Foscam IPCamera CGI Guide

Foscam IPCamera CGI Guide

Copyright@ Shenzhen Foscam Intelligent Technology Limited

1

Foscam IPCamera CGI Guide

Contents 1. General description....................................................................................................................12 2. All Platform CGI..........................................................................................................................13 AV Function...............................................................................................................................13 getImageSetting.................................................................................................................13 setBrightness..................................................................................................................... 13 setContrast.........................................................................................................................13 setHue................................................................................................................................14 setSaturation...................................................................................................................... 14 setSharpness...................................................................................................................... 14 setDenoiseLevel (not use).................................................................................................14 resetImageSetting..............................................................................................................15 getMirrorAndFlipSetting.................................................................................................. 15 mirrorVideo....................................................................................................................... 15 flipVideo............................................................................................................................16 getRatio............................................................................................................................. 16 setRatio..............................................................................................................................16 getH264FrmRefMode....................................................................................................... 17 setH264FrmRefMode........................................................................................................17 getScheduleRecordStreamChn......................................................................................... 17 setScheduleRecordStreamChn.......................................................................................... 18 setPwrFreq.........................................................................................................................18 getVideoStreamParam.......................................................................................................18 setVideoStreamParam....................................................................................................... 19 getSubVideoStreamParam................................................................................................ 19 setSubVideoStreamParam.................................................................................................20 getMainVideoStreamType.................................................................................................20 getSubVideoStreamType...................................................................................................20 setMainVideoStreamType................................................................................................. 21 setSubStreamFormat......................................................................................................... 21 GetMJStream.....................................................................................................................21 getOSDSetting...................................................................................................................22 setOSDSetting................................................................................................................... 22 getOsdMaskArea...............................................................................................................23 setOsdMaskArea............................................................................................................... 23 getOSDMask..................................................................................................................... 24 setOSDMask......................................................................................................................24 getMotionDetectConfig.................................................................................................... 24 setMotionDetectConfig.....................................................................................................25 setLocalAlarmRecordConfig............................................................................................ 27 getLocalAlarmRecordConfig............................................................................................27 getSnapConfig...................................................................................................................28 setSnapConfig................................................................................................................... 28 getScheduleSnapConfig.................................................................................................... 29 Copyright@ Shenzhen Foscam Intelligent Technology Limited

2

Foscam IPCamera CGI Guide

setScheduleSnapConfig.................................................................................................... 29 snapPicture........................................................................................................................ 30 snapPicture2...................................................................................................................... 30 getRecordList.................................................................................................................... 30 getRecordList2.................................................................................................................. 31 reloadRecordindex............................................................................................................ 31 getAlarmRecordConfig.....................................................................................................32 setAlarmRecordConfig..................................................................................................... 32 getRecordPath................................................................................................................... 32 setRecordPath....................................................................................................................33 getScheduleRecordConfig................................................................................................ 33 setScheduleRecordConfig.................................................................................................34 setIOAlarmConfig.............................................................................................................35 getIOAlarmConfig............................................................................................................ 35 clearIOAlarmOutput......................................................................................................... 36 setAudioAlarmConfig....................................................................................................... 36 getAudioAlarmConfig...................................................................................................... 37 setPCAudioAlarmCfg....................................................................................................... 37 getPCAudioAlarmCfg.......................................................................................................37 getMultiDevList................................................................................................................ 38 getMultiDevDetailInfo......................................................................................................38 addMultiDev......................................................................................................................38 delMultiDev...................................................................................................................... 39 setDeFrameLevel.............................................................................................................. 39 getDeFrameLevel..............................................................................................................39 .............................................................................................................................. 40 add........................................................................................................................40 del........................................................................................................................ 40 get.......................................................................................................................41 change................................................................................................................ 41 changeName.............................................................................................................. 41 changeNameAndPwdTogether.................................................................................. 42 ...................................................................................................................................42 ................................................................................................................................43 getSessionList................................................................................................................... 43 getList........................................................................................................................ 43 usrBeatHeart......................................................................................................................44 PTZ Control...............................................................................................................................44 ptzMoveUp........................................................................................................................44 ptzMoveDown...................................................................................................................44 ptzMoveLeft...................................................................................................................... 45 ptzMoveRight....................................................................................................................45 ptzMoveTopLeft................................................................................................................45 ptzMoveTopRight..............................................................................................................46 Copyright@ Shenzhen Foscam Intelligent Technology Limited

3

Foscam IPCamera CGI Guide

ptzMoveBottomLeft..........................................................................................................46 ptzMoveBottomRight........................................................................................................46 ptzStopRun........................................................................................................................ 46 ptzReset............................................................................................................................. 47 getPTZSpeed..................................................................................................................... 47 setPTZSpeed......................................................................................................................47 getPTZPresetPointList...................................................................................................... 48 ptzAddPresetPoint.............................................................................................................48 ptzDeletePresetPoint......................................................................................................... 48 ptzGotoPresetPoint............................................................................................................49 ptzGetCruiseMapList........................................................................................................ 49 ptzGetCruiseMapInfo........................................................................................................49 ptzSetCruiseMap............................................................................................................... 50 ptzDelCruiseMap.............................................................................................................. 50 ptzStartCruise.................................................................................................................... 50 ptzStopCruise.................................................................................................................... 51 setCruiseTime....................................................................................................................51 getCruiseTime................................................................................................................... 51 setCruiseTimeCustomed................................................................................................... 51 getCruiseTimeCustomed...................................................................................................52 setCruiseLoopCnt..............................................................................................................52 getCruiseLoopCnt............................................................................................................. 52 setCruiseCtrlMode............................................................................................................ 53 getCruiseCtrlMode............................................................................................................53 setCruisePrePointLingerTime........................................................................................... 53 getCruisePrePointLingerTime...........................................................................................53 zoomIn...............................................................................................................................54 zoomOut............................................................................................................................ 54 zoomStop...........................................................................................................................54 getZoomSpeed...................................................................................................................55 setZoomSpeed................................................................................................................... 55 setPTZSelfTestMode.........................................................................................................55 getPTZSelfTestMode........................................................................................................ 56 setPTZPrePointForSelfTest...............................................................................................56 getPTZPrePointForSelfTest.............................................................................................. 56 set485Info..........................................................................................................................57 get485Info......................................................................................................................... 57 Network..................................................................................................................................... 58 getIPInfo............................................................................................................................58 setIpInfo............................................................................................................................ 58 refreshWifiList.................................................................................................................. 59 getWifiList.........................................................................................................................59 setWifiSetting....................................................................................................................59 getWifiConfig....................................................................................................................61 Copyright@ Shenzhen Foscam Intelligent Technology Limited

4

Foscam IPCamera CGI Guide

getPortInfo.........................................................................................................................62 setPortInfo......................................................................................................................... 62 getUPnPConfig................................................................................................................. 62 setUPnPConfig.................................................................................................................. 63 getDDNSConfig................................................................................................................63 setDDNSConfig................................................................................................................ 64 setFtpConfig...................................................................................................................... 64 getFtpConfig......................................................................................................................65 testFtpServer......................................................................................................................65 getSMTPConfig................................................................................................................ 65 setSMTPConfig.................................................................................................................66 smtpTest.............................................................................................................................67 setP2PEnable.....................................................................................................................67 getP2PEnable.................................................................................................................... 68 setP2PPort......................................................................................................................... 68 getP2PPort.........................................................................................................................68 getP2PInfo.........................................................................................................................68 getPPPoEConfig................................................................................................................69 setPPPoEConfig................................................................................................................ 69 Device manage.......................................................................................................................... 69 setSystemTime.................................................................................................................. 69 getSystemTime..................................................................................................................70 openInfraLed..................................................................................................................... 71 closeInfraLed.....................................................................................................................71 getInfraLedConfig.............................................................................................................72 setInfraLedConfig............................................................................................................. 72 getScheduleInfraLedConfig.............................................................................................. 72 setScheduleInfraLedConfig.............................................................................................. 73 getDevState....................................................................................................................... 73 getDevName......................................................................................................................74 setDevName...................................................................................................................... 74 getDevInfo.........................................................................................................................75 getProductModel............................................................................................................... 75 getProductModelName..................................................................................................... 76 getProductLanguage..........................................................................................................76 getProductSensorType.......................................................................................................76 getProductWifiType.......................................................................................................... 76 getProductSdFlag.............................................................................................................. 77 getProductOutdoorFlag.....................................................................................................77 getProductPtFlag............................................................................................................... 77 getProductZoomFlag.........................................................................................................78 getProductRs485Flag........................................................................................................ 78 getProductIoAlarmFlag.....................................................................................................78 getProductOnvifFlag......................................................................................................... 78 Copyright@ Shenzhen Foscam Intelligent Technology Limited

5

Foscam IPCamera CGI Guide

getProductP2pFlag............................................................................................................ 79 getProductWpsFlag........................................................................................................... 79 getProductAudioFlag........................................................................................................ 79 getProductTalkFlag........................................................................................................... 80 getProductAppVer............................................................................................................. 80 getProductAllInfo..............................................................................................................80 getGeneratePubKey...........................................................................................................81 toolRestoreToFactory........................................................................................................81 System....................................................................................................................................... 82 rebootSystem.....................................................................................................................82 restoreToFactorySetting.................................................................................................... 82 exportConfig......................................................................................................................82 ImportConfig.....................................................................................................................83 FwUpgrade........................................................................................................................ 83 removePatch...................................................................................................................... 84 MISC......................................................................................................................................... 84 getFirewallConfig............................................................................................................. 84 setFirewallConfig..............................................................................................................84 getLog................................................................................................................................85 3. FosBaby+FosBaby_P1+Fosbaby_Baidu add cgi......................................................................... 85 getAudioVolume................................................................................................................85 setAudioVolume................................................................................................................ 85 getWifiMode..................................................................................................................... 86 getTemperatureAlarmConfig............................................................................................ 86 setTemperatureAlarmConfig.............................................................................................87 getTemperatureState..........................................................................................................87 Music......................................................................................................................................... 88 setMusicDefaultListRefresh..............................................................................................88 getMusicListsName...........................................................................................................88 getMusicsNameOfList...................................................................................................... 88 addMusicList.....................................................................................................................89 delMusicList......................................................................................................................90 setMusilayMode............................................................................................................91 getMusilayMode........................................................................................................... 91 setMusilayNext............................................................................................................. 91 setMusilayPre................................................................................................................92 getMusilayState.............................................................................................................92 setMusilayStart..............................................................................................................93 setMusilayStop..............................................................................................................93 setMusicDormantTime......................................................................................................93 getMusicDormantTime..................................................................................................... 94 Cloud......................................................................................................................................... 94 getCloudConfig................................................................................................................. 94 setCloudConfig................................................................................................................. 95 Copyright@ Shenzhen Foscam Intelligent Technology Limited

6

Foscam IPCamera CGI Guide

selectCloudServer............................................................................................................. 95 getCloudToken.................................................................................................................. 95 getCloudQuota.................................................................................................................. 96 testCloudServer................................................................................................................. 96 getPushConfig................................................................................................................... 97 setPushConfig................................................................................................................... 97 testPushServer................................................................................................................... 97 pushOperate.......................................................................................................................98 SetOnlineUpgrade............................................................................................................. 98 4. FosBaby_Baidu CGI(Only).......................................................................................................... 99 getBaiduRtmp....................................................................................................................99 setBaiduRtmp.................................................................................................................. 100 GetOnlineUpgradeState.................................................................................................. 101 5. FosBaby_P1 CGI(Only)..............................................................................................................101 getHumidityAlarmConfig............................................................................................... 101 setHumidityAlarmConfig................................................................................................102 getHumidityState.............................................................................................................103 setNightLightState...........................................................................................................103 getNightLightState.......................................................................................................... 103 setOneKeyAlarmConfig..................................................................................................103 getOneKeyAlarmConfig................................................................................................. 104 getTimingRebootConfig................................................................................................. 104 SetTimingRebootConfig................................................................................................. 105 getHumidityAlarmConfig.................................................................错误！未定义书签。 setHumidityAlarmConfig................................................................. 错误！未定义书签。 getHumidityState.............................................................................. 错误！未定义书签。 6. 3518E+Fosbaby+Fosbaby_P1+Fosbaby_Baidu.........................................................................105 getSoftApConfig............................................................................................................. 105 setSoftApConfig..............................................................................................................106 changeNetMode.............................................................................................................. 106 7. Fosbaby_P1+3518E.................................................................................................................... 107 setLedEnableState........................................................................................................... 109 getLedEnableState...........................................................................................................109 8. Amba S2L(Only)......................................................................................................................... 110 getHdrMode.....................................................................................................................110 setHdrMode..................................................................................................................... 110 getWdrMode....................................................................................................................110 setWdrMode.................................................................................................................... 111 getVideoStreamParam..................................................................................................... 111 setVideoStreamParam..................................................................................................... 111 getSubVideoStreamParam...............................................................................................112 setSubVideoStreamParam............................................................................................... 112 getMotionDetectConfig1.................................................................................................113 setMotionDetectConfig1................................................................................................. 114 Copyright@ Shenzhen Foscam Intelligent Technology Limited

7

Foscam IPCamera CGI Guide

History Ver

Auth

Edit date

Changes

1.0.0

XiaoJinsheng

2012-11-21

V1.0.0

1.0.1

Houzhen

2012-12-09

Add the following CGI command to set PT startup position: 1) setPTZSelfTestMode 2) getPTZSelfTestMode 3) setPTZPrePointForSelfTest 4) getPTZPrePointForSelfTest

1.0.2

XiaoJinsheng

2013-01-29

1. Add a snap CGI(snapPicture2) which retrun jpeg image data directly but a image url 2. Add MotionJpeg stream

1.0.3

Houzhen

2013-6-5

Check

and

Modify

CGI

command

document 1.0.4

Limaike

2013-6-8

CGI command check

1.0.5

Houzhen

2013-9-25

1.Add note for GetMJStream, defects of Firefox; 2.Modify Command: setContrast、mirrorVideo、flipVideo、、 setSnapConfig

、

setPTZSpeed

、

setInfraLedConfig 、 setSubStreamFormat 、 setPortInfo、getPortInfo； 3.Add command: getLocalAlarmRecordConfig

；

setLocalAlarmRecordConfig； getP2PEnable ； setP2PEnable ； getP2PPort ； setP2PPort ； setOSDMask ； getOSDMask ； getScheduleSnapConfig

；

setScheduleSnapConfig； 1.0.6

Houzhen

2013-12-12

1.Add command: -changeNameAndPwdTogether； -getPCAudioAlarmCfg； -setPCAudioAlarmCfg； -setH264FrmRefMode； -getH264FrmRefMode； -setCruiseTime； -getCruiseTime；

Copyright@ Shenzhen Foscam Intelligent Technology Limited

8

Foscam IPCamera CGI Guide

-setSubVideoStreamParam； -getSubVideoStreamParam； -setCruiseTimeCustomed； -getCruiseTimeCustomed； -setCruiseLoopCnt； -getCruiseLoopCnt； -setCruiseCtrlMode； -getCruiseCtrlMode； -setCruisePrePointLingerTime； -getCruisePrePointLingerTime； -getScheduleRecordStreamChn； -setScheduleRecordStreamChn； -getProductModel； -getProductModelName； -getProductLanguage； -getProductSensorType； -getProductWifiType； -getProductSdFlag； -getProductOutdoorFlag； -getProductPtFlag； -getProductZoomFlag； -getProductRs485Flag； -getProductIoAlarmFlag； -getProductOnvifFlag; -getProductP2pFlag; -getProductWpsFlag; -getProductAudioFlag; -getProductTalkFlag; -getProductAppVer; -getProductAllInfo; -getGeneratePubKey; -toolResetToFactory; -setScheduleInfraLedConfig; -getScheduleInfraLedConfig; 2.Modify error code-5、-7; 1.0.7

Houzhen

2013-12-14

Modify Command: 1.The usage of command-setSubStreamFormat, getSnapConfig, setSnapConfig.

Copyright@ Shenzhen Foscam Intelligent Technology Limited

9

Foscam IPCamera CGI Guide

2.The

example

and

description

of

command-setMotionDetectConfig, setScheduleSnapConfig, setIOAlarmConfig 1.0.8

Houzhen

2014-1-17

1.Add commmad: getRecordList2,reloadRecordindex

1.0.9

Houzhen

2014-3-15

1.Add command: getRatio, setRatio 2.Modify command: 1) The example of command: setCruisePrePointLingerTime, getCruisePrePointLingerTime. 2) The return discription of command: getProductWpsFlag. 3）The Param of command:smtpTest.

1.0.10

Houzhen

2014-4-2

1.Add commmad:getPPPoEConfig, setPPPoEConfig,getRecordPath,getScheduleRe cordConfig,getP2PInfo; 2.Modify the priviage of command for security: change,changeName,change NameAndPwdTogether,getSessionList,get List,getImageSetting,getMirrorAndFlipSetting, getMotionDetectConfig,getScheduleSnapConfi g,getVideoStreamParam,getSubVideoStreamPa ram,getMainVideoStreamType,getSubVideoStr eamType,getH264FrmRefMode,getSnapConfig ,getOsdMaskArea,getOSDSetting,getOSDMas k,getPTZSpeed,get485Info,getPTZPresetPoint List,ptzGetCruiseMapList,ptzGetCruiseMapInf o,getPTZSelfTestMode,getPTZPrePointForSelf Test,getCruiseTime,getCruiseTimeCustomed,g etCruiseLoopCnt,getCruiseCtrlMode,getCruise PrePointLingerTime,getZoomSpeed,getSMTP Config,getIPInfo,getPortInfo,getUPnPConfig,g etDevInfo,getDevName,getFirewallConfig,getS ystemTime,getFtpConfig,testFtpServer,getDD NSConfig,getLog,getRecordList,getRecordList 2,reloadRecordindex,getScheduleRecordStrea mChn,getAlarmRecordConfig,getLocalAlarmR

Copyright@ Shenzhen Foscam Intelligent Technology Limited

10

Foscam IPCamera CGI Guide

ecordConfig,getPCAudioAlarmCfg,getIOAlar mConfig,getDevState,getInfraLedConfig,getSc heduleInfraLedConfig,getP2PEnable,getP2PPo rt 1.0.11

Houzhen

2014-6-27

1.Add command: getDeFrameLevel, setDeFrameLevel

1.0.12

Houzhen

2014-7-9

1.Modify： 1) The parameter description of command setContrast.

1.0.13

PengMengjia

2014-11-24

integrate the CGI on all platforms and add new command

1.0.14

LeeJunliang

2015-5-10

1.Del command: 1)setMusilayPath,getMusilayPath 2.Modify command: 1)getMotionDetectConfig,setMotionDetectCon fig,setIOAlarmConfig,getIOAlarmConfig,getTe mperatureAlarmConfig.setTemperatureAlarmC onfig,getHumidityAlarmConfig,setHumidityAl armConfig,addMusicList,delMusicList

1.0.15

ZhangWei

2015-6-9

Add command of amba platform: getHdrMode,setHdrMode,getWdrMode,setWdr Mode,getVideoStreamParam,setVideoStreamPa ram,getSubVideoStreamParam,setSubStreamPa ram,getMotionDetectConfig1,setMotionDetecC onfig1

1.0.16

PengMengjia

2015-10-12

Add command: setFoscamRtmp;getFoscamRtmp;setSnapToFtp FilenameConfig;getSnapToFtpFilenameConfig; getCloudStreamLeve;setCloudStreamLevel

This document is for latest version.if you use this document for develop, your camera’s version must be latest.

Copyright@ Shenzhen Foscam Intelligent Technology Limited

11

Foscam IPCamera CGI Guide

1. General description  Our device can only authentication by name or attached at CGI request string currentlly. For example: https://xxxxxx.myfoscam.org:443/cgi-bin/CGIProxy.fcgi&usr=&pwd=123&cmd= ABC  We only GET and POST method. Only importConfig and fwUpgrade can POST method.  The cgi request string must be encode in url format. URL encode rule: The following chars will not be encoded: [A~Z] [a~z] [0~9] + @ * / The other chars will be encoded into hex format. For example: https://xxxxxx.myfoscam.org:443/cgi-bin/CGIProxy.fcgi?usr=&pwd=&cmd=getIPInfo

will be encode to: https://xxxxxx.myfoscam.org:443/cgi-bin/CGIProxy.fcgi?usr%3D%26pwd%3D%26cmd%3DgetIPInfo

 cgi execute result 1) We orgnize the cgi execute result as xml format, for example: 0 1 192.168.1.8 0.0.0.0 <mask>255.255.255.0 0.0.0.0 0.0.0.0 means the common execute result value

mean

0

Success

-1

CGI request string format error

-2

name or error

-3

Access deny

-4

CGI execute fail

-5

Timeout

-6

Reserve

-7

Unknown error

-8

Reserve

Copyright@ Shenzhen Foscam Intelligent Technology Limited

12

Foscam IPCamera CGI Guide

2. All Platform CGI AV Function getImageSetting Function

Get color attribute of video

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=getImageSetting

Param

None brightness

0~100

contrast

0~100

hue

0~100

saturation

0~100

sharpness

0~100

denoiseLevel

Not use

Return

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=getImageSetting&usr=&pwd=

setBrightness Function

Set brightness of video

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setBrightness

Param

brightness

Return

None

0~100

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=setBrightness&brightness=50&usr=&pwd=

setContrast Function

Set contrast of video

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setContrast

Param

constrast

0~100

Copyright@ Shenzhen Foscam Intelligent Technology Limited

13

Foscam IPCamera CGI Guide

Return

None

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=setContrast&constrast=50&usr=&pwd=

setHue Function

Set hue of video

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setHue

Param

hue

Return

None

0~100

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=setHue&hue=50&usr=&pwd=

setSaturation Function

Set saturation of video

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setSaturation

Param

saturation

Return

None

0~100

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=setSaturation&saturation=50&usr=&pwd=

setSharpness Function

Set sharpness of video

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setSharpness

Param

sharpness

Return

None

0~100

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=setSharpness&sharpness=50&usr=&pwd=

setDenoiseLevel (not use) Function

Set DenoiseLevel of video

Copyright@ Shenzhen Foscam Intelligent Technology Limited

14

Foscam IPCamera CGI Guide

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setSharpness

Param

DenoiseLevel

Return

None

0~100

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=setDenoiseLevel&level=50&usr=&pwd=

resetImageSetting Function

Reset color parameters to default value

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=resetImageSetting

Param

None

Return

None

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=resetImageSetting&usr=&pwd=

getMirrorAndFlipSetting Function

Get mirror and flip attribute of video

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=getMirrorAndFlipSetting

Param

None

Return

isMirror isFlip

0

Not mirred

1

Mirred

0

Not filpped

1

Flipped

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=getMirrorAndFlipSetting&usr=&pwd=

mirrorVideo Function

Mirror video

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=mirrorVideo

Param

isMirror

0

Not mirror

Copyright@ Shenzhen Foscam Intelligent Technology Limited

15

Foscam IPCamera CGI Guide

1 Return

Mirror

None

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=mirrorVideo&isMirror=1&usr=&pwd=

flipVideo Function

Flip video

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=flipVideo

Param

isFlip

Return

0

Not flip

1

Flip

None

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=flipVideo&isFlip=1&usr=&pwd=

getRatio Function

Get value for image distortion correction

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=getRatio

Param

None

Return

ratio

Three ranks for image distortion correction High:150. Middle:210. Low:430.

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=getRatio&usr=&pwd=

setRatio Function

Set value for image distortion correction

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setRatio

Param

ratio

1. 0-511，value for image distortion correction. 2. Three ranks,

Copyright@ Shenzhen Foscam Intelligent Technology Limited

16

Foscam IPCamera CGI Guide High:0-150. Middle:151-429. Low:430-511. 3. Default, Middle.

Return

None

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=setRatio&ratio=150&usr=&pwd=

getH264FrmRefMode Function

Get frame shipping reference mode of H264 encode stream

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=getH264FrmRefMode

Param

None

Return

mode

0 1

Normal reference mode Two frames are separated by four skipping

frames

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=getH264FrmRefMode&usr=&pwd=

setH264FrmRefMode Function

Set frame shipping reference mode of H264 encode stream

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setH264FrmRefMode

Param

mode

0 1

Normal reference mode Two frames are separated by four skipping

frames

Return

None

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=setH264FrmRefMode&mode=0&usr=&pwd=

getScheduleRecordStreamChn Function

Get stream channel for schedule record

privilege



Copyright@ Shenzhen Foscam Intelligent Technology Limited

17

Foscam IPCamera CGI Guide

Usage

/cgi-bin/CGIProxy.fcgi?cmd=getScheduleRecordStreamChn

Param

None

Return

chn

0 main stream 1 sub stream

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=getScheduleRecordStreamChn&usr=&pwd=

setScheduleRecordStreamChn Function

Set stream channel for schedule record

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setScheduleRecordStreamChn

Param

chn

0 main stream 1 sub stream

Return

None

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=setScheduleRecordStreamChn&chn=0&usr= &pwd=

setPwrFreq Function

Set power freq of sensor

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setPwrFreq

Param

freq

Return

0

60HZ

1

50HZ

2

outdoor mode

None

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=setPwrFreq&freq=0&usr=&pwd=

getVideoStreamParam Function

Get video stream param

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=getVideoStreamParam

Copyright@ Shenzhen Foscam Intelligent Technology Limited

18

Foscam IPCamera CGI Guide

Param

None

Return

resolutionN

Resolution of stream type N

bitRateN

Bit rate of stream type N

frameRateN

Frame rate of stream type N

GOPN

P frames between I frame of stream type N

isVBRN

Change

bit

(20480~2097152)

rate

of

stream

1-yes

0-nosetSubVideoStreamParam

Note

N means streamType [0~3]

Example

/cgi-bin/CGIProxy.fcgi?cmd=getVideoStreamParam&usr=&pwd=

setVideoStreamParam Function

Set the video stream param of stream N

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setVideoStreamParam

Param

streamType

0~3

resolution

Resolution of stream type N

bitRate

Bit rate of stream type N

frameRate

Frame rate of stream type N

GOP

P frames between I frame of stream type N

(20480~2097152)

The suggest value is: X * frameRate

isVBR Return

Change bit rate of stream type 1-Yes 0-No

None

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=setVideoStreamParam&streamType=0&resolution= 0&bitRate=2097152&frameRate=30&GOP=30&isVBR=0&usr=&pwd=

getSubVideoStreamParam Function

Get sub video stream param

privilege

visitor

Usage

/cgi-bin/CGIProxy.fcgi?cmd=getSubVideoStreamParam

Param

None

Return

resolutionN

Resolution of stream type N

bitRateN

Bit rate of stream type N

frameRateN

Frame rate of stream type N

GOPN

P frames between I frame of stream type N

Copyright@ Shenzhen Foscam Intelligent Technology Limited

(20480~2097152)

19

Foscam IPCamera CGI Guide

isVBRN

Not in use currentlly

Note

N means streamType [0~3]

Example

/cgi-bin/CGIProxy.fcgi?cmd=getSubVideoStreamParam&usr=&pwd=

setSubVideoStreamParam Function

Set the sub video stream param of stream N

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setSubVideoStreamParam

Param

streamType

0~3

resolution

Resolution of stream type N

bitRate

Bit rate of stream type N

frameRate

Frame rate of stream type N

GOP

P frames between I frame of stream type N

(20480~2097152)

The suggest value is: X * frameRate

isVBR Return

Not in use currentlly

None

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=setSubVideoStreamParam&streamType=0&resoluti on=0&bitRate=2097152&frameRate=30&GOP=30&isVBR=0&usr=&pwd=

getMainVideoStreamType Function

Get the stream type of main stream

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=getMainVideoStreamType

Param

None

Return

streamType

The stream type

0~3

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=getMainVideoStreamType&usr=&pwd=

getSubVideoStreamType Function

Get the stream type of sub stream

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=getSubVideoStreamType

Param

None

Copyright@ Shenzhen Foscam Intelligent Technology Limited

20

Foscam IPCamera CGI Guide

Return

streamType

The stream type

0~3

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=getSubVideoStreamType&usr=&pwd=

setMainVideoStreamType Function

Set the stream type of main stream

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setMainVideoStreamType

Param

streamType

Return

None

The stream type

0~3

Note Example

/cgi-bin/CGIProxy.fcgi?cmd=setMainVideoStreamType&streamType=0&usr=ad min&pwd=

setSubStreamFormat Function

Set the stream format of sub stream

privilege



Usage

/cgi-bin/CGIProxy.fcgi?cmd=setSubStreamFormat

Param

format

0

H264

1

MotionJpeg

Return

None

Note

Our device can only 2 streams:Main stream for PC access and Sub stream for mobile access, but someone need a MJ stream to embed their camera into a webpage, in this case, we should set sub stream format to Motion Jpeg,

and

then

you

can

get

MJ

stream

by

command:

/cgi-bin/CGIStream.cgi?cmd=GetMJStream, but when you as a sub stream , the stream data will be same as main stream.

Example

/cgi-bin/CGIProxy.fcgi?cmd=setSubStreamFormat&format=0&usr=&pwd=

GetMJStream Function

Get motion jpeg stream

privilege

visitor

Usage

/cgi-bin/CGIStream.cgi?cmd=GetMJStream

Param

None

Copyright@ Shenzhen Foscam Intelligent Technology Limited

21

Foscam IPCamera CGI Guide

Return

Motion jpeg stream data

Note

1) Motion jpeg stream data is returned from https server by a serverpush mode 2) MJ stream is VGA resolution @ 15fps 3) For some version of Firefox browse, the Firefox will crash when use “GetMJStream” CGI to get

mjstream long time. This problem is due to the

browse has some defects, it can not parse data correctly and directly. In order to fix this problem, we should as follows: A. Create a .txt empty document, such as “MJ.txt”. B.Input the content into you .txt document, as follows:
