OWNER’S MANUAL How to maintain and operate your EcoWater electronic demand water system

R

MODELS ESD 2502R30 ESD 2502R39

MODEL ESD 518

Systems Tested and Certified by NSF International and WQA against NSF/ANSI Standard 44 for softener performance.

EcoWater Systems PO Box 64420, St. Paul MN 55164--- 0420

Part No. 7277268 (Rev. D 11/17/05)

PRINTED IN USA

1

GUARANTEE BOND

LIMITED WARRANTY EcoWater Systems LLC Advantage Warranty Series ESD 518, ESD 2502R30 & ESD 2502R39 Water Systems Congratulations! You have just purchased the highest quality water conditioning product on the market. To your warranty, complete the enclosed Warranty Registration Card and mail it within 30 days of purchase. To whom is this warranty extended? EcoWater Systems LLC warrants its products to the original owner and guarantees that the products will be free from defects in materials and workmanship from the original date of installation. How does my warranty work? If, during the respective warranty period, a part proves, after inspection by EcoWater, to be defective, EcoWater will, at its sole option repair or replace that part at no charge, other than normal shipping, installation or service charges. What is covered by the warranty? EcoWater Systems LLC guarantees that, for the LIFETIME of the original owner, the MINERAL TANK will not rust, corrode, leak, burst, or in any other manner fail to perform its proper function and that, for a period of TEN YEARS, the SALT TANK will be free of defects in materials and workmanship and will perform its proper function and that, for a period of THREE YEARS, the VALVE BODY, ELECTRONIC FACEPLATE and ALL OTHER PARTS will be free of defects in materials and workmanship and will perform their normal functions. How do I obtain warranty service? Should you need service, your local, independent EcoWater Dealer is only a phone call away. PHONE:

The Safeco Insurance Company of America has issued it’s bond in the form shown below, guaranteeing full performance by EcoWater Systems LLC SAFECO INSURANCE COMPANY OF AMERICA, hereinafter called ‘‘Surety,’’ guarantees unto Bank of New York as Trustee holding said Guarantee Bond under the of a Trust Agreement dated April 9, 2003, for the use and benefit of original purchasers of residential EcoWater Systems Units within the Continental United States, as described herein, that EcoWater Systems LLC, will discharge the obligations of the ‘‘EcoWater Bonded Parts and Service Guarantee Policy.’’ PROVIDED, HOWEVER, that: 1. Liability of Surety hereunder shall not exceed the sum of FIVE HUNDRED AND 00/100th DOLLARS ($500.00) as to any one installation, and shall not exceed the sum of FIVE HUNDRED THOUSAND AND 00/100th DOLLARS ($500,000.00) in the aggregate, and 2. There shall be no liability hereunder as to any purchaser to whom there has not been issued at the time of installation and purchase completed registration card which is enclosed with a facsimile of this bond, and who has not returned such card in accordance with this guarantee.

To obtain warranty service, notice must be given, within thirty (30) days of the discovery of the defect, to your local EcoWater Systems dealer. If I need a part replaced after the factory warranty expires, is the replacement part warranted? Yes, EcoWater Systems LLC warrants FACTORY REPAIRS as well as all REPLACEMENT PARTS for a period of 90 DAYS. This warranty does not include normal shipping, installation or service charges. Are any additional warranties available? We are pleased to say, YES! EcoWater Systems LLC sells an EXTENDED, PARTS ONLY WARRANTY for the ELECTRONICS portion of your product. This warranty is called the “Perfect Ten” and extends the three year warranty on the electronic FACEPLATE, WIRING HARNESS, DRIVE MOTOR, TRANSFORMER, POWER CORD, SENSOR HOUSING, and MICRO SWITCHES to a total of TEN YEARS from the date of original installation. Your local dealer will provide details regarding this warranty or will refer you to the factory for additional information.* General Provisions The above warranties are effective provided the water conditioner is operated at water pressures not exceeding 125 psi, and at water temperatures not exceeding 120°F; provided further that the water conditioner is not subject to abuse, misuse, alteration, neglect, freezing, accident or negligence; and provided further that the water conditioner is not damaged as the result of any unusual force of nature such as, but not limited to, flood, hurricane, tornado or earthquake. EcoWater Systems LLC, is excused if failure to perform its warranty obligations is the result of strikes, government regulation, materials shortages, or other circumstances beyond its control. *THERE ARE NO WARRANTIES ON THE WATER CONDITIONER BEYOND THOSE SPECIFICALLY DESCRIBED ABOVE. ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR OF FITNESS FOR A PARTICULAR PURPOSE, ARE DISCLAIMED TO THE EXTENT THEY MIGHT EXTEND BEYOND THE ABOVE PERIODS. THE SOLE OBLIGATION OF ECOWATER SYSTEMS LLC UNDER THESE WARRANTIES IS TO REPLACE OR REPAIR THE COMPONENT OR PART WHICH PROVES TO BE DEFECTIVE WITHIN THE SPECIFIED TIME PERIOD, AND ECOWATER IS NOT LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES. NO ECOWATER DEALER, AGENT, REPRESENTATIVE, OR OTHER PERSON IS AUTHORIZED TO EXTEND OR EXPAND THE WARRANTIES EXPRESSLY DESCRIBED ABOVE. Some states do not allow limitations on how long an implied warranty lasts or exclusions or limitations of incidental or consequential damage, so the limitations and exclusions in this warranty may not apply to you. This warranty gives you specific legal rights, and you may have other rights which vary from state to state. This warranty applies to consumer ---owned installations only.

3. Claim must be made by such original purchaser in writing within 30 days from the expiration of these guarantees upon EcoWater Systems LLC, PO Box 64420, St. Paul, MN 55164, to perform the of said guarantee, and notice of any default on such guarantee must be sent to Surety at its address by ed Mail. SAFECO INSURANCE COMPANY OF AMERICA This is to certify that the original of the above guarantee and bond is on file with Bank of New York. BANK OF NEW YORK As Trustee

2

SAFETY GUIDES Follow the installation instructions carefully. Failure to install the EcoWater softener properly voids the warranty. Before you begin installation, read this entire manual. Then, obtain all the materials and tools you will need to make the installation. Check local plumbing and electrical codes. The installation must conform to them. In Massachusetts, plumbing codes of Massachusetts shall be adhered to. Consult with your licensed plumber. Use only lead -- free solder and flux for all sweat---solder connections, as required by state and federal codes. Use care when handling the EcoWater softener. Do not turn upside down, drop, or set on sharp protrusions. Do not locate the EcoWater softener where freezing temperatures occur. Do not attempt to treat water over 120˚F. Freezing, or hot water damage voids the warranty. Avoid installing in direct sunlight. Excessive sun heat may cause distortion or other damage to non---metallic parts. The EcoWater softener requires a minimum water flow of 3 gallons per minute at the inlet. Maximum allowable inlet water pressure is 125 psi. If daytime pressure is over 80 psi, nighttime pressure may exceed the maximum. Use a pressure reducing valve if necessary. (Adding a pressure reducing valve may reduce the flow.) The EcoWater softener works on 24 volt -- 60 hz electrical power only. Be sure to use the included transformer and plug it into a nominal 120V, 60 cycle household outlet that is grounded and properly protected by an overcurrent device such as a circuit breaker or fuse. If transformer is replaced, use only the authorized service Class II, 24 volt, 10 VA transformer. This system is not intended to be used for treating water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. European Directive 2002/96/EC requires all electrical and electronic equipment to be disposed of according to Waste Electrical and Electronic Equipment (WEEE) requirements. This directive or similar laws are in place nationally and can vary from region to region. Please refer to your state and local laws for proper disposal of this equipment.

3

DIMENSIONS / SPECIFICATIONS ESD 518

OUT

A

ESD 2502R30 ESD 2502R39

IN

20”

IN

14”

A

16”

14”

OUT 14”

IN --- OUT

16”

IN --- OUT

C

C

B

36--- 9/16” 32”

B

32--- 1/2”

MODEL

NOMINAL RESIN TANK SIZE

A

B

C

ESD 518

8” DIA. X 35”

3--- 3/8”

38--- 1/8”

45”

ESD 2502R30

8” DIA. X 40”

3--- 3/8”

41.6”

48.75”

ESD 2502R39

10” DIA. X 47”

3--- 3/4”

49.8”

56.6”

Rated Capacity (grains @ salt dose)

Service Flow Rate (gpm)

ESD 518

ESD 2502R30

ESD 2502R39

10,100 @ 2.0 lbs 21,500 @ 6.4 lbs 25,600 @ 10.7 lbs

12,200 @ 2.4 lbs 25,600 @ 7.5 lbs 30,600 @ 12.6 lbs

12,100 @ 2.4 lbs 31,700 @ 8.9 lbs 40,200 @ 15.4 lbs

5.0

7.8

7.0

Pressure Drop at Service Flow Rate (psi)

7

15

6

Intermittent Flow Rate (gpm) @ 15 psi ✦

8.7

7.8

13.3

Intermittent Flow Rate (gpm) @ 30 psi ✦

13.5

12.2

20.9

5030 @ 2.0

5070 @ 2.4

5030 @ 2.4

Amount of High Capacity Resin (cu ft)

.67

.79

1.13

Water Supply Max. Hardness (gpg)

50

60

80

Water Supply Max. Clear Water Iron (ppm) ◓

3

4

5

Rated Efficiency (gr / lb of salt @ min. salt dose) ◪

Water Pressure Limits (min./max. psi) ◮

20 -- 125

Min./Max. Water Temperature (˚F)

40_ -- 120_

Min. Water Supply Flow Rate (gpm)

3

Max. Drain Flow Rate (gpm)

2.0

2.0

2.3

These systems conform to NSF/ANSI 44 for the specific capacity claims as verified and substantiated by test data. ✦ Intermittent flow rate does not represent the maximum service flow rate used for determining the softeners rated capacity and efficiency. Continuous operation at flow rates greater than the maximum service flow rate may affect capacity and efficiency performance. The validity of these flow rates is verified by NSF. ◪ Efficiency rating is only valid at the minimum stated salt dose and service flow rate. These softeners were efficiency rated according to NSF/ANSI standard 44. ◓ Capacity to remove clear water iron is substantiated by WQA test data. ◮ Working pressure for Canadian use is 1.4 -- 7.0 kg/cm@.

4

INSTALLATION -- (MODELS ESD 518 & ESD 2502R30) (ESD 518 shown) FIGURE 1 CONDITIONED WATER by valve

120V, 60Hz outlet

HARD WATER

HARD WATER

3--- valve by system

outlet valve

transformer (supplied) to timer

OUTLET

OUTLET

inlet valve

to timer

INLET INLET

valve drain hose brine tank overflow hose

1---1/2” airgap

valve drain hose

1---1/2” airgap

brine tank overflow hose

Tie or wire valve drain hose in place, to keep over floor drain.

floor drain

NOTE: Faceplate and not shown for clarity of drawing.

floor drain

1. Close the shut off valve on the house main water pipe, near the water meter or pressure tank, to turn off the water.

2. Shut off the gas or electric supply to the water heater.

3. Open the highest and lowest water faucets in your house to let water drain from the pipes. Close faucets after water has drained. 4. If not already done, remove all cardboard or plastic packing pieces from inside the softener.

5

INSTALLATION (continued) -- (MODELS ESD 518 & ESD 2502R30) 5. INSTALL INLET AND OUTLET ADAPTORS, OR THE OPTIONAL BY VALVE.

7. Referring to page 5, run inlet and outlet pipes to the softener, observing all of the following notes. H

If the optional by valve is not used, be sure to use a three valve by as typically shown in Figure 1. Position in “by” only if needed for softener repairs. The by valve maintains continuity of the water supply when the softener is disconnected.

H

Be sure to plumb so HARD WATER flows TO the softener valve INLET.

H

If sweat soldering, first disconnect copper pipes from plastic softener parts. DO NOT SOLDER WITH COPPER CONNECTED TO THE SOFTENER OR PLASTIC PARTS WILL BE DAMAGED.

BY VALVE --- Push the by valve into the valve ports (can be inverted for connecting to floor level plumbing). Be sure the o---ring seals are lubricated with silicone grease or Vaseline.

H

If using threaded fittings, use extreme care not to cross thread onto plastic.

H

inlet and outlet plumbing in some manner, to keep the weight off of the softener valve.

SNAP THE TWO LARGE HOLDING CLIPS INTO PLACE, FROM THE TOP DOWN AS SHOWN. BE SURE THEY SNAP FIRMLY INTO PLACE, SO THE ADAPTORS, OR BY VALVE, DO NOT PULL OUT.

8. CONNECT THE VALVE DRAIN HOSE

IMPORTANT: Be sure the turbine, turbine and sensor housing are firmly in position, in or on the valve outlet.

H

INLET AND OUTLET ADAPTORS --- Push adaptors into the valve ports. Be sure the o---ring seals are lubricated with silicone grease or Vaseline. -- OR--

H

Attach a length of 3/8” I.D. hose to the valve drain fitting. Use a hose clamp to hold it in place. Place the other end of the hose over a floor drain, laundry tub, sump, standpipe or other suitable drain. BE SURE TO OBSERVE LOCAL CODES.

FIGURE 2

drain fitting

hose clamp

IMPORTANT NOTES: Leave an air gap of about 1---1/2” between the end of the hose and the drain. This gap is needed so you don’t get a back ---flow of sewer water into the softener. DO NOT put the end of the hose into the drain or connect without the air gap. Place and the hose so it does not kink or have sharp bends. Tie or wire the hose in place so water pressure will not make it “whip”. Do not pinch the hose shut. THE SOFTENER WILL NOT WORK IF THIS DRAIN HOSE IS PINCHED, PLUGGED OR CLOSED IN ANY WAY.

6. Move the softener into installation position, setting on a smooth and level surface. If needed, set it on a piece of 3/4” thick plywood (slightly larger than the bottom of the brine tank). Then shim under the plywood to level the softener.

Keep the hose lower than the drain fitting. In some homes, to get to a drain you must raise the hose and run it over head. If you need an overhead drain, do not raise the hose more than 8’ above the floor.

6

BRINE TANK ASSEMBLY -- (MODELS ESD 2502R30 & ESD 2502R39) Note: On some models, the factory may complete steps 1 and 2 below. 1. Locate the brinewell in position and secure with a screw and nut (from parts skin---pack).

FIGURE 3

nut

brinewell cover

compression nut

2. Lower the brine valve into the brinewell and install the brinewell cover.

brine tubing

3. Insert the grommet into the hole in the tank sidewall. Then, push the hose adaptor elbow into the grommet. brine tank

4. Continue with step 6., on page 8.

grommet elbow screw brine valve

brinewell

INSTALLATION -- (MODEL ESD 2502R39) BE SURE TO READ AND COMPLY WITH ALL GUIDES LISTED ON PAGE 3. 1. Install the installation adaptors, or the optional by valve (Figure 4). Be sure clips hold parts firmly in place. Pull on the adaptors or by valve to insure they are secure.

2. Run the hard water supply to the valve inlet, and conditioned water out from the valve outlet. CAUTION: Do all soldering, and allow to cool, before connecting pipe to the adaptors or by valve. 3. Install the ground clamp if cold water pipe ground continuity was interrupted.

Note: If the optional by valve is not used, be sure to install a 3---valve by (Figure 5). clip (2)

FIGURE 4

FIGURE 5

copper tubes (install in softener valve or by valve) OUTLET

By Valve

hard water to outside faucets

soft water

hard water INLET

clip (2)

Outlet Valve

by valve

Inlet Valve

GROUND CONTINUITY

OUT

ground clamp

IN

clip Soldered copper, threaded, or PVC plastic pipe and fittings. Plumb to copper tubes. Eliminate 3 valves shown above if using optional by.

to valve inlet from valve outlet

copper tube o--ring seal Valve Inlet

7

INSTALLATION (continued) -- (MODEL ESD 2502R39) 4. Run the valve and brine tank overflow drain hoses (Figure 6). Secure the valve drain hose to the drain fitting with the included hose clamp. Provide a minimum 1---1/2” air gap at the floor drain, standpipe, laundry tub, or other approved drain. If you need to elevate the valve drain hose to get to the drain point, do not raise more than 8’ above the floor. The gravity overflow hose must be lower than the drain fitting along the entire run.

FIGURE 6 compression nut screen brine tubing

nozzle assembly

brine tubing valve drain hose

Note: Flexible drain hose is not allowed by some state or local codes. A fitting (1/4” NPT x 1/2” O.D. tube, part no. 0504574) is available from EcoWater for adapting copper tubing to the valve drain fitting. 5. Route the brine valve tubing out of the brine tank and connect to the nozzle assembly. Use the small screen and compression nut included (on skin---pack) to fasten. 6. Connect the power cable to the transformer and plug into a 120V --- 60Hz electrical outlet.

WIRING SCHEMATIC

brine tank overflow hose

floor drain

1---1/2” airgap

7. Open nearby faucets and advance (use RCHG keypad) the softener valve to backwash position to vent air from the tank. Turn on the water supply and allow the softener to fill. When water at nearby faucets runs smooth, with no more air bubbles, close the faucets and advance the softener valve to ‘‘service’’.

BACK OF FACEPLATE TIMER

24V TRANSFORMER 120 V Power Source

8. Check your installation work for leaks. 9. Make all timer settings, page 9.

VALVE MOTOR

10. Sanitize the unit following procedures below, and use ‘‘Recharge Now’’ to start a recharge. brn POSITION SWITCH

11. Fill the brine tank with salt. You may use most water conditioner salts, but it must be clean. Recommended nugget, pellet or course solar salts have less than 1% impurities.

grn WATER METER SENSOR HOUSING

12. Install the brine tank cover.

DISINFECTING THE SOFTENER Care is taken at the factory to keep your softener clean and sanitary. Materials used to make the unit will not infect or contaminate your water supply, and will not cause bacteria to form or grow. However, during shipping, storage, installing and operating, bacteria could get into the unit. For this reason, sanitizing as follows is suggested when installing. 1. Use a pail or hose to fill the brine tank with about 3 gallons of water. 2. Remove the brinewell cover and pour about 1---1/2 oz. (2 to 3 tablespoons) of common household bleach into the softener brinewell. Clorox, Linco, BoPeep, White Sail, Eagle, etc. are brand names of bleach readily available. Replace the brinewell cover. 3. Start an automatic regeneration to draw the bleach into and through the softener, and to the drain. Note: When the sanitizing regeneration is over all remaining bleach is flushed from the system.

8

FIGURE 7

UP keypad

display

RECHARGE keypad

DOWN keypad

SELECT keypad

When the transformer is plugged in, a model code shows in the face plate display for the first few seconds. The model code for your water softener is S518, S30 OR H40, as shown in the following drawing. The model code is followed by a test number (example: J1.0). After the test number, 12:00 PM begins to flash. The words PRESENT TIME show in the display.

If the present time is between noon and midnight, be sure PM shows.

If the present time is between midnight and noon, be sure AM shows.

Model ESD 518

NOTE: Each press of the UP or DOWN keypads changes the time by 1 minute. Pressing and holding the keypads changes the time 32 minutes each second.

2. SET WATER HARDNESS NUMBER:

Model ESD 2502 R30

Press the SELECT keypad once to display 25 (flashing) and HARDNESS. Set the grains per gallon hardness of your water supply (determined by water analysis or call your local water department).

Model ESD 2502 R39

NOTE: If --- --- --- --- is flashing in the display, press the UP (↑) keypad (Figure 7) until the correct code shows, as needed for your model. Be sure to set the correct code. Then, press the SELECT keypad to display the flashing 12:00 PM. If other than the above codes show, when the transformer is first plugged in, please see page 13 to reset.

NOTE: If your water supply contains iron, compensate for it by adding to the water hardness number. For example, assume your water is 15 gpg hard and contains 2 ppm iron. Add 5 to the hardness number for each 1 ppm of iron. In this example, you would use 25 for your hardness number.

SOUND “BEEPER”: A “beeper” sounds while pressing keypads for timer set-up. One beep signals a change in the face plate display. Repeated beeps means the timer will not accept a change from the keypad you have pressed, telling you to use another keypad. For example, in setting the hardness (step 2), the beeper sounds repeatedly when the display reaches 1 using the DOWN keypad, or the highest hardness setting using the UP keypad.

2 ppm iron x 5 = 10 (times)

15 gpg hardness +10 25 HARDNESS NUMBER

Press the (↑) UP/DOWN (↓) keypads to set your water hardness number in the display. The DOWN keypad moves the display to 1. The UP keypad moves the display to the highest setting (see maximum setting for your model in the specifications).

NOTE: If the words PRESENT TIME do not show in the display, press the SELECT keypad (Figure 7) until they do.

NOTE: Each press of the UP/DOWN keypad changes the display by 1 between 1 and 25. Between 25 and the highest number, the display changes 5 at a time 25, 30, 35, etc. Continuous pressure on the UP or DOWN keypad changes the display twice each second.

Press the (↑) UP/DOWN (↓) keypads to set the present time. Press UP to move the display ahead; press DOWN to move the time backward.

NOTE: If using potassium chloride (KCl) instead of standard sodium chloride (NaCl) water softener salt, hardness setting must be increased by 25%.

1. SET PRESENT TIME OF DAY:

9

3. SET RECHARGE (REGENERATION) TIME:

NOTE: California regulations require the efficiency setting to be ON for sale in California.

Press the SELECT keypad once to display 2:00 AM (flashing) and RECHARGE TIME. At the 2:00 AM RECHARGE TIME setting, the softener begins regeneration at 2:00 AM, ending no later than 4:00 AM. This is a good time in most households because water is not being used.

NOTE: When efficiency setting is set to on, an icon will show in the upper right hand corner of the display. Press the SELECT button once to go to the backwash time setting.

If a different RECHARGE TIME setting would be better for your household, do the following.

NOTE: Factory default for this setting is 7 minutes.

Press the (↑) UP/DOWN (↓) keypads to set the desired RECHARGE starting hour. Be sure to observe the AM-PM as you did when setting the time of day.

Press the UP or DOWN button to set the desired backwash time.

NOTE: Each press of the UP/DOWN keypads changes the display 1 hour. Continuous pressure on the UP or DOWN keypad changes the display twice each second.

Press the SELECT button once to go to the rinse time setting. NOTE: Factory default for this setting is 3 minutes.

4. SET EFFICIENCY, BACKWASH TIME AND RINSE TIME:

Press the SELECT keypad once again, to return the present time (steady) of day.

Press and hold the SELECT button. “000--- ---’” should show in display. Press SELECT button once more to go to Efficiency screen. Press the UP or DOWN button to set the efficiency setting either on or off.

CALIFORNIA EFFICIENCY REQUIREMENT Your water softener has a “High Efficiency” feature with an “ON” or “OFF” setting. This softener setting is shipped in the “OFF” position, which utilizes the maximum rated capacity while most often achieving maximum salt efficiencies. When installing this unit in the State of California, you MUST turn this setting to the “ON” position which may initiate more frequent recharges, however it will operate at 4000 grains per pound of salt or higher. If you wish to turn the Salt Efficiency feature “ON” ( page.

icon will show in display), follow the instructions on this

10

EXTRA RECHARGE

play is flashing. The HARDNESS and RECHARGE TIME never require resetting unless a change is desired. Even if the timer is incorrect after a long power outage, the softener works as it should to keep your water soft. However, regenerations may occur at the wrong time of day until you reset the timer to the correct time of day.

Sometimes, a manually started regeneration (recharge) may be desired, or needed. Two examples are: . You have used more water than usual (guests visiting) and you may run out of soft water before the next timer started regeneration.

ERROR CODE

. You did not refill the softener with salt before it was gone.

An error code could appear in the face plate display if a problem occurs in the softener electronics.

You can start a regeneration right away, or you can set the timer to regenerate at the next 2:00 AM (or other preset recharge time). Do the following.

WATER METER:

RECHARGE NOW

The water meter, consisting of a turbine, turbine mounting assembly, and the sensor housing, is located at the valve outlet port. As water es through and spins the turbine, two magnets (in the turbine) cause a back --and---forth movement of a switch in the sensor housing. This switch movement sends a pulse to the electronic demand timer.

Press the RECHARGE keypad and hold for 3 seconds. RECHARGE NOW begins to flash in the display, and the softener enters the fill cycle of regeneration right away. This regeneration will last for about 2 hours. Then, you will have soft water again.

RECHARGE TONIGHT

ELECTRONIC DEMAND TIMER:

Press and release (do not hold) the RECHARGE keypad. RECHARGE TONIGHT flashes in the display, and the softener begins regeneration at the next preset recharge time. If you decide to cancel the regeneration before it has started, press and release the RECHARGE keypad once more to turn off the flashing RECHARGE TONIGHT.

The demand timer is actually a small computer. As it receives pulses from the water meter, it converts them to gallons of water ing through the water softener. It multiplies this water usage information times the water hardness (preprogrammed into timer) to continually calculate the soft water capacity required. The computer adjusts daily to water using habits, seeking to supply soft water for the longest time, using the least (and most efficient) amount of salt and water to regenerate. When the computer determines more capacity is needed, at the next regeneration starting time (2:00 a.m., or as otherwise preset), it will schedule a regeneration. RECHARGE TONIGHT shows in the display to inform of the coming regeneration.

PROGRAM MEMORY If electrical power to the softener goes off, the time display is blank but the face plate timer keeps the correct time for about 6 hours. When electrical power comes on again, you have to reset the present time only if the dis-

11

REFILLING WITH SALT

CLEANING THE NOZZLE AND VENTURI A clean nozzle and venturi (Figure 8) is a must for the EcoWater System Unit to work right. This small unit creates the suction to move brine from the brine tank, into the resin tank. If it should become plugged with sand, silt, dirt, etc., the EcoWater System Unit will not work, and you will get hard water. To get to the nozzle and venturi, remove the EcoWater System Unit top cover. Be sure the unit is in service cycle (no water pressure at nozzle and venturi). Then, holding the nozzle and venturi housing with one hand, turn off the cap. Do not lose the o ---ring seal. Lift out the screen and screen. Then, remove the nozzle and venturi. Wash the parts in warm, soapy water and rinse in fresh water. If needed, use a small brush to remove iron or dirt. Be careful not to scratch, misshape, etc., surfaces of the nozzle and venturi. Also, check and clean the gasket and flow plug(s) if dirty. Carefully replace all parts in the correct order. Lubricate the o---ring seal with silicone grease and locate in position. Install and tighten the cap, by hand only. Do not overtighten and break the cap or housing.

Remove the brine tank cover and check the salt storage level frequently. If the unit uses all the salt before you refill it, you will get hard water. Until you have established a refilling routine, check the salt every 2 or 3 weeks. ALWAYS refill if less than 1/2 full. Be sure the brinewell cover is on. RECOMMENDED SALT: Cube, pellet, coarse solar, etc., water conditioner salt is recommended. This type of salt is from high purity evaporated crystals, sometimes formed, or compressed, into briquets. It has less than 1% insoluble (will not dissolve in water) impurities. Clean, high grade rock salts are acceptable, but may require frequent brine tank cleaning to remove the ‘‘sludge’’ residue (insolubles). NOTE: If using potassium chloride (KCl) instead of standard sodium chloride (NaCl) water softener salt, hardness setting must be increased by 25%. SALT NOT RECOMMENDED: Rock salt, high in impurities, block, granulated, table, ice melting, ice cream making salts, etc., are not recommended.

FIGURE 8

SALT WITH IRON REMOVING ADDITIVES: Some salts have an additive to help a water conditioner handle iron in a water supply. Although this additive may help keep the resin bed clean, it may also release corrosive fumes that will weaken and shorten the life of some EcoWater System Unit parts.

BREAKING A SALT BRIDGE Sometimes, a hard crust or salt bridge forms in the brine tank. It is usually caused by high humidity or the wrong kind of salt. When the salt bridges, an empty space forms between the water and the salt. Then, salt will not dissolve in the water to make brine. Without brine, the resin bed does not regenerate and you will have hard water. If the storage tank is full of salt, it is hard to tell if you have a salt bridge. Salt is loose on top, but the bridge is under it. Take a broom handle, or like tool, and push it straight down into the salt. If a hard object is felt, it’s most likely a salt bridge. Carefully push into the bridge in several places to break it. NOTE: In humid areas, it is best to keep the salt storage level lower, and to refill more often.

12

RESIN BED CLEANING

FIGURE 9 plug distributor tube while adding resin

If the water supply contains ‘‘clear water ’’ iron (see page 9), regular resin bed cleaning is needed to keep the bed from coating with iron. Use resin bed cleaner, available from EcoWater, following directions on the container. Clean the resin every 6 months, or more often if iron appears in your conditioned water supply.

add resin

FREEBOARD

ADDING RESIN

resin tank bottom distributor tube resin bed

Normally, the resin bed (Figure 9) will last the lifetime of the EcoWater System Unit. However, certain conditions may require partial or total replacement of the resin bed. Some of these conditions are:

IMPORTANT NOTES: Turn off the water supply and relieve pressure.

(1) damaged top and/or bottom distributors have allowed resin to escape (2) resin bed iron fouled beyond use (3) some water supplies cause resin degradation

Handle the resin tank carefully. It is heavy when filled with resin and water. Do not lose o---ring seals or other small parts. Refer to the assembly instructions and to installation steps to reassemble and restart the unit.

To add more resin, or to replace the entire bed, use the following guides. See resin requirements on page 4.

CHECKING THE MODEL CODE ENTRY (See page 9) Unplug the transformer at the electrical outlet, then plug it in again. A “beep” will sound, then the model code displays for a few seconds. The test number will then display for a few seconds, followed by the present time display.

CHANGING THE MODEL CODE IMPORTANT: READ page 9 BEFORE CHANGING THIS CODE. 1. Enter the secondary mode...press SELECT and hold for 3 seconds. 2. Again, press SELECT and hold for 3 seconds. The current model code setting will be flashing. 3. Use the (↑) or (↓) keypad to display the desired model code. 4. Press SELECT to set. 5. Reset the timer (page 9) and reselect other desired options.

13

REPAIR PARTS -- ALL MODELS

Valve Assembly (see pages 16 --- 19 )

1

2 38 39 40

19 20 21 22

25

23

3

6

24 37

4 36 26

29

5 35

27

7

30

34 8

33

28

31 32

41 2 9

10

5

11

12

10 9

13

12

8

13

14

16 14

15 16

17

11

18

15

17

14

REPAIR PARTS -- ALL MODELS KEY NO.

PART NO.

KEY NO.

PART NO.

1

7252373

2

7218662

Transformer, 24V--- 10VA

23

7105047

Repl. Distributor (bottom)

Top Cover (ESD 518)

24

7176292

Clamp Section, 2 req.

7218670

Top Cover (ESD 2502 models)

25

7088033

Clamp Retainer, 2 req.

26

7114787

Resin Tank, 8” dia. x 35”, ESD 518

7113058

Resin Tank, 8” dia. x 40”, ESD 2502R30

7092202

Resin Tank, 10” dia. x 47”, ESD 2502R39

0502272

Resin, 1 cu ft (stand. mesh)

DESCRIPTION

DESCRIPTION

3

7210509

Faceplate (order following decal)

---

7214692

Decal

4

7238418

Repl. PWA

5

7211173

Faceplate

6

7210389

Salt Hole Cover (ESD 518)

0501741

Resin, 1/2 cu ft (stand. mesh)

7

7214244

Vapor Barrier (ESD 518)

28

1184700

Spacer (ESD 518, ESD 2502R30)

8

7210397

Rim (ESD 518)

29

7113008

Float, Stem and Guide Assem.

7210460

Rim (ESD 2502 models)

30

7170288

O --- ring, 15/16” x 1--- 3/16”

27

9

7155115

Brinewell Cover

31

1205500

Clip

10

7219595

Washer

32

7092252

Brine Valve Body

11

7109871

Brinewell

33

7080653

Clip

12

9003500

Grommet

34

7131365

Screen

13

1103200

Hose Adaptor

35

7113016

Tubing Assembly, BV

14

0900431

Hose Clamp

36

7095470

Brine Tube

15

7219587

Screw

37

7171349

Screen

16

7218604

Brine Tank (ESD 518)

38

9003201

Nut--- Ferrule, 2 req. =

7218612

Brine Tank (ESD 2502 models)

39

7161807

Tubing, 20 ft =

17

7141205

Tank Base

---

7161768

Tubing, 100 ft

18

7218620

Resin Tank Sleever (ESD 2502R30)

40

7094987

Union Connector =

7218646

Resin Tank Sleever (ESD 2502R39)

41

7210486

Brine Tank Cover (ESD 2502 models)

19

7170296

O --- ring Seal, 2--- 7/8” x 3--- 1/4”

J

7116488

Brine Valve Asm (incl. Key Nos. 29 --- 36)

20

7170254

O --- ring, 13/16” x 1--- 1/16”

J

7108118

Hose, 1/2” I.D. Drain (order length needed)

21

7077870

Top Distributor

22

7170270

O --- ring, 2--- 3/4” x 3”

= optional parts to extend brine tubing (not included) J Not shown.

15

REPAIR PARTS -- ESD 518 & ESD 2502R30

1 2 50 49

3

48

4

47

51

5 6 7 52

8

46 42 41

11 12

45

40

10 9 18

17

13

39

14

44

15

38

19

16

37

20

36

22

43

35

21

23 wear--- strip

24 25 31

seal cross--- section view

26

34

27 33

28

30 32 29

16

REPAIR PARTS -- ESD 518 & ESD 2502R30 KEY NO.

PART NO.

1

7224087

KEY NO.

PART NO.

Screw, #8-32 x 1” (2 req.)

31

7081201

Retainer (Nozzle & Venturi)

7170319

O-Ring, 1/4 x 3/8 (2 req.)

DESCRIPTION

DESCRIPTION

2

7228544

Motor (incl. 2 ea. of Key No. 1)

32

3

0900857

Screw, #6-20 x 3/8 (2 req.)

33

7081104

Nozzle & Venturi Housing

4

7231385

Motor Plate

34

1202600

Nut - Ferrule

5

0503288

Bearing

35

7095030

Cone Screen

6

7113927

Cam and Gear

36

1148800

Flow Plug, .3 gpm

7

7142942

Clip (Drain)

37

7147706

Nozzle & Venturi Gasket Kit (ESD 518)

8

0900431

Tubing Clamp

9

7024160

Drain Hose Adaptor

10

7170327

7248007

Nozzle & Venturi Gasket Kit (ESD 2502R30)

---

7204362

Gasket (only) (ESD 518)

O-Ring, 5/8 x 13/16

---

7190547

Gasket (only) (ESD 2502R30)

0521829

Flow Plug, .1 gpm

11

0501228

Flow Plug

38

12

7170238

O-Ring, 7/16 x 5/8

39

7146043

Screen

7167659

Screen

13

7170212

O-Ring, 3/4 x 15/16

40

14

7082087

Wave Washer

41

7170262

O-Ring, 1--- 1/8” x 1--- 3/8”

7199729

Cap1

15

7199232

Rotor & Disc

42

16

7170246

O-Ring, 3--- 3/8 x 3-5/8

43

0900060

O-Ring

17

7116713

Clip (2 req.)

44

7235371

Sensor Housing & Wiring Harness

18

0507369

Installation Nut (2 req.)

45

7085263

Valve Cover

19

0507615

Installation Tube (2 req.)

46

7074123

Screw, #10-14 x 2 (5 req.)

20

7170335

Washer (2 req.)

47

7077472

Expansion Pin

21

2207800

Installation Adaptor (2 req.) (incl. 2 ea. of Key No. 22)

48

7030713

Switch

49

7117816

Spacer

50

7070412

Screw, #4-24 x 1-1/8 (flat head)

51

7248706

Ground Clamp

52

7129871

By Valve (optional)

z

7214969

Nozzle & Venturi Assy. (incl. Key Nos. 33, & 35 --- 42)

z

7129716

Seal Kit (incl. Key Nos. 12, 13, 16, 23, 24 & 30)

22

7170288

O-Ring, 15/16 x 1-3/16 (2 req.)

23

7134224

Rotor Seal

24

7170204

O-Ring, 3/8 x 9/16

25

7092642

Plug (Drain Seal)

26

7129889

Spring

27

2204101

Turbine and Shaft

28

7117858

Turbine

29

7082053

Valve Body

30

7081764

Seal (Nozzle & Venturi)

z Not shown.

17

REPAIR PARTS -- ESD 2502 R39 1 2 46

3

45

4

44

5 6

47

7 8 43 48 41

11

42 40

13

seal

38

9

12

wear--- strip

39

10

14

cross--- section view

15

37 26

16

36

21

17

35 34 18 19 20

27 28

22 33

23

32

24

29 31

25

30

18

REPAIR PARTS -- ESD 2502 R39 KEY NO.

PART NO.

1

7224087

2

7228544

3

KEY NO.

PART NO.

Screw, #8-32 x 1” (2 req.)

27

0900060

O-ring

Motor (incl. 2 ea. of Key No. 1)

28

7081201

Retainer (Nozzle & Venturi)

7231393

Motor Plate

29

7195482

Seal (Nozzle & Venturi)

4

0900857

Screw, #6-20 x 3/8 (3 req.)

30

7171145

Valve Body

5

7171250

Bearing

31

7170319

O-ring, 1/4 x 3/8 (2 req.)

6

7219545

Cam and Gear

32

7081104

Nozzle & Venturi Housing

7

7169180

Clip (Drain)

33

1202600

Nut - Ferrule

8

0900431

Hose Clamp

34

7095030

Cone Screen

9

7271270

Drain Hose Adaptor

35

1148800

Flow Plug, .3 gpm

10

7170288

O-ring, 15/16 x 1-3/16

36

7114533

Nozzle and Venturi - Gasket Kit

11

0501228

Flow Plug, 2.0 gpm

12

7170327

O-ring, 5/8 x 13/16

---

7204362

Gasket only

13

7173024

O-ring, 1-1/8 x 1-1/2

37

7084607

Flow Plug, .15 gpm

14

7174313

Bearing, Wave Washer

38

7146043

Screen

15

7185500

Rotor & Disc

39

7167659

Screen

16

7173032

O-ring, 4-1/2 x 4-7/8

40

7170262

O-ring, 1-1/8 x 1-3/8

17

7185495

Rotor Seal

41

7199729

Cap

18

7172989

Seal

42

7175199

Wave Washer

19

7171187

Plug (Drain Seal)

43

7171161

Valve Cover

20

7129889

Spring

44

7172997

Screw, #10 x 2-5/8 (8 req.)

7145186

Switch

DESCRIPTION

DESCRIPTION

21

7089306

Clip (2 req.)

45

22

7077642

Copper Tube, 1” (2 req.)

46

7140738

Screw, #4-24 x 3/4 (2 req.)

7248706

Ground Clamp

23

7170262

O-ring, 1-1/8 x 1-3/8 (4 req.)

47

24

7094898

Turbine

48

7214383

By Valve (optional)

25

7101548

Turbine

◆

7253808

26

7248722

Wire Harness (Sensor)

Nozzle & Venturi Asm (incl. Key Nos. 32, & 34 --41)

◆

7185487

Seal Kit (incl. Key Nos. 12, 13, 16, 17, 18 & 29)

◆ not illustrated

19
