Design Example Report Title

60W Power Supply using TOP247Y

Specification

Input: 90-265 VAC Output: 20V/3A

Application

LCD Monitor

Author

Power Integrations Applications Department

Document Number

DER-25

Date

March 30, 2004

Revision

1.0

Summary and Features This design uses a TOP247Y and EER28L core transformer to create an LCD monitor supply that features the following: • Standby performance: delivers 585 mW at 1W input @ 240Vac • Uses crowbar secondary circuit for low-cost over-voltage protection, which forces the unit into auto-restart • No Load input power < 300 mW • Meets EN550022 B for conducted EMI • Min Efficiency 85% (90 Vac and full load)

The products and applications illustrated herein (including circuits external to the products and transformer construction) may be covered by one or more U.S. and foreign patents or potentially by pending U.S. and foreign patent applications assigned to Power Integrations. A complete list of Power Integrations’ patents may be found at www.powerint.com.

Power Integrations 5245 Hellyer Avenue, San Jose, CA 95138 USA. Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

Table Of Contents 1 2 3 4

Introduction................................................................................................................. 4 Power Supply Specification ........................................................................................ 5 Schematic................................................................................................................... 6 Principle of Operation................................................................................................. 7 4.1 Input EMI Filtering ............................................................................................... 7 4.2 TOPSwitch Primary ............................................................................................. 7 4.3 Output Rectification ............................................................................................. 7 4.4 Output ................................................................................................. 7 4.5 Protection ............................................................................................................ 8 5 PCB Layout ................................................................................................................ 8 6 Bill Of Materials ........................................................................................................ 10 7 Transformer.............................................................................................................. 12 7.1 Transformer Winding......................................................................................... 12 7.2 Electrical Specifications..................................................................................... 12 7.3 Transformer Construction.................................................................................. 13 7.4 Transformer Materials ....................................................................................... 14 7.5 Design Notes..................................................................................................... 14 7.6 Transformer Winding Instruction ....................................................................... 15 8 Transformer Design Spreadsheet ............................................................................ 16 9 Performance Data .................................................................................................... 18 9.1 Line and Load regulation................................................................................... 18 9.2 Efficiency........................................................................................................... 18 9.3 No-load Input Power.......................................................................................... 19 9.4 Output Power for 1 W Input Power.................................................................... 19 10 Output Ripple Measurements ............................................................................... 20 10.1 Ripple Measurement Technique ....................................................................... 20 11 Over-voltage Protection ........................................................................................ 21 12 Dynamic Load Transient ....................................................................................... 22 13 Conducted EMI ..................................................................................................... 23 14 Revision History .................................................................................................... 23

Page 2 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

Table of Figures Figure 1 – LCD Monitor Prototype Power Supply – Top View ........................................... 4 Figure 2 – LCD Monitor Prototype Power Supply – Bottom View ...................................... 4 Figure 3 – LCD Monitor Power Supply Schematic – 90-265 Vac, 20V, 3A........................ 6 Figure 4 – Printed Circuit Board ........................................................................................ 9 Figure 5 – Transformer Winding ...................................................................................... 12 Figure 6 – Transformer Construction............................................................................... 13 Figure 7 – W4 copper foil construction ............................................................................ 13 Figure 8 – Efficiency versus Output current..................................................................... 18 Figure 9 – No Load Input Power versus Input Voltage .................................................... 19 Figure 10 – Output power versus Input voltage for 1 W Input power............................... 19 Figure 11 – Oscilloscope Probe Prepared for Ripple Measurement................................ 20 Figure 12 – Oscilloscope Probe with Probe Master 5125BA BNC Adapter ..................... 20 Figure 13 – Output Voltage Ripple (worst case) 90 Vac, 20V, 3A load ........................... 21 Figure 14 – Output voltage with over-voltage protection ................................................. 21 Figure 15 – Dynamic Load Transient – Step Load 1.5A ↔ 3A, 90 Vac ........................... 22

Table of Tables Table 1 – Bill of Materials ................................................................................................ 11 Table 2 – Transformer Electrical Specifications............................................................... 12 Table 3 – Transformer Bill of Materials............................................................................ 14 Table 4 – Power Supply Design Parameters ................................................................... 14

Important Note: Although the prototype hardware is designed to satisfy safety isolation requirements, this engineering prototype has not been agency approved. Therefore all testing should be performed using an isolation transformer to provide the AC input to the prototype board. The layout shown in this report has been engineered to follow Power Integrations’ design guidelines to minimize EMI and susceptibility. Changing the layout may worsen EMI and other aspects of performance. Design Reports contain a power supply design specification, schematic, bill of materials, and transformer documentation. Performance data and typical operation characteristics are included. Typically only a single prototype has been built.

Page 3 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

1 Introduction This document is an engineering report of a 60 W Flyback power supply with 90-265 Vac input and 20V 3A output. The power supply uses TOPSwitch-GX TOP247Y, which comprises of 700 V MOSFET and PWM controller in a single IC. The document contains the power supply specification, schematic, PCB Layout, bill of materials and performance data.

Figure 1 – LCD Monitor Prototype Power Supply – Top View

Figure 2 – LCD Monitor Prototype Power Supply – Bottom View

Note: The prototype layout requires some additional components mounted on the underside.

Page 4 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

2 Power Supply Specification Description

Symbol

Min

Input Voltage Frequency No-load Input Power

VIN fLINE PNoLoad

Output Output Voltage 1 Output Ripple Voltage 1 Output Current 1

VOUT VRIPPLE IOUT

Total Output Power Continuous Output Power

Max

Units

Comment

90 47

VAC Hz W

2 Wire – no P.E.

50/60

265 63 0.3

19

20

21 200 3

V mV A

0

POUT

Dynamic Load recovery time Hold-up time Over-voltage protection

Efficiency

Typ

60 1

Environmental Conducted EMI

85

Surge

Page 5 of 24

135

87.5

mS mS %

@ 50 % - 100 % step load

of nominal output voltage

%

Meets CISPR22B / EN55022B Designed to meet IEC950, UL1950 Class II

Safety

Ambient Temperature

W

10 110

η

20 MHz Bandwidth

2 TAMB

0

50

kV o

C

1.2/50 µs surge, IEC 1000-4-5, Series Impedance: Differential Mode 2 Ω Common Mode: 12 Ω Free convection, sea level

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

3 Schematic

Figure 3 – LCD Monitor Power Supply Schematic – 90-265 Vac, 20V, 3A

Page 6 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

4 Principle of Operation The schematic in Figure 1 shows an off-line Flyback converter using the TOP247Y. The circuit is designed for 90 VAC to 265 VAC input, with one output: 20V, 3A. 4.1

Input EMI Filtering

Capacitor CX1 and the L2 leakage inductance help to filter differential mode conducted EMI. Inductor L2 and CY2-CY3 filter common mode conducted EMI. 4.2

TOPSwitch Primary

The AC line voltage is rectified and filtered to generate a high voltage DC bus via D3, D4, D8, D9 and C7. Diode D5, C2, R3, R4, and R5 clamp leakage spikes generated when the MOSFET in U2 switches off. D5 is a glass-ivated normal recovery rectifier. The slow, controlled recovery time of D5 allows energy stored in C2 to be recycled back to the output, significantly increasing efficiency. A normal (non-ivated) 1N4007 should not be substituted for the glass-ivated device. Resistors R9, R10, and R16 set the turnon voltage of the supply to approximately 76 VAC. C12 byes the U2 control pin. C13 has three functions. It provides the energy required by U2 during startup, sets the autorestart frequency during fault conditions, and also acts to roll off the gain of U2 as a function of frequency. R24 adds a zero to the control loop to stabilize the power supply control loop. D6, R8 and C9 provide rectified and filtered bias power for U1 and U2. Components Q2, D7, C10, R13, R17, R20, R21, R22, R25, R27, and R28 provide a signal to the U2’s “X-pin” to program it for frequency reduction at light load. This reduces the supply input power consumption under light load. Resistors R13, R20, and R22 reduce the U2 maximum current limit as a function of line voltage, making the maximum overload power more independent of line voltage. 4.3

Output Rectification

The T1output is rectified and filtered by D1, C3 and C4 for the 20V output. Components C1 and R1 provide snubbing for D1. Components L1, and C5 provide additional high frequency output filtering. Ferrite bead L3 provides some high frequency isolation between the secondary return and primary safety ground to improve EMI. 4.4

Output

Resistors R18, R26, and R27 are used to set the output voltage. Shunt regulator U1 drives Opto-coupler U1 through resistor R11 to provide information to the U2 control pin. The opto-coupler output also provides power to U2 during normal operating conditions. Capacitor C14 provides a path to the opto-coupler during supply start-up to reduce output voltage overshoot. Capacitor C11 and R23 provide frequency compensation for error amplifier U3. Capacitor C13 rolls off the gain of U2 at relatively low frequency. Resistor R24 provides a zero to cancel the phase shift of C13. Resistor R11 sets the gain of the direct signal path from the supply output through U1 and U3. Components C11 and R23 reduce the high frequency gain of U3. C8 and R14 increase the high frequency gain.

Page 7 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25 4.5

60W LCD Monitor Power Supply

March 30, 2004

Protection

Components Q1, D2, C6, and R6 provide over voltage protection of the output voltage. When output voltage exceeds 23.5V nominal, D2 breaks down and 1.5V appears at the gate of Q1, and turns ON the Q1, which in turn shorts the output, thus forcing the power supply into auto-restart mode. Components R6 and C6 help prevent false triggering of Q2.

5 PCB Layout Notes: 1. PCB layout shown is a prototype layout and does not have provision for the following components, they are soldered on the bottom side of the PCB. 1.1. C1, R1 (snubber across secondary winding). 1.2. R27 (pull-down resistor of Q2). 1.3. R2 (resistor across opto-coupler diode to bleed C14 – soft start capacitor, when power supply is OFF). 2. A green wire is soldered between secondary return and earth ground on the primary side, on the bottom side of the PCB. Running a PCB trace will not meet safety creepage of 6.54mm from primary traces. If this wire is run on the top side of the PCB, then heat sink requires a hole to run the wire. Another option is to have one mounting hole on secondary side connected to secondary return, and another mounting hole on the primary side connected to the ferrite bead L3 whose other end is connected to the earth ground, this option will eliminate the wire.

Page 8 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

Figure 4 – Printed Circuit Board

Page 9 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

6 Bill Of Materials Item

Qty

Reference

1

1

CX1

0.33 µF, 250 Vac, safety Film capacitor

Generic

Generic

2

1

CY1

2.2 nF, 4KV, safety ceramic capacitor

Generic

Generic

3

2

CY2, CY3

100 pF, 2.5KV, safety ceramic capacitor

Generic

Generic

4

1

C1

330 pF, 100V, X7R ceramic capacitor

Generic

Generic

5

1

C2

0.01 µF, 1KV, Z5U ceramic capacitor

Generic

Generic

6

2

C3, C4

470 µF, 35V, AL Electrolytic cap

35ZL470 10x20

Rubycon

7

1

C5

220 µF, 35V, AL Electrolytic cap

35ZL220 10x12.5

Rubycon

8

3

C6, C11, C12

0.1 µF, 50V, X7R ceramic cap

Generic

Generic

9

1

C7

150 µF, 400V, AL Electrolytic cap

Generic

Generic

10

1

C8

0.015 µF, 50V, X7R ceramic cap

Generic

Generic

11

1

C9

47 µF, 50V, AL Electrolytic cap

Generic

Generic

12

1

C10

0.47 µF, 25V, X7R ceramic cap

Generic

Generic

13

1

C13

47 µF, 10V, AL Electrolytic cap

Generic

Generic

14

1

C14

10 µF, 35V, AL Electrolytic cap

Generic

Generic

15

1

D1

MBR10100, Schottky diode, 100V, 10A

Generic

Generic

16

1

D2

Zener diode, 24V, 0.5W, ± 2 %

BZX79-B24

Philips

17

4

D3, D4, D8, D9

Diode, 600V, 2A, General purpose

RL205

Rectron

18

1

D5

Glass ivated diode, 1000V, 1A, trr = 2 µS (typical)

1N4007GP

Generic

19

2

D6, D7

Switching diode, 75V, 500 mA

LL4148

Generic

20

1

J1

AC Connector, 3-wire, 250 Vac

Generic

Generic

21

1

J2

Output Connector, 6-pin

Generic

Generic

22

1

L1

3.3uH, 5A, Ferrite drum core Inductor

Generic

Generic

23

1

L2

6mH, 1.6A, Common mode choke

ELF18N016A

Panasonic

24

1

L3

Ferrite Bead

2673021801

Fair-Rite

25

1

Q1

SCR, 200V, 8A

S2008V

Teccor

26

1

Q2

MMBT3906, PNP Transistor

Generic

Generic

27

1

RF1

5A, 250V, Fuse

Generic

Generic

28

1

RT1

5 Ω, 3A, Thermistor

Generic

Generic

29

1

R1

5.1 Ω, 1/2W, resistor

Generic

Generic

30

1

R2

1 KΩ, 5%, 1206

Generic

Generic

Page 10 of 24

Description

P/N

Manu.

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

Reference

March 30, 2004

Item

Qty

Description

P/N

Manu.

31

2

R3, R5

47 K Ω, 1/2W, 5%, Resistor

Generic

Generic

32

1

R4

33 Ω, 1/2W, 5%, Resistor

Generic

Generic

33

1

R6

300 Ω, 1/4W, 5%, Resistor

Generic

Generic

34

6

R7, R9, R10, R12, R16, R19

680 KΩ, 5%, 1206, resistor

Generic

Generic

35

1

R8

4.7 Ω, 5%, 1206, resistor

Generic

Generic

36

1

R11

1.5 KΩ, 5%, 1206, resistor

Generic

Generic

37

1

R13

2.2 MΩ, 1%, 1206, resistor

Generic

Generic

38

1

R14

150 Ω, 5%, 1206, resistor

Generic

Generic

39

1

R15

1 Ω, 5%, 1206, resistor

Generic

Generic

40

1

R17

13 KΩ, 5%, 1206, resistor

Generic

Generic

41

1

R18

69.8 KΩ, 1%, 1206, resistor

Generic

Generic

42

2

R22, R20

2.7 MΩ, 1%, 1206, resistor

Generic

Generic

43

2

R21, R30

240 Ω, 5%, 1206, resistor

Generic

Generic

44

1

R23

4.7 KΩ, 5%, 1206, resistor

Generic

Generic

45

1

R24

6.8 Ω, 5%, 1206, resistor

Generic

Generic

46

1

R25

24.9 KΩ, 1%, 1206, resistor

Generic

Generic

47

1

R26

910 KΩ, 1%, 1206, resistor

Generic

Generic

48

2

R27, R29

10 KΩ, 1%, 1206, resistor

Generic

Generic

49

1

R28

12 KΩ, 5%, 1206, resistor

Generic

Generic

50

1

T1

Core: EER28L, Bobbin: 12 pin Horizontal

Custom

Custom

51

1

U1

Opto-coupler, CTR = 150-300 %

PC817D

52

1

U2

TOPSwitch-GX

TOP247Y

53

1

U3

Reference voltage regulator, 1%

TL431

Sharp Power Integrations Generic

Table 1 – Bill of Materials

Page 11 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

7 Transformer 7.1

Transformer Winding 1

11,12

W6,16T,#26x2, Primary-2

W5,6T,#27x6, Secondary 9,10

3 3

6

W2,17T,#26x2, Primary-1

W3,5T,#35 Bias 5

2 NC

6

W1,8T,#26x4, core cancellation wndg.

W4,1T, 15 mmx2mils Copper Foil, Shield wndg.

1

Figure 5 – Transformer Winding

Note: 1. NC: Not connected. 7.2

Electrical Specifications

Electrical Strength

1 second, 60 Hz, from Pins 1-6 to Pins 7-12.

3000 Vac

Primary Inductance

Pins 1-2, all other windings open, measured at 132 kHz

390 µH – 411 µH – 432 µH

Resonant Frequency

Pins 1-2, all other windings open

300 kHz (Min.)

Primary Leakage Inductance

Pins 1-2, with Pins 5-12 shorted, measured at 132 kHz.

4.3 µH (Max.)

Table 2 – Transformer Electrical Specifications

Page 12 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

7.3

60W LCD Monitor Power Supply

March 30, 2004

Transformer Construction

Pins 7-12 3 mm Margin tape - 11 places (approx)

Pins 1-6 W6-finish(P1) W6-start(P3)

W5-start(P11,12) W5-finish(P9,10) 21mm,2mils Insulation Tape, 3 layer 5 places

W4-start(P6) W3-finish(P5)

16mm,2mils Insulation Tape, 2 layer 1 place, 1 layer 1 place

W3-start(P6) W2-finish(P3) W2-start(P2)

W1-finish(Not connected)

W1-start(P1) W1,8T,#26x4, Core cancellation W2,17T,#26x2, Primary-1 W3,5T,#35 Bias - Teflon tube

W4,1T,15mmx2mils Copper Foil W5,6T,#27x6, Secondary W6,16T,#26x2, Primary-2 Px - Pin No.x

Figure 6 – Transformer Construction

P-6 #35 termination wire

Tape: 25 mm width

W4,1T WxTxL = 15mm x 2mils x 1T

Tape: 25 mm width

Cu Foil

Cu Foil

Tape: 16 mm width

Figure 7 – W4 copper foil construction

Note: WxTxL: Width x Thickness x Length

Page 13 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25 7.4

60W LCD Monitor Power Supply

March 30, 2004

Transformer Materials

Item

Description 2

2

2

[1]

Core: EER28L Generic, gapped for AL = 358 nH/T - 377 nH/T - 397 nH/T

[2]

Bobbin: Horizontal 12-pin, generic, bobbin width = 21.8 mm

[3]

Magnet wire: # 26 AWG

[4]

Magnet wire: # 27 AWG

[5]

Magnet wire: # 35 AWG

[6]

Copper Foil: 15 mm x 2 mils

[7]

Tape: 3M 1298 Polyester Film (white) 25 mm x 2 mils (to wrap around copper foil)

[8]

Tape: 3M 1298 Polyester Film (white) 21 mm x 2 mils

[9]

Tape: 3M 1298 Polyester Film (white) 16 mm x 2 mils

[10]

Tape: 3M 1298 Polyester Film (white) 8 mm x 2 mils (to wrap the core together)

[11]

Margin Tape: 3M 1298 Polyester Film (white) 3 mm x 5 mils

[12]

Teflon tube

[13]

Varnish Table 3 – Transformer Bill of Materials

7.5

Design Notes Power Integrations Device Frequency of Operation Mode Peak Current Reflected Voltage (Secondary to Primary) Maximum AC Input Voltage Minimum AC Input Voltage

TOP247Y 132 KHz Continuous/ discontinuous 1.89 A 115 V 265 Vac 90 Vac

Table 4 – Power Supply Design Parameters

Page 14 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

7.6

60W LCD Monitor Power Supply

March 30, 2004

Transformer Winding Instruction

All windings should be wound in the forward direction. Bobbin orientation

Place the bobbin on the winding machine with pins 1-6 on the right side and pins 7-12 on the left side.

Margin Tape

Apply 3 mm margin tape on both sides of the bobbin appropriately, whenever necessary. Use Figure 6 as reference.

Teflon Tube

Use Teflon tube for all windings termination to meet safety creepage between primary and secondary.

W1 (Core Cancellation Winding)

Wind 8 turns from right to left with # 26 x 4 (quadfilar) magnet wire starting from pin 1, cut the wire after 8 turns and leave the finishing end unconnected. Use 8 mm tape to secure the wires end in place.

Basic Insulation

3 layers of 21 mm tape for insulation.

W2 (Primary Winding-1)

Wind 17T from right to left with # 26 x 2 (bifilar) magnet wire starting from pin 2 and finishing at 3.

Basic Insulation

3 layers of 21 mm tape for insulation.

W3 (Bias winding)

Wind 5 turns from right to left with # 35 magnet wire starting from pin 6 and finishing at pin 5. Spread the 5T evenly across the width of the bobbin.

Basic Insulation

2 layers of 16 mm tape for insulation.

W4 (Shield winding)

Prepare the Copper foil as shown in Figure 7. Wind 1T with copper foil starting from pin 6 and leave the finishing end unconnected. 8 mm tape can be used to secure the copper foil in place while winding.

Basic Insulation

3 layers of 21 mm tape for insulation.

W5 (Secondary winding)

Wind 6 turns from right to left with # 27 x 6 (hexa-filar) magnet wire starting temporarily from pins 1-2 and finishing at pins 9-10 – one layer of 16 mm tape – bring the starting end from pins 1-2 to pins 11-12 and terminate them.

Basic Insulation

3 layers of 21 mm tape for insulation.

W6 (Primary Winding-2)

Wind 16T from right to left with # 26 x 2 (bifilar) magnet wire starting from pin 3 and finishing at 1.

Outer Insulation

3 layers of 21 mm tape for insulation.

Core Assembly

Assemble and secure core halves.

Final Assembly

Impregnate transformer uniformly with varnish.

Note: 1. Teflon tube is not used in the prototype transformer.

Page 15 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

8 Transformer Design Spreadsheet ACDC_TOPGX_Rev1.2_ 052901 Copyright Power Integrations Inc. 2001

INPUT

INFO

OUTPUT

UNIT

TOP_GX_052901.xls: TOPSwitch-GX Continuous/Discontinuous Flyback Transformer Design Spreadsheet

ENTER APPLICATION VARIABLES VACMIN

85

Volts

Minimum AC Input Voltage

VACMAX

265

Volts

Maximum AC Input Voltage

fL

50

Hertz

AC Mains Frequency

VO

20

Volts

Output Voltage

PO

60

Watts

Output Power

n

0.82

Z

0.5

VB

15

tC

3

CIN

Efficiency Estimate Loss Allocation Factor Volts

Bias Voltage

mSeconds Bridge Rectifier Conduction Time Estimate

150

uFarads

Input Filter Capacitor

Universal

115 Doubled/230V

90W

150W External Ilimit reduction factor (KI=1.0 for default ILIMIT, KI <1.0 for lower ILIMIT)

ENTER TOPSWITCH-GX VARIABLES TOP-GX

top246

Chosen Device KI

TOP246

Power Out

0.83

ILIMITMIN

2.017 Amps

Use 1% resistor in setting external ILIMIT

ILIMITMAX Frequency - (F)=132kHz, (H)=66kHz

2.465 Amps

Use 1% resistor in setting external ILIMIT

fS

f 132000

1.32E+05 Hertz

Full (F) frequency option - 132kHz TOPSwitch-GX Switching Frequency: Choose between 132 kHz and 66 kHz

fSmin

1.24E+05 Hertz

TOPSwitch-GX Minimum Switching Frequency

fSmax

1.40E+05 Hertz

TOPSwitch-GX Maximum Switching Frequency

VOR

115

Volts

Reflected Output Voltage

VDS

5

Volts

TOPSwitch on-state Drain to Source Voltage

VD

1

Volts

Output Winding Diode Forward Voltage Drop

VDB

1

Volts

Bias Winding Diode Forward Voltage Drop Ripple to Peak Current Ratio (0.4 < KRP < 1.0 : 1.0< KDP<6.0)

P/N:

PC40EER28L-Z

P/N:

BEER-28L-1112H

KP

0.48

Core Type

EER28L

Core

EER28L

Bobbin

EER28L_BOBBIN

AE

0.847

0.847 cm^2

LE

7.83

7.83 cm

Core Effective Path Length

AL

2800

2800 nH/T^2

Ungapped Core Effective Inductance

BW

21.8

21.8 mm

Bobbin Physical Winding Width Safety Margin Width (Half the Primary to Secondary Creepage Distance)

M

3.15

L

2

Number of Primary Layers

NS DC INPUT VOLTAGE PARAMETERS

6

Number of Secondary Turns

VMIN

Page 16 of 24

mm

Core Effective Cross Sectional Area

87 Volts

Minimum DC Input Voltage

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25 VMAX

60W LCD Monitor Power Supply 375 Volts

Maximum DC Input Voltage

DMAX

0.58

Maximum Duty Cycle

IAVG

0.84 Amps

Average Primary Current

IP

1.89 Amps

Peak Primary Current

IR

0.91 Amps

Primary Ripple Current

IRMS

1.12 Amps

Primary RMS Current

LP

411 uHenries

Primary Inductance

NP

33

NB

5

ALG

381 nH/T^2

March 30, 2004

Primary Winding Number of Turns Bias Winding Number of Turns Gapped Core Effective Inductance

BM

2795 Gauss

Maximum Flux Density at PO, VMIN (BM<3000)

BP

3642 Gauss

Peak Flux Density (BP<4200)

BAC

671 Gauss

AC Flux Density for Core Loss Curves (0.5 X Peak to Peak)

ur

2060

Relative Permeability of Ungapped Core

LG

0.24 mm

Gap Length (Lg > 0.1 mm)

BWE

31 mm

Effective Bobbin Width

OD

0.94 mm

INS

0.08 mm

Estimated Total Insulation Thickness (= 2 * film thickness)

DIA

0.86 mm

Bare conductor diameter Primary Wire Gauge (Rounded to next smaller standard AWG value)

AWG CM

20 AWG

Maximum Primary Wire Diameter including insulation

1024 Cmils

Bare conductor effective area in circular mils !!!!!!!!!! DECREASE CMA> (decrease L(primary 918 Cmils/Amp layers),increase NS,smaller Core)

CMA Lumped parameters ISP

10.36 Amps

Peak Secondary Current

ISRMS

5.17 Amps

Secondary RMS Current

IO

3.00 Amps

Power Supply Output Current

IRIPPLE

4.21 Amps

Output Capacitor RMS Ripple Current

CMS

1034 Cmils

Secondary Bare Conductor minimum circular mils Secondary Wire Gauge (Rounded up to next larger standard AWG value)

AWGS

19 AWG

DIAS

0.91 mm

ODS

2.58 mm

Secondary Minimum Bare Conductor Diameter Secondary Maximum Outside Diameter for Triple Insulated Wire

INSS

0.83 mm

Maximum Secondary Insulation Wall Thickness

636 Volts

Maximum Drain Voltage Estimate (Includes Effect of Leakage Inductance)

VOLTAGE STRESS PARAMETERS VDRAIN PIVS

88 Volts

Output Rectifier Maximum Peak Inverse Voltage

PIVB

67 Volts

Bias Rectifier Maximum Peak Inverse Voltage

Page 17 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

9 Performance Data All measurements are performed at room temperature, and 60 Hz input line frequency. 9.1

Line and Load regulation

Load regulation: Line regulation: 9.2

19.96V for 0A – 0.5A, 19.95V for 0.51A – current limit. No change.

Efficiency 90.00

Efficiency (%)

88.00

86.00 90 Vac 120 Vac

84.00

220 Vac 264 Vac

82.00

80.00 0.5

1

1.5

2

2.5

3

Output Current (A)

Figure 8 – Efficiency versus Output current

Page 18 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25 9.3

60W LCD Monitor Power Supply

March 30, 2004

No-load Input Power 300

Input Power (mW)

280 260 240 220 Pin (No Load)

200 180 90

120

150

180

210

240

270

Input Voltage (Vac)

Figure 9 – No Load Input Power versus Input Voltage

9.4

Output Power for 1 W Input Power

Output Power (mW)

700

Pin = 1 W

650

600

550

500 90

120

150

180

210

240

270

Input Voltage (Vac)

Figure 10 – Output power versus Input voltage for 1 W Input power

Page 19 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

10 Output Ripple Measurements 10.1 Ripple Measurement Technique For DC output ripple measurements, a modified oscilloscope test probe must be utilized in order to reduce spurious signals due to pickup. Details of the probe modification are provided in Figure 11 and Figure 12. The 5125BA probe adapter is affixed with two capacitors tied in parallel across the probe tip. The capacitors include one (1) 0.1 µF/50 V ceramic type and one (1) 1.0 µF/50 V aluminum electrolytic. The aluminum electrolytic type capacitor is polarized, so proper polarity across DC outputs must be maintained (see below).

Probe Ground

Probe Tip Figure 11 – Oscilloscope Probe Prepared for Ripple Measurement (End Cap and Ground Lead Removed)

Figure 12 – Oscilloscope Probe with Probe Master 5125BA BNC Adapter (Modified with wires for probe ground for ripple measurement, and two parallel decoupling capacitors added)

Page 20 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

Figure 13 – Output Voltage Ripple (worst case) 90 Vac, 20V, 3A load

11 Over-voltage Protection This is the output voltage when the opto-coupler is shorted out, simulating an OVP condition. Vpeak = 23.6V.

Figure 14 – Output voltage with over-voltage protection

Page 21 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

12 Dynamic Load Transient

Figure 15 – Dynamic Load Transient – Step Load 1.5A ↔ 3A, 90 Vac

It can be seen that ∆VO = 308 mV only, which is well within the regulation band. Therefore, recovery time is irrelevant.

Page 22 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

13 Conducted EMI The conducted EMI tests are done at 220 Vac, 3A resistive load and for Neutral (worst case).

Figure 16 – Conducted EMI – EN55022 Class B, with 3-wire input, Neutral (worst case)

14 Revision History Date March 30, 2004

Page 23 of 24

Author MJ

Revision 1.0

Description & changes First Release

Reviewed VC / AM

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com

DER-25

60W LCD Monitor Power Supply

March 30, 2004

For the latest updates, visit our Web site: www.powerint.com Power Integrations reserves the right to make changes to its products at any time to improve reliability or manufacturability. Power Integrations does not assume any liability arising from the use of any device or circuit described herein, nor does it convey any license under its patent rights or the rights of others. The products and applications illustrated herein (including circuits external to the products and transformer construction) may be covered by one or more U.S. and foreign patents or potentially by pending U.S. and foreign patent applications assigned to Power Integrations. A complete list of Power Integrations’ patents may be found at www.powerint.com. The PI Logo, TOPSwitch, TinySwitch, LinkSwitch, and EcoSmart are ed trademarks of Power Integrations. PI Expert and DPA-Switch are trademarks of Power Integrations. © Copyright 2003, Power Integrations.

WORLD HEADQUARTERS Power Integrations 5245 Hellyer Avenue, San Jose, CA 95138, USA Main: +1-408-414-9200 Customer Service: Phone: +1-408-414-9665 Fax: +1-408-414-9765 e-mail: [email protected]

CHINA (SHENZHEN) Power Integrations International Holdings, Inc. Rm# 1705, Bao Hua Bldg. 1016 Hua Qiang Bei Lu, Shenzhen, Guangdong, 518031, China Phone: +86-755-8367-5143 Fax: +86-755-8377-9610 e-mail: [email protected]

ITALY Power Integrations s.r.l. Via Vittorio Veneto 12, Bresso, Milano, 20091, Italy Phone: +39-028-928-6001 Fax: +39-028-928-6009 e-mail: [email protected]

SINGAPORE (ASIA PACIFIC HEADQUARTERS) Power Integrations, Singapore 51 Newton Road, #15-08/10 Goldhill Plaza, Singapore, 308900 Phone: +65-6358-2160 Fax: +65-6358-2015 e-mail: [email protected]

AMERICAS Power Integrations, Inc. 4335 South Lee Street, Suite G, Buford, GA 30518, USA Phone: +1-678-714-6033 Fax: +1-678-714-6012 e-mail: [email protected]

Power Integrations, GmbH Rueckerstrasse 3, D-80336, Munich, Phone: +49-895-527-3910 Fax: +49-895-527-3920 e-mail: [email protected]

JAPAN Power Integrations, K.K. Keihin-Tatemono 1st Bldg. 12-20 Shin-Yokohama, 2-Chome, Kohoku-ku, Yokohama-shi, Kanagawa 222-0033, Japan Phone: +81-45-471-1021 Fax: +81-45-471-3717 e-mail: [email protected]

TAIWAN Power Integrations International Holdings, Inc. 17F-3, No. 510, Chung Hsiao E. Rd., Sec. 5, Taipei, Taiwan 110, R.O.C. Phone: +886-2-2727-1221 Fax: +886-2-2727-1223 e-mail: [email protected]

CHINA (SHANGHAI) Power Integrations International Holdings, Inc. Rm 807, Pacheer, Commercial Centre, 555 Nanjing West Road, Shanghai, 200041, China Phone: +86-21-6215-5548 Fax: +86-21-6215-2468 e-mail: [email protected]

INDIA (TECHNICAL ) Innovatech #1, (New #42) 8th Main Road, Vasanthnagar, Bangalore, India, 560052 Phone: +91-80-226-6023 Fax: +91-80-228-9727 e-mail: [email protected]

KOREA Power Integrations International Holdings, Inc. 8th Floor, DongSung Bldg. 17-8 Yoido-dong, Youngdeungpo-gu, Seoul, 150-874, Korea Phone: +82-2-782-2840 Fax: +82-2-782-4427 e-mail: [email protected]

UK (EUROPE & AFRICA HEADQUARTERS) Power Integrations (Europe) Ltd. Centennial Court, Easthampstead Road, Bracknell, Berkshire RG12 1YQ, United Kingdom Phone: +44-1344-462-300 Fax: +44-1344-311-732 e-mail: [email protected]

APPLICATIONS HOTLINE World Wide +1-408-414-9660

APPLICATIONS FAX World Wide +1-408-414-9760

Page 24 of 24

Power Integrations Tel: +1 408 414 9200 Fax: +1 408 414 9201 www.powerint.com
