Section 1: About This Manual 1.1 Standards and Other Documents „ This Fire Alarm Control complies with the following NFPA standards:

• • • • • • • • • • • •

NFPA 12A Halon 1301 Extinguishing Systems NFPA 13 Sprinkler Systems NFPA 15 Water Spray Systems NFPA 16 Foam/Water Deluge and Foam/Water Spray Systems NFPA 17 Dry Chemical Extinguishing Systems NFPA 17A Wet Chemical Extinguishing Systems NFPA 72 Central Station Fire Alarm Systems (Automatic, Manual and Waterflow) Protected Premises Unit (requires Notifier UDACT). NFPA 72 Local (Automatic, Manual, Waterflow and Sprinkler Supervisory) Fire Alarm Systems. NFPA 72 Auxiliary (Automatic, Manual and Waterflow) Fire Alarm Systems (requires TM-4). NFPA 72 Remote Station (Automatic, Manual and Waterflow) Fire Alarm Systems NFPA 72 Proprietary (Automatic, Manual and Waterflow) Fire Alarm Systems (Protected Premises Unit). NFPA 2001 Clean Agent Fire Extinguishing Systems

„ The installer should be familiar with the following documents and standards:

• • •

NFPA 72 Initiating Devices for Fire Alarm Systems NFPA 72 Inspection, Testing and Maintenance for Fire Alarm Systems NFPA 72 Notification Appliances for Fire Alarm Systems

Underwriters Laboratories (UL) • • • • • • • • • • • •

UL 38 Manually Actuated Signaling Boxes UL 217 Smoke Detectors, Single and Multiple Station UL 228 Door Closers - Holders for Fire Protective Signaling Systems UL 268 Smoke Detectors for Fire Protective Signaling Systems UL 268A Smoke Detectors for Duct Applications UL 346 Waterflow Indicators for Fire Protective Signaling Systems UL 464 Audible Signaling Appliances UL 521 Heat Detectors for Fire Protective Signaling Systems UL 864 Standard for Control Units for Fire Protective Signaling Systems UL 1481 Power Supplies for Fire Protective Signaling Systems UL 1971 Visual Signaling Appliances UL 1076 Proprietary Burglar Alarm Systems

Underwriters Laboratories of Canada (ULC) • •

ULC-S527-99 Standard for Control Units for Fire Alarm Systems ULC S524 Standard for the Installation of Fire Alarm Systems

Other • • • • • •

EIA-485 and EIA-232 Serial Interface Standards NEC Article 300 Wiring Methods NEC Article 760 Fire Protective Signaling Systems Applicable Local and State Building Codes Requirements of the Local Authority Having Jurisdiction Canadian Electrical Code, Part 1

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

7

About This Manual

UL 864 Compliance

1.2 UL 864 Compliance 1.2.1 Products Subject to AHJ Approval This product has been certified to comply with the requirements in the Standard for Control Units and Accessories for Fire Alarm Systems, UL 864 9th Edition. The following products have not received UL 864 9th Edition certification and may only be used in retrofit applications. Operation of the NFS2-3030 with products not tested for UL 864 9th Edition has not been evaluated and may not comply with NFPA 72 and/or the latest edition of UL 864. These applications will require the approval of the local Authority Having Jurisdiction (AHJ). •

For a complete list of all peripherals that can be used with this fire alarm control (FA), and which of those peripherals have not received UL 864, 9th Edition certification and may only be used in retrofit applications, see Section 2.5, “Compatible Equipment”, on page 16.

1.3 Related Documents The table below provides a list of documents referenced in this manual, as well as documents for selected other compatible devices. The document series chart (DOC-NOT) provides the current document revision. A copy of this document is included in every shipment. Compatible Conventional Devices (Non-addressable)

Document Number

Device Compatibility Document

15378

Fire Alarm Control (FA) and Main Power Supply Installation

Document Number

NFS2-3030 Installation, Programming and Operations Manuals

52544, 52545, 52546

AMPS-24/E Addressable Power Supply Manual

51907

DVC Digital Voice Command Manual

52411

DAA Digital Audio Amplifier Manual

52410

SLC Wiring Manual

51253

Note: For individual SLC Devices, refer to the SLC Wiring Manual *Note: Also documents some retrofit equipment manufactured under UL 8th edition Off-line Programming Utility

Document Number

VeriFire™ Tools CD help file

VERIFIRE-TCD

Cabinets & Chassis

Document Number

CAB-3/CAB-4 Series Cabinet Installation Document

15330

Battery/Peripherals Enclosure Installation Document

50295

Power Supplies, Auxiliary Power Supplies & Battery Chargers

Document Number

AS-2406 Installation Manual

51304

APS-6R Instruction Manual

50702

CHG-120 Battery Charger Manual

50641

FS-24 Field Charger/Power Supply Manual

50059

FS-24S6/FS-24S8 Field Charger/Power Supply

51977

Networking

Document Number

Noti•Fire•Net Manual, Network Version 4.0 & Higher

51584

NCM-W/F Installation Document

51533

NCS Network Control Station, Network Version 4.0 & Higher Manual

51658

NCA-2 Network Control Annunciator Manual

52482

NCA Network Control Annunciator Manual

51482

Table 1.1 Related Documents (1 of 2) 8

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Cautions and Warnings

About This Manual

System Components

Document Number

Annunciator Control System Manual

15842

Annunciator Fixed Module Manual

15048

ACM-8R Annunciator Control Module Manual

15342

LCD-80 Manual

15037

LCD-160 Manual

51850

LDM Series Lamp Driver Annunciator Manual

15885

SCS Smoke Control Manual (Smoke and HVAC Control Station) Manual

15712

DPI-232 Manual

51499

TM-4 Installation Document (Reverse Polarity Transmitter)

51490

UDACT Manual (Universal Digital Alarm Communicator/Transmitter)

50050

ACT-2 Installation Document

51118

VEC 25/50 Manual

50686

RM-1 Series Remote Microphone Installation Document

51138

RA400Z Remote LED Annunciator Document

I56-508

RFX Wireless Interface Manual

51012

UZC-256 Universal Zone Coder Manual

15216

UZC-256 Programming Manual

15976

XP Transponder Manual

15888

XP10-M Ten Input Monitor Module Installation Document

I56-1803

XP5 Series Manual

50786

XP6-C Supervised Control Module Installation Document

I56-1805

XP6-MA Six Zone Interface Module Installation Document

I56-1806

XP6-R Six Relay Control Module Installation Document

I56-1804

XPIQ Audio Transponder Manual

51013

Table 1.1 Related Documents (2 of 2)

NOTE: Where used in this manual, the term U refers to the main circuit board for the fire alarm control ’s central processing unit (see Section 2.2 “System Components” for a more detailed list of part numbers.)

1.4 Cautions and Warnings This manual contains cautions and warnings to alert the reader as follows:

!

!

CAUTION: Summary in bold Information about procedures that could cause programming errors, runtime errors, or equipment damage.

WARNING: Summary in bold Indicates information about procedures that could cause irreversible damage to the control , irreversible loss of programming data or personal injury.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

9

Notes

10

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Section 2: System Overview 2.1 System Description This manual describes the NFS2-3030, based on the U2-3030D (with display) and U2-3030ND (without display). It differs from the NFS-3030 as follows: •

It has been modified to include more memory.

•

The display contains more information – a “Controls Active” LED and an “Acknowledge” button.

•

There are no module circuits – circuit module functions are performed by Digital Voice Command equipment and SLC devices.

2.1.1 Standard Features •

Connections to easily mount from one to ten Signaling Line Circuit (SLC) loops

•

Network operation

•

Uses Notifier’s VIEW® early warning fire detection and the FlashScan® or CLIP families of detectors and modules

•

Alarm, Trouble, Supervisory and Security relays

•

for 32 annunciator addresses with either 64 or 96 points each (depending on the capability of the annunciator)

•

s Style 4, Style 6, Style 7 SLC loops

•

Logic Equations

•

Multi-line display

•

Ability to activate local sounder or relay bases in alarm or pre-alarm

•

Alarm verification pre-alarm indication (NYC)

•

Supervisory duct and smoke detectors

•

s Intelligent Sensing algorithms

•

EIA-485 connections for wiring ACS annunciators (including LDM custom graphic annunciators), TM-4 transmitter

•

EIA-232 connection for printer

•

Autoprogram feature for faster programming of new devices

•

Easy connection to VeriFire™ Tools programming utility

•

The basic system power supply is addressable, charges sealed lead-acid batteries ranging in capacity from 25 to 200 amp hours, and provides 4.5 amps of power for use by the U.

•

Easy connection to auxiliary power supplies and battery chargers for custom design of very large systems.

•

Diagnostic LEDs and switches

•

Ground fault detection

•

for Remote Text Display (LCD-160)

•

for Display and Control Center (DCC) functionality

2.1.2 Options Refer to Section 2.2 “System Components” for descriptions of the various optional modules. •

Rubberized keypad with a standard “QWERTY” keyboard layout, a 640-character LCD display, indicator LEDs, and switches.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

11

System Overview

System Components

•

Separately ordered Loop Control Modules and Loop Expander Modules provide up to ten SLC loops.

•

Optional equipment includes: ACS devices, UDACT Universal Digital Alarm Communicator/ Transmitter, ACM-8R remote relay module to provide additional relay points, and audio/voice components.

2.1.3 System Limitations System expansion must take into consideration the following: 1.

The physical limitations of the cabinet configuration.

2.

The electrical limitations of the system power supply.

3.

The capacity of the secondary power source (standby batteries).

2.2 System Components !

WARNING: UL 9th Edition Compliance This product has been certified to comply with the requirements in the Standard for Control Units and Accessories for Fire Alarm Systems, UL 864 9th Edition. Operation of the NFS2-3030 with products not tested for UL 864 9th Edition has not been evaluated and may not comply with NFPA 72 and/or the latest edition of UL 864. These applications will require the approval of the local Authority Having Jurisdiction (AHJ). This manual mentions products that have received UL 864, 9th Edition certification, and also mentions products that have not. For a complete list of all peripherals that can be used with this fire alarm control (FA), and which of those peripherals have not received UL 864, 9th Edition certification and may only be used in retrofit applications, see Section 2.5, “Compatible Equipment”, on page 16.

Central Processing Unit (U) and Keypad/Display The central processing unit for the NFS2-3030 system can be ordered with a keypad/display (P/N U2-3030D) or without a keypad/ display (P/N U2-3030ND). U2-3030D serves as “primary display” version for ULC applications. U2-3030ND is intended for use in network applications; LEDs and momentary switches on the printed circuit board mimic those on the keypad to enable operation and trouble-shooting at the when it is used without a local primary display. Power supply The main power supply is AMPS-24/AMPS-24E, which provides +24 VDC power and a battery charger for a basic system. Auxiliary power supplies and/or battery chargers are available to customize large systems. Enclosures Four cabinet sizes are available; doors and backboxes are ordered separately. “A” size backboxes hold one row of modules, “B” size backboxes hold two rows, “C” size backboxes hold three rows, and “D” size backboxes hold four rows. See Section 2.4 “System Cabinets” for basic description. A variety of dress s, trim rings, and blank modules are available to accompany specific combinations of system equipment; Notifier for a complete parts list. SLC Loops: LCM-320, LEM-320 To provide one SLC loop, connect one LCM-320 to the . Connect an LEM-320 to the LCM-320 to provide a second loop. Up to five pairs of modules can be installed on the to provide a maximum of ten SLC loops. Network Connection Connect an NCM-W or NCM-F to provide a connection to Noti•Fire•Net (network version 5.0 or higher). Annunciators The NFS2-3030 s ACM-24AT/ACM-48A (and their expanders) with either 64 or 96 points at an address, as well as ACM-16AT/ACM-32A/LDM-32 (and their expanders) with 64 points at an address and Notifier’s other ACS devices. (See Section 2.5 “Compatible Equipment” if looking for specific ACS devices.) Audio System Voice evacuation applications are documented in the Audio System manuals: Digital Voice Command Manual and the Digital Audio Amplifiers Manual. 12

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Product Diagram

System Overview

2.3 Product Diagram The control electronics are contained on one printed circuit board (PCB) that holds the central processing unit (U). The U can be purchased with or without keypad and display; (see Section 2.2 “System Components” for P/N details). Connections are identical on both versions. The following figure illustrates the location of the various connections, switches, jumpers and LEDs on the circuit board. See Section 3 “Installation” for more details. Note: Relay circuits are power-limited only if connected to a power-limited signal source. Relays are rated for 2A@30VDC resistive. See Figure 3.17, “Form-C Relay Connections” on page 32.

TB7 ACS (power-limited, supervised) TB9, RDP pins: LCD-160 TB9, TOut pins: Future Use

TB1 SECUR/ALARM Relay

*TB5, left side. Printer (isolated)

TB2 SUPV/ALARM Relay

Future Use

TB3 Trouble Relay

*TB5 CTX/CRX Keltron printer supervision (TB5 CTX, REF No connection)

TB4 Alarm Relay

*J1, Network Connection (NUP), Cable P/N 75556 *J7 SLC Loop Control and Expander Modules (LCM-320, LEM-320) Cable P/N 75565

SW1 Security SW2 Supervisory

J6 Security switch connection J5 Trouble bus connection

J2 LCD Connection J4 Backlight connection

SW3 Acknowledge SW4 Signal Silence SW5 System Reset

Service-level switches for local operation without keypad/display

U23030.wmf

J13 Power connections (non-power-limited). See Section 3.10 “Connecting Power Sources and Outputs”.

SW6 Lamp Test

Test Fixture: No connection

TB6 Accessory Power (See Section 3.10 “Connecting Power Sources and Outputs”)

Lithium battery for backup of on-board memory (See Section 3.5.4 “Memory-Backup Battery”)

Status Indicator LEDs (See Figure 2.3)

J9 Keypad Connection

Note: Dotted line indicates location of optional keypad & LCD display *Circuits marked with an asterisk are supervised by communication loss. See Appendix A, “Electrical Specifications” for details.

Figure 2.1 U Connections NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

13

System Overview

Product Diagram

U-3030D-ACS.cdr

The keyboard/display assembly is shown in Figure 2.2. As shown in Figure 2.3, LEDs on the keyboard/display are repeated on the printed circuit board. This enables operation and trouble-shooting when the is used without the display assembly.

Figure 2.2 U2-3030D (Shown with Two Annunciators in DP-DISP)

Controls Active (Keypad only) LED1 Power (Green)

3030-LEDSUL9th.wmf, 3030NCA2keypad.wmf

LED3 Fire Alarm (Red) LED8 Pre-Alarm (Red) LED7 Security (Blue) LED9 Supervisory (Yellow) LED6 System Trouble (Yellow) LED12 Other Event (Yellow) LED10 Signals Silenced (Yellow) LED11 Point Disabled (Yellow) LED5 U Failure (Yellow) LED4 Factory Use Only

LEDs on Printed Circuit Board

LEDs on Keypad

Figure 2.3 Status Indicator LEDs

2.3.1 Main Power Supply The AMPS-24/E addressable main power supply provides a total of 4.5 A to the U. During normal operation it recharges batteries ranging in capacity from 25 to 200 amp-hours. See Section 3.10, “Connecting Power Sources and Outputs”, on page 33 for basic wiring connections; see the AMPS-24/E Manual for complete details. Refer to the AMPS-24/E Manual to determine whether your system requires an auxiliary power supply.

14

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

System Cabinets

System Overview

2.4 System Cabinets The U and modules are installed in a CAB-4 series backbox. There are four different sizes available, holding from one to four rows of equipment plus batteries (up to two 25AH batteries). Backboxes are ordered separately from doors. The doors can be mounted on the left or the right side of the cabinet; reversible hinges are provided so that this choice can be made in the field. Doors open a full 180 degrees and have locks. Mounting methods include surface-mounting or semi-flush mounting on a wall between 16 inch (406.4 mm) on-center studs. A trim ring option is available for semi-flush mounting. External measurements for each cabinet size are provided below. Refer to CAB-3/CAB-4 Series Cabinet Installation Document (shipped with your cabinet) for specific mounting drawings and dimensions. A-size backbox (one row)

24.125 in (612.78 mm) wide 20.125 in (511.18 mm) tall 5.218 in (132.54 mm) deep Optional trim ring TR-A4

B-size backbox (two rows)

24.125 in (612.78 mm) wide 28.625 in (727.08 mm) tall 5.218 in (132.54 mm) deep Optional trim ring TR-B4

C-size backbox (three rows)

24.125 in (612.78 mm) wide 37.250 in (946.15 mm) tall 5.218 in (132.54 mm) deep Optional trim ring TR-C4

D-size backbox (four rows)

24.125 in (612.78 mm) wide 45.875 in (1165.23 mm) tall 5.218 in (132.54 mm) deep Optional trim ring TR-D4

The U and adjacent first-row modules mount in chassis CHS-M3. Additional rows of modules mount in the cabinet using CHS-4N (shipped in kit CHS-4MB), CHS-4L, or other chassis compatible with CAB-4 series enclosures. Some additional components available in the CAB-4 series include: •

DP-DISP. An Inner Dress for covering the backbox area surrounding various modules; for use in the top row.

•

BMP-1. Blank Module Plate for covering an unused module position. Provides another location for mounting option boards such as TM-4 or NCM-W.

•

MP-1B. Blank for covering recessed equipment in second, third, or fourth rows of backbox.

•

BP2-4. Battery dress .

•

DP-1B. High-profile battery cover.

•

ADP-4B. Annunciator dress ; for use in all but the top row.

For information on audio chassis and dress s, refer to the DVC Manual and DAA Manual.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

15

System Overview

Compatible Equipment

2.5 Compatible Equipment Compatible Notifier and System Sensor equipment that connects directly to the U is listed below. These are the most common devices at time of publishing; the most complete list of compatible intelligent SLC loop devices is provided in the SLC Wiring Manual; for conventional non-addressable equipment see the Device Compatibility Document. These devices are UL and ULC listed unless marked otherwise (in parentheses next to the product). Other control s and their equipment can also be connected in a network, via Noti•Fire•Net version 5.0; refer to the Noti•Fire•Net Version 4.0 & Higher Installation Manual for details. Some products are documented in a separate manual; see Section 1.3 “Related Documents”.

!

WARNING: UL 9th Edition Compliance This product has been certified to comply with the requirements in the Standard for Control Units and Accessories for Fire Alarm Systems, UL 864 9th Edition. Operation of the NFS2-3030 with products not tested for UL 864 9th Edition has not been evaluated and may not comply with NFPA 72 and/or the latest edition of UL 864. These applications will require the approval of the local Authority Having Jurisdiction (AHJ). Peripheral devices were listed under UL 8th Edition and may only be used in retrofit applications (see Section 1.2, “UL 864 Compliance”, on page 8).

Notifier Compatible Equipment ACM-24AT Annunciator Control Module ACM-48A Annunciator Control Module ACM-8R Annunciator Control Module ACT-2 Audio Coupling Transformer AEM-24AT Annunciator Expander Module AEM-48A Annunciator Expander Module AFM-16AT Annunciator Fixed Module AKS-1B Annunciator Key Switch AMPS-24/E Addressable Main Power Supply APS-6R Auxiliary Power Supply BX-501 Intelligent Detectors/Sensors Base B501 USA Intelligent Detector Base B501BH Sounder Base B710LP European Intelligent Detector Base B710HD HARSH Detector Base B224RB Low-profile Relay Base B224BIIsolator Base for Low-profile Detectors CHG-120 Battery Charger CMX-1 Addressable Control Module CMX-2 Addressable Control Module X-551 Intelligent Ionization Smoke Detector X-751 Intelligent Ionization Smoke Detector DAA-5025/DAA-5070 Digital Audio Amplifiers DVC/DVC-EM Digital Voice Command FCM-1NAC Module FDX-551 Intelligent Thermal Sensor FDX-551R Intelligent Thermal Rate-of-Rise Sensor FHS Fireman's Handset FTM-1 Telephone Module FMM-1 Monitor Module FMM-101 Mini Monitor Module FSD-751P/RP/PL Duct Detectors FSI-751 Ion Detector FSI-851 Ion Detector Acclimate Plus™ FAPT-751 Combination Photoelectric/Heat Detector FAPT-851 (Acclimate Plus™) Combination photo/ heat Detector FSM-101 Pull Station Monitor Module FPJ-1 Fireman's Phone Jack FRM-1 Relay Module FDM-1 Dual Monitor Module FSL-751 FlashScan VIEW® Laser Detector FSH-751 HARSH™ Photo Detector FSP-751 Photo Detector FSP-851 Photo Detector, listed for use in ducts

16

FSP-751T Photo/Thermal Detector FSP-851T Photo/heat Detector, listed for use in ducts. FST-751 Thermal Detector FST-751R Thermal Rate-of-rise Detector FST-851 Thermal Detector FST-851R Thermal Rate-of-rise Detector FST-851H High-temperature Thermal Detector FZM-1 Zone Module HPX-751 HARSH™ Hostile Environment Smoke

Detector ISO-X Loop Fault Isolator Module LCD-160 Liquid Crystal Display LCM-320 Loop Control Module LDM-32 Lamp Driver Module LDM-E32 Lamp Driver Module LDM-R32 Lamp Driver Module LEM-320 Loop Expander Module LPX-751 VIEW® Low Profile Laser Detector MMX-2 Addressable Monitor Module MMX-101 Addressable Mini Monitor Module NBG-12LX Series Addressable Manual Pull Station NCA-2 Network Communications Annunciator NCM-F Network Control Module (Fiber) NCM-W Network Control Module (Wire) NCS Network Control Station N-ELR Assortment ELR Pack with Mounting Plate EOL-CR/CB Assortment ELR Pack with Mounting Plate R-120 120 Ohm End-of-Line Resistor R-2.2K 2.2K End-of-Line Resistor R-27K 27K End-of-Line Resistor R-470 470 End-of-Line Resistor R-47K 47K End-of-Line Resistor A77-716B End-of-Line Resistor Assembly RA400 Remote Annunciator RA400Z Remote Annunciator with diode RFX Wireless Transmitter (version 2.0 and higher) (Not ULC-listed): SDRF-751 Wireless Photo/Thermal Smoke Detector; 5817CB Wireless Monitor Module RKS-S Remote Security Keyswitch (Not ULC-listed) RPJ-1 Remote Phone Jack RPT-485F EIA-485 Repeater (Fiber) RPT-485W EIA-485 Repeater (Wire) RPT-485WF EIA-485 Repeater (Wire/Fiber) RM-1 Remote Microphone RM-1SA Remote Microphone

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Compatible Equipment SCS-8, SCE-8 Smoke Control System SDX-551 Intelligent Photoelectric Detector SDX-551TH Intelligent Photoelectric and Thermal

Detector SDX-751 Intelligent Photoelectric Detector STS-1 Security Tamper Switch (Not ULC-listed) UDACT Universal Digital Alarm Communicator

System Overview UZC-256 Universal Zone Coder VeriFire™ Tools / Software XPIQ Quad Intelligent Audio Transponder XP6-C Supervised Control Module XP6-R Six Relay Control Module XP10-M Ten Input Monitor Module XP6-MA Six Zone Interface Module

Transmitter

System Sensor Compatible Equipment FSB-200S Single-ended beam smoke detector with sensitivity testing

FSB-200 Single-ended beam smoke detector. A2143-00 End of Line Resistor Assembly EOLR-1 End of Line Resistor Assembly

Retrofit Equipment: Compatible Notifier Equipment Listed Under Previous Editions of UL 864 NOTE: The products in this list have not received UL 864 9th Edition certification and may only be used in retrofit applications (see Section 1.2, “UL 864 Compliance”, on page 8). ✔ACM-16AT Annunciator Control Module ✔ACM-32A Annunciator Control Module ✔AS-2406 Auxiliary Charger/Power Supply ✔AEM-16AT Annunciator Expander Module ✔AEM-32A Annunciator Expander Module ✔AFM-16A Annunciator Fixed Module ✔AFM-32A Annunciator Fixed Module ✔AMG-1/E Audio Message Generator ✔BGX-101L Addressable Manual Pull Station ✔DPI-232 Direct Interface ✔FS-24 Field Charger Power Supply ✔FS-24S6/S8 Field Charger/Power Supply ✔IPX-751 Advanced Multi-Sensor Intelligent Detector ✔LCD-80 Liquid Crystal Display Module (ACS mode)

✔MMX-1 Addressable Monitor Module ✔NCA Network Communications Annunciator ✔VS4095 Keltron Printer (Dress plate P-40) (Not

ULC-listed)

✔PRN Series 80-Column Printers (PRN-4, PRN-5,

PRN-6)

✔TM-4 Transmitter Module ✔XP5-C Transponder Control Module ✔XP5-M Transponder Monitor Module ✔XPC-8 Transponder Control Module ✔XPM-8 Transponder Monitor Module ✔XPM-8L Transponder Monitor Module ✔XPP-1 Transponder Processor ✔XPR-8 Transponder Relay Module

Continued on next page... NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

17

Notes

18

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Section 3: Installation 3.1 Preparing for Installation Choose a location for the fire alarm system that is clean, dry, and vibration-free with moderate temperature. The area should be readily accessible with sufficient room to easily install and maintain it. There should be sufficient space for cabinet door(s) to open completely. Carefully unpack the system and inspect for shipping damage. Count the number of conductors needed for all devices and find the appropriate knockouts. (Refer to Section 3.11 “UL Power-limited Wiring Requirements” for selection guidelines.) Before installing the fire alarm system, read the following: •

Review the installation precautions at the front of this manual.

•

Installers should be familiar with the standards and codes specified in Section 1.1 “Standards and Other Documents”.

•

All wiring must comply with the National and Local codes for fire alarm systems.

•

Do not draw wiring into the bottom 9 inches (22.86 cm) of the cabinet except when using a separate battery cabinet; this space is for internal battery installation.

•

Review installation instructions in Section 3.2 “Installation Checklist”.

!

WARNING: Risk of irreparable equipment damage Make sure to install system components in the sequence listed below. Failure to do so can damage the control and other system components.

!

WARNING: Risk of irreparable equipment damage Wear a static discharge strap on wrist to prevent equipment damage.

3.2 Installation Checklist The checklist that follows contains references to information included in other manuals; see Section 1.3 “Related Documents” for document part numbers. 1. 2. 3.

4. 5. 6.

Task Mount the cabinet backbox to the wall. Attach U to chassis Attach option boards (e.g. SLC loop modules, network control modules, and other devices of the same size) to chassis. Attach chassis to backbox as appropriate for system design Wire relays Attach & wire other system components † Audio/Voice equipment

Refer to: Section 3.3 “Mounting a Cabinet” Section 3.5 “Attaching the U & Chassis” • Section 3.6 “Attaching Option Boards” • Section 3.7 “Connecting the Network Control Module” • Installation document for the specific device Section 3.4 “Laying Out Equipment in Cabinet and Chassis” Section 3.9 “Form-C Relays on the U”

DVC Digital Voice Command Manual and DAA Digital Audio Amplifiers Manual † Annunciators and other ACS devices Installation document for the specific device (such as ACS Manual, ACM-8R Manual, etc. ) † Remote Data Port devices LCD-160 Manual Table 3.1 Installation Checklist (1 of 2)

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

19

Installation

Mounting a Cabinet

Task † Printer or other output device(s) † Network devices 7. 8. 9.

Refer to: Section 3.13 “Installing Printers” Noti•Fire•Net Version 4.0 & Higher Manual, and/or Installation document for specific device(s) Section 3.14 “Wiring a Signaling Line Circuit (SLC)” and the SLC Wiring Manual

Wire the Signaling Line Circuits (Notification Appliance Circuits and Initiating Device Circuits) Calculate the proper battery rating. Main Power Supply Manual Install main power supply & batteries in • Section 3.10 “Connecting Power Sources and Outputs” separate enclosure. Run cable to main • Section 3.11 “UL Power-limited Wiring Requirements” & optional power supplies, DC power outputs, relays, etc. WARNING: Do not activate power at this time. Do NOT connect batteries.

!

† Main power supply.

10. 11. 12. 13. 14. 15. 16. 17. 18.

• Main Power Supply Manual • BB-100/200 Cabinet Installation Instructions † Auxiliary power supply and/or Auxiliary power supply manuals and/or battery charger external battery charger manuals. Note: If using multiple power supplies with one set of batteries, refer to main power supply manual for connection requirements. Check that all mounting holes are secured to insure a proper Earth Ground connection. Connect wire shielding to Earth Ground. Remove insulator from lithium battery Section 3.5.4 “Memory-Backup Battery” on U Apply AC power to the control by placing the external circuit breaker to the ON position. Do NOT connect batteries until AC power is checked (see next step). Check AC power. Section 3.10.3 “Checking AC Power” Connect the batteries using interconnect cable as described in power supply manual. Install the dress s, doors and CAB-3/CAB-4 Series Cabinet Installation Document covers. Program the control . Programming Manual. Field test the system. Section 5 “Testing the System” Table 3.1 Installation Checklist (2 of 2)

3.3 Mounting a Cabinet This section provides instructions for mounting the CAB-4 Series backbox to a wall. Follow these guidelines when mounting the backbox:

!

•

Locate the backbox so that the top edge is 66 inches (1.6764 m) above the surface of the finished floor.

•

Allow sufficient clearance around cabinet for door to swing freely. (See Section 2.4 “System Cabinets”.)

•

Use the four holes in the back surface of the backbox to provide secure mounting (See Figure 3.1).

•

Mount the backbox on a surface that is in a clean, dry, vibration-free area.

CAUTION: Unless you are familiar with the placement of components within this backbox, only use the knockout locations provided for conduit entry.

Follow the instructions below. 20

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Laying Out Equipment in Cabinet and Chassis

Installation

1.

Mark and pre-drill holes for the top two keyhole mounting bolts.

2.

Select and punch open the appropriate knock-outs. (For selection guidelines, see Section 3.11 “UL Power-limited Wiring Requirements”.)

3.

Using the keyholes, mount the backbox over the two screws.

4.

Mark the location for the two lower holes, remove the backbox and drill the mounting holes.

5.

Mount the backbox over the top two screws, then install the remaining fasteners. Tighten all fasteners securely.

6.

Feed wires through appropriate knockouts.

7.

Install U and other components according to this section, before installing hinges and door (see CAB-3/CAB-4 Series Cabinet Installation Document). CAB-4 Series backbox, D-size (four-row) CAB-4 Series backbox, A-size (one-row)

Keyholes 2 places

CAB4cabinetmountingholes.cdr

Chassismounting studs (2 per row of backbox)

Mounting holes 2 places

Chassismounting studs (2 per row of backbox)

Figure 3.1 Backbox-Mounting Holes and Chassis-Mounting Studs

3.4 Laying Out Equipment in Cabinet and Chassis The NFS2-3030 allows for flexible Four positions on chassis system design. It mounts in a CAB-4 CHS-M3 series backbox using either CHS-M3 or CA-2. Follow these guidelines when deciding where to locate Use appropriate mounting slot, equipment in the backbox. There are see Figure 3.5 four basic positions available on a on page 23 chassis; the number of layers that can be mounted in each position depends on the chassis model and the module size.

1

2

3

4

The U mounts in chassis CHS-M3 in the top row of the cabinet. The U and its optional display occupy the left half of the chassis (positions 1 and 2, see Figure 3.2). Positions 3 and 4 of CHS-M3 can hold up to four layers of equipment including option boards and NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

CHS-M3.cdr

„ CHS-M3

Positions 1 and 2: U and/or NCA-2 Positions 3 and 4: Four layers of equipment

Figure 3.2 Chassis CHS-M3

21

Installation

Laying Out Equipment in Cabinet and Chassis

annunciators (door-mounted in front of CHS-M3). See Figure 3.4 for possible configurations of these four layers. The BMP-1 Blank Module Plate covers unused positions and also provides a location to door-mount some option boards (see BMP-1 Product Installation Drawing for details). „ CA-2

Back plate Microphone and handset well

Half-chassis for control and optional pair of Loop Control and Expander Modules.

CA2chassisassembly.wmf

The CA-2 Audio Chassis assembly includes hardware to mount an audio command center installation in two rows of a CAB-4 backbox. Equipment will be located in the chassis as shown in Figure 3.6. See Section 3.5.2, “Mounting in the CA-2 Audio System Chassis” and the CA-2 Installation Document.

Half-chassis for DVC and optional NCM.

Figure 3.3 CA-2 Audio Chassis Assembly „ Options for Mounting Other Equipment Layers 1&2&3 mounted to PEM studs on chassis

Layers 1&2 mounted to PEM studs on chassis

CHS-M3-options.cdr

Layers 1&2&3 mounted to PEM studs on chassis

Layer 4 mounted to PEM studs and tab-slot

Layer 4 door-mounted*

Layer 4 mounted to PEM studs and tab-slot; Layer 3 suspended from Layer 4

*Note: If CHS-4N is used, door-mounting is only for use with ACM-24AT and ACM-48A series annunciators.

Figure 3.4 Configuring Equipment in Chassis (Side View): Positions 3 and 4 of CHS-M3, All 4 Positions of CHS-4N Second, third, and fourth rows of equipment use any chassis compatible with CAB-4 series backboxes, such as CHS-4N (shipped as part of CHS-4MB) or CHS-4L. Refer to the CAB-3/CAB-4 Series Cabinet Installation Document for a complete list. Some equipment (such as annunciators) can be door-mounted as shown in Figure 3.9; refer to your equipment’s documentation for instructions.

22

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Attaching the U & Chassis

Installation

Examples of option boards are LCM-320, LEM-320, NCM-W/F, TM-4, and DPI-232; see Section 3.6 “Attaching Option Boards”. The documentation shipped with your equipment may also contain device-specific instructions. NOTE: It is recommended that system design take into consideration the UL requirements for minimum separation of power-limited and non-power-limited wiring; for example, having all non-power-limited circuits grouped in one area of the cabinet (see Section 3.11 “UL Power-limited Wiring Requirements” and your power supply manual).

3.5 Attaching the U & Chassis Note for U2-3030D. Due to the difficulty of reaching under the keypad, it may be convenient to remove the insulator from the lithium memory-backup battery before mounting the U into the chassis. See Section 3.5.4 “Memory-Backup Battery”.

3.5.1 Mounting in CHS-M3 Mount U into positions 1 and 2 of CHS-M3 as follows; equipment may be mounted to the chassis before or after the chassis is mounted in the backbox. Some equipment may be door-mounted directly in front of the U; see Section 3.4 “Laying Out Equipment in Cabinet and Chassis” and the manual shipped with the other device. 1.

Attach four stand-offs to chassis as shown in Figure 3.5. U2-3030D (with keypad/display) requires the longer stand-offs: 1.5 inch (38.1 mm); U2-3030ND (without keypad/display) requires the shorter stand-offs: 0.25 inch (6.35 mm)

2.

Slide circuit-board tabs into slots on chassis as shown in Figure 3.5.

3.

Place the board over the stand-offs so that mounting holes line up with those on the chassis. Secure all stand-offs with screws provided.

U standoffs at Positions 1 and 2: 1.5 inch (38.1 mm) for use with U2-3030D or 0.25 inch (6.35 mm) for use with U2-3030ND

Chassis-mounting slots U2-3030ND (without keypad/display) U2-3030D (with keypad/display)

CHS-M3.cdr

NCA-2 (see NCA-2 Manual)

Figure 3.5 Standoffs on Chassis CHS-M3

!

CAUTION: It is critical that all mounting holes of the Fire Alarm Control are secured with a screw or stand-off to insure continuity of Earth Ground.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

23

Installation

Attaching the U & Chassis

3.5.2 Mounting in the CA-2 Audio System Chassis The NFS2-3030 will mount into the CA-2 chassis assembly—along with a DVC, microphone and optional telephone handset— as part of an audio command center installation.

Back plate Upper half-chassis (FA)

Microphone and handset well

•

a back plate that attaches to the backbox

•

two half-chassis, each of which takes up the left half of a backbox row

•

a microphone and telephone handset well

•

a microphone

CA-2 can also mount TELH-1, an optional telephone handset.

Lower half-chassis (DVC)

Figure 3.6 CA-2 Chassis Assembly

CA2chassisassembly.wmf

The CA-2 is a two-row assembly consisting of

The NFS2-3030 mounts in the upper half-chassis. (Refer to Figure 3.6 and Figure 3.7.) If first mounting an optional LCM-320/LEM-320 pair behind the FA, refer to Section 3.8.2, “Audio Applications with Chassis CA-2”. Mount the NFS2-3030 to its half-chassis without removing the half-chassis from the back plate. Refer to “Memory-Backup Battery” on page 25 for removal of insulator. Upper half-chassis

Slide the tabs at the bottom of the control into the inner slot at the bottom of the chassis. (See the DVC Manual for details)

Fasten with four screws as indicated.

NCA23030keypadangld.wmf NCA23030bdonhalfchas.wmf CA23030halfchassis.wmf

NFS2-3030

Figure 3.7 Mounting the NFS2-3030 onto the CA-2 Half-chassis Refer to the DVC Manual for installation of the DVC, microphone and handset into the CA-2.

3.5.3 Mounting Chassis in Backbox „ CHS-M3

Align chassis-mounting slots with chassis-mounting studs (see Figure 3.1 and Figure 3.5 for locations). Secure with nut & lock-washer provided with chassis. „ CA-2

Install all equipment into the CA-2 and attach to the CA-2 backplate before the chassis assembly is attached to the backbox. Align four backplate-mounting slots with backbox’s chassis-mounting studs. Secure with nut and lock-washer provided with chassis. For details, see the instructions in the CA-2 Installation Document.

24

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Attaching the U & Chassis

Installation

The lithium battery on the U provides backup of the U’s on-board memory during power loss. The U ships with an insulator to prevent the battery from discharging. To preserve the battery, the insulating tube should be left in place as long as possible before applying AC power. If the insulator is not removed before applying AC power, the control will show a trouble situation.

3030-lithium.cdr

3.5.4 Memory-Backup Battery

Lift clip gently while removing battery

Dotted line indicates location of insulator

This battery’s shelf-life should exceed 10 years, but if for some reason it fails, the control will show a trouble when powered up. To replace the lithium battery: 1.

!

Make a full backup of all system settings to prevent loss of all programming data.

2.

Disconnect all power sources.

3.

U2-3030D only: Disconnect wiring and remove U2-3030D from backbox (3 screws at top, lift board tabs out of slot) and remove keypad (4 screws on back, LCD display stays attached).

4.

Remove battery from under clip (use fingers, because screwdriver could damage components) and insert new battery.

CAUTION: The battery used in this device may present a risk of fire or chemical burn if mistreated. Do not recharge, disassemble, heat above 212°F (100°C), or incinerate. Replace battery with Notifier P/N 31004 "(RAYOVAC lithium 3 Volt BR2335)" only. Use of another battery may present a risk of fire or explosion.

5.

U2-3030D only: Replace keyboard, reinstall U2-3030D into chassis, and reconnect wiring.

6.

Follow system power-up procedures.

7.

Dispose of used battery promptly. Keep away from children. Do not disassemble and do not dispose of in fire.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

25

Installation

Attaching Option Boards

3.6 Attaching Option Boards If installing option boards into a CAB-4 Series backbox, mount & connect those boards at this time. This section contains general instructions for mounting an option board; see the documentation that shipped with your board for any product-specific instructions.

To mount option boards in the front of the chassis, use stand-offs built into the chassis arms.

CHS-M3.cdr

To mount option boards against the CHS-M3 backplate, attach stand-offs to the chassis studs.

When applicable, slide tabs at bottom of option boards into the matching slot.

For mounting in CHS-4L, see Figure 3.14

Figure 3.8 Mounting Option Boards in CHS-M3 As described in Section 3.4 “Laying Out Equipment in Cabinet and Chassis”, up to eight option boards can be mounted in CHS-M3 to the right of the U; additional modules can be mounted in other chassis. There are no slots in the first (back) two layers, but option boards with tabs (such as NCM-W) will still fit in those positions. Option boards can be door-mounted behind a single-space blank plate (see Figure 3.9), and mounted in any CAB-4 compatible chassis.

tm4adp4.cdr

Mount single-space blank plate onto compatible dress Single-space blank plate

Mount option board onto stand-offs on the blank plate Fasten option board to the plate with four screws (included).

Note: Mounting instructions for option boards are the same in various dress s.

Figure 3.9 Door-Mounting Option Boards with a Single-space Blank Plate 26

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Connecting the Network Control Module

Installation

Mounting procedures 1.

Install four 1 inch (25.4 mm) stand-offs onto the chassis as shown in Figure 3.8.

2.

Place the first option board over the stand-offs so that holes line up.

3.

If no more option boards will be mounted in that position, securely fasten all stand-offs with screws (provided with module). If mounting a second or third option board, attach another layer of stand-offs and repeat steps 2-3. Note: Set the switches on an option board before mounting another layer in front of it.

4.

If mounting a pair of SLC loop modules, refer to Section 3.8 “Connecting the Loop Control and Expander Modules” and to Section 3.8.5 “Installing a Multi-layer Module into the Chassis”.

5.

For the top (fourth) layer of option boards, slide the tab at the bottom of the board into the slots on the chassis, and lay the board back onto the top of the chassis so that the studs line up with mounting holes on the option board. Securely fasten all stand-offs with screws provided with module.

6.

If mounting the option board behind a blank module plate in a dress plate or annunciator backbox, see Figure 3.9 and the BMP-1 Product Installation Drawing. This dress plate is suitable for option boards, which do not need to be visible or accessible when the door is closed.

7.

If mounting a pair of loop control/expander modules, see Section 3.8 “Connecting the Loop Control and Expander Modules”.

NOTE: Mounting two pairs of loop-control and -expander modules in one chassis position may cause intermittent electrical interference. If this occurs, move one pair to a separate chassis position.

3.7 Connecting the Network Control Module If networking two or more control s (or network control annunciators), each one requires a Network Control Module; a wire version and a fiber version are available. The NCM-W/F can be installed in any option board position described in Section 3.6, “Attaching Option Boards”. The preferred positions are immediately to the right of the main circuit board, or in the row below. If the system uses Digital Voice Command, the DVC’s NCM-W/F can be mounted behind the DVC on its chassis; see the DVC Manual for instructions. If using the Digital Audio Amplifier, the DAA’s NCM-W/F can be mounted on the DAA chassis; see the DAA Manual for instructions. 1.

Mount the NCM in the selected position. If another board is going to be mounted in the slot immediately in front of it, use stand-offs to secure it in place. Otherwise use the screws provided.

2.

Connect J1 on the U to J3 on the NCM using the network cable provided (P/N 75556). Do not connect two NCMs via NUP ports (aka NUP to NUP).

3.

Connect Channel A and/or Channel B as described in the NCM Installation Document.

NOTE: See the Noti•Fire•Net Version 4.0 & Higher Manual and NCM Installation Document for system configuration information. See the BMP-1 Product Installation Drawing if considering mounting the module (wire version) behind blank module plate in a dress plate or annunciator backbox.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

27

Installation

Connecting the Loop Control and Expander Modules

3.8 Connecting the Loop Control and Expander Modules 3.8.1 Mounting Instructions Mount loop control and expander modules within the cabinet with the U. Two typical mounting positions are adjacent to the or in the row immediately below it. (DVC applications in the CA-2 chassis have specific requirements; see “Audio Applications with Chassis CA-2” at the end of this section.) Follow the basic chassis-mounting instructions given for option boards. Loop-expander modules are mounted first; Loop-control modules are mounted on top of those. Alternately, loop-control and loop-expander modules can be attached to each other and mounted as a pair to the chassis. See Figure 3.12 for connection instructions, connector locations and stand-off lengths. To suspend a pair of modules in the third and fourth layer of CHS-M3, follow the instructions given in Section 3.8.5 “Installing a Multi-layer Module into the Chassis”. If using loop control and expander modules in CHS-4L see Figure 3.14. NOTE: Mounting two pairs of loop control and expander modules in one chassis position may cause intermittent electrical interference. If this occurs, move one pair to a separate chassis position.

After all loop-control and loop-expander modules are mounted in the cabinet, connect the SLC loops to TB1 on each loop-control and loop-expander module as shown in Figure 3.16. Daisy-chain the loop-control modules as shown in Figure 3.15. The ribbon-cable connection runs from header J7 on the U to header J1 (“Data in”) on the first loop-control module, from J3 (“Data out”) on that unit to J1 on the next unit in the chain, and likewise for up to five loop-control modules. Each module should be assigned a unique SLC loop number (see below); loop number does not need to match the module’s location in this daisy-chain. FlashScan devices can operate in either FlashScan or, for retrofit applications, CLIP mode. Each LCM-320 or LEM-320 running a FlashScan SLC can up to 159 detectors and 159 modules. CLIP loops are limited to 99 detectors and 99 modules. These and other capacity restrictions for CLIP mode loops are discussed in Section 3.14 “Wiring a Signaling Line Circuit (SLC)”. Refer to the SLC Wiring Manual for wiring requirements and specific details.

!

28

CAUTION: Do not program more than 99 addresses on a CLIP-mode SLC loop, because this will slow the system down and compromise the response time of the to display off-normal events.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Connecting the Loop Control and Expander Modules

Installation

CA23030LCMLEM.wmf

3.8.2 Audio Applications with Chassis CA-2

Figure 3.10 Mounting First Pair of Loop Control and Expander Modules in CA-2 The first pair of loop control and expander modules should be mounted behind the DVC as shown in Figure 3.10, or in the row immediately below the CA-2. Any additional loop control and expander modules should be mounted in the row immediately below the CA-2.

3.8.3 Setting SLC Loop Number Assign a unique SLC loop number to the loop control module by setting SW1 on the module to 1, 3, 5, 7, or 9. The loop expander module which is mounted behind this loop control module will be assigned the next-higher even number. For example, if the LCM-320 is set to loop number 5, the LEM-320 mounted to it will be set to loop number 6.

3.8.4 Enabling External Power Supervision With LCM-320 revision 2.0 and higher, some type codes have external power supervision built into the software; see Section 4.2 “Devices Requiring External Power Supervision” for details.

3.8.5 Installing a Multi-layer Module into the Chassis Follow the instructions illustrated in Figure 3.13 to install a pair of loop control/expander modules into CHS-4N or CHS-M3. See Figure 3.14 to install loop control/expander modules in CHS-4L. 1.

Angle the module into the chassis so that the upper end of the rear board (or boards) fits into the top slot.

2.

Bring the module back down so that the lower board edges slip into the bottom slots.

3.

Secure the module to the chassis with the two module screws. Tighten securely.

4.

Connect the ribbon cable to the module.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

29

Installation

Connecting the Loop Control and Expander Modules

TB1 SLC Loop Connection

TB1 SLC Loop Connection

J3 Data Out to next LCM-320 J1 Data In from control or from previous LCM-320

LCM-320.wmf

Ground Fault LEDs: D32 Loop Expander Module Ground Fault D28 Loop Control Module Ground Fault LEM-320.wmf

J2 LEM-320 Connection

LCM-320 Connection

SW1 Set to assign a unique SLC loop number

LCM-320

LEM-320

Note: Do not cut any jumpers on LCM-320 or LEM-320.

Figure 3.11 LCM-320 and LEM-320 Diagram

Loop Expande r Module Loop Control Module

Loop Expander Module

Loop Control Module

J1

J2

A+ BSLC

A-

The long-pin end plugs directly into the back of the Loop Control Module board.

TB1

B+

Stand-off locations

The short-pin end plugs directly into the top of the Loop Expander Module plug.

LEM-LCM.cdr

J1

J2 on LCM-320 “LEM-320 Data”

J1

J2

!

CAUTION: If the stacker-connector is installed upside-down, the short-pin end of the plug can fail to make a secure connection when plugged through the Loop Control Module.

Loop Expander Module mounted behind Loop Control Module

Figure 3.12 Connecting Loop Control Modules with Loop Expander Modules

30

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Connecting the Loop Control and Expander Modules

Installation

Top Slot

voice-mount-mod.cdr

Module Screw

Chassis

Bottom Slots

Figure 3.13 Inserting a Two-Layer Module into CHS-4N or CHS-M3 Chassis NOTE: Depending on system components, clearance may be tight. Do not force modules! Move the assembly around gently until you find the angle where components and mounting studs each other without scraping together. Use a slimline screwdriver (3/32") to fasten down LEM-320 through the hole in the LCM-320 board.

CHS-4L-LEM-LCM.cdr

Angle tab on loop control module into slot on CHS-4L

For mounting in CHS-M3, see Figure 3.8

Figure 3.14 Inserting Pair of Loop Control and Expander Modules into CHS-4L

J7 on U

3030LCMchain.cdr

•

J1 on LCM-320 “Data in”

J3 on LCM-320 “Data out”

Figure 3.15 Connecting Multiple Pairs of Loop Control and Expander Modules NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

31

Form-C Relays on the U

A+ BSLC

A-

TB1

B+

TB1

Installation

B+ A+ B-

A+ BSLC

A-

TB1

B+

TB1

J1

A-

B+ A+ B-

A-

J2

J1

LCM-320 (in front)

LEM-320 (in back)

LEM-SLC.cdr

LEM-320 DATA

SW1 LCM-320PCA

LCM-SLC.cdr

J1

Figure 3.16 SLC Loop Connections on Loop-Control and Loop-Expander Modules

3.9 Form-C Relays on the U The provides a set of Form-C relays. These are rated for 2 A at 30 VDC (resistive): • • • •

Alarm - TB4 Trouble - TB3 Supervisory - TB2 Security - TB1

The Supervisory and Security s can also be configured as Alarm s by setting switches SW1 and SW2 away from the factory default positions shown in Figure 3.17.

3030-2-relays.wmf

SW1 set to Security SW2 set to Supervisory Move switch to opposite position to convert to Alarm relays.

Figure 3.17 Form-C Relay Connections

32

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Connecting Power Sources and Outputs

Installation

3.10 Connecting Power Sources and Outputs !

!

WARNING: Remove all power sources to equipment while connecting electrical components. Leave the external, main power breaker OFF until installation of the entire system is complete.

WARNING: Several sources of power can be connected to the control . Before servicing the control , disconnect all sources of input power including the battery. While energized, the control and associated equipment can be damaged by removing and/or inserting cards, modules, or interconnecting cables.

3.10.1 Overview Complete all mounting procedures and check all wiring before applying power. Electrical connections include the following: •

Primary power source. +24VDC, delivered through AMPS-24/AMPS-24E main power supply. If AMPS-24/E is mounted in a separate cabinet, power-supply wiring must be in conduit (for cabinet placement information see Section 3.4 “Laying Out Equipment in Cabinet and Chassis” and the AMPS-24/E Manual.

•

Secondary power source. +24 VDC from batteries, installed in the control (or in an optional battery cabinet). Secondary (battery) power is required to the system during loss of primary power.

•

External power sources. +24VDC auxiliary power supplies that are UL/ULC-listed for fire protective service.

•

Accessory power for peripheral devices. TB6 on the U draws power from primary, secondary and external sources to +24 VDC power to devices within the same enclosure as the U. If those devices have outputs, the outputs must be power-limited. Power rating is limited by the AMPS-24/24E (TB6) primary power source, which is +24VDC and 4.5 Amps max. Refer to the AMPS-24/24E Manual for further details.

NOTE: The U ships with an insulator to prevents its lithium battery from discharging. To preserve the battery, this insulator should be left in place as long as possible before applying AC power. Some installers may find it convenient to remove the insulator before mounting all equipment.

NOTE: If using multiple power supplies with one set of batteries, refer to main power supply manual for connection requirements.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

33

Installation

Connecting Power Sources and Outputs

3.10.2 Connecting the Power Supply Connect J13 Power on the U to TB2 on AMPS-24/E with Cable 75637 (see Figure 3.18). This cable is 20 feet long, and must run in conduit between the backbox containing the fire alarm control and the backbox containing the AMPS-24/E. See AMPS-24/E Manual for full details and installation precautions. In order to conserve batteries, connect AC power and check it before connecting batteries. Follow the procedures specified in the power supply manual.

Cable 75637 AMPS-24 Main Power Supply

3030-AMPS-24.wmf

Black Red

Black Brown Orange

Red

U2-3030

Figure 3.18 DC Power Connections: Main Power Supply

3.10.3 Checking AC Power Table 3.2 contains a checklist for checking the system with AC power applied to the main power supply:

!

CAUTION: While checking AC power, make sure batteries are not connected. Component

Status

U

The green Power indicator will come on when power is coming from the main power supply. The yellow Trouble indicator will come on until batteries are connected.

Main power supply

The green AC indicator will come on when AC is supplied. The yellow Trouble indicator will come on until batteries are connected.

Each auxiliary power supply

The yellow Trouble indicator comes on because batteries are not connected.

Table 3.2 AC Power Checklist

3.10.4 Auxiliary Power Supply Connections If an optional auxiliary power supply is installed in the cabinet, connect it at this time. Follow the connection procedures specified in your auxiliary power supply manual.

34

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

UL Power-limited Wiring Requirements

Installation

3.11 UL Power-limited Wiring Requirements Power-limited and non-power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25 inches (6.35 mm) from any non-power-limited circuit wiring. All power-limited and non-power-limited circuit wiring must enter and exit the cabinet through different knockout and or conduits. To maintain separations easily, it is recommended that non-power-limited modules are grouped together. For example, use a separate row or designated side of the enclosure so that power-limited and non-power-limited wiring do not cross. Install tie wraps and adhesive squares to secure the wiring. For a quick reference to control circuits, refer to Figure 2.1 at the start of this manual. The power-limiting label inside your cabinet door identifies which compatible modules have power-limited or non-power-limited wiring. Nonpower-limited circuit (Assumes relay is connected to a non-power-limited signal source)

Side-View

Power-limited circuits

NFS2-3030

Loopcontrol & Loopexpander modules

amps24cab3wiring.cdr

3030ULWIRING.cdr

Power-limited circuits

Separating non-power-limited and power limited circuits within the backbox with adhesive squares

Figure 3.19 Typical Wiring in a Four-Row Backbox Some devices (such as ACM-8R and LDM-R32) are power-limited only when connected to power-limited sources. When one of these devices is connected to a non-power-limited source, the power-limited marking must be removed, and at the time of installation, each non-power-limited circuit connected to these modules must be identified in the space provided on the cabinet door label. NOTE: Relays are power-limited only when connected to power-limited sources for the relay outputs.

3.12 ULC Remote Connection Feature ULC requires that devices such as TM-4 and UDACT be disconnected during annual testing to prevent transmission of false alarms. Disconnecting TM-4 for Annual Testing Follow standard installation procedures as described in the TM-4 installation documentation. To disable reporting, slide SW4 Disable All Output switch from “Enable” to “Disable.” Refer to TM-4 documentation for product drawing.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

35

Installation

Installing Printers

Disconnecting UDACT for Annual Testing Install UDACT as the last device on the EIA-485 line, with a listed key switch such as AKS-1B installed on the EIA-485 line. In this case only, install the ELR between the EIA-485 wires just in advance of the key switch (see Figure 3.20). The key switch should be installed so that key-removed is the closed position; it should be located inside the same backbox as the UDACT, as close to the UDACT as possible.

3030-UDACT-switch.cdr

NOTE: During testing when the key switch is turned, the will report a communication failure for the UDACT’s address.

UDACT

U

Figure 3.20 Wiring a Key Switch to Disconnect UDACT During Annual Testing

3.13 Installing Printers This section contains information on connecting a printer to the U and for setting the printer options. The basic steps are as follows: 1.

Make custom cable & connect it from printer to EIA-232 terminal on the U.

2.

Connect printer’s power supply.

3.

Configure printer settings as described in printer documentation.

The PRN provides a printed record (80 columns on standard 9" x 11" tractor-feed paper) of all system events (alarm, trouble) and status changes within the system. The control can be configured to time-stamp the printout with the current time-of-day and date for each event. The printer can be located up to 50 feet (15.25 m) from the control . Installation and configuration instructions follow.

6769cov.tif

„ Overview: PRN Printer

„ Overview: Keltron Remote Printer (Model VS4095)

The VS4095 is a two-color (red and black), 40-column, 24 VDC printer that can print up to 50 messages in 90 seconds. This printer connects to the EIA-232 TB5 on the U and to the +24V screw on TB6 of AMPS-24/E, and mounts in a separate cabinet next to the control . The VS4095 meets UL fire and security requirements for an ancillary device; it is not ULC-listed. For more information on the Keltron printer, the manufacturer (Keltron Corp., Waltham, MA). Installation and configuration instructions follow.

36

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Installing Printers

Installation

3.13.1 Printer Installation Sequence 1.

Fabricate a custom cable to connect a printer to the system. Length of the cable will vary with each installation, but should not exceed a maximum length of 50 feet (15.24 meters). Printer must be installed in the same room as . Using overall foil/braided-shield twisted-pair cable, properly connect one end to the DB-25 Connector (provided) using the wiring specifications shown in Figure 3.21.

2.

Tighten clamp on connector to secure cable. Connect the four open leads of the custom cable to the TB5 terminal block on the U as shown in Figure 3.21.

DB-25 connector on PRN Series Printer 7

Keltron Printer VS4095/5 power connections*

DB-25 connector on Keltron Printer VS4095/5*

32

7

43 2

DC IN +

DC IN -

3030-keltron.cdr

3030-printer.cdr

GND

ACCESSORIES TB6

GND

+24V 1AMP

+5V 1AMP

TB5 on Control

3030-keltronpower.cdr

Note: Outputs are power-limited but are not supervised.

TB6 of AMPS-24/E

TB5 on Control

*Note: VS4095/5 is not ULC-listed.

Figure 3.21 Printer Connections 3.

If installing a Keltron Printer VS4095/5, connect 24 VDC non-resettable power from a UL-listed power supply to the Keltron printer as shown in Figure 3.21 (14 AWG).

4.

If installing a PRN series printer, plug it into your AC power source. Note: PRN printers require a 120 VAC, 50/60 Hz primary power source. If required for the fire alarm system configuration (for example, a Proprietary Fire Alarm System), a remote printer requires a secondary power source (battery backup). Because a secondary power source is not provided, use a separate Uninterruptable Power Supply (UPS) that is UL-listed for Fire Protective Signaling.

5.

Plug the DB-25 connector end of the custom cable into the EIA-232 port of your printer. Tighten securely.

6.

Configure the printer as described in Section 3.13.2 “Configuring the Printer”.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

37

Installation

Installing Printers

3.13.2 Configuring the Printer Refer to the documentation supplied with your printer for instructions on configuring your printer.

PRN Printer Settings Set the printer options (under the menu area) according to the settings listed in Table 3.3. Option

Setting

Option

Setting

L/R Adjust

0

Menu Lock

ON

Font

HS Draft

Language

English

I

10 I

Paper Single Form Adjust Trac 1 Form Adjust Trac 2 Form Adjust Auto Sheet Feeder Form Adjust

LPI

6 LPI

Skip

0.0

ESC Character

ESC

Emulate

FX-850

Bidirectional Copy

ON

I/O Interface Buffer Serial Baud Format Protocol *

12/72 12/72 12/72 12/72

Serial 40K

Auto Tear

OFF

F-Eject

OFF

9600 8 Bit, None, 1 Stop ENQ/STX

CG-TAB

Graphic

Character Set

Standard

Country

E-USA ASCII

Form Length Trac 1 Lines Standard Trac 2 Lines Standard

Select Zero

ON

Barcode

Off

Auto-CR

OFF

Barmode

Unsecured

Auto-LF

OFF

66 10.5” 66 10.5”

*Protocol: When printing in graphics mode, set I/O Serial Protocol to “Robust XON/OFF”.

Table 3.3 PRN Setup Options

Keltron Printer VS4095/5 Settings The printer communicates using the following protocol: •

• • •

Baud Rate – Supervised mode: 2400 – Unsupervised mode: 300 (Supervision is a programmed setting; refer to the Programming section of the Programming Manual for instructions.) Data bits: 8 Parity: None Stop bits: 1

Set the printer DIP switches SP1 and SP2 according to settings in Table 3.4.

38

Supervised SP1

On

1 2

Unsupervised

Off

SP1

On

X

1

X

X

2

3

X

3

4

X

4

5

X

6

5 X

Off X

X X X

6

Supervised and Unsupervised SP2

Off X

2

X

3

X

4 5

X

On

1

X X

6

X

7

X

7

X

7

X

8

X

8

X

8

X

Table 3.4 Keltron DIP Switch Settings

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Wiring a Signaling Line Circuit (SLC)

Installation

3.14 Wiring a Signaling Line Circuit (SLC) 3.14.1 SLC Overview Communication between the U and intelligent and addressable initiating, monitor, and control devices takes place through a Signaling Line Circuit (SLC). You can wire an SLC to meet the requirements of NFPA Style 4, Style 6, or Style 7 circuits. This manual provides requirements and performance details specific to this control ; for installation information and general information, refer to the SLC Wiring Manual. For electrical specifications, see Appendix A.2 “SLC Loops”. For additional notes on SLC resistance values, see Section 5.3 “Operational Checks”.

3.14.2 SLC Capacity The NFS2-3030 s up to five pairs of loop control and expander modules, providing from one to ten SLC loops. Loop capacity depends on operating mode: •

Flash Scan: 01-159 intelligent detectors, 01-159 monitor and control modules

•

CLIP: 0-99 intelligent detectors, 01-99 monitor and control modules

FlashScan devices can operate in either FlashScan or, for retrofit applications, in CLIP mode. Older models of CLIP devices only addresses up to address 99. CLIP loops are limited to 99 detectors and 99 modules. NOTE: Response times for CLIP loops may vary. CLIP loops must be tested to assure that actuation of notification appliances occurs within 10 seconds after activation of an initiating device. Systems with response time that exceed 10 seconds must be approved by the AHJ.

The following configuration guidelines may be used to improve the response times of CLIP loops: 1.

All manual pull stations must be assigned addresses from 1-20.

2.

Loops must be programmed for Rapid Poll (refer to the programming manual for specific instructions).

3.

Modules on a fully loaded loop must adhere to a ratio of two monitor modules to one control module.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

39

Installation

Connecting a PC for Programming

3.14.3 SLC Installation Install loop control and expander modules as described in Section 3.8 “Connecting the Loop Control and Expander Modules”. Note that the unique SLC loop number assigned to a module does not need to match the module’s location in the cabinet. For details on deg, installing and configuring SLC loops, see the SLC Wiring Manual.

B+ A+ B- A- TB1

B+ A+ B- A- TB1

SLC Loop Connections on Loop Control Modules

SLC Loop #2 Connections on Loop Expander Module

3030-slcloops.cdr

Channel Channel B A

Channel B (output loop)

Channel A (loop return)

B+ A+ B- A-

Style 4 SLC Loops

SLC loop connections are the same for Loop Expander and Control Modules

T-Tapping is not allowed on a four-wire SLC. B+ A+ B- A-

Style 6 SLC Loops

Figure 3.22 SLC Loop Connections and Wiring

3.15 Connecting a PC for Programming A PC running the VeriFire™ Tools programming utility can and the operating program of the control when attached to J1 Network/Service Connection (NUP) or to the second Network/Service connection on an attached NCM-W/F. Refer to the VeriFire™ Tools CD for instructions. NOTE: operations that change the basic program of the control must be performed by responsible service personnel in attendance at the control . After ing a program, test the control in accordance with NFPA 72.

40

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Section 4: Applications 4.1 Overview A listing of chapters and topics covered in this section: Chapter

Covers the following topics

Section 4.3 “NFPA 72 Central or Remote Station Fire Alarm System (Protected Premises Unit)”

How to install a UDACT with the U for use as a NFPA Central or Remote Station Fire Alarm System (Protected Premises Unit)

Section 4.4 “NFPA 72 Proprietary Fire Alarm Systems”

How to set up a Protected Premises Unit to communicate with a listed compatible Protected Premises Receiving Unit.

Section 4.5 “Fire/Security Applications”

How to use the U as a combination Fire/Security system, including the following: • Installing a Security Tamper Switch into the cabinet • Circuit Wiring

NOTE: NFS2-3030 is not listed for Canadian security application. „ Municipal Box (Auxiliary)

Municipal Box applications require a TM-4 Transmitter module. Refer to the Transmitter Module TM-4 installation document for installation details.

4.2 Devices Requiring External Power Supervision With LCM-320 revision 2.0 and higher, certain type codes have external power supervision (FlashScan only) built into the software. An external power-supervision relay is required (see Figure 4.1) unless one of the following typecodes is selected for the device: • • • •

Control Relay Strobe Horn

• • • •

(Blank) Release Ckt Rel Ckt Ulc Rel Form C

• • • •

• • • •

Nonreset Ctl Alarms Pend Gen Alarm Gen Super

Gen Trouble Gen Pend Trouble Pend Form C Reset

SLC from FA or LCM/LEM

Non-resettable 24 VDC Power from a listed source – +

Device to be Supervised

N.C. Supervision Relay Part of EOLR-1 (Not required for FlashScan type codes that provide built-in power supervision.)

FCM-1

3030-external-power-sup.wmf

– +

Power Supervision Relay (EOLR-1) (Not required for FlashScan type codes that provide built-in power supervision.)

Figure 4.1 Enabling External Power Supervision Using Relays

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

41

Applications

NFPA 72 Central or Remote Station Fire Alarm System (Protected Premises Unit)

4.3 NFPA 72 Central or Remote Station Fire Alarm System (Protected Premises Unit) The figure below shows typical wiring diagram for a NFPA 72 Central Station Fire Alarm System (Protected Premises Unit) or a Remote Station Fire Alarm System (Protected Premises Unit) using the Universal Digital Alarm Communicator/Transmitter (UDACT) and NFS2-3030. Connect and program the UDACT according to the directions given in The UDACT Instruction Manual. NOTE: An NFPA 72 Central Station requires 24 hours of standby power; an NFPA 72 Remote Station requires 60 hours of standby power.

Typical wiring of a UDACT with NFS2-3030: FA Cabinet +24 VDC non-resettable power from main or auxiliary power supply

Ferrite cores P/N 29090

To supervised phone lines

Solid earth ground

EIA-485 (ACS Mode) TB7 on control

+24V Gnd RS+ ACS/Term RSShield RS+ TERM (NC) RS-

NOTE: Install a 120 ohm End-of-Line resistor (P/N 71244) UDACT TB1 terminals 3 and 4 if last or only device on EIA-485 line.

UDACT in ABS-8RB (shown with cover removed)

3030-UDACT.cdr

Supervised and power-limited EIA-485 and power wiring

Figure 4.2 Typical Wiring Diagram for a Central Station Fire Alarm System NOTE: This application can also be done with the TM-4 Transmitter; refer to the TM-4 Transmitter Module manual for more details.

NOTE: APS-6R and CHG-120 do not comply with requirements for AC loss delay reporting and must be used with Central Station Protected Premises systems.

42

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

NFPA 72 Proprietary Fire Alarm Systems

Applications

4.4 NFPA 72 Proprietary Fire Alarm Systems When connected and configured as a protected premises unit with monitor and relay modules, the NFS2-3030 will automatically transmit General Alarm, General Trouble, General Supervisory, and Security signals to a listed compatible Protected Premises Receiving Unit. A simplified drawing of connections between the receiving unit and the NFS2-3030 protected premises unit is shown in Figures 4.3 and 4.4. Connect the receiving unit to the protected premises unit as shown in Section 4.3 “NFPA 72 Central or Remote Station Fire Alarm System (Protected Premises Unit)”. Install and program the Receiving unit with type codes and zone mappings shown in Figure 4.3; see the programming manual for procedures. Relay Modules

Type code: Monitor

Type code: Relay Zone mapping: Z000

Type code: Security-L

Type code: Relay Zone mapping: ZF03

Type code: Superv

Type code: Relay Zone mapping: ZF04

Receiving Unit Compatible With NFS2-3030 PRN series printer

SLC Loop (twisted-pair wiring)

3030-Rcvg-blok.cdr

Monitor Modules SLC Loop (twisted-pair wiring)

NFS2-3030 Protected Premises Unit Type code: Trouble Mon

UPS

Type code: Relay Zone mapping: ZF01 & ZF02

Note: Remote printers require 120 VAC, 50/60Hz primary power. A secondary power source (battery backup) is not provided; the use of a separate Uninterruptable Power Supply (UPS) 50 watt minimum, UL-listed for Fire Protective Signaling is recommended. A UPS is required for NFPA 72 Proprietary Protected Premises Receiving Unit Applications.

Figure 4.3 Typical Proprietary Fire Alarm Systems Wiring Connections: Block View

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

43

Applications

Fire/Security Applications

Relay Module

Monitor Module Receiving Unit SLC Loop IN

PPU SLC Loop IN ELR-47K 8

66 77 88 99 10 11 12 12 13 13 11 00 15 14 1514

7

TENS

6

55 44 3 2

5 LLOOP OOP

55 44 3 2

66 77 8 99

1 00

ONES

0

9

1 2

8 7

TENS TENS

3

6

5 44 33 22

5

4 A ADD DDR RESS ESS

LLOOP OOP

55 44 3 2

6 77 8 99 10 11 12 12 13 1 00 15 14 1514 6 7 8 99

0 1 2

3030-Rcvg-wir.cdr

9

3 1 00

4

ONES ONES

A DD R ESS

Receiving Unit SLC Loop OUT

PPU SLC Loop OUT

Figure 4.4 Typical Proprietary Fire Alarm Systems Wiring Connections: Detail View

4.5 Fire/Security Applications NOTE: The NFS2-3030 is not approved for use in security applications in Canada.

4.5.1 General Operation The NFS2-3030 can be used as a combination Fire/Security system when installed and operated according to the instructions in this section. For security applications, program one or more monitor module (listed for security applications) with the SECURITY-L, SYSTEM MONITOR, or AREA MONITOR Type Codes, and wire as shown in Figure 4.6. Activating these types of modules lights the SECURITY LED, and displays a security alarm condition on the primary display. The sounder will sound until you acknowledge the Security alarm. You can also program additional sounders or output devices to activate with the security alarm initiating device. These type codes are designed to indicate an alarm in one or more of the following situations: (a) on an open or short circuit (b) on a ±50% change in resistance value from the End-of-Line resistor value (c) on loss of communication with the device. A tamper switch installed in the cabinet door will indicate a door tamper condition whenever the door is open. If the control indicates a Security alarm, you can perform acknowledge, signal silence, and system reset from the control . Damage can result from incorrect wiring connections.

4.5.2 General Security Requirements The following security requirements must be met:

44

•

Use AMPS-24/E power supply.

•

Shielded cable must be used on all input/output wiring associated with security functions.

•

SLC Loop Shielding (refer to the SLC Wiring Manual).

•

Security Module I/O Circuit Shielding - terminate the shield at earth ground at the junction box containing the module.

•

When employed as a Protected Premises Unit, the NFS2-3030 cabinet door must be wired with an STS-1 Tamper Switch that is monitored by the control NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Fire/Security Applications

Applications

•

If the system has arming and disarming capability, a ringback signal from the Central Station to the arming location is required for Grade A operation. The ringback signal informs the Protected Premises Control that the signal to arm/disarm has been received by the Central Station.

•

A single SLC loop may be used for both Fire and Security Device Connections.

There are five software type IDs associated with security operation: ACCESS MONITOR alarm, AREA MONITOR, EQUIP MONITOR, SECURITY-L, and SYS MONITOR. There is also one software function, Security Delay (SDEL). These software elements are essential to all aspects of security operation, including Control-By-Event (CBE) programming. Devices with the type IDs ACCESS MONITOR and EQUIP MONITOR do not automatically display at the LCD or require state change acknowledgment. State changes in devices with these software types may be output at a printer. Refer to this ’s Programming manual for more information about the characteristics of software type IDs.

!

WARNING: XP Transponder circuits (XPP-1, XPM-8, XPC-8, XPR-8, XPM-8L) are not suitable for security applications.

4.5.3 Installing a Security Tamper Switch Follow the instructions below to wire the cabinet with a Security Tamper Switch kit model STS-1. 1.

Install the STS-1 Tamper Switch onto the side of the backbox opposite the door hinge, pushing the switch through the opening until it snaps into place.

2.

Install the magnet on the same side of the cabinet door as the lock. Push the magnet through the opening in the door until it snaps into place.

3.

Connect the STS-1 connector to J6 Security on the U.

4.

Program supervision for Tamper Input “Yes”.

Connect to J6 Security

3030-sts1.cdr

STS-1 mounting location (side opposite of door hinges)

Figure 4.5 Installing the STS-1 Security Tamper Switch

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

45

Applications

Fire/Security Applications

4.5.4 Receiving Unit For applications requiring transmission of security alarm information to a central receiving unit, the U may be connected to a compatible receiving unit. For information on configuring the Receiving unit for Combination Fire/Security applications, refer to the documentation for that control .

4.5.5 Programming The control can communicate with any number of security devices. To do so, program the points as follows: 1. 2.

Select the address of the module(s) to be used for security. Select one of the type codes described in Section 4.5.2 “General Security Requirements”.

For detailed instruction on programming Type Codes, refer to the Programming Manual.

4.5.6 Wiring for Proprietary Security Alarm Applications Typical wiring for proprietary security alarm applications with the FMM-1 module. Note the following: •

The module is programmed with one of five type codes (see Section 4.5.2 “General Security Requirements”).

•

Supplementary use only applies to UL-listed systems.

•

NAC devices used for security cannot be shared with fire NAC devices.

•

Refer to the Device Compatibility Document for compatible NAC devices.

•

All monitor modules used for security application must be installed in the control cabinet with STS-1 Security Tamper Switch. NFS2-3030 Protected Premises Unit UL-listed, normally-open security switch

UL-listed, normally-closed security switch FMM-1

3030-burg-FMM.wmf

47K End-of-Line Resistor

SLC Channel A or B

Figure 4.6 Wiring Diagram for Proprietary Security Alarm Applications

46

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Fire/Security Applications

Applications

4.5.7 Connecting an RKS-S Remote Key Switch The RKS-S Remote Key Switch arms and disarms the system. It can be mounted in a UL listed single-gang electrical box. Both the monitor module and RKS-S must be mounted within the protected area. Figure 4.7 and Figure 4.8, respectively, depict the connection of the FMM-101 or FMM-1 module to the RKS-S. yellow (–)

FMM-101

purple (+) red (+) RKSFMM101.wmf

SLC black (–)

RKS-S (rear)

RKS-S (front)

!

R-47K End-of-Line Resistor

WARNING: XP Transponder circuits (XPP-1, XPM-8, XPC-8, XPR-8, XPM-8L) are not suitable for security applications.

Figure 4.7 Connecting the FMM-101 Module to the RKS-S

SLC Out

9 8 7 6 5

6 7 8 910 11 12 13 1 0 1514 TENS 6 7 89 5 4 3 2 10 ONES 5 4 3 2

1 2

SLC In

3 4

ADDRESS

LOOP

RKSFMM-b.cdr

0

FMM-1

RKS-S rear R-47K End-of-Line Resistor

Figure 4.8 Connecting the FMM-1 Module to the RKS-S

4.5.8 Single Tenant Security System with Entry/Exit Delay The following system requirements are illustrated in Figure 4.9. •

One NFS2-3030 Control

•

Multiple Security Supervisory Circuits Reporting to Central Station as a Single Area

•

The minimum security equipment required is as follows: —Multiple MM Monitor Modules per Protected Area —One Group Interface for security alarm

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

47

Applications

Fire/Security Applications

—One Group Interface to generate trouble arming system — Switch for Each Entry/Exit Door —RKS-S Key Switch —MM Monitor Modules —Remote Annunciator for Each Entry/Exit Door (ACM-24AT, ACM-48A, ACM-16AT, ACM-32A) —Security Devices Key

TENANT A

Motion Detector Switch Switch with MM Module AREA 1 (Perimeter and interior)

RKS-S Remote Key Switch with MM Module MM Security Access Monitor Remote Annunciator

MM

CM

CM

Group Interface * Pull Station Smoke Detector

To Signaling Line Circuit

* Group Interface must be physically located in either the protected premises or the Central Station

NFS2-3030 Central Station

Area6_b.cdr

MM

To Central Station (via EIA-485 circuit)

Entry/Exit Door

Note: See Programming Notes for Figure 4.9.

Figure 4.9 Single Tenant Security System with Entry/Exit Delay

Programming Notes for Figure 4.9 1.

Programming of Key Switch, Access Points, and Motion Detection RKS Remote Key Switch with Monitor Module Address: LXXMYYY (arbitrary) Type ID: ACCESS MONITOR Zone Map: (none) Custom Label: Arming Switch Switches with Monitor Modules Address: LXXMYYY (arbitrary) Type ID: ACCESS MONITOR Zone Map: ZA Custom Label: Exit Door # Motion Detectors with Monitor Modules Address: LXXMYYY (arbitrary) Type ID: ACCESS MONITOR Zone Map: ZB Custom Label: Motion Detection

2. 48

Programming of Logic Equations NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Fire/Security Applications

Applications

Logic Equation for 1 minute exit delay: ZLa* = DEL(01:00, 00:00, address of key switch) Logic Equation for Trouble arming system: ZLb* = AND (ZA, address of key switch, NOT(Zla)) Logic Equation to arm system: ZLc* = AND (ZLa, NOT(ZLb)) Logic Equation providing 30-second entry delay: ZLd* = SDEL(00:30, 00:30, ZA) Logic Equation for Security Alarm: ZLe* = AND (ZLc, OR (ZLd)) *Follow the following restrictions on values: a < b < c < d <e 3.

Programming Group Interfaces MM CM

Group Interface for Trouble when system is armed while access point(s) active A. CM programming Address: LXXMYYY (arbitrary) Type ID: RELAY Zone Map: ZLb Custom Label: Arming Trouble Group Output Signal Silence: No Walk Test: Yes/No (Installer Specified) Switch Inhibit: Yes B. MM Programming Address: LXXMYYY (arbitrary) Type ID: TROUBLE MON Zone Map: (none) Group Interface for Security Alarm A. CM programming Address: LXXMYYY (arbitrary) Type ID: RELAY Zone Map: ZLe Custom Label: Security Group Output Signal Silence: No Walk Test: Yes/No (Installer Specified) Switch Inhibit: Yes B. MM Programming Address: LXXMYYY (arbitrary) Type ID: SECURITY-L Zone Map: (none)

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

49

Applications

Releasing Applications

4.5.9 Security Annunciation Monitor ZLc

A1P2 Mode: Source:

Monitor ZLe

A1P3 Mode: Source:

Monitor LXXMYY

A1P4 Mode: Source:

Monitor LXXMYY

System Status (red is armed) System Alarm (red is alarm) Entry/Exit Door 1 Status (red is unsecured) Entry/Exit Door 2 Status (red is unsecured)

Additional doors can be monitored, up to the number of available annunciator points.

acm-24atface.cdr

A1P1 Mode: Source:

Figure 4.10 Sample Annunciator Display

4.6 Releasing Applications 4.6.1 Overview This control can be used for non-hazardous agent release or preaction/deluge control applications via the SLC loop. In a properly configured system with compatible, listed actuating and initiating devices, this control complies with the following NFPA standards for installation in accordance with the acceptable standard: Standard

Covers

NFPA 13

Sprinkler Systems

NFPA 15

Water Spray Systems

NFPA 16

Foam-Water Deluge and Foam-water Spray Systems

NFPA 17

Dry Chemical Extinguishing Systems

NFPA 17A

Wet Chemical Extinguishing Systems

NFPA 2001

Clean Agent Fire Extinguishing Systems

Table 4.1 NFPA Standards for Releasing Applications Refer to installation documents for the individual SLC loop device for voltage and maximum current requirements.

4.6.2 Programming The control s up to ten releasing software zones. You can map these zones to activate control modules. Program control module FCM-1 for the appropriate Type Code according to the chart below: Type Code: RELEASE CKT • For use in UL applications • Do not use REL-47K • Cannot use power-limited wiring • Supervised for open circuit only • Supervised for power loss

Type Code: REL CKT ULC • For use in UL or ULC applications • Requires REL-47K at solenoid • Power-limited wiring • Supervised for open circuit and shorts • Supervised for power loss

For more information, refer to the NFS2-3030 Programming Manual. 50

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Connecting a Releasing Device to FCM-1 Control Modules

Applications

4.6.3 Wiring Make sure to keep total system current within the limits of the power supply. You can power the module from the power supply of the control or any UL-listed 24 VDC regulated power-limited power supply for Fire Protective Signaling. For more information, refer to the Device Compatibility Document. References to wiring diagrams for releasing applications: •

To connect a releasing device to control module FCM-1, refer to Section 4.7.

•

To connect an NBG-12LRA Agent Release-Abort Station, refer to Section 4.8.

4.7 Connecting a Releasing Device to FCM-1 Control Modules Typical Connections Figure 4.11 shows typical connections for wiring a releasing device to this module. For ULC applications, REL-47K is required; see chart in Circuit Requirements below. SLC from FA or LCM/LEM – +

Non-resettable 24 VDC Power Brown

– +

Red REL-47K

(Use with Type Code Rel Ckt ULC, or see Circuit Requirement 3.)

FCM-1

Relconn-controlmod.wmf

UL-listed 24 VDC releasing device

Note: See Circuit Requirements below. Devices for use in releasing applications must be programmed as type code RELEASE CIRCUIT or REL CKT ULC.

Figure 4.11 Typical Connection of a 24 VDC Releasing Device to the FCM-1 Control Module Circuit Requirements When connecting releasing devices to FCM-1 control modules, note the following: 1.

For NFPA 13 and 15 applications, disable the Soak Timer (Soak=0000); for NFPA 16 applications, set the Soak Timer (0600-0900 seconds). Refer to the NFS2-3030 Programming Manual for instructions on setting the Soak Timer.

2.

For applications using power-limited circuits: a) Use an End-of-Line device (P/N REL-47K) with FCM-1 modules. Connect the End-of-Line device as shown in Figure 4.11. b) All wiring for releasing circuits is supervised against open and shorts. c) Program the releasing circuit for Type Code REL CKT ULC.

3.

For applications not requiring power-limited circuits: a) End-of-Line devices (P/N REL-47K) are not required; however, the releasing device circuit is not supervised against shorts. b) Limited energy cable cannot be used for wiring of a releasing device circuit. c) Maintain a 0.25 inch (6.35 mm) spacing between the releasing circuit device wiring and any power-limited circuit wiring. d) In non-power-limited applications, program the releasing circuit for Type Code RELEASE CKT.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

51

Applications

Connecting an NBG-12LRA Agent Release-Abort Station

4.8 Connecting an NBG-12LRA Agent Release-Abort Station Typical Connections Figure 4.12 shows typical connections for wiring an NBG-12LRA Agent Release-Abort Station. Yellow

Black

FMM-101

–

–

Manual Abort

+

+

Violet

Yellow

ELR mode R-47K supervised and power-limited

Release

+

+

3030-NBG12LRA.wmf

Red

Non-resettable +24 VDC from AMPS-24/E

FRM-1 C. System Common (–)

N.C.

1

6

2

5

4

– + N.O.

0 7-

24 VDC UL-listed releasing device Brown

REL-47K (use with Type Code “Rel Ckt ULC”)

6+

– + 3 – 4 + 1

FCM-1 Red

SLC loop to FA’s LCM-320 or + LEM-320

Black

FMM-101

– Violet Normal

Red

–

Manual Release

–

NBG-12LRA See Document 51369 for installation details.

2

24 VDC power from FA’s main power supply

– +

NOTE: See Circuit Requirements for Section 4.7, “Connecting a Releasing Device to FCM-1 Control Modules”, on page 51.

NOTE: Devices for use in releasing applications must be programmed as type code RELEASE CIRCUIT or REL CKT ULC.

52

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Section 5: Testing the System 5.1 Acceptance Test When finished with the original installation and all modifications, conduct a complete operational test on the entire installation to compliance with applicable NFPA standards. Testing should be conducted by a factory-trained fire alarm technician in the presence of a representative of the Authority Having Jurisdiction and the owner's representative. Follow procedures outlined in NFPA Standard 72’s section Inspection, Testing and Maintenance.

5.2 Periodic Testing and Service Periodic testing and servicing of the control , all initiating and notification devices, and any other associated equipment is essential to ensure proper and reliable operation. Test and service the control according to the schedules and procedures outlined in the following documents: •

NFPA Standard 72, Inspection, Testing and Maintenance.

•

Service manuals and instructions for the peripheral devices installed in your system. Correct any trouble condition or malfunction immediately.

5.3 Operational Checks Between formal periodic testing and servicing intervals, the following operation checks should be performed monthly, or more frequently when required by the Authority Having Jurisdiction. ‰

!

Disconnect all releasing devices to prevent accidental activation.

WARNING: Releasing devices should be physically disconnected. Do not use software disable functions in the as lockout. ‰

Check that the green POWER LED lights.

‰

Check that all status LEDs are off.

‰

Press and hold the LAMP TEST key. that all LEDs and all LCD display segments work.

‰

Before proceeding: a) notify the fire department and the central alarm receiving station if transmitting alarm conditions; b) notify facility personnel of the test so that alarm sounding devices are disregarded during the test period; and c) when necessary, disable activation of alarm notification appliances and speakers to prevent their sounding.

‰

Activate an Initiating Device Circuit using an alarm initiating device or an addressable initiating device on the SLC and check that all programmed active notification appliances function. Reset the alarm initiating device, the control , and any other associated equipment. In voice alarm applications, confirm that the proper tone(s) and/or messages sound during alarm conditions. Select the paging function and confirm that the message can be heard in the affected fire zones. Repeat the above step with each Initiating Device Circuit and each addressable device.

NOTE: SLC Resistance Values: The total DC resistance of the SLC pair cannot exceed 50 ohms. For instructions on how to measure the total DC resistance of a populated SLC pair, refer to the “Measuring Loop Resistance” section of the SLC Wiring Manual (P/N 51253)The minimum DC resistance between conductors of an unpopulated SLC pair cannot be less than 1 K ohms. Measure DC resistance on an unpopulated loop as shown in Figure 5.1 on page 54. ‰

Zero Ohms to ground will cause a ground fault. continued…

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

53

Testing the System

Battery Checks and Maintenance ‰

‰

On systems equipped with a firefighter’s telephone circuit, make a call from a telephone circuit and confirm a ring indication. Answer the call and confirm communication with the incoming caller. End the call and repeat for each telephone circuit in the system. Remove AC power, activate an Initiating Device Circuit through an alarm initiating device or an addressable initiating device on the SLC, and check that programmed active notification appliances sound, and alarm indicators illuminate. Measure the battery voltage with notification appliances active. Replace any battery with a terminal voltage less than 21.6 VDC and reapply AC Power.

NOTE: The battery test requires fully charged batteries. If batteries are new or discharged due to a recent power outage, allow the batteries to charge for 48 hours before testing. ‰ ‰ ‰

Return all circuits to their pretest condition. Check that all status LEDs are off and the green POWER LED is on. Notify fire, central station and/or building personnel when you finish testing the system. Step 1. Disconnect the SLC channel B (Out) and SLC channel A (Return) at the control . Step 2. Measure and record the resistance at SLC Out. Step 3. Measure and record the resistance at SLC Return. The minimum resistance is the lesser of two and three.

STEP 2

STEP 3 SLC Out

SLC-meas5.cdr

SLC Out

SLC Return SLC Return

Figure 5.1 Measuring DC Resistance on an Unpopulated SLC Loop

5.4 Battery Checks and Maintenance Maintenance-free sealed lead-acid batteries used in the system do not require the addition of water or electrolyte. These batteries are charged and maintained in a fully charged state by the main power supply's float charger during normal system operation. A discharged battery typically charges at 1.5–1.8 A and reaches the float voltage of 27.6 VDC within 48 hours. Follow the local AHJ and manufacturer recommendations for battery replacement intervals. Minimal replacement battery capacity appears on the control marking label. Immediately replace a leaking or damaged battery. You can get replacement batteries from the manufacturer.

!

WARNING: Batteries contain Sulfuric Acid, which can cause severe burns to the skin and eyes and damage to fabrics.

•

• • •

! 54

If a battery leaks and is made with the Sulfuric Acid, immediately flush skin and/or eyes with water for at least 15 minutes. Water and household baking soda provides a good neutralizing solution for Sulfuric Acid. If Sulfuric Acid gets into eyes, seek immediate medical attention. Ensure proper handling of the battery to prevent short circuits. Take care to avoid accidental shorting of the leads from uninsulated work benches, tools, bracelets, rings, and coins.

CAUTION: Shorting the battery leads can damage the battery, equipment, and could cause injury to personnel. NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Appendix A: Electrical Specifications A.1 Operating Power DC Power The control requires connection to AMPS-24, which is a +24 VDC regulated, powerlimited power supply, UL/ULC-listed for fire protective service, that can supply 0.1 amps continuous for U2-3030ND (0.3 amps for U2-3030D). For complete battery/current draw calculations, refer to the main power supply manual; if using an auxiliary power supply, there may be additional calculations in that manual.

A.2 SLC Loops Listed below are specifications for a Signaling Line Circuit loop. Refer to the SLC Wiring Manual for more detailed specifications and specific device listings. : Item

Value

Voltage

24 VDC nominal, 27.6 VDC maximum

Maximum length

The maximum wiring distance of an SLC using 12 AWG (3.25 mm2) twisted-pair wire is 12,500 ft. (3810 m) per channel. Note: Refer to Appendix A.4 “Wire Requirements” for limitations.

Maximum current

130 mA: LCM-320 100 mA: LEM-320 400 mA max*: Single SLC loop *Max short circuit…circuit will shut down until short circuit condition is corrected.

Maximum resistance

50 ohms (supervised and power-limited). For additional notes on SLC resistance values, see Section 5.3 “Operational Checks”.

A.3 Notification Appliance Circuits The FS-24S6 and FS-24S8 power supplies provide Notification Appliance Circuits. Refer to the FS-24S6/S8 manual for product-specific specifications. Refer to the Device Compatibility Document for compatible devices and notification appliances. Refer to the FS-24S6/FS-24S8 Manual for complete details about this power supply.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

55

Electrical Specifications

Wire Requirements

A.4 Wire Requirements Each type of circuit within the Fire Alarm Control System requires use of a specific wire type to ensure proper circuit operation. The wire gauge of a particular circuit depends on the length of that circuit and the current traveling through it. Use the table below to determine the specific wiring requirements for each circuit. Compliance with the Federal Communications Commission (FCC) and Canadian Department of Communication regulations on electrical energy radiation requires the following: Use twisted-pair shielded wire for any non-SLC-loop wiring entering or exiting the cabinet that is not enclosed in conduit. Use twisted-pair unshielded wiring for SLC-loop wiring. NOTE: If running an SLC in conduit with Notification Appliance Circuits, you can reduce problems by exclusively using electronic sounders (such as the MA/SS-24 Series) instead of more electronically noisy notification appliances (such as electromechanical bells or horns).

Distance (feet/meters)

Typical Wire Type*

Twisted-unshielded pair, 12 to 18 AWG (3.25 to 0.75mm2). 50 ohms, maximum per length of Style 6 & 7 loops. 50 ohms per branch maximum for Style 4 loop.

12,500 ft (3,810 m) 9,500 ft. (2,895.6 m) 6,000 ft. (1,828.8 m) 3,700 ft. (1,127.76 m)

12 AWG 14 AWG 16 AWG 18 AWG

or

Twisted-shielded pair.

10,000 ft (3048 m)

12 AWG

or

Untwisted, unshielded wire, in conduit or outside of conduit.

1,000 ft (304.8 m)

12 to 18 AWG

EIA-485 ACS Connection (power limited)

Connects to ACS devices such as annunciators and UDACT

Twisted-shielded pair with a characteristic impedance of 120 ohms. 18 AWG (0.75mm2) minimum.

6,000 ft (1829 m) (max)

16 AWG/1.30mm2

EIA-485 RDP Connection (power limited)

Connects to RDP devices such as LCD-160

Twisted-shielded pair with a characteristic impedance of 120 ohms. 18 AWG (0.75mm2) minimum.

4,000 ft (1219 m) (max)

16 AWG/1.30mm2

EIA-232 (power limited)

Connects to Printers or PC.

Twisted-shielded pair. 18 AWG (0.75mm2) minimum.

50 ft (15.24 m) without modem

16 AWG/1.30mm2

IDC Initiating Device Circuit

FMM-1, FMM-101 (power limited)

12-18 AWG Maximum circuit resistance is 20 ohms.

NAC Notification Appliance Circuit

FCM-1 (power limited)

12-18 AWG. MPS-24A: At alarm current level, no more than a 1.2 V drop at the end of the circuit, or sized to provide the minimum rated operating voltage of the appliances used.

To meet 1.2 V drop, or sized to provide the minimum rated operating voltage of the appliances used.

12 to 18 AWG (3.25 to 0.75mm2)

24 VDC Power Runs (power-limited)

To TM-4 Transmitter, Annunciator and FCM-1 modules

12-18 AWG. Size wire so that no more than 1.2 V drop across wire run from supply source to end of any branch.

To meet 1.2 volt drop

12 to 18 AWG (3.25 to 0.75mm2)

CHG-120

External battery charger

12 AWG in conduit

20 ft (6.1 m) maximum

12 AWG (3.25mm2)

Circuit Type

Circuit Function

Wire Requirements

SLC (power limited)

Connects to intelligent and addressable modules.

12 to 18 AWG (3.25 to 0.75mm2)

Table A.1 Wire Requirements *

Notifier brand cable is recommended; see the product catalog available from Paige Electric.

Relay Output circuits are “Common” 30VDC, 2A (see Section 3.9 “Form-C Relays on the U”). Power output circuits: TB6 on the U draws power from primary, secondary and external sources to +24 VDC power to devices within the same enclosure as the U. If those devices have outputs, the outputs must be power-limited. Power rating is determined by the power source(s). See Section 3.10.1 “Overview”, and the AMPS-24 Manual for more details. 56

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Appendix B: Canadian Applications B.1 Standalone Application U2-3030D, with its integral keypad/display, meets Canadian requirements for standalone applications. Its 640-character, multi-line display complies with ULC requirements for primary displays.

B.2 Local Network Application To meet ULC requirements, the network’s Manual Controls may only be operated from one location at any given time. When s are networked (using NCM Network Control Modules), employ AKS-1 Key Switch on each ’s Primary Annunciator to enable its functions. NCA-2 may be a Primary Annunciator when AKS-1 is installed. Refer to the NCA-2 Manual (P/N 52482) for more information. NOTE: Only one key should be issued for a networked system.

The NCA-2 or Network Control Station (NCS) may be employed as a Display and Control Center. In the event that communication fails between the s and the Control Center, the s will continue to function in local/standalone mode.

B.3 Automatic Alarm Signal Silence If selecting this feature for a system requiring annunciators, consult the Authority Having Jurisdiction.

B.4 Annunciator Applications 1.

In Canada, the ACM series annunciator modules must be used to annunciate the fire alarm input points/zones only, if no multi-line sequential display is installed.

2.

For Canadian applications, the following LED colors must be employed: – Red must be used to indicate active alarm inputs. – Yellow must be used to indicate supervisory, burglary or trouble signals. – Green must be used to indicate the presence of power or an activated output.

B.5 Releasing Devices Supervision for shorts is required; use REL-47K and type code Rel Ckt ULC. Refer to Section 4.6 “Releasing Applications”.

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

57

Notes

58

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Notes

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

59

Notes

60

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Index A

E

AC power, see your power supply manual 34 acceptance test 53 ACM-8R 35 ADP-4B 15 Agent Release-Abort Station 52 alarm relays see relays 32

electrical connections 33 electrical specifications 55 External Power Supervision 41

B backboxes 12, 15 mounting 20 battery battery calculations also see the manual for your main power supply 55 battery checks 54 memory-backup battery 25 blank modules 12, 15 BMP-1 15, 21 BP2-4 15

C CAB-4 series enclosures, see also backboxes 15 cabinets 15, 21 see also backboxes or doors 12 Canadian applications 57 central receiving unit, also see UDACT manual 46 chassis CHS-4L 15 CHS-4MB 15 CHS-4N, see CHS-4MB 15 CHS-M3 15, 21, 31 circuit board, see U 13 compatible equipment 16, 17 control circuit board, see U 13 U 12, 13 drawing 13 installation steps 23

D DC also see power 34 Display and Control Center (DCC) see Programming Manual doors 12, 15 DP-1B 15 DP-DISP 15 dress s 12, 15

F FCM-1 51 FS-24S6/S8 55 fire/security applications 44 FMM-1 46 Form-C relays see relays 32

I indicating device circuits, see NACs 55 installation checklist 19 preparation 19 insulator for memory-backup battery 25

K Keltron printer, see printers 38

L LCM-320/LEM-320, see SLC Loop Modules LDM-R32 35

M main power supply 14 maintenance 53, 54 manual pull station 39 mounting backboxes and doors 20 MP-1B 15

N NACs specifications 55 NBG-12LRA 52 NCM-W/F mounting 27 networking 27 NFPA applications NFPA 72 Central or Remote Station Fire Alarm System 42 overview 41

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Protected Premises Unit 42 nonpower-limited circuits UL wiring requirements 35 notification appliance circuits, see NACs 55

O operating power 55 operational checks 53 output relays see also Form-C relays 32 specifications 32 output relays see relays 32

P PC connection 40 periodic testing 53 power 34 AC power checklist 34 AC power connections also see your power supply manual 34 auxiliary power 34 DC power connections 34 installation steps 33 main power supply 14 power supply calculations, see also the manual for your main power supply 55 power-limited wiring requirements 35 specifications 33 PPU 42 printers 37, 38 installation 36 PRN printer settings 38 Proprietary Fire Alarm Systems 43 proprietary security alarm applications see also security 46 Protected Premises Receiving Unit 43

R receiving unit 43 related documentation 8 relays 32 releasing 50 FCM-1 connections 51 NBG-12LRA 52 remote connection feature 35 61

S–W

S security proprietary security alarm applications wiring 46 security relays see relays 32 security tamper switch 45 service 53 Signalling Line Circuit, see SLC see also SLC Wiring Manual 39 SLC see also SLC Wiring Manual 39 specifications 55 SLC Loop Modules external power supervision 41 SLC loop number 29 SLC loop number for SLC Loop Modules 29 specifications 55 STS-1, see also security 46 Supervisory and Security s configuring as Alarm s 32 supervisory relays see relays 32 supplemental documentation 8 system features 11 limitations 12 options 11 system description 11 system current draws also see the manual for your main power supply 55

Index

plications 46 see also SLC Wiring Manual 39 see SLC 39 UL nonpower-limited wiring requirements 35 wire requirements 56

T testing 53 TM-4 35 trouble relays see relays 32

U UDACT 36, 42 UL nonpower-limited wiring requirements 35 UL requirements 35 ULC remote connection feature 35 / software 40

V VeriFire™ Tools 40

W wiring nonpower-limited wiring requirements 35 proprietary security alarm ap62

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

Limited Warranty NOTIFIER® warrants products manufactured by it to be free from defects in materials and workmanship for eighteen (18) months from the date of manufacture, under normal use and service. Products are date stamped at time of manufacture. The sole and exclusive obligation of NOTIFIER® is to repair or replace, at its option, free of charge for parts and labor, any part that is defective in materials or workmanship under normal use and service. All returns for credit are subject to inspection and testing at the factory before actual determination is made to allow credit. NOTIFIER® does not warrant products not manufactured by it, but assigns to the purchaser any warranty extended by the manufacturer of such products. This warranty is void if the product is altered or repaired by anyone other than NOTIFIER® or as expressly authorized by NOTIFIER® in writing, or is serviced by anyone other than NOTIFIER® or its authorized distributors. This warranty is also void if there is a failure to maintain the products and systems in which they operate in a proper and workable manner. In case of defect, secure a Return Material Authorization form from our Return Authorization Department. This writing constitutes the only warranty made by NOTIFIER®, with respect to its products. NOTIFIER®, does not represent that its products will prevent any loss by fire or otherwise, or that its products will in all cases provide the protection for which they are installed or intended. Buyer acknowledges that NOTIFIER®, is not an insurer and assumes no risk for loss or damages or the cost of any inconvenience, transportation damage, misuse, abuse, accident or similar incident. NOTIFIER® GIVES NO WARRANTY, EXPRESS OR IMPLIED, OF MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE, OR OTHERWISE WHICH EXTENDS BEYOND THE DESCRIPTION ON THE FACE HEREOF. UNDER NO CIRCUMSTANCES SHALL NOTIFIER® BE LIABLE FOR ANY LOSS OF OR DAMAGE TO PROPERTY, DIRECT, INCIDENTAL OR CONSEQUENTIAL, ARISING OUT OF THE USE OF, OR INABILITY TO USE NOTIFIER®’S PRODUCTS. FURTHERMORE, NOTIFIER® SHALL NOT BE LIABLE FOR ANY PERSONAL INJURY OR DEATH WHICH MAY ARISE IN THE COURSE OF, OR AS A RESULT OF, PERSONAL, COMMERCIAL OR INDUSTRIAL USE OF ITS PRODUCTS. This warranty replaces all previous warranties and is the only warranty made by NOTIFIER®. No increase or alteration, written or verbal, of the obligation of this warranty is authorized. "NOTIFIER" is a ed trademark. Warn-NL-04-2005.fm

NFS2-3030 Installation Manual — P/N 52544:A 11/29/2005

63

World Headquarters 12 Clintonville Road Northford, CT 06472-1653 USA 203-484-7161 fax 203-484-7118 www.notifier.com

NOTIFIER is a Honeywell company.
