOIP+Software

NOTE STUN does not work with a symmetric NAT router. Enable debug through

syslog (see FAQ#10), and set STUN Test Enable to yes. The messages indicate whether you have symmetric NAT or not.


227

D Environmental Specifications

This appendix provides the specifications for the following ATAs: •

“PAP2T,” on page 228

•

“SPA2102,” on page 229

•


•


•


PAP2T Device Dimensions

3.98” x 3.98” x 1.10” (101 x 101 x 28 mm) W x H x D

Unit Weight

5.40 oz (153g)

Power

100-240V 50-60Hz, AC Input

Certification

FCC (Part 15 Class B), cUL, CE, IC-003, A-Tick

Operating Temp

32 to 113º F(0 to 45ºC)

Storage Temp

-17º to 158ºF (-27 to 70ºC)

Operating Humidity

10% to 90% relative humidity, Non-Condensing

Storage Humidity



228

D

Environmental Specifications SPA2102

SPA2102 Device Dimensions

3.98” x 3.98” x 1.10” (101 x 101 x 28 mm) W x H x D

Unit Weight

5.29 oz (0.15kg)

Power

100-240V 50-60Hz (26-34VA), AC Input

Certification

FCC (Part 15 Class B), CE, ICES-003

Operating Temp

32º to 113º F(0 to 45ºC)

Storage Temp

-13º to 185ºF (-25 to 85ºC)

Operating Humidity


Storage Humidity


Device Dimensions

3.98” x 3.98” x 1.10” (101 x 101 x 28 mm)

Unit Weight

5.11 oz (0.145kg)

Power

100-240V 50-60Hz (26-34VA), AC Input

Certification

FCC (Part 15 Class B), CE, ICES-003, A-Tick Certification, RoH

Operating Temp

32º to 113º F(0 to 45ºC)

Storage Temp

-13º to 185ºF (-25 to 85ºC)

Operating Humidity


Storage Humidity


SPA3102


229

D

Environmental Specifications SPA8000

SPA8000 Device Dimensions

6.69” x 1.54” x 8.66” (170 x 39 x 220 mm)

Unit Weight

2.85 lbs (1.30kg)

Power

100-240V 50-60Hz (26-34VA), AC Input

Certification

FCC (Part 15 Class B), CE, ICES-003, A-Tick Certification, RoH, UL

Operating Temp

32º to 113º F(0 to 45ºC)

Storage Temp

-13º to 185ºF (-25 to 85ºC)

Operating Humidity


Storage Humidity


Device Dimensions

6.69” x 1.54” x 8.66” (170 x 39 x 220 mm)

Unit Weight

2.85 lbs (1.30kg)

Power

100-240V 50-60Hz (26-34VA), AC Input

Certification

FCC (Part 15 Class B), CE, ICES-003, A-Tick Certification, RoH, UL

Operating Temp

32º to 113º F(0 to 45ºC)

Storage Temp

-13º to 185ºF (-25 to 85ºC)

Operating Humidity


Storage Humidity


SPA8800


230

E Where to Go From Here

This appendix describes additional resources that are available to help you and your customer obtain the full benefits of the SPA9000 Voice System.

•

“Product Resources,” on page 231

•

“Related Documentation,” on page 232

Product Resources Website addresses in this document are listed without http:// in front of the address because most current web browsers do not require it. If you use an older web browser, you may have to add http:// in front of the web address.

Resource

Location

Technical Documentation

http://www.cisco.com/en/US/products/ps10024/ prod_maintenance_guides_list.html

Firmware s

Go to tools.cisco.com//s, and enter the model number in the Software Search box.

Cisco Community Central > Small Business Community

www.myciscocommunity.com/community/ smallbiz/voiceandconferencing/voice

Phone

www.cisco.com/en/US// tsd_cisco_small_business__center_s.html

Warranty and End License Agreement

www.cisco.com/go/warranty


231

E

Where to Go From Here Related Documentation

Resource

Location

Open Source License Notices

www.cisco.com/go/osln

Regulatory Compliance and Safety Information

http://www.cisco.com/en/US/products/ps10024/ prod_maintenance_guides_list.html

Cisco Partner Central ( Required)

www.cisco.com/web/partners/sell/smb

Cisco Small Business Home

www.cisco.com/smb

Related Documentation The following table describes the various documents that Cisco provides to help you to install, configure, and manage the SPA9000 Voice System and its components. These documents and more are available at the following URL: www.cisco.com/en/US/products/ps10030/ tsd_products__series_home.html

Document Title

Description

Intended Audience

SPA9000 Voice System Installation and Configuration Guide Using the Setup Wizard

Installation, configuration and maintenance of the SPA9000 Voice System by using the Setup Wizard.

End s, VARs, and Service Providers

SPA9000 Voice System Installation and Configuration Guide Web-UI (Legacy) Based Product Configuration

Manual installation of the SPA9000 Voice System, by using the Web Interface, instead of the Cisco SPA900 Voice System Setup Wizard.

End s, VARs, and Service Providers


232

E

Where to Go From Here Related Documentation

Document Title

Description

Intended Audience

SPA9000 Voice System istration Guide

•

istration and configuration of system features using the SPA9000 and SPA400

VARs and Service Providers

•

Deployment options for ITSP, PSTN, and ISDN services

•

SPA9000, SPA400, SPA900 series phones

•

Configuration and management of SPA9x2 series IP phones

•

Deployment options with or without the SPA9000 IP PBX

•

SPA9x2 series IP phones

•

Phone setup

•

Phone features

•

SPA9x2 series IP phones

•

istration and use of Cisco Small Business ATAs

•

PAP2T, SPA2102, SPA3102, SPA8000

SPA9x2 Phone istration Guide

SPA9x2 Phone Guide

Analog Telephone Adapter istration Guide

VARs and Service Providers

VARs and phone ends

VARs, system s, and Service Providers

Guide for switch Guide for router


233

Linksys - Spa8000 3o4n1h

Overview 3z723u

More details 2i4a6q

Related Documents g842

Linksys - Spa8000 3o4n1h

Rv042 Linksys 3k253s

Linksys Rebate.pdf 4l4i45

Linksys Nas200 5z1j29

Linksys Guide 1b3z2d

Linksys Wrvs4400n 3u5nb

More Documents from "DrugacijiBorac" 2e4u7

Linksys - Spa8000 3o4n1h
