Here are some common formulas that are frequently used in the field.

Options: - Motor Formulas - Transformer Formulas E = Voltage / I = Amps /W = Watts / PF = Power Factor / Eff = Efficiency / HP = Horsepower

AC/DC Formulas To Find

Direct Current

Amps when Horsepower is Known

HP x 746 E x Eff kW x 1000 E

Amps when Kilowatts is known Amps when kVA is known Kilowatts

IxE 1000

Kilovolt-Amps Horsepower (output)

I x E x Eff 746

AC / 1phase 115v or 120v

AC / 1phase 208,230, or 240v

AC 3 phase All Voltages

HP x 746 HP x 746 HP x 746 E x Eff X PF E x Eff x PF 1.73 x E x Eff x PF kW x 1000 kW x 1000 kW x 1000 E x PF E x PF 1.73 x E x PF kVA x 1000 kVA x 1000 kVA x 1000 E E 1.73 x E I x E x PF I x E x PF I x E x 1.73 PF 1000 1000 1000 IxE I x E x 1.73 IxE 1000 1000 1000 I x E x Eff x PF I x E x Eff x PF I x E x Eff x 1.73 x PF 746 746 746

Three Phase Values For 208 volts x 1.732, use 360 For 230 volts x 1.732, use 398 For 240 volts x 1.732, use 416 For 440 volts x 1.732, use 762 For 460 volts x 1.732, use 797 For 480 Volts x 1.732, use 831 E = Voltage / I = Amps /W = Watts / PF = Power Factor / Eff = Efficiency / HP = Horsepower

AC Efficiency and Power Factor Formulas To Find

Single Phase

Three Phase

5/20/2011 5:01 PM

Useful Formulas

2 of 3

http://www.elec-toolbox.com/Formulas/Useful/formulas.htm

Efficiency Power Factor

746 x HP E x I x PF

746 x HP E x I x PF x 1.732

Input Watts VxA

Input Watts E x I x 1.732

Power - DC Circuits Watts = E xI Amps = W / E

Ohm's Law / Power Formulas

P = watts I = amps R = ohms E = Volts

Voltage Drop Formulas VD = Single Phase (2 or 3 wire) CM=

2 xKxIxL CM 2K x L x I VD

K = ohms per mil foot (Copper = 12.9 at 75°) (Alum = 21.2 at 75°) Note: K value changes with temperature.

See Code chapter 9, Table 8

VD=

1.73 x K x I x L L = Length of conductor in feet CM

CM=

1.73 x K x L x I VD

Three Phase

I = Current in conductor (amperes) CM = Circular mil area of conductor

Check out these Online Calculators! If there is anything you would like to add or if you have any comments please feel free to email E.T.E. at http://www.elec-toolbox.com/email.htm. Back to Main Page
