GA16DE ECU PINOUT Enviado por valvulita el Jue, 01/31/2013 - 20:38

* When the wire color is striped, the base color is given first, followed by the stripe color. i.e L/W = Blue with White Stripe B = Black

BR = Brown

W = White

OR = Orange

R = Red

P = Pink

G = Green

PU = Purple

L = Blue

GY = Gray

Y = Yellow

SB = Sky Blue

LG = Light Green

CH = Dark Brown DG = Dark Green

Pin

Wire

Description

Related Pins

101

SB

(ISC -O) Idle Air Control Valve (IACV) Auxiliary Air Control (AAC) Open

102

R/B

(INJ #1) Injector No. 1

103

P

(EGR) EGR Valve and EVAP Canister Purge Valve

104

G/B

(INJ #3) Injector No. 3

102,107,109

106

B/Y

(GND -E) ECCS Ground (Engine Ground)

39,43,10,19,112,118

107

Y/B

(INJ #2) Injector No. 2

102,104,109

L/B

(INJ #4) Injector No. 4

102,107,104

B/Y

(GND -E) ECCS Ground (Engine Ground)

39,43,10,19,106,118

114

Y/R

(VTC) Valve Timing Control Valve

115

OR

(O2H) Heated Oxygen Sensor (A/T models ONLY)

107,104,109

105

108 109 110 111 112 113

116

46

117 118

B/Y

(GND -E) ECCS Ground (Engine Ground)

39,43,10,19,106,112

1

W/B

(IGN) Ignition Signal

2

2

GY/R

(IGN CK) Ignition Signal

1

3

L/B

(TACH) Tachometer

4

W/G

(SSOFF) ECCS Self Shut Off

B/P

(FPR) Fuel Pump Relay

B/W

(GND -I) ECCS Ground (Engine Ground)

39,43,19,106,112,118

13

LG

(RFRH) Cooling Fan Relay-2

14

14

LG/R

(RFRL) Cooling Fan Relay-1

13

15

Y

(ACRLY) Air Conditioner Relay

21

18

OR/L

(LED-R) Malfunction Indicator Lamp

64,65,68

19

B/W

(GND -I) ECCS Ground (Engine Ground)

39,43,10,106,112,118

20

B/Y

(STSW) Start Signal

21

G

(ARCON) Air Conditioner Switch

22

G/OR

(NEUT) Park/Neutral Position Switch

23

Y

(TVO -1) Throttle Position Sensor

25

PU/W

(PWST) Power Steering Oil Pressure Switch

26

PU/R

(VSP) Vehicle Speed Sensor

P/B

(LKUP)(A/T models) Torque Converter Clutch Solenoid Valve

5 6 7 8 9 10 11 12

16 17

24

27 28 29 30 31 32

15

49,50

33 34 35

LG/B

(H/FAN) Blower Fan Electrical Load Signal

38

B/R

(IGN SW) Ignition Switch

39

B

(GND -C) ECCS Ground (Engine Ground)

43,10,19,106,112,118

40

L

(REF) Camshaft Position Sensor

44

41

B/W

(POS) Camshaft Position Sensor

45

42

PU/W

(ISC -C) Idle Air Control Valve (IACV) Auxiliary Air Control (AAC) Close

101

43

B

(GND -C) ECCS Ground

39,10,19,106,112,118

44

L

(REF) Camshaft Position Sensor

40

45

B/W

(POS) Camshaft Position Sensor

41

46

W

(O2S) (Oxygen Sensor M/T models) (Heated Oxygen Sensor A/T models)

115

47

OR

(QA+) Mass Air Flow Sensor

48

48

W

(QA-) Mass Air Flow Sensor Ground

47

49

P/L

(AVCC) Throttle Position Sensor Power Supply

23,50

50

B

(GND -A) Sensors Ground

51

BR/Y

(TW) Engine Coolant Temperature Sensor

54

W

(KNK) Knock Sensor

55

L/R

(R/DEF) Rear Defogger Relay Electrical Load Signal

60,35

56

W/R

(VB) ECM Power supply

4,61,40,44,41

60

R/G

(H/LMP) Headlamp Switch Electrical Load Signal

55,35

61

W/R

(VB) ECM Power supply

4,56

63

R/Y

(TA) Intake Air Temperature Sensor

50

64

G/B

(SCI RX) Data Link Connector

65,68

65

GY/L

(SCI TX) Data Link Connector

64,68

36 37

50

52 53

57 58 59

62

66

67 68

G/W

(SCI CL) Data Link Connector

64,65

W/L

(BATT) Power Supply (Backup-up)

4,56,61

69 70

        
