iVMS-4500(iPhone) Mobile Client Software
iVMS-4500(iPhone) Mobile Client Software Manual (V1.0)
Thank you for purchasing our product. This manual applies to iVMS-4500 (iPhone) mobile client software, please read it carefully for the better use of this software. The contents in this manual are subject to change without notice.
1
iVMS-4500(iPhone) Mobile Client Software
Contents Chapter 1 Introduction .................................................................................................. 3 1.1 Overview ........................................................................................................... 3 1.2 System Requirements ....................................................................................... 3 1.3 Performance Description .................................................................................. 3 Chapter 2 Running Software .......................................................................................... 4 2.1 Software .................................................................................................. 4 2.2 Main Menu ........................................................................................................ 5 Chapter 3 Devices Management.................................................................................... 6 3.1 Add Device ........................................................................................................ 6 3.2 Modify & Delete Device .................................................................................... 7 Chapter 4 Camera Configuration ................................................................................... 8 Chapter 5 Live Preview ................................................................................................ 10 5.1 Live Preview .................................................................................................... 10 5.2 PTZ Control ...................................................................................................... 12 Chapter 6 Group Management .................................................................................... 15 Chapter 7 Others .......................................................................................................... 17 Chapter 8 Troubleshooting .......................................................................................... 18
2
iVMS-4500(iPhone) Mobile Client Software
Chapter 1 Introduction 1.1 Overview iVMS-4500 (iPhone) mobile client software, which is based on iPhone OS, can be used to remotely monitor the live video that from embedded DVR, IP camera, IP speed dome and DVS via wireless network, and PTZ control can be achieved as well. With this software installed in your mobile device, you are able to log on to the front-end device via WIFI, 2G or 3G, besides, if there is no public IP available, it’s accessible by using a dynamic name, or by forwarding ports to the public IP of router.
1.2 System Requirements Hardware: iPhone 3G or 3GS Software: iPhone 3.0 OS or later version
1.3 Performance Description Stream Type Frame Type
Sub stream BBP or single P 2~8FPS (depends on the performance of mobile device) QCIF, CIF Video 32~256Kbps (depends on the net environment)
Frame Rate Mobile Client
Resolution Stream Type Bit Rate
3
iVMS-4500(iPhone) Mobile Client Software
Chapter 2 Running Software Please log on to Apple store web page and enter ‘iVMS-4500’ to search mobile client software, then the software and install it to your phone. After install the software successfully, you can click
2.1 Software needs to an if this application is used for the first time, enter the name and in the interface, and then click ‘’ to complete registration.
If it’s not the first time to run this application, the name that used last time will be the default name, before , you can also check ‘’ to save current .
4
icon to start the program.
iVMS-4500(iPhone) Mobile Client Software
2.2 Main Menu Click ‘’ to the software, main menu interface appears.
Main menu description Main Menu Descriptions Live Preview Live preview and PTZ control Devices Add new device, delete device, device’s information Favorites Define specific channels to your favorites Channel Config Configure camera’s stream type, resolution, frame rate and bit rate Local Config Configure the store path, access point and speed of PTZ control Setting modification Help Help document About Software’s version information
5
iVMS-4500(iPhone) Mobile Client Software
Chapter 3 Devices Management The device list is empty in default. Firstly you need to add a device that all operations such as preview, configuration and device management can be available then.
3.1 Add Device Click ‘Devices’ icon in the main menu to enter devices management interface, navigate to ‘Add’ option, you will be taken to a new device configuration interface.
You can select either ‘IP’ or ‘Domain’ mode to the device, domain mode is for the case that there is no fixed IP address available.
6
iVMS-4500(iPhone) Mobile Client Software
Parameters description Parameters Device name mode Address Port name Chann No.
Descriptions Define a name for the device IP or DDNS IP address/dynamic name address Traffic port of device Device’s name Device’s The number of cameras
The newly added device will be shown in the devices list, you can either click ‘Add’ to add more devices or click ‘iVMS-4500’ to exit and return to main menu.
3.2 Modify & Delete Device Select a device in the list, then click ‘
’ icon to
see the detail of the parameters configured, you can modify the parameters as well, besides, slide the device you can get the option to delete it.
7
iVMS-4500(iPhone) Mobile Client Software
Chapter 4 Camera Configuration After the device successfully, you can configure the preview parameters for each camera according to your net environment. Click
icon in the main menu to enter camera
configuration interface, all of the added devices will be listed. Now, we only add one device to this software.
Click the device and select a camera to enter parameters configuration interface.
8
iVMS-4500(iPhone) Mobile Client Software
You can configure stream type, resolution, image quality, bit rate, frame rate, etc. After finishing the parameters adjustment, click ‘Save’ to save the settings.
Camera parameters description Parameters Description Chan. name Define a name for the camera Para. type You can select customize or general Encoding para. You can select main stream or sub stream for live preview Resolution CIF or QCIF Image quality 6 levels of image quality Bitrate type Variable or constant bit rate Max. bitrate The maximum bit rate of each camera, you need to configure it according to the net environment. Frame rate Frame rate of the camera The parameters type can be ‘Customize’ or ‘General’, if select ‘customize’, then all of parameters are configurable, otherwise, the channel parameters will be fixed and not allowed to be adjusted. General parameters Parameters Descriptions Encoding para. Sub stream Stream type Video Resolution QCIF Image quality Lowest Bitrate type Constant Max. bitrate 32Kbps Frame rate 4FPS
9
iVMS-4500(iPhone) Mobile Client Software
Chapter 5 Live Preview After the proper parameters are configured, you can preview the cameras, control the PTZ as well.
5.1 Live Preview Enter live preview interface by clicking
in the
main menu, there is 4-split mode in default.
Button definitions Buttons Descriptions Cameras selection Stop playing Picture capture Call out PTZ control
Buttons
Descriptions Switch camera for previewing Stop playing all cameras
Preview In the 4-split screen, select the window on which you want to play live video, click or
to enter camera selection interface.
10
iVMS-4500(iPhone) Mobile Client Software
Click the device will unfold the cameras list, select a camera to start previewing.
In 4-split preview mode, you can double click any of the windows to get it enlarged, double click again the screen will be back to 4-split mode. Click
button you can stop previewing
the selected camera, all the playing videos will be stopped when click
button, and you can
exit the interface by clicking ‘iVMS-4500’ icon.
11
iVMS-4500(iPhone) Mobile Client Software
Picture Capture Click
button to capture the picture when
preview the video.
5.2 PTZ Control Click
button to enter PTZ control interface,
There are four direction icons on the screen, slider any of the icons will be able to control the pan or tilt position. Slider between two fingertips will zoom in/out the lens. You can click ‘iVMS-4500’ icon to exit and return to live preview interface.
PTZ control buttons definitions Buttons
Descriptions Brightness setting Presets setting/calling
12
iVMS-4500(iPhone) Mobile Client Software
Presets settings In the PTZ control mode, adjust the camera to right positions for this preset first, then click to enter preset configuration interface, the configuration appears. Select ‘Set’ on the and enter the number for this preset.
Presets calling In PTZ control mode, click
to enter preset
calling interface. Select ‘Call’ in the , and enter the preset number to call it.
13
iVMS-4500(iPhone) Mobile Client Software
Brightness Adjustment Click ‘
’ icon, then brightness adjustment
slider appears.
14
iVMS-4500(iPhone) Mobile Client Software
Chapter 6 Group Management Group management is a function that groups the camera and makes the preview easier when only concern some specific cameras. In the main menu interface, click
to
enter group management interface, there is no camera under ‘Favorites’, so you need to add cameras at this point.
In the cameras selection interface, Click the device to unfold cameras list, you can add any of the cameras to your favorites by selecting it. The cameras which have been selected will be marked with ‘ ’ icon.
15
iVMS-4500(iPhone) Mobile Client Software
After finish the cameras selection, click ‘Confirm’ to return to group management interface, the cameras you just added to your favorites are included in the list.
Slide the camera, the option to remove camera from ‘Favorites’ appears.
Now, navigate to the live preview interface, you can select the cameras directly from ‘Favorites’ for previewing.
16
iVMS-4500(iPhone) Mobile Client Software
Chapter 7 Others Local Configuration Click
icon in the main menu, you can drag
the slider to adjust the speed in pan and tilt direction, there are seven steps in all, among these steps, the higher level you set the higher speed in pan and tilt you will reach.
Modification Click
in the main menu you can enter
modify interface, you are allowed to modify your current . Enter old , new and then confirm new to complete the modification.
About Click
in the main menu, you will get the information of the software such as
version, build date. If needs any help during the operation, you can click out and open the help document. 17
to call
iVMS-4500(iPhone) Mobile Client Software
Chapter 8 Troubleshooting 1. What kinds of devices are compatible with iVMS-4500 mobile client software? The encoder which adopt H264 codec are compatible with this software, such as embedded DVR, DVS, IP camera and IP speed dome, besides it also requires this software to be applied with device which dual stream. 2. Why does the mobile client software prompt ‘ failed’ when access to the device via WIFI? Please check whether the WIFI parameters are configured properly in your phone. 3. After start previewing the video, why does the responding of the mobile device becomes very slow and the video is easy to get stuck? This problem may due that the lower performance of your mobile device, please try to preview less cameras at the same time, or decrease the frame rate and resolution, you may refer to the following parameter settings. Resolutions CIF QCIF
Recommend number of cameras 1 4
18
Recommend frame rate 8FPS or lower 8FPS or lower
