Specifications (Typical Value)

Classification Frequency Band

6-8 GHz

15 GHz

18 GHz

23 GHz

26 GHz

28 GHz

32 GHz

38 GHz

Range (GHz)

5.925-8.5

14.2-15.35

17.7-19.7

21.2-23.6

24.25-27.0

27.5-29.5

31.8-33.4

37.0-40.0

16 QAM Channel Spacing (MHz)

56 / 155 Mbps (18 GHz: 55 MHz) 28 / 155 Mbps (18 GHz: 27.5 MHz)

128 QAM

56 / 310 Mbps (18 GHz: 55 MHz)

Transmission Capacity

28 / 200 Mbps (18 GHz: 27.5 MHz)

256 QAM

56 / 400 Mbps (18 GHz: 55 MHz)

Frequency Stability

± 6 ppm

MTPC / ATPC

1 dB step available STM-1

Electrical 75 ohms, Optical (S-1.1 or L-1.1), APS function available

GbE

1000 Base-T (IEEE 802.3ab), 1000 Base-LX/SX (IEEE 8023z)

Traffic Interface

1x GbE (10/100/1000 Base-T or 1000 Base-LX/SX)+ 3x FE (10/100 Base-T) Tag Based VLAN (IEEE 802.1Q), Port Based VLAN

VLAN

QoS (IEEE802.1p): CoS/ ToS/ Diffserve based priority control Link aggregation up 800 Mbps

Service Channel

64 kbps V.11 2ch, 9.6 kbps RS232-C: 2 ch, EOW: 2ch

Wayside

2 Mbps: E1 interface or 10 Base-T (1ch / 155 Mbps) EN 302 217-2-2 RF Performance EN 300 019-1-1 Storage EN 300 019-1-2 Transportation EN 300 019-1-3 IDU Operation class 3.1E

Standard Compliance

EN 300 019-1-4 ODU Operation class 4.1 EN 301489-4 EMC EN 60950 Safety EN 300132-2 Power Supply Interface

Ambient Temperature

IDU: -5 to +50°C, ODU: -33 to +50°C

Power Line Voltage Power Consumption (ODU + IDU) Dimensions and Weight

-48 VDC (-40.5 to -57 VDC), +/-24 VDC optional Approx. 40W

1+0 1+1

Approx. 70W

ODU

6-8 GHz: 237(W) x 237(H) x 101(D) mm: Approx. 3.5 kg, 15-38 GHz: 239(W) x 247(H) x 68(D) mm: Approx. 3.0 kg

IDU

482(W) x 44(H) x 230(D) mm: Approx. 4kg (1+0), 5kg (1+1) Specifications are subject to change without notice.

Abbreviations ATPC BER BW CAPEX CCDP CoS CTRL EMC EOW ETSI

Automatic Transmitting Power Control Bit Error Rate Band Width Capital Expenditure Co-Channel Dual Polarization Class of Service Control Erector Magnetic Compatibility Engineering Order Wire European Telecommunications Standards Institute

FD FE GbE HS HYB IDU IEEE INTFC IP LTE

Frequency Diversity Fast Ethernet Gigabit Ethernet Hot Standby Hybrid combiner/divider Indoor Modulator/Demodulator Unit Institute of Electrical and Electronics Engineers Interface Internet Protocol Long Term Evolution

MODEM MTPC Node-B ODU OPEX OW PWE3 QAM QoS RMON RNC

Modulator/Demodulator Manual Transmitting Power Control Wireless Base Station Equipment Outdoor Transmitter/Receiver Unit Operation Expenditure Order Wire Pseudo Wire Emulation Edge-to-Edge Quadrature Amplitude Modulation Quality of Service Remote Monitoring Radio Network Controller

SD SDH STM ToS VLAN WiMAX WS xDSL

Space Diversity Synchronous Digital Hierarchy Synchronous Transport Module Type of Service Virtual LAN Worldwide Interoperability for Microwave Access Wayside xDigital Subscriber Line

PASOLINK NEO IP: Series name stands for next generation packet radio.

Cat. No. BMW036-2 08091002KM ©NEC Corporation 2008

NEC and the Evolving World of Ultra-High-Speed Packet Access PASOLINK NEO High Performance (HP)

Main Features

is designed for high-speed future networks of advanced point-to-point

Design concept

Technical merits

■ Low Capex/Opex Broadband Packet Radio

digital microwave access radio. It employs a common platform design

Key specifications

concept that provides scalable configurations to respond flexibly to a

■ Frequency band: 6 to 38 GHz ■ Radio transmission capacity:155 Mbps to 1.6 Gbps* ■ Interface:1 x GbE + 3 x FE (10/100/1000 Base-T or 1000 Base-LX/SX+ 3 x 10/100 Base-T) GbE (1000 Base-T or 1000 Base-LX/SX) STM-1 optical or electrical (x1 or 2) 1 or 2 E1 (wayside) ■ Modulation:16 QAM/128 QAM /256 QAM*

diverse range of market needs. NEO HP is designed with completely new technology using sub-micron silicon technology and the latest signal processing circuit. Therefore this digital radio delivers incomparable scalable performance and versatile interfaces. This performance will handle advanced IP networks of the future that will grow rapidly and

Scalability

massively. By adopting the same field-proven common-platform design of

■ Capacity and bandwidth upgradable by software and configuration Ê Ê UÊ£xxÊL«ÃÊ­ÓnÊâ®Êr€ÊÓääÊL«ÃÊ­ÓnÊâ®IÊ Ê Ê r€ÊΣäÊL«ÃÊ­xÈÊâ®Êr€Ê620 Mbps (56 MHz CCDP) Ê Ê r€Ê£°ÓÊL«ÃÊ­££ÓÊâÊ

*® Ê Ê r€Ê£°ÈÊL«ÃIÊ­££ÓÊâÊ

*®Ê ■ Modulation selectable by software Ê Ê UÊÀœ“Ê£ÈÊ+ÊÕ«ÊÌœÊÓxÈÊ+I ■ Flexible system configuration: 1+0, 1+1 (HS/SD/FD) ■ Common ODU for NEO series

the PASOLINK NEO series, NEO HP offers unrivaled reliability, while further improving scalability. NEO HP meets the increasing demand for digital transmission services, and satisfies the needs for integration with a variety of services such as WiMAX backbone, wireless xDSL and private intranetworking. NEO HP realizes NEC’s commitment of “Achieving Customer Satisfaction”; by taking investment value one step further.

■ Peerless high reliability ■ Super-low latency ■ High system gain ■ Low power consumption ■ Easy and stable cross polarized operation for 620/800 Mbps* (56 MHz) or 310/400 Mbps* (28 MHz) ■ Automatic protection switch for STM-1 interface ■ Gigabit Ethernet UÊHigh throughput and low latency UÊJumbo frame available (up to 9600 bytes) Uʈ˜ŽÊ>}}Ài}>̈œ˜ÊÕ«ÊÌœÊÈÓäÉÊnääIÊL«ÃÊ­vœÀÊL Ê6 ® ■ 6 ÊÃÕ««œÀÌÊiÝVi«ÌÊiÝÌiÀ˜>ÊLœÝ ■ *œÀÌÊL>Ãi`Ê6 ■ />}‡L>Ãi`Ê6 ]ÊnäÓ°£+ ■ QoS: 802.1p; CoS, ToS/Diffserve ■ MPLS ■ Adaptive modulation capability* ■ 75E1/150E1 High-capacity PDH (Optional) ■ PWE3 (Optional) Applications ■ Advanced mobile system network backbone ■ WiMAX backbone ■ High-speed internet network *By software upgrade

Additional Modem + ODU 1+0

WiMAX Backbone Network

1+1

155 / 200* Mbps

BS

ASN-GW

IP NETWORK

BS

155 / 200* Mbps

GbE VLAN INTFC

Additional Modem + ODU 1+0

GbE

1+1

310 / 400* Mbps GbE

310 / 400* Mbps

WS/ LAN

GbE

BS

Increment System Increment System

GbE/SDH MODEM Unit

GbE/SDH

RNC

620 / 800* Mbps

To ODU

Replace Interfaces

Node-B

Node-B

TDM/IP NETWORK

3G/LTE Mobile Network

Increment System

To ODU Control Unit MODEM Unit

1.2 / 1.6* Gbps

Node-B

620 / 800* Mbps

Network Application 3G/LTE/ WiMAX Backbone Network

Common Platform Concept

Configuration Scalability

*By software upgrade
