DX 350

Tower WiMAX Indoor IAD Modem

The World’s Leading WiMAX Integrated Access Device

www.greenpacket.com Version 02.01

WiMAX Indoor IAD Modem DX is part of Greenpacket’s portfolio of next generation Wave 2 compliant WiMAX

VoIP Capabilities

Modems for residential and enterprise s. It is a WiMAX Integrated Access Device (IAD) that features a blend of aesthetics, data and voice access ports, high gain antennas with omni directional performance to offer best-in-class performance. DX is packaged with a high speed wireless LAN access point that

Home and SOHO s

Multi –

enables multiple WiFi-enabled devices to enjoy a stable wireless WiMAX connectivity anytime within indoor perimeters.

Key Features • • • • • • • • •

IEEE 802.16e WiMAX Wave 2 Compliant s IEEE 802.11 b/g/n TDD SOFDMA MIMO Matrix A and B Operates within 3.3GHz to 3.6GHz Frequency Range 5, 7, 10MHz Channel Bandwidth Up to 28dBm Transmission Power 5dBi Antenna Gain Up to 30Mbps Throughput*

• • • • • • • • •

802.11n Access Point 2 LAN Ports (RJ-45) & 2 VoIP Ports (RJ-11) IP Router with Security 5 Classes of QoS s TR069/OMA-DM (Optional) Dual Omni Antenna 2Tx, 2Rx with Two 25dBm Tx power Over-the-air Firmware Upgrade Smart QoS for VoIP Packets

Benefits

MIMO A&B

IEEE 802.16e WiMAX Wave 2Compliant

- Advanced WiMAX feature that delivers the best portable and mobile experience on a globally certified and recognized broadband standard.

s IEEE 802.11b/g/n

- World’s first WiMAX + WiFi ( b/g/n )modem; Creating ultimate mobility and convenien through Next-Gerneration WiFi performance for Next-gerneration applications. Up to 15x leap in speeds and 10x extension of the WiFi coverage.

TDD SOFDMA

- Robust performance to combat interference and allows scalable asymmetric downlink/uplink bandwith utilization.

MIMO Matrix A & B

- Enhances indoor penetration, coverage and bandwidth capacity even in diffcult environments to deliver unparalleled experience.

Up to 28dBm Transmission Power

5dBi Antenna Gain Up to 30Mbps Throughput*

TR 069 360°

- Above industry average high transmission power to combat technological uplink performance limitations resulting in greater range performance, reduced network re-connects and dropped packets for a consistent service coverage. - Reduces the number of "coverage holes" for a an uninterrupted connectivity experience throughout WiMAX coverage zones. - 4G speeds for an enhanced quad-play experience delivering faster file transfers, HD video experiences, uninterrupted multi-player online gaming sessions, crisp and clear VoIP experience and high-speed web browsing.

2 LAN Ports ( RJ-45) & 2 VoIP Ports (RJ-11)

- Essential multi-, multi-port flexbility to enable carrier-class data & voice service for home and SOHD s.

5 Classes of QoS

- Ability to assign priority levels to multiple criteria such as applications, s and data flow, to a guaranteed level of performance.

s TR069

- Flexible and convenient way to manage devices remotely, securely and effciently.

Dual Omni Antenna

- Omni antenna with 5dBi gain, radiates and receives WiMAX signals from ay direction for greater flexibility in modem placement.

2Tx, 2Rx with Two 25dBM Tx power - Intelligently and automatically selects best antenna to improve signal strength for better uplink performance. Over-the-air Firmware Upgrade

* Subject to field conditions.

- Reduce service hassle and allow s to quickly and easily get connected online.

Technical Specification Networking

Physical Layer - IEEE 802.16e-2005 (WiMAX) Wave 2

DNS

- Yes

- IEEE 802.11b/g/n (WiFi)

NAT

- Yes

- Up to 30Mbps (DL), 6Mbps(UL)

DH

- Yes

- 20+ Mbps at 64QAM

Firewall

- Yes

Frequency Range

- 3.3GHz to 3.6GHz

Management Interface

- HTTP / HTTPs / FTP / TFTP client

Channel Bandwidth

- 5, 7, 10MHz

- SSL v2/3 / TLS 1.0

Adaptive Modulation

- QPSK 1/2, 3/4

- Web GUI (HTTP, HTTPs, HTML)

- 16QAM 1/2, 3/4

- CLI (Telnet, SSHv2)

Standard Data Rate

- UPnP

- 64QAM 1/2, 2/3, 3/4, 5/6 Maximum RF Transmit

- 25 dBm x 2 Transmit with UL MIMO

Remote Configuration and - TR069 Management Protocols

- SNMP v2c

Antenna Type

- Integrated Omni Antenna (5dBi)

Local Configuration

- Web browser access, CLI, Telnet

Receive Sensitivity

- Average 5dB higher receive sensitivity than

Management

MIMO

- Matrix A/B

Beamforming

- AMC 2X3 with sounding

Power

RCT WiMAX Forum specifications

- UL sounding

Multimedia Basic

- PUSC with dedicated pilots

Package

Convergence

- IEEE 802.3/ Ethernet CS

Sub-layer Service

- IPv4 CS - IPv6 CS - IEEE 802.1Q VLAN CS - IPv4 & IPv6 over IEEE 802.3 / Ethernet CS - Advanced Scheduling Algorithm with full QoS

- OTA (Over-the-air) software upgrade

Interface

- AMC 2x3 with dedicated pilots

MAC Layer

QoS Scheduler Options

Software Maintenance

- 10/100 Base-T (RJ-45) x 2

VoIP Gateway Package

- POTS (RJ-11) x 2

WiFi AP

- 802.11b/g/n

VoIP Caller ID Voice Enhancement DTMF Codec

-

- Unsolicited Grants (UGS) -

- Extended Real-time Polling Service (ertPS) - Real-time Polling Service (rtPS) - Non-real-time Polling Service (nrtPS) - Best Effort (BE) Radio Optimization

- ARQ and HARQ - Payload header suppression

Fax Voice Processing

- Robust header compression Security Options

- EAP client TLS and TTLS

QoS

Yes Yes Yes G711 (a-Law & u-Law) Optional: G.729 (a / b) G.726 G.723.1 iLBC Fax & Modem through T.38 G168 Echo cancelling Voice activity detection Comfort noise generation IP TOS

- End-to-end PKMv2 - Authentication based on X.509 certificate

Product Measurements

WiFi Standard Antenna Gain Modulation

Security

QoS

IEEE 802.11b/g/n Standard, WiFi Compliant 2dBi (Peak) 802.11b: CCK, DQPSK, DBPSK 802.11g: 64QAM, 16QAM, QPSK, BPSK 802.11n: 64QAM, 16QAM, QPSK, BPSK 64/128-bit WEP, WPA/WPA2 (Personal,Enterprise), 802.1x

-

802.11b: 16.5dBm ± 1.5dB 802.11g: 13dBm ± 1.5dB 802.11n: 13dBm ± 1.5dB (20MHz only) WMM

195.2mm

Transmitted Power

-

Electrical & Mechanical Dimensions (H x W x D)

- 195.2mm x 171.9mm x 95.2mm

Weight

- 450g

MTBF

- 300,000 @ 40°C

Power Supply

- AC 100 ~ 240V 50 / 60Hz 0.8A, DC 12V / 2A

Power Consumption

- < 24W

Temperature

- 0°C ~ 45°C (Operating) - -20°C ~ 55°C (Storage)

Humidity

- 10% - 85% non-condensing (Operating)

Material

- RoHS compliant

17 95

.2m

1.

9m

m

m

* Product specifications are subject to change without prior notice.
