DURAGAL

®

FLOORING SYSTEM

THE PERFECT SOLUTION FOR SLOPING SITES

Letter of Certification MORGAN CONSULTING ENGINEERS PTY LTD ABN 82 009 859 081

1 GREAT GEORGE STREET PADDINGTON QLD 4064 ◆

STRUCTURAL ◆ CIVIL ◆ HOUSING ◆ FORENSIC ◆

Monday, 12 August 2002 OneSteel Market Mills PO Box 156 NEWCASTLE NSW 2300 Dear Sir, RE:

Structural Engineers Certification DuraGal Flooring Tables

We hereby certify that we have checked the structural aspects of the design tables 1 to 28 in the DuraGal Flooring System Brochure dated August 2002. The tables and accompanying information must be strictly followed, or structural adequacy or statutory compliance may be compromised. We certify that designed using these tables are structurally adequate and in accordance with the Building Code of Australia and relevant SAA Codes of Practice. Yours Faithfully, MORGAN CONSULTING ENGINEERS PTY LTD

Robert N Morgan

Eng

For further information please OneSteel Direct Telephone: 1800 1 STEEL (1800 1 78335) Facsimile: 1800 101 141 Email: [email protected] This brochure contains general information about the use of the DuraGal Flooring System in single storey residential buildings. This information is a guide only and not a substitute for expert advice on how to successfully design and construct a residential building or install a flooring system. Successful design, construction and installation depends on many factors beyond the scope of this brochure, including, for example, correct site preparation, proper care of product prior to installation, workmanship during installation and engineering judgments specific to each installation. Product specification and other information in this brochure may change at any time without further notice. OneSteel does not accept any responsibility for other products named in, for any error in, or omission from, this brochure or for any loss or damage or other consequence arising from the use of this brochure by any person.

august 02 DuraGal

®

Flooring System Page

2

Joist Spans

DuraGal

®

Flooring System

Now you can build a better floor with the DuraGal Flooring System Difficult or sloping site construction can be easily handled by the DuraGal Flooring System. Developed by OneSteel Market Mills, the DuraGal Flooring System is a steel flooring system utilising the higher strength and lighter weight advantages of DuraGal Hollow sections. The DuraGal Flooring System is suitable for a wide range of single storey residential homes, decks and commercial floors. The DuraGal Flooring System has been developed by OneSteel to provide a simple, strong and lightweight modular system to handle difficult or sloping site construction. The system utilises the higher strength and lighter weight advantages of DuraGal hollow sections to produce a floor system that’s suitable for a wide range of building applications.

The many benefits offered by the DuraGal Flooring System has seen it adopted by many leading housing construction companies as their preferred system for sloping sites.

The DuraGal Flooring System is yet another example of the innovative building solutions developed by OneSteel Market Mills.

Suitable for single storey residential homes, decks and commercial floors, it offers the flexibility and ease of installation that can substantially reduce your on site construction costs.

Isn’t it time you started building a better floor with the DuraGal Flooring System?

Why you should use the DuraGal® Flooring System: -

Coating System

●

Quality – OneSteel’s commitment to quality means you can depend on DuraGal products to deliver reliable & consistent quality to site.

Simple and straightforward installation. No welding required. ● Unaffected by termites. ● DuraGal won’t shrink, rot or warp like timber, helping to reduce expensive callbacks. ● Larger spans, which can open up underfloor areas for use as workshop or storage. ● Improved underfloor access and ventilation. (less piers) ● The costs of site preparation such as, cut and fill, retaining walls and drainage can be minimised. ● Has the advantage of higher strength, lightweight, and corrosion resistant* DuraGal hollow steel sections. ● Manufactured to tight tolerances. ● Longer lengths. ● Comprehensive range of standard fittings to suit most applications. ● Floor sheets can still fixed by traditional methods. ● Australian made and available nationally

Versatility – New span tables for live loads of 1.5kPa, 3.0kPa and 5.0kPa, means the DuraGal Flooring System is now more versatile than ever.

* Refer to pages 22 to 29 of this publication for more details on corrosive environments & appropriate precautions during installation of exposed floors .

Features friendly – Requires only normal trade and electrical tools, no welding is involved. Fast and accurate levelling of the floor during or after construction is a great feature, and compensates for variations in the footings, now or later. Surface Protection – Internally painted DuraGal hollow sections have an In-line hot dip, galvanized coating with a minimum average coating mass of 100g/m2 applied to the external surface, the internal surface is coated with a 35 micron thick Zinc Phosphate coating. Recommended for use in non-aggressive environments*.

Cleaned Surface

●

Internally Painted Surface Conversion Coating

In-line Hot-dip Galvanized Coating

Selection of materials In the construction of a floor system, building products manufactured by OneSteel Market Mills, and building products manufactured by other companies will be used. The product information in this publication relates solely to the products manufactured by OneSteel Market Mills. It is strongly recommended that only DuraGal Internally painted hollow sections manufactured by OneSteel be specified for use when using the design information in this publication. Testing using only OneSteel Products has validated the design criteria contained within this publication. It is recommended a note to this effect is included on any design documentation. august 02 DuraGal

®

Flooring System Page

3

DuraGal

®

Flooring System

What the s Say Mr. Bruce Louis Production & Design Manager, AV Jennings Homes, Wyong NSW.

‘With fluctuating timber prices and instability of supply, we looked for an alternative system to the traditional timber bearers and joists for construction of elevated floors on sloping sites. After trialing several systems we adopted the DuraGal® Flooring System as our preferred option as it offers the best and

Contents Letter of Certification ........................ 2 Features & Benefits ..........................3

most cost effective solution for our company.” “An added benefit provided by this system is that it offers extra useable space under the floor which is used as a real selling feature.”

Mr. Dennis McColl

What s Say ........................ 4 Joist Spans For 1.5 kPa Floors ........................ 5 Bearer Spans For 1.5 kPa Floors ........................ 6

Managing Director, Aus Steel, Beresfield, NSW.

Joist Spans For 3 & 5 kPa Floors..................... 7 “It enables you to keep the floor nice and straight. We have also used the system a lot in patios, especially where there is no underfloor lining. It is a good, neat section that finishes off well.”

Bearer Spans For 3 & 5 kPa Floors....................... 8 Cantilever Spans For 1.5 kPa Floors....................... 9 Cantilever Spans For 3 kPa Floors................... 10

Mr. Jason Watts Production Manager, Executive Homes, Country Victoria and Southern NSW.

“The DuraGal Flooring System provides us with a flexible building system well ®

suited to a wide range of home designs and site conditions. The major benefits

Cantilever Spans For 5 kPa Floors.................... 11 Assembly - Brick Veneer....................... 12

to us include, being galvanized steel, being resistant to termite attack, easy to

Assembly - Free Standing ...................... 13

install, and providing a strong low maintenance system. Whenever an elevated

Bracing Details ...................... 15

floor is required we would recommend the DuraGal® Flooring System to our clients.”

Connections - Capacities ...................... 16 Footing Details ...................... 17 Construction Hints ...................... 18 Accessories ...................... 19 Termite Barriers ...................... 21 Corrosion Guide ...................... 22 Sealing of Fittings ........................24 Nailing ...................... 30 Cutting ...................... 30

august 02 DuraGal

®

Flooring System Page

4

Joist Spans For 1.5 kPa Domestic Floors Cyclonic & Non Cyclonic Regions

Flooring System

Continuous Span (SEE NOTE 2 - DESIGN CRITERIA)

Single Span TABLE 1 – JOISTS FOR 1.5 kPa FLOORS DURAGAL JOIST SPACING (mm) C450L0 4501 600 RHS SIZE2 MAXIMUM JOIST SPAN (m)

1

TABLE 2 – JOISTS FOR 1.5 kPa FLOORS DURAGAL JOIST SPACING (mm) C450L0 4501 600 RHS SIZE2 MAXIMUM SPAN (m)

1.5kPa

75 x 50x 1.6

2.52

2.39

75 x 50 x 1.6

2.14

2.05

x 2.0

2.72

2.57

x 2.0

2.30

2.20

100 x 50 x 1.6

3.31

3.10

100 x 50 x1.6

2.78

2.65

x 2.0

3.59

3.34

x 2.0

3.00

2.85

150 x 50 x 2.0

5.46

4.95

150 x 50 x 2.0

4.44

4.16

x 2.5

5.74

5.34

x 3.0

5.98

5.56

x 4.0

6.31

5.88

x 2.5

4.81

4.49

x 3.0

5.13

4.77

x 4.0

5.52

5.20

x 5.0

6.45

6.14

x 5.0

5.65

5.41

x 6.0

6.55

6.28

x 6.0

5.73

5.50

OneSteel Market Mills recommend 450mm joist spacing.

1

OneSteel Market Mills recommend 450mm joist spacing.

2

Preferred internally painted sizes shown in bold print. For availability of other internally painted sizes we recommend you consult the DuraGal Flooring System supplier in your area. This table also applies to decks with floor areas greater than 40m2

2

Preferred internally painted sizes shown in bold print. For availability of other internally painted sizes we recommend you consult the DuraGal Flooring System supplier in your area. 3 This table also applies to decks with floor areas greater than 40m2

DESIGN CRITERIA 1. Span Tables 1 to 4 & 13 to 16 have been calculated in accordance with AS 3623: Domestic metal framing, AS 4100: Steel Structures, AS1170.1: Dead and Live Loading, with Live Load, Q equal to 1.5kPa, and Dead Load, G equal to 0.4kPa. 2. For continuous span where the variation between adjacent spans exceeds 30% of the larger span, the single span tables must be used. 3. Tables are available on request for: - Live loads other than 1.5, 3 & 5kPa - DuraGal sizes not given in Table 1 to 6 4. If additional loads are applied the advice of a Structural Engineer must be sought.

3

FLOOR STIFFNESS • The maximum spans given in Table 1 to 4 comply with the Australian Standard AS 3623 - Domestic Metal Framing. • The spans given for the joists in Tables 1 and 2 are the maximum recommended spans and as such not all s will be satisfied with the stiffness of the floor. For those desiring a stiffer floor either the spans tabulated can be reduced, the joist spacing reduced, or both.

• If you need guidance for large open areas, areas not ing roof and wall loads, or to achieve the floor stiffness you require, consult your DuraGal Flooring System Supplier who can provide advice on the floor design to meet your needs.

• Joist spacing of 450mm spans calculated using 19mm particle board or 15mm F14 plywood floor sheeting. Joist spacing of 600mm spans calculated using 22mm floor sheeting.
