Yamaha Receiver Htr-4066 Owner's Manual 702s19

AV Receiver

Owner’s Manual Read the supplied booklet “Safety Brochure” before using the unit.

English

CONTENTS Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

7 Connecting recording devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 8 Connecting the power cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

FEATURES

5

9 Selecting an on-screen menu language . . . . . . . . . . . . . . . . . . . . . . . . . 30 10 Optimizing the speaker settings automatically (YPAO) . . . . . . . . . 31

What you can do with the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Part names and functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Front display (indicators) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

PLAYBACK

35

Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Basic playback procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

PREPARATIONS

11

Selecting the input source and favorite settings with one touch (SCENE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

General setup procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 1 Placing speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Configuring scene assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Selecting the sound mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Enjoying sound field effects (CINEMA DSP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

2 Connecting speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Enjoying unprocessed playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

5.1-channel system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Enjoying pure high fidelity sound (direct playback) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

7.1-channel system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Enjoying compressed music with enhanced sound (Compressed Music Enhancer) . . . . . . . . . . . . . . . . . . . 42

Connecting front speakers that bi-amp connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Enjoying surround sound with headphones (SILENT CINEMA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Connecting Zone B speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Listening to FM/AM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Input/output jacks and cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Setting the frequency steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

3 Connecting a TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Selecting a frequency for reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 ing favorite radio stations (presets) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

4 Connecting playback devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Radio Data System tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Connecting video devices (such as BD/DVD players) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Playing back iPod music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Connecting audio devices (such as CD players) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Connecting an iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Connecting to the jacks on the front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Playback of iPod content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

5 Connecting the FM/AM antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Playing back music stored on a USB storage device . . . . . . . . . . . . . . . 51

6 Connecting to a network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Connecting a USB storage device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Playback of USB storage device contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 En

2

Playing back music stored on media servers (PCs/NAS) . . . . . . . . . . . . 54

Controlling external devices with the remote control . . . . . . . . . . . . . 85

Media sharing setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

ing the remote control code for a TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Playback of PC music contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

ing the remote control codes for playback devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Listening to Internet radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Playing back iTunes/iPod music via a network (AirPlay) . . . . . . . . . . . 59

Resetting remote control codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Updating the unit’s firmware via the network . . . . . . . . . . . . . . . . . . . . 88

Playback of iTunes/iPod music contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Playing back music in multiple rooms (HTR-5066 only) . . . . . . . . . . . . 61

APPENDIX

89

Preparing Zone B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Viewing the current status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 Switching information on the front display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Configuring playback settings for different playback sources

Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90 Power, system and remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

(Option menu) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Option menu items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94 FM/AM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

CONFIGURATIONS

68

Configuring various functions (Setup menu) . . . . . . . . . . . . . . . . . . . . . . 68 Setup menu items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69 Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74 Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

USB and network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Error indications on the front display . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96 Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97 Audio information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97 HDMI and video information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98 Yamaha technologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99 Video signal flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100

ECO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Information on HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

HDMI Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100

Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

HDMI signal compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102

Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Reference diagram (rear ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Configuring the system settings (ADVANCED SETUP menu) . . . . . . . . 83 ADVANCED SETUP menu items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83 Changing the speaker impedance setting (SP IMP.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83 Selecting the remote control ID (REMOTE ID) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83 Changing the FM/AM tuning frequency setting (TU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105 Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Switching the video signal type (TV FORMAT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84 Restoring the default settings (INIT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84 Updating the firmware (UPDATE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84 Checking the firmware version (VERSION) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84 En

3

Accessories

Operating range of the remote control

Check that the following accessories are supplied with the product.

• Point the remote control at the remote control sensor on the unit and remain within the operating range shown below.

… Remote control

… Batteries (AAA, R03, UM-4) (x2)

Within 6 m (20 ft) 30°

30°

Insert the batteries the right way round.

… AM antenna

… FM antenna

*One of the above is supplied depending on the region of purchase.

… YPAO microphone

… CD-ROM (Owner’s Manual) • The illustrations of the main unit and remote control used in this manual are of the HTR-5066 (U.S.A. model), unless otherwise specified.

• Some features are not available in certain regions. • Due to product improvements, specifications and appearance are subject to change without notice. • This manual explains operations using the supplied remote control.

… Easy Setup Guide

… Safety Brochure

• This manual describes all the “iPod”, “iPhone” and “iPad” as the “iPod”. “iPod” refers to “iPod”, “iPhone” and “iPad”, unless otherwise specified. •

indicates precautions for use of the unit and its feature limitations.

•

indicates supplementary explanations for better use.

Accessories

En

4

FEATURES What you can do with the unit Wide variety of ed content • iPod/iPhone/iPad

. p.47

• USB

. p.51

• Media server (PC/NAS)

. p.54

• Internet radio

. p.57

• AirPlay

. p.59

s 2- to 5.1-channel (to 7.1-channel*) speaker system. Allows you to enjoy your favorite acoustic spaces in various styles. • Automatically optimizing the speaker . p.31 settings to suit your room (YPAO) • Reproducing stereo or multichannel sounds with the sound fields like actual movie theaters and concert halls (CINEMA DSP)

*

*

. p.38

• Enjoying compressed music with . p.42 enhanced sound (Compressed Music Enhancer) • Playing back music in multiple rooms . p.61 (Zone B)*

Network contents

* HTR-5066 only

Speakers Audio

iPod/iPhone/iPad

Audio HDMI Control

USB device

3D and 4K signals ed

Audio HDMI Control Audio/Video

BD/DVD player

Audio/Video

TV

AV receiver (the unit)

Control

Audio/Video (via HDMI or MHL) Smartphone/Tablet

Change the input source and favorite settings with one touch (SCENE)

. p.36

Sequential operation of a TV, AV receiver, and BD/DVD player (HDMI Control) TV remote control

. p.100

FEATURES ➤ What you can do with the unit

En

5

Full of useful functions!

Useful tips

❑ Connecting various devices (p.23)

❑ Creating 3-dimensional sound fields (p.38)

A number of HDMI jacks and various input/output jacks on the unit allow you to connect video devices (such as BD/DVD players), audio devices (such as CD players), game consoles, camcorders, and other devices.

The Virtual Presence Speaker (VPS) function allows you to create a 3-dimensional sound field in your own room (CINEMA DSP 3D).

The combination of video/audio input jacks does not match an external device... Use “Audio In” in the “Option” menu to change the combination of video/audio input jacks so that it matches the output jack(s) of your external device (p.25). Video and audio are not synchronized... Use “Lipsync” in the “Setup” menu to adjust the delay between video and audio output (p.76).

BD/DVD player

I want to hear audio from the TV speakers... Use “Audio Output” in the “Setup” menu to select the output destination of signals input into the unit (p.74). Your TV speakers may be selected as an output destination.

Set-top box

Game console

Camcorder

I want to use the supplied remote control to operate external devices…

TV

the remote control codes of the external devices (such as a TV and BD/DVD players) (p.85).

❑ Playing back TV audio in surround sound with a single HDMI cable connection (Audio Return Channel: ARC) (p.18) When using an ARC -compatible TV, you only need one HDMI cable to enable video output to the TV, audio input from the TV, and the transmission of HDMI Control signals. HDMI Control TV audio

Video from external device

❑ Easy operation and wireless music playback from iPhone or Android device By using the application for smartphone/tablet “AV CONTROLLER”, you can control the unit from an iPhone, iPad, iPod touch or Android devices. Visit our website for details.

❑ Listening to FM/AM radio (p.43) The unit is equipped with a built-in FM/AM tuner. You can up to 40 favorite radio stations as presets.

❑ Enjoying pure high fidelity sound (p.41) When the direct playback mode is enabled, the unit plays back the selected source with the least circuitry, which lets you to enjoy Hi-Fi sound quality.

❑ Easy operation with a TV screen

I want to change the on-screen menu language... Use “Language” in the “Setup” menu to select a language from English, Japanese, French, German, Spanish, Russian, Italian and Chinese (p.30). I want to update the firmware... Use “Network Update” (p.88) in the “Setup” menu or “UPDATE” (p.84) in the “ADVANCED SETUP” menu to update the unit’s firmware. Many other settings are available that let you to customize the unit. For details, see the following pages.

You can operate the iPod or USB storage device, view information, or easily configure the settings using the on-screen menu.

• SCENE settings (p.36)

❑ Low power consumption

• Various function settings (p.69)

The ECO mode (power saving function) reduces the unit’s power consumption and helps to create an eco-friendly home theater system (p.78).

• System settings (p.83)

• Sound/video settings and signal information for each source (p.64)

FEATURES ➤ What you can do with the unit

En

6

Part names and functions Front 1

2

3

4

5 6

7

8

9

:

A

YPAO MIC

DIRECT

INFO

MEMORY

PRESET

FM

AM

TUNING

VOLUME SCENE

BD DVD

PHONES

INPUT

TV

TONE CONTROL

NET

PROGRAM

RADIO

STRAIGHT

SILENT CINEMA

B 1 z (power) key Turns on/off (standby) the unit.

2 Standby indicator Lights up when the unit is in standby mode under any of the following conditions. • HDMI Control is enabled (p.74) • Standby Through is enabled (p.74) • Network Standby is enabled (p.81) • An iPod is being charged (p.47)

3 YPAO MIC jack For connecting the supplied YPAO microphone (p.31).

4 Remote control sensor Receives remote control signals (p.4).

5 INFO key Selects the information displayed on the front display (p.63).

6 MEMORY key s FM/AM radio stations as preset stations (p.44).

VIDEO AUX

VIDEO

AUDIO

C

D E F

G

H

5V

2.1A

I

7 PRESET keys Select a preset FM/AM radio station (p.45).

8 FM and AM keys Switch between FM and AM (p.43).

9 TUNING keys Select the radio frequency (p.43).

0 Front display Displays information (p.8).

A DIRECT key Enables/disables the direct playback mode (p.41).

B PHONES jack For connecting headphones.

C INPUT keys Select an input source.

D TONE CONTROL key

J E SCENE keys Select the ed input source and sound program with one touch. Also, turns on the unit when it is in standby mode (p.36).

F PROGRAM keys Select a sound program or a surround decoder (p.37).

G STRAIGHT key Enables/disables the straight decode mode (p.40).

H VIDEO AUX jacks For connecting devices, such as camcorders and game consoles (p.26).

I USB jack For connecting a USB storage device (p.51) or an iPod (p.47).

J VOLUME knob Adjusts the volume.

Adjusts the high-frequency range and low-frequency range of output sounds (p.65).

FEATURES ➤

Part names and functions

En

7

Front display (indicators)

1

2

3

4

5

ENHANCER ADAPTIVE DRC STEREO 3 TUNED

OUT

6

7

8

SLEEP SP A SP B

9

VOL. MUTE SW C

L R SL SR SBL SB SBR

:

1 HDMI Lights up when HDMI signals are being input or output.

OUT Lights up when HDMI signals are being output.

2 CINEMA DSP Lights up when CINEMA DSP (p.38) is working.

CINEMA DSP n Lights up when CINEMA DSP 3D (p.40) is working.

3 ENHANCER Lights up when Compressed Music Enhancer (p.42) is working.

4 ADAPTIVE DRC Lights up when Adaptive DRC (p.65) is working.

5 STEREO Lights up when the unit is receiving a stereo FM radio signal.

A

6 ZONE indicators (HTR-5066 only) “SP A” lights up when the Zone A speaker output is enabled and “SP B” lights up when the Zone B speaker output is enabled (p.62).

7 SLEEP Lights up when the sleep timer is on.

8 MUTE Blinks when audio is muted.

9 Volume indicator Indicates the current volume.

0 Cursor indicators Indicate the remote control cursor keys currently operational.

>

B

B Speaker indicators Indicate speaker terminals from which signals are output. L Subwoofer A Front speaker (L) S Front speaker (R) D Center speaker F Surround speaker (L) G Surround speaker (R) H Surround back speaker (L)* J Surround back speaker (R)* K Surround back speaker* * HTR-5066 only

A Information display Displays the current status (such as input name and sound mode name). You can switch the information by pressing INFO (p.63).

TUNED Lights up when the unit is receiving an FM/AM radio station signal.

FEATURES ➤


En

8

Rear 1

3

2

4

5

6

7 (HTR-5066 U.S.A. model)

HDMI 1

HDMI OUT

HDMI 2

HDMI 3

HDMI 4

HDMI 5 MHL 5V 1A

(BD/DVD)

NETWORK (NET)

ARC

DC OUT 5V 0.5A

ANTENNA AM

(RADIO) FM

COMPONENT VIDEO

PR

PR

PB

PB

SPEAKERS FRONT

CENTER

SURROUND

SURROUND BACK/BI AMP /ZONE B SINGLE

Y COMPONENT VIDEO

Y VIDEO

MONITOR OUT 1

OPTICAL

COAXIAL

COAXIAL

OPTICAL

AV 1

AV 2

AV 3

AV 4

( TV )

AV 5

AV 6

8

AV OUT

AUDIO

2 SUBWOOFER PRE OUT

9 : A B

1 HDMI OUT jack For connecting to an HDMI-compatible TV and outputting video/audio signals (p.18). When using ARC, TV audio signal can also be input through the HDMI OUT jack.

2 HDMI 1–4 jacks For connecting to HDMI-compatible playback devices and inputting video/audio signals (p.23).

3 HDMI 5/MHL jack For connecting to an HDMI- or MHL-compatible playback device and inputting video/audio signals (p.23).

4 ANTENNA jacks For connecting to FM and AM antennas (p.27).

5 NETWORK jack For connecting to a network (p.28).

6 DC OUT jack For supplying power to a Yamaha AV accessory. For details on connections, refer to the instruction manual of the AV accessory.

C 7 Power cable For connecting to an AC wall outlet (p.29).

8 AV 1–6 jacks For connecting to video/audio playback devices and inputting video/audio signals (p.23).

9 AV OUT jacks For outputting video/audio to a recording device (such as a VCR) (p.29).

0 AUDIO jacks

D

* The area around the video/audio output jacks is marked in white on the actual product to prevent improper connections.

B MONITOR OUT jacks COMPONENT VIDEO jacks: For connecting to a TV that s component video and outputting video signals (p.22).

VIDEO jack: For connecting to a TV that s composite video and outputting video signals (p.22).

C SPEAKERS terminals For connecting to speakers (p.15).

For connecting to an audio playback device and inputting audio signals (p.26).

A SUBWOOFER PRE OUT 1–2 jacks (HTR-5066) SUBWOOFER PRE OUT jack (HTR-4066) For connecting to a subwoofer (with built-in amplifier) (p.15).

• The SURROUND BACK/BI AMP/ZONE B jacks are available on HTR-5066 only.

D VOLTAGE SELECTOR (General model only) Selects the switch position according to your local voltage (p.29).

• (HTR-5066 only) You can connect 2 subwoofers (with built-in amplifier) to the unit.

FEATURES ➤


En

9

Remote control 1 Remote control signal transmitter

1

Transmits infrared signals. CODE SET

2

SOURCE RECEIVER

E

Turns on/off an external device.

SOURCE/RECEIVER key HDMI

1

2

3

Changes the device (the unit or external device) that is operated with the remote control (p.86). You can operate the unit when this key lights up in orange, and an external device when this key lights up in green.

4 MHL

3

2 SOURCE z key

1

2

3

5

AV

4

5

6

A

V-AUX

USB

NET

B

F

RECEIVER z key Turns on/off (standby) the unit.

ZONE

3 Input selection keys

AUDIO TUNER

4

FM

AM

5

INFO

MEMORY

MOVIE

MUSIC

6 7 8 9 :

PRESET

SUR. DECODE STRAIGHT

ENHANCER

SCENE BD DVD

TV

NET

RADIO

G

OPTION

SETUP

4 Radio keys VOLUME

ENTER

RETURN

POP-UP MENU

MUTE

I

Operate the FM/AM radio (p.43). FM Switches to FM radio. AM Switches to AM radio. MEMORY s FM/AM radio stations as presets. PRESET Select a preset station. TUNING Select the radio frequency.

5 INFO key 2

3

5

6

7

9

0

10

INPUT TV VOL

4

8

ENT

Selects the information displayed on the front display (p.63).

6 Sound mode keys Select a sound mode (p.37).

7 SLEEP key

TV

D

H

DISPLAY

MODE

1

C

DIRECT

SLEEP

TOP MENU

A B

TUNING

Select an input source for playback. HDMI 1–4 HDMI 1–4 jacks HDMI 5/MHL HDMI 5/MHL jack AV 1–6 AV 1–6 jacks V-AUX VIDEO AUX jack (on the front ) USB USB jack (on the front ) NET NETWORK jack (press repeatedly to select a desired network source) AUDIO AUDIO jacks

TV CH

MUTE

Switches the unit to standby mode automatically after a specified period of time has elapsed (sleep timer). Press repeatedly to set the time (120 min, 90 min, 60 min, 30 min, off).

8 SCENE keys (HTR-5066)

9 SETUP key Displays the setup menu (p.68).

0 Menu operation keys Cursor keys Select a menu or a parameter. ENTER Confirms a selected item. RETURN Returns to the previous screen.

A MODE key Switches between “Stereo” and “Mono” for FM radio reception (p.43). Switches the iPod operation modes (p.49).

B External device operation keys Let you play back and select menus and perform other operations for external devices (p.86).

C Numeric keys Let you enter numerical values, such as radio frequencies.

D TV operation keys Let you select TV input and volume, and perform other TV operations (p.85).

E CODE SET button s remote control codes of external devices on the remote control (p.85).

F ZONE keys (HTR-5066 only) Enable/disable the audio output to Zone A or Zone B (p.62).

★/★★ keys (HTR-4066 only) Change the external device to be controlled without switching the input source (p.86).

G OPTION key Displays the option menu (p.64).

H VOLUME keys Adjust the volume.

I MUTE key Mutes the audio output.

• To operate external devices with the remote control, a remote control code for each device before using (p.85).

Select the ed input source and sound program with one touch. Also, turns on the unit when it is in standby mode (p.36).

FEATURES ➤


En

10

PREPARATIONS General setup procedure 1 Placing speakers (p.12)

Select the speaker layout for the number of speakers that you are using and place them in your room.

2 Connecting speakers (p.15)

Connect the speakers to the unit.

3 Connecting a TV (p.18)

Connect a TV to the unit.

4 Connecting playback devices (p.23)

Connect video devices (such as BD/DVD players) and audio devices (such as CD players) to the unit.

5 Connecting the FM/AM antennas (p.27)

Connect the supplied FM/AM antennas to the unit.

6 Connecting to a network (p.28)

Connect the unit to a network.

7 Connecting recording devices (p.29)

Connect recording devices to the unit.

8 Connecting the power cable (p.29)

After all the connections are complete, plug in the power cable.

9

Selecting an on-screen menu language (p.30)

Select the desired on-screen menu language (default: English).

10

Optimizing the speaker settings automatically (YPAO) (p.31)

Optimize the speaker settings, such as volume balance and acoustic parameters, to suit your room (YPAO).

This completes all the preparations. Enjoy playing movies, music, radio and other content with the unit!

PREPARATIONS

➤ General setup procedure

En

11

1 Speaker placement 2 3 4 5 6 7 8 9 10

1 Placing speakers Select the speaker layout for the number of speakers that you are using and place the speakers and subwoofer in your room. This section describes the representative speaker layout examples. Caution • (U.S.A. model only) Under its default settings, the unit is configured for 8-ohm speakers. When connecting 6-ohm speakers, set the unit’s speaker impedance to “6 Ω MIN”. In this case, you can also use 4-ohm speakers as the front speakers. For details, see “Setting the speaker impedance” (p.14). • (Except for U.S.A. model) Use speakers with an impedance of at least 6 Ω.

Speaker system (the number of channels) Speaker type Front (L)

Abbr.

Function

1

Front (R)

2

Center

3

Surround (L)

4

Surround (R)

5

Produce front right/left channel sounds (stereo sounds). Produces center channel sounds (such as movie dialogue and vocals). Produce surround right/left channel sounds.

Surround back (L)*

6

Surround back (R)*

7

Surround back*

8

Produces sounds mixed from surround back left/right channel sounds.

9

Produces LFE (low-frequency effect) channel sounds and reinforces the bass parts of other channels. This channel is counted as “0.1”. You can connect 2 subwoofers (with built-in amplifier) to the unit.*

Subwoofer

Produce surround back left/right channel sounds.

7.1*

6.1*

5.1

4.1

3.1

2.1

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

●

● ● ● ●

●

●

●

* HTR-5066 only

• HTR-5066 s 2- to 7.1-channel system, and HTR-4066 s 2- to 5.1-channel speaker system. • (HTR-5066 only) Two subwoofers connected to the unit output the same sounds.

PREPARATIONS

➤ Placing speakers

En

12


7.1-channel system (HTR-5066 only)

1

9

5.1-channel system

1

2

3

9

4

9

5

10° to 30°

3

4

10° to 30°

6

2

5

10° to 30°

10° to 30°

7

30 cm (1 ft) or more


1

9

4.1-channel system

1

2

3

9

4

5

10° to 30°

2

10° to 30°

4

5

10° to 30°

10° to 30°

8

PREPARATIONS


En

13


■ Setting the speaker impedance

3.1-channel system

(U.S.A. model only)

1

9

2

3

Under its default settings, the unit is configured for 8-ohm speakers. When connecting 6-ohm speakers, set the speaker impedance to “6 Ω MIN”. In this case, you can also use 4-ohm speakers as the front speakers.

1

Before connecting speakers, connect the power cable to an AC wall outlet.

2

While holding down STRAIGHT on the front , press z (power). z (power)

STRAIGHT

3 2.1-channel system

SPIMP.8MIN 1

9

Check that “SP IMP.” is displayed on the front display.

2

4 5

Press STRAIGHT to select “6 Ω MIN”. Press z (power) to set the unit to standby mode and remove the power cable from the AC wall outlet.

You are now ready to connect the speakers.

PREPARATIONS


En

14

1 2 Speaker connections 3 4 5 6 7 8 9 10

2 Connecting speakers Connect the speakers placed in your room to the unit. The following diagrams provide connections for 5.1and 7.1-channel systems as examples. For other systems, connect speakers while referring to the connection diagram for the 5.1-channel system.

5.1-channel system


The unit (rear)

The unit (rear) SPEAKERS

PB FRONT

Caution

CENTER

SURROUND

SURROUND BACK/BI AMP /ZONE B

SPEAKERS PB FRONT

CENTER

SURROUND


SINGLE

Y

• Remove the unit’s power cable from an AC wall outlet and turn off the subwoofer before connecting the speakers. • Ensure that the core wires of the speaker cable do not touch one another or come into with the unit’s metal parts. Doing so may damage the unit or the speakers. If the speaker cables short circuit, “Check SP Wires” will appear on the front display when the unit is turned on.

SINGLE

Y

OR OUT

OR OUT 1

1

2 SUBWOOFER PRE OUT

2 SUBWOOFER PRE OUT

Cables required for connection (commercially available) Speaker cables (x the number of speakers) + –

+ –

1

2

1

2

Audio pin cable (x1: for connecting a subwoofer) 9

4

3

9

5

9

4

5 6

• (HTR-5066 only) You can connect 2 subwoofers (with built-in amplifier) to the unit. The 2 subwoofers output the same sound.

3

7

• When using only one surround back speaker, connect it to the SINGLE jack (L side).

PREPARATIONS ➤ Connecting speakers

En

15

1 2 Speaker connections 3 4 5 6 7 8 9 10

■ Connecting speaker cables Speaker cables have two wires. One is for connecting the negative (-) terminal of the unit and the speaker, and the other is for the positive (+) terminal. If the wires are colored to prevent confusion, connect the black wire to the negative and the other wire to the positive terminal. a Remove approximately 10 mm (3/8”) of insulation from the ends of the speaker cable and twist the bare wires of the cable firmly together. b Loosen the speaker terminal. c Insert the bare wires of the cable into the gap on the side (upper right or bottom left) of the terminal.

Connecting front speakers that bi-amp connections (HTR-5066 only) When using front speakers that bi-amp connections, connect them to the FRONT jacks and SURROUND BACK/BI-AMP/ZONE B jacks. To enable the bi-amp function, set “Power Amp Assign” (p.71) in the “Setup” menu to “BI-AMP” after connecting the power cable to an AC wall outlet. The unit (rear) SPEAKERS FRONT

CENTER

SURROUND

b

SINGLE

c

FR ON

T

d

• Surround back speakers cannot be used during bi-amp connections.

Connecting Zone B speakers (HTR-5066 only)


d Tighten the terminal. + (red)

Caution • Before making bi-amp connections, remove any brackets or cables that connect a woofer with a tweeter. Refer to the instruction manual of the speakers for details. If you are not making bi-amp connections, make sure that the brackets or cables are connected before connecting the speaker cables.

The Zone A/B function allows you to playback an input source in the room where the unit is installed (Zone A) and in another room (Zone B). To connect the Zone B speakers, see “Playing back music in multiple rooms (HTR-5066 only)” (p.61).

a

- (black)

Using a banana plug (U.S.A., China, Australia and General models only) 1

a Tighten the speaker terminal.

2

b Insert a banana plug into the end of the terminal. 3

Banana plug

a

9

FR ON T

4

b

5

■ Connecting the subwoofer (with built-in amplifier) Use an audio pin cable to connect the subwoofer. Y OR OU

MONIT

Audio pin cable

T 1

AV6

• The FRONT jacks and SURROUND BACK/BI-AMP/ZONE B jacks output the same signals.

AV OUT AUDIO

2 SUBW PRE OOFER OUT

PREPARATIONS ➤ Connecting speakers

En

16

Input/output jacks and cables ■ Video/audio jacks

■ Video jacks

■ Audio jacks

❑ HDMI jacks

❑ COMPONENT VIDEO jacks

❑ OPTICAL jacks

Transmit digital video and digital sound through a single jack. Use an HDMI cable.

Transmit video signals separated into three components: luminance (Y), chrominance blue (PB), and chrominance red (PR). Use a component video cable with three plugs.

Transmit digital audio signals. Use a digital optical cable. Remove the tip protector (if available) before using the cable.

HDMI cable

Digital optical cable Component video cable OPTICAL ( TV )

AV 4

❑ COAXIAL jacks

• Use a 19-pin HDMI cable with the HDMI logo. We recommend using a cable less than 5.0 m (16.4 ft) long to prevent signal quality degradation.

Transmit digital audio signals. Use a digital coaxial cable. Digital coaxial cable

• The unit’s HDMI jacks the HDMI Control, Audio Return Channel (ARC), and 3D and 4K video transmission (through output) features.

❑ VIDEO jacks

• Use high speed HDMI cables to enjoy 3D or 4K videos.

Transmit analog video signals. Use a video pin cable.

❑ HDMI/MHL jack Transmit digital video and digital sound. Use an MHL cable. HDMI 5 MHL 5V 1A

Video pin cable

❑ AUDIO jacks (Stereo L/R jacks) Transmit analog stereo audio signals. Use a stereo pin cable (RCA cable).

MHL cable

• The HDMI 5/MHL jack of the unit s both HDMI and MHL connections. Use a cable that matches the jack on your MHL-compatible mobile device. When connecting an HDMI-compatible playback device to the jack, use an HDMI cable. For details on an MHL connection, see “MHL connection” (p.23).

Stereo pin cable

(Stereo mini jack) Transmits analog stereo audio signals. Use a stereo mini-plug cable. Stereo mini-plug cable

PREPARATIONS ➤

Input/output jacks and cables

En

17

1 2 3 TV connection 4 5 6 7 8 9 10

3 Connecting a TV Connect a TV to the unit so that video input to the unit can be output to the TV. You can also enjoy playback of TV audio on the unit. The connection method varies depending on the functions and video input jacks available on your TV. Refer to the instruction manual of the TV and choose a connection method.

Does your TV Audio Return Channel (ARC)?

Yes

■ Connection Method 1 (p.18)

About Audio Return Channel (ARC)

Yes


■ Connection Method 1 (HDMI Control/ARC-compatible TV) Connect the TV to the unit with an HDMI cable.

No

Does your TV have an HDMI input jack?

HDMI Control allows you to operate external devices via HDMI. If you connect a TV that s HDMI Control to the unit with an HDMI cable, you can control the unit’s power and volume with the TV’s remote control. You can also control playback devices (such as an HDMI Control-compatible BD/DVD player) connected to the unit with an HDMI cable. For details, see “HDMI Control” (p.100).

ARC allows audio signals to travel both ways under HDMI Control. If you connect a TV that s HDMI Control and ARC to the unit with a single HDMI cable, you can output video/audio to the TV or input TV audio to the unit.

No

Does your TV HDMI Control?

About HDMI Control

Yes


• The following explanation is based on the assumption that you have not changed the “HDMI” parameters (p.74) in the “Setup” menu. • Use an HDMI cable that s ARC.

No The unit (rear)

HDMI OUT jack


HDMI input (ARC-compatible)

HDMI OUT HDMI 1

HDMI OUT

HDMI 2

HDMI

HDM

(BD/DVD)

ARC

ARC

HDMI

ARC

When connecting a video device with an analog video output

ANTEN AM

• If you will connect any video device to the AV 1–2 (COMPONENT VIDEO) jacks of the unit, you also need to connect the TV to the MONITOR OUT (COMPONENT VIDEO) jacks (p.22). • If you will connect any video device to the AV 3–6 (VIDEO) jacks or the VIDEO AUX (VIDEO) of the unit, you also need to connect the TV to the MONITOR OUT (VIDEO) jack (p.22).

When using a set-top box to watch TV

HDMI

(RADIO

PR

PB

Y COMPONENT VIDEO

VIDEO

OPTICAL

COAXIAL

COAXIAL

OPTICAL

AV 1

AV 2

AV 3

AV 4

( TV )

AV 5

AV 6

TV

• Connect the set-top box to the unit in the same way as playback devices (p.23). If you will receive TV broadcasts only from the set-top box, you do not need to make an audio cable connection between the TV and the unit or configure the ARC setting. • By connecting a TV to the unit with an HDMI cable, you can navigate the iPod, USB storage device and network sources, or configure the settings of the unit with the menu displayed on the TV.

PREPARATIONS ➤ Connecting a TV

En

18

1 2 3 TV connection 4 5 6 7 8 9 10 ❑ Necessary settings To use HDMI Control and ARC, you need to configure the following settings.

3

Configure the settings for HDMI Control.

For details on settings and operating your TV, refer to the instruction manual for the TV.

a Enable HDMI Control on the TV and playback devices (such as HDMI Control-compatible BD/DVD player).

1

After connecting external devices (such as a TV and playback devices) and the power cable to the unit, turn on the unit, TV, and playback devices.

b Turn off the TV’s main power and then turn off the unit and playback devices.

2

Configure the settings of the unit.

c Turn on the unit and playback devices and then turn on the TV’s main power. d Switch the TV input to display video from the unit.

a Check that ARC is enabled on the TV. b Switch the TV input to display video from the unit. c Press SETUP.

VOLUME

ENTER RETURN

DISPLAY

TOP

On the unit: The input to which the playback device is connected is selected. If not, select the input source manually. On the TV: The video from the playback device is displayed.

OPTION

SETUP

e Check the following.

SETUP Cursor keys ENTER

POP UP

d Use the cursor keys to select “HDMI” and press ENTER.

f Check that the unit is properly synchronized with the TV by turning off the TV or adjusting the TV volume with the TV remote control.

This completes the necessary settings. If you select a TV program with the TV remote control, the input source of the unit will be automatically switched to “AV 4” and the TV audio will be played back on the unit. If you cannot hear the TV’s audio, check that “ARC” (p.75) in the “Setup” menu is set to “On”.

Setup Speaker

Configuration

HDMI

• If HDMI Control does not work properly, try turning off and on (or unplugging and then plugging in again) the devices. It may solve the problem.

Sound ECO Function

• If the unit is not synchronized to the TV’s power operations, check the priority of the audio output setting on the TV.

Network Language

• If the audio is interrupted while using ARC, set “ARC” (p.75) in the “Setup” menu to “Off” and use a digital optical cable to input TV audio to the unit (p.20).

e Press ENTER again. f Use the cursor keys (q/w) to select “HDMI Control” and the cursor keys (e/r) to select “On” as shown below.

• “AV 4” is set as TV audio input at the factory. If you have connected any external device to the AV 4 jacks, use “TV Audio Input” (p.74) in the “Setup” menu to change the TV audio input assignment. To use the SCENE function (p.36), you also need to change the input assignment for SCENE(TV).

Configuration HDMI Control

On

Audio Output

Auto

Standby Through

Auto

TV Audio Input

AV4

Standby Sync

Auto

ARC

On

SCENE Back: RETURN

g Press SETUP.


En

19

1 2 3 TV connection 4 5 6 7 8 9 10

■ Connection Method 2 (HDMI Control-compatible TV)

❑ Necessary settings

Connect the TV to the unit with an HDMI cable and a digital optical cable.

To use HDMI Control, you need to configure the following settings. For details on settings and operating your TV, refer to the instruction manual for the TV.

• The following explanation is based on the assumption that you have not changed the “HDMI” parameters (p.74) in the “Setup” menu.

The unit (rear)

1

After connecting external devices (such as a TV and playback devices) and power cable of the unit, turn on the unit, TV, and playback devices.

2

Configure the settings of the unit.

HDMI OUT jack HDMI input HDMI OUT HDMI 1

HDMI OUT

HDMI 2

HDMI 3

HDMI

(BD/DVD)

ARC

ARC

HDMI

a Switch the TV input to display video from the unit.

HDMI

ANTENNA AM

(RADIO) FM

b Press SETUP.

PR

PB

Y COMPONENT VIDEO

OPTION

SETUP

VIDEO

OPTICAL OPTICAL

COAXIAL

COAXIAL

OPTICAL

AV 1

AV 2

AV 3

AV 4

OPTICAL

( TV )

AV 5

AV 6

O

O VOLUME

ENTER

A (TV) O

AV 4

AV 4 (OPTICAL) jack

Audio output (digital optical)

TV

RETURN

DISPLAY

TOP

SETUP Cursor keys ENTER

POP UP

c Use the cursor keys to select “HDMI” and press ENTER.

• By connecting a TV to the unit with an HDMI cable, you can navigate the iPod, USB storage device and network sources, or configure the settings of the unit with the menu displayed on the TV.

Setup Speaker

Configuration

HDMI Sound ECO Function Network Language

d Press ENTER again. e Use the cursor keys (q/w) to select “HDMI Control” and the cursor keys (e/r) to select “On” as shown below.

Configuration HDMI Control

On

Audio Output

Auto

Standby Through

Auto

TV Audio Input

AV4

Standby Sync

Auto

ARC

On

SCENE Back: RETURN

f Press SETUP.


En

20

1 2 3 TV connection 4 5 6 7 8 9 10

3

Configure the settings for HDMI Control. a Enable HDMI Control on the TV and playback devices (such as a HDMI Control-compatible BD/DVD player).

■ Connection Method 3 (TV with HDMI input jacks) Connect the TV to the unit with an HDMI cable and a digital optical cable. The unit (rear)

HDMI OUT jack HDMI input

b Turn off the TV’s main power and then turn off the unit and playback devices. c Turn on the unit and playback devices and then turn on the TV.

HDMI OUT HDMI 1

HDMI OUT

HDMI 2

HDMI 3

HDMI

(BD/DVD)

ARC

ARC

HDMI

d Switch the TV input to display video from the unit.

HDMI

ANTENNA AM

(RADIO) FM

PR

e Check the following. On the unit: The input to which the playback device is connected is selected. If not, select the input source manually. On the TV: The video from the playback device is displayed. f Check that the unit is properly synchronized with the TV by turning off the TV or adjusting the TV volume with the TV remote control.

This completes the necessary settings. If you select a TV program with the TV remote control, the input source of the unit will be automatically switched to “AV 4” and the TV audio will be played back on the unit.

• If HDMI Control does not work properly, try turning off and on (or unplugging and then plugging in again) the devices. It may solve the problem. • If the unit is not synchronized to the TV’s power operations, check the priority of the audio output setting on the TV.

PB

Y COMPONENT VIDEO

VIDEO

OPTICAL OPTICAL

COAXIAL

COAXIAL

OPTICAL

AV 1

AV 2

AV 3

AV 4

OPTICAL

( TV )

AV 5

AV 6

O

O

A (TV) O

AV 4

AV 4 (OPTICAL) jack

Audio output (digital optical)

TV

If you switch the input source of the unit to “AV 4” using the AV 4 or SCENE(TV) keys, the TV audio will be played back on the unit.

• By connecting a TV to the unit with an HDMI cable, you can navigate the iPod, USB storage device and network sources, or configure the settings of the unit with the menu displayed on the TV. • If you have connected any external device to the AV 4 jacks or if you want to use another input jack (other than OPTICAL) for connecting the TV, connect the TV to one of the AV 1–6 and AUDIO jacks. To use the SCENE function (p.36), you also need to change the input assignment for SCENE(TV).

• “AV 4” is set as TV audio input at the factory. If you have connected any external device to the AV 4 jacks or if you want to use another input jack (other than OPTICAL) for connecting the TV, use “TV Audio Input” (p.74) in the “Setup” menu to change the TV audio input assignment. To use the SCENE function (p.36), you also need to change the input assignment for SCENE(TV).


En

21

1 2 3 TV connection 4 5 6 7 8 9 10

■ Connection Method 4 (TV without HDMI input jacks)

❑ VIDEO (composite video) connection (with a video pin cable)

When connecting any video device to the AV 1–2 (COMPONENT VIDEO) jacks of the unit, connect the TV to the MONITOR OUT (COMPONENT VIDEO) jacks.

The unit (rear)

When connecting any video device to the AV 3–6 (VIDEO) jacks or the VIDEO AUX (VIDEO) jack of the unit, connect the TV to the MONITOR OUT (VIDEO) jack.

• If you connect your TV to the unit with a cable other than HDMI, video input to the unit via HDMI cannot be output to the TV. • Operations with TV screen are available only when your TV is connected to the unit via HDMI.

HDMI 1

HDMI OUT

If you select “AV 4” as the input source by pressing AV 4 or SCENE(TV), the TV audio will be played back on the unit.

MONITOR OUT (VIDEO) jack HDMI 2

HDMI 3

HDMI 4

Video input (composite video)

HDMI 5 MHL 5V

(BD/DVD)

VIDEO

ARC

V V

ANTENNA AM

(RADIO) FM

COMPONENT VIDEO

MONITOR OUT

PR

PR

PB

PB

Y COMPONENT VIDEO

Y VIDEO

MONITOR OUT 1

OPTICAL OPTICAL

COAXIAL

COAXIAL

OPTICAL

AV 1

AV 2

AV 3

AV 4

( TV )

AV 5

AV 6

AV OUT

OPTICAL

AUDIO

2 SUBWOOFER PRE OUT

O

O

(TV)

AV 4

• If you have connected any external device to the AV 4 jacks or if you want to use another input jack (other than OPTICAL) for connecting the TV, connect the TV to one of the AV 1–6 and AUDIO jacks. To use the SCENE function (p.36), you also need to change the input assignment for SCENE(TV).

AV 4 (OPTICAL) jack

TV Audio output (digital optical)

❑ COMPONENT VIDEO connection (with a component video cable) Video input (component video) MONITOR OUT (COMPONENT VIDEO) jacks

COMPONENT VIDEO PR

COMPONENT VIDEO

The unit (rear)

PR

HDMI 1

UT

HDMI 2

HDMI 3

HDMI 4

HDMI MHL 5V

(BD/DVD)

5

1A

PR

PR

PB

PB

Y

Y

PB

PB

Y

ANTENNA AM

(RADIO) FM

COMPONENT VIDEO

Y MONITOR OUT

PR

PB

Y VIDEO

MONITOR OUT 1

OPTICAL COAXIAL

COAXIAL

OPTICAL

AV 2

AV 3

AV 4

( TV )

AV 5

AV 6

AV OUT

OPTICAL

AUDIO

2 SUBWOOFER PRE OUT

O

O

(TV)

AV 4

AV 4 (OPTICAL) jack

TV Audio output (digital optical)


En

22

1 2 3 4 Playback device connections 5 6 7 8 9 10

4 Connecting playback devices The unit is equipped with a variety of input jacks including HDMI input jacks to allow you to connect different types of playback devices. For information on how to connect an iPod or a USB storage device, see the following pages. – Connecting an iPod (p.47) – Connecting a USB storage device (p.51)

Connecting video devices (such as BD/DVD players)

❑ MHL connection Connect an MHL-compatible mobile device (such as smartphones) to the unit with an MHL cable. You can enjoy full HD videos and multichannel audio sources stored on the mobile device. The HDMI 5 jack of the unit enables you to input videos and audio directly from the mobile device to the unit. HDMI 5/MHL jack The unit (rear) HDMI 5 MHL 5V 1A

Connect video devices such as BD/DVD players, set-top boxes (STBs) and game consoles to the unit. Depending on the video/audio output jacks available on your video device, choose one of the following connections. We recommend using an HDMI connection if the video device has an HDMI output jack.

HDMI 1

HDMI OUT

HDMI 2

HDMI 3

HDMI 4

HDMI 5 MHL 5V 1A

(BD/DVD)

ARC

ANTENNA AM

(RADIO) FM

COMPONENT VIDEO

PR

PR

PB

PB

MHL

Y COMPONENT VIDEO

MHL output

Y VIDEO

MONITOR OUT 1

• If the combination of video/audio input jacks available on the unit does not match your video device, change its combination according to the output jacks of your device (p.25).

MHL

OPTICAL

COAXIAL

COAXIAL

OPTICAL

AV 1

AV 2

AV 3

AV 4

( TV )

AV 5

Connect a video device to the unit with an HDMI cable.

If you select the input source by pressing HDMI 5, the video/audio played back on the mobile device will be output from the unit.

HDMI 1–5 jacks HDMI 1

HDMI 2

HDMI 3

HDMI 4

(BD/DVD)

HDMI 5 MHL 5V 1A

The unit (rear)

• To watch videos input to the HDMI 5/MHL jack, you need to connect your TV to the HDMI OUT jack of the unit (p.18 to 21). HDMI 1

HDMI 2

HDMI 3

HDMI 4

HDMI MHL 5V

(BD/DVD)

• You need to prepare an MHL cable that match the jack on your mobile device.

5

1A

HDMI output

HDMI

ARC

ANTENNA AM

(RADIO) FM

HDMI

COMPONENT VIDEO

PR

PR

PB

PB

Y COMPONENT VIDEO

AUDIO

2 SUBWOOFER PRE OUT

Mobile device

■ HDMI connection

HDMI OUT

AV 6

AV OUT

• You can operate the mobile device using the menu operation keys, external device operation keys and numeric keys on the remote control. However, some features may not be compatible, depending on the mobile device or its application. In this case, operate the mobile device itself.

HDMI

Y VIDEO

MONITOR OUT 1

OPTICAL

COAXIAL

COAXIAL

OPTICAL

AV 1

AV 2

AV 3

AV 4

( TV )

AV 5

AV 6

AV OUT

AUDIO

• If “Standby Through” (p.74) in the “Setup” menu is set to “On”, you can output mobile device videos/audio to the TV or operate the mobile device using the remote control of the unit even when the unit is in standby mode.

2 SUBWOOFER PRE OUT

Video device

• The unit supplies power to the mobile device in the following conditions. – The unit is turned on.

If you select the input source by pressing HDMI 1–5, the video/audio played back on the video device will be output from the unit.

– The unit is in standby mode while “Standby Through” (p.74) in the “Setup” menu is set to “On”.

• To watch videos input to the HDMI 1–5 jacks, you need to connect your TV to the HDMI OUT jack of the unit (p.18 to 21).

PREPARATIONS ➤ Connecting playback devices

En

23


■ Component video connection

■ Composite video connection

Connect a video device to the unit with a component video cable and an audio cable (digital optical or digital coaxial). Choose a set of input jacks (on the unit) depending on the audio output jacks available on your video device.

Connect a video device to the unit with a video pin cable and an audio cable (digital coaxial, digital optical, or stereo pin cable). Choose a set of input jacks (on the unit) depending on the audio output jacks available on your video device.

Output jacks on video device

Output jacks on video device Input jacks on the unit

Video

Input jacks on the unit

Audio

Video

Digital optical

AV 1 (COMPONENT VIDEO + OPTICAL)

Digital coaxial

AV 2 (COMPONENT VIDEO + COAXIAL)

Audio Digital coaxial

AV 3 (VIDEO + COAXIAL)

Digital optical

AV 4 (VIDEO + OPTICAL)

Analog stereo

AV 5–6 (VIDEO + AUDIO)

Component video Composite video

Video output (component video)

AV 1–2 (COMPONENT VIDEO) jacks

Video output (composite video)

COMPONENT VIDEO

The unit (rear)

AV 3–6 (VIDEO) jack

PR

VIDEO

PR HDMI 1

HDMI OUT

HDMI 2

(BD/DVD)

PB

ARC

PR

PR

PB

PB

Y

Y

V

PB

HDMI 1

HDMI OUT

VIDEO

Y COMPONENT VIDEO

ANTENNA AM

(RADIO) FM

PR

Y COMPONENT VIDEO

PR

HDMI 3

V

Y

AM

PB

HDMI 2

(BD/DVD)

ARC

PB

Video device

Y COMPONENT VIDEO

VIDEO

O

VIDEO

C

O

OPTICAL

COAXIAL

COAXIAL

OPTICAL

AV 1

AV 2

AV 3

AV 4

( TV )

OPTICAL AV 5

AV 1

Video device

COAXIAL

AV 2

C

OPTICAL

COAXIAL

COAXIAL

OPTICAL

AV 1

AV 2

AV 3

AV 4

( TV )

AV 5

AV 6

COAXIAL

AV OUT

O

C

O

OPTICAL

COAXIAL

AV 1 (OPTICAL) jack or AV 2 (COAXIAL) jack

C

COAXIAL

OPTICAL

OPTICAL

L

Audio output (digital optical or digital coaxial)

If you select the input source by pressing AV 1–2, the video/audio played back on the video device will be output from the unit.

• To watch videos input to the AV 1–2 (COMPONENT VIDEO) jacks, you need to connect your TV to the MONITOR OUT (COMPONENT VIDEO) jacks of the unit (p.22).

The unit (rear)

L

L

L

R

R

R

R

Audio output Any of AV 3 (COAXIAL) jack, (either digital optical, AV 4 (OPTICAL) jack, digital coaxial, or analog stereo) AV 5–6 (AUDIO) jacks

If you select the input source by pressing AV 3–6, the video/audio played back on the video device will be output from the unit.

• To watch videos input to the AV 3–6 (VIDEO) jacks, you need to connect your TV to the MONITOR OUT (VIDEO) jack of the unit (p.22).


En

24


■ Changing the combination of video/audio input jacks If the combination of video/audio input jacks available on the unit does not match your video device, change its combination according to the output jacks of your device. You can connect a video device that has the following video/audio output jacks. Output jacks on video device Video

Video

Digital optical

Component video

After connecting external devices (such as a TV and playback devices) and power cable of the unit, turn on the unit.

2

Press AV 2 to select “AV 2” (video input jack to be used) as the input source.

Input jacks on the unit

Audio

HDMI

1

Audio

HDMI

AV 1 (OPTICAL) AV 4 (OPTICAL)

HDMI 1–5

Digital coaxial

HDMI 1–5

AV 2–3 (COAXIAL)

Analog stereo

HDMI 1–5

AV 5–6 (AUDIO) AUDIO

Analog stereo

AV 1–2 (COMPONENT VIDEO)


1

2

3

1

2

3

5

6

A

NET

RADIO

For example, if you have connected a video device to AV 2 (COMPONENT VIDEO) and AV 5 (AUDIO) jacks of the unit, change the combination setting as follows.

5

BD DVD

TV

PR PR HDMI 1

HDMI OUT

HDMI 2

PB

HDMI 3

(BD/DVD)

PR Y

ARC

3 4

OPTION

VOLUME

ENTER RETURN

DISPLAY

Cursor keys ENTER

POP UP

Press OPTION. Use the cursor keys (q/w) to select “Audio In” and press ENTER. VOL.

AudioIn

COMPONENT VIDEO

The unit (rear)

OPTION

SETUP

Video output (component video)

AV 2 (COMPONENT VIDEO) jacks

AV 2

AV

4

TOP

❑ Necessary setting

4 MHL

5

PB

Use the cursor keys (e/r) to select “AV 5” (audio input jack to be used).

PB ANTENNA AM

Y

(RADIO) FM

VOL.

Y

PR

AudioAV5

PB

Y COMPONENT VIDEO

L

VIDEO

AUDIO L

AV 1

COAXIAL

AV 2

COAXIAL

OPTICAL ( TV )

AV 3

AV 4

AV 5

AV 6

L

L

R OPTICAL

AV OUT

R

R

R AV 5

AV 5 (AUDIO) jacks

Audio output (analog stereo)

Video device

6

Press OPTION.

This completes the necessary settings. If you select “AV 2” as the input source by pressing AV 2, the video/audio played back on the video device will be output from the unit.


En

25


Connecting audio devices (such as CD players)

Connecting to the jacks on the front

Connect audio devices such as CD players and MD players to the unit. Depending on the audio output jacks available on your audio device, choose one of the following connections.

Use the VIDEO AUX jacks on the front to temporarily connect devices such as camcorders and portable audio players to the unit.

Audio output jacks on audio device

Audio output jacks on the unit

Digital optical

AV 1 (OPTICAL) AV 4 (OPTICAL)

Digital coaxial

AV 2–3 (COAXIAL)

Analog stereo


Before making a connection, stop playback on the device and turn down the volume on the unit. SCENE

BD DVD

INPUT

TONE CONTROL

TV

NET

PROGRAM

RADIO

STRAIGHT

VIDEO AUX

AUDIO

The unit (front)

VIDEO

5V

2.1A

V

The unit (rear) HDMI 1

HDMI OUT

HDMI 2

HDMI 3

HDMI 4

(BD/DVD)

ARC

O

O

ANTENNA AM

(RADIO) FM

COMPONENT VIDEO

PR

PR

PB

PB

Y COMPONENT VIDEO

OPTICAL

C

C

Portable audio player

COAXIAL

Y VIDEO

OPTICAL

COAXIAL

MONITOR O

L

OPTICAL

COAXIAL

COAXIAL

OPTICAL

AV 1

AV 2

AV 3

AV 4

( TV )

AV 5

AV 6

AV OUT

AUDIO

SUB PR

L

L

L

R

R

R

AV 1–6 jacks AUDIO jacks

Audio device

R

Audio output (either digital optical, digital coaxial, or analog stereo)

If you select the input source by pressing AV 1–6 or AUDIO, the audio played back on the audio device will be output from the unit.

Camcorder

If you select “V-AUX” as the input source by pressing V-AUX, the video/audio played back on the device will be output from the unit.

• To watch videos input to the VIDEO AUX (VIDEO) jack, you need to connect your TV to the MONITOR OUT (VIDEO) jack of the unit (p.22). • You need to prepare the video/audio cables that match the output jacks on your device.

• For details on how to connect an iPod or a USB storage device, see “Connecting an iPod” (p.47) or “Connecting a USB storage device” (p.51). • When “USB” is selected as the input source, video signals input to the VIDEO AUX (VIDEO) jack are output from the MONITOR OUT (VIDEO) jack.


En

26

1 2 3 4 5 FM/AM antenna connections 6 7 8 9 10

5 Connecting the FM/AM antennas Connect the supplied FM/AM antennas to the unit. Fix the end of the FM antenna to a wall, and place the AM antenna on a flat surface. FM antenna AM antenna

The unit (rear) HDMI 1

HDMI OUT

HDMI 2

HDMI 3

HDMI 4

HDMI MHL 5V

(BD/DVD)

5

1A

NETWORK (NET)

ARC

DC OUT 5V 0.5A

ANTENNA AM

(RADIO) FM

COMPONENT VIDEO

PR

PR

PB

PB

Y COMPONENT VIDEO

Y

SPEAKERS FRONT

VIDEO

CENTER

SURROUND

SURROUND BA /ZONE

MONITOR OUT 1

OPTICAL

COAXIAL

COAXIAL

OPTICAL

AV 1

AV 2

AV 3

AV 4

( TV )

AV 5

AV 6

AV OUT

AUDIO

2 SUBWOOFER PRE OUT

Assembling and connecting the AM antenna

Hold down

Insert

Release

• Unwind only the length of cable needed from the AM antenna unit. • The wires of the AM antenna have no polarity.

PREPARATIONS ➤ Connecting the FM/AM antennas

En

27

1 2 3 4 5 6 Network connections 7 8 9 10

6 Connecting to a network Connect the unit to your router with a commercially-available STP network cable (CAT-5 or higher straight cable). You can enjoy Internet radio or music files stored on media servers, such as PCs and Network Attached Storage (NAS), on the unit.

• Some security software installed on your PC or the firewall settings of network devices (such as a router) may block the access of the unit to the network devices or the Internet. In these cases, configure the security software or firewall settings appropriately. • Each server must be connected to the same subnet as the unit.

Network Attached Storage (NAS)

Internet

• To use the service via the Internet, broadband connection is strongly recommended.

WAN

PC LAN

Modem

Router

Network cable

HDMI 1

HDMI OUT

HDMI 2

HDMI 3

HDMI 4

HDMI MHL 5V

(BD/DVD)

5

1A

NETWORK (NET)

ARC

DC OUT 5V 0.5A

ANTENNA AM

(RADIO) FM

COMPONENT VIDEO PR

PR

PB

PB FRONT

Y COMPONENT VIDEO

Y VIDEO

MONITOR OUT 1

OPTICAL

COAXIAL

COAXIAL

OPTICAL

AV 1

AV 2

AV 3

AV 4

( TV )

AV 5

AV 6

AV OUT

AUDIO

2 SUBWOOFER PRE OUT

The unit (rear)

• If you are using a router that s DH, you do not need to configure any network settings for the unit, as the network parameters (such as the IP address) will be assigned automatically to it. You only need to configure the network settings if your router does not DH or if you want to configure the network parameters manually (p.80). • You can check whether the network parameters (such as IP address) are properly assigned to the unit in “Information” (p.80) in the “Setup” menu.

PREPARATIONS ➤ Connecting to a network

En

28

1 2 3 4 5 6 7 Recording device connections 8 Power cable connection 9 10

7 Connecting recording devices You can connect video/audio recording devices to the AV OUT jacks. These jacks output analog video/audio signals selected as the input.

8 Connecting the power cable Before connecting the power cable (General model only) Set the switch position of VOLTAGE SELECTOR according to your local voltage. Voltages are AC 110–120/220–240 V, 50/60 Hz.

• To copy video/audio from a video device, connect the video device to the AV 5–6 jacks or VIDEO AUX (VIDEO/AUDIO) jacks of the unit. • To copy audio from an audio device, connect the audio device to the AV 5–6 jacks, AUDIO jacks, or VIDEO AUX (AUDIO) jacks of the unit. • Be sure to use the AV OUT jacks only for connecting recording devices.

• Make sure you set VOLTAGE SELECTOR of the unit BEFORE plugging the power cable into an AC wall outlet. Improper setting of VOLTAGE SELECTOR may cause damage to the unit and create a potential fire hazard.

VOLTAGE SELECTOR

Video/audio input AV OUT jacks

The unit (rear) V

HDMI 1

HDMI 2

HDMI 3

HDMI 4

HDMI MHL 5V

(BD/DVD)

V

1A

220V240V

L R

ANTENNA

(RADIO) FM

COMPONENT VIDEO

R

PR

AV OUT

PB

110V 120V

L

5

L AM

VOLTAGE SELECTOR

VIDEO

The unit (rear)

R

SPEAKERS

Video recording device

ENTER

SURROUND


AUDIO

Y VIDEO

MONITOR OUT 1

COAXIAL

COAXIAL

OPTICAL

AV 2

AV 3

AV 4

( TV )

AV 5

AV 6

AV OUT

AUDIO

2 SUBWOOFER PRE OUT

After all the connections are complete, plug in the power cable. The unit (rear) To an AC wall outlet

NETWORK (NET)

DC OUT 5V 0.5A

SPEAKERS FRONT

CENTER

SURROUND


PREPARATIONS

➤ Connecting recording devices

En

29

1 2 3 4 5 6 7 8 9 Language setting 10

9 Selecting an on-screen menu language

CODE SET

SOURCE RECEIVER

RECEIVER z

Select the desired on-screen menu language from English (default), Japanese, French, German, Spanish, Russian, Italian and Chinese.

HDMI

1

2

3

4 MHL

1

2

3

5

A

AV

4

5

6

V-AUX

USB

NET

1 2

B ZONE

AUDIO TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

TUNING

Press RECEIVER z to turn on the unit.

6

To exit from the menu, press SETUP.

• The information on the front display is provided in English only.

Turn on the TV and switch the TV input to display video from the unit (HDMI OUT jack).


ENHANCER

DIRECT

SLEEP

• Operations with TV screen are available only when your TV is connected to the unit via HDMI. If not, carry out operations while viewing the front display.

SCENE BD DVD

TV

NET

RADIO

SETUP

OPTION

SETUP

VOLUME

ENTER RETURN

DISPLAY

TOP MENU

POP-UP MENU

Cursor keys ENTER

3 4

MUTE

Press SETUP. Use the cursor keys to select “Language” and press ENTER.

MODE

1

2

3

4

5

6

7

8

9

0

10

Setup Speaker

English

HDMI

日本語 Français Deutsch Español Русский Italiano

Sound

ENT

ECO

TV

Function

INPUT TV VOL

TV CH

Network

MUTE

Language

5

中文

Use the cursor keys to select the desired language.

Setup Speaker

English

HDMI

日本語 Français Deutsch Español Русский

Sound ECO Function Network Language

Italiano 中文

PREPARATIONS ➤ Selecting an on-screen menu language

En

30

1 2 3 4 5 6 7 8 9 10 Automatic speaker setup

10 Optimizing the speaker settings automatically (YPAO)

CODE SET

SOURCE RECEIVER

RECEIVER z

HDMI

1

2

3

4 MHL

1

2

3

5

A

AV

4

5

6

V-AUX

USB

NET

B

The Yamaha Parametric room Acoustic Optimizer (YPAO) function detects speaker connections, measures the distances from them to your listening position(s), and then automatically optimizes the speaker settings, such as volume balance and acoustic parameters, to suit your room.

4

Place the YPAO microphone at your listening position (same height as your ears) and connect it to the YPAO MIC jack on the front . The unit (front)

ZONE

AUDIO TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

TUNING


ENHANCER

DIRECT

SLEEP SCENE BD DVD

TV

NET

– Use YPAO after connecting a TV and speakers to the unit. – During the measuring process, test tones are output at high volume. Ensure that the test tones do not frighten small children. Also, refrain from using this function at night when it may be a nuisance to others.

1

RADIO

– During the measuring process, you cannot adjust the volume.

OPTION

SETUP

• Please note the following when using YPAO.

2

– During the measuring process, keep the room as quiet as possible. VOLUME

ENTER RETURN

DISPLAY

TOP MENU

POP-UP MENU

MUTE

MODE

1

2

3

5

6

7

9

0

10

– Do not connect headphones.

1 2

Press RECEIVER z to turn on the unit. Turn on the TV and switch the TV input to display video from the unit (HDMI OUT jack).

YPAO microphone Listening 5 position

4

8

ENT

Ear height


TV

MUTE

3

4

INPUT TV VOL

9

TV CH

3

Turn on the subwoofer and set the volume to half. If the crossover frequency is adjustable, set it to maximum. VOLUME

MIN

MAX

CROSSOVER/ HIGH CUT

MIN

9

Place the YPAO microphone at your listening position (same height as your ears). We recommend the use of a tripod as a microphone stand. You can use the tripod screws to stabilize the microphone.

The following screen appears on the TV.

MAX

Auto Setup Start Exit

• (HTR-5066 only) If you are using bi-amp connection or Zone B speakers, set “Power Amp Assign” (p.71) in the “Setup” menu to the appropriate setting before starting YPAO.

PREPARATIONS ➤

Press SETUP key to Start

Power Amp Assign Basic

“Power Amp Assign” setting (p.71) (HTR-5066 only)

Optimizing the speaker settings automatically (YPAO)

En

31


CODE SET

SOURCE RECEIVER

• To cancel the operation, disconnect the YPAO microphone, or use the cursor keys to select “Exit” and press ENTER, before starting the measurement.

SOURCE/RECEIVER

HDMI

1

2

3

4

1

2

3

5

• A speaker with a problem is indicated by blinking of the speaker indicators in the front display. • If multiple warnings are given (when operating with the front display), use the cursor keys (q/w) to check the other warning messages.

MHL

AV

4

5

6

A

V-AUX

USB

NET

B

• Do not stand between the speakers and the YPAO microphone during the measurement process (about 3 minutes).

ZONE

6

• Move to the corner of the room or leave the room.

AUDIO

To save the measurement results, use the cursor keys (e/r) to select “SAVE” and press ENTER.

TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

5

TUNING


ENHANCER

SCENE TV

NET

DISPLAY

TOP MENU

POP-UP MENU

MUTE

MODE

1

2

3

5

6

7

9

0

10

4

Cursor keys ENTER RETURN

MUTE

TV CH

Result 3 / 2 / 0.1 ch 3.0 / 10.5 m

• To stop the measurement temporarily, press RETURN and follow the procedure in “Error messages” (p.33). • If cursor keys do not work, the remote control may be set to the external device operation mode. In this case, press SOURCE/RECEIVER to set the remote control to the unit operation mode (the key lights up in orange) and then use the cursor keys.

The adjusted speaker settings are applied.

The following screen appears on the TV when the measurement finishes.

• To finish the measurement without saving the result, select “CANCEL”.

8

7

Disconnect the YPAO microphone from the unit.

ENT

Auto Setup

TV

SAVE

-3.0 / +10.0 dB

INPUT TV VOL

Exit

SETUP

VOLUME

ENTER RETURN

Measurement Finished

Start

RADIO

OPTION

SETUP

Auto Setup

The measurement will start in 10 seconds. Press ENTER to start the measurement immediately.

DIRECT

SLEEP

BD DVD

To start the measurement, use the cursor keys to select “Start” and press SETUP.

Start Exit

This completes optimization of the speaker settings.

Measurement Finished Result 3 / 2 / 0.1 ch 3.0 / 10.5 m -3.0 / +10.0 dB OK:ENTER

1

Caution

2

• The YPAO microphone is sensitive to heat, so should not be placed anywhere where it could be exposed to direct sunlight or high temperatures (such as on top of AV equipment).

3 4

1 The number of speakers (front side/rear side/subwoofer) 2 Speaker distance (nearest/farthest) 3 Adjustment range of speaker output level 4 Warning message (if available)

• If any error message (such as E-1) or warning message (such as W-1) appears, see “Error messages” (p.33) or “Warning messages” (p.34).

PREPARATIONS ➤


En

32


Error messages If any error message is displayed during the measurement, resolve the problem and perform YPAO again.

Auto Setup Start

ERROR E-5:Noisy

Error message

Exit PROCEED

5%

TV screen

Error message

Cause

Remedy

E-1:No Front SP (E-1:NO FRNT SP)

Front speakers are not detected.

E-2:No Sur. SP (E-2:NO SUR SP)

One of the surround speakers cannot be detected.

E-4:SBR → SBL (E-4:SBR -> SBL)

A surround back speaker is connected to the R side only.

When using only one surround back speaker, you need to connect it to the SINGLE jack (L side). Exit YPAO, turn off the unit, and then reconnect the speaker.

E-5:Noisy (E-5:NOISY)

The noise is too loud.

Keep the room quiet and retry YPAO. If you select “PROCEED”, YPAO takes the measurement again and ignores any noise detected.

E-6:Check Sur. (E-6:CHECK SUR)

Surround back speakers are connected, but no surround speakers are connected.

Surround speakers need to be connected in order to use surround back speakers. Exit YPAO, turn off the unit, and then reconnect the speakers.

E-7:No MIC (E-7:NO MIC)

The YPAO microphone has been removed.

Connect the YPAO microphone to the YPAO MIC jack firmly and retry YPAO.

E-8:No Signal (E-8:NO SIGNAL)

The YPAO microphone cannot detect test tones.

Connect the YPAO microphone to the YPAO MIC jack firmly and retry YPAO. If this error occurs repeatedly, the nearest authorized Yamaha dealer or service center.

E-9: Cancel (E-9:CANCEL)

The measurement has been canceled.

Retry or exit YPAO as necessary.

E-10:Internal Err. (E-10:INTERNAL)

An internal error has occurred.

Exit YPAO, and turn off and on the unit. If this error occurs repeatedly, the nearest authorized Yamaha dealer or service center.

Exit YPAO, turn off the unit, and then check the speaker connections.

VOL.

E-5:NOISY

L SL

SW C

R SR

Front display

■ Procedure to handle errors

1 2

Check the content of error message and press ENTER. Use the cursor keys (e/r) to select the desired operation. To exit the YPAO measurement: a Select “EXIT” and press ENTER. b Use the cursor keys (q/w) to select “Exit” and press ENTER.

• Texts in parentheses denote indicators on the front display.

c Disconnect the YPAO microphone from the unit.

To retry the YPAO measurement from beginning: Select “RETRY” and press ENTER.

To proceed with the current YPAO measurement (for E-5 and E-9 only): Select “PROCEED” and press ENTER.

PREPARATIONS ➤


En

33


Warning messages If a warning message is displayed after the measurement, you can still save the measurement results by following on-screen instructions. However, we recommend you perform YPAO again in order to use the unit with the optimal speaker settings.

Auto Setup

Warning message

Cause

W-1:Out of Phase (W-1:PHASE)

Check the cable connections (+/-) of the problem speaker. If the speaker is connected incorrectly, exit YPAO, turn off the A speaker cable may be connected with the unit, and then reconnect the speaker cable. reverse polarity (+/-). Depending on the type of speakers or room environment, this message may appear even if the speakers are connected correctly. In this case, you can ignore the message.

W-2:Over Distance (W-2:DISTANCE)

A speaker is placed more than 24 m (80 ft) from the listening position.

Exit YPAO, turn off the unit, and place the problem speaker within 24 m (80 ft) of the listening position.

There are significant volume differences between the speakers.

Check the usage environment and cable connections (+/-) of each speaker, and the volume of the subwoofer. If there is any problem, exit YPAO, turn off the unit, and then reconnect speaker cable or correct the speaker positions. We recommend using the same speakers or speakers with specifications that are as similar as possible.

Measurement Finished

Start

Result

Exit

3 / 2 / 0.1 ch 3.0 / 10.5 m -3.0 / +10.0 dB OK:ENTER

Warning message

W-1:Out of Phase

Remedy

TV screen Problem speaker (blinks)

W-3:Level Error (W-3:LEVEL)

VOL.

W-1:PHASE

L SL

SW C

R SR

Front display


■ Procedure to handle warnings

1

Check the content of warning message and press ENTER.

2

Use the cursor keys (e/r) to select the desired operation. To save the measurement results: Select “SAVE” and press ENTER.

To discard the measurement result: Select “CANCEL” and press ENTER.

3

Disconnect the YPAO microphone from the unit.

PREPARATIONS ➤


En

34

PLAYBACK

CODE SET

SOURCE RECEIVER

HDMI

1

2

3

1

2

3

4

5

A

MHL

Input selection keys

Basic playback procedure

AV

4

5

6

V-AUX

USB

NET

B ZONE

1

Turn on the external devices (such as a TV or BD/DVD player) connected to the unit.

2

Use the input selection keys to select an input source.

3

Start playback on the external device or select a radio station.

AUDIO TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

TUNING


ENHANCER

DIRECT

SLEEP SCENE BD DVD

TV

NET

RADIO

OPTION

SETUP

Refer to the instruction manual for the external device. VOLUME

ENTER RETURN

VOLUME

For details on the following operations, see the corresponding pages.

MUTE

• Listening to FM/AM radio (p.43)

DISPLAY

TOP MENU

POP-UP MENU

MUTE

MODE

• Playing back iPod music (p.47)

1

2

3

4

5

6

7

8

9

0

10

• Playing back music stored on a USB storage device (p.51) • Playing back music stored on media servers (PCs/NAS) (p.54)

ENT

TV INPUT TV VOL

TV CH

• Listening to Internet radio (p.57)

MUTE

• Playing back iTunes/iPod music via a network (AirPlay) (p.59)

4

Press VOLUME to adjust the volume.

• To mute the audio output, press MUTE. Press MUTE again to unmute. • To adjust the treble/bass settings, use the “Option” menu or TONE CONTROL on the front (p.65).

PLAYBACK ➤ Basic playback procedure

En

35

Selecting the input source and favorite settings with one touch (SCENE)

CODE SET

SOURCE RECEIVER

SOURCE/RECEIVER

HDMI

1

2

3

4 MHL

1

2

3

5


AV

4

5

6

A

V-AUX

USB

NET

B

The SCENE function allows you to select the assigned input source, sound program, Compressed Music Enhancer on/off, and target zones (HTR-5066 only) with just one touch.

1

ZONE

AUDIO

AM PRESET

INFO

MEMORY

MOVIE

MUSIC

1

The input source and settings ed to the corresponding scene are selected. The unit turns on automatically when it is in standby mode.

TUNER FM

Press SCENE.

Configuring scene assignments

TUNING

• Select an input source (p.35) • Select a sound program (p.37) • Enable/disable Compressed Music Enhancer (p.42)


ENHANCER

By default, the following settings are ed for each scene.

DIRECT

• (HTR-5066 only) Enable/disable the audio output to Zone A/B (p.62)

SLEEP SCENE BD DVD

TV

NET

RADIO

SCENE

OPTION

SETUP

Input

Sound program

Compressed Target zone Music (HTR-5066 Enhancer only)

VOLUME

ENTER RETURN

SCENE

DISPLAY

TOP MENU

POP-UP MENU

BD/DVD

HDMI 1

MOVIE (Sci-Fi)

Off

MUTE

SCENE link playback

Zone A: enabled Zone B: disabled

On

On

2

2

3

4

5

6

7

8

9

0

SETComplete

10

TV

AV 4

STRAIGHT

On


NET

NET RADIO

MUSIC (7ch/5ch Stereo*)

On


Off

RADIO

MUSIC TUNER (7ch/5ch Stereo*)

On


Off

ENT

TV INPUT TV VOL

TV CH

MUTE

Hold down the desired SCENE key until “SET Complete” appears on the front display. VOL.

MODE

1

Perform the following operations to prepare the settings you want to assign to a scene.

3

L SL

SW C

R SR

If you want to control the corresponding playback device after selecting the scene, hold down the corresponding SCENE key and input selection key together for more than 3 seconds.

Once the setting is completed successfully, SOURCE/RECEIVER blinks twice.

• If you have not ed the remote control code of the playback device yet, see “ing the remote control codes for playback devices” (p.86) to it.

* HTR-5066: 7ch Stereo, HTR-4066: 5ch Stereo

• The SCENE link playback function allows you to automatically turn on the TV or start playback of an external device connected to the unit via HDMI, in conjunction with a scene selection. To enable SCENE link playback, set “SCENE” (p.75) in the “Setup” menu to “On”.

PLAYBACK ➤ Selecting the input source and favorite settings with one touch (SCENE)

En

36

Selecting the sound mode

CODE SET

SOURCE RECEIVER

The unit is equipped with a variety of sound programs and surround decoders that allow you to enjoy playback sources with your favorite sound mode (such as sound field effect or stereo playback).

HDMI

1

2

3

4 MHL

1

2

3

5

4

5

6

A

V-AUX

USB

NET

AV

B

❑ Selecting a sound program suitable for movies

ZONE

AUDIO TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

TUNING


ENHANCER

DIRECT

SLEEP SCENE BD DVD

TV

NET

RADIO

OPTION

SETUP

• Press MOVIE repeatedly. MOVIE MUSIC SUR.DECODE STRAIGHT DIRECT ENHANCER

This mode lets you enjoy sound field effects optimized for viewing video sources, such as movies, TV programs, and games (p.38).

• You can also switch the sound programs and surround decoder by pressing PROGRAM on the front . • The sound mode can be applied separately to each input source. • When you play back audio signals with a sampling rate of higher than 96 kHz or playing back DTS Express, the straight decode mode (p.40) is automatically selected. • You can check which speakers are currently outputting sound by looking at the speaker indicators on the unit’s front (p.8).

❑ Selecting a sound program suitable for music or stereo playback • Press MUSIC repeatedly.

VOLUME

ENTER RETURN

DISPLAY

TOP MENU

POP-UP MENU

This mode lets you enjoy sound field effects optimized for listening music sources or stereo playback (p.39).

MUTE

❑ Selecting a surround decoder

MODE

• Press SUR.DECODE repeatedly. 1

2

3

4

5

6

7

8

9

0

10 TV

INPUT TV VOL MUTE

TV CH

This mode lets you enjoy unprocessed multichannel playback from 2-channel sources (p.41).

ENT

❑ Switching to the straight decode mode • Press STRAIGHT. This mode lets you enjoy unprocessed sounds in original channels (p.40).

❑ Switching to the direct playback mode • Press DIRECT. This mode lets you enjoy pure high fidelity sound by reducing the electrical noise from other circuitry (p.41).

❑ Enabling Compressed Music Enhancer • Press ENHANCER. This mode lets you enjoy compressed music with additional depth and breadth (p.42).

PLAYBACK ➤ Selecting the sound mode

En

37

Enjoying sound field effects (CINEMA DSP)

The unit is equipped with a variety of sound programs that utilize Yamaha’s original DSP technology (CINEMA DSP). It allows you to easily create sound fields like actual movie theaters or concert halls in your room.

Drama

This program features stable reverberations that match a wide range of movie genres, from serious dramas to musicals and comedies. The reverberations are modest, but suitably stereophonic. The sound effects and background music are reproduced with a gentle echo that does not impinge on the articulation of the dialogue. You’ll never get tired listening for long periods.

Mono Movie

This program reproduces monaural video sources, such as classic movies, in an atmosphere of a good old movie theater. The program creates a pleasant space with depth, by adding breadth and the appropriate reverberation to the original audio.

Sports

This program allows listeners to enjoy the rich vividness of sport broadcasts and light entertainment programs. In sports broadcasts, the commentators’ voices are positioned clearly at the center, while the atmosphere inside the stadium is realistically conveyed by the peripheral delivery of the sounds of the fans in a suitable space.

Action Game

This program is suitable for action games, such as car racing and fighting games. The reality of, and emphasis on, various effects makes the player feel like they are right in the middle of the action, allowing for greater concentration. Use this program in combination with Compressed Music Enhancer for a more dynamic and strong sound field.

Roleplaying Game

This program is suitable for role-playing and adventure games. This program adds depth to the sound field for natural and realistic reproduction of background music, special effects, and dialogue from a wide variety of scenes. Use this program in combination with Compressed Music Enhancer for a clearer and more spatial sound field.

Sound program category “CINEMA DSP” lights up VOL.

Sci-Fi

L SL

SW C

R SR

Sound program

• When you play back DTS-HD sources, the DTS decoder is automatically selected.

• You can adjust the sound field effect level in “DSP Level” (p.65) in the “Option” menu.

■ Sound programs suitable for movies (MOVIE) The following sound programs are optimized for viewing video sources, such as movies, TV programs, and games.

Standard

This program creates a sound field that emphasizes the surround feeling without disturbing the original acoustic positioning of multichannel audio, such as Dolby Digital and DTS. Its design is based on the concept of the ideal movie theater, in which the audience is surrounded by beautiful reverberations from the left, right, and rear.

Spectacle

This program delivers the scale and grandeur of spectacular movie productions. It delivers an expansive sound space to match the cinemascope wide-screen, and boasts a broad dynamic range, providing everything from small delicate sounds to powerful loud booms.

Sci-Fi

This program clearly reproduces the finely elaborated sound design of the latest Sci-Fi and SFX movies. You can enjoy a variety of cinematographically created virtual spaces reproduced with clear separation between dialogue, sound effects, and background music.

Adventure

This program is ideal for reproducing the sound design of action and adventure movies precisely. The sound field restrains reverberations, but puts emphasis on reproducing a sensation of expansiveness on both sides, powerful space expanded widely to the left and right. The restrained depth creates a clear and powerful space, while also maintaining the articulation of the sounds and the separation of the channels.


En

38

■ Sound programs suitable for music/stereo playback (MUSIC) The following sound programs are optimized for listening to music sources. You can also select stereo playback.

Hall in Munich

This program simulates a Munich concert hall with approximately 2,500 seats that uses stylish wood for the interior finishing. Fine, beautiful reverberations spread richly, creating a calming atmosphere. The listener’s virtual seat is at the center left of the arena.

Hall in Vienna

This program simulates a 1700-seat, middle-sized concert hall with a shoebox shape that is traditional in Vienna. Pillars and ornate carvings create extremely complex reverberations from all around the audience, producing a very full, rich sound.

Chamber

This program creates a relatively wide space with a high ceiling, like an audience hall in a palace. It offers pleasant reverberations that are suitable for courtly music and chamber music.

Cellar Club

This program simulates an intimate concert venue with a low ceiling and homey atmosphere. A realistic, live sound field delivers powerful sounds that make you feel as if you are sitting in the front row in front of a small stage.

The Roxy Theatre

This program creates the sound field of a 460-seat rock music concert venue in Los Angeles. The listener’s virtual seat is at the center left of the hall.

The Bottom Line

This program creates the sound field at stage front in The Bottom Line, a famous New York jazz club once. The floor can seat 300 people to the left and right in a sound field offering real and vibrant sound.

Music Video

This program allows you to enjoy videos of pop, rock, and jazz concerts, as if you were there yourself. Immerse yourself in the hot concert atmosphere thanks to the vividness of the singers and solos on stage, a presence sound field that emphasizes the beat of rhythm instruments, and a surround sound field that reproduces the space of a big live hall.

2ch Stereo

Use this program to mix down multichannel sources to 2 channels. When multichannel signals are input, they are down mixed to 2 channels and output from the front speakers (this program does not utilize CINEMA DSP).

7ch Stereo 5ch Stereo

(HTR-5066: 7ch Stereo, HTR-4066: 5ch Stereo) Use this program to output sound from all speakers. When you play back multichannel sources, the unit mixes down the source to 2 channels, and then outputs the sound from all speakers. This program creates a larger sound field and is ideal for background music at parties.


En

39

CODE SET

SOURCE RECEIVER

■ Enjoying stereoscopic sound fields (CINEMA DSP 3D)

Enjoying unprocessed playback

CINEMA DSP 3D creates a natural stereoscopic sound field in your room.

■ Playing back in original channels (straight decode)

HDMI

1

2

3

4

2

3

5

You can play back input sources without any sound field effect processing.

MHL

1

AV

4

5

6

A

V-AUX

USB

NET

B

CINEMA DSP 3D functions when both of the following conditions are met.

ZONE

AUDIO TUNER FM

AM PRESET

INFO

MEMORY

MOVIE

MUSIC

TUNING


STRAIGHT ENHANCER

DIRECT

SLEEP SCENE BD DVD

TV

NET

RADIO

• “CINEMA DSP 3D Mode” (p.75) in the “Setup” menu is set to “On”.

1

VOL. VOLUME

ENTER RETURN

TOP MENU

POP-UP MENU

1

2

3

4

5

6

7

8

9

0

10 TV

TV VOL MUTE

TV CH

L SL

SW C

VOL. R SR

MUTE

MODE

INPUT

3

Hall in Vienna

DISPLAY

ENT

Press STRAIGHT. Each time you press the key, the straight decode mode is enabled or disabled.

“CINEMA DSP n” lights up

OPTION

SETUP

• One of the sound programs (except 2ch Stereo and 7ch/5ch Stereo) is selected (p.38).

When the straight decode mode is enabled, the unit produces stereo sound from the front speakers for 2-channel sources such as CDs, and produces unprocessed multichannel sounds for multichannel sources.

■ Enjoying sound field effects without surround speakers (Virtual CINEMA DSP) If you select one of the sound programs (except 2ch Stereo and 7ch/5ch Stereo) when no surround speakers are connected, the unit automatically creates the surround sound field using the front-side speakers.

STRAIGHT

L SL

SW C

R SR

• (HTR-5066 only) To enable 6.1/7.1-channel playback from 5.1-channel sources when surround back speakers are used, set “Extended Surround” (p.65) in the “Option” menu to a setting other than “Off”.


En

40

■ Playing back 2-channel sources in multichannel (surround decoder)

CODE SET

SOURCE RECEIVER

The surround decoder enables unprocessed multichannel playback from 2-channel sources. When a multichannel source is input, it works the same way as the straight decode mode.

HDMI

1

2

3

1

2

3

4

5

A

MHL

AV

4

5

6

V-AUX

USB

NET

For details on each decoder see “Glossary” (p.97).

B

1

ZONE

AUDIO TUNER FM

AM PRESET

INFO

MEMORY

MOVIE

MUSIC

Press SUR.DECODE to select a surround decoder. Each time you press the key, the surround decoder changes.

TUNING


SUR.DECODE ENHANCER

DIRECT

SLEEP SCENE BD DVD

TV

NET

RADIO

VOLUME

ENTER RETURN

DISPLAY

TOP MENU

POP-UP MENU

MUTE

ProLogic bPro Logic

bPLIIx Movie*

bPLIIx Music* 2

3

4

5

6

7

8

9

0

10

ENT

Press DIRECT. Each time you press the key, the direct playback mode is enabled or disabled. VOL.

bPLII Music

1

1

VOL.

bPLII Movie

MODE

When the direct playback mode is enabled, the unit plays back the selected source with the least circuitry in order to reduce the electrical noise from other circuitry (such as the front display). It allows you to enjoy Hi-Fi sound quality.

DIRECT L SL

SW C

R SR

OPTION

SETUP

Enjoying pure high fidelity sound (direct playback)

bPLII Game

DIRECT

L SL

SW C

R SR

Uses the Dolby Pro Logic decoder suitable for all sources. Use the Dolby Pro Logic II decoder (or Dolby Pro Logic IIx decoder) suitable for movies. Use the Dolby Pro Logic II decoder (or Dolby Pro Logic IIx decoder) suitable for music.

• When the direct playback mode is enabled, the following functions are not available. – Selecting sound programs – Adjusting the tone control – Operating the on-screen and “Option” menus – Viewing information on the front display (when not in operation)

bPLIIx Game*

Use the Dolby Pro Logic II decoder (or Dolby Pro Logic IIx decoder) suitable for games.

Neo: 6 Cinema

Uses the DTS Neo: 6 decoder suitable for movies.

Neo: 6 Music

Uses the DTS Neo: 6 decoder suitable for music.

TV INPUT TV VOL MUTE

TV CH

* HTR-5066 only

(HTR-5066 only) • You cannot select the Dolby Pro Logic IIx decoders when headphones are connected or when “Surround Back” in the “Setup” menu is set to “None”.

• You can adjust the surround decoder parameters in “DSP Parameter” (p.75) in the “Setup” menu.


En

41

Enjoying compressed music with enhanced sound (Compressed Music Enhancer)

CODE SET

SOURCE RECEIVER

HDMI

1

2

3

1

2

3

4

5

A

MHL

AV

4

5

6

V-AUX

USB

NET

Compressed Music Enhancer adds depth and breadth to the sound, allowing you to enjoy a dynamic sound close to the original sound before it was compressed. This function can be used along with any other sound modes.

B ZONE

AUDIO TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

TUNING


ENHANCER

DIRECT

ENHANCER

SLEEP SCENE BD DVD

TV

NET

RADIO

1

Press ENHANCER. Each time you press the key, Compressed Music Enhancer is enabled or disabled.

OPTION

SETUP

“ENHANCER” lights up VOLUME

ENTER

ENHANCER RETURN

VOL.

DISPLAY

TOP MENU

POP-UP MENU

MUTE

Enhancer On

L SL

SW C

R SR

MODE

1

2

3

4

5

6

7

8

9

0

10

ENT

• Compressed Music Enhancer does not work on the following audio sources. – Signals whose sampling rate is over 48 kHz – High-definition streaming audio

TV INPUT TV VOL

TV CH

MUTE

• You can also use “Enhancer” (p.66) in the “Option” menu to enable/disable Compressed Music Enhancer.

Enjoying surround sound with headphones (SILENT CINEMA)

You can enjoy surround or sound field effects, like a multichannel speaker system, with stereo headphones by connecting the headphones to the PHONES jack and selecting a sound program or a surround decoder.


En

42

Listening to FM/AM radio

CODE SET

SOURCE RECEIVER

You can tune into a radio station by specifying its frequency or selecting from ed radio stations.

HDMI

1

2

3

4 MHL

1

2

3

5

AV

4

5

6

A

V-AUX

USB

NET

B ZONE

FM AM

AUDIO TUNER FM

AM PRESET

INFO

MEMORY

MOVIE

MUSIC

TUNING

TUNING

• The radio frequencies differ depending on the country or region where the unit is being used. The explanation of this section uses a display with frequencies used in U.K. and Europe models.

ENHANCER

Setting the frequency steps

DIRECT

TV

NET

RADIO

OPTION

SETUP

VOLUME

ENTER RETURN

DISPLAY

Press FM or AM to select a band. VOL.

FM87.50MHz

2

SW C R L SL SR SBL SBR

Use the following keys to set a frequency.

(Asia and General models only)

TUNING: Increase/decrease the frequency. Hold down the key for about a second to search stations automatically.

At the factory, the frequency step setting is set to 50 kHz for FM and 9 kHz for AM. Depending on your country or region, set the frequency steps to 100 kHz for FM and 10 kHz for AM.

Numeric keys: Enter a frequency directly. For example, to select 98.50 MHz, press “9”, “8”, “5” and “0” (or ENT).

SCENE BD DVD

1

• If you cannot obtain good reception on the radio, adjust the direction of the FM/AM antennas.


SLEEP

Selecting a frequency for reception

VOL. TOP MENU

POP-UP MENU

MUTE

MODE

MODE

1

2

3

4

5

6

7

8

9

0

10

1 2

Numeric keys

STEREO TUNED

Set the unit to standby mode. When holding down STRAIGHT on the front , press z (power).

L SL

SW C

R SR

“TUNED” lights up when a signal is received from a radio station. “STEREO” also lights up when a stereo signal is received.

z (power)

ENT

FM98.50MHz

TV INPUT TV VOL

TV CH

MUTE

• “Wrong Station!” appears when you enter a frequency that is out of reception range.

PROGRAM

3

STRAIGHT

Press PROGRAM repeatedly to select “TU”.

• You can switch between “Stereo” (stereo) and “Mono” (monaural) for FM radio reception by pressing MODE. When the signal reception for an FM radio station is unstable, switching to monaural may improve it. • You can watch videos input from external devices while listening to radio by selecting the video input jack in “Video Out” (p.67) in the “Option” menu.

TUFM50/AM9

4 5

Press STRAIGHT to select “FM100/AM10”. Press z (power) to set the unit to standby mode and turn it on again. PLAYBACK ➤ Listening to FM/AM radio

En

43

ing favorite radio stations (presets)

CODE SET

• To specify the preset number from which to start the registration, press PRESET or cursor keys (q/w) to select a preset number within 5 seconds after step 4 (while “READY” is displayed) and then press ENTER (or just wait for 5 seconds).

SOURCE RECEIVER

You can up to 40 radio stations as presets. Once you have ed stations, you can easily tune into them by selecting their preset numbers.

HDMI

1

2

3

4

2

3

5

A

MHL

1

• To cancel the Auto Preset process, press RETURN.

AV

4

5

6

V-AUX

USB

NET

B ZONE

FM AM

AUDIO TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

TUNING

MEMORY PRESET

■ ing radio stations automatically (Auto Preset)

• To AM radio stations, follow “ing a radio station manually”.

SCENE TV

NET

RADIO

OPTION

SETUP

OPTION

VOLUME

ENTER DISPLAY

TOP MENU

POP-UP MENU

2

3

5

6

7

9

0

10


• (U.K. and Europe models only) Only Radio Data System broadcasting stations are stored automatically by the Auto Preset function.

1

Press FM or AM to select “TUNER” as the input source.

2 3

Press OPTION.

MUTE

MODE

1

4

8

Use the cursor keys to select “Auto Preset”.

ENT

VOL.

TV INPUT TV VOL

AutoPreset

DIRECT

SLEEP

RETURN

VOL.

Automatically FM radio stations with strong signals (up to 40 stations).


ENHANCER

BD DVD

When the Auto Preset process finishes, “FINISH” appears and the “Option” menu closes automatically.

AutoPreset

TV CH

MUTE

■ ing a radio station manually Select a radio station manually and it to a preset number.

1

Follow “Selecting a frequency for reception” (p.43) to tune into the desired radio station.

2

Hold down MEMORY for more than 2 seconds. The first time that you do a station, the selected radio station will be ed to the preset number “01”. Thereafter, each radio station you select will be ed to the next empty (unused) preset number after the most recently ed number. VOL. STEREO TUNED

4

To start the Auto Preset process, press ENTER. The registration will start in 5 seconds. Press ENTER again to start the registration immediately. “SEARCH” appears during Auto Preset VOL.

01:FM98.50MHz

SW C

R SR

Preset number

• To select a preset number for ing, press MEMORY once after tuning into the desired radio station, press PRESET to select a preset number, and then press MEMORY again.

01:FM87.50MHz Preset number from which to start the registration

L SL

VOL. STEREO TUNED

02:Empty

L SL

SW C

R SR

“Empty” (not in use) or the frequency currently ed

PLAYBACK ➤ Listening to FM/AM radio

En

44

CODE SET

SOURCE RECEIVER

HDMI

1

2

3

1

2

3

4

5

A

MHL

■ Selecting a preset station

■ Clearing preset stations

Tune into a ed radio station by selecting its preset number.

Clear radio stations ed to the preset numbers.

1


1


2

Press PRESET repeatedly to select the desired radio station.

2 3

Press OPTION.

AV

4

5

6

V-AUX

USB

NET

B ZONE

FM AM

AUDIO TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

TUNING

PRESET

ENHANCER

PRESET

DIRECT

NET

RADIO

OPTION

SETUP

L SL

SW C

ClearPreset

R SR

OPTION

VOLUME

ENTER

VOL.

VOL. STEREO TUNED

01:FM98.50MHz

SCENE TV

RETURN

Use the cursor keys to select “Clear Preset” and press ENTER.


SLEEP

BD DVD

You can also enter a preset number (01 to 40) directly by using the numeric keys after pressing PRESET once.

DISPLAY

Cursor keys ENTER

• “No Presets” appears when no radio stations are ed.

4

Use the cursor keys (q/w) to select a preset station to be cleared and press ENTER.

• “Wrong Num.” appears when an invalid number is entered. TOP MENU

POP-UP MENU

• “Empty” appears when a preset number not in use is entered.

MUTE

VOL. STEREO TUNED

01:FM98.50MHz

MODE

1

2

3

4

5

6

7

8

9

0

10

L SL

SW C

R SR

Preset station to be cleared Numeric keys

If the preset station is cleared, “Cleared” appears and then the next in-use preset number is displayed.

ENT

TV INPUT TV VOL

TV CH

VOL.

MUTE

01:Cleared

L SL

SW C

R SR

5

Repeat step 4 until all desired preset stations are cleared.

6

To exit from the menu, press OPTION.


En

45

Radio Data System tuning

CODE SET

• “Program Service”, “Program Type”, “Radio Text”, and “Clock Time” are not displayed if the radio station does not provide the Radio Data System service.

SOURCE RECEIVER

(U.K. and Europe models only)

HDMI

1

2

3

1

2

3

5

Radio Data System is a data transmission system used by FM stations in many countries. The unit can receive various types of Radio Data System data, such as “Program Service”, “Program Type,” “Radio Text” and “Clock Time”, when it is tuned into a Radio Data System broadcasting station.

4 MHL

AV

4

5

6

A

V-AUX

USB

NET

B ZONE

AUDIO TUNER FM

AM PRESET

TUNING

INFO

INFO

MEMORY

MOVIE

MUSIC


ENHANCER

DIRECT

1

SLEEP SCENE BD DVD

TV

NET

RADIO

OPTION

SETUP

DISPLAY

TOP MENU

POP-UP MENU

Tune into the desired Radio Data System broadcasting station.

OPTION

VOLUME

ENTER RETURN

■ Displaying the Radio Data System information

MUTE

MODE

1

2

3

4

5

6

7

8

9

0

10


• We recommend using “Auto Preset” to tune into the Radio Data System broadcasting stations (p.44).

2

Press INFO.

INFO

1

When “TUNER” is selected as the input source, press OPTION.

2

Use the cursor keys to select “Traffic Program” (Traffirogram) and press ENTER. The traffic information station search will start in 5 seconds. Press ENTER again to start the search immediately.

• To search upward/downward from the current frequency, press the cursor keys (q/w) while “READY” is displayed.

VOL. STEREO TUNED

ProgramType

L SL

SW C

R SR

ENT

• To cancel the search, press RETURN. • Texts in parentheses denote indicators on the front display.

TV

MUTE

When “TUNER” is selected as the input source, the unit automatically receives traffic information. To enable this function, follow the procedure below to set the traffic information station.

Each time you press the key, the displayed item changes.

Item name

INPUT TV VOL

■ Receiving traffic information automatically

TV CH

About 3 seconds later, the corresponding information for the displayed item appears.

9850

VOL.

CLASSICS

SW C

FINISH

VOL. STEREO TUNED

TPFM101.30MHz

STEREO TUNED L SL

The following screen appears for about 3 seconds when the search finishes.

L SL

SW C

R SR

R SR

Traffic information station (frequency) Information Program Service Program service name Program Type

Current program type

Radio Text

Information on the current program

Clock Time

Current time

DSP Program

Sound mode name

Audio Decoder

Decoder name

Frequency

Frequency

• “TP Not Found” appears for about 3 seconds when no traffic information stations are found.


En

46

Playing back iPod music You can play back iPod music on the unit using a USB cable supplied with the iPod.

Connecting an iPod Connect your iPod to the unit with the USB cable supplied with the iPod.

• An iPod may not be detected by the unit or some features may not be compatible, depending on the model or software version of the iPod. • To play back iPod videos on the unit, an Apple Composite AV Cable (not supplied) is required. Connect the USB and composite video plugs of the Apple Composite AV cable to the USB jack and VIDEO AUX (VIDEO) jack of the unit, and connect your TV and the unit with a video pin cable (p.22). To select a video, operate the iPod itself in the simple play mode (p.49).

1

Connect the USB cable to the iPod.

2

Connect the USB cable to the USB jack.

ed iPod (as of December 2012) • iPod touch (1st, 2nd, 3rd and 4th generation) • iPod nano (2nd, 3rd, 4th, 5th and 6th generation) • iPhone 4S, iPhone 4, iPhone 3GS, iPhone 3G, iPhone • iPad (3rd generation), iPad 2, iPad

The unit (front) RADIO

VIDEO AUX

STRAIGHT

AUDIO

USB

VIDEO

5V

2.1A

VOL.

Connected

L SL

SW C

R SR

• The iPod charges while it is connected to the unit. If you set the unit to standby mode while the iPod is charging, the iPod continues to charge up to 4 hours. If “Network Standby” (p.81) in the “Setup” menu is set to “On”, it continues to change without limit.

• Disconnect the iPod from the USB jack when it is not in use.

PLAYBACK ➤ Playing back iPod music

En

47

Playback of iPod content

CODE SET

SOURCE RECEIVER

Follow the procedure below to operate the iPod contents and start playback.

HDMI

1

2

3

4

• To return to the previous screen, press RETURN. • To switch between the browse and playback screens during playback, press DISPLAY.

MHL

1

2

3

5

4

5

6

A

V-AUX

USB

NET

You can control the iPod with the menu displayed on the TV screen.

AV

B

USB

• Operations with TV screen are available only when your TV is connected to the unit via HDMI. If not, carry out operations while viewing the front display, or directly operate the iPod itself in the simple play mode (p.49).

ZONE

AUDIO TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

TUNING

1

DIRECT

SLEEP

TV

NET

4 iPod Music

Press USB to select “USB” as the input source.

2

RADIO

Playlists Artists Albums Songs Genres Composers

5

OPTION

SETUP

VOLUME

ENTER RETURN

DISPLAY

TOP MENU

POP-UP MENU

MUTE

3

iPod Top


Music Videos

1/6 [DISPLAY] to Now Playing

1 List name

DISPLAY

2 Contents list

MODE

Displays the list of iPod content. Use the cursor keys to select an item and press ENTER to confirm the selection.

1/2 1

1

The browse screen is displayed on the TV.

SCENE BD DVD

■ Browse screen

• “_” (underscore) will be displayed for characters not ed by the unit.


ENHANCER

• To operate the iPod manually to select content or control playback, switch to the simple play mode (p.49).

2

3

5

6

7

9

0

10

4

3 Item number/total

8

4 Status indicators

ENT

TV INPUT TV VOL

• If playback is ongoing on your iPod, the playback screen is displayed.

TV CH

MUTE

2

Use the cursor keys to select an item and press ENTER. If a song is selected, playback starts and the playback screen is displayed.

Display the current repeat/shuffle settings (p.50) and playback status (such as play/pause).

5 Operation menu Press the cursor key (r) and then use the cursor keys (q/w) to select an item. Press ENTER to confirm the selection. Icon

Function Moves 10 pages backward. Moves to the previous page of the list.

iPod Now Playing

Moves to the next page of the list.

Artist Name Album Name Song Title 2:30

[DISPLAY] to List Browse

Moves 10 pages forward. 5:10

Moves to the playback screen.


En

48

■ Playback screen

CODE SET

SOURCE RECEIVER

1

HDMI

1

2

3

2

3

4

1

iPod Now Playing

MHL

1

■ Operating the iPod itself or remote control (simple play)

5

4

5

6

A

V-AUX

USB

NET

B

Album Name

2

Song Title 2:30

ZONE

Press MODE to switch to the simple play mode. The TV menu screen turns off and iPod operations are enabled.

Artist Name

AV

5:10

To display the TV menu screen, press MODE again.

AUDIO TUNER


FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

TUNING


ENHANCER

1 Status indicators

DIRECT


SLEEP SCENE BD DVD

TV

NET

2 Playback information VOLUME

ENTER RETURN

DISPLAY D

TOP MENU

POP-UP MENU


2

3

5

6

7

9

0

10

TV VOL MUTE

Function

4

Cursor keys

Select an item.

ENTER

Confirms the selection.

Use the following remote control keys to control playback.

RETURN

Returns to the previous screen. a

Function

External device operation keys

a

Resumes playback from pause.

MODE

s

Stops playback.

d

Stops playback temporarily.

8

ENT

f

TV INPUT

Operational remote control keys

Displays the artist name, album name, song title, and elapsed time/song length.


MUTE

MODE

1

Operate your iPod itself or the remote control to start playback.

RADIO

OPTION

SETUP

2

TV CH

g

Skips forward/backward.


d

Starts playback or stops playback temporarily.

s

Stops playback.

f g h j


Searches forward/backward (while holding down).

h j

Searches forward/backward (by holding down).


En

49

■ Repeat/shuffle settings

CODE SET

You can configure the repeat/shuffle settings of your iPod.

SOURCE RECEIVER

HDMI

1

2

3

1

2

3

4

5

A

MHL

• During simple play, configure the repeat/shuffle settings directly on your iPod or press MODE to display the TV menu screen and then follow the procedure below.

AV

4

5

6

V-AUX

USB

NET

B ZONE

AUDIO TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

When “USB” is selected as the input source, press OPTION.

2

Use the cursor keys to select “Shuffle” (Shuffle) or “Repeat” (Repeat) and press ENTER.

TUNING


ENHANCER

1

DIRECT

SLEEP SCENE BD DVD

TV

NET

RADIO

OPTION

SETUP

• To return to the previous screen during menu operations, press RETURN.

OPTION

• Texts in parentheses denote indicators on the front display. VOLUME

ENTER RETURN

DISPLAY

TOP MENU

POP-UP MENU


3

Use the cursor keys (e/r) to select a setting.

MUTE

Item

Setting

Function

Off (Off)

Turns off the shuffle function.

Songs (Songs)

Plays back songs in random order. “x” appears in the TV screen.

Albums (Albums)

Plays back albums in random order. “x” appears in the TV screen.

Off (Off)

Turns off the repeat function.

One (One)

Plays back the current song repeatedly. “c” appears in the TV screen.

All (All)

Plays back all songs repeatedly. “v” appears in the TV screen.

MODE

MODE

1

2

3

4

5

6

7

8

9

0

10

Shuffle (Shuffle)

ENT

TV INPUT TV VOL

TV CH

MUTE

Repeat (Repeat)

4



En

50

Playing back music stored on a USB storage device

CODE SET

SOURCE RECEIVER

You can play back music files stored on a USB storage device on the unit. Refer to the instruction manuals for the USB storage device for more information.

HDMI

1

2

3

4 MHL

1

2

3

5

4

5

6

A

V-AUX

USB

NET

AV

B

USB

• If the USB storage device contains many files, it may take time to load the them. In this case, “Loading...” appears in the front display.

The unit s USB mass storage class devices (FAT16 or FAT32 format).

ZONE

• Disconnect the USB storage device from the USB jack when it is not in use.

AUDIO TUNER FM

• Stop playback of the USB storage device before disconnect it from the USB jack.

AM PRESET

INFO

MEMORY

MOVIE

MUSIC

TUNING


ENHANCER

DIRECT

• The unit is compatible with sampling rate of up to 192 kHz for WAV and FLAC files, and 48 kHz for other files.

RADIO

• Some features may not be compatible, depending on the model or manufacturer of the USB storage device.

SLEEP SCENE BD DVD

TV

NET

• The unit s WAV (PCM format only), MP3, WMA, MPEG-4 AAC and FLAC files (1- or 2-channel audio only).

OPTION

SETUP

• Digital Rights Management (DRM) contents cannot be played back.

DISPLAY

TOP MENU

POP-UP MENU

1

2

3

4

5

6

7

8

You can control the USB memory device with the menu displayed on the TV screen.

1

Connect the USB storage device to the USB jack.


The unit (front)


1

RADIO

9

10

0

ENT

TV

VIDEO AUX

STRAIGHT

TV VOL

Follow the procedure below to operate the USB storage device contents and start playback.

MUTE

MODE

INPUT

Playback of USB storage device contents

Connecting a USB storage device

VOLUME

ENTER RETURN

• You cannot connect the PC to the USB jack of the unit.

Press USB to select “USB” as the input source. The browse screen is displayed on the TV.

TV CH

MUTE AUDIO

VIDEO

5V

2.1A

USB Top Blues Classical Electronica Jazz Pop Rock Soundtrack Speaking 1/12

USB storage device

USB

Connected

• If playback is ongoing on your USB storage device, the playback screen is displayed.

VOL.

L SL

SW C

R SR

PLAYBACK ➤ Playing back music stored on a USB storage device

En

51

2

CODE SET

SOURCE RECEIVER

■ Browse screen

Use the cursor keys to select an item and press ENTER.

1

HDMI

1

2

3

2

3

5

If a song is selected, playback starts and the playback screen is displayed.

4 MHL

1

AV

4

5

6

A

V-AUX

USB

NET

B

2 USB Now Playing

ZONE

AUDIO TUNER FM

PRESET INFO

MEMORY

MOVIE

MUSIC

TUNING

Blues Classical Electronica Jazz Pop Rock Soundtrack Speaking

3

Artist Name

AM

4

USB Top

5


Album Name Song Title


ENHANCER

2:30

1 List name


2 Contents list

DIRECT

SLEEP SCENE BD DVD

TV

NET

Displays the list of USB storage device contents. Use the cursor keys to select an item and press ENTER to confirm the selection.

RADIO

OPTION

SETUP

3 Item number/total VOLUME

ENTER RETURN

DISPLAY

TOP MENU

POP-UP MENU

MUTE

• To switch between the browse and playback screens during playback, press DISPLAY.

4 Status indicators Display the current repeat/shuffle settings (p.53) and playback status (such as play/pause).

5 Operation menu 2

3

5

6

7

9

0

10 TV

TV VOL

4

8

Press the cursor key (r) and then use the cursor keys (q/w) to select an item. Press ENTER to confirm the selection. Icon

Function

ENT

Moves 10 pages backward.

INPUT

MUTE

DISPLAY

• To return to the previous screen, press RETURN.

• Files not ed by the unit cannot be selected.

MODE

1


TV CH

Moves to the previous page of the list. Moves to the next page of the list. Moves 10 pages forward. Moves to the playback screen.


En

52

■ Playback screen

CODE SET

■ Repeat/shuffle settings You can configure the repeat/shuffle settings for playback of USB storage device contents.

SOURCE RECEIVER

HDMI

1

2

3

1

2

3

USB Now Playing

4 MHL

1

5

Artist Name

AV

4

5

6

V-AUX

USB

NET

A


B

AUDIO TUNER AM

INFO

MEMORY

MOVIE

MUSIC

PRESET


ENHANCER

1 Status indicators

TV

NET

RADIO

OPTION

SETUP

OPTION

VOLUME

ENTER DISPLAY D

TOP MENU

POP-UP MENU


MUTE

MODE

External device operation keys 1

2

3

4

5

6

7

8

9

0

10

ENT

2 Playback information Displays the artist name, album name, song title, and elapsed time. Use the following remote control keys to control playback. External device operation keys

TV CH


s

Stops playback.

d


f g


3


Item

Function

a

TV INPUT



DIRECT

SCENE

TV VOL


TUNING

SLEEP

RETURN

2


FM

BD DVD

When “USB” is selected as the input source, press OPTION.

2

2:30

ZONE

1


Shuffle (Shuffle)

Repeat (Repeat)

MUTE

4

Setting

Function

Off (Off)


On (On)

Plays back songs in the current album (folder) in random order. “x” appears on the TV screen.

Off (Off)


One (One)

Plays back the current song repeatedly. “c” appears on the TV screen.

All (All)

Plays back all songs in the current album (folder) repeatedly. “v” appears on the TV screen.



En

53

Playing back music stored on media servers (PCs/NAS)

CODE SET

SOURCE RECEIVER

2

3

4 MHL

1

2

3

5

A

Playback of PC music contents

You can play back music files stored on your PC or DLNA-compatible NAS on the unit.

HDMI

1

Follow the procedure below to operate the PC music contents and start playback.

AV

4

5

6

V-AUX

USB

NET

ZONE

• To use this function, the unit and your PC must be connected to the same router (p.28). You can check whether the network parameters (such as the IP address) are properly assigned to the unit in “Information” (p.80) in the “Setup” menu.

TUNING

• The unit s playback of WAV (PCM format only), MP3, WMA, MPEG-4 AAC and FLAC files.

B

NET

AUDIO TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET


ENHANCER

DIRECT

SLEEP SCENE BD DVD

TV

NET

RADIO

• The unit is compatible with sampling rates of up to 192 kHz for WAV and FLAC files, and 48 kHz for other files.


• To play back FLAC files, you need to install server software that s sharing of FLAC files via DLNA on your PC or use a NAS that s FLAC files.


1

OPTION

SETUP

VOLUME

ENTER RETURN

DISPLAY

TOP MENU

POP-UP MENU

MUTE

MODE

1

2

3

4

5

6

7

8

9

0

10

ENT

Cursor keys ENTER

You can control the PC/NAS with the menu displayed on the TV screen.

Media sharing setup

Press NET repeatedly to select “SERVER” as the input source. The browse screen is displayed on the TV.

To play back music files stored on your PC or DLNA-compatible NAS, first you need to configure the media sharing setting on each music server.

SERVER Media Server DESKTOP NAS A NAS B NOTE

■ For a PC with Windows Media Player installed


TV CH

1

Check that Windows Media Player 11 or later is installed on your PC.

2

In the media sharing settings, enable media sharing and allow media to be shared with the device.

■ For a PC or a NAS with other DLNA server software installed

1/4

• If playback of a music file selected from the unit is ongoing on your PC, the playback screen is displayed.

2

Use the cursor keys to select a music server and press ENTER.

Refer to the instruction manual for the device or software and configure the media sharing settings.

PLAYBACK ➤ Playing back music stored on media servers (PCs/NAS)

En

54

3

CODE SET

SOURCE RECEIVER


■ Browse screen 1

HDMI

1

2

3

2

3

5

If a song is selected, playback starts and the playback screen is displayed.

4 MHL

1

AV

4

5

6

A

V-AUX

USB

NET

B

2 SERVER Now Playing

ZONE

AUDIO TUNER FM

PRESET INFO

MEMORY

MOVIE

MUSIC

TUNING

Blues Classical Electronica Jazz Pop Rock Soundtrack Speaking

3

Artist Name

AM

4

SERVER NAS A

5 1/14

[DISPLAY] to Now Playing



ENHANCER

2:30

1 List name


2 Contents list

DIRECT

SLEEP SCENE BD DVD

TV

NET

Displays the list of PC content. Use the cursor keys to select an item and press ENTER to confirm the selection.

RADIO

OPTION

SETUP


ENTER RETURN

DISPLAY

TOP MENU

POP-UP MENU

MUTE

2

3

5

6

7

9

0

10

• To switch between the browse and playback screens during playback, press DISPLAY. • Files not ed by the unit cannot be selected.

4 Status indicators Display the current repeat/shuffle settings (p.56) and playback status (such as play/pause).

TV VOL

4

8


Function

ENT

Moves 10 pages backward.

TV INPUT

MUTE

DISPLAY

• To return to the previous screen, press RETURN.

5 Operation menu

MODE

1


TV CH

Moves to the previous page of the list. Moves to the next page of the list. Moves 10 pages forward. Moves to the playback screen.


En

55

■ Playback screen

CODE SET

■ Repeat/shuffle settings You can configure the repeat/shuffle settings for the playback of PC music content.

SOURCE RECEIVER

HDMI

1

2

3

1

2

3

SERVER Now Playing

4 MHL

1

5

Artist Name

AV

4

5

6

V-AUX

USB

NET

A


B

AUDIO TUNER AM

INFO

MEMORY

MOVIE

MUSIC

PRESET


ENHANCER

1 Status indicators

TV

NET

RADIO

OPTION

SETUP

OPTION

VOLUME

ENTER DISPLAY D

TOP MENU

POP-UP MENU


MUTE

2 Playback information Displays the artist name, album name, song title, and elapsed time.

Use the following remote control keys to control playback. External device operation keys


Function

2

3

4

5

6

7

8

9

0

10

a


s

Stops playback.

d


ENT

INPUT TV VOL

TV CH

g

3


Shuffle (Shuffle)

Repeat (Repeat)

f

TV

• Text in parentheses denotes indicators on the front display.

Item

MODE

1



DIRECT

SCENE

MUTE


TUNING

SLEEP

RETURN

2


FM

BD DVD

When “SERVER” is selected as the input source, press OPTION.

2

2:30

ZONE

1


• You can also use a DLNA-compatible Digital Media Controller (DMC) to control playback. For details, see “DMC Control” (p.81).

4

Setting

Function

Off (Off)


On (On)

Plays back songs in the current album (folder) in random order. “x” appears on the TV screen.

Off (Off)


One (One)

Plays back the current song repeatedly. “c” appears on the TV screen.

All (All)

Plays back all songs in the current album (folder) repeatedly. “v” appears on the TV screen.



En

56

Listening to Internet radio

CODE SET

SOURCE RECEIVER

You can listen to Internet radio stations from all over the world.

HDMI

1

2

3

4

You can control the Internet radio with the menu displayed on the TV screen.

MHL

1

2

3

5

A

AV

4

5

6

V-AUX

USB

NET

B

1

Press NET repeatedly to select “NET RADIO” as the input source. The browse screen is displayed on the TV.

NET

ZONE


AUDIO TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

TUNING


ENHANCER

• You may not be able to receive some Internet radio stations.

SCENE TV

NET

RADIO

• The unit uses the vTuner Internet radio station database service.

OPTION

SETUP

VOLUME

ENTER RETURN

DISPLAY

TOP MENU

POP-UP MENU

Bookmarks Locations Genres New Stations Popular Stations Podcasts Help

• This service may be discontinued without notice.

DIRECT

SLEEP

BD DVD

NET RADIO Top

• To use this function, the unit must be connected to the Internet (p.28). You can check whether the network parameters (such as the IP address) are properly assigned to the unit in “Information” (p.80) in the “Setup” menu.

MUTE


DISPLAY

1/7

2

Use the cursor keys to select an item and press ENTER. If an Internet radio station is selected, playback starts and the playback screen is displayed.

MODE

1

2

3

5

6

7

9

0

10

4

8

ENT

NET RADIO Now Playing


TV CH

Station Name Album Name Song Title 2:30


• To return to the previous screen, press RETURN. • To switch between the browse and playback screens during playback, press DISPLAY. • You can your favorite Internet radio stations to the “Bookmarks” folder by selecting “NET RADIO” as the input source on the unit and then accessing the following website with the web browser on your PC. To use this feature, you need the vTuner ID of the unit and your e-mail address to create your personal . You can check the vTunerID (MAC address of the unit) in “Information” (p.80) in the “Setup” menu.

http://yradio.vtuner.com/

PLAYBACK ➤


En

57

■ Browse screen

CODE SET

■ Playback screen

SOURCE RECEIVER

1

HDMI

1

2

3

1

2

3

5

AV

4

5

6

A

V-AUX

USB

NET

B

2

ZONE

4

NET RADIO Top

4 MHL

1

NET RADIO Now Playing

Bookmarks Locations Genres New Stations Popular Stations Podcasts Help

5

Station Name

2

Album Name Song Title 2:30

AUDIO TUNER FM

3

AM PRESET

INFO

MEMORY

MOVIE

MUSIC

TUNING


ENHANCER

SCENE TV

NET

1 List name

1 Playback indicator

2 Contents list

2 Playback information

Displays the list of Internet radio content. Use the cursor keys to select an item and press ENTER to confirm the selection.

RADIO

OPTION

SETUP


DIRECT

SLEEP

BD DVD


Displays the station name, album name, song title, and elapsed time.


ENTER RETURN

DISPLAY D

TOP MENU

POP-UP MENU

Cursor keys ENTER

MUTE


3

4

5

6

7

8

9

0

10 TV

MUTE


Function Moves 10 pages backward.

ENT

Moves to the previous page of the list.

INPUT TV VOL

• Some information may not be available depending on the station.

5 Operation menu

MODE

1

• Use the external device operation key (s) to stop playback.


TV CH

Moves to the next page of the list. Moves 10 pages forward. Moves to the playback screen.

PLAYBACK ➤


En

58

Playing back iTunes/iPod music via a network (AirPlay) The AirPlay function allows you to play back iTunes/iPod music on the unit via network.

Playback of iTunes/iPod music contents Follow the procedure below to play back iTunes/iPod music contents on the unit.

iTunes PC

1 Router The unit Starts playback on iTunes or iPod

Turn on the unit, and start iTunes on the PC or display the playback screen on the iPod. If the iTunes/iPod recognizes the unit, the AirPlay icon ( ) appears. iTunes (example)

iPod (example)

Playback starts

iPod

• To use this function, the unit and your PC or iPod must be connected to the same router (p.28). You can check whether the network parameters (such as the IP address) are properly assigned to the unit in “Information” (p.80) in the “Setup” menu.

ed iTunes/iPod (as of December 2012)

• If the icon does not appear, check whether the unit and PC/iPod are connected to the router properly.

2

• iTunes 10.2.2 or later (Windows/Mac)

On the iTunes/iPod, click (tap) the AirPlay icon and select the unit (network name of the unit) as the audio output device.

• iPod touch, iPhone or iPad with iOS 4.3.3 or later

iTunes (example)

iPod (example)

Network name of the unit

3

Select a song and start playback.

The unit automatically selects “AirPlay” as the input source and starts playback. The playback screen is displayed on the TV.

• The playback screen is available only when your TV is connected to the unit via HDMI.

PLAYBACK ➤ Playing back iTunes/iPod music via a network (AirPlay)

En

59

Use the following remote control keys to control playback. CODE SET

• You can turn on the unit automatically when starting playback on iTunes or iPod by setting “Network Standby” (p.81) in the “Setup” menu to “On”.

SOURCE RECEIVER

HDMI

1

2

3

4

2

3

5

• You can edit the network name (the unit’s name on the network) displayed on iTunes/iPod in “Network Name” (p.81) in the “Setup” menu.

MHL

1

• If you select the other input source on the unit during playback, playback on the iTunes/iPod stops automatically.

AV

4

5

6

A

V-AUX

USB

NET

B

• You can adjust the unit’s volume from the iTunes/iPod during playback. To disable volume controls from iTunes/iPod, set “Volume Interlock” (p.67) in the “Option” menu to “Off”.

ZONE

AUDIO TUNER FM

AM PRESET MEMORY

MOVIE

MUSIC

ENHANCER

• When you use iTunes/iPod controls to adjust volume, the volume may be unexpectedly loud. This could result in damage to the unit or speakers. If the volume suddenly increases during playback, stop playback on the iTunes/iPod immediately.

DIRECT

SCENE TV

NET

RADIO

OPTION

SETUP

s

Stops playback.

d


f Skips forward/backward.

• To control iTunes playback with the remote control of the unit, you need to configure the iTunes preferences to enable iTunes control from remote speakers in advance.

iTunes (example of English version)

■ Playback screen

VOLUME

ENTER DISPLAY D

TOP MENU

POP-UP MENU

MUTE

1

AirPlay Now Playing

MODE


2

3

4

5

6

7

8

Artist Name Album Name

2

Song Title 2:30 9



SLEEP

RETURN

a

g

TUNING

Function

Caution

INFO

BD DVD


10

0

5:30

ENT

TV INPUT TV VOL

TV CH

MUTE


Check this box

2 Playback information Displays the artist name, album name, song title, and elapsed time/song length.

PLAYBACK ➤ Playing back iTunes/iPod music via a network (AirPlay)

En

60

Playing back music in multiple rooms (HTR-5066 only) The Zone A/B function allows you to play back an input source in the room where the unit is installed (Zone A) and in another room (Zone B). For example, you can turn on Zone A (turn off Zone B) when you are in the living room, and turn on Zone B (turn off Zone A) when you are in the study room. Also, you can turn on both zones when you want to enjoy the same input source in those rooms simultaneously.

Preparing Zone B Connect the device that will be used in Zone B to the unit. Caution • Remove the unit’s power cable from the AC wall outlet before connecting speakers. • Ensure that the core wires of the speaker cable do not touch one another or come into with the unit’s metal parts. Doing so may damage the unit or the speakers. If the speaker cables short circuit, “Check SP Wires” will appear on the front display when the unit is turned on.

Connect the speakers placed in Zone B to the unit with speaker cables. To utilize the SURROUND BACK/BI AMP/ZONE B jacks for Zone B speakers, set “Power Amp Assign” (p.71) in the “Setup” menu to “Zone B” after connecting the power cable to an AC wall outlet. Study room (Zone B)

The unit (rear) SPEAKERS PB FRONT

CENTER

SURROUND


Y OR OUT 1

Living room (Zone A) 2 SUBWOOFER PRE OUT

• Multichannel sources are mixed down to 2 channels and output to the zone B. • The same input source is applied to both Zone A and Zone B. • By default, the volume for Zone B changes in conjunction with the volume for Zone A. If there is volume difference between Zone A/B, you can correct it in “ZoneB Trim” in the “Option” menu (p.62). Also, you can adjust the volume for Zone B separately (p.62).

1 1

9

2

2

3

• You can automatically enable/disable the audio output to Zone A/B in conjunction with a scene selection (p.36) 4

5

Zone B

Zone A

PLAYBACK ➤ Playing back music in multiple rooms (HTR-5066 only)

En

61

■ Basic playback procedure

CODE SET

SOURCE RECEIVER

SOURCE/RECEIVER

2

3

Press ZONE A or ZONE B to enable/disable audio output to Zone A or Zone B.

ZONE A ZONE B

“SP A” lights up in the front display when the Zone A output is enabled and “SP B” lights up when the Zone B output is enabled.

4 MHL

1

2

3

5

4

5

6

A

V-AUX

USB

NET

1


HDMI

1

AV

B ZONE

3

Setting range -10.0 dB to +10.0 dB (0.5 dB increments) Default 0.0 dB

AUDIO TUNER FM

“SP A” and/or “SP B” light up

AM PRESET MEMORY MUSIC

SP A SP B


ENHANCER

DIRECT

SCENE (BD/DVD) SCENE (TV)

RADIO

OPTION

SLEEP SCENE BD DVD

TV

NET OPTION

SETUP

VOLUME

ENTER RETURN

VOLUME

DISPLAY

TOP MENU

POP-UP MENU

MUTE

1

2

3

4

5

6

7

8

9

0

10 TV

INPUT TV VOL

TV CH

ENT

HDMI1

L SL

SW C

• This setting is not effective when “ZoneB Volume” (p.77) in the “Setup” menu is set to “Async.”.

Use the input selection keys to select an input source.

3

Start playback on the external device or select a radio station.

4

Press VOLUME to adjust the volume.

■ Correcting volume difference between Zone A and Zone B If you are bothered by volume difference between Zone A/B, follow the procedure below to adjust the volume for Zone B.

1 2


R SR

2

MUTE Cursor keys ENTER RETURN

MODE

MUTE

4

TUNING

VOL.

INFO MOVIE

Use the cursor keys (q/w) to select “ZoneB Trim” (ZB.Trim) and the cursor keys (e/r) to adjust the setting.

Press OPTION. Use the cursor keys to select “Volume Trim” (Volume Trim) and press ENTER.

You can separately adjust the volume for Zone B using the remote control when “ZoneB Volume” (p.77) in the “Setup” menu is set to “Async.”.

1

To set the remote control to the Zone B operation mode, while holding down the cursor key (r), hold down SCENE (TV) for more than 3 seconds. SOURCE/RECEIVER blinks twice.

2

Press VOLUME to adjust the volume for Zone B.

• To mute the audio output to Zone B, press MUTE.

3

• To return to the previous screen during menu operations, press RETURN. • Text in parentheses denotes indicators on the front display.

■ Adjusting the volume for Zone B separately

To set the remote control to the Zone A operation mode, while holding down the cursor key (r), hold down SCENE (BD/DVD) for more than 3 seconds. SOURCE/RECEIVER blinks twice.

PLAYBACK ➤ Playing back music in multiple rooms (HTR-5066 only)

En

62

Viewing the current status

CODE SET

SOURCE RECEIVER

HDMI

1

2

3

1

2

3

4

5

A

Switching information on the front display

MHL

AV

4

5

6

V-AUX

USB

NET

1

B ZONE

AUDIO TUNER

Press INFO. Each time you press the key, the displayed item changes. VOL.

FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

TUNING

AudioDecoder

INFO SUR. DECODE STRAIGHT

ENHANCER

L SL

SW C

R SR

Item name

DIRECT

SLEEP SCENE BD DVD

TV

NET

RADIO

OPTION

SETUP

About 3 seconds later, the corresponding information for the displayed item appears. VOL.

VOLUME

ENTER RETURN

ProLogic

DISPLAY

TOP MENU

POP-UP MENU

L SL

SW C

R SR

Information

MUTE

MODE

1

2

3

4

5

6

7

8

9

0

10 TV

INPUT TV VOL MUTE

TV CH

ENT

• Available items vary depending on the selected input source. The displayed item can also be applied separately to each input source group.

Input source group

Item

HDMI 1–5 AV 1–6 AUDIO V-AUX

Input (input source name), DSP Program (sound mode name), Audio Decoder (decoder name*)

USB SERVER AirPlay

NET RADIO

Song (song title), Artist (artist name), Album (album name), DSP Program (sound mode name), Audio Decoder (decoder name*) * During simple playback of iPod: Input (input source name), DSP Program (sound mode name), Audio Decoder (decoder name)

Song (song title), Album (album name), Station (station name), DSP Program (sound mode name), Audio Decoder (decoder name*) Frequency (frequency), DSP Program (sound mode name), Audio Decoder (decoder name*)

TUNER

* (U.K. and Europe models only) Radio Data System data is also available when the unit is tuned into a Radio Data System broadcasting station (p.46).

* The name of the audio decoder currently activated is displayed. If no audio decoder is activated, “Decoder Off” appears.

PLAYBACK ➤ Viewing the current status

En

63

Configuring playback settings for different playback sources (Option menu) You can configure separate playback settings for different playback sources. This menu is available on the front (or on the TV screen), allowing you to easily configure settings during playback.

1

Press OPTION.

Option menu items • Available items vary depending on the selected input source. • Text in parentheses denotes indicators on the front display.

OPTION

VOL.

ToneControl

L SL

SW C

R SR

• Depending on the region of purchase, some menu items for audio streaming services are also available. For details, refer to each manual on the supplied CD-ROM.

Item

Function

Tone Control (Tone Control)

Adjusts the high-frequency range and low-frequency range of sounds.

65

DSP Level (DSP Level)

Adjusts the sound field effect level.

65

Adaptive DRC (A.DRC)

Sets whether the dynamic range (from maximum to minimum) is automatically adjusted when the volume is adjusted.

65

(HTR-5066 only) Selects how to play back 5.1- to 7.1-channel sources when surround back speakers are used.

65

Front display

Option Tone Control DSP/Surround Volume Trim Lipsync Signal Info Audio In

2

TV screen

Enhancer (Enhancer)

Enables/disables Compressed Music Enhancer.

66


Input Trim (In.Trim)

Corrects volume differences between input sources.

66


3 4

DSP/Surround (DSP/Surround) Extended Surround (EXTD)

Page


Volume Trim (Volume Trim)

Subwoofer Trim Fine-adjusts the subwoofer volume. (SW.Trim)

66

(HTR-5066 only) Corrects volume differences between Zone A/B.

62

Lipsync (Lipsync)

Enables/disables the “Lipsync” setting in the “Setup” menu.

66

Signal Info (Signal Info)

Displays information about the video/audio signal.

66

Audio In (Audio In)

Combines the video jack of the selected input source with an audio jack of others.

67

Video Out (Video Out)

Selects a video to be output with radio sounds.

67

Auto Preset (Auto Preset)

Automatically s FM radio stations with strong signals as presets.

44

Clear Preset (Clear Preset)

Clear radio stations ed to preset numbers.

45

ZoneB Trim (ZB.Trim)


PLAYBACK ➤ Configuring playback settings for different playback sources (Option menu)

En

64

(U.K. and Europe models only) Traffic Program (Traffirogram) Automatically searches for a traffic information station.

Page 46

Repeat (Repeat)

Configures the repeat setting for the iPod (p.50), USB storage device (p.53), or media server (p.56).

—

Shuffle (Shuffle)

Configures the shuffle setting for the iPod (p.50), USB storage device (p.53), or media server (p.56).

—

Volume Interlock (Interlock)

Enables/disables volume controls from iTunes/iPod via AirPlay.

67

■ Tone Control (Tone Control)

Setting range -6.0 dB to By (By) to +6.0 dB, *0.5 dB increments Default By (By)

Sets whether the dynamic range (from maximum to minimum) is automatically adjusted when the volume level is adjusted. When it is set to “On”, it is useful for listening to playback at a low volume at night. Settings On (On)

Automatically adjusts the dynamic range.

Off (Off) (default)

The dynamic range is not automatically adjusted.

If “On” is selected, the dynamic range becomes narrow at a low volume and wide at a high volume. Volume: low

Adjusts the high-frequency range (Treble) and low-frequency range (Bass) of sounds. Choices Treble (Treble), Bass (Bass)

❑ Adaptive DRC (A.DRC)

On Off Input level

Volume: high Output level

Function

Output level

Item

On Off Input level

❑ Extended Surround (EXTD) (HTR-5066 only)

• If you set an extreme value, sounds may not match those from other channels.

Selects how to play back 5.1- to 7.1-channel sources when surround back speakers are used. Settings

Adjusting with the front controls a Press TONE CONTROL to select “Treble” or “Bass”. b Press PROGRAM to make an adjustment.

■ DSP/Surround (DSP/Surround)

Auto (Auto) (default)

Automatically selects the most suitable decoder if signals that contain surround back channel signals are input, and reproduces the signals in 6.1- or 7.1-channel. If two surround back speakers are connected, the unit reproduces the 5.1-channel signals in 7.1-channel.

bPLIIx Movie (bPLIIxMo)

Always reproduces signals in 7.1-channel using the Dolby Pro Logic IIx Movie decoder. This setting is available only when two surround back speakers are connected.

bPLIIx Music (bPLIIxMu)

Always reproduces signals in 6.1- or 7.1-channel using the Dolby Pro Logic IIx Music decoder. This setting is available only when one or two surround back speakers are connected.

EX/ES (EX/ES)

Automatically selects the Dolby EX or DTS-ES decoder, and reproduces signals in 6.1- or 7.1-channel.

Off (Off)

Always reproduces signals in their original channels. (Even when DTS-ES or Dolby Digital Surround EX signal is input, the unit reproduces the signal in 5.1-channel.)

Configures the sound field program and surround settings.

❑ DSP Level (DSP Level) Adjusts the sound field effect level. Setting range -6 dB to +3 dB (1 dB increments) Default 0 dB


En

65

■ Lipsync (Lipsync) • Some early Dolby Digital EX or DTS-ES sources do not contain a flag for reproducing surround back channel. We recommend you set “Extended Surround” to “bPLIIx Movie” or “EX/ES” when playing back those sources.

Enables/disables the adjustment configured in “Lipsync” (p.76) in the “Setup” menu.

❑ Enhancer (Enhancer)

• This setting is applied separately to each input source.

Settings

Enables/disables Compressed Music Enhancer (p.42).

• This setting is applied separately to each input source. • You can also use ENHANCER on the remote control to enable/disable Compressed Music Enhancer (p.42).

Settings Off (Off)

Disables Compressed Music Enhancer.

On (On)

Enables Compressed Music Enhancer.

Off (Off)

Disables the “Lipsync” adjustment.

On (On)

Enables the “Lipsync” adjustment.

Default AirPlay: Off (Off) Others: On (On)

■ Signal Info (Signal Info) Displays information about the video/audio signal.

Default USB, SERVER, NET RADIO, AirPlay, TUNER: On (On) Others: Off (Off)

Choices

■ Volume Trim (Volume Trim)

Format (FORMAT)

Audio format of the input signal

Channel (CHAN)

The number of source channels in the input signal (front/surround/LFE) For example, “3/2/0.1” means 3 front channels, 2 surround channels, and LFE.

Fine-adjusts volume difference between input sources or subwoofer volume.

❑ Input Trim (In.Trim) Corrects volume differences between input sources. If you are bothered by volume differences when switching between input sources, use this function to correct it.

Sampling (SAMPL)

The number of samples per second of the input digital signal

Bitrate (B RATE)

The amount of data per second of the input bitstream signal

Input (V IN)

Type and resolution of input signal

Output (V OUT)

Type and resolution of output signal

• This setting is applied separately to each input source.

Setting range -6.0 dB to +6.0 dB (0.5 dB increments)

• To switch the information on the front display, press the cursor keys (q/w) repeatedly.

Default 0.0 dB

❑ Subwoofer Trim (SW.Trim) Fine-adjusts the subwoofer volume. Setting range -6.0 dB to +6.0 dB (0.5 dB increments) Default 0.0 dB


En

66

■ Audio In (Audio In)

■ Volume Interlock (Interlock)

Combines the video jack of the selected input source (HDMI 1–5 or AV 1–2) with an audio jack of others. For example, use this function in the following cases.

Enables/disables volume controls from iTunes/iPod via AirPlay.

• Connecting a playback device that s HDMI video output, but not HDMI audio output • Connecting a playback device that has component video jacks and analog stereo jacks (such as game consoles) Input sources HDMI 1–5, AV 1–2

Settings Off (Off)

Disables volume controls from iTunes/iPod.

Limited (Ltd) (default)

Enables volume controls from iTunes/iPod within the limited range (-80 dB to 0 dB and mute).

Full (Full)

Enables volume controls from iTunes/iPod in the full range (-80 dB to +16.5 dB and mute).

■ Setup procedure (To input audio through a digital optical jack) Select “AV 1” or “AV 4” and connect the device to the unit’s corresponding audio jacks with a digital optical cable. (To input audio through a digital coaxial jack) Select “AV 2” or “AV 3” and connect the device to the unit’s corresponding audio jacks with a digital coaxial cable. (To input audio through analog audio jacks) Select “AV 5”, “AV 6”, or “AUDIO”, and connect the device to the unit’s corresponding audio jacks with a stereo pin cable.

■ Video Out (Video Out) Selects a video to be output with radio sounds. Settings Off (Off) (default)

Does not output video.

HDMI 1–5, AV 1–6, V-AUX

Outputs video input through the corresponding video input jacks.


En

67

CONFIGURATIONS Configuring various functions (Setup menu) You can configure the unit’s various function with the menu displayed on the TV screen.


1 2

Press SETUP. Use the cursor keys to select a menu and press ENTER.

Setup Speaker

Configuration

HDMI

Distance

Sound

Level

ECO

Equalizer

Function

Test Tone

Network Language

3


Setup Speaker

Configuration

HDMI

Distance

Sound

Level

ECO

Equalizer

Function

Test Tone

Network Language


4 5

Use the cursor keys (e/r) to select a setting and press ENTER. To exit from the menu, press SETUP. CONFIGURATIONS

➤ Configuring various functions (Setup menu)

En

68

Setup menu items Menu

Item

Configuration

Function Power Amp Assign

(HTR-5066 only) Selects a speaker system.

Subwoofer

Selects whether or not a subwoofer is connected.

71

Front

Selects the size of the front speakers.

71

Center

Selects whether or not a center speaker is connected and its size.

71

Surround

Selects whether or not surround speakers are connected and their size.

72

Surround Back

(HTR-5066 only) Selects whether or not surround back speakers are connected and their size.

72

Crossover

Sets the lower limit of the low-frequency component that can be output from speakers whose size is set to “Small”.

72

Subwoofer Phase

Sets the phase of the subwoofer.

72

Extra Bass

Sets the speakers to produce the front channel low-frequency components.

72

Speaker

HDMI

Page 71

Distance

Sets the distance between each speaker and listening position.

73

Level

Adjusts the volume of each speaker.

73

Equalizer

Adjusts the tone with an equalizer.

73

Test Tone

Enables/disables the test tone output.

73

HDMI Control

Enables/disables HDMI Control.

74

Audio Output

Selects a device to output audio.

74

Standby Through

Selects whether to output videos/audio (input through HDMI jacks) to the TV when the unit is in standby mode.

74

TV Audio Input

Selects an audio input jack of the unit to be used for TV audio input.

74

Standby Sync

Selects whether to use HDMI control to link the standby behavior of the TV and the unit.

75

ARC

Enables/disables ARC.

75

SCENE

Enables/disables SCENE link playback.

75

Configuration

CONFIGURATIONS


En

69

Menu

Item

Page

CINEMA DSP 3D Mode

Enables/disables CINEMA DSP 3D.

75

Panorama

Enables/disables the broadening effect of the front sound field.

75

Center Width

Adjusts the broadening effect of the center sound field.

76

Dimension

Adjusts the difference in level between the front and surround sound fields.

76

Center Image

Adjusts the center orientation level (broadening effect) of the front sound field.

76

Select

Selects the method to adjust the delay between video and audio output.

76

Adjustment

Adjusts the delay between video and audio output manually.

76

Dynamic Range

Selects the dynamic range adjustment method for bitstream audio (Dolby Digital and DTS signals) playback.

77

Max Volume

Sets the maximum volume to prevent excessive loudness.

77

Initial Volume

Sets the initial volume for when this receiver is turned on.

77

ZoneB Volume

(HTR-5066 only) Selects whether to adjust the volume for Zone B in conjunction with the volume for Zone A.

77

Auto Power Standby

Sets the amount of time for the auto-standby function.

77

ECO Mode

Enables/disables the eco mode (power saving mode).

78

Input Rename

Changes the input source name displayed on the front display.

78

Dimmer

Adjusts the brightness of the front display.

79

Prevents accidental changes to the settings.

79

Selects how to supply power through the DC OUT jack.

79

Information

Displays the network information on the unit.

80

IP Address

Configures the network parameters (such as IP address).

80

MAC Address Filter

Sets the MAC address filter to limit access to the unit from other network devices.

81

DMC Control

Selects whether to allow a DLNA-compatible Digital Media Controller (DMC) to control playback.

81

DSP Parameter

Sound

Function

Lipsync

Volume

ECO

Function Memory Guard DC OUT

Network

Language

Power Mode

Network Standby

Selects whether to enable/disable the function that turns on the unit from other network devices.

81

Network Name

Edits the network name (the unit’s name on the network) displayed on other network devices.

81

Network Update

Updates the firmware via the network.

82

Select an on-screen menu language.

82

CONFIGURATIONS


En

70

❑ Subwoofer

Speaker

Selects whether or not a subwoofer is connected. Configures the speaker settings manually. Settings Setup Speaker

Configuration

HDMI

Distance

Sound

Level

ECO

Equalizer

Function

Test Tone

Use (default)

Select this option when a subwoofer is connected. The subwoofer will produce LFE (low-frequency effect) channel audio and low-frequency components from other channels.

None

Select this option when no subwoofer is connected. The front speakers will produce LFE (low-frequency effect) channel audio and low-frequency components from other channels.

Network Language

❑ Front Selects the size of the front speakers.

■ Configuration

Settings

Configures the output characteristics of the speakers.

• When you configure the speaker size, select “Large” if the woofer diameter of your speaker is 16 cm (6-1/4”) or larger or “Small” if it is smaller than 16 cm (6-1/4”).

Small (default)

Select this option for small speakers. The subwoofer will produce front channel low-frequency components (configurable in “Crossover”).

Large

Select this option for large speakers. The front speakers will produce all of the front channel frequency components.

❑ Power Amp Assign (HTR-5066 only) Selects a speaker system.

• “Front” is automatically set to “Large” when “Subwoofer” is set to “None”.

In addition to the 5.1- or 7.1-channel speaker system, various speaker configurations are possible using the Zone B speakers or bi-amp connection.

❑ Center Selects whether or not a center speaker is connected and its size.

Settings Basic (default)

Select this option when you use a normal speaker system (not using Zone B speakers or a bi-amp connection).

BI-AMP

Select this option when you connect front speakers that bi-amp connections (p.16).

Zone B

Select this option when you use Zone B speakers (p.61) in addition to the speaker system in the main zone (Zone A).

Settings

Small (default)

Select this option for small speakers. The subwoofer or front speakers will produce center channel low-frequency components (configurable in “Crossover”).

Large

Select this option for large speakers. The center speaker will produce all of the center channel frequency components.

None

Select this option when no center speaker is connected. The front speakers will produce center channel audio.

CONFIGURATIONS


En

71

❑ Surround

❑ Crossover

Selects whether or not surround speakers are connected and their sizes.

Sets the lower limit of the low-frequency components that can be output from a speaker whose size is set to “Small”. A frequency sound lower than the specified value will be produced from the subwoofer or front speakers.

Settings

Small (default)

Select this option for small speakers. The subwoofer or front speakers will produce surround channel low-frequency components (configurable in “Crossover”).

Large

Select this option for large speakers. The surround speakers will produce all of the surround channel frequency components.

None

Select this option when no surround speakers are connected. The front speakers will produce surround channel audio. Virtual CINEMA DSP works when you select a sound program.

❑ Surround Back

Settings 40 Hz, 60 Hz, 80 Hz (default), 90 Hz, 100 Hz, 110 Hz, 120 Hz, 160 Hz, 200 Hz

• If the volume and crossover frequency are adjustable on your subwoofer, set the volume to half and crossover frequency to maximum.

❑ Subwoofer Phase Sets the phase of the subwoofer. When the bass sound is lacking or unclear, switch the subwoofer phase. Settings

(HTR-5066 only) Selects whether or not surround back speakers are connected and their sizes. Settings

Small x1

Select this option when one small speaker is connected. The subwoofer or front speakers will produce surround back channel low-frequency components (configurable in “Crossover”).

Small x2 (default)

Select this option when two small speakers are connected. The subwoofer or front speakers will produce surround back channel low-frequency components (configurable in “Crossover”).

Large x1

Select this option when one large speaker is connected. The surround back speaker will produce all of the surround back channel frequency components.

Large x2

Select this option when two large speakers are connected. The surround back speakers will produce all of the surround back channel frequency components.

None

Select this option when no surround back speakers are connected. The surround speakers and subwoofer (or front speakers) will produce surround back channel audio.

Normal (default)

Does not reverse the subwoofer phase.

Reverse

Reverses the subwoofer phase.

❑ Extra Bass Sets the speakers to produce the front channel low-frequency components. Settings Off (default)

Depending on the size of the front speakers, either the subwoofer or front speakers produce the front channel low-frequency components.

On

Both the front speakers and subwoofer produce the front channel low-frequency components.

• This setting is not available when “Subwoofer” is set to “None”, or when “Front” is set to “Small”.

• “Surround Back” is automatically set to “None” when “Power Amp Assign” is set to “BI-AMP” or “Zone B”, or when “Surround” is set to “None”.

CONFIGURATIONS


En

72

■ Distance Sets the distance between each speaker and listening position so that sounds from the speakers reach the listening position at the same time. First, select the unit of distance from “Meter” or “Feet”.

• “PEQ” is available only when the YPAO has been performed (p.31).

■ Manual equalizer adjustment

Choices Front L, Front R, Center, Surround L, Surround R, Surround Back L (HTR-5066 only), Surround Back R (HTR-5066 only), Subwoofer

1 2

Set “EQ Select” to “GEQ”.

Setting range 0.30 m to 24.00 m (1.0 ft to 80.0 ft), *0.05 m (0.2 ft) increments

3

Use the cursor keys (q/w) to select the desired band (frequency) and the cursor keys (e/r) to adjust the gain.

Default Front L, Front R, Subwoofer: 3.00 m (10.0 ft) Center: 2.60 m (8.6 ft) Others: 2.40 m (8.0 ft)

Use the cursor keys (q/w) to select “Channel” and the cursor keys (e/r) to select the desired speaker channel.

Setting range -6.0 dB to +6.0 dB

Equalizer

■ Level

EQ Select GEQ Edit Channel 63Hz 160Hz 400Hz 1kHz 2.5kHz 6.3kHz 16kHz

Adjusts the volume of each speaker. Choices Front L, Front R, Center, Surround L, Surround R, Surround Back L (HTR-5066 only), Surround Back R (HTR-5066 only), Subwoofer Setting range -10.0 dB to +10.0 dB (0.5 dB increments) Default Front L, Front R, Subwoofer: 0.0 dB Others: -1.0 dB

GEQ Front L

Back:RETURN

4


■ Test Tone Enables/disables the test tone output. Test tone output helps you to adjust the speaker balance or equalizer while confirming its effect.

■ Equalizer Adjusts the tone with an equalizer.

Settings

❑ EQ Select

Off (default)

Does not output test tones.

Selects the type of equalizer to be used.

On

Outputs test tones automatically when you adjust the speaker balance or equalizer.

Settings PEQ

Applies the parametric equalizer values obtained by the YPAO measurement (p.31).

GEQ (default)

Select this option when you want to adjust the equalizer manually. For details, see “Manual equalizer adjustment”.

Off

Does not use the equalizer.

CONFIGURATIONS


En

73

HDMI

HDMI OUT (TV) Enables/disables the audio output from a TV connected to the HDMI OUT jack.

Configures the HDMI settings.

Setup Speaker

Settings Off (default)

Disables the audio output from the TV.

On

Enables the audio output from the TV.

Configuration

HDMI

❑ Standby Through

Sound ECO Function

Select whether to output videos/audio (input through HDMI jacks) to the TV when the unit is in standby mode. If this function is set to “On”, you can use the input selection keys (HDMI 1–5) to select an HDMI input even when the unit is in standby mode (the standby indicator on the unit blinks).

Network Language

Settings

■ Configuration ❑ HDMI Control

Off (default)

Does not output videos/audio to the TV.

On

Outputs videos/audio to the TV. (The unit consumes more power than when “Off” is selected.)

Enables/disables HDMI Control (p.100). Settings Off (default)

Disables HDMI Control.

• This setting is available only when “HDMI Control” is set to “Off”.

On

Enables HDMI Control. Configure the settings in “TV Audio Input”, “Standby Sync”, “ARC”, and “SCENE”.

❑ TV Audio Input Selects an audio input jack of the unit to be used for TV audio input when “HDMI Control” is set to “On”. The unit’s input source automatically switches to TV audio when the TV input is switched to its built-in tuner.

• To use HDMI control, you need to perform the HDMI Control link setup (p.100) after connecting HDMI Control-compatible devices.

Settings AV 1–6, AUDIO

❑ Audio Output

Default AV 4

Selects a device to output audio.

• This setting is available only when “HDMI Control” is set to “Off”.

• When using ARC to input TV audio to the unit, you cannot use the input jacks selected here for connecting an external device because the input will be used for TV audio input.

Amp Enables/disables the audio output from the speakers connected to the unit. Settings Off

Disables the audio output from the speakers.

On (default)

Enables the audio output from the speakers.

CONFIGURATIONS


En

74

❑ Standby Sync

Sound

Select whether to use HDMI control to link the standby behavior of the TV and the unit when “HDMI Control” is set to “On”.

Configures the audio output settings.

Settings Off

Does not set the unit to standby mode when the TV is turned off.

On

Sets the unit to standby mode when the TV is turned off.

Auto (default)

Sets the unit to standby mode when the TV is turned off only when the unit is receiving TV audio or HDMI signals.

Setup Speaker

DSP Parameter

HDMI

Lipsync

Sound

Volume

ECO Function Network Language

❑ ARC Enables/disables ARC (p.18) when “HDMI Control” is set to “On”. Settings Off

Disables ARC.

On (default)

Enables ARC.

■ DSP Parameter Configures the surround decoder settings.

❑ CINEMA DSP 3D Mode • You do not need to change this setting normally. In case noises are produced from the speakers connected to the unit because TV audio signals input to the unit via ARC are not ed by the unit, set “ARC” to “Off” and use the TV’s speakers.

Enables/disables CINEMA DSP 3D (p.40). If this function is set to “On”, CINEMA DSP 3D functions with the selected sound programs (except 2ch Stereo and 7ch/5ch Stereo). Settings

❑ SCENE Enables/disable SCENE link playback when “HDMI Control” is set to “On”.

Off

Disables CINEMA DSP 3D.

When SCENE link playback is enabled, HDMI Control-compatible devices connected to the unit via HDMI automatically works as follows, with a scene selection.

On (default)

Enables CINEMA DSP 3D.

• TV: turning on and displaying video from the playback device • Playback device: starting playback Choices (SCENE keys) BD/DVD, TV, NET, RADIO Settings

❑ Panorama Enables/disables the broadening effect of the front sound field. When this function is enabled, you can wrap front right/left channel sounds around the field and generate a spacious sound field in combination with the surround sound field. This setting is effective when “bPLII Music” or “bPLIIx Music” (HTR-5066 only) is selected. Settings

Off

Disables SCENE link playback for the selected SCENE key.

On

Enables SCENE link playback for the selected SCENE key.

Off (default)

Disables the broadening effect of the front sound field.

On

Enables the broadening effect of the front sound field.

Default BD/DVD, TV: On NET, RADIO: Off

• SCENE link playback may not work properly due to the compatibility between devices. We recommend using TV and playback devices from the same manufacturer so that HDMI Control works more effectively.

CONFIGURATIONS


En

75

❑ Center Width

■ Lipsync

Adjusts the broadening effect of the center sound field. Higher to enhance the broadening effect, and lower to reduce it (closer to center). This setting is effective when “bPLII Music” or “bPLIIx Music” (HTR-5066 only) is selected.

Adjusts the delay between video and audio output.

Setting range 0 to 7 Default 3

❑ Dimension Adjusts the difference in level between the front and surround sound fields. Higher to strengthen the front sound field and lower to strengthen the surround sound field. This setting is effective when “bPLII Music” or “bPLIIx Music” (HTR-5066 only) is selected. Setting range -3 to +3

• You can enable/disable the Lipsync function by input sources in “Lipsync” (p.66) in the “Option” menu.

❑ Select Selects the method to adjust the delay between video and audio output. Setting range

Manual

Select this option when you want to adjust the delay between video and audio output manually. Adjust the audio output timing in “Adjustment”.

Auto (default)

Adjusts the delay between video and audio output automatically when a TV that s an automatic lipsync function is connected to the unit via HDMI. If necessary, you can fine-adjust the audio output timing in “Adjustment”.

Default 0

❑ Center Image

• “Select” is automatically set to “Manual” depending on the TV connected to the unit.

Adjusts the center orientation level (broadening effect) of the front sound field. Higher to strengthen the center orientation level (less broadening effect) and lower to weaken (more broadening effect). This setting is effective when “Neo:6 Music” is selected.

❑ Adjustment

Setting range 0.0 to 1.0 Default 0.3

Adjusts the delay between video and audio output manually when “Select” is set to “Manual”. You can fine-adjust the audio output timing when “Select” is set to “Auto”. Setting range 0 ms to 250 ms (1 ms increments) Default 0 ms

CONFIGURATIONS


En

76

■ Volume Configures the volume settings.

• If “ZoneB Volume” is set to “Async.”, the volume for Zone B is temporarily set to -40 dB. As necessary, adjust the volume using the remote control (p.62).

❑ Dynamic Range Selects the dynamic range adjustment method for bitstream audio (Dolby Digital and DTS signals) playback.

ECO Configures the power supply settings.

Settings Maximum (default)

Produces audio without adjusting the dynamic range.

Standard

Optimizes the dynamic range for regular home use.

Min/Auto

Sets the dynamic range for clear sound even at night or at low volumes. When playing back Dolby TrueHD signals, the dynamic range is automatically adjusted based on the input signal information.

Setup Speaker

Auto Power Standby

HDMI

ECO Mode

Sound ECO Function Network Language

❑ Max Volume Sets the maximum volume to prevent excessive loudness. Setting range -30.0 dB to +15.0 dB (5.0 dB increments), +16.5 dB

■ Auto Power Standby Sets the amount of time for the auto-standby function. If you do not operate the unit for the specified time, the unit will automatically go into standby mode.

Default +16.5 dB

Settings

❑ Initial Volume Sets the initial volume when the receiver is turned on. Settings Off (default)

Sets the level to the volume level of the unit when it last entered standby mode.

Mute

Sets the unit to mute the audio output.

-80.0 dB to +16.5 dB Sets the level to the specified volume level. (0.5 dB increments)

❑ ZoneB Volume

Off

Does not set the unit to standby mode automatically.

2 hours, 4 hours, 8 hours, 12 hours

Sets the unit to standby mode when you have not operated the unit for the specified time. For example, when “2 hours” is selected, the unit will switch to standby mode if you do not operate it for 2 hours.

Default U.K. and Europe models: 8 hours Other models: Off

• Just before the unit enters standby mode, “AutoPowerStdby” appears and then countdown starts in the front display.

(HTR-5066 only) Selects whether to adjust the volume for Zone B in conjunction with the volume for Zone A. Settings Sync. (default)

Adjusts the volume for Zone B in conjunction with the volume for Zone A.

Async.

Does not adjust the volume for Zone B in conjunction with the volume for Zone A. Adjust the volume for Zone B separately (p.62).

CONFIGURATIONS


En

77

■ ECO Mode

Function

Enables/disables the eco (power saving) mode. When the eco mode is enabled, you can reduce the unit’s power consumption.

Configures the functions that make the unit easier to use.

Settings Setup

Off (default)

Disables the eco mode.

On

Enables the eco mode.

Speaker

Input Rename

HDMI

Dimmer

Sound

Memory Guard

ECO

DC OUT

Function Network Language

• Be sure to press ENTER to restart the unit after selecting a setting. The new setting will take effect after the unit is restarted. • When “ECO Mode” is set to “On”, the front display may become dark. • If you want to play audio at high volume, set “ECO Mode” to “Off”.

■ Input Rename Changes the input source name displayed on the front display. Input sources HDMI 1–5, AV 1–6, AUDIO, USB, V-AUX

■ Procedure

1

Use the cursor keys (q/w) to select an input source to be renamed and press ENTER.

• To select a name from the presets, use the cursor keys (q/w) to select an input source and the cursor keys (e/r) to select a preset name.

2

Use the cursor keys (e/r) to move the edit position and the cursor keys (q/w) to select a character.

Input Rename HDMI1 B l u - r a y OK:ENTER CANCEL:RETURN

3

To confirm the new name, press ENTER.

• To cancel the entry, press RETURN.

CONFIGURATIONS


En

78

4 5

To change another input source name, repeat steps 1 to 3.

■ DC OUT


Configures the DC OUT jack setting.

❑ Power Mode

■ Dimmer

Selects how to supply power to the Yamaha AV accessory connected to the DC OUT jack.

Adjusts the brightness of the front display. Setting range -4 to 0 (higher to brighten)

Settings

Default 0

Continuous (default)

Supplies power through the DC OUT jack continuously regardless of the power state (on/standby) of the unit.

Power Sync.

Supplies power through the DC OUT jack only when the unit is turned on.

• The front display may become dark when “ECO Mode” (p.78) is set to “On”.

■ Memory Guard Prevents accidental changes to the settings. Settings Off (default)

Does not protect the settings.

On

Protects the settings until “Off” is selected.

• When “Memory Guard” is set to “On”, the lock icon (o) is displayed on the menu screen.

o

Memory Guard Memory Guard

Icon

On

Back:RETURN

CONFIGURATIONS


En

79

■ IP Address

Network Configures the network settings.

Configures the network parameters (such as IP address).

❑ DH Select whether to use a DH server.

Setup Speaker

Information

HDMI

IP Address

Sound

MAC Address Filter

ECO

DMC Control

Function

Network Standby

Network

Network Name

Language

Network Update

Settings Off

Does not use a DH server. Configure the network parameters manually. For details, see “Manual network settings”.

On (default)

Uses a DH server to automatically obtain the unit’s network parameters (such as IP address).

■ Manual network settings

■ Information Displays the network information on the unit. Status

The connection status of the NETWORK jack

MAC Address

MAC address

IP Address

IP address

Subnet Mask

Subnet mask

Default Gateway

The IP address of the default gateway

DNS Server (P)

The IP address of the primary DNS server

DNS Server (S)

The IP address of the secondary DNS server

vTuner ID

The ID of the Internet radio (vTuner)

1 2

Set “DH” to “Off”. Use the cursor keys (q/w) to select a parameter type. IP Address

Specifies an IP address.

Subnet Mask

Specifies a subnet mask.

Default Gateway

Specifies the IP address of the default gateway.

DNS Server (P)

Specifies the IP address of the primary DNS server.

DNS Server (S)

Specifies the IP address of the secondary DNS server.

3

Use the cursor keys (e/r) to move the edit position and the cursor keys (q/w) to select a value.

4


CONFIGURATIONS


En

80

■ MAC Address Filter

■ Network Standby

Sets the MAC address filter to limit access to the unit from other network devices.

Selects whether the unit can be turned on from other network devices (network standby).

❑ Filter

Settings

Enables/disables the MAC address filter.

Off (default)

Disables the network standby function.

On

Enables the network standby function. (The unit consumes more power than when “Off” is selected.)

Settings Off (default)

Disables the MAC address filter.

On

Enables the MAC address filter. In “MAC Address 1–10”, specify the MAC addresses of the network devices that will be permitted access to the unit.

❑ MAC Address 1–10 Specifies the MAC addresses (up to 10) of the network devices that will be permitted access to the unit when “Filter” is set to “On”.

3

Edits the network name (the unit’s name on the network) displayed on other network devices. ■ Procedure

1 2

■ Procedure

1 2

■ Network Name

Use the cursor keys (q/w) to select an MAC address number (1 to 10). Use the cursor keys (e/r) to move the edit position and the cursor keys (q/w) to select a value.

Press ENTER to enter the name edit screen. Use the cursor keys (e/r) to move the edit position and the cursor keys (q/w) to select a character.

Network Name


Y a m a h a

x x x x x x

■ DMC Control Selects whether to allow DLNA-compatible Digital Media Controller (DMC) to control playback. Settings Disable

Does not allow DMCs to control playback.

Enable (default)

Allows DMCs to control playback.

Back:RETURN

3 4

To confirm the new name, press ENTER. To exit from the menu, press SETUP.

• A Digital Media Controller (DMC) is a device that can control other network devices through the network. When this function is enabled, you can control playback of the unit from DMCs (such as Windows Media Player 12) on the same network.

CONFIGURATIONS


En

81

■ Network Update Updates the firmware via the network.

Language Select an on-screen menu language.

❑ Perform Update Starts the process to update the unit’s firmware. For details, see “Updating the unit’s firmware” (p.88).

Setup Speaker

English

HDMI

日本語 Français Deutsch Español Русский Italiano

❑ Firmware Version

Sound

Displays the version of the firmware installed on the unit.

Network

ECO Function Language

中文

❑ System ID Displays the system ID number.

Settings English (default)

English

日本語

Japanese

Français

French

Deutsch

German

Español

Spanish Russian

Italiano

Italian Chinese

• Japanese and Chinese characters used in content information (such as song titles) cannot be displayed. • The information on the front display is provided in English only.

CONFIGURATIONS


En

82

Changing the speaker impedance setting (SP IMP.)

Configuring the system settings (ADVANCED SETUP menu)

(U.S.A. model only)

Configure the system settings of the unit while viewing the front display.

1 2

SPIMP.8MIN

Set the unit to standby mode.

Change the unit’s speaker impedance settings depending on the impedance of the speakers connected.

While holding down STRAIGHT on the front , press z (power).

Settings z (power)

PROGRAM

3 4 5

STRAIGHT

6 Ω MIN

Select this option when you connect 6-ohm speakers to the unit. You can also use 4-ohm speakers as the front speakers.

8 Ω MIN (default)

Select this option when you connect 8-ohm or higher speakers to the unit.

Selecting the remote control ID (REMOTE ID)

Press PROGRAM to select an item. Press STRAIGHT to select a setting.

REMOTEIDID1

Press z (power) to set the unit to standby mode and turn it on again. The new settings take effect.

Change the unit’s remote control ID so that it matches the remote control’s ID (default: ID1). When using multiple Yamaha AV receivers, you can set each remote control with a unique remote control ID for its corresponding receiver. Settings ID1 (default), ID2

ADVANCED SETUP menu items Item

Function

Page

SP IMP.

(U.S.A. model only) Changes the speaker impedance setting.

83

REMOTE ID

Selects the unit’s remote control ID.

83

TU

(Asia and General models only) Changes the FM/AM tuning frequency setting.

84

TV FORMAT

Switches the video signal type of HDMI output.

84

■ Changing the remote control ID of the remote control

1

To select ID1, while holding down the cursor key (e), hold down SCENE (BD/DVD) for more than 3 seconds. To select ID2, while holding down the cursor key (e), hold down SCENE (TV) for more than 3 seconds.

• The ed remote control codes (p.85) are not cleared even if you change the remote control ID.

INIT

Restores the default settings.

84

UPDATE

Updates the firmware.

84

VERSION

Checks the version of firmware currently installed on the unit.

84

CONFIGURATIONS ➤


En

83

Changing the FM/AM tuning frequency setting (TU)

Updating the firmware (UPDATE)

(Asia and General models only)

TUFM50/AM9 Change the FM/AM tuning frequency setting of the unit depending on your country or region. Settings FM100/AM10

Select this when you want to adjust the FM frequency by 100-kHz steps and AM by 10-kHz steps.

FM50/AM9 (default)

Select this when you want to adjust the FM frequency by 50-kHz steps and AM by 9-kHz steps.

Switching the video signal type (TV FORMAT)

TVFORMATNTSC

UPDATEUSB New firmware that provides additional features or product improvements will be released as needed. Updates can be ed from our website. If the unit is connected to the Internet, you can the firmware via the network. For details, refer to the information supplied with updates. ■ Firmware update procedure Do not perform this procedure unless firmware update is necessary. Also, make sure you read the information supplied with updates before updating the firmware.

1

Press STRAIGHT repeatedly to select “USB” or “NETWORK” and press INFO to start firmware update. Choices USB

Update the firmware using a USB memory device.

NETWORK

Update the firmware via the network.

Switch the video signal type of HDMI output so that it matches to the format of your TV. Since the unit automatically selects the video signal type so that it matches to the TV, it is unnecessary to change the setting normally. Change the setting only when images on the TV screen do not appear correctly. Settings NTSC, PAL

• If the unit detects newer firmware over the network, the envelope icon (p) will appear in the “Network Update” screen. In this case, you can also update the unit’s firmware by following the procedure in “Updating the unit’s firmware” (p.88).

Checking the firmware version (VERSION)

Default U.S.A., Korea and General models: NTSC Other models: PAL

Restoring the default settings (INIT)

INITCANCEL

VERSIONxx.xx Check the version of firmware currently installed on the unit.

• You can also check the firmware version in “Network Update” (p.82) in the “Setup” menu. • It may take a while until the firmware version is displayed.

Restores the default settings for the unit. Choices ALL

Restores the default settings for the unit.

CANCEL

Does not perform an initialization.

CONFIGURATIONS ➤


En

84

CODE SET

SOURCE RECEIVER

CODE SET

You can use the unit’s remote control to operate external devices (such as BD/DVD players) if you have ed the remote control code of the external device.

HDMI

1

2

3

4 MHL

1

2

3

5

AV

4

5

6

A

V-AUX

USB

NET

B ZONE

TUNER AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

TUNING


ENHANCER

DIRECT

NET

• If the unit’s remote control is without batteries for more than 2 minutes, the ed codes may be cleared. If this happens, insert new batteries and the codes again.

If it blinks six times, registration has failed. Repeat from Step 2.

■ TV operations

RADIO

• Under the unit’s default settings, the amplifier code (Yamaha: 5098) is set for all the input selection keys. With this setting, you can control HDMI Control-compatible devices connected to the unit with the remote control. (This function may not work depending on the specification of the external device.)

OPTION

SETUP

VOLUME

ENTER RETURN

Use the numeric keys to enter the 4-digit remote control code.

Once the remote control code is successfully ed, SOURCE/RECEIVER blinks twice.

SCENE TV

Press TV z.

• Ensure that the remote control ID of the external device is set to “ID1”. If any other ID is selected, the remote control operations may not work properly.

SLEEP

BD DVD

3 4

• You cannot control an external device that does not have a remote control sensor.

AUDIO

FM

Controlling external devices with the remote control

SOURCE/RECEIVER

Once you have ed the remote control code for your TV, you can control it using the TV operation keys, regardless of the input source selected on the unit.

DISPLAY

TOP MENU

POP-UP MENU

MUTE

ing the remote control code for a TV

MODE

1

2

3

4

5

6

7

8

9

0

10

You can use the unit’s remote control to operate a TV if you have ed its remote control code. Numeric keys

TV operation keys

INPUT

Switches the video inputs of the TV.

MUTE

Mutes the audio output of the TV.

TV VOL

Adjust the volume of the TV.

TV CH

Switch the channels of the TV

TV z

Turns on/off the TV.

ENT


TV CH

TV operation keys TV z

• You can also your TV’s remote control code to the unit’s input selection keys (p.86). This would allow you to use the cursor keys or numeric keys to operate the TV (this function may not be available on some TV models).

1

Use “Remote Control Code Search” in the CD-ROM to find your TV’s remote control code.

• If there are multiple remote control codes, the first code in the list. If that does not work, try the other codes.

2

Press CODE SET using a pointed object such as the tip of a ballpoint pen. SOURCE/RECEIVER blinks twice. Perform each of the following steps within 1 minute. Otherwise, the setting will be canceled. If this happens, repeat from Step 2.

CONFIGURATIONS

➤ Controlling external devices with the remote control

En

85

CODE SET

SOURCE RECEIVER

SOURCE z CODE SET SOURCE/RECEIVER

ing the remote control codes for playback devices

HDMI

1

2

3

1

2

3

4

5

A

MHL


AV

4

5

6

V-AUX

USB

NET

B ZONE

AUDIO

You can use the unit’s remote control to operate playback devices if you have ed their remote control codes. You can also use the input selection keys to change the playback devices that are controlled by the remote control, because their remote control codes are assigned to the input selection keys.

TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

TUNING

• (HTR-4066 only) If you assign the remote control code for an external device to the star (★ or ★★) key, you can operate the device with the remote control without switching the input source after pressing the star key.


ENHANCER

DIRECT

SLEEP

■ Playback device operations Once you have ed the remote control code for your playback device, you can control it using the following keys after selecting the input source or scene.

• By pressing SOURCE/RECEIVER, you can switch the devices (the unit or external device) that are operated by the menu operation keys, DISPLAY and numeric keys. You can operate the unit when SOURCE/RECEIVER lights up in orange, and an external device when SOURCE/RECEIVER lights up in green. For example, if you the remote control code of your BD/DVD player on HDMI 1, you can operate the unit when SOURCE/RECEIVER lights up in orange, and the BD/DVD player when SOURCE/RECEIVER lights up in green.

SOURCE z

Turns on/off the playback device.

SCENE BD DVD

TV

NET

RADIO

1

OPTION

SETUP

VOLUME

ENTER RETURN

Menu operation keys

Use “Remote Control Code Search” in the CD-ROM to find the remote control code for your playback device.

POP-UP MENU

1

2

3

4

External device operation keys DISPLAY

5

6

7

8

Numeric keys

9

0

10

• If there are multiple remote control codes, the first code in the list. If that does not work, try the other codes.

2

ENT

Press CODE SET using a pointed object such as the tip of a ballpoint pen. External device operation keys

SOURCE/RECEIVER blinks twice.

TV

TV operation keys TV VOL

ENTER

Confirms a selected item.

RETURN

MUTE

MODE

INPUT

Select an item.

DISPLAY

DISPLAY D

TOP MENU

Menu operation keys

Cursor keys

Perform each of the following steps within 1 minute. Otherwise, the setting will be canceled. If this happens, repeat from Step 2.

TV CH

MUTE

3 4

Returns to the previous screen. Switches information on the display.

TOP MENU

Displays the top menu.

POP-UP MENU

Displays the pop-up menu.

s

Stops playback.

d


a

Starts playback of the selected song/video.

h j

Searches forward/backward (by holding down).

f

Press the input selection key. For example, press HDMI 1 to set the remote control code for the playback device connected to the HDMI 1 jack.

g


Numeric keys

Enter numerical values.

TV operation keys

Control the TV (p.85).

Use the numeric keys to enter the 4-digit remote control code.

Once the remote control code is ed successfully, SOURCE/RECEIVER blinks twice.

• These keys work only if the corresponding function is available on your playback device and if the device can be operated with an infrared remote control.

If it blinks six times, registration has failed. Repeat from Step 2.

• For details on how to a remote control code to a SCENE key, refer to “Configuring scene assignments” (p.36).

CONFIGURATIONS


En

86

CODE SET

SOURCE RECEIVER

CODE SET SOURCE/RECEIVER

HDMI

1

2

3

4

2

3

5

MHL

1


4

5

6

A

USB

NET

B

You can reset a remote control code ed to each input selection key.

1

AV

V-AUX

Resetting remote control codes

ZONE

SOURCE/RECEIVER blinks twice.

AUDIO TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET

Perform each of the following steps within 1 minute. Otherwise, the setting will be canceled. If this happens, repeat from Step 1.

TUNING


ENHANCER

DIRECT

2 3

SLEEP SCENE BD DVD

TV

NET

RADIO

OPTION

SETUP

VOLUME

ENTER RETURN

POP-UP MENU

Press the input selection key. Use the numeric keys to enter “5098”.

Once the remote control code is reset successfully, SOURCE/RECEIVER blinks twice.

DISPLAY

TOP MENU

Press CODE SET using a pointed object such as the tip of a ballpoint pen.

MUTE

If it blinks six times, resetting has failed. Repeat from Step 1.

MODE

To reset the remote control to factory default settings 1

2

3

4

5

6

7

8

9

0

10

ENT

a Press CODE SET using a pointed object such as the tip of a ballpoint pen. Numeric keys

b Press SOURCE/RECEIVER. c Use the numeric keys to enter “9981”.

TV INPUT TV VOL

TV CH

MUTE

CONFIGURATIONS


En

87

Updating the unit’s firmware via the network

CODE SET

SOURCE RECEIVER

New firmware that provides additional features or product improvements will be released as needed. If the unit is connected to the Internet, you can the firmware via the network and update it.

HDMI

1

2

3

4 MHL

1

2

3

5

4

5

6

A

V-AUX

USB

NET

AV

B ZONE

• To cancel the operation without updating the firmware, press SETUP.

4

Note

AUDIO

Use the cursor keys to select “Perform Update” and press ENTER.

TUNER FM

AM

INFO

MEMORY

MOVIE

MUSIC

PRESET


ENHANCER

• If the unit is connected to the wireless network via a wireless network adapter, network update may not be possible depending on the condition of the wireless connection. In this case, update the firmware using the USB memory device (p.84).

DIRECT

SLEEP SCENE BD DVD

TV

NET

RADIO

SETUP

OPTION

SETUP

VOLUME

ENTER RETURN

DISPLAY

TOP MENU

POP-UP MENU

MUTE

MODE

1

2

3

4

5

6

7

8

9

0

10 TV

ENT

• To perform the following procedure, your TV must be connected to the unit via HDMI. If not, perform the update from the “ADVANCED SETUP” menu (p.84).

TV VOL

5

If “UPDATE SUCCESS PLEASE POWER OFF!” appears on the front display, press z (power) on the front .

The firmware update is complete.

Cursor keys ENTER

• You can also update the firmware using the USB memory device from the “ADVANCED SETUP” menu (p.84).

1 2

Press SETUP.

3

Use the cursor keys to select “Network Update” and press ENTER.

INPUT

MUTE

The on-screen display turns off and the firmware update starts.

• Do not operate the unit or disconnect the power cable or network cable during firmware update. Firmware update takes about 20 minutes or more (depending on your Internet connection speed).

TUNING

Use the cursor keys to select “Network” and press ENTER.

TV CH

If new firmware is available, the envelope icon (p) appears in the “Network Update” screen.

Network Update

p

Icon

Perform Update Firmware Version System ID

x.xx xxxxxxxx

Update:ENTER Back:RETURN

CONFIGURATIONS ➤

Updating the unit’s firmware via the network

En

88

APPENDIX Frequently asked questions The new speaker system does not provide an ideal sound balance... If you have changed speakers or have a new speaker system, use YPAO to optimize the speaker settings again (p.31). If you want to adjust the speaker settings manually, use “Speaker” in the “Setup” menu (p.71).

Since we have small children, we want to set limitations on the volume control... If a small child accidentally operates the controls on the main unit or remote control, the volume may suddenly increase. This may also cause injury or damage the unit or speakers. We recommend using “Max Volume” in the “Setup” menu to set the maximum volume level for the unit in advance (p.77).

I am occasionally startled by a sudden loud sound when turning on the unit... By default, the volume level when the unit last entered standby mode is automatically applied. If you want to fix the volume, use “Initial Volume” in the “Setup” menu to set the volume to be applied when the receiver is turned on (p.77).

We are bothered by volume differences when switching between input sources…

system. For information on how HDMI Control works between your TV and playback devices, refer to the instruction manuals for each device.

I want to display a device name or a manufacture name on the front display when selecting an input source... By default, input source names (such as “HDMI 1” and “AV 1”) are displayed on the front display when an input source is selected. If you want to rename them as you like, use “Input Rename” (p.78) in the “Setup” menu. You can also select a name from the presets (such as “Blu-ray” and “DVD”).

I want to prevent accidental changes to the settings... You can protect the settings configured on the unit (such as speaker settings) by utilizing “Memory Guard” in the “Setup” menu (p.79).

The unit’s remote control is simultaneously controlling another Yamaha product as well as the unit... When using multiple Yamaha products, the remote control may work on another Yamaha product or another remote control may work on the unit. If this happens, different remote control IDs for the devices that you want to control with each remote control (p.83).

You can correct volume differences between input sources by utilizing “Input Trim” in the “Option” menu (p.66).

I want to enjoy videos/audio played back on the video device even when the unit is in standby mode…

I made HDMI connections but HDMI Control does not work at all...

If you have connected a video device to the unit with HDMI, you can output videos/audio played back on the video device to the TV even when the unit is in standby mode. To use this function, set “Standby Through” (p.74) in the “Setup” menu to “On”. You can also switch the input source using the remote control of the unit when this function is enabled.

To use HDMI Control, you need to perform the HDMI Control link setup (p.100). After connecting HDMI Control-compatible devices (such as BD/DVD players) to the unit, enable HDMI Control on each device and perform the HDMI Control link setup. This setup is required every time you add a new HDMI Control-compatible device to your

APPENDIX

➤ Frequently asked questions

En

89

Troubleshooting Refer to the table below when the unit does not function properly. If the problem you are experiencing is not listed below or if the instructions below do not help, turn off the unit, disconnect the power cable, and the nearest authorized Yamaha dealer or service center.

First, check the following: a The power cables of the unit, TV and playback devices (such as BD/DVD players) are connected to AC wall outlets securely. b The unit, subwoofer, TV and playback devices (such as BD/DVD players) are turned on. c The connectors of each cable are securely inserted in to jacks on each device.

Power, system and remote control Problem

Cause

Remedy

The power does not turn on.

The protection circuitry has been activated three times consecutively. If the unit is in this condition, the standby indicator on the unit blinks when you try to turn on the power.

As a safety precaution, capability to turn on the power is disabled. your nearest Yamaha dealer or service center to request repair.

The power does not turn off.

The internal microcomputer has frozen, due to an external electric shock (such as lightning or excessive static electricity) or to a drop in the power supply voltage.

Hold down z (power) on the front for more than 10 seconds to initialize and reboot the unit. (If the problem persists, disconnect the power cable from the AC wall outlet and plug it again.)

The power turns off (standby mode) immediately.

The unit was turned on while a speaker cable was shorted.

Twist the bare wires of each speaker cable firmly and reconnect to the unit and speakers (p.16).

The sleep timer worked.

Turn on the unit and start playback again.

The auto-standby function kicked in because the unit was not used for the specified time.

To disable the auto-standby function, set “Auto Power Standby” in the “Setup” menu to “Off” (p.77).

The unit enters standby mode automatically.

The unit is not reacting.

The speaker impedance setting is incorrect.

Set the speaker impedance to match your speakers (p.83).

The protection circuitry has been activated because of a short circuit.

Twist the bare wires of each speaker cable firmly and reconnect to the unit and speakers (p.16).

The internal microcomputer is frozen, due to an external electric shock (such as lightning or excessive static electricity) or to a drop in the power supply voltage.

Hold down z (power) on the front for more than 10 seconds to initialize and reboot the unit. (If the problem persists, disconnect the power cable from the AC wall outlet and plug it again.)

APPENDIX ➤ Troubleshooting

En

90

Problem

The unit cannot be controlled using the remote control.

Cause The unit is out of the operating range.

Use the remote control within the operating range (p.4).

The batteries are weak.

Replace with new batteries.

The unit’s remote control sensor is exposed to direct sunlight or strong lighting.

Adjust the lighting angle, or reposition the unit.

The remote control is set to control external devices.

Press SOURCE/RECEIVER to set the remote control to control the unit (the key lights up in orange).

The remote control IDs of the unit and the remote control are not identical.

Change the remote control ID of the unit or the remote control (p.83).

The remote control is set to the Zone B operation mode.

Set the remote control to the Zone A operation mode (p.62).

The remote control is set to control the unit.

Press SOURCE/RECEIVER to set the remote control to control external devices (the key lights up in green).

The corresponding remote control code is not set properly.

Set the remote control code again (p.85). Even if the remote control code is ed properly, some products may not respond to the remote control.

A remote control code for another playback device is assigned to HDMI 5.

Reset the remote control code ed to HDMI 5 (p.87).

The mobile device or its application is not externally controllable.

Directly operate the mobile device itself.

External devices cannot be controlled using the remote control.

The MHL-compatible mobile device cannot be controlled using the remote control.

Remedy


En

91

Audio Problem

No sound.

The volume cannot be increased.

No sound is coming from a specific speaker.

(HTR-5066 only) No sound is coming from the surround back speaker.

No sound is coming from the subwoofer.

Cause

Remedy

Another input source is selected.

Select an appropriate input source with the input selection keys.

Signals that the unit cannot reproduce are being input.

Some digital audio formats cannot be played back on the unit. To check the audio format of the input signal, use “Signal Info” in the “Option” menu (p.66).

(HTR-5066 only) Audio output to Zone A (or Zone B) is disabled.

Press ZONE A (ZONE B) to enable audio output to Zone A (or Zone B).

The cable connecting the unit and playback device is defective.

If there is no problem with the connection, replace with another cable.

The maximum volume is set.

Use “Max Volume” in the “Setup” menu to adjust the maximum volume (p.77).

A device connected to the output jacks of the unit is not turned on. (This may happen due to the nature of AV receivers.)

Turn on all devices connected to the output jacks of the unit.

The playback source does not contain a signal for the channel.

To check it, use “Signal Info” in the “Option” menu (p.66).

The currently selected sound program/decoder does not use the speaker.

To check it, use “Test Tone” in the “Setup” menu (p.73).

Audio output of the speaker is disabled.

Perform YPAO (p.31) or use “Configuration” in the “Setup” menu to change the speaker settings (p.71).

The volume of the speaker is set too low.

Perform YPAO (p.31) or use “Level” in the “Setup” menu to adjust the speaker volume (p.73).

(HTR-5066 only) Audio output to Zone A (or Zone B) is disabled.

Press ZONE A (ZONE B) to enable audio output to Zone A (or Zone B).

The speaker cable connecting the unit and the speaker is defective.

If there is no problem with the connection, replace with another speaker cable.

The speaker is malfunctioning.

To check it, replace with another speaker. If the problem persists, the unit may be malfunctioning.

The extended surround is disabled.

Use “Extended Surround” in the “Option” menu to select a decoder to be used (p.65).

“Power Amp Assign” is set to “BI-AMP” or “Zone B”.

When “Power Amp Assign” in the “Setup” menu is set to “BI-AMP” or “Zone B”, you cannot use the surround back speakers. To use the surround back speakers, set “Power Amp Assign” to “Basic” (p.71).

The playback source does not contain LFE or low-frequency signals.

To check it, set “Extra Bass” in the “Setup” menu to “On”, in order to output the front channel low-frequency components from the subwoofer (p.72).

Subwoofer output is disabled.

Perform YPAO (p.31) or set “Subwoofer” in the “Setup” menu to “Use” (p.71).

The volume of the subwoofer is too low.

Adjust the volume on the subwoofer.

The subwoofer has been turned off by its auto-standby function.

Disable the auto-standby function of the subwoofer or adjust its sensitivity level.


En

92

Problem

No sound from the playback device (connected to the unit with HDMI).

No sound from the TV (when HDMI Control is used).

Only the front speakers work on multichannel audio.

Cause

Remedy

The TV does not HD (High-bandwidth Digital Content Protection).

Refer to the instruction manuals for the TV and check the TV’s specifications.

The unit is set not to output audio input through HDMI jacks from the SPEAKERS terminals.

In “Audio Output” in the “Setup” menu, set “Amp” to “On” (p.74).

The number of devices connected to the HDMI OUT jack exceeds the limit.

Disconnect some of the HDMI devices.

The TV is set to output audio from the TV speakers.

Change the audio output setting on your TV so that the TV audio is output from the speakers connected to the unit.

A TV that does not ARC is connected to the unit only with an HDMI cable.

Use a digital optical cable to make an audio connection (p.20).

(If the TV is connected to the unit with an audio cable) The TV audio input setting does not match the actual connection.

Use “TV Audio Input” in the “Setup” menu to select the correct audio input jack (p.74).

(If you are trying to use ARC) ARC is disabled on the unit or TV.

Set “ARC” in the “Setup” menu to “On” (p.75). Also, enable ARC on the TV.

The playback device is set to output 2-channel audio (such as PCM) only.

To check it, use “Signal Info” in the “Option” menu (p.66). If necessary, change the digital audio output setting on the playback device.

The unit is too close to another digital or radio frequency device.

Move the unit further away from the device.

The cable connecting the unit and playback device is defective.


Noise/hum is heard. The volume of the unit is too high.

Turn down the volume. If “ECO Mode” is set to “On”, set it to “Off” (p.78).

A device connected to the unit’s output jacks is not turned on.

Turn on all devices connected to the unit’s output jacks.

The sound is distorted.


En

93

Video Problem

No video.

No video from the playback device (connected to the unit with HDMI).

Cause

Remedy

Another input source is selected on the unit.

Select an appropriate input source with the input selection keys.

Another input source is selected on the TV.

Switch the TV input to display the video from the unit.

The video signal output from the unit is not ed by the TV.

Check the video output setting of the playback device. For information about video signals ed by the TV, refer to the instruction manuals for the TV.

The cable connecting the unit and TV (or playback device) is defective.


The input video signal (resolution) is not ed by the unit.

To check the information about the current video signal (resolution), use “Signal Info” in the “Option” menu (p.66). For information about video signals ed by the unit, see “HDMI signal compatibility” (p.102).

The TV does not HD (High-bandwidth Digital Content Protection).

Refer to the instruction manuals for the TV and check the TV’s specifications.

The number of devices connected to the HDMI OUT jack is over the limit.

Disconnect some of the HDMI devices.

The TV is not connected to the unit via HDMI.

You can display the menu of the unit on the TV only when they are connected with an HDMI cable. If necessary, use an HDMI cable to connect them (p.18 to 21).

Another input source is selected on the TV.

Switch the TV input to display the video from the unit (HDMI OUT jack).

Cause

Remedy

There is multi-path interference.

Adjust the FM antenna height or orientation, or place it in a different location.

The menu of the unit is not displayed on the TV.

FM/AM radio Problem

Press MODE to select monaural FM radio reception (p.43).

FM radio reception is weak or noisy.

AM radio reception is weak or noisy.

Your area is too far from the FM station transmitter.

Use an outdoor FM antenna. We recommend using a sensitive multi-element antenna.

The noises may be caused by fluorescent lamps, motors, thermostats, or other electrical equipment.

It is difficult to completely eliminate noise. It may be reduced by using an outdoor AM antenna. Select the station manually (p.43).

Your area is too far from the FM station transmitter.

Use an outdoor antenna. We recommend using a sensitive multi-element antenna. Adjust the AM antenna orientation.

Radio stations cannot be selected automatically. The AM radio signal is weak.

Select the station manually (p.43). Use an outdoor AM antenna. Connect it to the ANTENNA (AM) jack together with the supplied AM antenna.

AM radio stations cannot be ed as presets.

Auto Preset has been used.

Auto Preset is for ing FM radio stations only. AM radio stations manually (p.44).


En

94

USB and network Problem

Cause

Remedy

The USB device is not connected to the USB jack securely.

Turn off the unit, reconnect your USB device, and turn the unit on again.

The unit does not detect the USB device. The file system of the USB device is not FAT16 or FAT32.

Use a USB device with FAT16 or FAT32 format.

Folders and files in the USB device cannot be viewed.

The data in the USB device is protected by the encryption.

Use a USB device without an encryption function.

The network feature does not function.

The network parameters (IP address) have not been obtained properly.

Enable the DH server function on your router and set “DH” in the “Setup” menu to “On” on the unit (p.80). If you want to configure the network parameters manually, check that you are using an IP address which is not used by other network devices in your network (p.80).

The media sharing setting is not correct.

Configure the sharing setting and select the unit as a device to which music contents are shared (p.54).

Some security software installed on your PC is blocking the access of the unit to your PC.

Check the settings of security software installed on your PC.

The unit and PC are not in the same network.

Check the network connections and your router settings, and then connect the unit and the PC to the same network.

The MAC address filter is enabled on the unit.

In “MAC Address Filter” in the “Setup” menu, disable the MAC address filter or specify the MAC address of your PC to allow it to access to the unit (p.81).

The files are not ed by the unit or the media server.

Use the file format ed by both the unit and the media server. For information about the file formats ed by the unit, see “Playing back music stored on media servers (PCs/NAS)” (p.54).

The selected Internet radio station is currently not available.

There may be a network problem at the radio station, or the service may have been stopped. Try the station later or select another station.

The selected Internet radio station is currently broadcasting silence.

Some Internet radio stations broadcast silence at certain of times of the day. Try the station later or select another station.

Access to the network is restricted by the firewall settings of your network devices (such as the router).

Check the firewall settings of your network devices. The Internet radio can be played only when it es through the port designated by each radio station. The port number varies depending on the radio station.

The MAC address filter is enabled on the unit.

In “MAC Address Filter” in the “Setup” menu, disable the MAC address filter or specify the MAC address of your smartphone/tablet to allow it to access to the unit (p.81).

The unit and smartphone/tablet are not in the same network.

Check the network connections and your router settings, and then connect the unit and smartphone/tablet to the same network.

The unit does not detect the PC.

The files in the PC cannot be viewed or played back.

The Internet radio cannot be played.

The application for smartphone/tablet “AV Controller” does not detect the unit.


En

95

Error indications on the front display Message

Cause

Remedy

Access denied

Access to the PC is denied.

Configure the sharing settings and select the unit as a device to which music contents are shared (p.54).

The unit cannot access the USB device.

Turn off the unit and reconnect your USB device. If the problem persists, try another USB device.

The unit cannot access the iPod.

Turn off the iPod and turn it on again.

Access error Make sure your router and modem are turned on. There is a problem with the signal path from the network to the unit. Check the connection between the unit and your router (or hub) (p.28). Check SP Wires

The speaker cables short circuit.

Twist the bare wires of the cables firmly and connect to the unit and speakers properly.

Connect error

The unit has detected the iPod, but cannot access it.

Turn off the iPod and then turn it on again.

Internal Error

An internal error has occurred.

the nearest authorized Yamaha dealer or service center.

MHL Overloaded

An overcurrent is flowing through the MHL-compatible mobile device.

Turn off the unit and check the connection between the unit and mobile device.

No content

There are no playable files in the selected folder.

Select a folder that contains files ed by the unit.

The unit cannot detect the USB device.


No device The unit cannot detect the iPod.

Turn off the iPod and then turn it on again.

Please wait

The unit is preparing for connecting to the network.

Wait until the message disappears. If the message stays more than 3 minutes, turn off the unit and turn it on again.

RemID Mismatch

The remote control IDs of the unit and the remote control are not identical.

Change the remote control ID of the unit or the remote control (p.83).

The unit cannot play back the songs stored on the iPod for some reason.

Check the song data. If it cannot be played on the iPod itself, the song data or storage area may be defective.

The unit cannot play back the songs stored on the PC for some reason.

Check if the format of files you are trying to play is ed by the unit. For information about the formats ed by the unit, see “Playing back music stored on media servers (PCs/NAS)” (p.54). If the unit s the file format, but still cannot play back any files, the network may be overloaded with heavy traffic.

Unknown iPod

The connected iPod is not ed by the unit.

Use an iPod ed by the unit (p.47).

USB Overloaded

An overcurrent is flowing through the USB device.


Unable to play

APPENDIX ➤

Error indications on the front display

En

96

Glossary Audio information ■ Audio decoding format Dolby Digital Dolby Digital is a compressed digital audio format developed by Dolby Laboratories, Inc. that s 5.1-channel audio. This technology is used for audio on most DVD discs.

Dolby Digital EX Dolby Digital EX creates total 6.1-channel audio from 5.1-channel sources that are recorded with Dolby Digital Surround EX. This decoder adds a surround back sound to the original 5.1-channel sound.

Dolby Digital Plus Dolby Digital Plus is a compressed digital audio format developed by Dolby Laboratories, Inc. that s 7.1-channel audio. Dolby Digital Plus remains fully compatible with the existing multichannel audio systems that Dolby Digital. This technology is used for audio on BD (Blu-ray discs).

Dolby Pro Logic II Dolby Pro Logic II enables 5-channel playback from 2-channel sources. There are three modes available: “Music mode” for music sources, “Movie mode” for movie sources, and “Game mode” for game sources.

Dolby Pro Logic IIx

DTS Express DTS Express is a compressed digital audio format that s 5.1-channel audio and allows a higher compression rate than the DTS Digital Surround format developed by DTS, Inc. This technology is developed for audio streaming services on the Internet and secondary audio on BD (Blu-ray discs).

DTS-HD High Resolution Audio DTS-HD High Resolution Audio is a compressed digital audio format developed by DTS, Inc. that s 7.1-channel and 96 kHz/24-bit audio. DTS-HD High Resolution Audio remains fully compatible with the existing multichannel audio systems that DTS Digital Surround. This technology is used for audio on BD (Blu-ray discs).

DTS-HD Master Audio DTS-HD Master Audio is an advanced lossless audio format developed to offer a high-definition home theater experience with the quality of the studio master by DTS, Inc. DTS-HD Master Audio can carry up to eight channels of 96 kHz/24-bit audio (up to six channels of 192 kHz/24-bit audio) simultaneously. This technology is used for audio on BD (Blu-ray discs).

DTS Neo:6 DTS Neo:6 enables 6-channel playback from 2-channel sources. There are two modes available: “Music mode” for music sources and “Cinema mode” for movie sources. This technology provides discrete full-bandwidth matrix channels of surround sound.

DSD (Direct Stream Digital)

Dolby Pro Logic IIx enables 7-channel playback from 2-channel or multichannel sources. There are three modes available: “Music mode” for music sources, “Movie mode” for movie sources and “Game mode” for game sources (for 2-channel sources only).

DSD (Direct Stream Digital) technology stores audio signals on digital storage media, such as SACD (Super Audio CDs). The signals are stored at a high-frequency sampling rate of 2.8224 MHz. The highest frequency response is equal to or higher than 100 kHz, with a dynamic range of 120 dB. This technology offers better audio quality than that used for CDs.

Dolby TrueHD

FLAC

Dolby TrueHD is an advanced lossless audio format developed by Dolby Laboratories, Inc. to offer a high-definition home theater experience with the quality of the studio master. Dolby TrueHD can carry up to eight channels of 96 kHz/24-bit audio (up to six channels of 192 kHz/24-bit audio) simultaneously. This technology is used for audio on BD (Blu-ray discs).

FLAC is a file format for lossless audio data compression. FLAC is inferior to lossy compressed audio formats in compression rate but provides higher audio quality.

DTS 96/24 DTS 96/24 is a compressed digital audio format that s 5.1-channel and 96 kHz/24-bit audio. This format remains fully compatible with the existing multichannel audio systems that DTS Digital Surround. This technology is used for music DVDs, etc.

DTS Digital Surround DTS Digital Surround is a compressed digital audio format developed by DTS, Inc. that s 5.1-channel audio. This technology is used for audio on most DVD discs.

DTS-ES DTS-ES creates total 6.1-channel audio from 5.1-channel sources that are recorded with DTS-ES. This decoder adds a surround back sound to the original 5.1-channel sound. In the DTS-ES Matrix 6.1 format, a surround back sound is recorded in the surround channels, and in the DTS-ES Discrete 6.1 format, a discrete surround back channel is recorded.

MP3 One of the compressed digital audio format used by MPEG. With psychoacoustic technologies, this compression method achieves a high compression rate. Reportedly, it is capable of compressing data quantity by about 1/10 maintaining a certain level of audio quality.

MPEG-4 AAC An MPEG-4 audio standard. It is used for mobile telephones, portable audio players, and audio streaming services on Internet because it allows a high compression rate of data while maintaining better audio quality than MP3.

PCM (Pulse Code Modulation) PCM is a signal format under which an analog audio signal is digitized, recorded, and transmitted. This technology is the basis of all other audio format. This technology is used as a lossless audio format called Linear PCM for audio on a variety of media, including CDs and BD (Blu-ray discs).

APPENDIX ➤ Glossary

En

97

Sampling frequency/Quantization bit Sampling frequency and quantization bits indicate the quantity of information when an analog audio signal is digitized. These values are noted as in the following example: “48 kHz/24-bit”. • Sampling frequency Sampling frequency (the number of times the signal is sampled per second) is called the sampling rate. When the sampling frequency is higher, the range of frequencies that can be played back are wider. • Quantization bit The number of quantization bits indicate the degree of accuracy when converting the sound level into a numeric value. When the number of quantized bits is higher, the expression of the sound level is more accurate.

WAV Windows standard audio file format, which defines the method of recording the digital data obtained by converting audio signals. By default, the PCM method (no compression) is used, but you can also use other compression methods.

WMA (Windows Media Audio) One of the compressed digital audio formats developed by Microsoft Corporation. With psychoacoustic technologies, this compression method achieves a high compression rate. Reportedly, it is capable of compressing data quantity by about 1/20 maintaining a certain level of audio quality.

■ Others Bi-amplification connection (Bi-amp) A bi-amplification connection uses two amplifiers for a speaker. When you use the bi-amplification connection, the unit drives the tweeter and woofer in a speaker with the discrete amplifiers. As a consequence, the tweeter and woofer provide clear audio signal without the interference.

LFE (Low Frequency Effects) 0.1 channel This channel reproduces low-frequency bass signals and has a frequency range from 20 Hz to 120 Hz. This channel is added to the channels for all bands with Dolby Digital or DTS to enhance low frequency audio effects. This channel is labeled 0.1 because it is limited to only low frequency audio.

Lip sync Video output sometimes lags behind audio output due to the complexity of signal processing caused by an increase in video signal capacity. Lip sync is a technique for automatically correcting the timing lag between audio and video output.

HDMI and video information Component video signal With the component video signal system, the video signal is separated into the Y signal for luminance and the Pb and Pr signals for chrominance. Color can be reproduced more faithfully with this system because each of these signals is independent.

Composite video signal With the composite video signal system, color, brightness, and synchronization data signals are combined and transmitted with a single cable.

Deep Color Deep Color is a technology that HDMI specification s. Deep Color increases the number of available colors within the boundaries defined by the RGB or YCbCr color space. Conventional color systems process the color using 8 bits. Deep Color processes the color with 10, 12, or 16 bits. This technology allows HDTVs and other displays to increase from millions of colors to billions of colors and eliminate on-screen color banding for smooth tonal transitions and subtle gradations between colors.

HDMI HDMI (High-Definition Multimedia Interface) is the world-wide standard interface for digital audio/video signal transmission. This interface transmits both digital audio and digital video signals using a single cable without any loss. HDMI complies with HD (High-bandwidth Digital Content Protection) and provides a secure audio/video interface. For further information on HDMI, visit the HDMI website at “http://www.hdmi.org/”.

MHL MHL (Mobile High-definition Link) is the interface standard for high-speed digital video signal transmission that is developed for mobile devices. This interface transmits both digital audio and digital video signals from mobile devices (such as smartphones) using a single cable with any loss. As with HDMI, MHL complies with HD (High-bandwidth Digital Content Protection).

x.v.Color “x.v.Color” is a technology that the HDMI specification s. It is a more extensive color space than sRGB and allows the expression of colors that were not hitherto possible. While remaining compatible with the color gamut of sRGB standards, “x.v.Color” expands the color space, and thus can produce more vivid, natural images.


En

98

Yamaha technologies CINEMA DSP (Digital Sound Field Processor) Since the Dolby Surround and DTS systems were originally designed for use in movie theaters, their effect is best experienced in a theater that has many speakers designed for acoustic effects. Since home conditions (such as room size, wall material, and number of speakers) can differ so widely, it is inevitable that there are differences in the sound that you hear. Based on a wealth of actually measured data, CINEMA DSP, Yamaha’s original DSP technology provides the audiovisual experience of a movie theater in your own home.

CINEMA DSP 3D The actually measured sound field data contain the information of the height of the sound images. CINEMA DSP 3D mode achieves the reproduction of the accurate height of the sound images so that it creates the accurate and intensive 3D sound fields in a listening room.

Compressed Music Enhancer The Compressed Music Enhancer feature compensates for missing harmonics in compression music formats (such as MP3). As a result, this technology provides improved performance for the overall sound system.

SILENT CINEMA Yamaha has developed a natural, realistic sound effect DSP algorithm for headphones. Parameters for headphones have been set for each sound program, so that accurate representations of all the sound programs can be enjoyed on headphones.

Virtual CINEMA DSP Virtual CINEMA DSP allows the system to virtually reproduce the sound field of the surround speakers with front left and right speakers. Even if the surround speakers are not connected, the unit creates the realistic sound field in a listening room.

Virtual Presence Speaker (VPS) Virtual Presence Speaker allows the system to virtually reproduce the height of the 3D sound field without front presence speakers. Even if the front presence speakers are not connected, the unit creates the 3D sound field in your room.


En

99

Video signal flow

Information on HDMI

Video signals input from a video device to the unit are output to a TV as shown below. Video device

The unit

TV

HDMI Control HDMI Control allows you to operate external devices via HDMI. If you connect a TV that s HDMI Control to the unit with an HDMI cable, you can control the unit (such as power and volume) with TV remote control operations. You can also control playback devices (such as HDMI Control-compatible BD/DVD players) connected to the unit with an HDMI cable. For details on connections, see “Connecting a TV” (p.18) and “Connecting video devices (such as BD/DVD players)” (p.23). Operations available from the TV’s remote control

HDMI in HDMI

• Standby synchronization

HDMI out

HDMI

HDMI

HDMI

• Volume control including mute • Switching to input audio from the TV when the TV input is switched to its built-in tuner • Switching to input video/audio from the selected playback device • Switching between audio output devices (the unit or TV speaker) (Example) HDMI Control

HDMI Control COMPONENT VIDEO in COMPONENT VIDEO

COMPONENT VIDEO

COMPONENT VIDEO out COMPONENT VIDEO

COMPONENT VIDEO

PR

PR

PR

PR

PB

PB

PB

PB

Y

Y

Y

Y

Playback device also turns off

The unit turns off (standby) Turn off the TV

Operations available from the unit’s remote control • Starting playback on the playback device and turning on the TV with a scene selection (p.36)

VIDEO

VIDEO in

VIDEO out

VIDEO

VIDEO

• Switching the TV input to display the “Setup” menu (when SETUP is pressed) VIDEO

• Controlling the playback device (playback and menu operations) without ing remote control codes (p.86)

APPENDIX

➤ Information on HDMI

En

100

(Example)

7 HDMI Control

HDMI Control

Turns on and displays video from the playback device

Playback starts

Press SCENE (BD/DVD)

To use HDMI Control, you need to perform the following HDMI Control link setup after connecting the TV and playback devices.

Check that the unit is properly synchronized with the TV by turning off the TV or adjusting the TV volume with the TV remote control.

• If HDMI Control does not work properly, try unplugging the TV in Step 2 and plugging in the TV again in Step 3. It may solve the problem. Also, HDMI Control may not work if the number of connected devices exceeds the limit. In this case, disable HDMI Control on the devices not in use. • If the unit is not synchronized to the TV’s power operations, check the priority of the audio output setting on the TV. • We recommend using TV and playback devices from the same manufacturer so that HDMI Control works more effectively.

• This setup is required every time you add a new HDMI Control-compatible device to your system.

1 2

Turn on the unit, TV, and playback devices. Enable HDMI Control on the unit, TV, and playback devices (such as HDMI Control-compatible BD/DVD players). To enable HDMI Control on the unit, set “HDMI Control” (p.74) in the “Setup” menu to “On” and configure the related items (“TV Audio Input”, “Standby Sync”, “ARC”, and “SCENE”).

3

Turn off the main power of the TV and then turn off the unit and playback devices.

4 5 6

Turn on the unit and playback devices and then turn on the TV. Switch the TV input to display the video from the unit. Check the followings. On the unit: The input to which the playback device is connected is selected. If not, select the input source manually. On the TV: The video from the playback device is displayed.

APPENDIX


En

101

HDMI signal compatibility Audio signals Audio signal type

Audio signal format

Compatible media (example)

2ch Linear PCM

2ch, 32 to 192 kHz, 16/20/24 bit

CD, DVD-Video, DVD-Audio

Multichannel Linear PCM

8ch, 32 to 192 kHz, 16/20/24 bit

DVD-Audio, BD (Blu-ray disc), HD DVD

DSD

2 to 5.1ch, 2.8224 MHz, 1 bit

SACD

Bitstream

Dolby Digital, DTS

DVD-Video

Bitstream (High definition audio)

Dolby TrueHD, Dolby Digital Plus, DTS-HD Master Audio, DTS-HD BD (Blu-ray disc), HD DVD High Resolution Audio, DTS Express

Video signals The unit is compatible with the video signals of the following resolutions: • VGA

• 720p/60 Hz, 50 Hz

• 480i/60 Hz

• 1080i/60 Hz, 50 Hz

• 576i/50 Hz

• 1080p/60 Hz, 50 Hz, 30 Hz, 25 Hz, 24 Hz

• 480p/60 Hz

• 4K/30 Hz, 25 Hz, 24 Hz

• 576p/50 Hz

• When PM copy-protected DVD-Audio is played back, video/audio signals may not be output, depending on the type of the DVD player. • The unit is not compatible with HD-incompatible HDMI or DVI devices. For details, refer to the instruction manual for each device. • To decode audio bitstream signals on the unit, set the input source device appropriately so that the device outputs the bitstream audio signals directly (does not decode the bitstream signals on the playback device). For details, refer to the instruction manual for the playback device.

APPENDIX


En

102

Reference diagram (rear )

HDMI 1

HDMI OUT

HDMI 2

HDMI 3

HDMI 4

HDMI 5 MHL 5V 1A

(BD/DVD)

NETWORK (NET)

ARC

DC OUT 5V 0.5A

ANTENNA AM

(RADIO) FM

COMPONENT VIDEO

PR

PR

PB

PB

SPEAKERS FRONT

CENTER

SURROUND


Y COMPONENT VIDEO

Y VIDEO

MONITOR OUT 1

OPTICAL

COAXIAL

COAXIAL

OPTICAL

AV 1

AV 2

AV 3

AV 4

( TV )

AV 5

AV 6

AV OUT

AUDIO

2 SUBWOOFER PRE OUT

(HTR-5066 U.S.A. model)

• The area around the video/audio output jacks is marked in white on the actual product to prevent improper connections.

APPENDIX

➤ Reference diagram (rear )

En

103

Trademarks Windows™ Windows is a ed trademark of Microsoft Corporation in the United States and other countries. Manufactured under license from Dolby Laboratories. Dolby, Pro Logic, Surround EX and the double-D symbol are trademarks of Dolby Laboratories. MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.

Internet Explorer, Windows Media Audio and Windows Media Player are either ed trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

Android™ (For HTR-4066) Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567 & other U.S. and worldwide patents issued & pending. DTS-HD, the Symbol, & DTS-HD and the Symbol together are ed trademarks of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

Android is a trademark of Google Inc.

This receiver s network connections.

HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or ed trademarks of HDMI Licensing LLC in the United States and other countries. (For HTR-5066) Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567 & other U.S. and worldwide patents issued & pending. DTS-HD, the Symbol, & DTS-HD and the Symbol together are ed trademarks & DTS-HD Master Audio is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

MHL and the MHL logo are a trademark, ed trademark or service mark of MHL, LLC in the United States and/or other countries.

x.v.Color™ “x.v.Color” is a trademark of Sony Corporation.

“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic accessory has been designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone, or iPad may affect wireless performance. AirPlay, the AirPlay logo, iPad, iPhone, iPod, iPod nano, and iPod touch are trademarks of Apple Inc., ed in the U.S. and other countries.

“SILENT CINEMA” is a trademark of Yamaha Corporation.

DLNA™ and DLNA CERTIFIED™ are trademarks or ed trademarks of Digital Living Network Alliance. All rights reserved. Unauthorized use is strictly prohibited.

APPENDIX

➤ Trademarks

En

104

Specifications Input jacks • Analog Audio Audio x 4 (AV 5–6, AUDIO, V-AUX [Mini Jack]) • Digital Audio (ed frequencies: 32 kHz to 96 kHz) Optical x 2 (AV 1, AV 4)

• Video MONITOR OUT - Composite x 1

MHL

AV OUT

• Video Format (Repeater Mode)

- Composite x 1 • HDMI Output HDMI OUT x 1

Composite x 5 (AV 3–6, V-AUX) Component x 2 (AV 1–2) • HDMI Input HDMI x 5 (HDMI 1–5*) * HDMI 5: MHL input compatible • Other jacks USB x 1 (USB2.0) NETWORK x 1 (100Base-TX/10Base-T)

Output jacks

• Link Function: CEC ed

- Component x 1

Coaxial x 2 (AV 2–3) • Video

• Content Protection: HD compatible

- VGA - 480i/60 Hz - 576i/50 Hz - 480p/60 Hz

Other jacks

- 576p/50 Hz

• YPAO MIC x 1

- 720p/60 Hz, 50 Hz

• DC OUT x 1

- 1080i/60 Hz, 50 Hz - 1080p/30 Hz, 25 Hz, 24 Hz

HDMI • HDMI features: Deep Color, “x.v.Color,” Auto Lip Sync, ARC (Audio Return Channel), 3D, 4K

• Audio Format - PCM 2-ch to 8-ch (Max. 192 kHz/24-bit) • Current Supply Capacity: 1.0 A

• Video Format (Repeater Mode) - VGA

TUNER

• Analog Audio

- 480i/60 Hz

• Analog Tuner

[HTR-5066]

- 576i/50 Hz

[U.K. and Europe models]

- Speaker Out x 7 (FRONT L/R, CENTER, SURROUND L/R,

- 480p/60 Hz

FM/AM with Radio Data System x 1 (TUNER)

SURROUND BACK L/R*)

- 576p/50 Hz

[Other models]

* Note: assignment is possible. [SURROUND BACK,

- 720p/60 Hz, 50 Hz

FM/AM x 1 (TUNER)

BI-AMP (FRONT L/R), ZONE B]

- 1080i/60 Hz, 50 Hz

- Subwoofer Out x 2 (SUBWOOFER 1–2, mono)

- 1080p/60 Hz, 50 Hz, 30 Hz, 25 Hz, 24 Hz

- AV OUT x 1

- 4K/30 Hz, 25 Hz, 24 Hz

- Headphone x 1 [HTR-4066] - Speaker Out x 5 (FRONT L/R, CENTER, SURROUND L/R) - Subwoofer Out x 1 - AV OUT x 1 - Headphone x 1

• Audio Format - Dolby TrueHD - Dolby Digital Plus - Dolby Digital

USB • Capable of iPod, Mass Storage Class USB Memory • Current Supply Capacity: 2.1 A

Network • PC Client Function

- DTS-HD Master Audio

• Compatible with DLNA ver. 1.5

- DTS-HD High Resolution Audio

• AirPlay ed

- DTS Express

• Internet Radio

- DTS - DSD 6-ch - PCM 2-ch to 8-ch (Max. 192 kHz/24-bit)

APPENDIX ➤ Specifications

En

105

Compatible Decoding Formats • Decoding Format - Dolby TrueHD, Dolby Digital Plus - Dolby Digital EX - Dolby Digital - DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS Express - DTS, DTS 96/24, DTS-ES Matrix 6.1, DTS-ES Discrete 6.1 - DTS Digital Surround • Post Decoding Format [HTR-5066] - Dolby Pro Logic - Dolby Pro Logic II Music, Dolby Pro Logic II Movie, Dolby Pro Logic II Game - Dolby Pro Logic IIx Music, Dolby Pro Logic IIx Movie, Dolby Pro Logic IIx Game - DTS Neo:6 Music, DTS Neo:6 Cinema [HTR-4066] - Dolby Pro Logic - Dolby Pro Logic II Music, Dolby Pro Logic II Movie, Dolby Pro Logic II Game - DTS Neo:6 Music, DTS Neo:6 Cinema

Audio Section • Rated Output Power (2-channel driven) [U.S.A. model] (20 Hz to 20 kHz, 0.09% THD, 8 Ω) [Other models] (20 Hz to 20 kHz, 0.09% THD, 6 Ω) Front L/R .................................................................80 W+80 W [U.S.A. model] (1 kHz, 0.9% THD, 8 Ω) Front L/R .................................................................95 W+95 W Center ............................................................................... 95 W Surround L/R...........................................................95 W+95 W Surround Back L/R [HTR-5066]............................. 95 W+95 W

• Rated Output Power (1-channel driven) [U.S.A. model] (1 kHz, 0.9% THD, 8 Ω) [Other models] (1 kHz, 0.9% THD, 6 Ω)

• Frequency Response AV 5 etc. to Front (10 Hz to 100 kHz).......................... +0/-3 dB • Signal to Noise Ratio (IHF-A Network)

Front L/R .....................................................................115 W/ch

AV 5 etc. (Input Shorted 250 mV, Speaker Out)

Center ........................................................................115 W/ch

......................................................................... 100 dB or more

Surround L/R ..............................................................115 W/ch Surround Back L/R [HTR-5066] .................................115 W/ch • Maximum Effective Output Power (JEITA, 1 kHz, 10% THD, 6 Ω) [China, Korea, Asia and General models] Front L/R .....................................................................135 W/ch Center.........................................................................135 W/ch Surround L/R ..............................................................135 W/ch Surround Back L/R [HTR-5066] .................................135 W/ch • Dynamic Power (IHF) [U.S.A. model] HTR-4066: Front L/R (8/6/4/2 Ω)................................110/130/160/180 W HTR-5066: Front L/R (8/6/4/2 Ω)................................120/140/170/190 W [Other models] HTR-4066: Front L/R (6/4/2 Ω)..........................................110/130/160 W HTR-5066: Front L/R (6/4/2 Ω)..........................................120/140/170 W

• Residual Noise (IHF-A Network) Front L/R (Speaker Out) ..................................... 150 µV or less • Channel Separation AV 5 etc. (Input 5.1 kΩ Shorted, 1 kHz/10 kHz) .................................................................60 dB/45 dB or more • Volume Control Range..............................................MUTE, -80 dB to +16.5 dB Step.................................................................................0.5 dB • Tone Control Characteristics Bass Boost/Cut .............................±6 dB/0.5 dB Step at 50 Hz Bass Turnover ................................................................350 Hz Treble Boost/Cut.......................... ±6 dB/0.5 dB Step at 20 kHz Treble Turnover ............................................................. 3.5 kHz • Filter Characteristics (fc=40/60/80/90/100/110/120/160/200 Hz) H.P.F. (Front, Center, Surround).................................12 dB/oct. H.P.F. (Surround Back [HTR-5066]) ..........................12 dB/oct. L.P.F. (Subwoofer) .....................................................24 dB/oct.

• Dynamic Headroom [U.S.A. model] 8 Ω.................................................................................. 0.2 dB • Damping Factor Front L/R, 20 Hz to 20 kHz, 8 Ω............................. 120 or more • Input Sensitivity / Input Impedance AV 5 etc. (1 kHz, 100 W/8 Ω).............................. 200 mV/47 kΩ • Maximum Input Signal AV 5 etc. (1 kHz, 0.5% THD, Effect On) ............................2.3 V • Output Level / Output Impedance AV OUT.............................................................. 200 mV/1.2 kΩ SUBWOOFER........................................................... 1 V/1.2 kΩ • Headphone Jack Rated Output / Impedance AV 5 etc. (1 kHz, 50 mV, 8 Ω) ............................. 100 mV/470 Ω


En

106

Video Section

General

• Video Signal Type

• Power Supply

[U.S.A., Korea and General models]............................... NTSC

[U.S.A. model].................................................AC 120 V, 60 Hz

[Other models].................................................................... PAL

[General model] .............AC110 to 120/220 to 240 V, 50/60 Hz

• Video Signal Level

[China model]..................................................AC 220 V, 50 Hz

Composite ............................................................. 1 Vp-p/75 Ω

[Korea model] .................................................AC 220 V, 60 Hz

Component

[Australia model] .............................................AC 240 V, 50 Hz

Y.......................................................................... 1 Vp-p/75 Ω

[U.K. and Europe models] ..............................AC 230 V, 50 Hz

Pb/Pr ................................................................ 0.7 Vp-p/75 Ω

[Asia model] ....................................AC 220 to 240 V, 50/60 Hz

• Video Maximum Input Level .......................... 1.5 Vp-p or more • Video Signal to Noise Ratio ................................50 dB or more • Monitor Out Frequency Response Component ............................................ 5 Hz to 60 MHz, -3 dB

FM Section • Tuning Range [U.S.A. model] ............................................. 87.5 to 107.9 MHz [Asia and General models]

• Power Consumption [U.S.A. model].................................................... 270 W/320 VA [Other models] ................................................................280 W • Standby Power Consumption HDMI Control Off, Standby Through Off .............. 0.1 W or less HDMI Control On, Standby Through On (No Signals) .......................................................................... 1.0 W (Typical) Network Standby On ......................................... 2.0 W (Typical) • Dimensions (W x H x D)

.......................................87.5/87.50 MHz to 108.0/108.00 MHz

..................... 435 x 161 x 315 mm (17-1/8” x 6-3/8” x 12-3/8”)

[Other models].................................87.50 MHz to 108.00 MHz

* Including legs and protrusions

• 50 dB Quiet Sensitivity (IHF, 1 kHz, 100% MOD.) Mono................................................................. 3 µV (20.8 dBf) • Signal to Noise Ratio (IHF)

• Weight [HTR-5066]......................................................8.2 kg (18.1 lbs) [HTR-4066]......................................................8.1 kg (17.9 lbs)

Mono................................................................................ 71 dB Stereo .............................................................................. 69 dB * Specifications are subject to change without notice.

• Harmonic Distortion (IHF, 1 kHz) Mono................................................................................. 0.3% Stereo ............................................................................... 0.5% • Antenna Input ................................................75 Ω unbalanced

AM section • Tuning Range [U.S.A. model] ................................................ 530 to 1710 kHz [Asia and General models]...... 530/531 kHz to 1710/1611 kHz [Other models]......................................... 531 kHz to 1611 kHz


En

107

Index Symbols

Audio Output (HDMI, Setup menu) 74 Audio Return Channel (ARC) 18 Auto Power Standby (ECO, Setup menu) 77 Auto Preset (FM radio, Option menu) 44 Automatic speaker setting optimization 31 Automatic station preset (FM radio) 44 AutoPowerStdby (ECO, Setup menu) 77 AV OUT jack 9

★/★★ keys 10 Envelope icon (p) 88 Lock icon (o) 79

Numerics 2.1-channel system 14 2ch Stereo (sound program) 39 3.1-channel system 14 4.1-channel system 13 4K signal (video signal resolution) 5.1-channel system 13, 15 5ch Stereo (sound program) 39 6.1-channel system 13 7.1-channel system 13, 15 7ch Stereo (sound program) 39

B 102

A A.DRC (DSP/Surround, Option menu) 65 Access denied (error indication) 96 Access error (error indication) 96 Action Game (sound program) 38 Adaptive DRC (DSP/Surround, Option menu) 65 Adjustment (Lipsync, Setup menu) 76 ADVANCED SETUP menu 83 Adventure (sound program) 38 AirPlay 59 AM antenna connection 27 AM radio listening 43 Amp (Audio Output, Setup menu) 74 ARC (Audio Return Channel) 18 ARC (HDMI, Setup menu) 75 Audio Decoder (front display information) 63 Audio device connection 26 Audio file format (PC/NAS) 54 Audio file format (USB storage device) 51 Audio In (Option menu) 67 AUDIO jack 17

B RATE (Signal Info, Option menu) 66 Banana plug 16 Basic playback operation 35 Bass (Tone Control, Option menu) 65 BI-AMP (Power Amp Assign, Setup menu) Bi-amp speaker connection 16 Bitrate (Signal Info, Option menu) 66 Bitstream 102

Component video connection (video device) 24 COMPONENT VIDEO jack 17 Composite video connection (video device) 24 Compressed Music Enhancer 42 Configuration (HDMI, Setup menu) 74 Configuration (Speaker, Setup menu) 71 Connect error (error indication) 96 Crossover (Speaker, Setup menu) 72 Crossover frequency setting 72 Crossover frequency setting (subwoofer) 31

D 71

C CAT-5 cable 28 Cellar Club (sound program) 39 Center (Speaker, Setup menu) 71 Center Image (DSP Parameter, Setup menu) 76 Center Width (DSP Parameter, Setup menu) 76 Chamber (sound program) 39 CHAN (Signal Info, Option menu) 66 Channel (Signal Info, Option menu) 66 Check SP Wires (error indication) 96 Check Sur. (YPAO error message) 33 CINEMA DSP 38 CINEMA DSP 3D 40 CINEMA DSP 3D Mode (DSP Parameter, Setup menu) 75 Clear Preset (FM/AM radio, Option menu) 45 Clock Time (Radio Data System) 46 COAXIAL jack 17 Component video cable 17

DC OUT (Function, Setup menu) 79 DC OUT jack 9 Decoder Off (front display information) 63 Default Gateway (Information, Setup menu) 80 Default Gateway (IP Address, Setup menu) 80 DH (IP Address, Setup menu) 80 Digital coaxial cable 17 Digital Media Controller (DMC) 81 Digital optical cable 17 Dimension (DSP Parameter, Setup menu) 76 Dimmer (Function, Setup menu) 79 DIRECT (sound mode) 41 Direct playback 41 Direct Stream Digital (DSD) 97 Distance (Speaker, Setup menu) 73 DLNA 54 DMC (Digital Media Controller) 81 DMC Control (Network, Setup menu) 81 DNS Server (Information, Setup menu) 80 DNS Server (IP Address, Setup menu) 80 Dolby Digital EX (Extended Surround) 65 Dolby Pro Logic (surround decoder) 41 Dolby Pro Logic II Game (surround decoder) 41 Dolby Pro Logic II Movie (surround decoder) 41 Dolby Pro Logic II Music (surround decoder) 41 Dolby Pro Logic IIx Game (surround decoder) 41

APPENDIX

➤ Index

En

108

Dolby Pro Logic IIx Movie (Extended Surround) 65 Dolby Pro Logic IIx Movie (surround decoder) 41 Dolby Pro Logic IIx Music (Extended Surround) 65 Dolby Pro Logic IIx Music (surround decoder) 41 Drama (sound program) 38 DSD (Direct Stream Digital) 97 DSP Level (DSP/Surround, Option menu) 65 DSP Parameter (Sound, Setup menu) 75 DSP Program (front display information) 63 DSP/Surround (Option menu) 65 DTS Neo:6 Cinema (surround decoder) 41 DTS Neo:6 Music (surround decoder) 41 DTS-ES (Extended Surround) 65 Dynamic Range (Volume, Setup menu) 77

Format (Signal Info, Option menu) 66 Frequency (FM/AM radio) 43 Frequency step setting 43, 84 Front (Speaker, Setup menu) 71 Front display (part names and functions) 8 Front display brightness 79 Front display information 63 Front (part names and functions) 7 Front jack connection 26 Function (Setup menu) 78

E

Hall in Munich (sound program) 39 Hall in Vienna (sound program) 39 HDMI (Setup menu) 74 HDMI cable 17 HDMI connection (video device) 23 HDMI Control (HDMI, Setup menu) 74 HDMI jack 17 HDMI OUT (TV) (Audio Output, Setup menu) HDMI signal compatibility 102 Headphones 42 High definition audio 102 High speed HDMI cable 17

ECO (Setup menu) 77 ECO Mode (Setup menu) 78 Enhancer (DSP/Surround, Option menu) 66 ENHANCER (sound mode) 42 EQ Select (Equalizer, Setup menu) 73 Equalizer (Speaker, Setup menu) 73 Error indication (front display) 96 EX/ES (Extended Surround, Option menu) 65 EXTD (DSP/Surround, Option menu) 65 Extended Surround (DSP/Surround, Option menu) 65 External device control (remote control) 85 External device operation key (remote control) 10 Extra Bass (Speaker, Setup menu) 72

F Filter (MAC Address Filter, Setup menu) 81 Firmware update 84 Firmware update (network) 84, 88 Firmware update (USB) 84 Firmware Version (Network Update, Setup menu) Firmware version check 84 FM antenna connection 27 FM radio listening 43 FM/AM radio tuning 43 FORMAT (Signal Info, Option menu) 66

82

Input Trim (Volume Trim, Option menu) 66 Interlock (Option menu) 67 Internal Err. (YPAO error message) 33 Internal Error (error indication) 96 Internet radio listening 57 IP Address (Information, Setup menu) 80 IP Address (Network, Setup menu) 80 iPod charge 47 iPod connection 47 iPod content playback 48 iPod content playback (AirPlay) 59 iTunes content playback (AirPlay) 59

G GEQ (Equalizer, Setup menu)

73

L

H

I In.Trim (Volume Trim, Option menu) 66 Indicator (part names and functions) 8 INFO key 7, 10 Information (Network, Setup menu) 80 Information display (front display) 8 Information switching (front display) 63 INIT (ADVANCED SETUP menu) 84 Initial Volume (Volume, Setup menu) 77 Input (front display information) 63 Input (Signal Info, Option menu) 66 Input Rename (Function, Setup menu) 78 Input selection key (remote control) 10

74

Language (Setup menu) 82 Level (Speaker, Setup menu) 73 Level Error (YPAO warning message) LFE (Low Frequency Effects) 98 Lipsync 98 Lipsync (Option menu) 66 Lipsync (Sound, Setup menu) 76 Low Frequency Effects (LFE) 98

34

M MAC Address (Information, Setup menu) 80 MAC Address (MAC Address Filter, Setup menu) MAC Address Filter (Network, Setup menu) 81 Manual station preset (FM/AM radio) 44 Max Volume (Volume, Setup menu) 77 Media sharing setup 54 Memory Guard (Function, Setup menu) 79 Menu language selection 30 Menu operation key (remote control) 10 MHL cable 17 MHL connection 23 MHL jack 17 MHL Overloaded (error indication) 96 MHL-compatible mobile device 23 MODE key 10 Monaural reception (FM radio) 43 Mono Movie (sound program) 38

APPENDIX

➤ Index

81

En

109

PC content playback 54 PEQ (Equalizer, Setup menu) 73 Perform Update (Network Update, Setup menu) 82 PHONES jack 7 Playback device connection 23 Playback device operation (remote control) 86 Please wait (error indication) 96 Power Amp Assign (Speaker, Setup menu) 71 Power cable connection 29 Power management 77 Power Mode (DC OUT, Setup menu) 79 Preset station selection (FM/AM radio) 45 Program Service (Radio Data System) 46 Program Type (Radio Data System) 46

MOVIE (sound program category) 38 Multiple room playback 61 MUSIC (sound program category) 39 Music Video (sound program) 39 MUTE key 10 Muting 35

N NAS (Network Attached Storage) 28 NAS connection 28 NAS content playback 54 Network (Setup menu) 80 Network Attached Storage (NAS) 28 Network cable 28 Network connection 28 Network information 80 Network Name (Network, Setup menu) 81 Network Standby (Network, Setup menu) 81 Network Update (Network, Setup menu) 82 No content (error indication) 96 No device (error indication) 96 No Front SP (YPAO error message) 33 No MIC (YPAO error message) 33 No Signal (YPAO error message) 33 No Sur. SP (YPAO error message) 33 Noisy (YPAO error message) 33 NTSC (TV FORMAT, ADVANCED SETUP menu) Numeric key (remote control) 10

R

84

O OPTICAL jack 17 OPTION key 10 Option menu 64 Out of Phase (YPAO warning message) 34 Output (Signal Info, Option menu) 66 Over Distance (YPAO warning message) 34

P PAL (TV FORMAT, ADVANCED SETUP menu) Panorama (DSP Parameter, Setup menu) 75 PC connection 28

84

Radio Data System (FM radio) 46 Radio Data System information 46 Radio Data System tuning 46 Radio Text (Radio Data System) 46 Rear (part names and functions) 9 Recording device connection 29 RemID Mismatch (error indication) 96 Remote control (part names and functions) 10 Remote control code registration (playback device) 86 Remote control code registration (TV) 85 Remote Control Code Search 85, 86 Remote control ID setting 83 Remote control ID setting (remote control) 83 Remote control sensor 7 Remote control signal transmitter (remote control) REMOTE ID (ADVANCED SETUP menu) 83 Rename (input name) 78 Rename (network name) 81 Repeat (iPod, Option menu) 50 Repeat (PC/NAS, Option menu) 56 Repeat (USB storage device, Option menu) 53 Reset (remote control) 87 Roleplaying Game (sound program) 38

10

Router connection

28

S SAMPL (Signal Info, Option menu) 66 Sampling (Signal Info, Option menu) 66 SBR → SBL (YPAO error message) 33 SCENE (HDMI, Setup menu) 75 Scene configuration 36 SCENE function 36 SCENE link playback 36 Sci-Fi (sound program) 38 Select (Lipsync, Setup menu) 76 SETUP key 10 Setup menu 68 Shuffle (iPod, Option menu) 50 Shuffle (PC/NAS. Option menu) 56 Shuffle (USB storage device, Option menu) Signal Info (Option menu) 66 Signal information 66 SILENT CINEMA 42 Simple play (iPod) 49 SLEEP key 10 Sleep timer 10 Sound (Setup menu) 75 Sound field effect 38 Sound mode selection 37 Sound program 38 SP IMP. (ADVANCED SETUP menu) 83 Speaker (Setup menu) 71 Speaker cable connection 16 Speaker connection 15 Speaker impedance 12 Speaker impedance setting 14, 83 Speaker indicator (front display) 8 Speaker placement 12 Spectacle (sound program) 38 Sports (sound program) 38 Standard (sound program) 38 Standby indicator (front ) 7 Standby Sync (HDMI, Setup menu) 75

APPENDIX

53

➤ Index

En

110

Standby Through (HDMI, Setup menu) 74 Station preset (FM/AM radio) 44 Status (Information, Setup menu) 80 Stereo mini jack 17 Stereo mini-plug cable 17 Stereo pin cable (RCA cable) 17 Stereo reception (FM radio) 43 STP network cable 28 STRAIGHT (sound mode) 40 Straight decode 40 Subnet Mask (Information, Setup menu) 80 Subnet Mask (IP Address, Setup menu) 80 Subwoofer (Speaker, Setup menu) 71 Subwoofer connection 16 Subwoofer Phase (Speaker, Setup menu) 72 Subwoofer Trim (Volume Trim, Option menu) 66 SUR.DECODE (sound mode) 41 Surround (Speaker, Setup menu) 72 Surround Back (Speaker, Setup menu) 72 Surround decoder 41 SW.Trim (Volume Trim, Option menu) 66 System ID (Network Update, Setup menu) 82

T Test Tone (Speaker, Setup menu) 73 The Bottom Line (sound program) 39 The Roxy Theatre (sound program) 39 Tone Control (Option menu) 65 TONE CONTROL key 7 TP (Traffic Program) 46 Traffic information (Radio Data System) 46 Traffic Program (FM radio, Option menu) 46 Treble (Tone Control, Option menu) 65 TU (ADVANCED SETUP menu) 84 TV Audio Input (HDMI, Setup menu) 74 TV connection 18 TV connection (ARC-compatible TV) 18 TV connection (HDMI Control-compatible TV) 20 TV connection (TV with HDMI input jacks) 21 TV connection (TV without HDMI input jacks) 22

TV FORMAT (ADVANCED SETUP menu) TV operation (remote control) 85 TV operation key (remote control) 10

U Unable to play (error indication) 96 Unknown iPod (error indication) 96 UPDATE (ADVANCED SETUP menu) 84 USB jack 7 USB mass storage class device 51 USB Overloaded (error indication) 96 USB storage device connection 51 USB storage device content playback 51 Cancel (YPAO error message) 33

V V IN (Signal Info, Option menu) 66 V OUT (Signal Info, Option menu) 66 VERSION (ADVANCED SETUP menu) 84 VIDEO AUX jack 7 Video device connection 23 VIDEO jack 17 Video Out (Option menu) 67 Video pin cable 17 Video signal flow 100 Video signal type setting 84 Video/audio input jack combination 25 Virtual CINEMA DSP 40 Virtual Presence Speaker (VPS) 6 Voltage selection 29 VOLTAGE SELECTOR 9 Volume (Sound, Setup menu) 77 Volume Interlock (Option menu) 67 Volume Trim (Option menu) 66 VPS (Virtual Presence Speaker) 6 vTuner ID (Information, Setup menu) 80

84

YPAO (Yamaha Parametric room Acoustic Optimizer YPAO error message 33 YPAO MIC jack 7 YPAO microphone 31 YPAO warning message 34

31

Z ZB.Trim (Volume Trim, Option menu) 62 Zone B 61 Zone B (Power Amp Assign, Setup menu) 71 Zone B operation 62 Zone B preparation 61 Zone B speaker connection 61 Zone B Volume (Volume, Setup menu) 77 Zone B volume adjustment 62 ZONE indicator (front display) 8 ZONE key 10 ZoneB Trim (Volume Trim, Option menu) 62

Y Yamaha Parametric room Acoustic Optimizer (YPAO)

31

APPENDIX

➤ Index

En

111

© 2013 Yamaha Corporation YF214A0/EN

Yamaha Receiver Htr-4066 Owner's Manual 702s19

Overview 3z723u

More details 2i4a6q

Related Documents g842

Yamaha Fx140 Owners Manual 5b3o6d

Yamaha Rxv379 Owners Manual 5n713d

Yamaha Moxf Editor Owners Manual 502h2x

Yamaha Aerox 50 Owners Manual 343q54

Yamaha Pro R3 Owners Manual 12286u

Yamaha Clp 880 Owners Manual 4o3bn

More Documents from "Debra Barret" 3m493l

Yamaha Receiver Htr-4066 Owner's Manual 702s19

Euroschiavi Marco Della Luna Antonio Miclavez Pdf 6r1932

347259299-479-mcqs-for-osmt-medical-lab-technician-exams-pauljonesblog-com.pdf 711330

Ferro Manganese Slag Pdf 4b1141

Ethanol Production By Fermentation Pdf 2b5q3j

Rice Diet Kempner.pdf 4s3i5g
