Chapter 5 Grounding for the Control of EMI There are two primary reasons for grounding devices, cables, equipments, and systems. The first reason is to prevent shock and fire hazards in the event that an equipment frame or housing develops a high voltage due to lightning or an accidental breakdown of wiring or components. The second reason is to reduce EMI effects resulting from electromagnetic fields, common impedance, or other forms of interference coupling. Historically, grounding requirements arose from the need to provide protection from electrical faults, lightning, and industrially generated static electricity. Because most power-fault and lightning control relies on a low-impedance path to earth, all major components of an electrical power generation and transmission system were earth grounded to provide the required low-impedance path. As a result, strong emphasis was placed on earth grounding of electrical equipment, and the overall philosophy was “ground, ground, ground” without regard to other problems, such as EMI, that may be created by this approach. When electronic equipments were introduced, grounding problems became evident. These problems resulted from the fact that the circuit and equipment grounds often provided the mechanism for undesired EMI coupling. Also, with electronic systems, the ground may simultaneously perform two or more functions, and these multiple functions may be in conflict either in of operational requirements or in of implementation techniques. For example, as illustrated in Fig. 5.1, the ground network for an electronic equipment may be used as a signal return, provide safety, provide EMI control, and also perform as part of an antenna system. Therefore, in order to avoid creating EMI problems, it is essential to recognize that an effective grounding system, like any other portion of 81
Duff.book Page 82 Friday, January 28, 2011 2:18 PM
82
GROUNDING FOR THE CONTROL OF EMI Electronic Enclosure
Sig. In Signal Ground, Signal Return, dc Common
Sig. Out
Signal Ground, Cabinet Ground, Safety Ground, etc. Building Ground, Power Ground, Safety Ground, etc. Antenna Ground, Building Ground, Lightning Ground etc.
Figure 5.1 The multiple functions of grounds.
an equipment or system, must be carefully designed and implemented. Grounding is a system problem and in order for a grounding arrangement to perform well it must be well conceived and accurately designed and implemented. The grounding configurations must be weighed with regard to dimensions and frequency, just like any functional circuit. The objective of this chapter is to help engineers, designers, and technicians to optimize the functionality and reliability of their equipment by providing an orderly systems approach to grounding. Such an approach is highly preferable to the empirical and sometimes contradictory approaches that are often employed.
5.1 Definitions The term ground is one of the most abused words in the electronic engineering vocabulary. In addition, several other words are often used in conjunction with the term ground, and these words are also often misused. For the purpose of this chapter, it is important to carefully define these . The definitions that follow are given in of the noun rather than the verb. Ground: Any reference conductor that is used for a common return. Earth: The soil into which a safety conductor (rod, grid, plate) is driven or buried to provide a low-impedance sink for fault and lightning currents.
Duff.book Page 83 Friday, January 28, 2011 2:18 PM
CHARACTERISTICS OF GROUNDING SYSTEMS
83
Reference: Some object whose potential (often 0 V with respect to earth or a power supply) is the one to which analog and logic circuits, equipments, and systems can be related or benchmarked. Return: The low (reference) voltage side of a wire pair (e.g., neutral), outer jacket of a coax or conductor providing a path for intentional current to get back to the source. Bond: The process used to two metal surfaces via a low-impedance path. Connection: A mechanical t between two electrical conductors, often including an intermediary conductor such as a jumper, pigtail, or shield braid. Figure 5.2 illustrates the reason that the term ground can be a misleading, ambiguous term if one does not consider its electrical parameters. Referring to Fig. 5.2, it is apparent that significant voltages may exist between two different points on the “ground” associated with a platform, facility, or rack. This potential difference is a major cause for EMI problems resulting from grounding of circuits, equipments, or systems.
5.2 Characteristics of Grounding Systems Ideally, a ground system should provide a zero-impedance path to all signals for which it serves as a reference. If this were the situation, signal currents from different circuits or equipments that are connected to the ground could return to their respective sources without creating unwanted coupling between the circuits or equipments. Many interference problems occur because designers treat the ground as ideal and fail to give proper attention to the actual characteristics of the grounding system. One of the primary reasons that designers treat the ground system as ideal is that this assumption is often valid from the standpoint of the circuit or equipment design parameters (i.e., the impedance at power or signal frequencies is small and has little or no impact on circuit or equipment performance). However, the non-ideal properties of the ground must be recognized if EMI problems are to be avoided.
5.2.1
Impedance Characteristics
Every element (conductor) of a grounding system, whether it be for power grounding, signal grounding, or lightning protection, has properties of resistance, capacitance, and inductance. Shields and drain wires
Duff.book Page 84 Friday, January 28, 2011 2:18 PM
84
GROUNDING FOR THE CONTROL OF EMI “Ground” Means any Reference Conductor that is Used for a Common Return Earthing is only a particular case of grounding.
0V Ref. 100 V 50 V 30 V 17 V 10 V 80 V On an aircraft, 10 to 100 V differences may exist between structural points.
10 V
In a building, levels of several kilovolts develop on grounds when lightning creates earth gradients.
10 V
Ground?
In vehicles, differences of several volts develop between points on the steel body.
What For? Where? How? Is this “ground” really equipotential?
In a ship, levels of several hundred volts exist between decks, superstructures and rigging.
In racks, several hundred millivolts can develop between different drawers.
Figure 5.2 Ground can be a misleading, ambiguous term if one does not consider its electrical parameters.
of signal cables, the green wire power safety ground, lightning down conductors, transformer vault buses, structural steel —all conductors have these properties. The resistance property is exhibited by all metals. The resistance of a ground path conductor is a function of the material, its length, and its cross-sectional area. The capacitance associated with a ground conductor is determined by its geometric
Duff.book Page 85 Friday, January 28, 2011 2:18 PM
CHARACTERISTICS OF GROUNDING SYSTEMS
85
shape, its proximity to other conductors, and the nature of the intervening dielectric. The inductance is a function of its size, geometry, length, and, to a limited extent, the relative permeability of the metal. The impedance of the grounding system is a function of the resistance, inductance, capacitance, and frequency. Because the inductance properties of a conductor decrease with width and increase with length, it is frequently recommended that a length-to-width ratio of 5:1 be used for grounding straps. This 5:1 length-to-width ratio provides a reactance that is approximately 45 percent of that of a straight circular wire. The impedance of straight circular wires is provided as a function of frequency in Table 5.1 for several wire gauges and lengths. Typical ground plane impedances are provided in Table 5.2 for comparison. Note that for typical length wires, ground plane impedances are several orders of magnitude less than those of a circular wire. Also note that the impedance of both circular wires and ground planes increase with increasing frequency and become quite significant at higher frequencies. A commonly encountered situation is that of a ground cable (power or signal) running along in the proximity of a ground plane. This situation is illustrated in Fig. 5.3 for equipment grounding. Figure 5.4 illustrates a representative circuit of this simple ground path. The effects of the resistive elements of the circuit will predominate at very low frequencies. The relative influence of the reactive elements will increase at increasing frequencies. At some frequency, the magnitude of the inductive reactance (jωL) equals the magnitude of the capacitive reactance (1/jωC), and the circuit becomes resonant. The frequency of the primary (or first) resonance can be determined from: 1 f = ------------------2π LC
(5.1)
where L is the total cable inductance, and C is the net capacitance between the cable and the ground plane. At resonance, the impedance presented by the grounding path will either be high or low, depending on whether it is parallel or series resonant, respectively. At parallel resonance, the impedance seen looking into one end of the cable will be much higher than expected from R + jωL. (For good conductors, e.g., copper and aluminum, R « ωL; thus, jωL generally provides an accurate estimate of the impedance of a ground conductor at frequencies above a few hundred hertz). At parallel resonance: Zp = QωL
(5.2)
Duff.book Page 86 Friday, January 28, 2011 2:18 PM
86
GROUNDING FOR THE CONTROL OF EMI Table 5.1
Impedance of Straight Circular Copper Wires
AWG# = 2 , D = 6.54mm Freq.
l = 1cm l = 10cm
AWG# = 10, D = 2.59mm
l = 1m
l = 10m
l = 1cm
AWG# = 22, D = .64mm
l = 10cm
l = 1m
l = 10m
l = 1cm
l = 10cm
l = 1m
32.8m 32.8m 32.9m 33.2m 33.7m
529µ 529µ 529µ 530µ 530µ
5.29m 5.29m 5.30m 5.30m 5.30m
52.9m 53.0m 53.0m 53.0m 53.0m
529m 530m 530m 530m 530m
l = 10m
10Hz 20Hz 30Hz 50Hz 70Hz
5.13µ 5.14µ 5.15µ 5.20µ 5.27µ
51.4µ 52.0µ 52.8µ 55.5µ 59.3µ
517µ 532µ 555µ 624µ 715µ
5.22m 5.50m 5.94m 7.16m 8.68m
32.7µ 32.7µ 32.8µ 32.8µ 32.8µ
327µ 328µ 328µ 329µ 330µ
3.28m 3.28m 3.28m 3.30m 3.33m
100Hz 200Hz 300Hz 500Hz 700Hz
5.41µ 6.20µ 7.32µ 10.1µ 13.2µ
66.7µ 99.5µ 137µ 219µ 303µ
877µ 1.51m 2.19m 3.59m 5.01m
11.2m 20.6m 30.4m 50.3m 70.2m
32.9µ 33.2µ 33.7µ 35.3µ 37.7µ
332µ 345µ 365µ 425µ 500µ
3.38m 3.67m 4.11m 5.28m 6.66m
34.6m 39.6m 46.9m 64.8m 84.8m
530µ 530µ 530µ 530µ 530µ
5.30m 5.30m 5.30m 5.31m 5.32m
53.0m 53.0m 53.0m 53.2m 53.4m
530m 530m 531m 533m 537m
1kHz 2kHz 3kHz 5kHz 7kHz
18.1µ 429µ 35.2µ 855µ 52.5µ 1.28m 87.3µ 2.13m 122µ 2.98m
7.14m 14.2m 21.3m 35.6m 49.8m
100m 200m 300m 500m 700m
42.2µ 62.5µ 86.3µ 137µ 189µ
632µ 1.13m 1.65m 2.72m 3.79m
8.91m 16.8m 25.0m 41.5m 58.1m
116m 225m 336m 559m 783m
531µ 536µ 545µ 571µ 609µ
5.34m 5.48m 5.71m 6.39m 7.28m
53.9m 56.6m 60.9m 72.9m 87.9m
545m 589m 656m 835m 1.04Ω
10kHz 20kHz 30kHz 50kHz 70kHz
174µ 348µ 523µ 871µ 1.22m
4.26m 8.53m 12.8m 21.3m 29.8m
71.2m 142m 213m 356m 498m
1.00Ω 2.00Ω 3.00Ω 5.00Ω 7.00Ω
268µ 533µ 799µ 1.33m 1.86m
5.41m 10.8m 16.2m 27.0m 37.8m
82.9m 165m 248m 414m 580m
1.11Ω 2.23Ω 3.35Ω 5.58Ω 7.82Ω
681µ 1.00m 1.39m 2.20m 3.04m
8.89m 15.2m 22.0m 36.1m 50.2m
113m 207m 305m 504m 704m
1.39Ω 2.63Ω 3.91Ω 6.48Ω 9.06Ω
100kHz 200kHz 300kHz 500kHz 700kHz
1.74m 42.6m 3.48m 85.3m 5.23m 128m 8.71m 213m 12.2m 298m
712m 1.42Ω 2.13Ω 3.56Ω 4.98Ω
10.0Ω 20.0Ω 30.0Ω 50.0Ω 70.0Ω
2.66m 5.32m 7.98m 13.3m 18.6m
54.0m 108m 162m 270m 378m
828m 1.65Ω 2.48Ω 4.14Ω 5.80Ω
11.1Ω 22.3Ω 33.5Ω 55.8Ω 78.2Ω
4.31m 8.59m 12.8m 21.4m 30.0m
71.6m 142m 214m 357m 500m
1.00Ω 2.00Ω 3.01Ω 5.01Ω 7.02Ω
12.9Ω 25.8Ω 38.7Ω 64.6Ω 90.4Ω
1MHz 2MHz 3MHz 5MHz 7MHz
17.4m 426m 34.8m 853m 52.3m 1.28Ω 87.1m 2.13Ω 122m 2.98Ω
7.12Ω 14.2Ω 21.3Ω 35.6Ω 49.8Ω
100Ω 200Ω 300Ω 500Ω 700Ω
26.6m 53.2m 79.8m 133m 186m
540m 1.08Ω 1.62Ω 2.70Ω 3.78Ω
8.28Ω 16.5Ω 24.8Ω 41.4Ω 58.0Ω
111Ω 223Ω 335Ω 558Ω 782Ω
42.8m 85.7m 128m 214m 300m
714m 1.42Ω 2.14Ω 3.57Ω 5.00Ω
10.0Ω 20.0Ω 30.1Ω 50.1Ω 70.2Ω
129Ω 258Ω 387Ω 646Ω 904Ω
10MHz 20MHz 30MHz 50MHz 70MHz
174m 348m 523m 871m 1.22Ω
4.26Ω 8.53Ω 12.8Ω 21.3Ω 29.8Ω
71.2Ω 142Ω 213Ω 356Ω 498Ω
1.00kΩ 2.00kΩ 3.00kΩ 5.00kΩ 7.00kΩ
266m 532m 798m 1.33Ω 1.86Ω
5.40Ω 10.8Ω 16.2Ω 27.0Ω 37.8Ω
82.8Ω 165Ω 248Ω 414Ω 580Ω
1.11kΩ 2.23kΩ 3.35kΩ 5.58kΩ 7.82kΩ
428m 857m 1.28Ω 2.14Ω 3.00Ω
7.14Ω 14.2Ω 21.4Ω 35.7Ω 50.0Ω
100Ω 200Ω 301Ω 501Ω 702Ω
1.29kΩ 2.58kΩ 3.87kΩ 6.46kΩ 9.04kΩ
100MHz 200MHz 300MHz 500MHz 700MHz 1GHz
1.74Ω 42.6Ω 3.48Ω 85.3Ω 5.23Ω 128Ω 8.71Ω 213Ω 12.2Ω 298Ω 17.4Ω 426Ω
712Ω 1.42kΩ 2.13kΩ 3.56kΩ 4.98kΩ 7.12kΩ
10.0kΩ 20.0kΩ 30.0kΩ 50.0kΩ 70.0kΩ
2.66Ω 5.32Ω 7.98Ω 13.3Ω 18.6Ω 26.6Ω
54.0Ω 108Ω 162Ω 270Ω 378Ω 540Ω
828Ω 1.65kΩ 2.48kΩ 4.14kΩ 5.80kΩ 8.28kΩ
11.1kΩ 22.3kΩ 33.5kΩ 55.8kΩ 78.2kΩ
4.28Ω 8.57Ω 12.8Ω 21.4Ω 30.0Ω 42.8Ω
71.4Ω 142Ω 214Ω 357Ω 500Ω 714Ω
1.00kΩ 2.00kΩ 3.01kΩ 5.01kΩ 7.02kΩ 10.0kΩ
12.9kΩ 25.8kΩ 38.7kΩ 64.6kΩ 90.4kΩ
*AWG = American Wire Gage D = wire diameter in mm l = wire length in cm or m µ = microhms m = milliohms Ω = ohms
Non-Valid Region for which l ≥ λ/4
where Q, the quality factor, is defined as: ωL Q = -----------R ( ac )
(5.3)
where R(ac) is the cable resistance at the frequency of resonance. Then:
Duff.book Page 87 Friday, January 28, 2011 2:18 PM
CHARACTERISTICS OF GROUNDING SYSTEMS Table 5.2
Metal Ground Plane Impedance in Ohms/Square COPPER, COND-1, PERM-1
Freq.
87
t = .03
t = .1
t = .3
t=1
STEEL, COND-17, PERM-200 t = .1
t = .3
t=1
10Hz 20Hz 30Hz 50Hz 70Hz
574µ 574µ 574µ 574µ 574µ
172µ 172µ 172µ 172µ 172µ
57.4µ 57.4µ 57.4µ 57.4µ 57.4µ
17.2µ 17.2µ 17.2µ 17.2µ 17.2µ
5.74µ 5.75µ 5.75µ 5.76µ 5.78µ
1.75µ 1.83µ 1.95µ 2.30µ 2.71µ
3.38m 3.38m 3.38m 3.38m 3.38m
1.01m 1.01m 1.01m 1.01m 1.01m
338µ 338µ 338µ 338µ 338µ
101µ 102µ 103µ 106µ 110µ
38.5µ 49.5µ 62.3µ 86.2µ 105µ
40.3µ 56.6µ 69.3µ 89.6µ 106µ
100Hz 200Hz 300Hz 500Hz 700Hz
574µ 574µ 574µ 574µ 574µ
172µ 172µ 172µ 172µ 172µ
57.4µ 57.4µ 57.4µ 57.4µ 57.4µ
17.2µ 17.2µ 17.2µ 17.3µ 17.3µ
5.82µ 6.04µ 6.38µ 7.36µ 8.55µ
3.35µ 5.16µ 6.43µ 8.27µ 9.77µ
3.38m 3.38m 3.38m 3.38m 3.38m
1.01m 1.01m 1.01m 1.01m 1.01m
338µ 340µ 342µ 350µ 362µ
118µ 157µ 199µ 275µ 335µ
127µ 179µ 219µ 283µ 335µ
126µ 179µ 219µ 283µ 335µ
1kHz 2kHz 3kHz 5kHz 7kHz
574µ 574µ 574µ 574µ 574µ
172µ 172µ 172µ 172µ 172µ
57.4µ 57.5µ 57.5µ 57.6µ 57.8µ
17.5µ 18.3µ 19.5µ 23.0µ 27.1µ
10.4µ 16.1µ 20.3µ 26.2µ 30.9µ
11.6µ 16.5µ 20.2µ 26.1µ 30.9µ
3.38m 3.38m 3.38m 3.38m 3.38m
1.01m 1.02m 1.03m 1.06m 1.10m
385µ 495µ 623µ 862µ 1.05m
403µ 566µ 693µ 896µ 1.06m
400µ 566µ 694µ 896µ 1.06m
400µ 566µ 694µ 896µ 1.06m
10kHz 20kHz 30kHz 50kHz 70kHz
574µ 574µ 574µ 574µ 574µ
172µ 172µ 172µ 173µ 173µ
58.2µ 60.4µ 63.8µ 73.6µ 85.5µ
33.5µ 51.6µ 64.3µ 82.7µ 97.7µ
36.9µ 52.2µ 63.9µ 82.6µ 97.7µ
36.9µ 52.2µ 63.9µ 82.6µ 97.7µ
3.38m 3.40m 3.42m 3.50m 3.62m
1.18m 1.57m 1.99m 2.75m 3.35m
1.27m 1.79m 2.19m 2.83m 3.35m
1.26m 1.79m 2.19m 2.83m 3.35m
1.26m 1.79m 2.19m 2.83m 3.35m
1.26m 1.79m 2.19m 2.83m 3.35m
100kHz 200kHz 300kHz 500kHz 700kHz
574µ 575µ 575µ 576µ 578µ
175µ 183µ 195µ 230µ 271µ
140µ 161µ 203µ 262µ 309µ
116µ 165µ 202µ 261µ 309µ
116µ 165µ 202µ 261µ 309µ
116µ 165µ 202µ 261µ 309µ
3.85m 4.95m 6.23m 8.62m 10.5m
4.03m 5.66m 6.93m 8.96m 10.6m
4.00m 5.66m 6.94m 8.96m 10.6m
4.00m 5.66m 6.94m 8.96m 10.6m
4.00m 5.66m 6.94m 8.96m 10.6m
4.00m 5.66m 6.94m 8.96m 10.6m
1MHz 2MHz 3MHz 5MHz 7MHz
582µ 604µ 638µ 736µ 855µ
335µ 516µ 643µ 827µ 977µ
369µ 522µ 639µ 826µ 977µ
369µ 522µ 639µ 826µ 977µ
369µ 522µ 639µ 826µ 977µ
369µ 522µ 639µ 826µ 977µ
12.7m 17.9m 21.9m 28.3m 33.5m
12.6m 17.9m 21.9m 28.3m 33.5m
12.6m 17.9m 21.9m 28.3m 33.5m
12.6m 17.9m 21.9m 28.3m 33.5m
12.6m 17.9m 21.9m 28.3m 33.5m
12.6m 17.9m 21.9m 28.3m 33.5m
10MHz 20MHz 30MHz 50MHz 70MHz
1.04m 1.61m 2.03m 2.62m 3.09m
1.16m 1.65m 2.02m 2.61m 3.09m
1.16m 1.65m 2.02m 2.61m 3.09m
1.16m 1.65m 2.02m 2.61m 3.09m
1.16m 1.65m 2.02m 2.61m 3.09m
1.16m 1.65m 2.02m 2.61m 3.09m
40.0m 56.6m 69.4m 89.6m 106m
40.0m 56.6m 69.4m 89.6m 106m
40.0m 56.6m 69.4m 89.6m 106m
40.0m 56.6m 69.4m 89.6m 106m
40.0m 56.6m 69.4m 89.6m 106m
40.0m 56.6m 69.4m 89.6m 106m
100MHz 200MHz 300MHz 500MHz 700MHz
3.69m 5.22m 6.39m 8.26m 9.77m
3.69m 5.22m 6.39m 8.26m 9.77m
3.69m 5.22m 6.39m 8.26m 9.77m
3.69m 5.22m 6.39m 8.26m 9.77m
3.69m 5.22m 6.39m 8.26m 9.77m
3.69m 5.22m 6.39m 8.26m 9.77m
126m 179m 219m 283m 335m
126m 179m 219m 283m 335m
126m 179m 219m 283m 335m
126m 179m 219m 283m 335m
126m 179m 219m 283m 335m
126m 179m 219m 283m 335m
1GHz 2GHz 3GHz 5GHz 7GHz 10GHz
11.6m 16.5m 20.2m 26.1m 30.9m 36.9m
11.6m 16.5m 20.2m 26.1m 30.9m 36.9m
11.6m 16.5m 20.2m 26.1m 30.9m 36.9m
11.6m 16.5m 20.2m 26.1m 30.9m 36.9m
11.6m 16.5m 20.2m 26.1m 30.9m 36.9m
11.6m 16.5m 20.2m 26.1m 30.9m 36.9m
400m 566m 694m 896m 1.06Ω 1.26Ω
400m 566m 694m 896m 1.06Ω 1.26Ω
400m 566m 694m 896m 1.06Ω 1.26Ω
400m 566m 694m 896m 1.06Ω 1.26Ω
400m 566m 694m 896m 1.06Ω 1.26Ω
400m 566m 694m 896m 1.06Ω 1.26Ω
* t is in units of mm µ = microhms m = milliohms Ω = ohms
t=3
t = 10
t = .03
t=3
t = 10
NOTE: Do not use table at frequencies in MHz above 5/lm since the separation distance in meters, lm, of two grounded equipments will exceed 0.05λ where error becomes significant.
2 2
ωL ω L Z p = QωL = ------------ ωL = ------------R ( ac ) R ( ac )
(5.4)
Duff.book Page 88 Friday, January 28, 2011 2:18 PM
88
GROUNDING FOR THE CONTROL OF EMI
Equipment Grounding Conductor Zin
Zo =
L/C
ZL = 0
Ground Plane
Figure 5.3 Idealized equipment grounding. Ground Cable
Ground Plane
Figure 5.4 Equivalent circuit of a ground cable parallel to a ground plane.
Above the primary resonance, subsequent resonances (both parallel and series) will occur between the various possible combinations of inductances and capacitances (including parasitics) in the path. Series resonances in the grounding circuit will also occur between the inductances of wire segments and one or more of the shunt capacitances. The impedance (Zs) of a series resonant path is: ωL Z s = -------Q
(5.5)
ωL R ( ac ) Z s = ---------------------- = R ( ac ) ωL
(5.6)
Therefore,
The series resonant impedance is thus determined by, and is equal to, the series ac resistance of the particular inductance and capacitance in resonance. (At the higher ordered resonances, where the resonant frequency is established by wire segments and not the total path, the series impedance of the path to ground may be less than predicted from a consideration of the entire ground conductor length). An understanding of the high-frequency behavior of a grounding conductor is simplified by viewing it as a transmission line. If the ground
Duff.book Page 89 Friday, January 28, 2011 2:18 PM
CHARACTERISTICS OF GROUNDING SYSTEMS
89
path is considered uniform along its run, the voltages and currents along the line can be described as a function of time and distance. If the resistance elements in Fig. 5.4 are small relative to the inductances and capacitances, the grounding path has a characteristic impedance, Zo, equal to L ⁄ C where L and C are the per-unit length values of inductance and capacitance. The situation illustrated in Fig. 5.3 is of particular interest in equipment grounding. The input impedance of the grounding path, i.e., the impedance to ground seen by the equipment case, is: Zin = jZ • tan βχ
(5.7)
where, β = ω LC = the phase constant for the transmission line χ = the length of the path from the box to the short where βχ is less than π/2 radians, i.e., when the electrical path length is less than a quarter wavelength (λ/4), the input impedance of the shortcircuited line is inductive with a value ranging from 0 (βχ = 0) to ∞ (βχ = π/2 radians). As βχ = increases beyond π/2 radians in value, the impedance of the grounding path cycles alternately between its open- and short-circuit values. Thus, from the vantage point of the device or component that is grounded, the impedance is analogous to that offered by a short-circuited transmission line. Where βχ = π/2, the impedance offered by the ground conductor behaves like a lossless parallel LC resonant circuit. Just below resonance, the impedance is inductive; just above resonance, it is capacitive; while at resonance, the impedance is real and quite high (infinite in the perfectly lossless case). Resonance occurs at values of χ equal to integer multiples of quarter wavelengths, such as a half wavelength, three-quarter wavelength, etc. Typical ground networks are complex circuits of Rs, Ls, and Cs with frequency-dependent properties including both parallel and series resonances. These resonances are important to the performance of a ground network. Resonance effects in a grounding path are illustrated in Fig. 5.5. The relative effectiveness of a grounding conductor as a function of frequency is directly related to its impedance behavior (Fig. 5.6). It is evident from Figs. 5.5 and 5.6 that, for maximum efficiency, ground conductor lengths should be a small portion of the wavelength at the frequency of the signal of concern. The most effective performance is obtained at frequencies well below the first resonance.
Duff.book Page 90 Friday, January 28, 2011 2:18 PM
90
GROUNDING FOR THE CONTROL OF EMI
2 2 Zp = w L R ac
log10 |Z|
Parallel Resonances, fp
Rac
jw L
Zs = R ac
R dc
Series Resonances, fs
log10 f
Figure 5.5 Typical impedance vs. frequency behavior of a grounding conductor.
200
|Z| in Ohms
150
100
50
0 0
50
100
150
200
Frequency in MHz
Figure 5.6 Photograph of the swept frequency behavior of a grounding strap.
5.2.2
Antenna Characteristics
Antenna effects are also related to circuit resonance behavior. Ground conductors will act as antennas to radiate or pick up potential interference energy, depending on their lengths relative to a wavelength, i.e.,
Duff.book Page 91 Friday, January 28, 2011 2:18 PM
GROUND-RELATED INTERFERENCE
91
their efficiency. This fact permits a wavelength-to-physical-length ratio to be derived for ground conductors. The efficiency of a conductor as an antenna is related to its radiation resistance. Radiation resistance is a direct measure of the energy radiated from the antenna. A good measure of performance for a wire is a quarter-wave monopole, which has a radiation resistance of 36.5 Ω. An antenna that transmits or receives 10 percent or less than a monopole can be considered to be inefficient. To be effective, a ground wire should be an inefficient antenna. A convenient criterion for a poor antenna, i.e., a good ground wire, is that its length be λ/10 or less. Thus, a recommended goal in the design of an effective grounding system is to maintain ground wires exposed to potentially interfering signals at lengths less than 1/10 of a wavelength of the interfering signal.
5.3 Ground-Related Interference Interference is any extraneous electrical or electromagnetic disturbance that tends to disrupt the reception of desired signals or produces undesirable responses in a circuit or system. Interference can be produced by both natural and man-made sources, either external or internal to the circuit. The correct operation of complex electronic equipment and facilities is inherently dependent upon the frequencies and amplitudes of both the signals utilized in the system and the potential interference emissions that are present. If the frequency of an undesired signal is within the operating frequency range of a circuit, the circuit may respond to the undesired signal (it may even happen out of band). The severity of the interference is a function of the amplitude and frequency of the undesired signal relative to that of the desired signal at the point of detection. Ground-related interference often involves one of two basic coupling mechanisms. The first mechanism results from the fact that the signal circuits of electronic equipments share the ground with other circuits or equipments. This mechanism is called common-ground impedance coupling. Any shared impedance can provide a mechanism for interference coupling. Figure 5.7 illustrates the mechanism by which interference is coupled between culprit and victim circuits via the common-ground impedance. In this case, the interference current, I, flowing through the common-ground impedance, Z, will produce an interfering signal voltage, Vc, in the victim circuit. It should be emphasized that the interference current flowing in the common impedance may be either a current that is related to the normal operation of the culprit circuit or an intermittent current that occurs due to abnormal events (lightning, power faults, load changes, power line transients, etc.).
Duff.book Page 92 Friday, January 28, 2011 2:18 PM
92
GROUNDING FOR THE CONTROL OF EMI I1
Rg1 Rg2
Culprit Source
Victim Receptor
I2
Finite Common Impedance in Ground V1
RL1 RL2
Vi
V2
Vc Z I1 + I2
Figure 5.7 Common-mode impedance coupling between circuits.
Even if the equipment pairs do not use the signal ground as the signal return, the signal ground can still be the cause of coupling between them. Figure 5.8 illustrates the effect of a stray current, IR, flowing in the signal ground. The current IR may be the result of the direct coupling of another equipment pair to the signal ground. It may be the result of external coupling to the signal ground, or induced in the ground by an incident field. In either case, IR produces a voltage VN in the ground impedance ZR. This voltage produces a current in the interconnecting loop, which in turn develops a voltage across ZL in Equipment B. Thus, it is evident that interference can conductively couple through the signal ground to all circuits and equipment connected across the non-zero impedance elements of that ground. Equipment A
Equipment B Z
+
ZL
VS Z
VL + VN
–
ZR Ground
– V N
+
IR
Figure 5.8 Conductive coupling of extraneous noise into equipment interconnecting cables.
Duff.book Page 93 Friday, January 28, 2011 2:18 PM
GROUND-RELATED INTERFERENCE
93
The second EMI coupling mechanism involving ground is a radiation mechanism whereby the ground loop, as shown in Fig. 5.9, acts as a receiving or transmitting antenna. For this EMI coupling mechanism, the characteristics of the ground (resistance or impedance) do not play an important role, because the induced EMI voltage (for the susceptibility case) or the emitted EMI field (for the emission case) is mainly a function of the EMI driving function (field strength, voltage, or current), the geometry and dimensions of the ground loop, and the frequency of the EMI signal. It should be noted that both the conducted and radiated EMI coupling mechanisms identified above involve a “ground loop.” However, it Electromagnetic Wave I1, I2 Represent Common Mode Currents Box #1
Box #2
Zw
I1
C ZS
Signal Reference Plane
D D´
C´
I2
Zw
Vo
eS
ZL Load Reference Plane
E
B
Vi
A
Ground Reference Plane
F
I
(a) Susceptibility Case Electromagnetic Wave
Box #1
Zw
C Zw eS
IR
Vo
ZL
E
B
D D´
C´
ZS
Signal Reference Plane
Box #2 IS
IG
A
F I
(b) Emission Case
Figure 5.9 Common-mode radiation into and from ground loops.
Load Reference Plane
Duff.book Page 94 Friday, January 28, 2011 2:18 PM
94
GROUNDING FOR THE CONTROL OF EMI
should be recognized that ground loop EMI problems can exist without a physical connection to ground. In particular, at RF frequencies, distributed capacitance to ground can create a ground loop condition even though circuits or equipments are floated with respect to ground. Also, it should be noted that, for both of the EMI coupling mechanisms involving the ground loop, the EMI currents in the signal lead and the return are flowing in the same direction. This EMI condition (where the currents in the signal lead and the return are in phase) is referred to as common-mode EMI. The EMI control techniques that will be effective for ground loop problems are those that either reduce the coupling of EMI into the ground loop or provide suppression of the common-mode EMI that is coupled into the ground loop.
5.4 Circuit, Equipment, and System Grounding In the previous section, EMI coupling mechanisms resulting from circuit, equipment, and system grounding were identified and discussed. At this point, it should be obvious that grounding is very important from the standpoint of minimizing and controlling EMI. However, grounding is one of the least understood and most significant culprits in many system-level EMI problems. The grounding scheme of a system must perform the following functions: • Analog, low-level, and low-frequency circuits must have noise-free dedicated returns. Due to the low frequencies involved, wires are generally used (more or less dictating a single-point or star ground system). • Analog high-frequency circuits {radio, video, etc.} must have lowimpedance, noise-free return circuits, generally in form of planes or coaxial cables. • Returns of logic circuits, especially high-speed logic, must have low impedances over the whole bandwidth (dictated by the fastest rise times), since power and signal returns share the same paths. • Returns of powerful loads (solenoids, motors, lamps, etc.) should be distinct from any of the above, even though they may end up in the same terminal of the power supply regulator. • Return paths to chassis of cable shields, transformer shields, filters, etc. must not interfere with functional returns. • When the electrical reference is distinct from the chassis ground, provision and accessibility must exist to connect and disconnect one from the other.
Duff.book Page 95 Friday, January 28, 2011 2:18 PM
CIRCUIT, EQUIPMENT, AND SYSTEM GROUNDING
95
• More generally, for signals that communicate within the equipment or between parts of a system, the grounding scheme must provide a common reference with minimum ground shift (unless these links are balanced, optically isolated, etc.). Minimum ground shift means that the common-mode voltage must stay below the sensitivity threshold of the most susceptible device in the link. All the above constraints can be accommodated if their functional returns and protective grounds are integrated into a grounding system hierarchy as shown in Fig. 5.10. The application of this concept is the subject of the following discussion. Modern electronic systems seldom have only one ground. To mitigate interference, such as due to common-mode impedance coupling, as many separate grounds as possible are used. Separate grounds in each subsystem for structural grounds, signal grounds, shield grounds, and primary and secondary power grounds are desirable if economically and logistically practical. These individual grounds from each subsystem are finally connected by the shortest route back to the system ground point, where they form an overall system potential reference. Low-Level, Low-Frequency Ground (mV to mV dc to a few 100 kHz)
Low-Level High-Frequency Ground. Radio Communication (mV to mV, kHz to GHz)
Digital Levels, High-Frequency Ground. (Volts, dc to 100 MHz)
Relays, etc. . . ., Signaling Grounds (5 V to 50 V dc to a few kHz)
DC Power Ground (Returns for Loads > 1 A)
Lightning, EMP Ground (Tens of kA, dc to a few tens of MHz)
AC Power Safety Ground (50 Hz/60 Hz or 400 Hz)
Figure 5.10 Grounding hierarchy.
Duff.book Page 96 Friday, January 28, 2011 2:18 PM
96
GROUNDING FOR THE CONTROL OF EMI
This method is known as a single-point ground and is illustrated in Fig. 5.11.
5.4.1
Single-Point Grounding Scheme
The single-point or star type of grounding scheme shown in the figure avoids problems of common-mode impedance coupling discussed in the previous section. The only common path is in the earth ground (for earth-based structures), but this usually consists of a substantial conductor of very-low impedance. Thus, as long as no or low ground currents flow in any low-impedance common paths, all subsystems or equipments are maintained at essentially the same reference potential. The problem of implementing the above single-point grounding scheme comes about when (1) interconnecting cables are used, especially ones having cable shields that have lengths on the order of 1/20 of a wavelength or greater, and (2) parasitic capacitance exists between subsystem or equipment housings or between subsystems and the grounds of other subsystems. This situation is illustrated in Fig. 5.12. Here, cable shields connect some of the subsystems together so that more than one grounding path from a particular subsystem to the ground point exists. Unless precautions are taken, common-impedance ground currents could flow. At high frequencies, the parasitic capacitive reactance represents low-impedance paths, and the bond inductance of a subsystem-to-ground point results in higher impedances. Thus, again, common-mode currents may flow or unequal potentials may develop between subsystems.
Subsystem (or Equipment) #1
Subsystem (or Equipment) #2
Subsystem (or Equipment) #3
System (or Subsystem) Ground Point
Earth Ground Subsystem (or Equipment) #4
Prime Power Generator
Subsystem (or Equipment) #N
Figure 5.11 Single-point or star grounding arrangement.
Duff.book Page 97 Friday, January 28, 2011 2:18 PM
CIRCUIT, EQUIPMENT, AND SYSTEM GROUNDING Interconnecting Cable Subsystem (or Equipment) #1
97
Parasitic Capacitance Subsystem (or Equipment) #2
Subsystem (or Equipment) #3
System (or Subsystem) Ground Point Parasitic Capacitance Earth Ground Subsystem (or Equipment) #4
Prime Power Generator
Subsystem (or Equipment) #N
Figure 5.12 Degeneration of single-point ground by interconnecting cables and parasitic capacitance.
5.4.2
Multipoint Grounding Scheme
Rather than have an uncontrolled situation as shown in Fig. 5.12, the other grounding alternative is multipoint grounding as illustrated in Fig. 5.13. For the example shown in Fig. 5.13, each equipment or subsystem is bonded as directly as possible to a common low-impedance Ground Plane Subsystem (or Equipment) #1
Subsystem (or Equipment) #2
Ground Lugs or Bonds on Unit Frame Grounds
Subsystem (or Equipment) #3
Interconnecting Cables
Earth Ground Subsystem (or Equipment) #4
Prime Power Generator Ground Plane
Figure 5.13 Multipoint grounding system.
Subsystem (or Equipment) #N
Duff.book Page 98 Friday, January 28, 2011 2:18 PM
98
GROUNDING FOR THE CONTROL OF EMI
ground plane to form a homogeneous, low-impedance path. Thus, common-mode currents and other EMI problems will be minimized. The ground plane then is earthed for safety purposes.
5.4.3
Selection of a Grounding Scheme
The facts are that a single-point grounding scheme operates better at low frequencies, and a multipoint ground behaves best at high frequencies. If the overall system, for example, is a network of audio equipment, with many low-level sensors and control circuits behaving as broadband transient noise sources, then the high-frequency performance is irrelevant, since no receptor responds above audio frequency. For this situation, a single-point ground would be effective. Conversely, if the overall system were a receiver complex of 30 to 1,000 MHz tuners, amplifiers, and displays, then low-level, low-frequency performance is irrelevant. Here, multipoint grounding applies, and interconnecting coaxial cables should be used. The above comparison of audio versus VHF/UHF systems makes clear the selection of the correct approach. The problem then narrows down to one of defining where low- and high-frequency crossover exists for any given subsystem or equipment. The answer here in part involves the highest significant operating frequency of low-level circuits relative to the physical distance between the farthest located equipments. The determination of the crossover frequency region involves consideration of (1) magnetic versus electric field coupling problems and (2) ground-plane impedance problems due to separation. Hybrid single and multipoint grounding systems are often the best approach for crossover region applications. When printed circuits and ICs are used, network proximity is considerably closer. Thus, multipoint grounding is more economical and practical to produce per card, wafer, or chip. Interconnection of these components through wafer risers, motherboards, etc. should use a grounding scheme following the illustrations of previous paragraphs. This will likely still represent a multipoint or hybrid grounding approach in which any single-point grounding (for hybrid grounds), if used, would be to avoid low-frequency ground current loops and/or common-mode impedance coupling. In summary, many system-level EMI problems can be avoided by paying careful attention to the grounding scheme used. Common-mode, common-ground impedance problems may be reduced by application of one or more of the following techniques.
Duff.book Page 99 Friday, January 28, 2011 2:18 PM
CIRCUIT, EQUIPMENT, AND SYSTEM GROUNDING
99
• Eliminate common impedance by using a single point ground (Fig. 5.11) if possible. This configuration is usually optimal for power frequencies and signal frequencies below 300 kHz. • Separate and isolate grounds on the basis of signal type, level, and frequency as illustrated in Fig. 5.10. • Minimize ground impedance as illustrated in Fig. 5.14 by using ground bus, ground plane, or ground grid. • Float circuits or equipments if practical from a safety standpoint as illustrated in Fig. 5.15. The effectiveness of floating circuits or equipments depends on their physical isolation from other conductors. In large facilities, it is difficult to achieve a floating system. • Use an inductor or capacitor in the ground connection to provide high- or low-frequency isolation, respectively, as illustrated in Figs. 5.16 and 5.17. Daisy Chaining (Poor)
Heavier Ground Path (Better)
Ground Plane (Better Still)
or:
Parallel Ground Wires (Better)
Ground Grid (Better Still)
Figure 5.14 Means of decreasing common-impedance coupling by decreasing ground path impedance. From the bad practice of daisy-chain (top), the improvement evolves toward a plane (left) or a grid (right).
Duff.book Page 100 Friday, January 28, 2011 2:18 PM
100
GROUNDING FOR THE CONTROL OF EMI Box 1
Box 2 Safety Bus
Z
ZL
Vo
Case Zs
Float Vi
(a) Float Equipment Enclosures Box 1
Box 2
Float Vi (b) Float Circuits and Boards
Figure 5.15 Float circuits or equipments.
Rs Vs
RL
Figure 5.16 Capacitive grounding.
• Use filters or ferrites in ground loops to limit common-mode currents or provide a common-mode voltage drop. • Use a common-mode choke as illustrated in Fig. 5.18 or a commonmode isolation transformer as illustrated in Fig. 5.19 to suppress ground-loop EMI. These devices may provide on the order of 60 dB
Duff.book Page 101 Friday, January 28, 2011 2:18 PM
CIRCUIT, EQUIPMENT, AND SYSTEM GROUNDING
101
Vs
RL
RF Choke
Figure 5.17 Inductive grounding.
Rs
Is
I’n
Vs
• •
I”n
RL
Is
In
Vn
Figure 5.18 Common-mode chokes.
A
C Victim
Primary
Secondary
B
Case
Or Green Wire
A
=
D Ordinary Isolation Transformer
Parasitic Cap
C Victim
B D en
Figure 5.19 Common-mode isolation transformer.
Duff.book Page 102 Friday, January 28, 2011 2:18 PM
102
GROUNDING FOR THE CONTROL OF EMI
of common-mode rejection at frequencies up to several hundred kilohertz. • Use optical isolators and/or fiber optics to block common-mode EMI effects as illustrated in Fig. 5.20. Optical isolators provide a high degree of common-mode rejection at frequencies up to and including the HF band (i.e., 3 to 30 MHz). Optical isolators are usually limited to digital applications (they are not applicable to low-level analog circuits). • Use balanced circuits to minimize effects of common-mode EMI in the ground loop as illustrated in Fig. 5.21. With a perfectly balanced circuit, the currents flowing in the two parts of the circuit will produce equal and opposite voltages across the load, so the resulting voltage across the load is zero. Balanced circuits can provide significant (greater than 20 dB) common-mode reduction for low-frequency conditions. However, at higher frequencies (above 30 MHz), other effects start to predominate, and the effectiveness of balanced circuits diminishes. Common-mode radiated EMI effects resulting from emissions that are radiated or picked up by a ground loop may be reduced by the application of one or more of the following techniques: • Minimize the common-mode ground loop area by routing interconnecting wires or cable close to the ground. • Reduce the common-mode ground loop currents by floating circuits or equipments; using optical isolators; or inserting common-mode filters, chokes, or isolation transformers. • Use balanced circuits or balanced drivers and receivers.
Figure 5.20 Use of optical isolation to combat common-mode impedance.
Duff.book Page 103 Friday, January 28, 2011 2:18 PM
GROUND SYSTEM CONFIGURATIONS R1
RS 2 VS
+
2
_ + _
VS 2 RS
103
Z1 Balanced Signal Source
Vo
RL
R2
2 Z2
RCM
VCM
Common-Mode Noise Source
Figure 5.21 Balanced configuration with respect to common-mode voltage.
5.5 Ground System Configurations The ground system for a collection of circuits within a system or facility can assume any one of several different configurations. Each of these configurations tends to be optimal under certain conditions and may contribute to EMI problems under other conditions. In general, the ground configurations will involve either a floating ground, a singlepoint ground, a multipoint ground, or some hybrid combination of these. A floating ground configuration is illustrated in Fig. 5.22. This type of signal ground system is electrically isolated from the ground and other conductive objects. Hence, noise currents present in the ground system will not be conductively coupled to the signal circuits. The floating ground system concept is also employed in equipment design to isolate signal returns from equipment cabinets and thus prevent unwanted currents in cabinets from coupling directly to signal circuits. Effectiveness of floating ground systems depends on their true isolation from other nearby conductors; floating ground systems must really float. In large facilities, it is often difficult to achieve and maintain an effective floating system. Such a floating system is most practical if a few circuits or a few pieces of equipment are involved and power is applied from either batteries or dc-to-dc converters.
Duff.book Page 104 Friday, January 28, 2011 2:18 PM
104
GROUNDING FOR THE CONTROL OF EMI
Figure 5.22 Floating Signal Ground.
A single-point ground for an equipment complex is illustrated in Fig. 5.23. With this configuration, the signal circuits are referenced to a single point, and this single point is then connected to the facility ground. The ideal single-point signal ground network is one in which separate ground conductors extend from one point on the facility ground to the return side of each of the numerous circuits located throughout a facility. This type of ground network requires an extremely large number of conductors and is not generally economically feasible. In lieu of the ideal, various degrees of approximation to singlepoint grounding are employed. Equipment
Signal Ground
Structure or other Grounded Objects
Figure 5.23 Single-point signal ground.
Duff.book Page 105 Friday, January 28, 2011 2:18 PM
GROUND SYSTEM CONFIGURATIONS
105
The configuration illustrated in Fig. 5.24 represents a ground bus arrangement that is often used to provide an approximation to the single-point grounding concept. The ground bus system illustrated in Fig. 5.24 assumes the form of a tree. Within each system, the individual subsystems are single-point grounded. Each of the system ground points is then connected to the tree ground bus with a single insulated conductor. The single-point ground accomplishes each of the three functions of signal circuit grounding. That is, a signal reference is established in each unit or piece of equipment, and these individual references are connected together. These, in turn, are connected to the facility ground at least at one point, which provides fault protection for the circuits and provides control over static charge buildup. An important advantage of the single-point configuration is that it helps control conductively coupled interference. As illustrated in Fig. 5.23, closed paths for noise currents in the signal ground network are avoided, and the interference currents, or voltages in the facility ground system, are not conductively coupled into the signal circuits via the signal ground network. Therefore, the single-point signal ground network minimizes the effects of any noise currents that may be flowing in the facility ground. In a large installation, a major disadvantage of a single-point ground configuration is the requirement for long conductors. In addition to
System C System A
System B Subsystem A
Grounding Bus
Subsystem B Subsystem C
Earth Ground
Figure 5.24 Single-point ground bus system using a common bus.
Duff.book Page 106 Friday, January 28, 2011 2:18 PM
106
GROUNDING FOR THE CONTROL OF EMI
being expensive, long conductors prevent realization of a satisfactory reference for higher frequencies because of large self-impedances. Furthermore, because of stray capacitance between conductors, singlepoint grounding essentially ceases to exist as the signal frequency is increased. In general, for typical equipments, systems, or facilities, single-point grounds tend to be optimum for frequencies below approximately 300 kHz. The multiple-point ground illustrated in Fig. 5.25 is the third configuration frequently used for signal ground networks. This configuration establishes many conductive paths to various electronic systems or subsystems within a facility. Within each subsystem, circuits and networks have multiple connections to this ground network. Thus, in a facility, numerous parallel paths exist between any two points in the multiplepoint ground network. Multiple-point grounding frequently simplifies circuit construction inside complex equipment. It permits equipment employing coaxial cables to be interfaced more easily, since the outer conductor of the coaxial cable does not have to be floated relative to the equipment cabinet or enclosure. However, multiple-point grounding suffers from an important disadvantage. Power currents and other high-amplitude, low-frequency currents flowing through the facility ground system can conductively couple into signal circuits to create intolerable interference in susceptible low-frequency circuits. Also, multiple ground loops are created, and this makes it more difficult to control radiated emission or susceptibility resulting from the common-mode ground loop effects. In addition,
Safety Ground
Equipment
Signal Ground
Facility Ground
Figure 5.25 Multiple-point ground configuration.
Duff.book Page 107 Friday, January 28, 2011 2:18 PM
GROUND SYSTEM CONFIGURATIONS
107
for multiple-point grounding to be effective, all ground conductors between the separate points must be less than 0.1 wavelength of the interference signal. Otherwise, common-ground impedance and groundradiated effects will become significant. In general, multiple-point grounding configurations tend to be optimum at higher frequencies (i.e., above 30 MHz). To illustrate one form of a hybrid-ground system, Fig. 5.26 shows a 19-in cabinet rack containing five separate sliding drawers. Each drawer contains a portion of the system (top to bottom): (1) RF and IF preamp circuitry for reception of microwave signals, (2) IF and video Single-Point Power Line & Gnd Return (SPPL&GR) LO BPF & RF Ampl
Ant In
PreSelector
IF Preamp
A
Video Ampl.
B
Multipoint Ground Plane
SPPL&GR
A
Mixer
IF Ampl.
Log IF Ampl.
Demodulator
Signal Ground
Power Ground
Multipoint Ground Plane
B
Sweep Circuits
CRO
Driver
Singlepoint Ground Plane Diff Ampl.
Recorders
Audio Driver
Singlepoint Ground Plane Earth Ground Distribution Block Gnd
Figure 5.26 Grounding arrangement used in cabinet racks.
Display Drawer
Duff.book Page 108 Friday, January 28, 2011 2:18 PM
108
GROUNDING FOR THE CONTROL OF EMI
signal amplifiers, (3) display drivers, displays, and control circuits, (4) low-level audio circuits and recorders for documenting sensitive multichannel, hard-line telemetry sensor outputs, and (5) secondary and regulated power supplies. The hybrid aspect results from: • The RF and IF video drawers are similar. Here, unit-level boxes or stages (interconnecting coaxial cables are grounded at both ends) are multipoint grounded to the drawer-chassis ground plane. The chassis is then grounded to the dagger pin, chassis ground bus as suggested in Fig. 5.27. The power ground to these drawers, on the other hand, is using a single-point ground from its bus in a manner identical to the audio drawer.
Insulator Low-Level RF Circuits & IF Preamp To Power Gnd To Signal Gnd
Antenna Jack
IF Amplifiers, BP Filters Demodulators, & Video Ampl Video Cables, Coax or Twisted Shielded Pair Display Drivers and Readout Circuitry
Computer Clock Input
Low-Level Audio Sensor Circuits & Display Power Raceway
Multiplex Input Sensor Jack
AC Power Mains Input Ground or Earthing Stake
Secondary & Regulated Power Supplies
Weld Ground Distribution Block
Figure 5.27 Block diagram detail of hybrid grounding arrangement.
Chassis Shelves of Rails
Signal Gnd
RF-IF Coax Cables
Duff.book Page 109 Friday, January 28, 2011 2:18 PM
EMI CONTROL DEVICES AND TECHNIQUES
109
• The chassis or signal ground and power ground busses each constitute a multipoint grounding scheme to the drawer level. The individual ground busses are single-point grounded at the bottom ground distribution block. This avoids circulating common-mode current between chassis or signal ground and power grounds, since power ground current can vary due to transient surges in certain modes of equipment operation. • Interconnecting cables between different drawer levels are run separately, and their shields, when used, are treated in the same grounding manner as at the drawer level. • The audio and display drawers shown in Fig. 5.27 use single-point grounding throughout for both their unit-level boxes (interconnecting twisted cable is grounded at one end to its unit) and power leads. Cable and unit shields are all grounded together at the common dagger pin bus. Similarly, the outgoing power leads and twisted returns are separately bonded on their dagger pin busses. To review the above scheme, the following is observed: • The audio and display drawers have ground runs of about 0.6 m and an upper frequency of operation of about 1 MHz (driver and sweep circuits). Thus, single-point grounding to the strike pins is indicated. • The RF and IF drawers process UHF and 30 MHz signals over a distance of a meter so that multipoint grounding is indicated. • The regulated power supplies furnish equipment units having transient surge demands. The longest length is about 1.5 m, and significant transient frequency components may extend up in the HF region. Here, hybrid grounding is indicated: single-point within a drawer and multipoint from the power bus to all drawers.
5.6 EMI Control Devices and Techniques The performance of some EMI control techniques or devices may be significantly influenced by grounding. In particular, cable shields; isolation transformers; EMI filters; ESD, lightning, and EMF protection techniques; and Faraday shields must be properly grounded so as to provide maximum EMI protection. A detailed discussion of specific grounding considerations associated with these EMI control techniques or devices is beyond the scope of this book. However, it is important to emphasize the importance of grounding on the performance of these techniques or devices, and details may be found in the references.
Duff.book Page 110 Friday, January 28, 2011 2:18 PM
110
GROUNDING FOR THE CONTROL OF EMI
Suggested Readings: Grounding [1] Morrison, Ralph, and W. H. Lewis, Grounding and Shielding in Facilities, Hoboken, NJ: John Wiley & Sons, 1990. [1] Morrison, Ralph, Grounding and Shielding Techniques in Instrumentation, 3rd ed., Hoboken, NJ: John Wiley & Sons, 1990. [1] Denny, Hugh W., Grounding for the Control of EMI, Gainesville, VA, Interference Control Technologies, Inc. [1] Grounding, Bonding and Shielding for Electronic Equipment and Facilities, MIL-HDBK-419.
Chapter 5 Grounding for the Control of EMI There are two primary reasons for grounding devices, cables, equipments, and systems. The first reason is to prevent shock and fire hazards in the event that an equipment frame or housing develops a high voltage due to lightning or an accidental breakdown of wiring or components. The second reason is to reduce EMI effects resulting from electromagnetic fields, common impedance, or other forms of interference coupling. Historically, grounding requirements arose from the need to provide protection from electrical faults, lightning, and industrially generated static electricity. Because most power-fault and lightning control relies on a low-impedance path to earth, all major components of an electrical power generation and transmission system were earth grounded to provide the required low-impedance path. As a result, strong emphasis was placed on earth grounding of electrical equipment, and the overall philosophy was “ground, ground, ground” without regard to other problems, such as EMI, that may be created by this approach. When electronic equipments were introduced, grounding problems became evident. These problems resulted from the fact that the circuit and equipment grounds often provided the mechanism for undesired EMI coupling. Also, with electronic systems, the ground may simultaneously perform two or more functions, and these multiple functions may be in conflict either in of operational requirements or in of implementation techniques. For example, as illustrated in Fig. 5.1, the ground network for an electronic equipment may be used as a signal return, provide safety, provide EMI control, and also perform as part of an antenna system. Therefore, in order to avoid creating EMI problems, it is essential to recognize that an effective grounding system, like any other portion of 81
Duff.book Page 82 Friday, January 28, 2011 2:18 PM
82
GROUNDING FOR THE CONTROL OF EMI Electronic Enclosure
Sig. In Signal Ground, Signal Return, dc Common
Sig. Out
Signal Ground, Cabinet Ground, Safety Ground, etc. Building Ground, Power Ground, Safety Ground, etc. Antenna Ground, Building Ground, Lightning Ground etc.
Figure 5.1 The multiple functions of grounds.
an equipment or system, must be carefully designed and implemented. Grounding is a system problem and in order for a grounding arrangement to perform well it must be well conceived and accurately designed and implemented. The grounding configurations must be weighed with regard to dimensions and frequency, just like any functional circuit. The objective of this chapter is to help engineers, designers, and technicians to optimize the functionality and reliability of their equipment by providing an orderly systems approach to grounding. Such an approach is highly preferable to the empirical and sometimes contradictory approaches that are often employed.
5.1 Definitions The term ground is one of the most abused words in the electronic engineering vocabulary. In addition, several other words are often used in conjunction with the term ground, and these words are also often misused. For the purpose of this chapter, it is important to carefully define these . The definitions that follow are given in of the noun rather than the verb. Ground: Any reference conductor that is used for a common return. Earth: The soil into which a safety conductor (rod, grid, plate) is driven or buried to provide a low-impedance sink for fault and lightning currents.
Duff.book Page 83 Friday, January 28, 2011 2:18 PM
CHARACTERISTICS OF GROUNDING SYSTEMS
83
Reference: Some object whose potential (often 0 V with respect to earth or a power supply) is the one to which analog and logic circuits, equipments, and systems can be related or benchmarked. Return: The low (reference) voltage side of a wire pair (e.g., neutral), outer jacket of a coax or conductor providing a path for intentional current to get back to the source. Bond: The process used to two metal surfaces via a low-impedance path. Connection: A mechanical t between two electrical conductors, often including an intermediary conductor such as a jumper, pigtail, or shield braid. Figure 5.2 illustrates the reason that the term ground can be a misleading, ambiguous term if one does not consider its electrical parameters. Referring to Fig. 5.2, it is apparent that significant voltages may exist between two different points on the “ground” associated with a platform, facility, or rack. This potential difference is a major cause for EMI problems resulting from grounding of circuits, equipments, or systems.
5.2 Characteristics of Grounding Systems Ideally, a ground system should provide a zero-impedance path to all signals for which it serves as a reference. If this were the situation, signal currents from different circuits or equipments that are connected to the ground could return to their respective sources without creating unwanted coupling between the circuits or equipments. Many interference problems occur because designers treat the ground as ideal and fail to give proper attention to the actual characteristics of the grounding system. One of the primary reasons that designers treat the ground system as ideal is that this assumption is often valid from the standpoint of the circuit or equipment design parameters (i.e., the impedance at power or signal frequencies is small and has little or no impact on circuit or equipment performance). However, the non-ideal properties of the ground must be recognized if EMI problems are to be avoided.
5.2.1
Impedance Characteristics
Every element (conductor) of a grounding system, whether it be for power grounding, signal grounding, or lightning protection, has properties of resistance, capacitance, and inductance. Shields and drain wires
Duff.book Page 84 Friday, January 28, 2011 2:18 PM
84
GROUNDING FOR THE CONTROL OF EMI “Ground” Means any Reference Conductor that is Used for a Common Return Earthing is only a particular case of grounding.
0V Ref. 100 V 50 V 30 V 17 V 10 V 80 V On an aircraft, 10 to 100 V differences may exist between structural points.
10 V
In a building, levels of several kilovolts develop on grounds when lightning creates earth gradients.
10 V
Ground?
In vehicles, differences of several volts develop between points on the steel body.
What For? Where? How? Is this “ground” really equipotential?
In a ship, levels of several hundred volts exist between decks, superstructures and rigging.
In racks, several hundred millivolts can develop between different drawers.
Figure 5.2 Ground can be a misleading, ambiguous term if one does not consider its electrical parameters.
of signal cables, the green wire power safety ground, lightning down conductors, transformer vault buses, structural steel —all conductors have these properties. The resistance property is exhibited by all metals. The resistance of a ground path conductor is a function of the material, its length, and its cross-sectional area. The capacitance associated with a ground conductor is determined by its geometric
Duff.book Page 85 Friday, January 28, 2011 2:18 PM
CHARACTERISTICS OF GROUNDING SYSTEMS
85
shape, its proximity to other conductors, and the nature of the intervening dielectric. The inductance is a function of its size, geometry, length, and, to a limited extent, the relative permeability of the metal. The impedance of the grounding system is a function of the resistance, inductance, capacitance, and frequency. Because the inductance properties of a conductor decrease with width and increase with length, it is frequently recommended that a length-to-width ratio of 5:1 be used for grounding straps. This 5:1 length-to-width ratio provides a reactance that is approximately 45 percent of that of a straight circular wire. The impedance of straight circular wires is provided as a function of frequency in Table 5.1 for several wire gauges and lengths. Typical ground plane impedances are provided in Table 5.2 for comparison. Note that for typical length wires, ground plane impedances are several orders of magnitude less than those of a circular wire. Also note that the impedance of both circular wires and ground planes increase with increasing frequency and become quite significant at higher frequencies. A commonly encountered situation is that of a ground cable (power or signal) running along in the proximity of a ground plane. This situation is illustrated in Fig. 5.3 for equipment grounding. Figure 5.4 illustrates a representative circuit of this simple ground path. The effects of the resistive elements of the circuit will predominate at very low frequencies. The relative influence of the reactive elements will increase at increasing frequencies. At some frequency, the magnitude of the inductive reactance (jωL) equals the magnitude of the capacitive reactance (1/jωC), and the circuit becomes resonant. The frequency of the primary (or first) resonance can be determined from: 1 f = ------------------2π LC
(5.1)
where L is the total cable inductance, and C is the net capacitance between the cable and the ground plane. At resonance, the impedance presented by the grounding path will either be high or low, depending on whether it is parallel or series resonant, respectively. At parallel resonance, the impedance seen looking into one end of the cable will be much higher than expected from R + jωL. (For good conductors, e.g., copper and aluminum, R « ωL; thus, jωL generally provides an accurate estimate of the impedance of a ground conductor at frequencies above a few hundred hertz). At parallel resonance: Zp = QωL
(5.2)
Duff.book Page 86 Friday, January 28, 2011 2:18 PM
86
GROUNDING FOR THE CONTROL OF EMI Table 5.1
Impedance of Straight Circular Copper Wires
AWG# = 2 , D = 6.54mm Freq.
l = 1cm l = 10cm
AWG# = 10, D = 2.59mm
l = 1m
l = 10m
l = 1cm
AWG# = 22, D = .64mm
l = 10cm
l = 1m
l = 10m
l = 1cm
l = 10cm
l = 1m
32.8m 32.8m 32.9m 33.2m 33.7m
529µ 529µ 529µ 530µ 530µ
5.29m 5.29m 5.30m 5.30m 5.30m
52.9m 53.0m 53.0m 53.0m 53.0m
529m 530m 530m 530m 530m
l = 10m
10Hz 20Hz 30Hz 50Hz 70Hz
5.13µ 5.14µ 5.15µ 5.20µ 5.27µ
51.4µ 52.0µ 52.8µ 55.5µ 59.3µ
517µ 532µ 555µ 624µ 715µ
5.22m 5.50m 5.94m 7.16m 8.68m
32.7µ 32.7µ 32.8µ 32.8µ 32.8µ
327µ 328µ 328µ 329µ 330µ
3.28m 3.28m 3.28m 3.30m 3.33m
100Hz 200Hz 300Hz 500Hz 700Hz
5.41µ 6.20µ 7.32µ 10.1µ 13.2µ
66.7µ 99.5µ 137µ 219µ 303µ
877µ 1.51m 2.19m 3.59m 5.01m
11.2m 20.6m 30.4m 50.3m 70.2m
32.9µ 33.2µ 33.7µ 35.3µ 37.7µ
332µ 345µ 365µ 425µ 500µ
3.38m 3.67m 4.11m 5.28m 6.66m
34.6m 39.6m 46.9m 64.8m 84.8m
530µ 530µ 530µ 530µ 530µ
5.30m 5.30m 5.30m 5.31m 5.32m
53.0m 53.0m 53.0m 53.2m 53.4m
530m 530m 531m 533m 537m
1kHz 2kHz 3kHz 5kHz 7kHz
18.1µ 429µ 35.2µ 855µ 52.5µ 1.28m 87.3µ 2.13m 122µ 2.98m
7.14m 14.2m 21.3m 35.6m 49.8m
100m 200m 300m 500m 700m
42.2µ 62.5µ 86.3µ 137µ 189µ
632µ 1.13m 1.65m 2.72m 3.79m
8.91m 16.8m 25.0m 41.5m 58.1m
116m 225m 336m 559m 783m
531µ 536µ 545µ 571µ 609µ
5.34m 5.48m 5.71m 6.39m 7.28m
53.9m 56.6m 60.9m 72.9m 87.9m
545m 589m 656m 835m 1.04Ω
10kHz 20kHz 30kHz 50kHz 70kHz
174µ 348µ 523µ 871µ 1.22m
4.26m 8.53m 12.8m 21.3m 29.8m
71.2m 142m 213m 356m 498m
1.00Ω 2.00Ω 3.00Ω 5.00Ω 7.00Ω
268µ 533µ 799µ 1.33m 1.86m
5.41m 10.8m 16.2m 27.0m 37.8m
82.9m 165m 248m 414m 580m
1.11Ω 2.23Ω 3.35Ω 5.58Ω 7.82Ω
681µ 1.00m 1.39m 2.20m 3.04m
8.89m 15.2m 22.0m 36.1m 50.2m
113m 207m 305m 504m 704m
1.39Ω 2.63Ω 3.91Ω 6.48Ω 9.06Ω
100kHz 200kHz 300kHz 500kHz 700kHz
1.74m 42.6m 3.48m 85.3m 5.23m 128m 8.71m 213m 12.2m 298m
712m 1.42Ω 2.13Ω 3.56Ω 4.98Ω
10.0Ω 20.0Ω 30.0Ω 50.0Ω 70.0Ω
2.66m 5.32m 7.98m 13.3m 18.6m
54.0m 108m 162m 270m 378m
828m 1.65Ω 2.48Ω 4.14Ω 5.80Ω
11.1Ω 22.3Ω 33.5Ω 55.8Ω 78.2Ω
4.31m 8.59m 12.8m 21.4m 30.0m
71.6m 142m 214m 357m 500m
1.00Ω 2.00Ω 3.01Ω 5.01Ω 7.02Ω
12.9Ω 25.8Ω 38.7Ω 64.6Ω 90.4Ω
1MHz 2MHz 3MHz 5MHz 7MHz
17.4m 426m 34.8m 853m 52.3m 1.28Ω 87.1m 2.13Ω 122m 2.98Ω
7.12Ω 14.2Ω 21.3Ω 35.6Ω 49.8Ω
100Ω 200Ω 300Ω 500Ω 700Ω
26.6m 53.2m 79.8m 133m 186m
540m 1.08Ω 1.62Ω 2.70Ω 3.78Ω
8.28Ω 16.5Ω 24.8Ω 41.4Ω 58.0Ω
111Ω 223Ω 335Ω 558Ω 782Ω
42.8m 85.7m 128m 214m 300m
714m 1.42Ω 2.14Ω 3.57Ω 5.00Ω
10.0Ω 20.0Ω 30.1Ω 50.1Ω 70.2Ω
129Ω 258Ω 387Ω 646Ω 904Ω
10MHz 20MHz 30MHz 50MHz 70MHz
174m 348m 523m 871m 1.22Ω
4.26Ω 8.53Ω 12.8Ω 21.3Ω 29.8Ω
71.2Ω 142Ω 213Ω 356Ω 498Ω
1.00kΩ 2.00kΩ 3.00kΩ 5.00kΩ 7.00kΩ
266m 532m 798m 1.33Ω 1.86Ω
5.40Ω 10.8Ω 16.2Ω 27.0Ω 37.8Ω
82.8Ω 165Ω 248Ω 414Ω 580Ω
1.11kΩ 2.23kΩ 3.35kΩ 5.58kΩ 7.82kΩ
428m 857m 1.28Ω 2.14Ω 3.00Ω
7.14Ω 14.2Ω 21.4Ω 35.7Ω 50.0Ω
100Ω 200Ω 301Ω 501Ω 702Ω
1.29kΩ 2.58kΩ 3.87kΩ 6.46kΩ 9.04kΩ
100MHz 200MHz 300MHz 500MHz 700MHz 1GHz
1.74Ω 42.6Ω 3.48Ω 85.3Ω 5.23Ω 128Ω 8.71Ω 213Ω 12.2Ω 298Ω 17.4Ω 426Ω
712Ω 1.42kΩ 2.13kΩ 3.56kΩ 4.98kΩ 7.12kΩ
10.0kΩ 20.0kΩ 30.0kΩ 50.0kΩ 70.0kΩ
2.66Ω 5.32Ω 7.98Ω 13.3Ω 18.6Ω 26.6Ω
54.0Ω 108Ω 162Ω 270Ω 378Ω 540Ω
828Ω 1.65kΩ 2.48kΩ 4.14kΩ 5.80kΩ 8.28kΩ
11.1kΩ 22.3kΩ 33.5kΩ 55.8kΩ 78.2kΩ
4.28Ω 8.57Ω 12.8Ω 21.4Ω 30.0Ω 42.8Ω
71.4Ω 142Ω 214Ω 357Ω 500Ω 714Ω
1.00kΩ 2.00kΩ 3.01kΩ 5.01kΩ 7.02kΩ 10.0kΩ
12.9kΩ 25.8kΩ 38.7kΩ 64.6kΩ 90.4kΩ
*AWG = American Wire Gage D = wire diameter in mm l = wire length in cm or m µ = microhms m = milliohms Ω = ohms
Non-Valid Region for which l ≥ λ/4
where Q, the quality factor, is defined as: ωL Q = -----------R ( ac )
(5.3)
where R(ac) is the cable resistance at the frequency of resonance. Then:
Duff.book Page 87 Friday, January 28, 2011 2:18 PM
CHARACTERISTICS OF GROUNDING SYSTEMS Table 5.2
Metal Ground Plane Impedance in Ohms/Square COPPER, COND-1, PERM-1
Freq.
87
t = .03
t = .1
t = .3
t=1
STEEL, COND-17, PERM-200 t = .1
t = .3
t=1
10Hz 20Hz 30Hz 50Hz 70Hz
574µ 574µ 574µ 574µ 574µ
172µ 172µ 172µ 172µ 172µ
57.4µ 57.4µ 57.4µ 57.4µ 57.4µ
17.2µ 17.2µ 17.2µ 17.2µ 17.2µ
5.74µ 5.75µ 5.75µ 5.76µ 5.78µ
1.75µ 1.83µ 1.95µ 2.30µ 2.71µ
3.38m 3.38m 3.38m 3.38m 3.38m
1.01m 1.01m 1.01m 1.01m 1.01m
338µ 338µ 338µ 338µ 338µ
101µ 102µ 103µ 106µ 110µ
38.5µ 49.5µ 62.3µ 86.2µ 105µ
40.3µ 56.6µ 69.3µ 89.6µ 106µ
100Hz 200Hz 300Hz 500Hz 700Hz
574µ 574µ 574µ 574µ 574µ
172µ 172µ 172µ 172µ 172µ
57.4µ 57.4µ 57.4µ 57.4µ 57.4µ
17.2µ 17.2µ 17.2µ 17.3µ 17.3µ
5.82µ 6.04µ 6.38µ 7.36µ 8.55µ
3.35µ 5.16µ 6.43µ 8.27µ 9.77µ
3.38m 3.38m 3.38m 3.38m 3.38m
1.01m 1.01m 1.01m 1.01m 1.01m
338µ 340µ 342µ 350µ 362µ
118µ 157µ 199µ 275µ 335µ
127µ 179µ 219µ 283µ 335µ
126µ 179µ 219µ 283µ 335µ
1kHz 2kHz 3kHz 5kHz 7kHz
574µ 574µ 574µ 574µ 574µ
172µ 172µ 172µ 172µ 172µ
57.4µ 57.5µ 57.5µ 57.6µ 57.8µ
17.5µ 18.3µ 19.5µ 23.0µ 27.1µ
10.4µ 16.1µ 20.3µ 26.2µ 30.9µ
11.6µ 16.5µ 20.2µ 26.1µ 30.9µ
3.38m 3.38m 3.38m 3.38m 3.38m
1.01m 1.02m 1.03m 1.06m 1.10m
385µ 495µ 623µ 862µ 1.05m
403µ 566µ 693µ 896µ 1.06m
400µ 566µ 694µ 896µ 1.06m
400µ 566µ 694µ 896µ 1.06m
10kHz 20kHz 30kHz 50kHz 70kHz
574µ 574µ 574µ 574µ 574µ
172µ 172µ 172µ 173µ 173µ
58.2µ 60.4µ 63.8µ 73.6µ 85.5µ
33.5µ 51.6µ 64.3µ 82.7µ 97.7µ
36.9µ 52.2µ 63.9µ 82.6µ 97.7µ
36.9µ 52.2µ 63.9µ 82.6µ 97.7µ
3.38m 3.40m 3.42m 3.50m 3.62m
1.18m 1.57m 1.99m 2.75m 3.35m
1.27m 1.79m 2.19m 2.83m 3.35m
1.26m 1.79m 2.19m 2.83m 3.35m
1.26m 1.79m 2.19m 2.83m 3.35m
1.26m 1.79m 2.19m 2.83m 3.35m
100kHz 200kHz 300kHz 500kHz 700kHz
574µ 575µ 575µ 576µ 578µ
175µ 183µ 195µ 230µ 271µ
140µ 161µ 203µ 262µ 309µ
116µ 165µ 202µ 261µ 309µ
116µ 165µ 202µ 261µ 309µ
116µ 165µ 202µ 261µ 309µ
3.85m 4.95m 6.23m 8.62m 10.5m
4.03m 5.66m 6.93m 8.96m 10.6m
4.00m 5.66m 6.94m 8.96m 10.6m
4.00m 5.66m 6.94m 8.96m 10.6m
4.00m 5.66m 6.94m 8.96m 10.6m
4.00m 5.66m 6.94m 8.96m 10.6m
1MHz 2MHz 3MHz 5MHz 7MHz
582µ 604µ 638µ 736µ 855µ
335µ 516µ 643µ 827µ 977µ
369µ 522µ 639µ 826µ 977µ
369µ 522µ 639µ 826µ 977µ
369µ 522µ 639µ 826µ 977µ
369µ 522µ 639µ 826µ 977µ
12.7m 17.9m 21.9m 28.3m 33.5m
12.6m 17.9m 21.9m 28.3m 33.5m
12.6m 17.9m 21.9m 28.3m 33.5m
12.6m 17.9m 21.9m 28.3m 33.5m
12.6m 17.9m 21.9m 28.3m 33.5m
12.6m 17.9m 21.9m 28.3m 33.5m
10MHz 20MHz 30MHz 50MHz 70MHz
1.04m 1.61m 2.03m 2.62m 3.09m
1.16m 1.65m 2.02m 2.61m 3.09m
1.16m 1.65m 2.02m 2.61m 3.09m
1.16m 1.65m 2.02m 2.61m 3.09m
1.16m 1.65m 2.02m 2.61m 3.09m
1.16m 1.65m 2.02m 2.61m 3.09m
40.0m 56.6m 69.4m 89.6m 106m
40.0m 56.6m 69.4m 89.6m 106m
40.0m 56.6m 69.4m 89.6m 106m
40.0m 56.6m 69.4m 89.6m 106m
40.0m 56.6m 69.4m 89.6m 106m
40.0m 56.6m 69.4m 89.6m 106m
100MHz 200MHz 300MHz 500MHz 700MHz
3.69m 5.22m 6.39m 8.26m 9.77m
3.69m 5.22m 6.39m 8.26m 9.77m
3.69m 5.22m 6.39m 8.26m 9.77m
3.69m 5.22m 6.39m 8.26m 9.77m
3.69m 5.22m 6.39m 8.26m 9.77m
3.69m 5.22m 6.39m 8.26m 9.77m
126m 179m 219m 283m 335m
126m 179m 219m 283m 335m
126m 179m 219m 283m 335m
126m 179m 219m 283m 335m
126m 179m 219m 283m 335m
126m 179m 219m 283m 335m
1GHz 2GHz 3GHz 5GHz 7GHz 10GHz
11.6m 16.5m 20.2m 26.1m 30.9m 36.9m
11.6m 16.5m 20.2m 26.1m 30.9m 36.9m
11.6m 16.5m 20.2m 26.1m 30.9m 36.9m
11.6m 16.5m 20.2m 26.1m 30.9m 36.9m
11.6m 16.5m 20.2m 26.1m 30.9m 36.9m
11.6m 16.5m 20.2m 26.1m 30.9m 36.9m
400m 566m 694m 896m 1.06Ω 1.26Ω
400m 566m 694m 896m 1.06Ω 1.26Ω
400m 566m 694m 896m 1.06Ω 1.26Ω
400m 566m 694m 896m 1.06Ω 1.26Ω
400m 566m 694m 896m 1.06Ω 1.26Ω
400m 566m 694m 896m 1.06Ω 1.26Ω
* t is in units of mm µ = microhms m = milliohms Ω = ohms
t=3
t = 10
t = .03
t=3
t = 10
NOTE: Do not use table at frequencies in MHz above 5/lm since the separation distance in meters, lm, of two grounded equipments will exceed 0.05λ where error becomes significant.
2 2
ωL ω L Z p = QωL = ------------ ωL = ------------R ( ac ) R ( ac )
(5.4)
Duff.book Page 88 Friday, January 28, 2011 2:18 PM
88
GROUNDING FOR THE CONTROL OF EMI
Equipment Grounding Conductor Zin
Zo =
L/C
ZL = 0
Ground Plane
Figure 5.3 Idealized equipment grounding. Ground Cable
Ground Plane
Figure 5.4 Equivalent circuit of a ground cable parallel to a ground plane.
Above the primary resonance, subsequent resonances (both parallel and series) will occur between the various possible combinations of inductances and capacitances (including parasitics) in the path. Series resonances in the grounding circuit will also occur between the inductances of wire segments and one or more of the shunt capacitances. The impedance (Zs) of a series resonant path is: ωL Z s = -------Q
(5.5)
ωL R ( ac ) Z s = ---------------------- = R ( ac ) ωL
(5.6)
Therefore,
The series resonant impedance is thus determined by, and is equal to, the series ac resistance of the particular inductance and capacitance in resonance. (At the higher ordered resonances, where the resonant frequency is established by wire segments and not the total path, the series impedance of the path to ground may be less than predicted from a consideration of the entire ground conductor length). An understanding of the high-frequency behavior of a grounding conductor is simplified by viewing it as a transmission line. If the ground
Duff.book Page 89 Friday, January 28, 2011 2:18 PM
CHARACTERISTICS OF GROUNDING SYSTEMS
89
path is considered uniform along its run, the voltages and currents along the line can be described as a function of time and distance. If the resistance elements in Fig. 5.4 are small relative to the inductances and capacitances, the grounding path has a characteristic impedance, Zo, equal to L ⁄ C where L and C are the per-unit length values of inductance and capacitance. The situation illustrated in Fig. 5.3 is of particular interest in equipment grounding. The input impedance of the grounding path, i.e., the impedance to ground seen by the equipment case, is: Zin = jZ • tan βχ
(5.7)
where, β = ω LC = the phase constant for the transmission line χ = the length of the path from the box to the short where βχ is less than π/2 radians, i.e., when the electrical path length is less than a quarter wavelength (λ/4), the input impedance of the shortcircuited line is inductive with a value ranging from 0 (βχ = 0) to ∞ (βχ = π/2 radians). As βχ = increases beyond π/2 radians in value, the impedance of the grounding path cycles alternately between its open- and short-circuit values. Thus, from the vantage point of the device or component that is grounded, the impedance is analogous to that offered by a short-circuited transmission line. Where βχ = π/2, the impedance offered by the ground conductor behaves like a lossless parallel LC resonant circuit. Just below resonance, the impedance is inductive; just above resonance, it is capacitive; while at resonance, the impedance is real and quite high (infinite in the perfectly lossless case). Resonance occurs at values of χ equal to integer multiples of quarter wavelengths, such as a half wavelength, three-quarter wavelength, etc. Typical ground networks are complex circuits of Rs, Ls, and Cs with frequency-dependent properties including both parallel and series resonances. These resonances are important to the performance of a ground network. Resonance effects in a grounding path are illustrated in Fig. 5.5. The relative effectiveness of a grounding conductor as a function of frequency is directly related to its impedance behavior (Fig. 5.6). It is evident from Figs. 5.5 and 5.6 that, for maximum efficiency, ground conductor lengths should be a small portion of the wavelength at the frequency of the signal of concern. The most effective performance is obtained at frequencies well below the first resonance.
Duff.book Page 90 Friday, January 28, 2011 2:18 PM
90
GROUNDING FOR THE CONTROL OF EMI
2 2 Zp = w L R ac
log10 |Z|
Parallel Resonances, fp
Rac
jw L
Zs = R ac
R dc
Series Resonances, fs
log10 f
Figure 5.5 Typical impedance vs. frequency behavior of a grounding conductor.
200
|Z| in Ohms
150
100
50
0 0
50
100
150
200
Frequency in MHz
Figure 5.6 Photograph of the swept frequency behavior of a grounding strap.
5.2.2
Antenna Characteristics
Antenna effects are also related to circuit resonance behavior. Ground conductors will act as antennas to radiate or pick up potential interference energy, depending on their lengths relative to a wavelength, i.e.,
Duff.book Page 91 Friday, January 28, 2011 2:18 PM
GROUND-RELATED INTERFERENCE
91
their efficiency. This fact permits a wavelength-to-physical-length ratio to be derived for ground conductors. The efficiency of a conductor as an antenna is related to its radiation resistance. Radiation resistance is a direct measure of the energy radiated from the antenna. A good measure of performance for a wire is a quarter-wave monopole, which has a radiation resistance of 36.5 Ω. An antenna that transmits or receives 10 percent or less than a monopole can be considered to be inefficient. To be effective, a ground wire should be an inefficient antenna. A convenient criterion for a poor antenna, i.e., a good ground wire, is that its length be λ/10 or less. Thus, a recommended goal in the design of an effective grounding system is to maintain ground wires exposed to potentially interfering signals at lengths less than 1/10 of a wavelength of the interfering signal.
5.3 Ground-Related Interference Interference is any extraneous electrical or electromagnetic disturbance that tends to disrupt the reception of desired signals or produces undesirable responses in a circuit or system. Interference can be produced by both natural and man-made sources, either external or internal to the circuit. The correct operation of complex electronic equipment and facilities is inherently dependent upon the frequencies and amplitudes of both the signals utilized in the system and the potential interference emissions that are present. If the frequency of an undesired signal is within the operating frequency range of a circuit, the circuit may respond to the undesired signal (it may even happen out of band). The severity of the interference is a function of the amplitude and frequency of the undesired signal relative to that of the desired signal at the point of detection. Ground-related interference often involves one of two basic coupling mechanisms. The first mechanism results from the fact that the signal circuits of electronic equipments share the ground with other circuits or equipments. This mechanism is called common-ground impedance coupling. Any shared impedance can provide a mechanism for interference coupling. Figure 5.7 illustrates the mechanism by which interference is coupled between culprit and victim circuits via the common-ground impedance. In this case, the interference current, I, flowing through the common-ground impedance, Z, will produce an interfering signal voltage, Vc, in the victim circuit. It should be emphasized that the interference current flowing in the common impedance may be either a current that is related to the normal operation of the culprit circuit or an intermittent current that occurs due to abnormal events (lightning, power faults, load changes, power line transients, etc.).
Duff.book Page 92 Friday, January 28, 2011 2:18 PM
92
GROUNDING FOR THE CONTROL OF EMI I1
Rg1 Rg2
Culprit Source
Victim Receptor
I2
Finite Common Impedance in Ground V1
RL1 RL2
Vi
V2
Vc Z I1 + I2
Figure 5.7 Common-mode impedance coupling between circuits.
Even if the equipment pairs do not use the signal ground as the signal return, the signal ground can still be the cause of coupling between them. Figure 5.8 illustrates the effect of a stray current, IR, flowing in the signal ground. The current IR may be the result of the direct coupling of another equipment pair to the signal ground. It may be the result of external coupling to the signal ground, or induced in the ground by an incident field. In either case, IR produces a voltage VN in the ground impedance ZR. This voltage produces a current in the interconnecting loop, which in turn develops a voltage across ZL in Equipment B. Thus, it is evident that interference can conductively couple through the signal ground to all circuits and equipment connected across the non-zero impedance elements of that ground. Equipment A
Equipment B Z
+
ZL
VS Z
VL + VN
–
ZR Ground
– V N
+
IR
Figure 5.8 Conductive coupling of extraneous noise into equipment interconnecting cables.
Duff.book Page 93 Friday, January 28, 2011 2:18 PM
GROUND-RELATED INTERFERENCE
93
The second EMI coupling mechanism involving ground is a radiation mechanism whereby the ground loop, as shown in Fig. 5.9, acts as a receiving or transmitting antenna. For this EMI coupling mechanism, the characteristics of the ground (resistance or impedance) do not play an important role, because the induced EMI voltage (for the susceptibility case) or the emitted EMI field (for the emission case) is mainly a function of the EMI driving function (field strength, voltage, or current), the geometry and dimensions of the ground loop, and the frequency of the EMI signal. It should be noted that both the conducted and radiated EMI coupling mechanisms identified above involve a “ground loop.” However, it Electromagnetic Wave I1, I2 Represent Common Mode Currents Box #1
Box #2
Zw
I1
C ZS
Signal Reference Plane
D D´
C´
I2
Zw
Vo
eS
ZL Load Reference Plane
E
B
Vi
A
Ground Reference Plane
F
I
(a) Susceptibility Case Electromagnetic Wave
Box #1
Zw
C Zw eS
IR
Vo
ZL
E
B
D D´
C´
ZS
Signal Reference Plane
Box #2 IS
IG
A
F I
(b) Emission Case
Figure 5.9 Common-mode radiation into and from ground loops.
Load Reference Plane
Duff.book Page 94 Friday, January 28, 2011 2:18 PM
94
GROUNDING FOR THE CONTROL OF EMI
should be recognized that ground loop EMI problems can exist without a physical connection to ground. In particular, at RF frequencies, distributed capacitance to ground can create a ground loop condition even though circuits or equipments are floated with respect to ground. Also, it should be noted that, for both of the EMI coupling mechanisms involving the ground loop, the EMI currents in the signal lead and the return are flowing in the same direction. This EMI condition (where the currents in the signal lead and the return are in phase) is referred to as common-mode EMI. The EMI control techniques that will be effective for ground loop problems are those that either reduce the coupling of EMI into the ground loop or provide suppression of the common-mode EMI that is coupled into the ground loop.
5.4 Circuit, Equipment, and System Grounding In the previous section, EMI coupling mechanisms resulting from circuit, equipment, and system grounding were identified and discussed. At this point, it should be obvious that grounding is very important from the standpoint of minimizing and controlling EMI. However, grounding is one of the least understood and most significant culprits in many system-level EMI problems. The grounding scheme of a system must perform the following functions: • Analog, low-level, and low-frequency circuits must have noise-free dedicated returns. Due to the low frequencies involved, wires are generally used (more or less dictating a single-point or star ground system). • Analog high-frequency circuits {radio, video, etc.} must have lowimpedance, noise-free return circuits, generally in form of planes or coaxial cables. • Returns of logic circuits, especially high-speed logic, must have low impedances over the whole bandwidth (dictated by the fastest rise times), since power and signal returns share the same paths. • Returns of powerful loads (solenoids, motors, lamps, etc.) should be distinct from any of the above, even though they may end up in the same terminal of the power supply regulator. • Return paths to chassis of cable shields, transformer shields, filters, etc. must not interfere with functional returns. • When the electrical reference is distinct from the chassis ground, provision and accessibility must exist to connect and disconnect one from the other.
Duff.book Page 95 Friday, January 28, 2011 2:18 PM
CIRCUIT, EQUIPMENT, AND SYSTEM GROUNDING
95
• More generally, for signals that communicate within the equipment or between parts of a system, the grounding scheme must provide a common reference with minimum ground shift (unless these links are balanced, optically isolated, etc.). Minimum ground shift means that the common-mode voltage must stay below the sensitivity threshold of the most susceptible device in the link. All the above constraints can be accommodated if their functional returns and protective grounds are integrated into a grounding system hierarchy as shown in Fig. 5.10. The application of this concept is the subject of the following discussion. Modern electronic systems seldom have only one ground. To mitigate interference, such as due to common-mode impedance coupling, as many separate grounds as possible are used. Separate grounds in each subsystem for structural grounds, signal grounds, shield grounds, and primary and secondary power grounds are desirable if economically and logistically practical. These individual grounds from each subsystem are finally connected by the shortest route back to the system ground point, where they form an overall system potential reference. Low-Level, Low-Frequency Ground (mV to mV dc to a few 100 kHz)
Low-Level High-Frequency Ground. Radio Communication (mV to mV, kHz to GHz)
Digital Levels, High-Frequency Ground. (Volts, dc to 100 MHz)
Relays, etc. . . ., Signaling Grounds (5 V to 50 V dc to a few kHz)
DC Power Ground (Returns for Loads > 1 A)
Lightning, EMP Ground (Tens of kA, dc to a few tens of MHz)
AC Power Safety Ground (50 Hz/60 Hz or 400 Hz)
Figure 5.10 Grounding hierarchy.
Duff.book Page 96 Friday, January 28, 2011 2:18 PM
96
GROUNDING FOR THE CONTROL OF EMI
This method is known as a single-point ground and is illustrated in Fig. 5.11.
5.4.1
Single-Point Grounding Scheme
The single-point or star type of grounding scheme shown in the figure avoids problems of common-mode impedance coupling discussed in the previous section. The only common path is in the earth ground (for earth-based structures), but this usually consists of a substantial conductor of very-low impedance. Thus, as long as no or low ground currents flow in any low-impedance common paths, all subsystems or equipments are maintained at essentially the same reference potential. The problem of implementing the above single-point grounding scheme comes about when (1) interconnecting cables are used, especially ones having cable shields that have lengths on the order of 1/20 of a wavelength or greater, and (2) parasitic capacitance exists between subsystem or equipment housings or between subsystems and the grounds of other subsystems. This situation is illustrated in Fig. 5.12. Here, cable shields connect some of the subsystems together so that more than one grounding path from a particular subsystem to the ground point exists. Unless precautions are taken, common-impedance ground currents could flow. At high frequencies, the parasitic capacitive reactance represents low-impedance paths, and the bond inductance of a subsystem-to-ground point results in higher impedances. Thus, again, common-mode currents may flow or unequal potentials may develop between subsystems.
Subsystem (or Equipment) #1
Subsystem (or Equipment) #2
Subsystem (or Equipment) #3
System (or Subsystem) Ground Point
Earth Ground Subsystem (or Equipment) #4
Prime Power Generator
Subsystem (or Equipment) #N
Figure 5.11 Single-point or star grounding arrangement.
Duff.book Page 97 Friday, January 28, 2011 2:18 PM
CIRCUIT, EQUIPMENT, AND SYSTEM GROUNDING Interconnecting Cable Subsystem (or Equipment) #1
97
Parasitic Capacitance Subsystem (or Equipment) #2
Subsystem (or Equipment) #3
System (or Subsystem) Ground Point Parasitic Capacitance Earth Ground Subsystem (or Equipment) #4
Prime Power Generator
Subsystem (or Equipment) #N
Figure 5.12 Degeneration of single-point ground by interconnecting cables and parasitic capacitance.
5.4.2
Multipoint Grounding Scheme
Rather than have an uncontrolled situation as shown in Fig. 5.12, the other grounding alternative is multipoint grounding as illustrated in Fig. 5.13. For the example shown in Fig. 5.13, each equipment or subsystem is bonded as directly as possible to a common low-impedance Ground Plane Subsystem (or Equipment) #1
Subsystem (or Equipment) #2
Ground Lugs or Bonds on Unit Frame Grounds
Subsystem (or Equipment) #3
Interconnecting Cables
Earth Ground Subsystem (or Equipment) #4
Prime Power Generator Ground Plane
Figure 5.13 Multipoint grounding system.
Subsystem (or Equipment) #N
Duff.book Page 98 Friday, January 28, 2011 2:18 PM
98
GROUNDING FOR THE CONTROL OF EMI
ground plane to form a homogeneous, low-impedance path. Thus, common-mode currents and other EMI problems will be minimized. The ground plane then is earthed for safety purposes.
5.4.3
Selection of a Grounding Scheme
The facts are that a single-point grounding scheme operates better at low frequencies, and a multipoint ground behaves best at high frequencies. If the overall system, for example, is a network of audio equipment, with many low-level sensors and control circuits behaving as broadband transient noise sources, then the high-frequency performance is irrelevant, since no receptor responds above audio frequency. For this situation, a single-point ground would be effective. Conversely, if the overall system were a receiver complex of 30 to 1,000 MHz tuners, amplifiers, and displays, then low-level, low-frequency performance is irrelevant. Here, multipoint grounding applies, and interconnecting coaxial cables should be used. The above comparison of audio versus VHF/UHF systems makes clear the selection of the correct approach. The problem then narrows down to one of defining where low- and high-frequency crossover exists for any given subsystem or equipment. The answer here in part involves the highest significant operating frequency of low-level circuits relative to the physical distance between the farthest located equipments. The determination of the crossover frequency region involves consideration of (1) magnetic versus electric field coupling problems and (2) ground-plane impedance problems due to separation. Hybrid single and multipoint grounding systems are often the best approach for crossover region applications. When printed circuits and ICs are used, network proximity is considerably closer. Thus, multipoint grounding is more economical and practical to produce per card, wafer, or chip. Interconnection of these components through wafer risers, motherboards, etc. should use a grounding scheme following the illustrations of previous paragraphs. This will likely still represent a multipoint or hybrid grounding approach in which any single-point grounding (for hybrid grounds), if used, would be to avoid low-frequency ground current loops and/or common-mode impedance coupling. In summary, many system-level EMI problems can be avoided by paying careful attention to the grounding scheme used. Common-mode, common-ground impedance problems may be reduced by application of one or more of the following techniques.
Duff.book Page 99 Friday, January 28, 2011 2:18 PM
CIRCUIT, EQUIPMENT, AND SYSTEM GROUNDING
99
• Eliminate common impedance by using a single point ground (Fig. 5.11) if possible. This configuration is usually optimal for power frequencies and signal frequencies below 300 kHz. • Separate and isolate grounds on the basis of signal type, level, and frequency as illustrated in Fig. 5.10. • Minimize ground impedance as illustrated in Fig. 5.14 by using ground bus, ground plane, or ground grid. • Float circuits or equipments if practical from a safety standpoint as illustrated in Fig. 5.15. The effectiveness of floating circuits or equipments depends on their physical isolation from other conductors. In large facilities, it is difficult to achieve a floating system. • Use an inductor or capacitor in the ground connection to provide high- or low-frequency isolation, respectively, as illustrated in Figs. 5.16 and 5.17. Daisy Chaining (Poor)
Heavier Ground Path (Better)
Ground Plane (Better Still)
or:
Parallel Ground Wires (Better)
Ground Grid (Better Still)
Figure 5.14 Means of decreasing common-impedance coupling by decreasing ground path impedance. From the bad practice of daisy-chain (top), the improvement evolves toward a plane (left) or a grid (right).
Duff.book Page 100 Friday, January 28, 2011 2:18 PM
100
GROUNDING FOR THE CONTROL OF EMI Box 1
Box 2 Safety Bus
Z
ZL
Vo
Case Zs
Float Vi
(a) Float Equipment Enclosures Box 1
Box 2
Float Vi (b) Float Circuits and Boards
Figure 5.15 Float circuits or equipments.
Rs Vs
RL
Figure 5.16 Capacitive grounding.
• Use filters or ferrites in ground loops to limit common-mode currents or provide a common-mode voltage drop. • Use a common-mode choke as illustrated in Fig. 5.18 or a commonmode isolation transformer as illustrated in Fig. 5.19 to suppress ground-loop EMI. These devices may provide on the order of 60 dB
Duff.book Page 101 Friday, January 28, 2011 2:18 PM
CIRCUIT, EQUIPMENT, AND SYSTEM GROUNDING
101
Vs
RL
RF Choke
Figure 5.17 Inductive grounding.
Rs
Is
I’n
Vs
• •
I”n
RL
Is
In
Vn
Figure 5.18 Common-mode chokes.
A
C Victim
Primary
Secondary
B
Case
Or Green Wire
A
=
D Ordinary Isolation Transformer
Parasitic Cap
C Victim
B D en
Figure 5.19 Common-mode isolation transformer.
Duff.book Page 102 Friday, January 28, 2011 2:18 PM
102
GROUNDING FOR THE CONTROL OF EMI
of common-mode rejection at frequencies up to several hundred kilohertz. • Use optical isolators and/or fiber optics to block common-mode EMI effects as illustrated in Fig. 5.20. Optical isolators provide a high degree of common-mode rejection at frequencies up to and including the HF band (i.e., 3 to 30 MHz). Optical isolators are usually limited to digital applications (they are not applicable to low-level analog circuits). • Use balanced circuits to minimize effects of common-mode EMI in the ground loop as illustrated in Fig. 5.21. With a perfectly balanced circuit, the currents flowing in the two parts of the circuit will produce equal and opposite voltages across the load, so the resulting voltage across the load is zero. Balanced circuits can provide significant (greater than 20 dB) common-mode reduction for low-frequency conditions. However, at higher frequencies (above 30 MHz), other effects start to predominate, and the effectiveness of balanced circuits diminishes. Common-mode radiated EMI effects resulting from emissions that are radiated or picked up by a ground loop may be reduced by the application of one or more of the following techniques: • Minimize the common-mode ground loop area by routing interconnecting wires or cable close to the ground. • Reduce the common-mode ground loop currents by floating circuits or equipments; using optical isolators; or inserting common-mode filters, chokes, or isolation transformers. • Use balanced circuits or balanced drivers and receivers.
Figure 5.20 Use of optical isolation to combat common-mode impedance.
Duff.book Page 103 Friday, January 28, 2011 2:18 PM
GROUND SYSTEM CONFIGURATIONS R1
RS 2 VS
+
2
_ + _
VS 2 RS
103
Z1 Balanced Signal Source
Vo
RL
R2
2 Z2
RCM
VCM
Common-Mode Noise Source
Figure 5.21 Balanced configuration with respect to common-mode voltage.
5.5 Ground System Configurations The ground system for a collection of circuits within a system or facility can assume any one of several different configurations. Each of these configurations tends to be optimal under certain conditions and may contribute to EMI problems under other conditions. In general, the ground configurations will involve either a floating ground, a singlepoint ground, a multipoint ground, or some hybrid combination of these. A floating ground configuration is illustrated in Fig. 5.22. This type of signal ground system is electrically isolated from the ground and other conductive objects. Hence, noise currents present in the ground system will not be conductively coupled to the signal circuits. The floating ground system concept is also employed in equipment design to isolate signal returns from equipment cabinets and thus prevent unwanted currents in cabinets from coupling directly to signal circuits. Effectiveness of floating ground systems depends on their true isolation from other nearby conductors; floating ground systems must really float. In large facilities, it is often difficult to achieve and maintain an effective floating system. Such a floating system is most practical if a few circuits or a few pieces of equipment are involved and power is applied from either batteries or dc-to-dc converters.
Duff.book Page 104 Friday, January 28, 2011 2:18 PM
104
GROUNDING FOR THE CONTROL OF EMI
Figure 5.22 Floating Signal Ground.
A single-point ground for an equipment complex is illustrated in Fig. 5.23. With this configuration, the signal circuits are referenced to a single point, and this single point is then connected to the facility ground. The ideal single-point signal ground network is one in which separate ground conductors extend from one point on the facility ground to the return side of each of the numerous circuits located throughout a facility. This type of ground network requires an extremely large number of conductors and is not generally economically feasible. In lieu of the ideal, various degrees of approximation to singlepoint grounding are employed. Equipment
Signal Ground
Structure or other Grounded Objects
Figure 5.23 Single-point signal ground.
Duff.book Page 105 Friday, January 28, 2011 2:18 PM
GROUND SYSTEM CONFIGURATIONS
105
The configuration illustrated in Fig. 5.24 represents a ground bus arrangement that is often used to provide an approximation to the single-point grounding concept. The ground bus system illustrated in Fig. 5.24 assumes the form of a tree. Within each system, the individual subsystems are single-point grounded. Each of the system ground points is then connected to the tree ground bus with a single insulated conductor. The single-point ground accomplishes each of the three functions of signal circuit grounding. That is, a signal reference is established in each unit or piece of equipment, and these individual references are connected together. These, in turn, are connected to the facility ground at least at one point, which provides fault protection for the circuits and provides control over static charge buildup. An important advantage of the single-point configuration is that it helps control conductively coupled interference. As illustrated in Fig. 5.23, closed paths for noise currents in the signal ground network are avoided, and the interference currents, or voltages in the facility ground system, are not conductively coupled into the signal circuits via the signal ground network. Therefore, the single-point signal ground network minimizes the effects of any noise currents that may be flowing in the facility ground. In a large installation, a major disadvantage of a single-point ground configuration is the requirement for long conductors. In addition to
System C System A
System B Subsystem A
Grounding Bus
Subsystem B Subsystem C
Earth Ground
Figure 5.24 Single-point ground bus system using a common bus.
Duff.book Page 106 Friday, January 28, 2011 2:18 PM
106
GROUNDING FOR THE CONTROL OF EMI
being expensive, long conductors prevent realization of a satisfactory reference for higher frequencies because of large self-impedances. Furthermore, because of stray capacitance between conductors, singlepoint grounding essentially ceases to exist as the signal frequency is increased. In general, for typical equipments, systems, or facilities, single-point grounds tend to be optimum for frequencies below approximately 300 kHz. The multiple-point ground illustrated in Fig. 5.25 is the third configuration frequently used for signal ground networks. This configuration establishes many conductive paths to various electronic systems or subsystems within a facility. Within each subsystem, circuits and networks have multiple connections to this ground network. Thus, in a facility, numerous parallel paths exist between any two points in the multiplepoint ground network. Multiple-point grounding frequently simplifies circuit construction inside complex equipment. It permits equipment employing coaxial cables to be interfaced more easily, since the outer conductor of the coaxial cable does not have to be floated relative to the equipment cabinet or enclosure. However, multiple-point grounding suffers from an important disadvantage. Power currents and other high-amplitude, low-frequency currents flowing through the facility ground system can conductively couple into signal circuits to create intolerable interference in susceptible low-frequency circuits. Also, multiple ground loops are created, and this makes it more difficult to control radiated emission or susceptibility resulting from the common-mode ground loop effects. In addition,
Safety Ground
Equipment
Signal Ground
Facility Ground
Figure 5.25 Multiple-point ground configuration.
Duff.book Page 107 Friday, January 28, 2011 2:18 PM
GROUND SYSTEM CONFIGURATIONS
107
for multiple-point grounding to be effective, all ground conductors between the separate points must be less than 0.1 wavelength of the interference signal. Otherwise, common-ground impedance and groundradiated effects will become significant. In general, multiple-point grounding configurations tend to be optimum at higher frequencies (i.e., above 30 MHz). To illustrate one form of a hybrid-ground system, Fig. 5.26 shows a 19-in cabinet rack containing five separate sliding drawers. Each drawer contains a portion of the system (top to bottom): (1) RF and IF preamp circuitry for reception of microwave signals, (2) IF and video Single-Point Power Line & Gnd Return (SPPL&GR) LO BPF & RF Ampl
Ant In
PreSelector
IF Preamp
A
Video Ampl.
B
Multipoint Ground Plane
SPPL&GR
A
Mixer
IF Ampl.
Log IF Ampl.
Demodulator
Signal Ground
Power Ground
Multipoint Ground Plane
B
Sweep Circuits
CRO
Driver
Singlepoint Ground Plane Diff Ampl.
Recorders
Audio Driver
Singlepoint Ground Plane Earth Ground Distribution Block Gnd
Figure 5.26 Grounding arrangement used in cabinet racks.
Display Drawer
Duff.book Page 108 Friday, January 28, 2011 2:18 PM
108
GROUNDING FOR THE CONTROL OF EMI
signal amplifiers, (3) display drivers, displays, and control circuits, (4) low-level audio circuits and recorders for documenting sensitive multichannel, hard-line telemetry sensor outputs, and (5) secondary and regulated power supplies. The hybrid aspect results from: • The RF and IF video drawers are similar. Here, unit-level boxes or stages (interconnecting coaxial cables are grounded at both ends) are multipoint grounded to the drawer-chassis ground plane. The chassis is then grounded to the dagger pin, chassis ground bus as suggested in Fig. 5.27. The power ground to these drawers, on the other hand, is using a single-point ground from its bus in a manner identical to the audio drawer.
Insulator Low-Level RF Circuits & IF Preamp To Power Gnd To Signal Gnd
Antenna Jack
IF Amplifiers, BP Filters Demodulators, & Video Ampl Video Cables, Coax or Twisted Shielded Pair Display Drivers and Readout Circuitry
Computer Clock Input
Low-Level Audio Sensor Circuits & Display Power Raceway
Multiplex Input Sensor Jack
AC Power Mains Input Ground or Earthing Stake
Secondary & Regulated Power Supplies
Weld Ground Distribution Block
Figure 5.27 Block diagram detail of hybrid grounding arrangement.
Chassis Shelves of Rails
Signal Gnd
RF-IF Coax Cables
Duff.book Page 109 Friday, January 28, 2011 2:18 PM
EMI CONTROL DEVICES AND TECHNIQUES
109
• The chassis or signal ground and power ground busses each constitute a multipoint grounding scheme to the drawer level. The individual ground busses are single-point grounded at the bottom ground distribution block. This avoids circulating common-mode current between chassis or signal ground and power grounds, since power ground current can vary due to transient surges in certain modes of equipment operation. • Interconnecting cables between different drawer levels are run separately, and their shields, when used, are treated in the same grounding manner as at the drawer level. • The audio and display drawers shown in Fig. 5.27 use single-point grounding throughout for both their unit-level boxes (interconnecting twisted cable is grounded at one end to its unit) and power leads. Cable and unit shields are all grounded together at the common dagger pin bus. Similarly, the outgoing power leads and twisted returns are separately bonded on their dagger pin busses. To review the above scheme, the following is observed: • The audio and display drawers have ground runs of about 0.6 m and an upper frequency of operation of about 1 MHz (driver and sweep circuits). Thus, single-point grounding to the strike pins is indicated. • The RF and IF drawers process UHF and 30 MHz signals over a distance of a meter so that multipoint grounding is indicated. • The regulated power supplies furnish equipment units having transient surge demands. The longest length is about 1.5 m, and significant transient frequency components may extend up in the HF region. Here, hybrid grounding is indicated: single-point within a drawer and multipoint from the power bus to all drawers.
5.6 EMI Control Devices and Techniques The performance of some EMI control techniques or devices may be significantly influenced by grounding. In particular, cable shields; isolation transformers; EMI filters; ESD, lightning, and EMF protection techniques; and Faraday shields must be properly grounded so as to provide maximum EMI protection. A detailed discussion of specific grounding considerations associated with these EMI control techniques or devices is beyond the scope of this book. However, it is important to emphasize the importance of grounding on the performance of these techniques or devices, and details may be found in the references.
Duff.book Page 110 Friday, January 28, 2011 2:18 PM
110
GROUNDING FOR THE CONTROL OF EMI
Suggested Readings: Grounding [1] Morrison, Ralph, and W. H. Lewis, Grounding and Shielding in Facilities, Hoboken, NJ: John Wiley & Sons, 1990. [1] Morrison, Ralph, Grounding and Shielding Techniques in Instrumentation, 3rd ed., Hoboken, NJ: John Wiley & Sons, 1990. [1] Denny, Hugh W., Grounding for the Control of EMI, Gainesville, VA, Interference Control Technologies, Inc. [1] Grounding, Bonding and Shielding for Electronic Equipment and Facilities, MIL-HDBK-419.
Related Documents g842
U3 - Emi Control Techniques 6j6x6p
December 2019 35
U3 715b3p
October 2020 0
U3 715b3p
April 2020 24
Quality Control Techniques 2q374x
July 2021 0
Management Modern Control Techniques 552032
December 2019 40
Control Techniques For Sales 3i312h
December 2021 0More Documents from "Anonymous gdmgfOSlP" 5q1l5i
U3 - Emi Control Techniques 6j6x6p
December 2019 35
Week 7_ Handout 1_style And (1) (1) 1w2k54
June 2020 7
All-of-the-stars-sheet-music-ed-sheeran-(sheetmusic-free.com).pdf 55465u
November 2019 1,220
Apunte De Podologia Modulo Podologia Clinica 6z2s6h
April 2020 26
Imagenes Frases Positivas De Amor - Buscar Con Google i3n6b
February 2023 0
