Code: 9A01501 III B. Tech I Semester (R09) Regular & Supplementary Examinations, November 2012 DESIGN & DRAWING OF REINFORCED CONCRETE STRUCTURES (Civil Engineering) Time: 3 hours Max Marks: 70 Use of IS 456-2000, IS-800 code books to be permitted in the examination hall. Part A (Answer any one question, 1 x 28 marks) ***** 1 Design a RC cantilever beam with tension steel only to carry a super imposed load of 10kN/m over a clear span of 3.5 m with a uniform breadth of 300 mm overall depth of beam at the free end is to be 300 mm. Permissible stresses in concrete and steel are 7 N/mm2 and 190 N/mm2. 2
(a) (b)
3
(a)
(b)
4
5
What is meant by limit state? Discuss the different ‘limit states’ to be considered in reinforced concrete design. Why is the partial safety factor for concrete (γc) greater than that for reinforcing steel (γs) in the consideration of ultimate limit states? Part B (Answer any three questions, 3 x 14 marks) A RC floor slab of 100 mm thick is ed by T-beam at 3 m intervals c/c. The slab carries a total superimposed load of 3 kN/m2 in addition to itself weight. The effective span of T-beams is 9 m. Design the beam using M20 grade concrete and Fe 415 grade steel. Determine the moment capacity of a doubly-reinforced rectangular cross-section beam for the following data: b = 350 mm, d = 700 mm, Ast=1400 mm2, fy = 415 N/mm2, fck=25 N/mm2, ASC=650 mm2.
D L
R O
W U
The critical section of an RC rectangular beam is subjected to a bending moment of 28 kNm, a torsional moment of 15 kNm and a shear force of 32 kN. The overall size of the section is 350 mm x 700 mm. provide effective cover to reinforcement as 50 mm. concrete grade M 25 and steel grade Fe 415 are used. Design the necessary reinforcements for the section. Draw the drawings showing the design details. (a) (b)
T N
Explain the limitations of the traditional limit state method with regard to the design of axially loaded reinforced concrete columns. Design the reinforcement in a column of size 300 mm x 450 mm, with an uned length of 6.0 m, subjected to a factored axial load of 1150 kN. Assume the column to be braced, and pinned at both ends in both end directions. Assume M20 concrete and Fe415 steel, and design by: (i) Strength reduction coefficient method. (ii) Additional moment method.
J
6
Design a footing of a brick wall 30 cm thick which is transmitting a load of 150 kN/m per unit length. The gross bearing capacity of the soil is 100 kN/m2. Use M20 grade concrete and Fe 415 HYSD. Assume suitable data.
7
Design reinforced concrete slab for a room measuring 5 m x 5 m. The slab is to rest upon 11/2 brick thick walls constructed all round. The flooring is to consist of 25 mm thick cement concrete layer. The flooring may be assumed to be subjected to a uniformly distributed super imposed load of 4kN/m2.The following data may be assumed in the design: Use M 20 grade of concrete and Fe 415 grade steel. Draw a cross section of the designed slab showing clearly the bar bending schedule of the reinforcement. *****
