Umts/3g/wcdma Call Flows 442kw

c

Random Access Channel (RACH) Procedure c

RACH is a common transport channel in the uplink and is always mapped one-to-one onto physical channels (PRACHs). In one cell, several RACHs/PRACHs may be configured. If more than one PRACH is configured in a cell, the UE performs PRACH selection randomly. The parameters for RACH access procedure includes: access slots, preamble scrambling code, preamble signatures, spreading factor for data part, available signatures and sub-channels for each Access Service Class (ASC) and power control information. The Physical channel information for PRACH is broadcasted in SIB5/6 and the fast changing cell parameters such as uplink interference levels used for open loop power control and dynamic persistence value are broadcasted in SIB7. RACH access procedure follows slotted-ALOHA approach with fast acquisition indication combined with power ramping in steps. Maximum of 16 different PRACHs can be offered in a cell, in FDD, the various PRACHs are distinguished either by employing different preamble scrambling codes or by using common scrambling code with different signatures and sub-channels. With in a single PRACH, a partitioning of the resources between the maximum 8 ASC is possible, thereby providing a means of access prioritization between ASCs by allocating more resources to high priority classes than to low priority classes.ASC 0 is assigned highest priority and ASC 7 is assigned lowest priority.ASC 0 shall be used to make emergency calls which has got more priority. The available 15 access slots are split between 12 RACH sub-channels. The RACH transmission consists of two parts, namely preamble transmission and message part transmission. The preamble part is 4096 chips, transmitted with spreading factor 256 and uses one of 16 access signatures and fits into one access slot. ASC is defined by an identifier i that defines a certain partition of the PRACH resources and is associated with persistence value P(i). The persistence value for P(0) is always set to one and is associated with ASC 0.The persistence values for others are calculated from signaling. These persistence values controls the RACH transmissions. À ÀÀAÀ HE RACH PROCEDURE To start a RACH procedure, the UE selects a random number, between 0 and 1 and if r<= P(i), the physical layer PRACH procedure is initiated else it is deferred by 10 ms and then the procedure is started again. Once the UE PRACH procedure is initiated, then the real transmission takes place. PREAMBLE A D DAA PAR RA MÀÀO As described above, the preamble part transmission starts first. The UE picks one access signature of those available for the given ASC and an initial preamble power level based on the received primary ICH power level and transmits by picking randomly one slot out of the next set of access slots belonging to one of the PRACH sub-channels associated with the relevant ASC.

c

The UE then waits for the appropriate access indicator sent by the network on the downlink Acquisition Indicator Channel (AICH) access slot which is paired with the uplink access slot on which the preamble was sent. There are 3 possible scenarios possible. 1.c If the Acquisition Indication (AI) received is a positive acknowledgement, then UE sends the data after a predefined amount of with a power level which is calculated from the level used to send the last preamble. 2.c IF the AI received is a negative acknowledgement, the UE stops with the transmission and hands back control to the MAC layer. After a back-off period, the UE will regain access according to the MAC procedure based on persistence probabilities. å c If no acknowledgement is received, then it is considered that network did not receive the preamble. If the maximum number of preambles that can be sent during a physical layer PRACH procedure is not exceeded, the terminal sends another preamble by increasing the power in steps. The ability of the UE to increase its output power, in of steps to a specific value is called as open loop power control. RACH follows open loop power controlc c c c c c c c c c c c c c c c c c

c

åUM Complete Mobile Circuit itched Call etup

Originated

c

c

£ stem Ànformation (BCCH) The UE reads the System Information that is broadcast on BCCH. The information is not read continuously. It is only read if the information changes D RRC: RRC Connection Request (CCCH) The Mobile decides to initiate a voice call. The first message the UE will send on CCCH is RRC Connection Request. This will contain among other things, Initial UE Identity and Establishment Cause å

BAP: Radio Link etup Request

The SRNC sends this message to Node B. It will the Cell Id, TFS, TFCS, frequency, UL Scrambling code, etc to Node B. 4

BAP: Radio Link etup Response

Node B allocates the resources and starts PHY Reception. While transmitting the response it includes the Transport layer addressing information that includes the Binding Identity of the AAL2 for Iub data transport bearer 5 ALCAP: Establish REQ The AAL2 binding identity (Iub Data Transport Bearer Id) is ed to ALCAP protocol in Node B. The Iub Data Transport bearer is now bounce to DCH. 6 ALCAP: Establish C Establish confirm from ALCAP in Node B : DCH-P: Donlink nchronization The Node B and SRNC establishes synchronization for the Iub Data Transport bearer by means of exchange of the appropriate DCH Frame Protocol frames. 8: DCH-P: Uplink nchronization Once the UL synchronization is achieved, Node B starts DL transmission. 9: RRC: RRC Connection etup (CCCH) RRC Connection Setup message is sent on CCCH with the parameters required to establish DCH. Also the state indicator will be set to DCH for the voice (or CS) call. £: BAP: Radio Link Restore Àndication Once the UE establishes Radio Link, Node B will send RL Restore indication to the SRNC. ££: RRC: RRC Connection etup Complete (DCCH)

c

RRC Connection Setup complete will be sent on DCCH. Integrity and Ciphering related parameters and UE capability information will be sent back to SRNC £D: RRC: Ànitial Direct ransfer [CM ervice Request] First NAS message is now sent by the UE. It indicates that a UE originated Voice call is required. The UE identity (TMSI) will also be ed in this message £å: RA AP: Ànitial UE Message [CM ervice Request] The NAS message will be forwarded to appropriate CN Domain (CS Domain in this case). Along with the CM service request, it will also include LAI and SAI. £4: RA AP: Direct ransfer [Authentication Request] MSC/VLR needs to perform authentication to make sure that the UE is genuine. For this reason it will challenge the UE with a Authentication token and RAND (random number) £5: RRC: Donlink Direct ransfer [Authentication Request] SRNC transfers the NAS message to the UE £6: RRC: Uplink Direct ransfer [Authentication Response] UE computes the response (RES) and sends it back in the NAS message £: RA AP: Direct ransfer [Authentication Response] SRNC relays the response to the MSC/VLR. The MSC/VLR will compare the response RES with the expected response XRES. If they are the same then the procedure will continue. £8: RA AP: ecurit Mode Command MSC/VLR sends the Security Mode Command to start Ciphering and Integrity Protection. Ciphering is optional while Integrity Protection is mandatory. The Algorithms, etc are known to the MSC/VLR and the UE and only the ones that are common between them are used. £9: RRC: ecurit Mode Command RRC Forwards the Security Mode command received from MSC/VLR to the UE. D: RRC: ecurit Mode Complete The UE configures the Ciphering and Integrity Protection and responds back to the network. The response message is Integrity Protected for further safety. Ciphering is started at Ciphering activation time. Since this is a Circuit switched call, the Ciphering will be started in MAC. In case of AM and UM bearers it is started in RLC. D£: RA AP: ecurit Mode Complete

c

The network forwards the Security Mode Complete message to MSC/VLR. DD: RA AP: Direct ransfer [MÀ Reallocation Command] The network may decide to re-allocate the TMSI to the UE. It sends a DT message which includes the NAS TMSI Reallocation Command. Då: RRC: DL Direct ransfer [MÀ Reallocation Command] The RNC relays the DT message to the UE. D4: RRC: UL Direct ransfer [MÀ Reallocation Complete] The UE takes the new TMSI and responds with the Complete message D5: RA AP: Direct ransfer [MÀ Reallocation Complete] The RNC relays the message to the CN domain D6: RRC: UL Direct ransfer [etup] The UE now sends the 'Setup' message in UL Direct Transfer message. This will include all the required parameters for setting up the voice call. It will include the number that UE wishes to be ed and the bearer capability D: RA AP: Direct ransfer [etup] The network relays the message to the MSC/VLR D8: RA AP: Direct ransfer [Call Proceeding] The MSC/VLR sends Call Proceeding to the UE indicating that it is now starting with the RAB establishment procedure. D9: RRC: DL Direct ransfer [Call Proceeding] The network relays it to the UE. å: RA AP: RAB Assignment Request The CN initiates establishment of the Radio Access Bearer using the RAB Assignment Request message. This message includes the QoS of the call being established, the Transport Address, Iu Transport association, etc. å£: ALCAP: Establish REQ SRNC initiates the set-up of Iu Data Transport bearer using ALCAP protocol. The request contains the AAL2 Binding Identity to Bind the Iu Data Transport Bearer to the RAB. (Note that this is not done in case of PS RAB)

c

åD: ALCAP: Establish C The CN responds with the ALCAP Establish CNF åå: BAP: Radio Link Reconfiguration Prepare SRNC requests Node B to prepare establishment of DCH to carry the RAB. It es the TFS, TFCS and Power Control Information in the message. å4: BAP: Radio Link Reconfiguration Read Node B allocates the resources and responds with the Ready message. It sends back the AAL2 address and the AAL2 binding Id for the Iub data transport bearer. å5: ALCAP: Establish REQ SRNC initiates setup of Iub Data Transport Bearer using ALCAP protocol. The request contains the AAL2 Binding Identity to bind the Iub Data Transport Bearer to DCH. å6: ALCAP: Establish C The Node B responds with the Establish Confirm. å: DCH-P: Donlink nchronization The Node B and SRNC establish synchronism for the Iub Data Transport Bearer by means of exchange of the appropriate DCH frame protocol frames. SRNC sends the DL Synchronization frames. å8: DCH-P: Uplink nchronization The Node B responds with the UE Synchronization frames. å9: BAP: Radio Link Reconfiguration Complete Finally the SRNC instructs the Node B of the CFN at which the new configuration will come into effect. 4: RRC: Radio Bearer etup SRNC sends the RB Setup message to add the new DCH's. The message will be received using the old configuration. 4£: RRC: Radio Bearer etup Response After the activation time the UE will respond with complete message using the new configuration. 4D: RA AP: RAB Assignment Response

c

The SRNC responds with the response to the MSC/VLR. 4å: ÀUP: Ànitial Address Message MSC/VLR sends the Initial Address Message to the PSTN. The message tells the PSTN to reserve an idle trunk circuit from originating switch to the destination switch. 44: ÀUP: Address Complete Message The ACM message is sent to indicate that the remote end of the trunk circuit has been reserved. 45: RA AP: Direct ransfer [Alert] The Alert message is sent to the SRNC. This message contains the ACM received from the PSTN. 46: RRC: Direct ransfer [Alert] The Alert message is forwarded to the UE. The Alert message will initiate the ringing tone on the handset. 4: ÀUP: Anser Message When the person that is being called picks up his phone, an Answer message is sent to the MSC/VLR. 48: RA AP: Direct ransfer [Connect] The MSC/VLR sends the Connect message to the SRNC via Direct Transfer message. The Connect message indicates that the End has answered the call. 49: RRC: DL Direct ransfer [Connect] The SRNC forwards the Connect message to the UE. 5: RRC: UL Direct ransfer [Connect Acknoledge] The UE confirms the reception of the Connect message using the Connect Acknowledge and sending it via Direct Transfer 5£: RA AP: Direct ransfer [Connect Acknoledge] The Network forwards the Connect Acknowledge to the MSC/VLR. The call has now been successfully established. c c c c

c

Message equence for UE Registration on Circuit itched and Packet itched Domain

c

c c c

c

Message sequence for Mobile Originated and Mobile erminated Circuit itched Call

c

c

Message sequence for Mobile Originated and Mobile erminated Packet itched Call

c

c

c

A look at Ànter-requenc Measurements À According to 3GPP specifications, a UE is required to many different kinds of measurements. The most commonly used are intra-frequency measurements, interfrequency measurements and traffic volume measurements. In this article we will look at Inter-Frequency measurements. If every aspect of that is considered then we would need to write a big fat book. We will look at the need and how and why these measurements are performed. Also it would be important to mention here that all the measurement types are independent of each other. À Inter-Frequency measurements are not a must for a mobile handset to . If and only if the UE is able to more than one frequency than this measurements will be used. Some of the reasons why we need these measurements are as follows: {c

{c

{c

There could be presence of Hotspots. Say there could be one cell in a large area. But that area has a race course. During the racing season it is full of people using their mobile phones. Thus this one cell might not be able to handle all these calls. For this particular race course, during the racing season there might be a small cell (technically known as micro cell while the cell that covers the big area is known as macro cell). The s would be handed over to these micro cells during the season so other ¶s calls won¶t be much affected. If a lot of people are camped on a same frequency and they move to the same area then the traffic on this particular frequency will increase. To evenly balance the traffic between different frequencies some of the s would be forced to do Inter-Frequency measurements and hence perform Inter-Frequency handover. The might move to an area where the current frequency coverage is about to end. At this particular point the network would ask the UE to perform the Inter-Frequency measurement and move to the new frequency as soon as possible to avoid the loss of call.

 À c cccccccccccccccccccccccccccccccccccccccccccc ccccccccccccccccccccccccccccccccccccccccc cccccccccccccccccccccccccccccccccccccccccccccccc ccccccccc c c

cccccccccccc ccccccc cccccccccccccccccccccccccccccccccccccccccccccccc cccccccccccccccccccccccccccccccccccccccccccccccc cccccccccccc c cccccccccccccccccc ccccccc cccccccccccccccccccccccccccccccccccccccccccccccc

c

The network decides that inter frequency measurements need to be performed and sends the MEASUREMENT CONTROL MESSAGE with Measurement type set to Inter-Frequency measurements. Generally it will set an Event as well along with the measurements. The following are list of Events that can trigger Measurement Report. {c {c

{c {c {c {c

x Change of Best Frequency x The estimated quality of the currently used frequency is below a certain threshold and the estimated quality of a non-used frequency is above a certain threshold x The estimated quality of a non-used frequency is above a certain threshold x The estimated quality of the currently used frequency is below a certain threshold x The estimated quality of a non-used frequency is below a certain threshold x The estimated quality of the currently used frequency is above a certain threshold

The most commonly used events from the above list are events 2b and 2d. In case when UE enters 'End of Coverage' area, network will send MCM with event Id set to event 2b and 2d. Event 2d performs the same function as event 2b for the current frequency but the threshold set in case of 2d is much lower. When event 2b is triggered a hand over to new frequency is performed without any problems. In case if event 2b is not triggered while event 2d is triggered that means that the other frequency is not strong enough but the current frequency has deteriorated very much and the only option is to handover to new frequency. In this case the results will not definitely be success.   No discussion about inter-frequency measurements would be complete without discussing HCS. In UMTS, Node B's will be capable of ing multiple frequencies, though this is not mandatory (and the cost of these Node B's would be more). Thus the cells with different frequencies would be arranged in a hierarchical structures as shown in the figures below.

c

Figure 1 shows a scenario when there are two identical layers of Macro cells. The network can decide depending on the load which frequency the UE should camp on. Figure 2 shows a Macro and Micro layer. The Micro cells would be available in hot spots where there is extremely high traffic compared to other areas. Figure 3 shows a combination of the first two cases. c c c c c c c c c c c c c c

c

A look at PDP Context in UM netorks Packet Data Protocol (PDP) A Packet Data Protocol (PDP) context offers a packet data connection over which the UE and the network can exchange IP packets. Usage of these packet data connections is restricted to specific services. These services can be accessed via so-called access points. Packet Data Protocol Context is one of the most important concepts for the UMTS Packet Data Architecture. The PDP Context has a record of parameters, which consists of all the required information for establishing an end-to-end connection: {c {c {c {c {c {c

PDPccc PDPcc cc * c c c * c c cccc * c c c * c c cc cc ? c c P?Pc c?Pcc DNc c D cDNc c cDNcc

The PDP Context is mainly designed for two purposes for the terminal. º c PDPc c c c c c c P c D c P c PDPc c c Pc cc cPc cc c cc c c c cc {c c c c c c c c c c c * c c c c c * c c c cc cc DPc c c cc cc

{c

Multiple PDP Context As mobile phones develop, there will be a need to serve parallel applications running on them with simultaneous PS calls. These PS calls can differ in their QoS (Quality of Service) parameters, and/or in the target network (PDN ± Packet Data Network) to which they provide connection. Multiple PDP Contexts means that one mobile terminal can have multiple PDP contexts. Each of the Multiple PDP Contexts can at the same time have different QoS profiles. The primary PDP Context is a normal PDP Context with default QoS profile attributes and it is always activated first. For the multiple primary PDP Contexts, each context has different PDP Address and different APN Multiple PDP contexts will have special significance when IMS is introduced and all the services will be PS (IP) based. In an IMS based network the MS can (and will) activate separate PDP contexts for SIP based signaling and for all the sessions of different, eventually parallel services (e.g. parallel VoIP call and PS data call, etc.). A different QoS ± which matches the application will be used for each connection. The data flow ( plane) of a particular PDP context can terminate either in the Mobile Terminal (MT) itself or in the connected Terminal Equipment (TE) as shown in Figure below. The application for which the connection is provided is running either on the MT or on the TE

c

respectively. An example for the first possibility is a video telephony client running on the mobile, for the second possibility a web browser running on the connected notebook.

c

In IMS based systems it is expected that several embedded applications will run on the MT, requiring multiple PDP contexts. For the TE (e.g. connected PC) one additional PDP context may be also active. Multiple PDP contexts have two sub-categories: c c DPc c c c c c DNcc ! c DPc c c c c c c DNc c c c* cc

Multiple Primar PDP Contexts Multiple primary PDP contexts are two or more PDP contexts independent from one another, each of them using one unique PDP address. They give the possibility to have simultaneous connections to different PDNs ± e.g. to the internet for one application, while to a private network for another one. Beside the unique PDP address, each PDP context has its own QoS and NSAPI (Network Layer Service Access Point Identifier, see later) assigned. Each PDP context has a separate RAB (Radio Access Bearer) and GTP tunnel to transfer plane data. The PDP contexts typically terminate in different access points on the network side (although it is allowed that they terminate in the same access point). The terminating access points can be located in the same or in different GGSNs. The example in Figure below shows the plane path for three primary PDP contexts providing connections to three different PDNs:

c

c

Primary PDP contexts can be activated or deactivated independently from one another. QoS of any of the active PDP contexts can be modified with the PDP context modification procedure initiated by the MS or by the network. (See Below for details) econdar PDP Contexts A secondary PDP context is always associated with a primary PDP context. PDP address (IP address) and access point (AP) is re-used from the primary context. Hence the primary and the associated secondary PDP context provide connection to the same PDN with different guaranteed QoS. One primary PDP context might have multiple secondary contexts assigned. Each PDP context (i.e. the primary and all secondary) has its own RAB and GTP tunnel to transfer plane data. Also, each context is identified by a unique NSAPI (Network Layer Service Access Point Identifier). The primary PDP context has to be active prior to activating an associated secondary PDP context. Any secondary PDP context can be deactivated while keeping the associated primary context (and eventual other secondary PDP contexts) active. If a primary PDP context is deactivated, this will also deactivate all the assigned secondary PDP contexts. QoS of any active primary or secondary PDP context can be modified with the PDP context modification procedure initiated by the MS or by the network. (See below for details) As the PDP address (IP address) is common for the primary and for (all) the associated secondary PDP contexts, the TFT (Traffic Flow Template) is introduced to route downlink plane data into the correct GTP tunnel and hence into the correct RAB for each context. The example in Figure below shows the plane for a primary and two associated secondary PDP contexts:

c

c

Combination of multiple primary PDP contexts and secondary PDP contexts is also possible. For example, two primaries with one secondary context for each will result in four active PDP contexts in total. The maximum number of ed PDP contexts is terminal dependent. raffic lo emplate () The Traffic Flow Template (TFT) is used by GGSN to discriminate between different payloads. The TFT incorporates from one to eight packet filters; a unique packet filter identifier identifies each filter. Filtering can be based on one or more of the following filter attributes: {c {c {c {c {c {c

cc c c cc Pc c cc D c ccc c ccc Pc cc Pcc c cc "c Pcc

The TFT is provided by the MS in the Activate Secondary PDP Context Request message, it is stored by the GGSN, and is examined when routing downlink plane data. The TFT can be modified or deleted with the MS initiated PDP context modification procedure. A TFT may be also assigned to a primary PDP context by means of the MS initiated PDP context modification procedure. A TFT is built up from Packet Filters (minimum 1, maximum 8 of them) to provide flexibility in filtering. The relationship between PDP contexts, TFTs and Packet Filters is illustrated in Figure below:

c

c PDP context procedures Primar PDP context activation This procedure is used to establish a logical connection with the Quality of Service (QoS) functionality through the network from the UE to the GGSN. PDP context activation is initiated by the UE and changes the session management state to active, creates the PDP context, receives the IP address and reserves radio resources. After a PDP context activation the UE is able to send IP packets over the air interface. The UE can have up to 11 PDP contexts active concurrently. econdar PDP context activation A secondary PDP context activation allows the subscriber to establish a second PDP context with the same IP address as the primary PDP context. The two contexts may have different QoS profiles, which makes the feature useful for applications that have different QoS requirements (e.g., IP multimedia). The access point name, though, will be the same for the primary and secondary PDP contexts. PDP context modification The UE, the SGSN or the GGSN initiate this procedure for updating the corresponding PDP context. Additionally, the radio access network is able to request a PDP context modification from the SGSN (e.g., when coverage to the UE has been lost). The procedures modify parameters that were negotiated during an activation procedure for one or several PDP contexts. PDP context deactivation

c

This procedure is used to delete a particular logical connection between the UE and the GGSN. The initiative to deactivate a PDP context can come from the UE, the SGSN, the Home Location (HLR) or the GGSN.

c Access points Access points can be understood as IP routers that provide the connection between the UE and the selected service. Examples of such services are: {c {c {c {c

ccc #cc èc? c è?P#cc c c#cc Pc c c cc

Depending on the operator of the network, more than one of these services might be provided by the same access point. The UE needs to be aware of an Access Point Name (APN) ± the address of a GGSN ± which gives access to the service-providing entity (e.g., an MMSC, the Internet or the P-CSCF). One GGSN may provide different services that can be accessed by different APNs. When establishing a primary PDP context with an APN the UE receives an IP address or ± in the case of IPv6 ± an IPv6 prefix that it has to use when communicating over that PDP context. This means that when a UE has established several connections to different APNs the UE will have different IP addresses for each of the provided services. c c

c c

Handover principle and concepts À By definition, handover means transfer of connection from one radio channel to other. This definition was formed before the advent of UMTS. When UMTS came this definition was no longer valid. In order not to confuse the jargon, the definition was kept as it is and new definitions were added. These new definitions called the soft and softer handover will be discussed later in this tutorial. As most of us would be aware, the main purpose of handover is to maintain an ongoing call. This is necessary as the might be moving (maybe with high speed) and it would be annoying if the call keeps dropping when the changes to another cell/area. Also it is possible that the number of s in an area changes while the call for a is ongoing and for the call to continue the network needs to change the frequency of an ongoing call. Finally the might enter an area where the UMTS network coverage ends and the might be handed over to a GSM/GPRS network. It is very difficult to explain everything about handover in a tutorial like this but we will try our best. Interested s can refer to the documents specified in the references section. Also one thing that should be noted is that all these procedures come into effect only when the call is ongoing (RRC Connection is established). SRNS Relocation, even though not strictly classified as handover will be explained in this tutorial.  Before we start discussing the handovers in detail we would like to list all of them for convenience of the reader 1.c 2.c 3.c 4.c 5.c 6.c 7.c

Softer Handover Soft Handover Intra-frequency hard handover Inter-frequency hard handover SRNS Relocation Combined Hard handover and SRNS Relocation Inter-RAT hard handover



c

Fig 1: Softer Handover Strictly speaking softer handover is not really a handover. In this case the UE combines more than one radio link to improve the reception quality. On the other hand the Node B combines the data from more than one cell to obtain good quality data from the UE. [1] Specifies the maximum number of Radio Links that a UE can simultaneously as 8. In practice this would be limited to 4 as it is very difficult to make the receiver with 8 fingers. Generally speaking when RRC connection is established, it would always be established on one cell. The network initiates Intra-Frequency measurements to check if there are any other cells the UE can connect simultaneously to improve the quality of the data being transferred between the RNC and the UE. If a suitable cell is found then Active Set Update procedure is initiated. Using this Active Set Update message, the network adds or deletes more than one radio link to the UE. The only requirement is that from the start till the end of this Active Set Update procedure, one Radio Link should remain common. 

Fig 2: Soft Handover

c

Soft Handover is the same as softer handover but in this case the cells belong to more than one node B. In this case the combining is done in the RNC. It is possible to simultaneously have soft and softer handovers.

Fig 3: Soft Handover with Iur connection A more complicated soft handover would include a cell that belongs to a Node B in different RNC. In this case an Iur connection is established with the drift RNC (RNC 2) and the data would be transferred to the Serving RNC (RNC 1) via Iur connection. In a typical UMTS system, the UE is in soft/softer handover around 50% of the time. One of the very important requirements for the soft/softer handover is that the frames from different cells should be within 50ms of each other or this would not work. The last thing one needs to is that the soft/softer handover is initiated from the RNC and the core network is not involved in this procedure.   Hard handover occurs when the radio links for UE change and there are no radio links that are common before the procedure is initiated and after the procedure is completed. There are two types of hard handover. First is Intra-frequency hard handover and the second is Inter-frequency hard handover. Intra-frequency hard handover will not occur for the FDD system. It would happen in TDD system. In this case the code spreading/scrambling code for UE will change but the frequency remains the same. Inter-frequency hard handover generally occurs when hierarchical cells are present. In this case

c

the frequency at which the UE is working changes. This happens when the current cell is congested, etc. Have a look at the Inter-Frequency Measurement primer for more information. Hard handover procedure can be initiated by the network or by the UE. Generally it would be initiated by the network using one of the Radio Bearer Control messages. In case of UE initiated, it would happen if the UE performs a Cell Update procedure and that Cell Update reaches the RNC on a different frequency. The Core Network is not involved in this procedure. ! SRNS Relocation procedure is not strictly speaking a handover procedure but it can be used in combination with the handover procedure. A simple SRNS Relocation can be explained with the help of figures present in [9].

Fig

4:

Data

flow

before

SRNS

Relocation

procedure

([9],

Fig

37)

Fig 5: Data flow after SRNS Relocation procedure ([9], Fig 38) The UE is active on a cell that belongs to a different RNC (than the one on which call was initiated) and a different MSC/SGSN. This arrangement causes unnecessary signaling between two RNC's. Hence the relocation procedure is initiated.

c

In this, the CN negotiated the relocation procedure between the two RNS's. Once the procedure is completed the connection towards the old domain is released as shown in Fig. 5. The relocation procedures will generally be used for UE in Packet Switched mode. This procedure is time consuming and is not really suitable for real time services. " 

!

Fig 6: Before Combined hard handover and SRNS Relocation Procedure([9], Fig. 40)

Fig 7: After Combined hard handover and SRNS Relocation Procedure([9], Fig. 41) The combined procedure is a combination of hard handover and SRNS Relocation. Fig. 6 and 7 explain the procedure. À #



When UE reaches end of coverage area for UMTS services, it can handover to a 2G service like GSM (if the UE s multiple RAT). Inter-RAT handover procedure can be initiated in variety of ways. RNS might send a  command explicitly telling the UE to move to a different RAT or the UE might select a cell that belongs to a different RAT or the Network may ask UE to perform . Inter-RAT hard handover using  command can be performed when there are no RAB's or when there is at least one CS domain RAB. The state of the UE is CELL_DCH.

c

Inter-RAT hard handover using can be performed when UE is either in CELL_DCH or CELL_FACH state. The only requirement is that there should be at least a PS signaling connection and no CS signaling connection.

utorial: Medium Access Control (MAC) in åUM Protocol tack À MAC is a Layer 2 protocol and it resides between Physical Layer (L1) and RLC. The internal configuration of MAC is done by the RRC layer (L3). The interface between PHY and MAC are the transport channels where as the interface between RLC and MAC are the logical channels. MAC provides services to both plane as well as Control plane. MAC takes care of circuit switched as well as packet switch traffic and signaling traffic as well.

Fig 1: Radio (Taken from 25.301, figure 2)

Interface

Protocol

Architecture

One important thing to is that the MAC is not symmetrical protocol. It is different in

c

UL and DL. # MAC sub layer provides following services to the upper layers: Data Transfer: This service provides unacknowledged transfer of MAC SDU's between peer MAC entities. {c Reallocation of radio resources and MAC parameters: On request by RRC, MAC can change the identity of the UE, change the transport format set, change the transport channel type, etc. {c Reporting of Measurements: Traffic volume measurements are performed in MAC and reported to RRC {c

# MAC Functions include: {c {c

{c

{c

{c

{c

{c

{c

{c

Mapping between logical channels and transport channels Selection of appropriate Transport Format for each Transport channel depending on instantaneous source rate. Given the Transport Format Combination Set assigned by RRC, MAC selects the appropriate transport format within an assigned transport format set for each active transport channel depending on source rate. The control of transport formats ensures efficient use of transport channels. Priority handling between data flows of one UE. When selecting between the Transport Format Combinations in the given Transport Format Combination Set, priorities of the data flows to be mapped onto the corresponding Transport Channels can be taken into . Priority handling between UEs by means of dynamic scheduling. In order to utilize the spectrum resources efficiently for burst transfer, a dynamic scheduling function may be applied. MAC realizes priority handling on common and shared transport channels. Identification of UEs on common transport channels. When a particular UE is addressed on a common downlink channel, or when a UE is using the RACH, there is a need for inband identification of the UE. Since the MAC layer handles the access to, and multiplexing onto, the transport channels, the identification functionality is naturally also placed in MAC. Multiplexing/demultiplexing of upper layer PDUs into/from transport blocks delivered to/from the physical layer on common transport channels. MAC should service multiplexing for common transport channels, since the physical layer does not multiplexing of these channels. Multiplexing/demultiplexing of upper layer PDUs into/from transport block sets delivered to/from the physical layer on dedicated transport channels. The MAC allows service multiplexing for dedicated transport channels. This function can be utilized when several upper layer services (e.g. RLC instances) can be mapped efficiently on the same transport channel. In this case the identification of multiplexing is contained in the MAC protocol control information. Traffic volume measurement. Measurement of traffic volume on logical channels and reporting to RRC. Based on the reported traffic volume information, RRC performs transport channel switching decisions. Transport Channel type switching. Execution of the switching between common and dedicated transport channels based on a switching decision derived by RRC.

c

Ciphering. This function prevents unauthorized acquisition of data. Ciphering is performed in the MAC layer for transparent RLC mode. {c Access Service Class selection for RACH and CH transmission. The RACH resources (i.e. access slots and preamble signatures for FDD, timeslot and channelization code for TDD) and CH resources (i.e. access slots and preamble signatures for FDD only) may be divided between different Access Service Classes in order to provide different priorities of RACH and CH usage. In addition it is possible for more than one ASC or for all ASCs to be assigned to the same access slot/signature space. Each access service class will also have a set of back-off parameters associated with it, some or all of which may be broadcast by the network. The MAC function applies the appropriate back-off and indicates to the PHY layer the RACH and CH partition associated to a given MAC PDU transfer. {c





Before discussing anything further, we should look at the channel structures for Layer 1, MAC and RLC. The Transport Channels are interface between MAC and Layer 1, while Logical Channels are interface between MAC and RLC. Transport channels can be further subdivided into Common Transport Channels (where there is need for inband identification of the UEs when particular UEs are addressed); and dedicated transport channels (where the UEs are identified by the physical channel, i.e. code and frequency for FDD and code, time slot and frequency for TDD). Common transport channel types are: {c

{c

{c {c {c {c {c

{c

Random Access Channel (RACH): A contention based uplink channel used for transmission of relatively small amounts of data, e.g. for initial access or non-real-time dedicated control or traffic data. Common Packet Channel (CH): A contention based channel used for transmission of burst data traffic. This channel only exists in FDD mode and only in the uplink direction. The common packet channel is shared by the UEs in a cell and therefore, it is a common resource. The CH is fast power controlled. Forward Access Channel (FACH): Common downlink channel without closed-loop power control used for transmission of relatively small amount of data. Downlink Shared Channel (DSCH): A downlink channel shared by several UEs carrying dedicated control or traffic data. Uplink Shared Channel (USCH): An uplink channel shared by several UEs carrying dedicated control or traffic data, used in TDD mode only. Broadcast Channel (BCH): A downlink channel used for broadcast of system information into an entire cell. Paging Channel (PCH): A downlink channel used for broadcast of control information into an entire cell allowing efficient UE sleep mode procedures. Currently identified information types are paging and notification. Another use could be UTRAN notification of change of BCCH information. High Speed Downlink Shared Channel (HS-DSCH): A downlink channel shared between UEs by allocation of individual codes, from a common pool of codes assigned for the channel.

Dedicated transport channel types are:

c {c

Dedicated Channel (DCH): A channel dedicated to one UE used in uplink or downlink.

A general classification of logical channels is into two groups; Control Channels (for the transfer of control plane information) and Traffic Channels (for the transfer of plane information). Control Channels: {c {c

{c

{c

{c

Broadcast Control Channel (BCCH): A downlink channel for broadcasting system control information. Paging Control Channel (PCCH): A downlink channel that transfers paging information. This channel is used when the network does not know the location cell of the UE, or, the UE is in the cell connected state (utilizing UE sleep mode procedures). Common Control Channel (CCCH): Bi-directional channel for transmitting control information between network and UEs. This channel is commonly used by the UEs having no RRC connection with the network and by the UEs using common transport channels when accessing a new cell after cell reselection. Dedicated Control Channel (DCCH): A point-to-point bi-directional channel that transmits dedicated control information between a UE and the network. This channel is established through RRC connection setup procedure. Shared Channel Control Channel (SHCCH): Bi-directional channel that transmits control information for uplink and downlink shared channels between network and UEs. This channel is for TDD only.

Traffic Channels: Dedicated Traffic Channel (DTCH): A Dedicated Traffic Channel (DTCH) is a point-topoint channel, dedicated to one UE, for the transfer of information. A DTCH can exist in both uplink and downlink. {c Common Traffic Channel (CTCH): A point-to-multipoint unidirectional channel for transfer of dedicated information for all or a group of specified UEs. {c

The mapping of Logical channels to transport channels is shown in the diagram below.

Fig. 2: Logical channels mapped onto transport channels, seen from the UE side (Taken from 25.301, figure 4)

c

Fig. 3: Logical channels mapped onto transport channels, seen from the UTRAN side (Taken from 25.301, figure 5)

# $ As mentioned earlier, the MAC protocol is not symmetrical in UL and DL. The MAC entities might be present in the UL and/or DL. The functional entities are as follows: MAC-b: Mac-b represents the control entity for the broadcast channel (BCH). There is one (current cell) or multiple (current cell plus neighboring cells) MAC-b entities in each UE and one MAC-b in the UTRAN for each cell. The MAC Control SAP is used to transfer Control information to MAC-b. {c MAC-c/sh: MAC-c/sh handles the paging channel (PCH), the forward access channel (FACH), the random access channel (RACH), common packet channel (UL CH) that exists in FDD mode, the downlink shared channel (DSCH) and the uplink shared channel that exists in TDD mode. There is one MAC-c/sh entity in each UE and one in UTRAN for each cell. {c MAC-d: MAC-d handles the dedicated transport channel (DCH). There is one MAC-d entity in the UE and one MAC-d entity in the UTRAN for each UE that has one or more dedicated logical channels to or from the UTRAN. {c MAC-hs: MAC-hs handles the high speed downlink shared channel (HS-DSCH). There is one MAC-hs entity in the UTRAN for each cell that s HS-DSCH transmission. {c

Ñ # £ In case of TM RBs, RLC acts like a pipe that transfers the data to the MAC layer without adding any headers. Thus in this case Ciphering has to be performed in the MAC layer. In all other cases (AM and UM RBs), Ciphering is performed in the RLC layer. The part of MAC PDU that is ciphered is the MAC SDU as shown in the fig below.

c

Fig. 4: Ciphered (Taken from 25.321, figure 11.5.1)

part

of

MAC

PDU

!" Dynamic radio bearer control is performed by RRC, based on the traffic volume measurements reported by MAC. Traffic volume information is measured in MAC layer and the results are reported from MAC layer to RRC layer. This concept can be explained with the help of the diagram below. c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c ccccccccccccccccccccccccccccccccccccccccccccccccccc c cccc c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c ccccccccccccccccccccccc c c

c c c c c ccc c cccc c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c cccc c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c cccccccccccccccccccccccccc c cccc c c c c c c c c c c c c c c c c c c c c c c c c ! c c c c c c c c c c c c c c cccc c c c c c c c c c c c c c c c c c c c c c c c cccc cccc c c c c c c c c c c c c c c c c c c c c c c c c ! c c c c c c c c c c c c c c cccc c c c c c c c c c c c c c c c c c c c c c c c c cccc c c c c c c c c c c c "!c c c c c c c c c c c c c c c c c c c c c c c c cccccccccccccccccccccccccc c cccc c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c cccc c c c c c c c c c c c c c c c ccc c cccc c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c cccc c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c c cccc

At least every TTI, the MAC layer shall receive from each RLC entity the value of its Buffer Occupancy (BO), expressed in bytes. RRC can configure MAC to keep track of statistics (i.e.

c

raw BO, average of BO and variance of BO) on the BO values of all Radio Bearers mapped onto a given transport channel. When the average or variance is requested, an averaging interval duration will also be provided. Every time the BO values are reported to MAC, the UE shall whether an event was triggered or if a periodic report is required. If reporting is required (multiple reports may be triggered in a single TTI), the MAC shall deliver to RRC the reporting quantities required for the corresponding RBs. In the case of average and variance of BO, the averaging should be performed for the interval with the configured duration ending at the time when the event was triggered. å # #  The physical RACH resources (i.e. access slots and preamble signatures for FDD) may be divided between different Access Service Classes in order to provide different priorities of RACH usage. It is possible for more than one ASC or for all ASCs to be assigned to the same access slot/signature space. Access Service Classes are numbered in the range 0 £ 7 £ NumASC £ 7 (i.e. the maximum number of ASCs is 8). An ASC is defined by an identifier that defines a certain partition of the PRACH resources and an associated persistence value Pi. A set of ASC parameters consists of NumASC+1 such parameters (i, Pi), i = 0« NumASC. The PRACH partitions and the persistence values Pi are derived by the RRC protocol from system information. The set of ASC parameters is provided to MAC with the CMAC-Config-REQ primitive. The ASC enumeration is such that it corresponds to the order of priority (ASC 0 = highest priority, ASC 7 = lowest priority). ASC 0 shall be used in case of Emergency Call or for reasons with equivalent priority. At radio bearer setup/reconfiguration each involved logical channel is assigned a MAC Logical channel Priority (MLP) in the range 1« 8. When the MAC sub layer is configured for RACH transmission in the UE, these MLP levels shall be employed for ASC selection on MAC. The following ASC selection scheme shall be applied, where NumASC is the highest available ASC number and Min MLP the highest logical channel priority assigned to one logical channel: {c {c

in case all TBs in the TB set have the same MLP, select ASC = min(NumASC, MLP); in case TBs in a TB set have different priority, determine the highest priority level MinMLP and select ASC = min(NumASC, MinMLP).

When an RRC CONNECTION REQUEST message is sent RRC determines ASC by means of the access class. The ASC to be used in these circumstances is signaled to MAC by means of the CMAC-CONFIG-REQ message. If MAC has knowledge of a U-RNTI then the ASC is determined in the MAC entity. If no URNTI has been indicated to MAC then MAC will use the ASC indicated in the CMACCONFIG-REQ primitive. [ x RRC can control the scheduling of uplink data by giving each logical channel a priority between 1 and 8, where 1 is the highest priority and 8 the lowest. TFC selection in the UE shall be done in accordance with the priorities indicated by RRC. Logical channels have absolute priority, i.e.

c

the UE shall maximize the transmission of higher priority data. Hence higher priority data flows will be given higher bit rate combinations while lower priority data flows will have to use low bit rate combinations. Note that zero bit rate is a special case of low bit rate combination. MAC has to derive the priority parameters from two sources: {c {c

The buffer occupancy parameter received from RLC MAC logical channel priority received from RRC

A given TFC can be in any of the following states: {c {c {c

ed state; Excess-power state; Blocked state.

Fig. 5. State transitions (Taken from [1], fig. 11.4.1)

for

the

state

of

a

given

TFC

UEs in CELL_FACH state may estimate the channel path loss and set to excess power state all the TFCs requiring more power than the Maximum UE transmitter power. All other TFCs shall be set to ed state. Every time the set of ed TFCs changes, the available bitrates shall be indicated to upper layers for each logical channel in order to facilitate the adaptation of codec data rates when codec¶s ing variable-rate operation are used. The details of the computation of the available bitrates and the interaction with the application layer are not further specified. At Radio Bearer Setup (or Reconfiguration), each logical channel is assigned MAC logical channel priority (MLP) in rage 1-8 by RRC. MAC has to then select a TFC that can transmit as much as and as high priority data as possible. In a noisy cell, a high priority TFC can be blocked if its use would cause the UE to transmit more power than the UEs current maximum transmitter power. c c c

c

Àntroduction to åUM MAC UMAC Basics Functional Overview The functions of MAC can be summarized as follows: {c {c {c {c {c

{c {c {c

{c {c

{c {c {c

c c ccc c#cc c c c c º c c c c c c c c c #cc cc c c c c c$#cc cc c$cc c c c#cc c c $c c

c c #cc %?c c c $c c c c c c c c c c c c c c

c c ccc c c c cc cc c c

c cc c c c c c c$c cc c c c c

c c c c c c c c c $c cc c cc c c ccc

c cc$c c c $c ccc cccc ccc c cc

& c c c Dc & c c c c & c ccc c

c c#cc

& c c c c PDc & c c c c c & c ccc c c c#cc c c

#cc $c cc c?c c'(c c c c c cc c?c c c c c''c c c c c c cc c c c c c c)c c c''c c?c c c c c c c ccc c c c c c cP* cc c c c cc c?cccc c ccc c c%?cc+ c cc c cc ccc c cc c c c c c cc c%?c c%''c %''c c%?c c c c c c c c c c c c %'(c c c c c c c c c c c c%''cc c c c cc c c cc cccc c cc c c%''cc c c c c c c c c cc cc c c c c c c c c c c %?c c c c c c c c c c c c c %''c c c c c c c c c c cc cc c #cc c c c

c '(#cc ?c'(c , cccc c c ccc c ccc cc? cº cc c?c ccc cc'( cc ?ccc c c'?ccPc #cc c c%Dc cc cc c c?'*#cc %D c) c' c cc

If one has to look at the UMAC in of design perspective it will look as follows

c

c

Thus according to the above figure there are three interfaces/SAP to U-MAC. They are: a c c c c c c c ''c c ? c c cc c cc c c%''ccc c c%?cc c c cccc c c c cc {c a c c c c c c c c c c c c -c c c c c c c c c %P*c c % ?c cc {c a c c c c '(c c ?c c c c c c cc c ccc c c%?cc%'(c cc

{c

Channel structure The MAC operates on the channels defined below; the transport channels are described between MAC and Layer 1, the logical channels are described between MAC and RLC. ransport channels Common transport channel types are: {c {c {c {c {c {c {c {c

' c?c c '?#cc º c?c c º?#cc D cc c D#cc ccD cc c %D#cc

c c Pc c(cºDDc c #cc cc c c cDDc c #cc ) cc )#cc Pcc P cc

Dedicated transport channel types are: {c

D cc D cc

Logical Channels The MAC layer provides data transfer services on logical channels. A set of logical channel types is defined for different kinds of data transfer services as offered by MAC.

c

Each logical channel type is defined by what type of information is transferred. 0%



The configuration of logical channel types is depicted in figure below.

Data Processing in UL and DL U-MAC is part of the U-Plane of the UMTS protocol stack and so its performance influences the overall system performance. Processing of data, in particular in the UL, is time critical in that completion of the processing of UL data must be within a finite time and leave enough time for U-PHY to carry out its processing before transmitting the data over the air interface. Processing of data in the DL is less time critical and can be done on an 'as soon as possible' basis To process the data in UL which is very time critical there is always some background processing in UMAC while it is preparing to send the data in UL. The background tasks and UL processing are initiated by a trigger called TTI. It's an event timer set to trigger U-MAC at each frame boundary (i.e. at 10ms intervals) so that there is 10ms left before data transmission on the air interface is to take place. UL data transfer is then initiated (i.e. TF and TFC selection) which results in UMAC_Status_IND primitive being sent to U-RLC. Finally, traffic volume measurement takes place (therefore taking in to the latest buffer occupancies in U-RLC). When the required data is received back from U-RLC it is processed and ed to U-PHY. In the DL Data is received from U-PHY asynchronously with the data grouped by its TTI, i.e. each primitive contains data for a single TTI. UMAC after identifying that the data is meant for this UE, will transfer the PDUs to URLC. U-MAC's primary task is to carry data between U-PHY and U-RLC in both the UL and the DL. This task is of the highest priority. In the background, two other sets of tasks are also happening. Firstly, configuration primitives received from U-RRC are received asynchronously. Secondly, every frame (10ms), other tasks are initiated that need attention, i.e. traffic volume measurement, RACH access, activation of delayed configurations etc.

c

MAC Overview The basic UMAC architecture of UMAC is shown blow

c

As shown in the above figure UMAC consist of three different UMV entities which can be considered as different modules when implementing UMAC for UE. In of design perspective the following section gives and idea what are the modules UMAC can have while implementing. Please note that this is just an idea of having certain modules in UMAC. Engineers can design and can implement modules different to what explained below.

URRC SAP This sub-component or module is responsible for handling all primitives received from, and sent to, U-RRC. So basically this can be implemented as file which will contain definition for all the data structures related to the primitives received from URRC. URRC SAP's header file contains the 'C' structures, that represent the configuration primitives, and is shared with U-RRC. The of the structure will be the parameters of the primitives. The file will also contain the function definition and prototype for handling message to and from URRC. All the primitives received through URRC SAP should contain primitive identifier. This will enable the developer to call the corresponding function to take the actions based on the received primitive. On the transmitting side, the URRC SAP creates the final primitive and adds the primitive header before sending it to U-RRC.

U-PHY SAP This sub-component or module is responsible for handling all primitives received from, and sent to, U-PHY. Primitives are received encapsulated by a primitive header within which is an identifier of the

c

primitive On the transmitting side, the U-PHY SAP creates the final primitive and adds the primitive header before sending the primitive to U-PHY. U-PHY SAP's header file contains the 'C' structures, that represent the primitives and is shared with U-PHY.

U-RLC SAP The 'U-RLC SAP' sub-component is responsible for handling all primitives received from, and sent to, U-RLC. If we consider a better design then I would recommend that this SAP should be only used in the DL. In DL the primitives are received with primitive identifier embedded into it. The correct function in the correct U-MAC sub-component (MAC-c/sh, MAC-d, MAC-b) is called ing the primitive itself. For data transmission primitives this needs the Radio Bearer number to be acquired from within the primitive to enable the appropriate mapping for the Radio Bearer to be identified from the configuration provided by the 'Database'. The primitive may then contain several instances, for example the data for several Radio Bearers. In this case the sub-component splits the primitive intelligently to handle the ing of the data to different sub-components (if required). On the transmitting side, the U-RLC SAP creates the final primitive and adds the primitive header before sending the primitive to U-RLC. U-RLC SAP's header file contains the 'C' structures, that represent the primitives, and is shared with U-RLC. In case of UL I will recommend that instead of ing the primitives in each TTI it's better to have the function calls. This is because it is felt that the performance of the protocol stack can be significantly improved by violating the principle of everything being handled by the U-RLC SAP. When U-MAC needs to get the data or PDUs from URLC in each TTI or if it needs to know the buffer occupancies in U-RLC, direct function calls are made so that the latest values are obtained. By using function calls, the other possible solution of extra primitives ing between the layers, and the extra delays that incurs at a critical time due to the overhead of the Protocol Stack Framework, is avoided. In a similar way, in the case of U-RLC TM Radio Bearers, U-MAC uses a function call to request the more detailed (than the pure buffer occupancies) information required about what is waiting in the U-RLC buffer.

Create UMAC This sub-component (can be given any other name) is responsible for initializing the U-MAC software ready for use by calling the initialization procedures within each of the other subcomponents. In other way this is the initialization of the UMAC task. Please note that this is just the initialization of the UMAC data structure or it's just a software initialization. Following this U-MAC still needs to be configured by U-RRC, via the URRC SAP, before any data transfer can occur. This initialization should occur when power is first applied to the processor or when the CUMAC_Initialization_REQ primitive is received. The initialization process can be viewed as initializing the data structure, allocating the necessary memory for the static buffers or primitives and so on. In this process most of the variables used in UMAC are initialized to their default values as suggested in the 3GPP specs.

c

Vill UMAC This sub-component is responsible for halting the U-MAC software so that it uses the minimum of system resources.

MAC-b (mac_b) The 'MAC-b' sub-component is responsible for handling of the broadcast information received in the DL on the BCH transport channel. It is initiated by the receipt of the UPHY_Data_IND primitive that has a data indication, within the primitive, with the Transport Channel Type set to BCH. There can be several instances of MAC-b (due to the possibility of there being several broadcast channels being monitored at one time). Due to the simplicity of the 'MAC-b' subcomponent there is no requirement for instance context data. The 'Database' provides the configuration information to map the data to the correct BCCH so that the data can be ed to U-RLC with the UMAC_Data_IND primitive.

MAC-c/sh (mac_csh) The 'MAC-c/sh' sub-component is responsible for processing of information on the common and shared transport channels in both the UL and the DL. In of implementation and design it is initiated by one of two events. c c (c

&c c c c c c c %?c c %'(c c c ?.D .'$*c c ccc c c c c c c c' c)c Dc c ccc c cc c c cc

&c c cc ! c c D(c

&c c c c c c c %?c c %P*c c c P*.D .NDc c c c c c c c c c c c c cc c cDc cº? cD c ccc'cc cc

NOTE: The RLC provides RLC-PDUs to the MAC, which fit into the available transport blocks on the transport channels. When data is received from U-RLC in the UL, via the UMAC_Data_REQ primitive, the TCTF and UE ID (CRNTI is always added in UL but only for dedicated logical channel data) header fields are added and then the data is ed to the 'U-PHY SAP' sub-component for transmission to U-PHY. In the DL (if multiple transport channels are received then this procedure is carried out for each transport channel), the TCTF field is stripped off the data. If the logical channel indicated by the TCTF field is for a common/shared logical channel then the data is ed up to U-RLC with the UMAC_Data_IND primitive. If the logical channel indicated by the TCTF field is for a dedicated logical channel then the UE ID field is stripped off the data. The UE ID is compared against the UE ID provided by the 'Database'. This can either be a U-RNTI, a C-RNTI or a DSCH-RNTI, the UE ID Type field gives the type (U-MAC has all three values, if available at the UE, configured in the 'Database'). If the two UE IDs do not match then the data is discarded. If the two UE IDs match then the data is de-multiplexed, if necessary, and then ed up to URLC, also with the UMAC_Data_IND primitive. Thus the following functionality is covered by UMAC -c/sh:

c {c

{c

{c

{c

{c

{c

ºc/ cc c c c c c c c c c c c c c c c cc c cºccc c?ccc c c

c c c c c cc c ºc c c c

c c c c c c c c c cc#cc &c$c cc c c$cccc cPcc'"Nc '$*$c c ''c c c c ?#c c c c c ?c c c?#cc c& ccc c c ccc c c c cc c?%c c'?cc Pcc c cc cc cc c cºc cc ºc cc c c cc c c c c c c c c c c c c c c c c cc''cc cc

There is one MAC-c/sh entity in each UE.

MAC-d (mac_d) The 'MAC-d' sub-component is responsible for processing of information on dedicated transport channels in both the UL and the DL. The following functionality is covered by MAC-d: cc c cc c c c c c c c c c c c c c c c '' c c c c c c c c c c c c c ''c ?c c c c c c c c cc c

cc c c cc {c &c/ cc c c&c/cccc c cc c cc c c c c c c %Dc c c ?%c c %Dc c c ?c c c c c ccc cc {c cc c c c c c c c c c c c c ?% c D c cccc cc012 cc {c D cc c Dc cc c c cc cc?% cD c c ccc cc012 cc {c

c {c

(cºc cc c c cc c c c c c c c c c c c c c c c c cc''cc cc

The MAC-d entity is responsible for mapping dedicated logical channels for the uplink either onto dedicated transport channels or to transfer data to MAC-c/sh to be transmitted via common channels. One dedicated logical channel can be mapped simultaneously onto DCH and DSCH. One dedicated logical channel can be simultaneously mapped onto DCH and HS-DSCH. The MAC-d entity has a connection to the MAC-c/sh entity. This connection is used to transfer data to the MAC-c/sh to transmit data on transport channels that are handled by MAC-c/sh (uplink) or to receive data from transport channels that are handled by MAC-c/sh (downlink). The MAC-d entity has a connection to the MAC-hs entity. This connection is used to receive data from the HS-DSCH transport channel which is handled by MAC-hs (downlink). There is one MAC-d entity in the UE. In of implementation and design perspective it is initiated by one of two events... c D c cc c c c c%?c c %'(c c c?.D .'$*c c c c c c c c c c c c ' c)c Dc c c c c c cc c c cc c c cc ! c D c c c c c c c %?c c %P*c c c P*.D .NDc c ccc c c c c c c c ccc c c D cD c ccc'cc cc

When data is received from U-RLC in the UL, via the UMAC_Data_REQ primitive, the mapping information is acquired from the 'Database'. The data is multiplexed with other logical channels on a block by block basis (with the C/T field added). The data is ciphered if required (again the 'Database' is queried to see if ciphering is configured for this particular Radio Bearer) and then the data is ed to U-PHY with the UPHY_DCH_Data_REQ primitive. Note that the UMAC_Data_REQ primitive received from U-RLC will have contained all of the dedicated logical channel data, therefore this procedure will be executed for each logical channel and the UPHY_DCH_Data_REQ primitive will include all the data to be sent on the single CCTrCh. In the DL, for data received directly from U-PHY with the UPHY_Data_IND primitive the mapping and configuration is queried from the 'Database' for the transport channel the data is received on (if multiple transport channels are received in the UPHY_Data_IND primitive then this procedure is carried out for each transport channel). The data is de-multiplexed on a block by block basis (by stripping off and using the C/T field), deciphered if required before being ed to U-RLC with the UMAC_Data_IND primitive (with the correct Radio Bearer set within the primitive). MAC-d has another final task, which is to handle loopback testing. When this mode is in operation U-MAC will echo the TBs received back to U-PHY with the addition of the CRC information of the received blocks appended. U-RRC should have provided the appropriate TFs to allow this to happen.

Database

c

This module can be considered as a heart of the UMAC layer. The best way to implement this is to define a structure whose are equivalent to the configuration parameters given my URRC once the UMAC task is initialised. The 'Database' sub-component processes and holds the information provided by U-RRC through the URRC SAP plus other information regarding the status of the U-MAC layer at a particular point in time (previous successful transmission of data on a logical channel etc.). It provides an intelligent interface to access information, for example to provide the TTI for each UL transport channel as well as straightforward access to the configuration information. It also provides the ability to handle configuration information that is not to be used until a specified time in the future and handle the switching of information (plus, for the special case of a TFCSS configuration, reverting back to the unmodified TFCS after the configured time). The following information is contained within the database: {c {c {c {c {c {c {c {c {c {c {c

' c)c cc cº c cc cº c c cc cº c c cc c3 c c cc ' c"D$c cc c c cc c c c c cc cc c c c c cc

When configurations are received by U-MAC from U-RRC they are not handled immediately but stored in a queue until immediately after the event timer trigger is received (via the 'Data Handler'). At the same time configurations that have been delayed further, due to possessing an activation time, are activated if the correct CFN has now arrived . The UMAC design should ensure that configurations do not change during processing of data (e.g. between the request of data from U-RLC with UMAC_Status_IND and the receipt of data with UMAC_Data_REQ). As a good design please try to develop the habit that as much as possible of the configuration information stored by the 'Database' is stored as pointers to the primitive structures that have been received from U-RRC. The memory of the primitive structure is released when the configuration is no longer required. The pointers should be stored in static variables. When other sub-components request some information from the 'Database' then they receive the pointer to the primitive structure. This means that the sub-components of U-MAC also need to be able to share the CUMAC SAP's header file. However there are a couple of special exceptions that can be considered. Firstly, TFCS configurations and TFCSS configurations are handled by using the information provided to modify the already stored TFCS configuration primitive. Secondly, again with TFCS and TFCSS configurations, the information provided is decoded from the CTFC to the TFIs and stored like this therefore avoiding the need to decode the CTFCs every time Transport Format Combination Selection takes place. Finally, the Database module should be intelligent enough to handle the arrival of different primitives at the same time.

Data Handler This sub-component receives a frame tick via an event timer trigger configured to initiate UMAC once every frame at the frame boundary. From this it informs other sub-components that need to be actioned to do something at this time. These are:

{c {c

{c

{c

c c ,D ,c % c Nc c c c c c c c ºNc c c c c cc cc c, c c'?c ,c% c'?cc c ccc c c % c c c '?c c c c c c c c c c c c cº c c cccc c c c c c%'(c c c ?. .NDc cc c , cº c c ,c % c cº c c c c c c c c c c c c %'(c c c ?. .NDc cc c ,c 3 c ,c % c c c c c c (c c cc cccc cc c c c%''cc cc

Transport Format Combination Selection The 'Transport Format Combination Selection' module provides a Transport Format Combination Selection service for DCH transport channels to be mapped to a single CCTrCh. Some preparation of data for the Transport Format Combination Selection routine, which does not depend on information that changes every frame, is done as soon as configuration primitives are handled after receipt from U-RRC. TFC selection is processor intensive, therefore limiting the amount of work done when we want to move data through the stack is desirable. Firstly, TFC selection is done on the transport channels whereas U-RRC configures U-MAC with Radio Bearers (which map one to one on to logical channels). The transport channel information (which logical channels are mapped to each transport channel) is therefore prepared at configuration time. Secondly, an array of TF information is prepared at configuration time to save the TFC selection from searching through each transport channel's TFS. Transport Format Combination Selection needs to acquire the logical channel to transport channel mappings from the 'Database' sub-component, the TTIs of the transport channels and the buffer occupancies of the logical channels from U-RLC (via direct function calls) to make the selection. The logical channel priorities stored by the 'Database' in the Radio Bearer configurations are also taken in to . There is also the facility for TFCs in the TFCS to be flagged as not being available if the estimated U-PHY power usage of a TFC is greater than the maximum UE transmit power. This is handled internally within the 'Database' so should not be visible to 'Transport Format Combination Selection'. When the event timer trigger is received (via the 'Data Handler') then logical channel to DCH transport channel mappings are read from the 'Database', Transport Format Combination Selection is done and the required data is requested from U-RLC via the UMAC_Status_IND primitive or a function call. Note that in both cases, U-MAC calculates how much header information will be need to be added to the U-RLC data, during transmission, and subtracts this value from the TB sizes in the selected TFs. This new value is the one used in the UMAC_Status_IND primitives sent to U-RLC. In the case of two or more DCH transport channels, with different TTIs, being multiplexed to a single CCTrCh (for example, if we have two DCH transport channels, one with a TTI of 10ms and another with a TTI of 20ms) every 20ms data for both transport channels will be transferred to U-PHY. However in the 'in-between frame', i.e. every other 10ms, data for only the transport channel with the TTI of 10ms will be transferred to U-PHY. This raise the big question which is what happens in the TFC selection when data is being transferred for only one of the two transport channels? The solution for this is to the TF selected (as part of the TFC) for

c

the 20ms TTI transport channel in the last frame and ensure the use of the same TF in this frame. The other option from U-MAC's point of view would be to select a zero TF, i.e. one that does not contain any data format (zero size, no coding). The theory is that U-PHY will still need the 20ms TTI transport channel properly identified in the TFCI for encoding purposes (as the 20ms TTI transport channel data is physically transmitted over 20ms). Ditto for decoding purposes in the UTRAN's U-PHY. If, in another case, no transport channels' TTI coincides with the current frame then the Transport Format Combination selected for the last frame where there was data to send is to be used by U-PHY, however U-MAC will not bother informing U-PHY of this as it can be assumed. No data needs to be requested from U-RLC (although the UMAC_Status_IND primitive is still sent to U-RLC so that it knows the success or not of the last transmission on each RB).

Control of RACH transmissions The 'Control of RACH transmissions' sub-component controls the timing of sending data to UPHY plus selection of the Access Service Class of RACH transport channel information being ed to U-PHY. When the event timer trigger (via the 'Scheduler') is received the sub-component determines whether there is old data waiting to be re-sent or new data is required. If new data is required then logical channel to RACH transport channel mappings are read from the 'Database' and Transport Format Selection is done. The required data is then requested from U-RLC via the UMAC_Status_IND primitive. Note that, like the 'Transport Format Combination Selection' subcomponent, U-MAC calculates how much header information will be need to be added to the URLC data, during transmission, and takes this in to in the UMAC_Status_IND primitive sent to U-RLC. If old data is to be re-sent then the 'Control of RACH transmissions' procedure is executed to determine whether it should send the data to U-PHY immediately or wait longer. When U-MAC wants to transmit data on the RACH transport channel it needs to request access by sending the UPHY_RACH_Data_REQ primitive to U-PHY containing the data. If U-PHY receives a positive AICH signal then it transmits the RACH data to the UTRAN. U-PHY will then confirm whether the data was sent or, if not, the reason why not with the UPHY_RACH_Access_CNF primitive. This keeps the functionality of U-MAC working to a minimum granularity of a frame. In the case of an unsuccessful RACH transmission then a retry may occur in the next frame (initiated by the 'Scheduler' sub-component), dependant on the Control of RACH transmissions procedure. An identifier is attached to the UPHY_RACH_Data_REQ primitive so that U-PHY is aware that the data is being retried so that it may increase the preamble power.

Traffic Volume Measurements The 'Traffic Volume Measurement' sub-component monitors the amount of information queued to be transmitted by U-MAC in the UL, providing reports to U-RRC as requested in the configuration of U-MAC by U-RRC. It is initiated by the 'Scheduler' sub-component every 10ms at which time the 'Traffic Volume Measurement' sub-component, from the configuration held by the 'Database', finds out the buffer occupancies of all logical channels, mapped to the required transport channels to be monitored, via direct function calls to U-RLC. It then does the appropriate calculations and reports, if necessary, the traffic volume on all Radio Bearers to U-RRC with the CUMAC_Measurement_IND primitive (either the straightforward buffer occupancy, the buffer

c

occupancy average over time or the buffer occupancy variance over time). The calculations also involve keeping track of the running averages and variances for each logical channel. The two triggers that initiate U-MAC to send a measurement report to U-RRC are measurements that occur at a defined period and / or measurements that go above or below specified configured values. When new measurements are configured then functions in the 'Traffic Volume Measurements' sub-component are called to initialize local variables and also to determine logical channel to transport channel mappings so that they do not have to be worked out when the measurements are to be calculated.

Data Flow through UMAC The figure below shows the mapping of logical channels to transport channels.

c

In the case of dedicated channels (DCH, DTCH and DCCH) and FACH there can be multiple instances of each. It is also important to note that U-MAC does not distinguish between DTCH and DCCH - as far as U-MAC is concerned they are processed in the same manner. When data enters U-MAC, either at the U-PHY SAP or the U-RLC SAP the SAP sub-component looks up routing information, in the Database, to decide which internal U-MAC sub-component needs to process the data.

Uplink Data Flow through UMAC Uplink Initiation As soon as UMAC receives the trigger via the 'Data Handler' it triggers procedures in both the 'Control of RACH transmissions' and 'Transport Format Combination Selection' subcomponents. These results in a single UMAC_Status_IND primitive being sent to U-RLC. The request can include information about multiple logical channels. The 'Control of RACH transmissions' sub-component determines which logical channels are mapped to the RACH transport channel. If any logical channels are mapped it then acquires the buffer occupancy for each of those logical channels from U-RLC (via direct function calls) and

c

does a Transport Format selection from the configured RACH TFS. Both CCCH and DTCH/DCCH may be mapped to RACH, so the UMAC_Status_IND primitive is sent to U-RLC (via U-RLC SAP) requesting the appropriate amount of data for both. The 'MAC-d' sub-component determines which logical channels are mapped to the DCHs, acquires the buffer occupancy for each of those logical channels from U-RLC (again via direct function calls to U-RLC) and does a Transport Format Combination selection from the configured DCH TFCS. The UMAC_Status_IND primitive is then sent (again via U-RLC SAP) requesting the appropriate amount of data for the DTCH/DCCHs. Note that the two sub-components should send a request to U-RLC SAP even if no actual data is required, so that U-RLC SAP knows this and can send the UMAC_Status_IND primitive to URLC at the right time. Also included in the UMAC_Status_IND primitive is a boolean that provides details to U-RLC about whether the last transmission on each particular logical channel was successful or not. This is only regarding the data being ed to U-PHY and so is really only of use for RACH transport channel data. After a transmission, in the case of there being no data actually to send in the next frame from the logical channel then the primitive is sent anyway but requesting zero data. The Buffer Occupancy request for UM and AM Radio Bearers returns the number of bytes waiting in U-RLC for that Radio Bearer. For TM Radio Bearers the size of the next SDU plus the number of SDUs of that size is returned. This is due to the different way that TM works in relation to UM and AM, by not allowing segmentation in U-RLC. U-MAC is provided with the U-RLC mode by U-RRC, in the Radio Bearer configuration. Although U-RRC provides a logical channel priority to U-MAC for CCCH it is actually fixed to one (specified in the U-RRC 3GPP specification) so in practice CCCH data will take priority over DTCH/DCCH data (one being the highest logical channel priority possible).

Uplink Data, Common logical channel to common Tr channel In this the CCCH (logical channel) data that is to be sent on the RACH transport channel. The data received from URLC will immediately be processed by MAC-c/sh and ed on to UPHY.

Uplink, dedicated logical mapped to common Tr channel In this case DTCH/DCCH data has to be sent on the RACH transport channel. In this scenario there can be several DTCH/DCCHs may be multiplexed. The incoming data from URLC is multiplexed by MAC-c/sh, then the appropriate headers are added and the data is ed on to UPHY.

Uplink, common logical channel mapped to dedicated or common logical channel mapped to common Tr channel In this scenario the requirement will be that both CCCH logical channel data and DTCH/DCCH logical channel data is to be sent on the RACH transport. It thus combines the previous two cases.

Uplink, dedicated logical channel mapped to dedicated Tr channel

c

The DTCH/DCCH logical channel data is to be sent on DCH transport channels. The incoming data is immediately processed by MAC-d and ed on to U-PHY. As all the logical channels were requested in a single UMAC_Status_IND primitive then all the data for the logical channels is received in a single UMAC_Data_REQ primitive. The transport channel data is transferred to U-PHY as a single UPHY_Data_REQ primitive (i.e. all of the data for a single CCTrCh is sent together).

Downlink data flow In the DL it is much more straightforward as data is received from U-PHY with the UPHY_Data_IND primitive asynchronously. Each UPHY_Data_IND primitive contains data for a single TTI. The data is processed as soon as possible and ed to U-RLC with a single UMAC_Data_IND primitive. If U-PHY sends several transport channels in a single primitive then each will be processed sequentially within the single STF. The U-PHY SAP will separate transport channel data that is to be sent to different U-MAC sub-components (i.e. 'MAC-b', 'MAC-c/sh' and 'MAC-d') and transfer only the data appropriate to that sub-component. After processing U-MAC will collate the data in U-RLC SAP - i.e. the primitive will include the data for all of the logical channels being sent due to the data with a particular TTI in an incoming UPHY_Data_IND. The different scenarios which can happen DL in of mapping of logical channel to transport channel are as follows: {c {c {c {c {c {c {c

D D D D D D D

c)c c)cc cº?c c)cc cº?c c)cc c cc cº?c ccc cD&º?c cD&Dcc c c c cc

Identification of Logical Channel Type from Radio Bearer ID No U-RRC messages defined in the U-RRC 3GPP specification contain the Logical Channel Type. This means that when UE U-RRC receives the Radio Bearer configuration from UTRAN U-RRC it has no information about the Logical Channel Type used for each Radio Bearer (whereas there is a Transport Channel Type so that information is known). Therefore how can UMAC be given the information to map a Logical Channel Type to a Transport Channel Type? The answer is that in the UE the Logical Channel Type can be inferred from the Radio Bearer ID. For Radio Bearers 0 through 4 the Logical Channel Type is specified in the U-RRC 3GPP specification section 6.3. For Radio Bearers 5 through 31 the Logical Channel Type is always DCCH or DTCH (which U-MAC does not distinguish between). In the DL Radio Bearer IDs are not specified in the 3GPP specifications for some of the common logical channels. However, for our implementation negative values have been assigned. The table below illustrates the above facts. Radio Bearer RB 0 RB 1 RB 2 RB 3

Logical inferred CCCH DCCH DCCH DCCH

Channel

c

RB 4 RB 5..32

DCCH DTCH or DCCH

Elements for layer-to-layer communication The interaction between the MAC layer and other layers are described in of primitives where the primitives represent the logical exchange of information and control between the MAC layer and other layers. The primitives shall not specify or constrain implementations. The MAC is connected to layer 1, RLC and RRC. The following sub clauses describe the primitives between these layers.

Primitives between MAC and RLC The primitives between MAC layer and RLC layer are shown in table below. Parameter Requeté Indication Résponse MAC-DATA Data, BO, UE-ID Data, No_TB, type indicator, RLC Entity Info TD (note), Error indication MAC-STATUS No_PDU, BO, PDU_Size, TX status, RLC Entity Info Status_Report_REQ NOTE: TDD only. Generic Name

Confirm

MAC-DAA-ReqÀnd: ?%D??%' c c c c c c c c c c PDc c c c c c c c c c#cc {c ?%D??%c c c c c c c c PDc c c c c c cc c c c c c cc {c

MAC-AU-ÀndResp: ?%?%c c c c '(c c c c c c c c c c c c c c ? c P c c c c c PDc c c c c c c c c cc Dc#c cc c c?c cc c c c c c c c c cc c c cc ccc c c c c cºc c c cc c c c c c ? c c $c ?%?%c cc c c c c c ?c c '(c c ?c c c c c*c *%D??%'$*ccc ccº c ! ! c c c c c c '(c PDc c '?c c Pc c c c c c c cc cc {c ?%?%'c cc'(c c cc?%?% c cc c c '(c cc c c c c c cc c cc c c ccccc c c c c c cc c c? cc {c

$ % a) Data: It contains the RLC layer messages (RLC-PDU) to be transmitted, or the RLC layer

c

messages that have been received by the MAC sub-layer. b) Number of transmitted transport blocks (No_TB) : indicates the number of transport blocks transmitted by the peer entity within the transmission time interval, based on the TFI value. c) Buffer Occupancy (BO): the parameter Buffer Occupancy (BO) indicates for each logical channel the amount of data in number of bytes that is available for transmission and retransmission in RLC layer. When MAC is connected to an AM RLC entity, control PDUs to be transmitted and RLC PDUs outside the RLC Tx window shall also be included in the BO. RLC PDUs that have been transmitted but not negatively acknowledged by the peer entity shall not be included in the BO. d) RX Timing Deviation (TD), TDD only: it contains the RX Timing Deviation as measured by the physical layer for the physical resources carrying the data of the Message Unit. This parameter is optional and only for Indication. It is needed for the transfer of the RX Timing Deviation measurement of RACH transmissions carrying CCCH data to RRC. e) Number of PDU (No_PDU): specifies the number of PDUs that the RLC is permitted to transfer to MAC within a transmission time interval. f) PDU Size (PDU_Size): specifies the size of PDU that can be transferred to MAC within a transmission time interval. g) UE-ID Type Indicator: indicates the UE-ID type to be included in MAC for a DCCH and DTCH when they are mapped onto a common transport channel (i.e. FACH, RACH, DSCH in FDD or CH). On the UE side UE-ID Type Indicator shall always be set to C-RNTI. h) TX status: when set to value "transmission unsuccessful" this parameter indicates to RLC that transmission of an RLC PDU failed in the previous Transmission Time Interval, when set to value "transmission successful" this parameter indicates to RLC that the requested RLC PDU(s) has been submitted for transmission by the physical layer. i) RLC Entity Info: indicates to MAC the configuration parameters that are critical to TFC selection depending on its mode and the amount of data that could be transmitted at the next TTI. This primitive is meant to insure that MAC can perform TFC selection (see sub clause 11.4). j) Error indication: When a MAC SDU is delivered to upper layer, an error indication is given for the SDU to upper layer if an error indication for the SDU has been received from lower layer. k) Status_Report_REQ: indicates to all AM RLC entities mapped on HS-DSCH to generate a status report when the MAC-hs resets.

Primitives between MAC and RRC The primitives between MAC and RRC are shown in table below. Parameter Request CMAC-CONFIG UE information elements, Generic Name

Indication

Response

Confirm

c

RB information elements, TrCH information elements, RACH transmission control elements, Ciphering elements, CH transmission control elements CMACMeasurement information Measurement MEASUREMENT elements result CMAC-STATUS Status info CMAC-CO À-Req: {c

"Nº4%' ccc c c c ccc c cc cc c'Nc c c c c c ccc cc ºc c cc c c c cc

CMAC-MEAUREME -ReqÀnd: ?%$?'$$N%' c c c c ''c c c ?c c c c c c c #cc {c ?%$?'$$N%ccc c c''c c c c cc {c

CMAC-AU-Ànd: {c

?%?%c c c''c c c cc

$ a) UE information elements: S-RNTI, SRNC identity, C-RNTI, Activation time b) RB information elements: RB multiplexing info (Transport channel identity, Logical channel identity, MAC logical channel priority) c) TrCH information elements: Transport Format Combination Set, MAC-hs reset indicator, Reordering release timer (T1) d) Measurement information elements: Reporting Quantity identifiers Time interval to take an average or a variance (applicable when Average or Variance is Reporting Quantity) e)Measurement result: Reporting Quantity f) Status info: when set to value ""transmission unsuccessful"" this parameter indicates to RRC that transmission of a TM RLC PDU failed (due to e.g. Maximum number of preamble ramping cycles reached for RACH in FDD), when set to value "transmission successful" this parameter indicates to RRC that the requested TM RLC PDU(s) has been submitted for transmission by the physical layer.

c

g) RACH transmission control elements: Set of ASC parameters (identifier for PRACH partitions, persistence values), Maximum number of preamble ramping cycles (FDD) or synchronization attempts (1.28 Ms TDD), Minimum and maximum number of time units between two preamble ramping cycles, NBO1min and NBO1max (FDD only), ASC for RRC CONNECTION REQUEST message h) Ciphering elements: Ciphering mode, Ciphering key, Ciphering sequence number i) CH transmission control elements: CH persistency value, P for each Transport Format, Maximum number of preamble ramping cycles N_access_fails, NF_max (Maximum number of frames for CH transmission for each Transport Format), N_EOT (Number of EOT for release of CH transmission), Backoff control timer parameters, Transport Format Set, Initial Priority Delays, Channel Assignment Active indication

Elements for peer-to-peer communication Protocol data units   A MAC PDU is a bit string, with a length not necessarily a multiple of 8 bits. Generally the bit string is to be read from left to right and then in the reading order of the lines. Depending on the provided service, MAC SDUs are bit strings with any non-null length, or bit strings with an integer number of octets in length. An SDU is included into a MAC PDU from first bit onward. In the UE for the uplink, all MAC PDUs delivered to the physical layer within one TTI are defined as Transport Block Set (TBS). It consists of one or several Transport Blocks, each containing one MAC PDU. The Transport Blocks, shall be transmitted in the order as delivered from RLC. When multiplexing of RLC PDUs from different logical channels is performed on MAC, the order of all Transport Blocks originating from the same logical channel shall be the same as the order of the sequence delivered from RLC. The order of the different logical channels in a TBS is set by the MAC protocol.

!& '#'!# A MAC PDU consists of an optional MAC header and a MAC Service Data Unit (MAC SDU) see figure below.

c

Both the MAC header and the MAC SDU are of variable size. The content and the size of the MAC header depends on the type of the logical channel, and in some cases none of the parameters in the MAC header are needed. The size of the MAC-SDU depends on the size of the RLC-PDU, which is defined during the setup procedure.

' !&#'!#

c

For HS-DSCH the MAC-d PDU format equals the MAC PDU format for the non HS-DSCH case.

!&#'!# In case of HS-DSCH a MAC PDU consists of one MAC-hs header and one or more MAC-hs SDUs where each MAC-hs SDU equals a MAC-d PDU. A maximum of one MAC-hs PDU can be transmitted in a TTI per UE. The MAC-hs header is of variable size. The MAC-hs SDUs in one TTI belongs to the same reordering queue.

c

Formats and parameters NOTE: MAC header field encodings as specified in this clause with designation "Reserved" are forbidden to be used by a sender in this version of the protocol.

! ! & #'!# ' ! &#'!# The following fields are defined for the MAC header for transport channels other than HS-DSCH and for the MAC-d PDU header for HS-DSCH: {c

c c c º c c ºc c c c c c c c c c c cc cº?cc'?c cc c c cc)ccc c c c cc cccc c cºc cºDDccDDc c cc cc!cåccc5 cN c c cc c cºcc cº?c cºDDcc c !c c6c cc c cc c c!c c c cc cDDcc cåc c5c c c c cc c cåc c c ccºc c c'?c cDDcc c!c cc cc c cc c c!c c c cc

Table 1: Coding of the Target Channel Type Field on FACH for TDD TCTF 000 001 010 01100

Designation BCCH CCCH CTCH DCCH or DTCH

01101-

over FACH Reserved

01111

(PDUs with this coding will be discarded by this version of the protocol)

100 SHCCH

c 101-111

Reserved (PDUs with this coding will be discarded by this version of the protocol)

cc

Table 2: Coding of the Target Channel Type Field on FACH for FDD TCTF 00 01000000 0100000101111111

10000000 1000000110111111

11

Designation BCCH CCCH Reserved (PDUs with this coding will be discarded by this version of the protocol) CTCH Reserved (PDUs with this coding will be discarded by this version of the protocol) DCCH or DTCH over FACH

cc

Table 3: Coding of the Target Channel Type Field on USCH or DSCH (TDD only) TCTF 0 1

Designation SHCCH DCCH or DTCH over USCH or DSCH

cc

Table 4: Coding of the Target Channel Type Field on RACH for FDD TCTF 00 01

Designation CCCH DCCH or DTCH

10-11

over RACH Reserved (PDUs with this coding will be discarded by this version of the protocol)

cc

Table 5: Coding of the Target Channel Type Field on RACH for TDD

c TCTF 00 0100

Designation CCCH DCCH or DTCH

0101-

Over RACH Reserved

0111

10 11

(PDUs with this coding will be discarded by this version of the protocol) SHCCH Reserved (PDUs with this coding will be discarded by this version of the protocol)

{c

&c c c &c c c c c c c c c c c cccc c c c cc c c%Dc c c?% c c %D cc&cccc c c c c c c cc c c c ccc cº?cc'?ccc cc c c c c c c &c c c c c c c c c

c c c c c c cc c c c% c&c cc

Table : Structure of the C/T field C/T field 0000 0001 ... 1110 1111

Designation Logical channel 1 Logical channel 2 ... Logical channel 15 Reserved (PDUs with this coding will be discarded by this version of the protocol)

{c

$% c c $%c c c c c c c $c c

c c c c c c c$%cc c?cc cc c '?Nc' cN c c c %'Nc cccc c?cc c Dc c '(c c ')c c c c

c c c c c #c c%'Ncccccc #cc c c ' c N c c c %'Nc c c c Dc c Dc c c c ccc cDcc cccc cDcc cc c c

c cc cc c cDc c#cc c c ºDDc Dc ' c N c c c D%'Nc c c c Dc c Dcc cc c cDc c#%c c$cc cccc ?c c c c c ?c c ?P c c c c c $%c c c c ?ccccc c cc

Table : Lengths of UE Id field UE Id type U-RNTI C-RNTI DSCH-

Length of UE Id field 32 bits 16 bits 16 bits

c RNTI {c

$%c cc$%ccccc cc c c c c$%ccc?c cc

Table : UE-Id Type field definition UE-Id Type field 2 bits 00 01

UE-Id Type U-RNTI C-RNTI or DSCH-RNTI Reserved

10

(PDUs with this coding will be discarded by this version of the protocol) Reserved

11

(PDUs with this coding will be discarded by this version of the protocol)

! !& #'!# a) DTCH or DCCH mapped to DCH, no multiplexing of dedicated channels on MAC: no MAC header is required. b) DTCH or DCCH mapped to DCH, with multiplexing of dedicated channels on MAC: C/T field is included in MAC header. c) DTCH or DCCH mapped to RACH/FACH: TCTF field, C/T field, UE-Id type field and UE-Id are included in the MAC header. For FACH, the UE-Id type field used is the C-RNTI or URNTI. For RACH, the UE-Id type field used is the C-RNTI. d) DTCH or DCCH mapped to DSCH or USCH: the TCTF field is included in the MAC header for TDD only. The UE-Id type and UE-Id are included in the MAC header for FDD only. The UE-Id type field used is the DSCH-RNTI. The C/T field is included if multiplexing on MAC is applied. e) DTCH or DCCH mapped to DSCH or USCH where DTCH or DCCH are the only logical channels: the UE-Id type and UE-Id are included in the MAC header for FDD only. The UE-Id type field used is the DSCH-RNTI. The C/T field is included in the MAC header if multiplexing on MAC is applied. f) DTCH or DCCH mapped to CH: UE-Id type field and UE-Id are included in the MAC header. The C/T field is included in the MAC header if multiplexing on MAC is applied. The UE-Id type field used is the C-RNTI. c

c

c ?Dc c cDccDcc

'  ! !& #'!# The MAC-d PDU header for DTCH and DCCH mapped on HS-DSCH is as shown in figure below. C/T field is included in the MAC-d PDU header if multiplexing on MAC is applied. c

c ?%Dc c cDccDc c c%Dcc

 a) BCCH mapped to BCH: no MAC header is included. b) BCCH mapped to FACH: the TCTF field is included in MAC header. c

c ?Dc c c)cc

 There is no MAC header for PCCH.

 CCCH mapped to RACH/FACH: TCTF field is included in MAC header. c

c c ?Dc c ccc

  The TCTF field is included as MAC header for CTCH as shown in figure below. c

c ?Dc c ccc

 # The MAC header for SHCCH is as shown in figure below. c

c ?Dc c ccc

a) SHCCH mapped to RACH and USCH/FACH and DSCH: TCTF has to be included. b) SHCCH mapped to RACH and USCH/FACH and DSCH, where SHCCH is the only channel.

! &#'!# {c

{c

{c

{c

{c

3 c ºc 3º c c 3ºc c c c c c c c c c c c ?%c PDc cc3ºcccc c c cc cc cccc c c c c cc *c c *cD cc*cDcc c c c c c c c ccc c c c ccc c c c c c c cc c c c*cDcccåc cc c cN c N ccNcc cc c c c c c c c c%D ccNcccc c c c c c% cc cc cc c c cNcccc cc cc c D ccDcc c cc cc c c c?%D c c?%Dcc cccDcc cccccc c cc *cD cc c c cDcccåc cc N c c ?%Dc PDc N c c c c c ?%c PDc c c c c c c c Nc c c c c c Nc c c 7c c c ºDDc c c c c Dc ccccccc c cc71 cc !6ccDDc c c c c c PDc cc c c c c c c c c 5 c c å 6c cDDc c c c c Dc ccccccc c c cå6 cc Dc c cc c c Dc c c c c cc c$c cc cc

c {c ºc º ccºccccc cc ccc cc c?%cc c cc cºccc c c818c cºccc ccc c c cDcNccºc cc cºc c c c c 88c c ºc c c c c c ?%c PD c c c c c ?%c c c c c ccºc c c818ccccccc c cc7 cc

c c c c cc c c c cccccc c$c cc cc

! ! a) DTCH or DCCH mapped to HS-DSCH: The Queue ID field and TSN field are always included in the MAC-hs header. One SID field, N field and F field is included for each MAC-d PDU size included in the MAC-hs PDU. Padding is not explicitly indicated but is included in the end of the MAC-hs PDU if the total size of the MAC-hs payload plus the MAC-hs header is smaller than the transport block set size. c c c c c c c c c

oft Handover (HO) À Soft Handover is one of the most interesting feature of the WCDMA operation. In this case the UE always has radio link connection. In case of GSM only hard handover was possible where the radio connection is lost before new connection is established. In UMTS hard handover is also possible when we are changing frequencies but generally soft handover will be used when in the same frequency. Hard handover is possible in the same frequency (Intra-frequency) scenario when RAB is being added and there are not enough codes available on the current cell then the network might ask the UE to move to new cell (scrambling code). In this tutorial we will not mention Softer handover separately as it is a special case of Soft Handover. For more details please see Handover Tutorial. Softer handover will be referred to as Soft Handover in this document. Please note that Soft handover procedure could include Radio link that belongs to the same Node

c

B, different Node B but the same RNC or a Node B that belongs to dirrent RNC (Drift RNC). For more details please see Handover Tutorial. Also note that the Soft Handover procedures does not involve the Core Network. It just involves the RNC, Node B and the UE. The Soft Handover procedure is only applicable to UEs in FDD mode of operation. Ô Ñ Before we begin there are some that need to be discussed. The UE measures the cells on the Intra Frequency in order for the network to decide which cells to add in the Active Set. An Active Set contains all the Cells that the UE is listening to and Transmitting to. The Cells that UE measures belong to one of the three categories: 1.c Cells, which belong to the active set. information is sent from all these cells. In FDD, the cells in the active set are involved in soft handover. The UE shall only consider active set cells included in the variable CELL_INFO_LIST for measurement; i.e. active set cells not included in the CELL_INFO_LIST shall not be considered in any event evaluation and measurement reporting. 2.c Cells, which are not included in the active set, but are included in the CELL_INFO_LIST belong to the monitored set. 3.c Cells detected by the UE, which are neither in the CELL_INFO_LIST nor in the active set belong to the detected set. Reporting of measurements of the detected set is only applicable to intra-frequency measurements made by UEs in CELL_DCH state. $ % $00 я When RRC Connection is setup, UE generally moves to CELL_DCH. This is based on the network configuration and it is the network that will decide if the UE has to enter CELL_DCH or CELL_FACH. For simplicity we assume that the network puts the UE in CELL_DCH. In CELL_DCH state UE generally starts with one Radio Link that belongs to its Active Set. In CELL_DCH state UE will generally start Intra Frequency Measurements. These measurements are either setup via System Information broadcasted on BCH or through a Measurement Control Message (MCM). The System Information Block Sib11/12 or MCM contains the Cell Info List that the UE has to store to perform measurements. All the cells in the Cell Info List are either in Active Set and if not in Active Set then they are in Monitored Set. The network might ask the UE to report Detected Cells. These are the cells that UE can see but were not sent in the Cell Info List. If asked then the UE reports them whenever Measurement Reports are sent out. À These Measurements can be either Periodic or Event Based. For SHO, Event Based Measurements are generally used. The Intra Frequency Measurement Events are from 1A to 1I. For SHO Event 1A, Event 1B and Event 1C are important. Event 1A and Event 1C could be periodic Event Based Measurements. In this case the network might ask that if an Event is trigerred than the UE should keep sending the report N number of times; where N is specified in the Measurement Control message or Sib11/12.

c

The figure above demonstrates a simple (cannot happen in practice though) scenario when Cell 1 has same power but Cell 2 has its power increasing till a certain point after which it decreases. Now the Intra Frequency Event 1A notifies to UTRAN that a particular Cell has reached power level above the threshold. Similarly Event 1B notifies to UTRAN that a particular cell has power level below the threshold. For Event 1A (and 1C) UTRAN can request more than one report for a single event that has occurred. This is to make sure that only suitable cells are added to active list. When Event 1A is sent to the UTRAN, UTRAN will add the new cell in the UE's active cell list and will send an ACTIVE SET UPDATE message that will add the cell to the UE's active set. Similarly when Event 1B is sent then UTRAN will send ACTIVE SET UPDATE message to remove the cell from UE's active set. When Event 1C is sent, UTRAN will send ACTIVE SET UPDATE message that will remove one or more cells and will add one or more cells. The only restriction for 1C is that there should be atleast one radio link that is not affected by the procedure. This radio link will exist before and after ACTIVE SET UPDATE message. To avoid problems, Event 1B can only occur is there are more than one active radio links. Similarly there is an option available in the Measurement Criteria IE that deactivates Event 1A after certain number of cells are added in the active set. This is to avoid sending 1A and 1C for the same scenario. Similarly Event 1C only becomes applicable if there are more than one active radio links. The network can decide how many radio links are needed in active set for Event 1C triggering to start.

c

The figure above shows the scenario of triggering of Event 1C. In this case when the first Event 1C is triggered UTRAN sends ACTIVE SET UPDATE to add Cell 4 and delete Cell 2. Similarly when the second Event 1C is triggered Cell 1 is replaced by Cell 3. % % $& Lets look at an example where Cell 2 has triggered Event 1A and the network decides to add it in the Active Set c ccccccccccccccccccccccccccccccccc#c$cccccccccccccccccccccccccccc c ccccccccccccccccccccccccccccccccccccccccccccccccccc ccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccc ccccccc %c c c&c'%cc(cccccccccccccccccccccccc cccc ccccccccccccccccccccccccccccccccccccccc$)%c c*c + cccccccc cccccccccccccccccccccccccccccccccccccc ccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccc cccccccccccccccccccccccccccccccc* c ,ccccccccccccccccccccccccccccccccc cccccccccccccccccccccccccccccccccccccccccc$)%c c*c cccc cccccccccccccccccccccccccccccccccccccc cccccccccccccccccccccccccccccccccccccccc)%c ccccccccccccccccccc cccccccccccccccccccccccccccccccccccccc ccccccccccccccccccccccccccccccccccccccccccccccccccc)%c-cccccccc cccccccccccccccccccccccccccccccccccccc cccccccccccccccccccccccccccccccccccccccccccccc$)%c c c"#ccc cccccccccccccccccccccccccccccccccccccc ccccccccccccccccccccccccccccccccccccccccccc!.-)%c!/0c*1ccccc cccccccccccccccccccccccccccccccccccccc cccccccccccccccccccccccccccccccccccccccccccc!.-)%c0c*1cccccc cccccccccccccccccccccccccccccccccccccc cccccccccccccccccccccccccccccccccc* c,cccccccccccccccccccccccccccc cccccc %c&c*c# ccccccccccccccccccccccccccccccccccccccccc cccc ccccccccccc ##cc(cccccccccccccccccccccccccccccccccccccccccccccc ccccccccccccccccccccccccccccc %c&c*c# c cccccccccc cccc ccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccc ccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccc c

Similarly suppose Cell 2 has now triggered Event 1B and UTRAN decides that Cell 2 has to be removed than the signaling flow will be as follows:

c c ccccccccccccccccccccccccccccccccc#c$cccccccccccccccccccccccccccc c ccccccccccccccccccccccccccccccccccccccccccccccccccc ccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccc ccccccc %c c c&c'$%cc(cccccccccccccccccccccccc cccc cccccc %c&c*c# ccccccccccccccccccccccccccccccccccccccccc cccc ccccccccccc &cc(ccccccccccccccccccccccccccccccccccccccccccc ccccccccccccccccccccccccccccc %c&c*c# c cccccccccc cccc ccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccc cccccccccccccccccccccccccccccccccccccc$)%c c!c +cccccccccc cccccccccccccccccccccccccccccccccccccc cccccccccccccccccccccccccccccccccccccccccc$)%c c!c ccccc cccccccccccccccccccccccccccccccccccccc ccccccccccccccccccccccccccccccccccccccc)%c cccccccccccccccccccc cccccccccccccccccccccccccccccccccccccc ccccccccccccccccccccccccccccccccccccccccccccccccccccccc)%c cccc cccccccccccccccccccccccccccccccccccccc ccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccc ccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccccc cccc

The signaling for Event 1C will be combination of the above. c c c c c c c c c c c c c c c c

c

CAMEL: An Àntroduction À Customized Applications for Mobile network Enhanced Logic also known as CAMEL was developed as a standard for mobile intelligence across different vendor equipments for GSM network. What this means is that the end should be able to roam between different networks (maybe in different countries) and be reachable at the same number and should receive only one bill from the original service provider (Home Operator). Before CAMEL, the GSM networks used INAP (Intelligent Network Application Part) for injecting intelligence in GSM networks. The limitations of INAP was that it did not mobility management. CAMEL solved the mobility management problem and provided with much more functionality. With the evolution of 3G standards, CAMEL has evolved to provide new functionalities that will be discussed later. CAMEL has been divided into Phases. The last section in this primer lists the functionality of each phases. The latest Phase is Phase 4. If an IPLMN (Interrogating PLMN) or VPLMN (Visiting PLMN) s CAMEL Phase 4, it shall also provide the functionality of all previous CAMEL phases. The first commercial implementation of CAMEL (phase 1) was in August 2000 by Telecom Mobiles (), Mobistar (Belgium) and Dutchtone (The Netherlands). xx% $ ( " ) $ ( # " #$0 {c

{c {c {c {c {c {c

c c c c c c c

c " & c c c c c c c cc c cc c cc ?$(c ccc cPc cc c$ cc c c ccc ?$(cc cPc cccc c c cc cc&Pc ccc c c c3 Pcc3 c cP cc ?$(c ccc cPc c ccc c$ c c cPc'( cc

c

$& #$0 Before we proceed further and use more technical , it would be wise to understand CAMEL procedure with the help of some examples.

c

Take a simple scenario of a voice call being made. When a subscriber starts to make a call, this request is received by the network's Mobile Switching Centre (MSC). The MSC then sends a message that 'queries' the S's database. Note that the essential element of any CAMEL solution is a Service Control Point (S). This unit effectively hosts a database which holds the instructions needed for an intelligent application. The S processes that query, comes up with an appropriate response and then sends a message back to the MSC telling what action it should take with the subscriber¶s request for a specific service. The call is then connected in the most appropriate manner, a process which is transparent to the customer. A very good example of this process in action is short code dialing over a VPN (Virtual Private Network) where the calls a colleague¶s internal extension telephone number but is, in fact, routed to that person¶s mobile phone which is roaming abroad. The main addition in CAMEL phase 2 which phase 1 omitted is for a Specialized Resource Function (SRF) a component most often found in Voice Response Units (VRUs). For example, when an balance reaches zero for a pre-paid customer under phase 1, the customer will simply be cut off. With phase 2 thanks to for SRF, the customer will hear automatically generated messages from the Voice Response Unit warning that the balance is dangerously low before a call and even during the call. Naturally this leads to greater customer satisfaction. For any further discussions we would need to use some technical . They are discussed in this section. {c



c (Nc c c c (Nc P(Nc c c cc c c cc

c {c {c

{c {c

{c

{c {c

{c

{c

{c

{c

{c

c?c$ccc c cc c c c c" ccc " cc c c c "

! ! c c c c c c c c c c c c ºc c c c cc

c

$& % % [13] Gives example of Signaling procedures using CAMEL for originating and terminating calls and has been described below.

c

c

If an active originating CAMEL Subscription Information (CSI) is found in the VLR during the call set up of a MS, the Visited Service Switching Function (VSSF) sends an Initial Detection Point message to the gsmSCF and the VMSC suspends the call processing. The Initial Detection Point shall always contain the service key, called and calling party number, calling party¶s category, location number, bearer capability, event type Basic Call State Model (BCSM), location information and the International Mobile Station Identity (IMSI). After the service logic processing CAMEL specific handling is initiated from the gsmSCF, see figure above.

c

In the case of mobile terminating call, the Gateway MSC (GMSC) in the interrogating PLMN identifies the HLR of the called party with the help of the MSISDN. Then the GMSC sends a Routing Information-Request to the HLR. The HLR checks the CSI of the called party and sends the information stored

c

in the subscriber record back to the GMSC. Now, the GMSC acts according to CSI. If the terminating CSI is active the trigger criteria of a Detection Point (DP) is fulfilled and the call processing is suspended. An Initial DP message, which shall always contain the service key, called party number, event type BCSM and the IMSI is sent to the CSE and the service logic execution is started. Thereafter CAMEL specific handling is initiated, see figure above. #$0 '

CAMEL phase £: £ £ £ º



{c

Triggering on MO, MT and forwarded calls.

{c {c {c {c {c {c

{c

Any Time Interrogation

N c Nc c cc N cc cc ( c c c c c c c c cc c cc c c c c c 4c cc N c c c c c º -c c 3PNc c cc

ccc c3PNcc cº cc c' cc c' cc c c %c c c P(Ncc

{c

The CSE may request HLR to provide subscriber status and/or location information at any time.

c c c c cc % % c c c c cc cc cc {c c cc

{c {c

{c

{c

CAMEL phase D: D £ D º

Triggering on MO, MT and forwarded calls.

ccc 3PNc ccc cº cc c' cc c' cc º % ccc %c c c Dºcc {c cc cc

{c {c {c {c {c {c {c



{c

c c c c c 4c cc

c

Charging operations

{c {c {c {c {c {c

P%c "ccºcc º% cc P c cc %cc P cD cc ( cD c cc 'ccc

CSE provided e-parameters

{c

"c? cc

New detection points (Abandon, Busy, Not Reachable, No Answer, Route Select Failure cases) Triggering criteria

%cc

c c cc {c ) c%c cc {c c c c cc {c

c

{c

To reduce CSE & SSP load

{c

The CSE may request HLR to provide subscriber status and/or location information at any time.

Any Time Interrogation

-

c c c c c c % % c c c c c c cc cc {c N cc cc

{c

Dc %c c %c cc {c c 9c c c Nc c cc

{c

USSD communication between MS and CSE

Control of north American carrier information

Notification of supplementary service (CCBS, ECT, CD and MPTY) invocation to CSE

{c {c {c

$c%cc $ccc cc c c c c c cc cc c

{c

Fraud control c

å CAMEL phase å: å £ å º cc

Triggering on MO, MT and forwarded calls.

Purpose / s {c {c {c {c {c {c {c

ccc ºc3PNcc cº cc c' cc c' cc º % ccc %cc c Dºcc

Restri

c

c {c

cc cc

{c {c {c {c {c {c

P%c "ccºcc º% cc P c cc P cD cc ( cD c cc 'ccc

?$(!c c c c ? c )c N c 'cN c?c' c cºccc

{c {c {c

c c c cc ) c%c cc c c c cc

?$(åcc c c cc

{c

c c c c c c c c cc

Charging operations

CSE provided e-parameters

c cc

c

c

c

{c

c

c

cc$c9cPc cc

c {c

Any Time Interrogation. Enhanced with CAMEL3 current location retrieval, and ATI for GMLC.

c $c c c ('c c c c c& c c c cc cc

{c

USSD communication between MS and CSE

{c {c

Dc%c c%c cc c9c c cNccc

Control of north American carrier information

{c {c {c

$c%cc $ccc cc c c c c c cc c cc

{c

Fraud control

Notification of supplementary service (CCBS, ECT, CD and MPTY) invocation to CSE

c

c {c

To control CSE overload situations within HPLMN

{c

c c c c c èc cºcDc$cP*cc

MT call triggering in VMSC-B

{c

Pre-paid for MT air-time charge (1st minute c free, e.g. in USA)

Abandon as an EDP-R

{c

Improves charging

Enhanced Free Format Charging data (40 octets -> 160 octets)

{c

Reporting of MSRN/FTN to CSE

{c

Call Gapping

{c

c Makes the CSE service logic easier c Charging control of optimally routed calls c

c c cc!cc $c c c ºc c c cc {c "%c c c c c 3P(Nc &c c % %cc {c 3 c cc {c {c

CSE-HLR interface: ATM/ATSI/NSDC

Subscribed dialed services (D-CSI)

{c

HPLMN specific service numbers

{c

Serving Network Dialed services (N-CSI)

{c

VPLMN specific service numbers

{c

MO SMS control (CS+PS)

{c {c

$c% cc $c3PNcc

{c {c

Inter-working with GPRS

{c

GPRS pre-paid

{c

CS Mobility management notifications

{c

CSE can monitor location / reachability c

$c c c % c c c c èc c ºc Dc $c P* cc c {c cc cc!cc

{c

Service Interaction Indicators

CAMEL phase 4: [ £ [

Functionality

Purpose / s

Triggering on MO, MT and forwarded calls.

{c {c {c {c {c {c {c {c

ccc ºc3PNcc cº cc c' cc c' cc º % ccc %cc c Dºcc cc cc

Charging operations

{c {c {c {c {c {c

P%c "ccºcc º% cc P c cc P cD cc ( cD c cc 'ccc

CSE provided e-parameters

{c

MO & MT AoC

CAMEL2 new detection points (Abandon, Busy, Not

{c {c

Restrictions

c

c

c È Cleaner termination of relationship. Èc) c%c cc

c

c

Reachable, No Answer, Route Select Failure cases)

{c

Èc c c c cc

CAMEL3 new detection points.

{c

È To trigger on demand only, e.g. for hunting services.

trigger

c

È To reduce CSE & SSP load

Triggering criteria

{c

Any Time Interrogation. Enhanced with CAMEL3 current location retrieval, and ATI for GMLC. CAMEL4 enhances this to PS domain.

c $c c c ('c c c c c & c c c cc cc c {c c?c c4(cc

USSD communication between MS and CSE

{c {c

Dc%c c%c ccc c9c c cNccc

{c {c {c

$c%Èccc $ccc cc c c c c c c c c cc

{c

È Fraud control

c

Control of north American carrier information Notification of supplementary service (CCBS, ECT, CD and MPTY) invocation to CSE

{c

c

c {c

Call Gapping

For CS calls È To control CSE overload situations only. Not for within HPLMN SMS or GPRS.

{c

È To control MT supplementary services (CW, hold, CF, CD, ECT, MPTY)

MT call triggering in VMSC-B

{c

È%c cc% cc c c c c cc?cc

Abandon as an EDP-R

{c

È Improves charging

Enhanced Free Format Charging data (40 octets -> 160 octets)

{c

Reporting of MSRN/FTN to CSE

c c {c

interface:

È Charging control of optimally routed calls

c

c cc!cc $c c c ºc c c cc {c "%c c c c c c 3P(Nc&c % %cc {c 3 c cc {c {c

CSE-HLR ATM/ATSI/NSDC

È Makes the CSE service logic easier

c

Subscribed dialed services (DCSI)

{c

È HPLMN specific service numbers

È No call supervision

Serving Network services (N-CSI)

{c

È VPLMN specific service numbers

È No call supervision

SMS control (CS+PS)

{c {c

È Enhances pre-paid. Èc$c3PNcc

Inter-working with GPRS

{c

È GPRS pre-paid

CS Mobility notifications

{c

È CSE can monitor location / reachability

Dialed

management

È Not content based È Not content based c

È CSE can control inter-working with supplementary services (CW, hold, CF, CD, ECT, MPTY). c {c Èc cc cc!cc {c

Service Interaction Indicators

Interactions Routing

with

Optimal

{c

È CSE can control usage of OR c

Call Party Handling

{c {c {c {c {c

è%cccc ccc Pc cc % ccc Ncc)cc

Mid call procedure for MO and MT calls

{c {c

c cPc cc cc ? cc cc

CAMEL for IMS

{c {c

c%cc c ccc4P'ccc

{c {c

$ c c%cc cc 3 c c cc

Inclusion injection

of

flexible

tone

c

c

c

c

{c

c

c

Provision of location information of called subscriber (Alerting phase)

{c

The location of B-subscriber at the beginning of the call provided to service logic c

Notification of GPRS mobility management to CSE

{c

CSE can monitor location / reachability in PS side

Inclusion of ODB data in the CSE-HLR interface

{c

Location information during an ongoing call (Handover DP)

{c

c

Enhancement of MSP ph 2 c c c c c c c %P(Nc& c % c cc

c

c

Transfer of the IMEI (with software version) and MS class mark to the CSE

{c

allow the gsmSCF to determine information about the capabilities of the ME c

Any Time Interrogation from CSE to MNP-SRF

{c

Number portability query for prepay calls

{c

Partial implementation CAMEL phase 4

of

c

A functional entity (VMSC, GMSC or SGSN) may the complete CAMEL phase4 functionality or, as a network option, it may the complete CAMEL phase3 functionality c and a partial implementation of CAMEL phase4.

[ D [ c

Enhancements of Dialed Services Full CAMEL4 SCUDIF

prepay



ÈFull control of Dialed Services

for ÈThe capability to report basic service code changes during ccc ongoing call.

Change of position procedure armed with È Technical enhancement to reduce the signaling load criteria c c c c c c c c c c c c

ccc

ccc

c

High peed Donlink (HDPA): A utorial

Packet

Access

Introduction: HSDPA is a major Release 5 feature. Some of the enhancements will be done in Release 6. HSDPA is designed to data rates up to 10.8 Mbps and at the same time it will co-exist with R99 in the same frequency band of 5MHz. As could be observed this data rate is much higher than the Broadband speeds people generally use in their homes (512Vbps ). HSDPA will be able to satisfy the most demanding Multimedia applications. The peak rate offered by HSDPA is about 10Mbps in 5MHz channel. One important thing to note is that the more important thing here is not the peak rate but the throughput capacity which increases significantly. This leads to more s being able to use high data rates on a single carrier.

What¶s New in HSDPA: 3 Slot TTI (2ms) CQI: Channel Quality Indication AMC: Adaptive Modulation and Coding Constellation Re-Arranging (16 QAM) H-ARQ: Hybrid Automatic Repeat Request N-channel SAW: N-Channel Stop and Wait Protocol New MAC (High Speed) instance

New Stuff for HSDPA: The implementation of HSDPA will require changes mainly in Physical layer. Layer 2 will be affected as well because new high speed MAC entity will be required. The impact to other layers will be minimum. The following sections will throw some light on some of the new features required for HSDPA.

HSDPA Physical and Transport Channels: To HSDPA new Physical channels have been defined: H-PDCH or High peed Phsical Donlink hared Channel: This is a downlink channel which is both time and code multiplexed. The channelization codes have a fixed spreading factor, SF = 16. Multi-code transmissions are allowed that translates to UE being assigned multiple channelization codes in the same TTI, depending on the UE capability. The same scrambling code sequence is applied to all the channelization codes that form the single HSDSCH CCTrCH. If there are multiple UE's then they may be assigned channelization codes in the same TTI (multiplexing of multiple UE's in the code domain). H-DPCCH or High peed Dedicated Phsical Control Channel: This is an uplink channel

c

that carries the Acknowledgements of the packet received on HS-PDSCH and also the CQI (Channel Quality Indication). THE CQI estimates have to be transmitted by the UE every 2.0 ms frame. This information is very important as it ensures reliability and impacts power capacity. H-CCH or High peed hared Control Channel: The HS-SCCH is a fixed rate (60 kbps, SF=128) downlink physical channel used to carry downlink signaling related to HS-DSCH transmission. This provides timing and coding information thus allowing the UE to listen to the HS-DSCH at the correct time and using the correct codes to allow successful decoding of UE data. The main features of the physical channel are as follows: Fixed Spreading Factor of 16 for HS-DSCH QPSV and 16 QAM Modulation Static TTI Length of 3 Time Slots = 2ms Fixed CRC of 24 bits Error Correction using 1/3 Turbo Coding

To HSDPA the following new Transport channels have been defined: H-DCH or High peed Donlink hared channel: The High Speed Downlink Shared Channel is a downlink transport channel shared by several UEs. The HS-DSCH is associated with one downlink DPCH, and one or several Shared Control Channels (HS-SCCH). The HSDSCH is transmitted over the entire cell or over only part of the cell using e.g. beam-forming antennas.

Adaptive Modulation and Coding (AMC): HSPDA standard ensures that highest possible data rate is achieved for all s regardless of whether they are close to the base station or far off. This is done using ACM. For HS-DSCH, the transport format, including the modulation scheme and code rate, can be selected based on the downlink channel quality. The selection of transport format is done by the MAC-HS located in Node B and is based on channel quality reported by the UE. The spreading factor cannot change but the coding rate can change between 1/4 and 3/4. The higher coding rate reduces the number of errors. Also the standards multicodes. This means that up to 15 codes can be allocated to a UE.

Hybrid Automatic Repeat Request (HARQ): In case of ARQ, the receiving system on receipt of data checks the CRC. If the CRC is the same as that received in the message ACV is sent back to the sender. In case if CRC does not match then NACV is sent back and the packet discarded. In case of HARQ, this method of CRC checking is improved based on the following two things. In this when an error is detected in CRC, NACV is sent back but the packet is not discarded. It is stored. In case the re-transmitted packet is again erroneous then the previous and current packet is combined in an attempt to recover from errors. Each time the packet is

c

resent, the same scheme is applied. Eventually the error will be either resolved or maximum number of retries is reached. In that case higher layer protocols will deal with the error. ) " &)IR is similar to Chase combining but the redundant information that was not transmitted earlier is also included to improve the chances of reception without errors or with enough errors removed so as to allow combining with the previously stored packet and resolve the errors.

Fast Cell Site Selection (FCSS): When the UE moves between the cells, it is possible that it would be served by different cells. Hence the UE will construct a list of Active Set (the term Active Set is incorrect and the term that will be used eventually is "Eligible Set") Cells that it can use at any one time. The mobile will indicate on HS-DPCCH as to which one is the best cell for DL transmission. The serving cell then decides the modulation and coding scheme to be used for the mobile and in addition may code multiplex multiple mobiles within that HSDPA frame. To Simplify this procedure, it is further subdivided into Intra-Node B FCS and Inter-Node FCS.

c

High peed Uplink Packet Access (HUPA) Introduction: High Speed Uplink Packet Access (HSUPA) is a release 6 feature in 3GPP specifications and is part of HSPA (High Speed Packet Access) family. HSUPA is more often called as the Enhanced Uplink Dedicated Channel (E-DCH) by the technically aware people. The main aim of HSUPA is to increase the uplink data transfer speed in the UMTS environment and it offers data speeds of up to 5.8 Mbps in the uplink. HSUPA achieves its high performance through more efficient uplink scheduling in the base station and faster retransmission control.

Requirements: HSUPA was designed based on the following requirements {c

{c {c {c

{c

{c {c {c

c $c c c c c c c c cc c c c c ccc& c cc ccc c c c c c c c c c c c c c c c c c c c c c c c cc cc c ccc cc%ccc c cc ºc ccc c c c cc c c%cc c c c cc c %c c %c cc c cc c c c cc cc c c c c cc c c c c c c c c c c ' c* c cc c c c c c cc c cc c c c c c c c $c c c c c c Nc c c c c c c c c c c c c c c ccccc & c cc cc c c cc cc c cc cc c c c c cc c$cc c ccc c cccc c c cc c c c c cc c c c c c c c c c c c cc ccc c c c c$cc ccc ccc c c',::c'ccc'c5 cc$cc ccc cc c cc c c cc c c cDP? c $ c c c c c c c c c c c c c c c c c (c c c c c c c c $c c c c c c c c c c c DP?c c c c c c c $cc c c cDP? cc

Abbreviations: It would be important to following abbreviations before proceeding: {c {c {c {c {c

?4 c? c4 cc $%?4 c$%Dc? c4 ccc $%D c$cD ccc $%DP c$%DcD c ccc $%DPD c$%DcD cD ccc

c {c {c {c {c {c {c {c {c {c {c {c

$% c$%Dcc?'*c ccc $%'4 c$%Dc' c4 ccc $%'N c$%Dc' cN c c cc $%º c$%Dc cº c cc ?'* cc? c' c' cc DP? cccD c?cc '4 c' c4 cc '( c' c(c cc 'N c' c cN cc 4 cc4 cc N c c cN cc

HSUPA General Features {c {c {c {c {c {c {c {c {c

c c c c5 7cc )Pc cc N c c cc c cc cº c c!c ccc 1 cc! cc c c c1 cc cc cc c?'*c ?'*cc º ccc ccc c c cc

Protocol Architecture of E-DCH

c

The following modifications to the existing nodes are needed to enhanced uplink DCH: UE: A new MAC entity (MAC-es/MAC-e) is added in the UE below MAC-d. MAC- es/MAC-e in the UE handles HARQ retransmissions, scheduling and MAC-e multiplexing, E-DCH TFC selection. ode B: A new MAC entity (MAC-e) is added in the Node B to handle HARQ retransmissions, scheduling and MAC-e demultiplexing. -R C: A new MAC entity (MAC-es) is added in the SRNC to provide in-sequence delivery

c

(reordering) and to handle combining of data from different Node Bs in case of soft handover.

HSUPA Physical Layer categories The following E-DCH UE categories are defined in the specifications: P?c c

c Maximum c c number of c c 1c c !c c c HSUPA c P?cc c codes c transmitted c c 1c P?c c

c c c c c) c cc c c c

cc !c

c P?c c

cc c

ºc

1c cc c

7!:c

%c

1 7åcc

c!cc !c

ºc

1c cc!c c c

5:!c

!::c

ccc

cåcc !c

ºc

1c cc c

5:!c

%c

ccc

ccc !c

º!c

1c cc!c c c

!1111c

56å7c

! :!ccc

c5cc !c

º!c

1c cc c

!1111c

%c

! 11ccc

ccc c

º!c

1c cc!c c c

!1111c

5!1c

5 7ccc

New Channels Dedicated transport channel E-DCH - Enhanced Dedicated Channel: The Enhanced Dedicated Channel (E-DCH) is an uplink transport channel.

Uplink Dedicated Physical channels E-DPCCH and E-DPDCH:

c

c

The E-DPDCH is used to carry the E-DCH transport channel. There may be zero, one, or several E-DPDCH on each radio link. The E-DPCCH is a physical channel used to transmit control information associated with the E-DCH. There is at most one E-DPCCH on each radio link. E-DPDCH and E-DPCCH are always transmitted simultaneously, except for the case that EDPDCH but not E-DPCCH is DTXed due to power scaling. E-DPCCH shall not be transmitted in a slot unless DPCCH is also transmitted in the same slot. Figure above shows the E-DPDCH and E-DPCCH (sub)frame structure. Each radio frame is divided in 5 sub frames, each of length 2 ms; the first sub frame starts at the start of each radio frame and the 5th sub frame ends at the end of each radio frame. The E-DPDCH slot formats, corresponding rates and number of bits are specified in Table A. The E-DPCCH slot format is listed in Table B. Table A: E-DPDCH slot formats ! & $ Ô ' ! Ô(! Ô( Ô( " 1c

5c

!5c 51c

å1c

1c

c

å1c

!6c å11c

1c

!1c

!c

1c

c 11c

!1c

1c

åc

!1c

å!c !11c

!1c

61c

c

!1c

c !11c

61c

1c

5c

61c

6c

611c

:1c

å!1c

c

:1c

c

:11c

:!1c

1c

c 7c

:!1c

!c

:!11c

å61c

!61c

Table B: E-DPCCH slot formats ! & $ Ô ' ! Ô(! Ô( Ô( " 1c

5c

!5c 51c

å1c

1c

Downlink Dedicated Physical channels E-DCH Relative rant Channel (E-RCH):

c

The E-DCH Relative Grant Channel (E-RGCH) is a fixed rate (SF=128) dedicated downlink physical channel carrying the uplink E-DCH relative grants. Figure above illustrates the structure of the E-RGCH. A relative grant is transmitted using 3, 12 or 15 consecutive slots and in each slot a sequence of 40 ternary values is transmitted. The 3 and 12 slot duration shall be used on an E-RGCH transmitted to UEs for which the cell transmitting the E-RGCH is in the E-DCH serving radio link set and for which the E-DCH TTI is respectively 2 and 10 ms. The 15 slot duration shall be used on an E-RGCH transmitted to UEs for which the cell transmitting the ERGCH is not in the E-DCH serving radio link set. E-DCH Hbrid ARQ Àndicator Channel (E-HÀCH): The E-DCH Hybrid ARQ Indicator Channel (E-HICH) is a fixed rate (SF=128) dedicated downlink physical channel carrying the uplink E-DCH hybrid ARQ acknowledgement indicator. Figure above (same as E-RGCH) illustrates the structure of the E-HICH. A hybrid ARQ acknowledgement indicator is transmitted using 3 or 12 consecutive slots and in each slot a sequence of 40 binary values is transmitted. The 3 and 12 slot duration shall be used for UEs which E-DCH TTI is set to respectively 2 ms and 10 ms. ractional Dedicated Phsical Channel (-DPCH):

c

c

The F-DPCH carries control information generated at layer 1 (TPC commands). It is a special case of downlink DPCCH. Figure above shows the frame structure of the F-DPCH. Each frame of length 10ms is split into 15 slots, each of length Tslot = 2560 chips, corresponding to one power-control period. There are 2 bits/slot.

Common downlink physical channels E-DCH Absolute rant Channel (E-ACH):

c

The E-DCH Absolute Grant Channel (E-AGCH) is a fixed rate (30 kbps, SF=256) downlink physical channel carrying the uplink E-DCH absolute grant. Figure above illustrates the frame and sub-frame structure of the E-AGCH. An E-DCH absolute grant shall be transmitted over one E-AGCH sub-frame or one E-AGCH frame. The transmission over one E-AGCH sub-frame and over one E-AGCH frame shall be used for UEs for which E-DCH TTI is set to respectively 2 ms and 10 ms.

HARQ protocol General Principle The HARQ protocol has the following characteristics: {c {c {c

cc c?'*cc#cc c?'*ccc c c c?&N?#cc c?'*ccc c c cc c cc c c c c c c c c c 6c c c c ! c c c c

c c c c 1 c c º c c c c %c c c c c$c cc c c c c c cc c c c! c $% Dc#cc c c c c c c c c c c c c c $c c c c

c c c c cc?%Dcc c c c c c c c cc c c c c c cc lc c $c c c c , c c c ,c c c c c?'*c c c c c?%c cc c?%D cc c P% cc cc cc$%Dc c% cc cc% ccc c c cc c #cc c c c c c c c ?%c ?'*c c c c c c c

ccc c cDc cc {c cN c)c % cc cN c)c % c cc c c c$% Dc c?'*#cc {c c c c c c c c c c c c c c cc c c c cccc #cc c c '?Nc c c $c c c c c c c c c '3c c c c c c c c '3c c c c c c c c $%ºc ' c cN c 'Ncc c c #cc c c c c c c c c %?'*c c c c c c c c N c)c cccc cc c c c c c cc

Error handling The most frequent error cases to be handled are the following: N?c c c c c ? c c $c c c c c c c c ?'*c c c c c c c c c c c $c c c ' c c c c c c#cc {c ?cc cccN? cc c$c c c c c cNècc%cc?c c c$ ccc cc c c c c$cc c'Nc c c c cc c cNèc c c c c c c ccc c c#cc {c $ cccc cc c?'*c cc c cc c c c c ?'*c c c c c c $%DPc c c c c'N. c ccc c c c?'*c cc cc c c c$c?'*c cc'Ncc c c c ºNc% cc c c c c c c c cc c c c c c c c c cc c c c c cc c D c c c c c c c c 'Nc c c c c c cc cc c c c c c cc {c

Signaling examples E-DCH Establishment with TTI Reconfiguration This scenario shows an example of E-DCH configuration. Also TTI reconfiguration is shown in the same scenario. It is assumed that in this example DCH was established before. c

c

c c 'Nc c c c c c c c c $%Dc c c $c c c c 'N?Pc

c ' c (c ' c Pc c c c c c 'N cc P cDc cD c$c$%DPc c ºccc$%Dc'(cDc$%DcºDDc cc ! c c'Nc c c$%DcN c)c c cc c cc cc c N)?Pc c ' c (c ' c Pc c c $%Dc c cc P cDc cD c$cc$%Dc'(cDc$%DcºDDc cc å c c $%Dc N c )c c c N)?Pc c ' c (c ' c ' cc P cDc c' cc$%DcºDDc c' cc c c 'Nc c c 'N?Pc c ' c (c ' c 'c c c 'N cc P cDc c' c$%DcºDDc c' cc 5 c c 'Nc c %c c c c c D c c )c c ?(?Pc c c c c c??(!c)c c cc ccD c c)c c c$%D cc c c'Nc c %c ccccD c ccc?(?Pc cc c c c??(!c)c c cc ccD c c)c c c$%D cc 7 c c'Nc cc c c'N?Pc c' c(c' c

c c

c 'N cc

c P c'Nc c c cc c c ccºN cc 6 c c'Nc c cN)?Pc c' c(c' c

c c c$%DcN c)c c c c cc P c'Nc c c cc c c ccºN cc : c c 'Nc c c c ''c c ' c )c ' c c c $ cc P c c c$%Dc cc$%'N cc 1 cc$c cc''c c' c)c' c c c c'N cc cc'Nc cc c c ccD c cc Dcc?(?Pc cc ! cc'Nc cc c c ccD c cc Dcc?(?Pc cc å cc 'Nc c c c c c c c c c c c c 'N?Pc c ' c (c ' c Pc c c c c c 'N cc P c$%DPc c cc cc'Nc c c$%DcN c)c c cc c cc cc cN)?Pc c' c(c' c c c$%Dc ccc 5 cc $%Dc N c )c c c N)?Pc c ' c (c ' c ' cc P c$%DcºDDc c' cc cc 'Nc c c 'N?Pc c ' c (c ' c 'c c c 'N cc P c$%DcºDDc c' cc 7 cc'Nc cc c c'N?Pc c' c(c' c

c c c 'N cc P c'Nc c c cc c c ccºN cc 6 cc'Nc c cN)?Pc c' c(c' c

c c c$%DcN c)c c c c cc P c'Nc c c cc c c ccºN cc : cc 'Nc c c c ''c c ' c )c ' c c c $ cc P c c c$%Dc cc$%'N cc !1 cc$c cc''c c' c)c' c c c c'N cc

c c c c c c c c c c c c

c

Multimedia Broadcast Multicast ervice À Point to multipoint services exist today which allow data from a single source entity to be transmitted to multiple endpoints. These services are expected to be used extensively over wireless networks, hence there is a need for a capability in the PLMN to efficiently them. The Multimedia Broadcast/Multicast Service (MBMS) will provide this capability for such broadcast/multicast services provided by the home environment and other VASPs. MBMS is an IP data cast (IPDC) service that can be offered via existing UMTS and GSM networks. It would be possible for the to interact with this service via an uplink channel. This feature causes this service to be more complicated as it is not as straightforward as a Unicast service like conventional digital television. MBMS is a UMTS release 6 features and according to [1] it is already very popular with operators and equipment manufacturers. It is expected that Networks would be ing MBMS by Q4, 2007 while UE's will be ing MBMS by Q2, 2008. As per [1], 30% of UE's will be ing MBMS by 2010. Release 6 was finalized in June 2005. It is important to note that MBMS is not just a technology to preserve capacity or reduce costs by providing an efficient means to reliably distribute multimedia content over 3G networks but also an opportunity for 3G network operators to deliver new and innovative revenue-generating services to their subscribers. Ñ " Ô BROADCA

MULÀCA Multicast service is a unidirectional pointBroadcast service is a unidirectional pointto-multipoint service in which data is to-multipoint service in which data is transmitted from single source to transmitted from single source to multiple Multicast group in associated Multicast UE's in the associated broadcast area area. These are push type services. The end The end has to be part of Multicast does not have to subscribe to be part of group to receive them. broadcast group No interaction possible

Interaction possible. In this case multicast s have a return channel for the interaction procedure.

They are free

They could be free or paid type.

Ô " ( To date, the following services (defined in R99 and R4) are available: 1.c A cell broadcast service (CBS) [15, 16] allowing for low bit-rate data to be transmitted to

c

all subscribers in a set of given cells over a shared broadcast channel. This service offers a message-based service 2.c An IP-Multicast service [13, 14] allowing for mobile subscribers to receive multicast traffic. This service does not allow for multiple subscribers to share radio or core network resources and as such does not offer any advantages as far as resource utilization within the PLMN and over the radio access network.

  Ñ Ô )*+ 3GPP has defined two modes of operation of MBMS {c {c

the broadcast mode the multicast mode

# The broadcast mode is a unidirectional point-to-multipoint transmission of multimedia data (e.g. text, audio, picture, video) from a single source entity to all s in a broadcast service area. The broadcast mode is intended to efficiently use radio/network resources e.g. data is transmitted over a common radio channel. Data is transmitted in the broadcast service area as defined by the network (Home environment). MBMS data transmission should adapt to different RAN capabilities or different radio resource availability, e.g. by reducing the bitrates of the MBMS data.

Figure above gives an example of how a network can be configured to broadcast a variety of high bit rate services to s within the associated broadcast service area. A broadcast service received by the UE, involves one or more successive broadcast sessions. A broadcast service might, for example, consist of a single on-going session (e.g. a media stream) or may involve several intermittent sessions over an extended period of time (e.g. messages). The difference between the CBS of R99 and Broadcast of R6 is that CBS is used for low bit rate services (messaging) while the broadcast mode enables the broadcast of multimedia services (Audio, Video etc).

c

An example of a service using the broadcast mode could be advertising or a welcome message to the network. As not all s attached to the network may wish to receive these messages then the shall be able to enable/disable the reception of these broadcast service on his UE. The broadcast mode differs from the multicast mode in that there is no specific requirement to activate or subscribe to the MBMS in broadcast mode. The broadcast mode should allow terminals to minimize their power consumption. It is expected that charging data for the end will not be generated for this mode. The reception of the traffic in the broadcast mode is not guaranteed. The receiver may be able to recognize data loss. # The multicast mode allows the unidirectional point-to-multipoint transmission of multimedia data (e.g. text, audio, picture, video) from a single source point to a multicast group in a multicast service area. The multicast mode is intended to efficiently use radio/network resources e.g. data is transmitted over a common radio channel. Data is transmitted in the multicast service area as defined by the network (Home environment). In the multicast mode there is the possibility for the network to selectively transmit to cells within the multicast service area which contain of a multicast group. MBMS data transmission should adapt to different RAN capabilities or different radio resource availability, e.g. by reducing the bitrates of the MBMS data. A multicast service received by the UE, involves one or more successive multicast sessions. A multicast service might, for example, consist of a single on-going session (e.g. a multimedia stream) or may involve several intermittent multicast sessions over an extended period of time (e.g. messages). An example of a service using the multicast mode could be a football results service for which a subscription is required. Unlike the broadcast mode, the multicast mode generally requires a subscription to the multicast subscription group and then the ing the corresponding multicast group. The subscription and group ing may be made by the PLMN operator, the or a third party on their behalf (e.g. company). Unlike the broadcast mode, it is expected that charging data for the end will be generated for this mode.

c

Reception of multicast services cannot be guaranteed over the access network. For many applications and services guaranteed data reception may be carried out by higher layer services or applications which make use of MBMS. Multicast mode should allow terminals to minimize their power consumption. The multicast mode defined in this specification should not be confused with IP Multicast (discussed above). There are similarities between these two services and such similarities may be exploited in 3GPP networks given that 3GPP multicast mode has been defined with consideration to maximizing efficiency on the radio interface and of network resources. Multicast mode shall be inter-operable with IETF IP Multicast. This could allow the best use of IP service platforms to help maximize the availability of applications and content so that current and future services can be delivered in a more resource efficient manner. Figure above shows a general high level overview of multicast mode network. c

MBM RA Requirements The following RAN requirements have been identified [7]: 1.c MBMS data transfer shall be downlink only. 2.c QoS attributes shall be the same for MBMS Multicast and Broadcast modes. 3.c During MBMS data transmission it shall be possible to receive paging messages, which also should contain some additional information, such as CLI. 4.c Simultaneous reception of MBMS and non-MBMS services shall depend upon UE capabilities. 5.c Simultaneous reception of more than one MBMS services shall depend upon UE capabilities. 6.c A notification procedure shall be used to indicate the start of MBMS data transmission. This procedure shall contain MBMS RB information. 7.c A mechanism to enable the Network to move MBMS subscribers between cells is required. 8.c MBMS UE multicast activation (ing) shall be transparent to UTRAN. 9.c A mechanism is required that enables the non-transmission of MBMS multicast mode in a cell which does not contain any MBMS UEs ed to the multicast group. 10.cReception of MBMS shall not be guaranteed at RAN level. MBMS does not individual retransmissions at the radio link layer, nor does it retransmissions based on from individual subscribers at the radio level. This does not preclude the periodic repetitions of the MBMS content based on operator or content provider scheduling or retransmissions based on at the application level. 11.cMBMS shall not prevent the capability for SRNS/SBSS relocation. 12.cA mechanism to provide UTRAN the received QoS per UE is not required as part of MBMS. 13.cUE controlled "service based" cell selection/reselection shall not be permitted. 14.cHandover and SGSN relocation shall not be affected by an active MBMS session. 15.cIn the case of UTRAN only, guaranteed 'QoS' linked to a certain initial downlink power setting is not required; however, the purpose and possibility of some reporting mechanism could be identified to measure the delivered QoS. 16.cMBMS Multicast mode transmissions should use dedicated resources (p-t-p) or common

c

resources (p-t-m). The selection of the connection type (p-t-p or p-t-m) is operator dependent, typically based on downlink radio resource environment such as radio resource efficiency. A "threshold" related to the number of s may be utilized, resulting in the need for a mechanism to identify the number of subscribers in a given "area". 17.cMBMS solutions to be adopted should minimize the impact on the RAN physical layer and maximize reuse of existing physical layer and other RAN functionality. 18.cMBMS charging should be transparent to the RAN. 19.cMBMS should allow for low UE power consumption. 20.cHeader compression should be used. 21.cMBMS should not prevent for SGSN in pool. 22.cData loss during cell change should be minimal. The following MBMS Notification Requirements have been identified: 1.c MBMS notification shall be transmitted within the MBMS service area. 2.c MBMS notification shall be sent so it could be received by all UEs with an activated MBMS service, regardless of their RRC state or the lack of an RRC connection. 3.c MBMS notification should maximize the reuse of existing channels. 4.c MBMS notification should allow terminals to minimize their power consumption, meaning that UEs with an activated MBMS service should not listen permanently, but at regular intervals to MBMS notification. 5.c Reception of MBMS notification cannot be guaranteed. 6.c UEs may receive MBMS notification and simultaneously monitor other occasions, e.g. UE dedicated paging and CBS messages. The avoidance of collisions cannot be guaranteed. If collisions occur, the UE dedicated Paging has higher priority (UE requirement).

MBM Architecture The MBMS architecture is based on the following principles: 1.c MBMS architecture shall enable the efficient usage of radio-network and core-network resources, with the main focus on the radio interface efficiency. Specifically, multiple s should be able to share common resources when receiving identical traffic. 2.c The MBMS architecture shall common features for MBMS multicast and broadcast modes, e.g. both modes shall preferably use the same low-layer bearer for data transport over the radio interface. 3.c The MBMS architecture does not describe the means by which the BM-SC obtains the service data. The data source may be external or internal to the PLMN e.g. content servers in the fixed IP network, any UE attached to the PLMNMBMS shall both IP multicast and IP uncast sources. 4.c MBMS architecture should re-use, to the extent possible, existing 3GPP network components and protocol elements thus minimizing necessary changes to existing infrastructure and providing a solution based on well-known concepts. 5.c MBMS shall be a point-to-multipoint bearer service for IP packets in the PS domain. 6.c MBMS shall be interoperable with IETF IP Multicast. 7.c MBMS shall IETF IP Multicast addressing. 8.c It shall be possible for UEs to receive MBMS when the terminal is attached.

c

9.c It shall be possible for UEs to receive MBMS data in parallel to other services and signaling (e.g. paging, voice call). 10.cMBMS shall different quality of service levels. The mechanisms for this are for further study, one example is repetitions to all s. 11.cMBMS service areas shall be defined per individual service with a per cell granularity. 12.cMBMS is not ed in the CS domain. 13.cWhen the UE is already receiving data of an MBMS service, it shall be possible for the UE to be notified about a forthcoming and potentially about an ongoing data transfer from other MBMS services. 14.cCharging data shall be provided per subscriber for MBMS multicast mode . 15.cThe MBMS bearer service concept should contain the decision making process for selection of point-to-point or point-to-multipoint configurations. 16.cThe architecture should be able to provide home MBMS multicast services to s when roaming outside their home network as subject to inter-operator agreements. 17.cMBMS should be designed to minimize power consumption within the mobile station. 18.cApplications shall be tolerant to packet loss and duplication caused by e.g. UE mobility or transmission loss. 19.cThe backwards compatibility of the MBMS service to the R99 IP multicast delivery mechanism shall be considered. Interworking possibilities between MBMS capable network elements and non-MBMS capable network elements (e.g. interworking with R99 IP Multicast service GGSNs) shall be described. 20.cThe MBMS standard should avoid placing excessive signaling load requirements on the network. In particular, the MBMS standard should permit operators to configure their networks so that when a UE, which is not actually receiving a media stream, changes between GSM and UMTS cells in the same Routing Area, there is no significant signaling traffic load on the network. #

MBMS Architecture is as shown above. The dotted lines means functions / reference points that

c

are optional. Gp applies only when SGSN and GGSN are in different PLMN. SGSN: In the MBMS architecture the SGSN performs individual service control functions and the SGSN concentrates all individual s of the same MBMS service into a single MBMS service. The SGSN maintains a single connection with the source of the MBMS data. GGSN: The GGSN terminates the MBMS GTP tunnels from the SGSN and links these tunnels via IP multicast with the MBMS data source. BM-SC: The BM-SC is an MBMS data source. MBMS data may be scheduled in the BM-SC, e.g. for transmission to the every hour. It offers interfaces over that content provider can request data delivery to s. The BM-SC may authorize and charge content provider. MBMS Data Sources: The architecture allows for other MBMS broadcast/multicast data sources. Internal data sources may directly provide their data. Data delivery by external sources is controlled by Border Gateways (BG) which may allow for example data from single addresses and ports to into the PLMN for delivery by an MBMS service. Optional Network Elements: The SGSN may use CAMEL to handle pre-paid services, e.g. credit checking for on-line charging. {c The Cell Broadcast Centre (CBC) may be used to announce MBMS services to the s. How this is accomplished is FFS. {c The BM-SC might use OSA-SCS to interact with third parties. {c

MBM Channel tructure There exists two transmission modes to provide the MBMS service: {c {c

Point-to-point transmission (p-t-p/PTP) Point-to-multipoint transmission (p-t-m/PTM)

Figure above [17] shows an example scenario where one cell uses p-t-m while an other cell has only one s UE which is kept in p-t-p state. From the MBMS operation point of view,

c

procedures are obviously simpler if the content is always provided in a point-to-multipoint manner without shifting s back and forth between different states. Point-to-Point ransmission Point-to-point transmission is used to transfer MBMS specific control/ plane information as well as dedicated control/ plane information between the network and one UE in RRC Connected Mode. It is used only for the multicast mode of MBMS. For a UE in CELL_FACH and Cell_DCH, DCCH or DTCH is used, allowing all existing mappings to transport channels. Point-to-multipoint ransmission Point-to-multipoint transmission is used to transfer MBMS specific control/ plane information between the network and several UEs in RRC Connected or Idle Mode. It is used for broadcast or multicast mode of MBMS. Logical Channels # ' ' &: This logical channel is used for a p-t-m downlink transmission of control plane information between network and UEs in RRC Connected or Idle Mode. The control plane information on MCCH is MBMS specific and is sent to UEs in a cell with an activated (ed) MBMS service. MCCH can be sent in S-CCH carrying the DCCH of the UEs in CELL_FACH state, or in standalone S-CCH, or in same S-CCH with MTCH. The MCCH is always mapped to one specific FACH in the S-CCH as indicated on the BCCH. If MCCH is the only logical channel mapped in to the FACH, the absence of the TCTF field is explicitly signaled otherwise the TCTF field is used in MAC header to identify MCCH logical channel type. In case of soft combining, the MCCH is mapped to a different S-CCH (CCTrCH in TDD) than MTCH. Reception of paging has priority over reception of MCCH for Idle mode and URA/CELL_PCH UEs. # ' ' &: This logical channel is used for a p-t-m downlink transmission of plane information between network and UEs in RRC Connected or Idle Mode. The plane information on MTCH is MBMS Service specific and is sent to UEs in a cell with an activated MBMS service. The MTCH is always mapped to one specific FACH in the S-CCH as indicated on the MCCH. The TCTF field is always used in MAC header to identify MTCH logical channel type. # ' ' # &# This logical channel is used for a p-t-m downlink transmission of MBMS service transmission schedule between network and UEs in RRC Connected or Idle Mode. The control plane information on MSCH is MBMS service and S-CCH specific and is sent to UEs in a cell receiving MTCH. One MSCH is sent in each S-CCH carrying the MTCH. The MSCH is always mapped to one specific FACH in the S-CCH as indicated on the MCCH. Due to different error requirements the MSCH is mapped to a different FACH than MTCH. If MSCH is the only logical channel mapped in to the FACH, the absence of the TCTF field is explicitly signaled otherwise the TCTF field is used in MAC header to identify MSCH logical channel

c

type. ransport Channel FACH is used as a transport channel for MTCH, MSCH and MCCH. Phsical Channel SCCH is used as a physical channel for FACH carrying MTCH or MCCH or MSCH. Mapping beteen channels Only in downlink, the following connections between logical channels and transport channels exist: {c {c {c

MCCH can be mapped to FACH MTCH can be mapped to FACH MSCH can be mapped to FACH

The mappings as seen from the UE and UTRAN sides are shown in Figure a and Figure b below respectively [6]:

Figure a: Logical channels mapped onto transport channel, seen from the UE side

Figure b: Logical channels mapped onto transport channel, seen from the UTRAN side

Data los through Laer D

c

! $  : For MCCH, the RLC mode to be employed is UM-RLC, with required enhancements to out of sequence SDU delivery. A MAC header is used for logical channel type identification. ! $   For MTCH, the RLC mode to be employed is UM-RLC, with required enhancements to selective combining. Quick repeat may be used in RLC-UM. A MAC header is used for logical channel type identification and MBMS service identification. ! $ # : For MSCH, the RLC mode to be employed is UM-RLC. A MAC header is used for logical channel type identification. MBM otification Àndicator Channel MBMS notification utilizes a new MBMS specific PICH called the MBMS Notification Indicator Channel (MICH) in each cell. c
