ARMORSEAL® 8100 ArmorSeal Heavy WATER BASED EPOXY FLOOR COATING Duty Floor P A B70-8100 S G Coatings P A B70-8160 S S art art Part
B
B70V8100
eries eries
loss atin Hardener
Revised: March. 13, 2017
8.18
Product Description
Recommended Uses
ARMORSEAL 8100 is the next generation in water based epoxy floor coatings; a two-component polyamine epoxy with excellent chemical and abrasion resistance that is breathable. It is designed for use in commercial, industrial and residential floor applications. A LEED 4.2 compliant material that offers improved performance while maintaining ease of application properties common to water based materials. This versatile material is self-priming over concrete, can be used as a stand alone coating or as a receiver coat for paint chip floors. Available in a gloss or satin finish • Breathable • <50 g/L • Color Retention, resists yellowing • Resists disbondment due to Moisture Vapor Transmission (MVT) • Ease of application
Durable epoxy floor coating for general purpose use in industrial and commercial environments, such as: • Warehouse Floors • Garages • Residential • Automotive Showrooms • Industrial and Commercial Floors • Light manufacturing Plants • Acceptable for use in USDA inspected facilities
Product Characteristics
Performance Characteristics Substrate: Concrete Surface Preparation: Clean, dry, sound System Tested:
Finish: Gloss or Satin Color: Clear*,Tile Red, Deck Gray, Haze Gray and a wide range of tinted colors using CCE colorants 2 cts. ArmorSeal 8100 Safety Colors Gloss only * For Clear, use the Ultra Deep Base (for more detail, see Application Bulletin Performance Tips Test Name Volume Solids: 41% ± 2%, mixed, may vary by color Weight Solids: 50% ± 2%, mixed, may vary by color Abrasion VOC <50 g/L; 0.42 lb/gal, mixed (EPA Method 24): Resistance Mix Ratio: 4:1 by volume
Recommended Spreading Rate per coat: Wet mils (microns) Dry mils (microns) ~Coverage sq ft/gal (m2/L)
Minimum
Maximum
5.0 (125) 2.0 (50) 130 (3.3)
12.0 (300) 5.0 (125) 320 (8.1)
NOTE: Brush or roll to cove base or vertical surfaces may require multiple coats to achieve maximum film thickness and uniformity of appearance.
Adhesion Finish Flexibility Impact Resistance Pencil Hardness
Drying Schedule @ 7.0 mils wet (175 microns): @ 50°F/10°C
@ 77°F/25°C 50% RH 45 minutes
@ 120°F/49°C
To touch: 1 hour 25 minutes To recoat*: minimum: 8 hours 6 hours 3 hours maximum: 72 hours 72 hours 72 hours To Cure 7 days 7 days 7 days Foot Traffic: 18 hours Heavy Traffic: 48 hours Drying time is temperature, humidity, and film thickness dependent. *If recoating after 72 hours abrade surface first. Pot Life: 8 hours 5½ hours 3½ hours Sweat-in-Time: None None None Shelf Life:
Part A: 24months, unopened Part B: 36 months Store indoors at 40°F (4.5°C) to 100°F (38°C)
Flash Point: Reducer/Clean Up:
>230°F (110°C), Seta Flash, mixed Water
Slip Resistance, Floors WVP Perms (US) Hot Tire Pick-up
@ 2.0 - 4.0 mils (50-100 microns) dft
Test Method ASTM D4060, CS17 wheel, 1000 cycles, 1 kg load ASTM D4541 Satin Gloss ASTM D 522 ASTM D2794 ASTM D3363 ASTM C1028**, .60 Minimum Static Coefficient of Friction Grains(hr ft2 in Hg) ITM @ 140ºF (60ºC)
Results 150 mg loss 550 psi concrete 15-25 units@ 85º 90+ units @ 60º 180º bend 1/8" mandrel Direct 100 in.lb. Indirect 80 in.lb. H es wet and dry, with and without SharkGrip Additive Gloss – 2.0 Satin – 5.0 es
**Test method withdrawn in 2014 without replacement
www.sherwin-williams.com/protective
continued on back
ARMORSEAL® 8100 ArmorSeal Heavy WATER BASED EPOXY FLOOR COATING Duty Floor P A B70-8100 S G Coatings P A B70-8160 S S art art Part
Revised: March. 13, 2017
B
B70V8100
eries eries
Product Information
loss atin Hardener
8.18
Surface Preparation
Recommended Systems Dry Film Thickness / ct. Mils (Microns) Concrete Floors, unpainted: 1 ct. ArmorSeal 8100 2.0-4.0 (50-100) (reduced with one pint of water per gallon) 2 cts. ArmorSeal 8100 2.0-4.0 (50-100)
Surface must be clean, dry, and in sound condition. Remove all oil, dust, grease, dirt, loose rust, and other foreign material to ensure adequate adhesion. Refer to product Application Bulletin for detailed surface preparation information. Do not use hydrocarbon solvents for cleaning.
Concrete Floors, previously painted: 1 ct. Spot prime bare areas with ArmorSeal 8100
2.0-4.0
(50-100)
2 cts. ArmorSeal 8100
2.0-4.0
(50-100)
The systems listed above are representative of the product's use, other systems may be appropriate.
Minimum recommended surface preparation: Concrete & Masonry: SSPC-SP13/NACE 6, or ICRI No. 310.2R, CSP1-3
Tinting
Tint part A with CCE colorants at 100% strength. Five minutes minimum mixing on a mechanical shaker is required for complete mixing of color.
Application Conditions Temperature: Relative humidity:
50°F (10°C) minimum, 100°F (38°C) maximum (air, surface, and material) At least 5°F (2.8°C) above dew point 85% maximum
Refer to product Application Bulletin for detailed application information.
Ordering Information Packaging:
1 gallon (3.78L) and 5 gallon (18.9L) containers
Weight:
9.9 ± 0.2 lb/gal ; 1.12 Kg/L mixed, may vary by color
Safety Precautions Refer to the MSDS sheet before use. Published technical data and instructions are subject to change without notice. your Sherwin-Williams representative for additional technical data and instructions.
Warranty Disclaimer The information and recommendations set forth in this Product Data Sheet are based upon tests conducted by or on behalf of The Sherwin-Williams Company. Such information and recommendations set forth herein are subject to change and pertain to the product offered at the time of publication. Consult your SherwinWilliams representative to obtain the most recent Product Data Information and Application Bulletin.
The Sherwin-Williams Company warrants our products to be free of manufacturing defects in accord with applicable Sherwin-Williams quality control procedures. Liability for products proven defective, if any, is limited to replacement of the defective product or the refund of the purchase price paid for the defective product as determined by Sherwin-Williams. NO OTHER WARRANTY OR GUARANTEE OF ANY KIND IS MADE BY SHERWIN-WILLIAMS, EXPRESSED OR IMPLIED, STATUTORY, BY OPERATION OF LAW OR OTHERWISE, INCLUDING MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
www.sherwin-williams.com/protective
ARMORSEAL® 8100 ArmorSeal Heavy WATER BASED EPOXY FLOOR COATING Duty Floor P A B70-8100 S G Coatings P A B70-8160 S S art art Part
B
Application Bulletin
Revised: March. 13, 2017
B70V8100
eries eries
loss atin Hardener
8.18
Application Conditions
Surface Preparations Surface must be clean, dry, and in sound condition. Remove all oil, dust, grease, dirt, loose rust, and other foreign material to ensure adequate adhesion.
Temperature:
50°F (10°C) minimum, 100°F (38°C) maximum (air, surface, and material) At least 5°F (2.8°C) above dew point
Do not use hydrocarbon solvents for cleaning.
Relative humidity:
85% maximum
Concrete and Masonry For surface preparation, refer to SSPC-SP13/NACE 6, or ICRI No. 310.2R, CSP 1-3. Surfaces should be thoroughly clean and dry. Concrete and mortar must be cured at least 28 days @ 75°F (24°C). Remove all loose mortar and foreign material. Surface must be free of laitance, concrete dust, dirt, form release agents, moisture curing membranes, loose cement and hardeners. Fill bug holes, air pockets and other voids with Steel-Seam FT910. Primer required. Follow the standard methods listed below when applicable: ASTM D4258 Standard Practice for Cleaning Concrete. ASTM D4259 Standard Practice for Abrading Concrete. ASTM D4260 Standard Practice for Etching Concrete. ASTM F1869 Standard Test Method for Measuring Moisture Vapor Emission Rate of Concrete. SSPC-SP 13/Nace 6 Surface Preparation of Concrete. ICRI No. 310.2R Concrete Surface Preparation. Previously Painted Surfaces If in sound condition, clean the surface of all foreign material. Smooth, hard or glossy coatings and surfaces should be dulled by abrading the surface. Apply a test area, allowing paint to dry one week before testing adhesion. If adhesion is poor, or if this product attacks the previous finish, removal of the previous coating may be necessary. If paint is peeling or badly weathered, clean surface to sound substrate and treat as a new surface as above.
Application Equipment The following is a guide. Any reduction must be compliant with existing VOC regulations and compatible with the existing enviromental and application conditions. Reducer/Clean Up ����������Water Clear/Ultradeep tint base requires reduction of 5% by volume Brush Brush �����������������������������Nylon/Polyester or Natural Bristle Reduction �����������������������as needed up to 10% by volume, for primer coat only Roller Cover �����������������������������1/4"-3/8" woven with solvent resistant core Reduction �����������������������as needed up to 10% by volume, for primer coat only
If specific application equipment is not listed above, equivalent equipment may be substituted.
Surface Preparation Standards
Condition of Surface
White Metal Near White Metal Commercial Blast Brush-Off Blast Hand Tool Cleaning Rusted Pitted & Rusted Power Tool Cleaning Rusted Pitted & Rusted
ISO 8501-1 BS7079:A1 Sa 3 Sa 2.5 Sa 2 Sa 1 C St 2 D St 2 C St 3 D St 3
SSPC SP 5 SP 10 SP 6 SP 7 SP 2 SP 2 SP 3 SP 3
NACE 1 2 3 4 -
www.sherwin-williams.com/protective
continued on back
ARMORSEAL® 8100 ArmorSeal Heavy WATER BASED EPOXY FLOOR COATING Duty Floor P A B70-8100 S G Coatings P A B70-8160 S S
Revised: March. 13, 2017
art art Part
B
Application Bulletin
Application Procedures Mix contents of each component thoroughly with low speed power agitation. Make certain no pigment remains on the bottom of the can. Then combine four parts by volume of Part A with one part by volume of Part B. Thoroughly agitate the mixture with power agitation. If reducer is used, add only after both components have been thoroughly mixed. Apply paint at the recommended film thickness and spreading rate as indicated below:
Recommended Spreading Rate per coat: Minimum
Maximum
5.0 (125) 2.0 (50) 130 (3.3)
12.0 (300) 5.0 (125) 320 (8.1)
NOTE: Brush or roll to cove base or vertical surfaces may require multiple coats to achieve maximum film thickness and uniformity of appearance.
Drying Schedule @ 7.0 mils wet (175 microns): @ 50°F/10°C
To touch: To recoat*: minimum:
maximum:
To Cure Foot Traffic:
1 hour 8 hours
72 hours
7 days 36 hours
@ 77°F/25°C 50% RH
1 hour
6 hours
72 hours
7 days 18 hours
loss atin Hardener
8.18
Performance Tips
Surface preparation must be completed as indicated.
Wet mils (microns) Dry mils (microns) ~Coverage sq ft/gal (m2/L)
B70V8100
eries eries
@ 120°F/49°C
30 minutes 3 hours
72 hours
7 days 8 hours
Drying time is temperature, humidity, and film thickness dependent. *If recoating after 72 hours, abrade surface first.
Pot Life: 8 hours 5½ hours 3½ hours Sweat-in-Time: None None None Application of coating above maximum or below minimum recommended spreading rate may adversely affect coating performance.
Clean Up Instructions
During the early stages of drying, the coating is sensitive to rain, dew, high humidity, and moisture condensation. Plan painting schedules to avoid these influences during the first 16-24 hours of curing. Spreading rates are calculated on volume solids and do not include an application loss factor due to surface profile, roughness or porosity of the surface, skill and technique of the applicator, method of application, various surface irregularities, material lost during mixing, spillage, overthinning, climatic conditions, and excessive film build. For Clear applications, use the Ultra Deep Base, reduce 5% with potable water. When first mixed and applied, the material is white, but will dry Clear. DO NOT exceed 10 mils WFT. Avoid puddling material at edges or in depressions as it may not dry clear. Excessive reduction of material can affect film build, appearance, and adhesion. Do not apply the material beyond recommended pot life. Do not mix previously catalyzed material with new. Always test adhesion by applying a test patch of 2-3 square feet. Allow to dry one week before checking adhesion. Do not use hydrocarbon solvents for cleaning. Anti-slip additives, such as H&C SharkGrip® or Armorseal Hi-Wear Additive, may be added to the coating to provide some slip resistance. This product should not be used in place of a non-skid finish. Refer to Product Information sheet for additional performance characteristics and properties.
Safety Precautions Refer to the MSDS sheet before use.
Clean spills and spatters immediately with soap and warm water. Clean hands and tools immediately after use with soap and warm water.
Disclaimer The information and recommendations set forth in this Product Data Sheet are based upon tests conducted by or on behalf of The Sherwin-Williams Company. Such information and recommendations set forth herein are subject to change and pertain to the product offered at the time of publication. Consult your SherwinWilliams representative to obtain the most recent Product Data Information and Application Bulletin.
Published technical data and instructions are subject to change without notice. your Sherwin-Williams representative for additional technical data and instructions.
Warranty The Sherwin-Williams Company warrants our products to be free of manufacturing defects in accord with applicable Sherwin-Williams quality control procedures. Liability for products proven defective, if any, is limited to replacement of the defective product or the refund of the purchase price paid for the defective product as determined by Sherwin-Williams. NO OTHER WARRANTY OR GUARANTEE OF ANY KIND IS MADE BY SHERWIN-WILLIAMS, EXPRESSED OR IMPLIED, STATUTORY, BY OPERATION OF LAW OR OTHERWISE, INCLUDING MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
www.sherwin-williams.com/protective
B
B70V8100
eries eries
loss atin Hardener
Revised: March. 13, 2017
8.18
Product Description
Recommended Uses
ARMORSEAL 8100 is the next generation in water based epoxy floor coatings; a two-component polyamine epoxy with excellent chemical and abrasion resistance that is breathable. It is designed for use in commercial, industrial and residential floor applications. A LEED 4.2 compliant material that offers improved performance while maintaining ease of application properties common to water based materials. This versatile material is self-priming over concrete, can be used as a stand alone coating or as a receiver coat for paint chip floors. Available in a gloss or satin finish • Breathable • <50 g/L • Color Retention, resists yellowing • Resists disbondment due to Moisture Vapor Transmission (MVT) • Ease of application
Durable epoxy floor coating for general purpose use in industrial and commercial environments, such as: • Warehouse Floors • Garages • Residential • Automotive Showrooms • Industrial and Commercial Floors • Light manufacturing Plants • Acceptable for use in USDA inspected facilities
Product Characteristics
Performance Characteristics Substrate: Concrete Surface Preparation: Clean, dry, sound System Tested:
Finish: Gloss or Satin Color: Clear*,Tile Red, Deck Gray, Haze Gray and a wide range of tinted colors using CCE colorants 2 cts. ArmorSeal 8100 Safety Colors Gloss only * For Clear, use the Ultra Deep Base (for more detail, see Application Bulletin Performance Tips Test Name Volume Solids: 41% ± 2%, mixed, may vary by color Weight Solids: 50% ± 2%, mixed, may vary by color Abrasion VOC <50 g/L; 0.42 lb/gal, mixed (EPA Method 24): Resistance Mix Ratio: 4:1 by volume
Recommended Spreading Rate per coat: Wet mils (microns) Dry mils (microns) ~Coverage sq ft/gal (m2/L)
Minimum
Maximum
5.0 (125) 2.0 (50) 130 (3.3)
12.0 (300) 5.0 (125) 320 (8.1)
NOTE: Brush or roll to cove base or vertical surfaces may require multiple coats to achieve maximum film thickness and uniformity of appearance.
Adhesion Finish Flexibility Impact Resistance Pencil Hardness
Drying Schedule @ 7.0 mils wet (175 microns): @ 50°F/10°C
@ 77°F/25°C 50% RH 45 minutes
@ 120°F/49°C
To touch: 1 hour 25 minutes To recoat*: minimum: 8 hours 6 hours 3 hours maximum: 72 hours 72 hours 72 hours To Cure 7 days 7 days 7 days Foot Traffic: 18 hours Heavy Traffic: 48 hours Drying time is temperature, humidity, and film thickness dependent. *If recoating after 72 hours abrade surface first. Pot Life: 8 hours 5½ hours 3½ hours Sweat-in-Time: None None None Shelf Life:
Part A: 24months, unopened Part B: 36 months Store indoors at 40°F (4.5°C) to 100°F (38°C)
Flash Point: Reducer/Clean Up:
>230°F (110°C), Seta Flash, mixed Water
Slip Resistance, Floors WVP Perms (US) Hot Tire Pick-up
@ 2.0 - 4.0 mils (50-100 microns) dft
Test Method ASTM D4060, CS17 wheel, 1000 cycles, 1 kg load ASTM D4541 Satin Gloss ASTM D 522 ASTM D2794 ASTM D3363 ASTM C1028**, .60 Minimum Static Coefficient of Friction Grains(hr ft2 in Hg) ITM @ 140ºF (60ºC)
Results 150 mg loss 550 psi concrete 15-25 units@ 85º 90+ units @ 60º 180º bend 1/8" mandrel Direct 100 in.lb. Indirect 80 in.lb. H es wet and dry, with and without SharkGrip Additive Gloss – 2.0 Satin – 5.0 es
**Test method withdrawn in 2014 without replacement
www.sherwin-williams.com/protective
continued on back
ARMORSEAL® 8100 ArmorSeal Heavy WATER BASED EPOXY FLOOR COATING Duty Floor P A B70-8100 S G Coatings P A B70-8160 S S art art Part
Revised: March. 13, 2017
B
B70V8100
eries eries
Product Information
loss atin Hardener
8.18
Surface Preparation
Recommended Systems Dry Film Thickness / ct. Mils (Microns) Concrete Floors, unpainted: 1 ct. ArmorSeal 8100 2.0-4.0 (50-100) (reduced with one pint of water per gallon) 2 cts. ArmorSeal 8100 2.0-4.0 (50-100)
Surface must be clean, dry, and in sound condition. Remove all oil, dust, grease, dirt, loose rust, and other foreign material to ensure adequate adhesion. Refer to product Application Bulletin for detailed surface preparation information. Do not use hydrocarbon solvents for cleaning.
Concrete Floors, previously painted: 1 ct. Spot prime bare areas with ArmorSeal 8100
2.0-4.0
(50-100)
2 cts. ArmorSeal 8100
2.0-4.0
(50-100)
The systems listed above are representative of the product's use, other systems may be appropriate.
Minimum recommended surface preparation: Concrete & Masonry: SSPC-SP13/NACE 6, or ICRI No. 310.2R, CSP1-3
Tinting
Tint part A with CCE colorants at 100% strength. Five minutes minimum mixing on a mechanical shaker is required for complete mixing of color.
Application Conditions Temperature: Relative humidity:
50°F (10°C) minimum, 100°F (38°C) maximum (air, surface, and material) At least 5°F (2.8°C) above dew point 85% maximum
Refer to product Application Bulletin for detailed application information.
Ordering Information Packaging:
1 gallon (3.78L) and 5 gallon (18.9L) containers
Weight:
9.9 ± 0.2 lb/gal ; 1.12 Kg/L mixed, may vary by color
Safety Precautions Refer to the MSDS sheet before use. Published technical data and instructions are subject to change without notice. your Sherwin-Williams representative for additional technical data and instructions.
Warranty Disclaimer The information and recommendations set forth in this Product Data Sheet are based upon tests conducted by or on behalf of The Sherwin-Williams Company. Such information and recommendations set forth herein are subject to change and pertain to the product offered at the time of publication. Consult your SherwinWilliams representative to obtain the most recent Product Data Information and Application Bulletin.
The Sherwin-Williams Company warrants our products to be free of manufacturing defects in accord with applicable Sherwin-Williams quality control procedures. Liability for products proven defective, if any, is limited to replacement of the defective product or the refund of the purchase price paid for the defective product as determined by Sherwin-Williams. NO OTHER WARRANTY OR GUARANTEE OF ANY KIND IS MADE BY SHERWIN-WILLIAMS, EXPRESSED OR IMPLIED, STATUTORY, BY OPERATION OF LAW OR OTHERWISE, INCLUDING MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
www.sherwin-williams.com/protective
ARMORSEAL® 8100 ArmorSeal Heavy WATER BASED EPOXY FLOOR COATING Duty Floor P A B70-8100 S G Coatings P A B70-8160 S S art art Part
B
Application Bulletin
Revised: March. 13, 2017
B70V8100
eries eries
loss atin Hardener
8.18
Application Conditions
Surface Preparations Surface must be clean, dry, and in sound condition. Remove all oil, dust, grease, dirt, loose rust, and other foreign material to ensure adequate adhesion.
Temperature:
50°F (10°C) minimum, 100°F (38°C) maximum (air, surface, and material) At least 5°F (2.8°C) above dew point
Do not use hydrocarbon solvents for cleaning.
Relative humidity:
85% maximum
Concrete and Masonry For surface preparation, refer to SSPC-SP13/NACE 6, or ICRI No. 310.2R, CSP 1-3. Surfaces should be thoroughly clean and dry. Concrete and mortar must be cured at least 28 days @ 75°F (24°C). Remove all loose mortar and foreign material. Surface must be free of laitance, concrete dust, dirt, form release agents, moisture curing membranes, loose cement and hardeners. Fill bug holes, air pockets and other voids with Steel-Seam FT910. Primer required. Follow the standard methods listed below when applicable: ASTM D4258 Standard Practice for Cleaning Concrete. ASTM D4259 Standard Practice for Abrading Concrete. ASTM D4260 Standard Practice for Etching Concrete. ASTM F1869 Standard Test Method for Measuring Moisture Vapor Emission Rate of Concrete. SSPC-SP 13/Nace 6 Surface Preparation of Concrete. ICRI No. 310.2R Concrete Surface Preparation. Previously Painted Surfaces If in sound condition, clean the surface of all foreign material. Smooth, hard or glossy coatings and surfaces should be dulled by abrading the surface. Apply a test area, allowing paint to dry one week before testing adhesion. If adhesion is poor, or if this product attacks the previous finish, removal of the previous coating may be necessary. If paint is peeling or badly weathered, clean surface to sound substrate and treat as a new surface as above.
Application Equipment The following is a guide. Any reduction must be compliant with existing VOC regulations and compatible with the existing enviromental and application conditions. Reducer/Clean Up ����������Water Clear/Ultradeep tint base requires reduction of 5% by volume Brush Brush �����������������������������Nylon/Polyester or Natural Bristle Reduction �����������������������as needed up to 10% by volume, for primer coat only Roller Cover �����������������������������1/4"-3/8" woven with solvent resistant core Reduction �����������������������as needed up to 10% by volume, for primer coat only
If specific application equipment is not listed above, equivalent equipment may be substituted.
Surface Preparation Standards
Condition of Surface
White Metal Near White Metal Commercial Blast Brush-Off Blast Hand Tool Cleaning Rusted Pitted & Rusted Power Tool Cleaning Rusted Pitted & Rusted
ISO 8501-1 BS7079:A1 Sa 3 Sa 2.5 Sa 2 Sa 1 C St 2 D St 2 C St 3 D St 3
SSPC SP 5 SP 10 SP 6 SP 7 SP 2 SP 2 SP 3 SP 3
NACE 1 2 3 4 -
www.sherwin-williams.com/protective
continued on back
ARMORSEAL® 8100 ArmorSeal Heavy WATER BASED EPOXY FLOOR COATING Duty Floor P A B70-8100 S G Coatings P A B70-8160 S S
Revised: March. 13, 2017
art art Part
B
Application Bulletin
Application Procedures Mix contents of each component thoroughly with low speed power agitation. Make certain no pigment remains on the bottom of the can. Then combine four parts by volume of Part A with one part by volume of Part B. Thoroughly agitate the mixture with power agitation. If reducer is used, add only after both components have been thoroughly mixed. Apply paint at the recommended film thickness and spreading rate as indicated below:
Recommended Spreading Rate per coat: Minimum
Maximum
5.0 (125) 2.0 (50) 130 (3.3)
12.0 (300) 5.0 (125) 320 (8.1)
NOTE: Brush or roll to cove base or vertical surfaces may require multiple coats to achieve maximum film thickness and uniformity of appearance.
Drying Schedule @ 7.0 mils wet (175 microns): @ 50°F/10°C
To touch: To recoat*: minimum:
maximum:
To Cure Foot Traffic:
1 hour 8 hours
72 hours
7 days 36 hours
@ 77°F/25°C 50% RH
1 hour
6 hours
72 hours
7 days 18 hours
loss atin Hardener
8.18
Performance Tips
Surface preparation must be completed as indicated.
Wet mils (microns) Dry mils (microns) ~Coverage sq ft/gal (m2/L)
B70V8100
eries eries
@ 120°F/49°C
30 minutes 3 hours
72 hours
7 days 8 hours
Drying time is temperature, humidity, and film thickness dependent. *If recoating after 72 hours, abrade surface first.
Pot Life: 8 hours 5½ hours 3½ hours Sweat-in-Time: None None None Application of coating above maximum or below minimum recommended spreading rate may adversely affect coating performance.
Clean Up Instructions
During the early stages of drying, the coating is sensitive to rain, dew, high humidity, and moisture condensation. Plan painting schedules to avoid these influences during the first 16-24 hours of curing. Spreading rates are calculated on volume solids and do not include an application loss factor due to surface profile, roughness or porosity of the surface, skill and technique of the applicator, method of application, various surface irregularities, material lost during mixing, spillage, overthinning, climatic conditions, and excessive film build. For Clear applications, use the Ultra Deep Base, reduce 5% with potable water. When first mixed and applied, the material is white, but will dry Clear. DO NOT exceed 10 mils WFT. Avoid puddling material at edges or in depressions as it may not dry clear. Excessive reduction of material can affect film build, appearance, and adhesion. Do not apply the material beyond recommended pot life. Do not mix previously catalyzed material with new. Always test adhesion by applying a test patch of 2-3 square feet. Allow to dry one week before checking adhesion. Do not use hydrocarbon solvents for cleaning. Anti-slip additives, such as H&C SharkGrip® or Armorseal Hi-Wear Additive, may be added to the coating to provide some slip resistance. This product should not be used in place of a non-skid finish. Refer to Product Information sheet for additional performance characteristics and properties.
Safety Precautions Refer to the MSDS sheet before use.
Clean spills and spatters immediately with soap and warm water. Clean hands and tools immediately after use with soap and warm water.
Disclaimer The information and recommendations set forth in this Product Data Sheet are based upon tests conducted by or on behalf of The Sherwin-Williams Company. Such information and recommendations set forth herein are subject to change and pertain to the product offered at the time of publication. Consult your SherwinWilliams representative to obtain the most recent Product Data Information and Application Bulletin.
Published technical data and instructions are subject to change without notice. your Sherwin-Williams representative for additional technical data and instructions.
Warranty The Sherwin-Williams Company warrants our products to be free of manufacturing defects in accord with applicable Sherwin-Williams quality control procedures. Liability for products proven defective, if any, is limited to replacement of the defective product or the refund of the purchase price paid for the defective product as determined by Sherwin-Williams. NO OTHER WARRANTY OR GUARANTEE OF ANY KIND IS MADE BY SHERWIN-WILLIAMS, EXPRESSED OR IMPLIED, STATUTORY, BY OPERATION OF LAW OR OTHERWISE, INCLUDING MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
www.sherwin-williams.com/protective
