PRODUCTION PLANNING AND CONTROL (PPC)

PLANNING

CONTROL

PRODUCTION

Planning+ Control = Productivity

CONTENT  Production System  Production Planning Items  Controlling Items  Nature of MRP

PRODUCTION…

PRODUCTION PLANNING AND CONTROL (PPC)  PRODUCTION: that transformation of raw

materials to finished goods.  PLANNING: looks ahead, anticipates possible difficulties and decides in advance as to how the production, best, be carried out.  CONTROL: phase makes sure that the programmed production is constantly maintained.

PRODUCTION SYSTEM  System is a whose function is to convert a

set of inputs into a set of desired outputs.

PRODUCTION PLANNING  Given a specific process planning, process

technologies and production conditions

 predetermine varieties, quantities, qualitiy, and

scheduled of products to be produced according to market demand of products..

And Where we are-----------?  Destination ---------------?

TIME DIMENSIONS  Long Range Planning; is done annually and

focus on a planning horizon greater than one year.  Medium Range Planning; usually covers a period from 6 months to 18 months, with monthly or sometimes quarterly time increments.  Short Range Planning; covers a period from one day or less to six months, with weekly time increment usually.

PRODUCTION PLANNING

PLANNING ROUTING SCHEDULING LOADING

PRODUCTION PLANNING PLANNING  That may be defined as the technique of foreseeing every step in a long series of seperate operations.  Each step to be taken at the right time, and in the right place and each operation to be performed in maximum efficiency.

PRODUCTION PLANNING ROUTING  Under this operations , their path and sequence are established.  The main aim of routing; determine the best and cheapest sequence of operations and to ensure that this sequence is strictly followed.

PRODUCTION PLANNING Routing procedure involves following different activities;  An analysis of the article to determine what to make and what to buy  To determine the quality and type of material  Determining the manufacturing operations and their sequence  An analysis of cost of the article  Determination of scrap factors

PRODUCTION PLANNING SCHEDULING  It mainly concerns with time element and priorities of a job.  The pattern of scheduling differs from one job to another which is explained as below: Production Schedule Master Schedule Manufacturing Schedule

PRODUCTION PLANNING LOADING  Defined as the relationship between load and capacity, so as to assign the work for the production. Capacity: the time available for work at work centres expressed in machine hours or in man hours. Load: to assign work to the capacity available at particular work centres.  It includes the assignment of the work to the operators at their machines or work places.

PRODUCTION PLANNING  Loading determines; who will do the work as

routing determines; where and scheduling determines; when it shall be done.

PLANNING PHASE PRIOR PLANNING Forecasting  Type, Quantitiy,Quality Product Design  Specifications,Bill of Materials Order Writing  To undertake a particular job.

PLANNING PHASE ACTIVE PLANNING Process Planning and Routing  Economic Process, How to do, Where to Work Materials and Tools Control  Requirements, Controls Loading  Assignment of Work, Manpower, Machinery Scheduling  Time Phase, Sequence of Work

PLANNING PHASE ACTION PHASE Dispatching  Ordering to start the working CONTROL PHASE Progress Reporting  Data Reporting, Performance Comparison Corrective Phase  Expediting, Replanning

PRODUCTION CONTROL

DISPATCHING FOLLOWING UP INSPECTION CORRECTIVE

PRODUCTION CONTROL  Production control; is the process of planning

production in advance of operations, establishing the extract route of each individual item part or assembly, setting, starting and finishing for each important item, assembly  the finishing production and releasing the necessary orders as well as initiating the necessary follow-up to have the smooth function of the enterprise.

PRODUCTION CONTROL DISPATCHING Involves issue of production orders for starting the operations.  Movement of materials to different workstations  Movement of tools and fixtures necessary for each operation  Beginning of work on each operation

PRODUCTION CONTROL DISPATCHING  Recording of time and cost involved in each

operation  Movement of work from one operation to another in accordance with the route sheet  Inspecting or supervision of work

PRODUCTION CONTROL FOLLOW UP  It includes delays or deviations from the production plans.  It helps to reveal detects in routing and scheduling, misunderstanding of orders and instruction, under loading or overloading of work.

PRODUCTION CONTROL INSPECTION  To ensure the quality of goods. It can be required as effective agency of production CORRECTIVE MEASURES  involve any of those activities of adjusting the route, rescheduling of work changing the workloads, repairs and maintenance of machinery or equipment, control over inventories of the cause of deviation is the poor performance of the employees

MATERIAL REQUIREMENT PLANNING (MRP) PHILOSOPHY MRP- Materials should be expedited when their lack would delay the overall production schedule. AIM of MRP  Renawal of products inventory  To meet customer orders

FACTORS OF MRP Main Production Plan Product Tree Inventory Situation Folder Performance Report  Planned Order Schedule  Special Situation Report

Assignments: 1. What do you understand by Production

Planning and Control? Explain the various steps.  2.Explain objectives of PPC.

THANK YOU FOR YOUR LISTENING 
