Compatibility Matrix 3bk2l

Cisco Wireless Solutions Software Compatibility Matrix Last Updated: July 03, 2019

This document lists the software compatibility matrix information for the Cisco wireless devices used in a Cisco centralized and distributed wireless LAN solution and in converged access solutions.

Contents This document contains the following sections: •

Conventions, page 2

•

Cisco Catalyst 9800 Series Wireless Controllers, page 2

•

ed Access Points in Cisco Wireless Software Releases, page 2

•

ed Cisco WLC Platforms in Software Releases, page 16

•

Cisco Prime Infrastructure Compatibility Matrix, page 17

•

Cisco Connected Mobile Experiences (CMX) Compatibility Matrix, page 68

•

Cisco Mobility Services Engine Compatibility Matrixes, page 72

•

Cisco Mobility Express Solution Compatibility Matrix, page 90

•

Converged Access Solution Compatibility Matrix, page 93

•

ed Converged Access Solution Hardware, page 98

•

Compatibility Matrix for Legacy Products, page 99

•

Inter-Release Controller Mobility, page 116

•

New Mobility Matrix, page 119

•

Cisco Community, page 121

•

Communications, Services, and Additional Information, page 121

•

Cisco Bug Search Tool, page 121

Cisco Systems, Inc. www.cisco.com

Conventions

Conventions See Cisco Technical Tips Conventions for information about document conventions.

Cisco Catalyst 9800 Series Wireless Controllers This section contains compatibility information about the Cisco Catalyst 9800 Series Wireless Controllers. Table 1

Cisco Catalyst 9800 Series Wireless Controllers Release Compatibility Matrix1

Cisco Catalyst 9800 Series Wireless Controllers

Cisco Identity Services Engine (ISE)

Cisco Access Control Server (ACS)

Cisco Prime Infrastructure

Cisco AireOS-IRCM Interoperability

Cisco DNA Center

Cisco IOS XE Gibraltar 16.11.1c

2.6 2.4 2.3

5.5 5.4

3.6 3.5

8.9.100.0 8.8.120.0 8.8.111.0

1.3.0.2

Cisco IOS XE Gibraltar 16.11.1b

2.6 2.4 2.3

5.5 5.4

3.6 3.5

8.9.100.0 8.8.120.0 8.8.111.0

—

Cisco IOS XE Gibraltar 16.10.1

2.4 2.3 2.2

5.5 5.4

3.5

8.8.111.0

—

Cisco IOS XE Gibraltar 16.10.1e

2.4 2.3 2.2

5.5 5.4

3.5

8.8.111.0

1.2.10

1. For Cisco CMX compatibility details, see the Cisco Connected Mobile Experiences (CMX) Compatibility Matrix, page 68.

Table 2

Wireless Controller Foreign and Anchor

Foreign + Anchor

Cisco Catalyst 9800 Wireless Controller for Cloud

Cisco Catalyst 9800-40 Wireless Controller

Cisco Catalyst 9800-80 Wireless Controller

Cisco 3504 Controller

Y

Y

Y


Y

Y

Y


Y

Y

Y

ed Access Points in Cisco Wireless Software Releases Table 3 lists the ed access points for various Cisco Wireless software releases.

Cisco Wireless Solutions Software Compatibility Matrix

2

ed Access Points in Cisco Wireless Software Releases

For information about compatibility of Cisco Prime Infrastructure with Cisco WLC, see the “Cisco Prime Infrastructure Compatibility Matrix” section on page 17. For information about compatibility of Cisco Mobility Services Engine with Cisco WLC, see the “Cisco Mobility Services Engine Compatibility Matrixes” section on page 72. For compatibility information about Cisco WLC and Cisco ISE, see the Cisco ISE Compatibility Information page. Table 3

Cisco Catalyst 9800 Wireless Controller and ed Access Points

Cisco WLC Release

Access Point Release

ed Access Points

Cisco IOS XE Gibraltar 16.11.1b

15.3(3)JPH2

Lightweight APs: 9115, 9117, 9120, 1700, 1800, 2700, 2800, 3700, 3800, 4800 Series Access Points Cisco Industrial Wireless 3700 Series Access Points Outdoor and Industrial APs: 1542, 1560, 1570 Sensors: Cisco Aironet 1800s Active Sensor

Cisco IOS XE Gibraltar 16.10.1

15.3(3)JI1

Lightweight APs: 1700, 1800, 2700, 2800, 3700, 3800, 4800 Series Access Points Outdoor and Industrial APs: 1542, 1560, 1570 Sensors: Cisco Aironet 1800s Active Sensor

Table 4

Cisco WLC Software Releases, AP IOS Releases, and ed Access Points

Cisco WLC Access Point Release IOS Release 8.9.111.0

15.3(3)JJ1

ed Access Points Lightweight APs: 9120, 9117, 9115, 1700, 1800i, 1810 OEAP, 1810W, 1815i, 1815m, 1815t, 1815w, 1830, 1850, 2700, 2800, 3702e, 3702i, 3702p, 3800, 4800, 700, 700W, AP803, Integrated Access Point on Cisco 1100 ISR, Cisco 1101 ISR, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1540, 1560, 1570, and IW3700 Modules: AIR-RM3010L-x-K9 and AIR-RM3000M

8.9.100.0

15.3(3)JJ

Lightweight APs: 9115, 9117, 1700, 1800i, 1810 OEAP, 1810W, 1815i, 1815m, 1815t, 1815w, 1830, 1850, 2700, 2800, 3702e, 3702i, 3702p, 3800, 4800, 700, 700W, AP803, Integrated Access Point on Cisco 1100 ISR, Cisco 1101 ISR, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1540, 1560, 1570, and IW3700 Modules: AIR-RM3010L-x-K9 and AIR-RM3000M

8.8.125.0

15.3(3)JI5

8.8.120.0

15.3(3)JI4

8.8.111.0

15.3(3)JI3

8.8.100.0

15.3(3)JI1

Lightweight APs: 1700, 1800i, 1810 OEAP, 1810W, 1815i, 1815m, 1815t, 1815w, 1830, 1850, 2700, 2800, 3702e, 3702i, 3702p, 3800, 4800, 700, 700W, AP803, Integrated Access Point on Cisco 1100 ISR, Cisco 1101 ISR, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1540, 1560, 1570, and IW3700 Modules: AIR-RM3010L-x-K9 and AIR-RM3000M


3


Table 4

Cisco WLC Software Releases, AP IOS Releases, and ed Access Points (continued)


15.3(3)JH1

ed Access Points Lightweight APs: 1700, 1800i, 1810 OEAP, 1810W, 1815i, 1815m, 1815t, 1815w, 1830, 1850, 2700, 2800, 3702e, 3702i, 3702p, 3800, 4800, 700, 700W, AP803, Integrated Access Point on Cisco 1100 ISR, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1540, 1560, 1570, and IW3700 Modules: AIR-RM3010L-x-K9 and AIR-RM3000M

8.7.102.0

15.3(3)JH

Lightweight APs: 1700, 1800i, 1810 OEAP, 1810W, 1815i, 1815m, 1815t, 1815w, 1830, 1850, 2700, 2800, 3702e, 3702i, 3702p, 3800, 700, 700W, AP803, Integrated Access Point on Cisco 1100 ISR, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1540, 1560, 1570, and IW3700 Modules: AIR-RM3010L-x-K9 and AIR-RM3000M

8.6.101.0

15.3(3)JG1

Lightweight APs: 1700, 1800i, 1810 OEAP, 1810W, 1815i, 1815m, 1815t, 1815w, 1830, 1850, 2700, 2800, 3702e, 3702i, 3702p, 3800, 700, 700W, AP803, Integrated Access Point on Cisco 1100 ISR, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1540, 1560, 1570, and IW3700 Modules: AIR-RM3010L-x-K9 and AIR-RM3000M

8.5.151.0

15.3(3)JF10

Lightweight APs: 1600, 1700, 1800i, 1810 OEAP, 1810W, 1815i, 1815m, 1815t, 1815w, 1830, 1850, 2600, 2700, 2800, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 3800, 700, 700W, AP802, AP803, Integrated Access Point on Cisco 1100 ISR, ASA5506W-AP702

8.5.140.0

15.3(3)JF9

8.5.135.0

15.3(3)JF8

8.5.131.0

15.3(3)JF7

8.5.120.0

15.3(3)JF5

Outdoor and Industrial APs: 1532E, 1532I, 1540, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, 1560, 1570, and IW3700

8.5.110.0

15.3(3)JF4

Note

8.5.105.0

15.3(3)JF1

8.5.103.0

15.3(3)JF

8.4.100.0

15.3(3)JE

The Cisco Aironet 1550 Series APs with 64-MB memory are not ed.

Modules: AIR-RM3010L-x-K9 and AIR-RM3000M Lightweight APs: 1600, 1700, 1810 OEAP, 1810W, 1815i, 1815w, 1830, 1850, 2600, 2700, 2800, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 3800, 700, 700W, AP802, AP803, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, 1560, 1570, and IW3700 Note

The Cisco Aironet 1550 Series APs with 64-MB memory are not ed.

Modules: AIR-RM3010L-x-K9 and AIR-RM3000M


4


Table 4



15.3(3)JD17 15.3(3)JDA17

8.3.143.0

15.3(3)JD16 15.3(3)JDA16

8.3.141.0

15.3(3)JD14 15.3(3)JDA14

8.3.140.0

15.3(3)JD13 15.3(3)JDA13

8.3.133.0

15.3(3)JD11 15.3(3)JDA11

8.3.132.0

15.3(3)JD9 15.3(3)JDA9

8.3.130.0

15.3(3)JD7, 15.3(3)JDA7

8.3.122.0 8.3.121.0

15.3(3)JD6 15.3(3)JD5

8.3.112.0

15.3(3)JD4

ed Access Points Lightweight APs: 1040, 1140, 1260, 1600, 1700, 1810 OEAP, 1810W, 1815i, 1830, 1850, 2600, 2700, 2800, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 3800, 600 OEAP, 700, 700W, AP802, AP803, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, 1560, 1570, and IW3700 Modules: AIR-RM3010L-x-K9 and AIR-RM3000M The Cisco 1040 Series, 1140 Series, and 1260 Series access points have feature parity with Cisco Wireless Release 8.0. Features introduced in Cisco Wireless Release 8.1 or later are not ed on these access points.

Lightweight APs: 1040, 1140, 1260, 1600, 1700, 1810 OEAP, 1810W, 1815i, 1830, 1850, 2600, 2700, 2800, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 3800, 600 OEAP, 700, 700W, AP802, AP803, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, 1560, 1570, and IW3700 Modules: AIR-RM3010L-x-K9 and AIR-RM3000M The Cisco 1040 Series, 1140 Series, and 1260 Series access points have feature parity with Cisco Wireless Release 8.0. Features introduced in Cisco Wireless Release 8.1 or later are not ed on these access points.

8.3.102.0

15.3(3)JD

Lightweight APs: 1040, 1140, 1260, 1600, 1700, 1810 OEAP, 1810W, 1830, 1850, 2600, 2700, 2800, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 3800, 600 OEAP, 700, 700W, AP802, AP803, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, 1570, and IW3700 Modules: AIR-RM3010L-x-K9 and AIR-RM3000M Note

The Cisco 1040 Series, 1140 Series, and 1260 Series access points have feature parity with Cisco Wireless Release 8.0. Features introduced in Cisco Wireless Release 8.1 and later are not ed on these access points.


5


Table 4



15.3(3)JC15 15.3(3)JCA15

8.2.166.0

15.3(3)JC14 15.3(3)JCA14

8.2.164.0

15.3(3)JC9 15.3(3)JCA9

8.2.161.0

15.3(3)JC8 15.3(3)JCA8

8.2.160.0

15.3(3)JC7

8.2.151.0

15.3(3)JC6

8.2.141.0

15.3(3)JC5

8.2.130.0

15.3(3)JC4

8.2.121.0

15.3(3)JC3

ed Access Points Lightweight APs: 1040, 1140, 1260, 1600, 1700, 1810 OEAP, 1810W, 1830, 1850, 2600, 2700, 2800, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 3800, 600 OEAP, 700, 700W, AP802, AP803, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, 1570, and IW3700 Modules: AIR-RM3010L-x-K9 and AIR-RM3000M Note



8.2.111.0

15.3(3)JC2



8.2.110.0

15.3(3)JC1




Note

Initial for –B regulatory domain APs.


6


Table 4



15.3(3)JC

ed Access Points Lightweight APs: 1040, 1140, 1260, 1600, 1700, 1830, 1850, 2600, 2700, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 600 OEAP, 700, 700W, AP802, AP803, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, 1570, and IW3700 Modules: AIR-RM3010L-x-K9 and AIR-RM3000M Note

8.1.131.0

15.3(3)JBB6


Lightweight APs: 1040, 1140, 1260, 1600, 1700, 1830, 1850, 2600, 2700, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 600 OEAP, 700, 700W, AP802, AP803, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, 1570, and IW3700 Modules: AIR-RM3010L-x-K9 and AIR-RM3000M Note

8.1.122.0

15.3(3)JBB5


Lightweight APs: 1040, 1140, 1260, 1600, 1700, 1830, 1850, 2600, 2700, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 600 OEAP, 700, 700W, AP802, AP803, ASA5506W-AP702 Outdoor and Industrial APs: 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, 1570, and IW3700 Note

8.1.111.0

15.3(3)JBB1


Lightweight APs: 1040, 1140, 1260, 1600, 1700, 1850, 2600, 2700, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 600 OEAP, 700, 700W, and AP802 Outdoor and Industrial APs: 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, and 1570 Note

8.1.102.0

15.3(3)JBB


Lightweight APs: 1040, 1140, 1260, 1600, 1700, 2600, 2700, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 600 OEAP, 700, 700W, and AP802 Outdoor and Industrial APs: 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, and 1570 Note



7


Table 4



8.0.150.0

8.0.140.0 8.0.135.0

ed Access Points

153-3.JA12 Lightweight APs: 1040, 1130, 1140, 1240, 1250, 1260, 1600, 1700, 2600, 2700, 3500e, 3500i, 15.3(3)JAA12 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 600 OEAP, 700, 700W, AP801, and AP802 12.4(25e)JAP12 Note Cisco MSE Release 8.0.140.9 and later includes wIPS and CAS for the Cisco 15.3(3)JA11 Aironet 1800, 2800, and 3800 series. 15.3(3)JAA11 12.4(25e)JAP11 Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, 1570, and IW3702 15.3(3)JA10/ 12.4(25e)JAP10 Note The Cisco Wireless Release 8.0.135.0 is a repost of the Cisco Wireless Release 8.0.132.0 and 8.0.133.0. This release impacts only the Cisco Aironet 1570 Series APs 15.3(3)JA9/ with -B regulatory domain and meet the following criteria: 12.4(25e)JAP9 a. The Cisco 1570 APs that are made available on or after June 2, 2016, for the USA

region b. The Cisco 1570 APs that are identified with version ID 02 (V02)

This release ensures that Cisco 1570 APs that are made available to customers in the USA are in compliance with the new FCC rules that come into effect on June 2, 2016. 8.0.133.0

15.3(3)JA8/ 12.4(25e)JAP8

Lightweight APs: 1040, 1130, 1140, 1240, 1250, 1260, 1600, 1700, 2600, 2700, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 600 OEAP, 700, 700W, AP801, and AP802

8.0.132.0

15.3(3)JA7/ 12.4(25e)JAP7

Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, 1570, and IW3702 Note


8.0.121.0

15.3(3)JA5/ 12.4(25e)JAP5

Lightweight APs: 1040, 1130, 1140, 1240, 1250, 1260, 1600, 1700, 2600, 2700, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 600 OEAP, 700, 700W, AP801, and AP802

8.0.120.0

15.3(3)JA4/ 12.4(25e)JAP4

Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, 1570, and IW3702

8.0.110.0 8.0.115.0

15.3(3)JA1/ 12.4(25e)JAP1

Lightweight APs: 1040, 1130, 1140, 1240, 1250, 1260, 1600, 1700, 2600, 2700, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 600 OEAP, 700, 700W, AP801, and AP802 Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, 1552S, and 1570

8.0.100.0

15.3(3)JAB/ 12.4(25e)JAP

Lightweight APs: 1040, 1130, 1140, 1240, 1250, 1260, 1600, 1700, 2600, 2700, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 600 OEAP, 700, 700W, AP801, and AP802 Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, and 1552S

7.6.130.0

15.2(4)JB6/ 12.4.25e-JAO6

Lightweight APs: 1040, 1130, 1140, 1240, 1250, 1260, 1600, 2600, 2700, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 600 OEAP, 700, 700W, AP801, and AP802

7.6.120.0

15.2(4)JB5/ 12.4(25e)JAO5

Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, and 1552S

7.6.110.0

15.2(4)JB4/ 12.4(25e)JAO4

Lightweight APs: 1040, 1130, 1140, 1240, 1250, 1260, 1600, 2600, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 3702e, 3702i, 3702p, 600 OEAP, 700, AP801, and AP802

7.6.100.0

15.2(4)JB3/ 12.4(25e)JAO3

Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1532E, 1532I, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, and 1552S


8


Table 4



15.2(4)JA1/ 12.4(25e)JAN1

ed Access Points Lightweight APs: 1040, 1130, 1140, 1240, 1250, 1260, 1600, 2600, 3500e, 3500i, 3500p, 3600e, 3600i, 3600p, 600 OEAP, 700, AP801, and AP802 Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, and 1552S

7.4.150.0

15.2(2)JB6/ 12.4(25e)JAM6

Lightweight APs: 1040, 1130, 1140, 1240, 1250, 1260, 1600, 2600, 3500e, 3500i, 3500p, 3600e, 3600i, 600 OEAP, AP801, AP802 Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, and 1552S Note


7.4.140.0

15-2(2)JB5/ 12.4(25e)JAM5

Lightweight APs: 1040, 1130, 1140, 1240, 1250, 1260, 1600, 2600, 3500e, 3500i, 3500p, 3600e, 3600i, 600 OEAP, AP801, AP802

7.4.130.0

15.2(2)JB3/ 12.4(25e)JAM4

Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, and 1552S

7.4.121.0

15.2(2)JB3/ 12.4(25e)JAM3

7.4.110.0

15.2(2)JB2/ 12.4(25e)JAM2

7.4.100.60 15.2(2)JB1/ 12.4(25e)JAM1 7.4.100.0

15.2(2)JB/ 12.4(25e)JAM

7.3.112.0

15.2(2)JA1/ 12.4(25e)JAL2

Lightweight APs: 1040, 1130, 1140, 1240, 1250, 1260, 2600, 3500e, 3500i, 3600e, 3600i, 3500p, 600 OEAP, AP801, and AP802

7.3.101.0

15.2(2)JA/ 12.4(25e)JAL

Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1552E, 1552H, 1552I, 1552C, 1552EU, 1552CU, and 1552S

7.2.115.2

12.4(25e)JA2

7.2.111.3

12.4(25e)JA2

Lightweight APs: 1040, 1130, 1140, 1240, 1250, 1260, 2600, 3500e, 3500i, 3500p, 3600e, 3600i, 600 OEAP, AP801, and AP802

7.2.110.0

12.4(25e)JA1

Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1552E, 1552H, 1552I, 1552C, and 1552S

7.2.103.0

12.4(25e)JA

Lightweight APs: 1040, 1130, 1140, 1240, 1250, 1260, 3500e, 3500i, 3600e, 3500p, 3600i, 600 OEAP, AP801, and AP802 Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1552E, 1552H, 1552I, 1552C, and 1552S

7.0.252.0

12.4(23c)JA10

7.0.251.2

12.4(23c)JA9

Lightweight APs: 1040, 1120, 1130, 1140, 1220, 1230, 1240, 1250, 1260, 1300, 3500, OEAP 600 Series, 3500p, AP801, and AP802

7.0.250.0

12.4(23c)JA8

Outdoor and Industrial APs: 1522, 1524SB, 1552E, 1552H, 1552I, 1552C, and 1552S

7.0.240.0

12.4(23c)JA7

7.0.235.3

12.4(23c)JA6

7.0.235.0

12.4(23c)JA5

7.0.230.0

12.4(23c)JA4

7.0.220.0

12.4(23c)JA3


9


Table 4



12.4(23c)JA2

ed Access Points Lightweight APs: 1040, 1120, 1130, 1140, 1220, 1230, 1240, 1250, 1260, 3500e, 3500i, 3500p, 600 OEAP, AP801, AP802 Outdoor and Industrial APs: 1522, 1524PS, 1524SB, 1552E, 1552H, 1552I, and 1552C

7.0.98.218 12.4(23c)JZ 7.0.98.0

12.4(23c)JA

Lightweight APs: 1040, 1120, 1130, 1140, 1220, 1230, 1240, 1250, 1260, 1300, 3500, and AP801 Outdoor and Industrial APs: 1522, 1524PS, and 1524SB

6.0.202.0

12.4(21a)JHC

Lightweight APs: 1120, 1130, 1140, 1230AG, 1240, 1250, 1300, and AP801 Outdoor and Industrial APs: 1522, 1524PS, and 1524SB

5.2.193.0

12.4(18a)JA2

Lightweight APs: 1120, 1130, 1140, 1220, 1230AG, 1240, 1250, 1300, and AP801 Outdoor and Industrial APs: 1522 and 1524PS

4.1.192.35 — M (Mesh Release 3)

1505, 1510, 1522, 1524PS, 1130, 1240

4.1.191.24 — M (Mesh Release 2)

1505, 1510, 1522 (US, Canada, and RoW), 1130, 1240

4.1.190.5 — (Mesh Release 1)

1505, 1510, 1522 (US and Canada)

Software Release for Specific Access Point Modules Table 5 lists the Cisco WLC software releases that specific Cisco access point modules. The First column lists the earliest Cisco WLC software release that s the access point module. For access point modules that are not ed in ongoing releases, the Last column lists the last release that s the access point module. Table 5

Software for Access Point Modules

First Cisco Wireless Release

Last Cisco Wire- First Cisco IOS less Release XE Release

Last Cisco IOS XE Release

AIR-CAP702Wx-K9

7.6.120.0

—

3.6.0E

—

AIR-CAP702W-xK910

7.6.120.0

—

3.6.0E

—

AIR-CAP702I-x-K9

7.5.102.0

—

3.6.0E

—

AIR-CAP702W-x-K9

7.6.120.0

—

3.6.0E

—

Access Points 700W Series 700 Series


10


Table 5

Software for Access Point Modules (continued)




AIR-AP1010

3.0.100.0

4.2.209.0

—

—

AIR-AP1020

3.0.100.0

4.2.209.0

—

—

AIR-AP1030

3.0.100.0

4.2.209.0

—

—

Airespace AS1200

—

4.0

—

—

AIR-LAP1041N

7.0.98.0

8.3.x

3.2.0SE

—

AIR-LAP1042N

7.0.98.0

8.3.x

3.2.0SE

—

AIR-LAP1121

4.0.155.0

7.0.x

—

—

AIR-LAP1131

3.1.59.24

8.0.x

—

—

AIR-LAP1141N

5.2.157.0

8.3.x

3.2.0SE

—

AIR-LAP1142N

5.2.157.0

8.3.x

3.2.0SE

—

AIR-AP1220A

3.1.59.24

7.0.x

—

—

AIR-AP1220B

3.1.59.24

7.0.x

—

—

AIR-AP1230A

3.1.59.24

7.0.x

—

—

AIR-AP1230B

3.1.59.24

7.0.x

—

—

AIR-LAP1231G

3.1.59.24

7.0.x

—

—

AIR-LAP1232AG

3.1.59.24

7.0.x

—

—

AIR-LAP1242G

3.1.59.24

8.0.x

—

—

AIR-LAP1242AG

3.1.59.24

8.0.x

—

—

AIR-LAP1250

4.2.61.0

8.0.x

—

—

AIR-LAP1252G

4.2.61.0

8.0.x

—

—

AIR-LAP1252AG

4.2.61.0

8.0.x

—

—

AIR-LAP1261N

7.0.116.0

8.3.x

3.2.0SE

—

AIR-LAP1262N

7.0.98.0

8.3.x

3.2.0SE

—

1300 Series

AIR-BR1310G

4.0.155.0

7.0.x

—

—

1400 Series

Standalone Only

N/A

—

—

—

1600 Series

AIR-CAP1602I-x-K9

7.4.100.0

8.5.x

3.2.0SE

—

AIR-CAP1602I-xK910

7.4.100.0

8.5.x

3.2.0SE

—

AIR-SAP1602I-x-K9

7.4.100.0

8.5.x

3.2.0SE

—

AIR-SAP1602I-xK9-5

7.4.100.0

8.5.x

3.2.0SE

—

AIR-CAP1602E-x-K9

7.4.100.0

8.5.x

3.2.0SE

—

AIR-SAP1602E-xK9-5

7.4.100.0

8.5.x

3.2.0SE

—

AIR-CAP1702I-x-K9

8.0.100.0

—

3.7.0E

—

AIR-CAP1702I-xK910

8.0.100.0

—

3.7.0E

—

1810 Series

AIR-OEAP1810-x-K9

8.2.110.0

—

—

—

1810W Series

AIR-AP1810W-x-K9

8.2.110.0

—

—

—

Access Points 1000 Series

1100 Series

1220 Series 1230 Series


1260 Series

1700 Series


11


Table 5





AIR-AP1815I-x-K9

8.3.112.0

—

—

—

AIR-AP1815W-x-K9

8.4.100.0

—

—

—

AIR-AP1815M-x-K9

8.5.103.0

—

—

—

AIR-AP1815T-x-K9

8.5.103.0

—

—

—

AIR-AP1832I-UXK9

8.1.122.0

—

3.7.3

—

AIR-AP1832I-UXK910

8.1.122.0

—

3.7.3

—

AIR-AP1832I-UXK9C

8.1.122.0

—

3.7.3

—

AIR-AP1832I-UXK910C

8.1.122.0

—

3.7.3

—

AIR-AP1832I-x-K9

8.1.122.0

—

3.7.3

—

AIR-AP1832I-x-K9C

8.1.122.0

—

3.7.3

—

AIR-AP1852I-UXK9

8.1.111.0

3.7.3

—

AIR-AP1852I-UXK910

8.1.111.0

3.7.3

—

AIR-AP1852I-UXK9C

8.1.111.0

3.7.3

—

AIR-AP1852I-UXK910C

8.1.111.0

3.7.3

—

AIR-AP1852E-UXK9

8.1.111.0

3.7.3

—

AIR-AP1852E-UXK910

8.1.111.0

3.7.3

—

AIR-AP1852E-UXK9C

8.1.111.0

3.7.3

—

AIR-AP1852E-UXK910C

8.1.111.0

3.7.3

—

AIR-AP1852E-x-K9

8.1.111.0

3.7.3

—

AIR-AP1852E-x-K9C

8.1.111.0

3.7.3

—

AIR-AP1852I-x-K9

8.1.111.0

3.7.3

—

AIR-AP1852I-x-K9C

8.1.111.0

3.7.3

—

AP801

—

5.1.151.0

8.0.x

—

—

AP802

—

7.0.98.0

8.5.x

—

—

AP802H

—

7.3.101.0

8.5.x

—

—

AP803

—

8.1.122.0

—

—

—

Integrated Access Point on Cisco 1100 ISR

ISR-AP1100AC-X

8.5.103.0

—

—

—

Integrated Access Point on Cisco 1101 ISR

ISR-AP1101AC-X

8.8.100.0

—

—

—

ISR-AP1101AC-I-X

8.8.100.0

—

—

—

ASA 5506W-AP702

—

8.1.122.0

—

—

—


1830 Series

1850 Series


12


Table 5





AIR-CAP2602I-x-K9

7.2.110.0

8.5.x

3.2.0SE

—

AIR-CAP2602I-xK910

7.2.110.0

8.5.x

3.2.0SE

—

AIR-SAP2602I-x-K9

7.2.110.0

8.5.x

3.2.0SE

—

AIR-SAP2602I-x-K95

7.2.110.0

8.5.x

3.2.0SE

—

AIR-CAP2602E-x-K9

7.2.110.0

8.5.x

3.2.0SE

—

AIR-CAP2602E-xK910

7.2.110.0

8.5.x

3.2.0SE

—

AIR-CAP2702I-x-K9

7.6.120.0

—

3.6.0E

—

AIR-CAP2702E-x-K9

7.6.120.0

—

3.6.0E

—

AIR-AP2702I-UXK9

8.0.110.0

—

—

—

AIR-AP2802E-x-K9

8.2.110.0

—

—

—

AIR-AP2802I-x-K9

8.2.110.0

—

—

—

AIR-CAP3501E

7.0.98.x

8.5.x

3.2.0SE

—

AIR-CAP3501I

7.0.98.x

8.5.x

3.2.0SE

—

AIR-CAP3502E

7.0.98.x

8.5.x

3.2.0SE

—

AIR-CAP3502I

7.0.98.x

8.5.x

3.2.0SE

—

AIR-CAP3502P

7.0.116.0

8.5.x

3.2.0SE

—

AIR-CAP3602I

7.1.91.0

8.5.x

3.2.0SE

—

AIR-CAP3602E

7.1.91.0

8.5.x

3.2.0SE

—

AIR-CAP3702I

7.6.100.0

—

3.3.1SE

—

AIR-CAP3702E

7.6.100.0

—

3.3.1SE

—

AIR-CAP3702P

7.6.100.0

—

3.3.1SE

—

AIR-AP3802E-x-K9

8.2.110.0

—

—

—

AIR-AP3802I-x-K9

8.2.110.0

—

—

—

AIR-AP3802P-x-K9

8.2.110.0

—

—

—

AIR-AP4800-x-K9

8.7.106.0

—

—

—

AIR-AP4800-x-K9C

8.7.106.0

—

—

—

91201

C9120AXI-x

8.9.111.0

—

Gibraltar 16.11.1b

—

9117

C9117AXI-x

8.9.100.0

—

Gibraltar 16.11.1b

—

9115

C9115AXI-x C9115AXE-x

8.9.100.0

—

Gibraltar 16.11.1b

—

600 Series

AIR-OEAP602I

7.0.116.0

8.3.x

—

—

1500 Mesh Series

AIR-LAP-1505

3.1.59.24

4.2.207.54M

—

—

AIR-LAP-1510

3.1.59.24

4.2.207.54M

—

—


2700 Series



3800 Series

4800 Series


13


Table 5




-A and N: 4.1.190.1 or 5.2 or later2

8.0.x

—

—

All other reg. domains: 4.1.191.24M or 5.2 or later1

8.0.x

—

—

-A and N: 4.1.190.1 or 5.2 or later1

8.0.x

—

—


8.0.x

—

—

-A and N: 4.1.190.1 or 5.2 or later1

8.0.x

—

—


8.0.x

—

—

AIR-LAP1523CM

7.0.116.0 or later.

8.0.x

—

—

AIR-LAP1524SB

-A, C and N: 6.0 or later

8.0.x

—

—

All other reg. domains: 7.0.116.0 or later.

8.0.x

—

—

AIR-LAP1524PS

-A: 4.1.192.22M or 5.2 or later1

8.0.x

—

—

AIR-CAP1532I-x-K9

7.6.100.0

—

3.6.0E3

—

AIR-CAP1552E-x-K9

7.6.100.0

—

3.6.0E

—

AIR-AP1542I-x-K9

8.5.103.0

—

—

—

AIR-AP1542D-x-K9

8.5.103.0

—

—

—

AIR-CAP1552I-x-K9

7.0.116.0

8.5.x

—

—

AIR-CAP1552E-x-K9

7.0.116.0

8.5.x

—

—

AIR-CAP1552C-x-K9

7.0.116.0

8.5.x

—

—

AIR-CAP1552H-x-K9

7.0.116.0

8.5.x

—

—

AIR-CAP1552SA-x-K9

7.0.220.0

8.5.x

—

—

AIR-CAP1552SD-x-K9

7.0.220.0

8.5.x

—

—

AIR-CAP1552CU-x-K9

7.3.101.0

8.5.x

—

—

AIR-CAP1552EU-x-K9

7.3.101.0

8.5.x

—

—


Access Points 1520 Mesh Series

AIR-LAP1522AG

AIR-LAP1522HZ

AIR-LAP1522PC

1530 Series 1540 Series 1550 Series

4


14


Table 5





AIR-CAP1552SA-x-K9

7.0.220.0

8.5.x

—

—

AIR-CAP1552SD-x-K9

7.0.220.0

8.5.x

—

—

AIR-AP1562I-x-K9

8.3.111.0

—

—

—

AIR-AP1562E-x-K9

8.3.111.0

—

—

—

AIR-AP1562D-x-K9

8.3.111.0

—

—

—

AIR-AP1572EAC-x-K9

8.0.110.0

—

3.7.0E

—

AIR-AP1572ICy -x-K9

8.0.110.0

—

3.7.0E

—

AIR-AP1572ECy-x-K9

8.0.110.0

—

3.7.0E

—

AIR-AP1572EAC-B-K9

8.0.135.0

—

—

—

AIR-AP1572EC1-B-K9

8.0.135.0

—

—

—

AIR-AP1572EC2-B-K9

8.0.135.0

—

—

—

AIR-AP1572IC1-B-K9

8.0.135.0

—

—

—

AIR-AP1572IC2-B-K9

8.0.135.0

—

—

—

IW3702-2E-UXK9

8.0.120.0

—

—

—

IW3702-4E-UXK9

8.0.120.0

—

—

—

IW3702-2E-B-K9

8.2.110.0

—

—

—

IW3702-4E-B-K9

8.2.110.0

—

—

—

IW3702-2E-M-K9

8.3.102.0

—

—

—

IW3702-4E-M-K9

8.3.102.0

—

—

—

IW3702-2E-R-K9

8.3.102.0

—

—

—

IW3702-4E-R-K9

8.3.102.0

—

—

—

IW3702-2E-Q-K9

8.3.102.0

—

—

—

IW3702-4E-Q-K9

8.3.102.0

—

—

—

IW3702-2E-S-K9

8.3.102.0

—

—

—

IW3702-4E-S-K9

8.3.102.0

—

—

—

Access Points 1552S 1560 Series

1570 version ID 01 (V01)

1570 version ID 02 (V02)

IW3700

5

1. Cisco Catalyst 9120, 9117, 9115 Access Points Regulatory domains: Customers are responsible for ing approval for use in their individual countries. To approval and to identify the regulatory domain that corresponds to a particular country, visit https://www.cisco.com/go/aironet/compliance. Not all regulatory domains have been approved. As they are approved, the part numbers will be available on the Global Price List. 2. These access points are ed in the separate 4.1.19x.x mesh software release or with release 5.2 or later releases. These access points are not ed in the 4.2, 5.0, or 5.1 Releases. 3. The Cisco Aironet 1530 Series APs are ed operating only in Local mode; these APs in mesh mode are not ed. 4. The Cisco Aironet 1550 Series APs with 64-MB memory are not ed from Release 8.4. 5. y—Country DOCSIS Compliance, see ordering guide for details.


15

ed Cisco WLC Platforms in Software Releases

Related Information •

See the relevant release notes before you perform any software upgrade: https://www.cisco.com/c/en/us//wireless/wireless-lan-controller-software/products-releasenotes-list.html.

•

Product Approval Status: https://prdapp.cloudapps.cisco.com/cse/prdapp/jsp/externalsearch.do?action=externalsearch&page =EXTERNAL_SEARCH

•

Wireless LAN Compliance Lookup: https://www.cisco.com/c/dam/assets/prod/wireless/wireless-compliance-tool/index.html

ed Cisco WLC Platforms in Software Releases Table 6 lists the Cisco WLC software releases in which the started and ended, as applicable, for various Cisco WLC hardware platforms. Table 6

Cisco WLC Platform in Software Releases

Cisco WLC Platform

First

Last

2100

4.2.x

7.x

2504

7.0.x

8.5

3504

8.5

—

4400

4.2.x

7.x

5508

6.0.x

8.5

5520

8.1.x

—

7510

7.0.x

8.5

8510

7.3.x

8.5

8540

8.1.x

—

Virtual Controller (vWLC)

7.3.x

—

WiSM

4.2.x

7.x

WiSM2 (1 DP)

7.0.x

8.5

WiSM2 (2 DP)

7.2.x

8.5

SRE

7.0.x

—

For information about ed hardware for Cisco Converged Access Solution, see the “ed Converged Access Solution Hardware” section on page 98


16

Cisco Prime Infrastructure Compatibility Matrix

Cisco Prime Infrastructure Compatibility Matrix This section contains the following topics: •

Cisco Prime Infrastructure and Cisco Wireless Release Compatibility Matrix, page 17

•

Cisco Prime Infrastructure and Cisco Converged Access Solution Compatibility Matrix, page 58

Cisco Prime Infrastructure and Cisco Wireless Release Compatibility Matrix Table 7 lists the Cisco WLC releases, Cisco CMX releases, Cisco Mobility Service Engine (MSE) releases, and Identity Services Engine (ISE) versions that are compatible with the Cisco Prime Infrastructure releases. For information about wireless device in Cisco Prime Infrastructure, see the following URL: https://www.cisco.com/c/en/us//cloud-systems-management/prime-infrastructure/products-devi ce--tables-list.html


17



18


Table 7

Cisco Prime Infrastructure and Cisco Wireless Release Compatibility Matrix1

Cisco Prime Infrastructure Cisco WLC

ISE

3.6

2.6

8.9.111.0 8.9.100.0 8.8.125.0 8.8.120.0 8.8.111.0 8.8.100.0 8.7.106.0 8.7.102.0 8.6.101.0 8.5.151.0 8.5.140.0 8.5.135.0 8.5.131.0 8.5.120.0 8.5.110.0 8.5.105.0 8.5.103.0 8.4.100.0 8.3.150.0 8.3.143.0 8.3.141.0 8.3.140.0 8.3.133.0 8.3.132.0 8.3.130.0 8.3.12x.0 8.3.112.0 8.3.102.0 8.2.170.0 8.2.166.0 8.2.164.0 8.2.161.0 8.2.160.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.152.0 8.0.150.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0 7.6.130.0

Remarks

2.4 2.3 2.2 2.1 2.0 1.4 1.3


19


Table 7

Cisco Prime Infrastructure and Cisco Wireless Release Compatibility Matrix1 (continued)


ISE

3.5

2.4

20

8.8.125.0 8.8.120.0 8.8.111.0 8.8.100.0

Remarks

2.3 2.2

2.1 8.7.106.0 8.7.102.0 2.0 8.6.101.0 1.4 8.5.151.0 8.5.140.0 1.3 8.5.135.0 8.5.131.0 8.5.120.0 8.5.110.0 8.5.105.0 8.5.103.0 8.4.100.0 8.3.150.0 8.3.143.0 8.3.141.0 8.3.140.0 8.3.133.0 8.3.132.0 8.3.130.0 8.3.12x.0 8.3.112.0 8.3.102.0 8.2.170.0 8.2.166.0 8.2.164.0 8.2.161.0 8.2.160.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.152.0 8.0.150.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0 Cisco Wireless Solutions Software Compatibility Matrix 7.6.130.0 7.6.120.0 7.6.110.0


Table 7



ISE

3.4

2.4

8.7.106.0 8.7.102.0 8.6.101.0 8.5.151.0 8.5.140.0 8.5.135.0 8.5.131.0 8.5.120.0 8.5.110.0 8.5.105.0 8.5.103.0 8.4.100.0 8.3.150.0 8.3.143.0 8.3.141.0 8.3.140.0 8.3.133.0 8.3.132.0 8.3.130.0 8.3.12x.0 8.3.112.0 8.3.102.0 8.2.170.0 8.2.166.0 8.2.164.0 8.2.161.0 8.2.160.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.152.0 8.0.150.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0 7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0

Remarks

2.3 2.2 2.1 2.0 1.4 1.3


21


Table 7



ISE

3.3

2.3

8.7.106.0 8.7.102.0 8.6.101.0 8.5.151.0 8.5.140.0 8.5.135.0 8.5.131.0 8.5.120.0 8.5.110.0 8.5.105.0 8.5.103.0 8.4.100.0 8.3.150.0 8.3.143.0 8.3.141.0 8.3.140.0 8.3.133.0 8.3.132.0 8.3.130.0 8.3.12x.0 8.3.112.0 8.3.102.0 8.2.170.0 8.2.166.0 8.2.164.0 8.2.161.0 8.2.160.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.152.0 8.0.150.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0

Remarks

2.2 2.1 2.0 1.4 1.3


22


Table 7



ISE

Remarks

7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0


23


Table 7



ISE

Remarks

3.2.1

2.2

**The latest Cisco Identity Services Engine (ISE) Patch Version works.

8.5.151.0 8.5.140.0 8.5.135.0 8.5.131.0 8.5.120.0 8.5.110.0 8.5.105.0 8.5.103.0 8.4.100.0 8.3.150.0 8.3.143.0 8.3.141.0 8.3.140.0 8.3.133.0 8.3.132.0 8.3.130.0 8.3.12x.0 8.3.112.0 8.3.102.0 8.2.170.0 8.2.166.0 8.2.164.0 8.2.161.0 8.2.160.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.152.0 8.0.150.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0

2.12 2.02 1.4**2 1.3**


24


Table 7



ISE

Remarks

7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0


25


Table 7



ISE

Remarks

3.2

2.2


8.5.151.0 8.5.140.0 8.5.135.0 8.5.131.0 8.5.120.0 8.5.110.0 8.5.105.0 8.5.103.0 8.4.100.0 8.3.150.0 8.3.143.0 8.3.141.0 8.3.140.0 8.3.133.0 8.3.132.0 8.3.130.0 8.3.12x.0 8.3.112.0 8.3.102.0 8.2.170.0 8.2.166.0 8.2.164.0 8.2.161.0 8.2.160.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.152.0 8.0.150.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0

2.12 2.02 1.4**2 1.3**


26


Table 7



ISE

Remarks

7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0


27


Table 7



ISE

Remarks

3.1.7

2.2


8.4.100.0 8.3.150.0 8.3.143.0 8.3.141.0 8.3.140.0 8.3.133.0 8.3.132.0 8.3.130.0 8.3.12x.0 8.3.111.0 8.3.112.0 8.3.102.0 8.2.170.0 8.2.166.0 8.2.164.0 8.2.161.0 8.2.160.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.152.0 8.0.150.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0

2.12 2.02 1.4**2 1.3**


28


Table 7



ISE

Remarks

7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0


29


Table 7



ISE

Remarks

3.1.6

2.2


8.4.100.0 8.3.150.0 8.3.143.0 8.3.141.0 8.3.140.0 8.3.133.0 8.3.132.0 8.3.130.0 8.3.12x.0

2.12 2.02 1.4**2 1.3**

8.3.112.0 8.3.111.0 8.3.102.0 8.2.170.0 8.2.166.0 8.2.164.0 8.2.161.0 8.2.160.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.152.0 8.0.150.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0


30


Table 7



ISE

Remarks

7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0


31


Table 7


Cisco Prime Infrastructure Cisco WLC 3.1.5

8.4.100.0 8.3.150.0 8.3.143.0 8.3.141.0 8.3.140.0 8.3.133.0 8.3.132.0 8.3.130.0 8.3.12x.0 8.3.112.0 8.3.102.0 8.2.170.0 8.2.166.0 8.2.164.0 8.2.161.0 8.2.160.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.152.0 8.0.150.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0

ISE 2.1

2

Remarks **The latest Cisco Identity Services Engine (ISE) Patch Version works.

2.02 1.4**2 1.3**


32


Table 7



ISE

Remarks

7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0


33


Table 7



8.3.150.0 8.3.143.0 8.3.141.0 8.3.140.0 8.3.133.0 8.3.132.0 8.3.130.0 8.3.12x.0 8.3.112.0 8.3.102.0

ISE 2.1

2

2.02 1.4**2

Remarks **For Cisco Prime Infrastructure 3.1.4 to work, you must apply Cisco Identity Services Engine (ISE) Patch 3 Version (1.4.0.253-Patch3-141133) to an existing ISE 1.4.0 installation.

1.3

8.2.170.0 8.2.166.0 8.2.164.0 8.2.161.0 8.2.160.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.152.0 8.0.150.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0


34


Table 7



ISE

Remarks

7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0


35


Table 7



8.3.150.0 8.3.143.0 8.3.141.0 8.3.140.0 8.3.133.0 8.3.132.0 8.3.130.0 8.3.12x.0 8.3.112.0 8.3.102.0

ISE 2.0

2

1.4**2 1.3

Remarks *Cisco Aironet 1810 Series OEAPs are not ed. **For Cisco Prime Infrastructure 3.1.3 to work, you must apply Cisco Identity Services Engine (ISE) Patch 3 Version (1.4.0.253-Patch3-141133) to an existing ISE 1.4.0 installation.

8.2.170.0 8.2.166.0 8.2.164.0 8.2.161.0 8.2.160.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.152.0 8.0.150.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0


36


Table 7



ISE

Remarks

7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0


37


Table 7



8.3.13x.0 8.3.12x.0 8.3.112.0*** 8.3.102.0*** 8.2.170.0

ISE 2.0

2

1.4**2 1.3

Remarks **For Cisco Prime Infrastructure 3.1.1 to work, you must apply Cisco Identity Services Engine (ISE) Patch 3 Version (1.4.0.253-Patch3-141133) to an existing ISE 1.4.0 installation. ***No new features of Cisco WLC 8.3.x are ed with Cisco Prime Infrastructure Release 3.1.1.

8.2.16x.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0


38


Table 7



ISE

Remarks

8.2.170.0

2.02

8.2.16x.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0

1.4**2

**For Cisco Prime Infrastructure 3.1 to work, you must apply Cisco Identity Services Engine (ISE) Patch 3 Version (1.4.0.253-Patch3-141133) to an existing ISE 1.4.0 installation.

7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 3.1

1.3


39


Table 7



ISE

Remarks

1.4**2

**For Cisco Prime Infrastructure 3.0 to work, you must apply Cisco Identity Services Engine (ISE) Patch 3 Version (1.4.0.253-Patch3-141133) to an existing ISE 1.4.0 installation.

7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 3.0 Technology Package

8.2.16x.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.2.100.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0

1.3


40


Table 7



ISE

Remarks

7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0


41


Table 7



8.1.131.0* 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0 7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0

ISE 1.4** 1.3

Remarks 2

*No new features of Cisco WLC 8.1.131.0 are ed with Cisco Prime Infrastructure Release 3.0, but the Mobility Express features are ed. **For Cisco Prime Infrastructure 3.0 to work, you must apply Cisco Identity Services Engine (ISE) Patch 3 Version (1.4.0.253-Patch3-141133) to an existing ISE 1.4.0 installation.


42


Table 7



8.1.131.0* 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0 7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0

ISE 1.4** 1.3

Remarks 2



43


Table 7



8.1.131.0* 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0 7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0

ISE 1.4** 1.3

Remarks 2



44


Table 7


Cisco Prime Infrastructure Cisco WLC 3.0

8.1.131.0 8.1.122.0* 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0 7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0

ISE 1.4** 1.3

Remarks 2

*No new features of Cisco WLC 8.1.122.0 or later including Mobility Express is ed with PI Release 3.0. **For PI 3.0 to work, you must apply Cisco Identity Services Engine (ISE) Patch 3 Version (1.4.0.253-Patch3-141133) to an existing ISE 1.4.0 installation.


45


Table 7



8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0 7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

ISE 1.4** 1.3

Remarks 2

**For PI 2.2.3 to work, you must apply Cisco Identity Services Engine (ISE) Patch 3 Version (1.4.0.253-Patch3-141133) to an existing ISE 1.4.0 installation. Cisco Prime Infrastructure 2.2.2 allows you to manage Cisco WLC 8.1.x; however, features introduced in Cisco WLC 8.1.x are not ed.


46


Table 7



ISE

Remarks

2.2.2

1.3

Cisco Prime Infrastructure 2.2.2 allows you to manage Cisco WLC 8.1.x; however, features introduced in Cisco WLC 8.1.x are not ed.

8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0 7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0


47


Table 7



ISE

Remarks

2.2.1

1.3

Cisco Prime Infrastructure 2.2.1 allows you to manage Cisco WLC 8.1.x; however, features introduced in Cisco WLC 8.1.x are not ed.

8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.115.0 8.0.110.0 8.0.100.0 7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0


48


Table 7



8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0 7.6.130.0 7.6.120.0 7.6.110.0 7.6.100.0 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

ISE

Remarks

1.3 1.2*** 1.1 1.0

* Prime Infrastructure 2.2 allows you to manage Cisco WLC Release 8.0.110.0. For the ed WLC features, see the “ed features” section of the Prime Infrastructure 2.2 Release Notes at the following URL. https://www.cisco.com/c/en/us/td/docs/net_mgmt/prime/infrastructure/2-2/release/n otes/i_rn.html ** Prime Infrastructure 2.2 allows you to manage Cisco MSE Release 8.0.110.0. For more information on Cisco MSE model and platform details, see Table 10. *** Prime Infrastructure s ISE 1.2 in non-FIPS mode. Note

For version compatibility for Cisco MSE Release 8.0 wIPS with PI 2.2, see Table 10.


49


Table 7


Cisco Prime Infrastructure Cisco WLC 2.1.2***

8.0.15x.0 8.0.140.0* 8.0.13x.0* 8.0.121.0* 8.0.120.0* 8.0.115.0* 8.0.110.0* 8.0.100.0* 7.6.130.0* 7.6.120.0* 7.6.110.0* 7.6.100.0* 7.5.102.0* 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

ISE

Remarks

1.0 1.1 1.2

* Prime Infrastructure 2.1.2 allows you to manage Cisco WLC Releases 7.5.102.0, 7.6.x, and 8.0.x with the features of Cisco WLC 7.4.130.0 and earlier releases. Cisco Prime Infrastructure 2.1.2 does not any features that are introduced in Cisco WLC Releases 7.5.102.0 and 7.6.x except the new access point platforms and the new mobility feature. ** Prime Infrastructure 2.1.2 allows you to manage Cisco MSE Releases 7.5.102.101, 7.6.100.0, 7.6.120.0, 8.0.100.0, and 8.0.110.0 with feature compatibility of Cisco MSE Release 7.4.121.0. Prime Infrastructure 2.1.2 does not any new features introduced in Cisco MSE Releases 7.5.102.101 and 7.6.120.0. For information on Cisco MSE model and platform details, see Table 11. *** Cisco AP701E is not ed by Prime Infrastructure 2.1.2.


50


Table 7


Cisco Prime Infrastructure Cisco WLC 2.1.1***

8.0.15x.0 8.0.140.0* 8.0.13x.0* 8.0.121.0* 8.0.120.0* 8.0.115.0* 8.0.110.0* 8.0.100.0* 7.6.130.0* 7.6.120.0* 7.6.110.0* 7.6.100.0* 7.5.102.0* 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

ISE

Remarks

1.0 1.1 1.2

* Prime Infrastructure 2.1.1 allows you to manage Cisco WLC Releases 7.5.102.0, 7.6.100.0, 7.6.110.0, 7.6.120.0, and 8.0.100.0 with the features of Cisco WLC 7.4.130.0 and earlier releases. Cisco Prime Infrastructure 2.1.1 does not any features that are introduced in Cisco WLC Releases 7.5.102.0 and 7.6.x except the new access point platforms and the new mobility feature. ** Prime Infrastructure 2.1.1 allows you to manage Cisco MSE Releases 7.5.102.101, 7.6.100.0, 7.6.120.0, 8.0.110.0 and 8.0.110.0 with feature compatibility of Cisco MSE Release 7.4.121.0. Prime Infrastructure 2.1.1 does not any new features introduced in Cisco MSE Releases 7.5.102.101 and 7.6.120.0. For information on Cisco MSE model and platform details, see Table 11. *** Cisco AP701E is not ed by Prime Infrastructure 2.1.1. Also, Cisco Aironet 1700 Series Access Points are not ed by Prime Infrastructure until Prime Infrastructure Release 2.2.


51


Table 7



7.6.120.0* 7.5.102.0* 7.4.150.0 7.4.140.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

ISE

Remarks

1.0 1.1 1.2

*Prime Infrastructure 2.1 allows you to manage Cisco WLC Releases 7.5.102.0 and 7.6.120.0 with the features of Cisco WLC 7.4.130.0 and earlier releases. Prime Infrastructure 2.1 does not any features that are introduced in Cisco WLC Releases 7.5.102.0 and 7.6.x except the new access point platforms and the new mobility feature. ** Prime Infrastructure 2.1 allows you to manage Cisco MSE Releases 7.5.102.101 and 7.6.120.0 with feature compatibility of Cisco MSE Release 7.4.121.0. Prime Infrastructure 2.1 does not any new features introduced in Cisco MSE Releases 7.5.102.101 and 7.6.120.0. For information on Cisco MSE model and platform details, see Table 11.


52


Table 7



7.5.102.0* 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

ISE

Remarks

1.0 1.1 1.2

* Cisco Prime Infrastructure 2.0 enables you to manage Cisco WLC 7.5.102.0 with the features of Cisco WLC 7.4.130.0 and earlier releases. Prime Infrastructure 2.0 does not any features that are introduced in Cisco WLC 7.5.102.0 or later releases including the new access point platforms. ** Cisco Prime Infrastructure 2.0 enables you to manage 7.5.102.101 or later releases of Cisco MSE with features of Cisco MSE Release 7.4.121.0 and earlier releases. Prime Infrastructure 2.0 does not any features that are introduced in Cisco MSE Release 7.5.102.101 or later releases. For information on Cisco MSE model and platform details, see Table 11.


53


Table 7


Cisco Prime Infrastructure Cisco WLC Update 2 for 1.4.0.45

7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

ISE

Remarks

1.0 1.1 1.2

The Update 2 for Cisco Prime Infrastructure 1.4.0.45 enables you to manage Cisco WLC 7.6.x with the features of Cisco WLC 7.5.102.0 and earlier releases. This release does not any new features of Cisco WLC 7.6.x. However, this release s two new AP platforms—Cisco 702w and Cisco 2700. Note

For version compatibility for Cisco MSE Release 8.0 wIPS with Update 2 for 1.4.0.45, see Table 10.


54


Table 7


Cisco Prime Infrastructure Cisco WLC Update 1 for 1.4.0.45

7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

ISE

Remarks

1.0 1.1 1.2

The Update 1 for Cisco Prime Infrastructure 1.4.0.45 enables you to manage Cisco WLC 7.6.x with the features of Cisco WLC 7.5.102.0 and earlier releases. This release does not any new features of Cisco WLC 7.6.x. However, the Aironet 3700 Series Access Points are ed. Note

For version compatibility for Cisco MSE Release 8.0 wIPS with Update 1 for 1.4.0.45, see Table 10.


55


Table 7


Cisco Prime Infrastructure Cisco WLC 1.4.0.45

7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

ISE

Remarks

1.0 1.1 1.2

—


56


Table 7


Cisco Prime Infrastructure Cisco WLC Update 4 for 1.3.0.20 Update 1 for 1.3.0.20 1.3.0.20

1.2.1.12

ISE

Remarks

7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

1.0 1.1 1.2

—

7.3.112.0 7.3.101.0 7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

1.0 1.1

—

1. For Cisco CMX and Cisco MSE compatibility details, see the Cisco Connected Mobile Experiences (CMX) Compatibility Matrix, page 68 and the Cisco Mobility Services Engine Compatibility Matrixes, page 72. 2. Cisco ISE Release 2.x or 1.4 only works with Cisco MSE Release 8.0 or earlier.


57


Cisco Prime Infrastructure and Cisco Converged Access Solution Compatibility Matrix Table 8 lists the Cisco IOS/IOS XE releases and the corresponding devices that are compatible with the Cisco Prime Infrastructure releases. Table 8

Cisco Prime Infrastructure and Cisco IOS/IOS XE Release Compatibility Matrix

Cisco Prime Infrastructure Cisco IOS/IOS XE Release 3.6

Gibraltar 16.10.1 Fuji 16.9.1 Fuji 16.8.1 Fuji 16.7.1 Everest 16.6.1 Everest 16.5.1 Everest 16.4.1 Denali 16.3.1

Device

Remarks

Cisco Catalyst 3850 Switch / Catalyst 38xx stack-able Ethernet Switch

Denali 16.x.x does not Cisco MSE Release 8.0.x.

Cisco Catalyst 3650 Switch / Catalyst 36xx stack-able Ethernet Switch Cisco 5700 Series Wireless Controller / Catalyst 57xx stack-able Ethernet Switch Cisco Catalyst 4500 Series Switch Supervisor Engine 8-E platform (Platform from 03.07.00.E and later).

Denali 16.3.2 Denali 16.3.3 Denali16.2.2 Denali 16.1.2 Denali 16.2.1 Denali 16.1.1 03.07.03E 03.07.002E 03.07.001E 03.07.000E 03.06.03E 03.06.02E 03.06.01E 03.06.00E


58


Table 8

Cisco Prime Infrastructure and Cisco IOS/IOS XE Release Compatibility Matrix (continued)


Gibraltar 16.10.1 Fuji 16.9.1 Fuji 16.8.1 Fuji 16.7.1 Everest 16.6.1 Everest 16.5.1 Everest 16.4.1 Denali 16.3.1

Device

Remarks




Denali 16.3.2 Denali 16.3.3 Denali 16.2.2 Denali 16.1.2 Denali 16.2.1 Denali 16.1.1 03.07.03E 03.07.002E 03.07.001E 03.07.000E 03.06.03E 03.06.02E 03.06.01E 03.06.00E


59


Table 8



Everest 16.6.1 Everest 16.5.1 Everest 16.4.1 Denali 16.3.1 Denali 16.3.2 Denali 16.3.3 Denali 16.2.2 Denali 16.1.2

Device

Remarks




Denali 16.2.1 Denali 16.1.1 03.07.03E 03.07.002E 03.07.001E 03.07.000E 03.06.03E 03.06.02E 03.06.01E 03.06.00E 3.3

Denali 16.3.1 Denali 16.3.2 Denali 16.3.3 Denali 16.2.2 Denali 16.1.2 Denali 16.2.1 Denali 16.1.1 03.07.03E 03.07.002E 03.07.001E 03.07.000E

Cisco Catalyst 3850 Switch / Catalyst 38xx stack-able Ethernet Switch Cisco Catalyst 3650 Switch / Catalyst 36xx stack-able Ethernet Switch Cisco 5700 Series Wireless Controller / Catalyst 57xx stack-able Ethernet Switch Cisco Catalyst 4500 Series Switch Supervisor Engine 8-E platform (Platform from 03.07.00.E and later).

03.06.03E 03.06.02E 03.06.01E 03.06.0


60



Table 8




Device

Remarks




03.06.03E 03.06.02E 03.06.01E 03.06.00E 3.1.7

Denali 16.3.5 Denali 16.3.3 Denali 16.3.2 Denali 16.3.1 Denali 16.2.2 Denali 16.1.2 Denali 16.2.1 Denali 16.1.1




03.07.03E 03.07.002E 03.07.001E 03.07.000E 03.06.03E 03.06.02E 03.06.01E 03.06.00E


61


Table 8


Cisco Prime Infrastructure Cisco IOS/IOS XE Release 3.1.6


Device

Remarks




03.06.03E 03.06.02E 03.06.01E 03.06.00E 3.1.5

Denali 16.3.1 Denali 16.3.2 Denali 16.2.2 Denali 16.1.2 Denali 16.2.1 Denali 16.1.1 03.07.03E 03.07.002E 03.07.001E 03.07.000E 03.06.03E 03.06.02E 03.06.01E 03.06.00E



62



Table 8


Cisco Prime Infrastructure Cisco IOS/IOS XE Release 3.1.4

Denali 16.3.1 Denali 16.1.2 Denali 16.2.2 Denali 16.2.1 Denali 16.1.1

3.1.3

Remarks



Cisco Catalyst 3650 Switch / Catalyst 36xx stack-able Ethernet Switch Cisco 5700 Series Wireless Controller / Catalyst 57xx stack-able Ethernet Switch

03.07.03E 03.07.002E 03.07.001E 03.07.000E 03.06.03E 03.06.02E 03.06.01E 03.06.00E

Cisco Catalyst 4500 Series Switch Supervisor Engine 8-E platform (Platform from 03.07.00.E and later).

Denali 16.2.2


Denali 16.1.2 Denali 16.2.1 Denali 16.1.1 03.07.03E 03.07.002E 03.07.001E 03.07.000E 03.06.03E 03.06.02E 03.06.01E 03.06.00E 3.1.1

Device

Denali 16.1.2 Denali 16.2.1 Denali 16.1.1 03.07.03E 03.07.002E 03.07.001E 03.07.000E 03.06.03E 03.06.02E 03.06.01E 03.06.00E







63


Table 8



Denali 16.1.2 Denali 16.2.1 Denali 16.1.1 03.07.03E 03.07.002E 03.07.001E 03.07.000E 03.06.03E 03.06.02E 03.06.01E 03.06.00E

3.0 Technology Pack

3.0.2

Device

Remarks




Denali 16.1.1 03.07.002E 03.07.001E 03.07.000E 03.06.03E 03.06.02E 03.06.01E 03.06.00E


03.07.002E 03.07.001E 03.07.000E 03.06.03E 03.06.02E 03.06.01E 03.06.00E




3.0.1

03.07.002E 03.07.001E 03.07.000E 03.06.03E 03.06.02E 03.06.01E 03.06.00E



64



Table 8



03.07.002E 03.07.001E 03.07.000E 03.06.03E 03.06.02E 03.06.01E 03.06.00E

Device

Remarks


2.2.3

03.07.00E 03.06.03E 03.06.01E 03.06.00E 03.03.03S 03.03.04S 03.03.05SE 03.07.00E* 03.07.01E

Cisco Catalyst 3850 Switch / Catalyst 38xx stack-able Ethernet Switch Cisco Catalyst 3650 Switch / Catalyst 36xx stack-able Ethernet Switch Cisco 5700 Series Wireless Controller / Catalyst 57xx stack-able Ethernet Switch Cisco Catalyst 3850 Switch / Catalyst 38xx stack-able Ethernet Switch Cisco Catalyst 3650 Switch / Catalyst 36xx stack-able Ethernet Switch

*With Release 03.07.00.E, is introduced for Cisco Catalyst 4500 Series Switch Supervisor Engine 8-E platform.

Cisco 5700 Series Wireless Controller / Catalyst 57xx stack-able Ethernet Switch Cisco Catalyst 4500 Series Switch Supervisor Engine 8-E 2.2.2

03.07.00E 03.06.03E 03.06.01E 03.06.00E 03.03.03S 03.03.04S 03.03.05SE 03.07.00E* 03.07.01E

Cisco Catalyst 3850 Switch / Catalyst 38xx stack-able Ethernet Switch Cisco Catalyst 3650 Switch / Catalyst 36xx stack-able Ethernet Switch Cisco 5700 Series Wireless Controller / Catalyst 57xx stack-able Ethernet Switch Cisco Catalyst 3850 Switch / Catalyst 38xx stack-able Ethernet Switch Cisco Catalyst 3650 Switch / Catalyst 36xx stack-able Ethernet Switch


Cisco 5700 Series Wireless Controller / Catalyst 57xx stack-able Ethernet Switch Cisco Catalyst 4500 Series Switch Supervisor Engine 8-E


65


Table 8



03.07.00E 03.06.03E 03.06.01E 03.06.00E 03.03.03S 03.03.04S 03.03.05SE 03.07.00E* 03.07.01E

Device

Remarks



Cisco Catalyst 3650 Switch / Catalyst 36xx stack-able Ethernet Switch Cisco 5700 Series Wireless Controller / Catalyst 57xx stack-able Ethernet Switch

Cisco Catalyst 3850 Switch / Catalyst 38xx stack-able Ethernet Switch Cisco Catalyst 3650 Switch / Catalyst 36xx stack-able Ethernet Switch Cisco 5700 Series Wireless Controller / Catalyst 57xx stack-able Ethernet Switch Cisco Catalyst 4500 Series Switch Supervisor Engine 8-E

2.1.2

2.1.1

2.1

03.06.03E 3.6.1E 3.6.0E 03.03.03S 03.03.04S 03.03.05SE

3.6.0E 03.03.02SE 03.03.01SE 03.03.00SE

Cisco Catalyst 3850 Switch / Catalyst 38xx stack-able Ethernet Switch Cisco Catalyst 3650 Switch / Catalyst 36xx stack-able Ethernet Switch Cisco 5700 Series Wireless Controller / Catalyst 57xx stack-able Ethernet Switch

Cisco Catalyst 3850 Switch / Catalyst 38xx stack-able Ethernet Switch Cisco Catalyst 3650 Switch / Catalyst 36xx stack-able Ethernet Switch

We recommend that you use Cisco Prime Infrastructure 2.1 if Cisco MSE is not deployed. We recommend that you use Cisco Prime Infrastructure 2.1.1 if Cisco MSE is also deployed.

Cisco 5700 Series Wireless Controller / Catalyst 57xx stack-able Ethernet Switch

We recommend that you use Cisco Prime Infrastructure 2.1 if Cisco MSE is not deployed.

3.6.0E 3.3.2SE 3.3.1SE 3.3.0SE 3.2.3SE 3.2.2SE


3.6.0E 3.3.2SE 3.3.1SE 3.3.0SE


For Release 3.6.0E, we recommend that you use Cisco Prime Infrastructure 2.1 if Cisco MSE is not deployed. If Cisco MSE is deployed on your network, we recommend that you Cisco Prime Infrastructure 2.1.1.

Cisco 5700 Series Wireless Controller / Catalyst 57xx stack-able Ethernet Switch


66

We recommend that you use Cisco Prime Infrastructure 2.1.2 if Cisco MSE is also deployed.

—


Table 8


Cisco Prime Infrastructure Cisco IOS/IOS XE Release

Device

Remarks

2.0

3.3.1SE 3.3.0SE 3.2.3SE

Cisco Catalyst 3850 Switch

Cisco Catalyst 3650 Switch that is ed with 3.3.xSE release is not ed with Cisco Prime Infrastructure 2.0.

IOS12.2(50)SE IOS12.2(50)SG IOS12.2(33)SXI


Can be used only for monitoring purposes.

3.2.1SE 3.2.2SE






3.2.1SE






—

—

—




1.4.0.45

1.3.0.20

1.2.1.12

Cisco 5700 Series Wireless Controller


67

Cisco Connected Mobile Experiences (CMX) Compatibility Matrix

Cisco Connected Mobile Experiences (CMX) Compatibility Matrix This section contains the following topics: •

Important Notes, page 68

•

Cisco CMX Compatibility Matrix, page 70

Important Notes This section describes Cisco CMX compatibility limitations with the platforms and releases listed in the Cisco CMX Compatibility Matrix, Table 9 on page 70. General •

We strongly recommend that you Cisco CMX Release 10.4.1.x or later if you are running Cisco CMX Release 10.3 or earlier.

Cisco High Availability •

The High Availability feature on Cisco CMX: – Is ed only in Cisco CMX Release 10.3.x or later. – Is ed on all platforms ed by Cisco CMX Release 10.3.x or later.

Note

The HA feature in Cisco CMX Release 10.3.x or later is not ed on the Cisco MSE 3355.

– Requires that both primary and standby servers have the same virtual machine size and the same

virtual Cisco MSE appliances. Cisco CMX Hyperlocation •

Cisco CMX Release 10.2.x (non-Cisco Hyperlocation apps) is compatible with Cisco Prime Infrastructure Release 2.2.x and 3.0.x.

•

Cisco CMX Hyperlocation with the High Availability feature on Cisco CMX requires Cisco WLC Release 8.4.1.210 or later.

•

Cisco CMX Hyperlocation requires Cisco WLC Release 8.1.131.0 or later.

•

Cisco CMX Hyperlocation is not be ed on the Cisco MSE 3355.

•

Cisco CMX Hyperlocation is not ed on the Cisco Mobility Express Controllers.

Cisco Prime Infrastructure •

You must manually maps from Cisco Prime Infrastructure to Cisco CMX Release 10.3.x or later. Auto-import is not ed.

•

You must manually maps from Cisco Prime Infrastructure to Cisco CMX Release 10.2.2. Client display within Cisco Prime Infrastructure is not ed on Cisco CMX Release 10.2.2.


68


•

Cisco CMX Release 10.2.3 (Cisco Hyperlocation and Cisco 2800 and 3800 series access points) is compatible with Cisco Prime Infrastructure Release 3.1.x with device pack and update patch. ? – PI 3.1.3 update patch:

https://software.cisco.com//release.html?mdfid=286304360&flowid=&softwareid=2 84272933&release=3.1.3&relind=AVAILABLE&rellifecycle=&reltype=latest. – PI 3.1.3 device pack:

https://software.cisco.com//release.html?mdfid=286304360&softwareid=286208063 &release=3.1.3&relind=AVAILABLE&rellifecycle=&relt Cisco 3375 Appliance for Cisco Connected Mobile Experiences •

Cisco CMX Release 10.5.1 or later s the Cisco 3375 Appliance for Cisco Connected Mobile Experiences.

Cisco Access Points •

Cisco CMX s Cisco 3702i, 3702e, 3800, 2800, 4800,1830, and 1850 access points.

Cisco ME •

Cisco CMX Release 10.5.0 s Cisco ME Release 8.8 running on Cisco 1830 and 1850 access points.

Cisco MSE 3355 •

Cisco CMX Release 10.4.x or later does not the Cisco MSE 3355 platform.

•

Cisco CMX Release 10.3.x release or earlier are ed on the Cisco MSE 3355 platform. However, the HA feature in Cisco CMX Release 10.3.x is not ed on the Cisco MSE 3355.

•

Cisco CMX Release 10.2.x or later is ed on the Cisco MSE 3355 but on a limited scale in of number of tracked clients and number of WLCs synchronized. Scale numbers for Location and Presence Analytics are documented in the https://www.cisco.com/c/en/us/solutions/collateral/enterprise-networks/connected-mobile-experie nces/datasheet-c78-734648.html.

Cisco Switches •

Cisco CMX Releases 10.3.1 or later is not compatible with the following Cisco switch platforms: – Cisco Catalyst 2960-24TT switch running Cisco Release 15.0(2)SE11 – Cisco Catalyst 2960-48-PST-L switch running Cisco Release 15.0(2)SE11 – Cisco Catalyst 2960X-24PS-L switch running Cisco Release 15.2(2)E7 – Cisco Catalyst 3650-24PS switch running Cisco Release 16.3.5b – Cisco Catalyst 3560-24PS switch running Cisco Release 12.2(55)SE11 – Cisco Catalyst 3850-24XS switch running Cisco Release 16.3.5.b – Cisco Nexus 5596UP switch running Cisco Release 7.1(4)N1(1)

Cisco USB BLE Beacon •

Cisco CMX Release 10.6.0 or later s the Cisco USB BLE Beacon (AIR-BLE-USB).

Cisco Wireless LAN Controllers •

Cisco CMX Release 10.5.1 and later s Cisco WLC Release 8.8.100.

•

The Cisco CMX Release 10.5 CMX Grouping feature requires Cisco WLC Release 8.7 or later.


69


•

Cisco WLC Release 7.x s the complete set of Cisco CMX Connect services. However: – Cisco WLC Release 8.2 or later is required to use these features available on Cisco CMX

Release 10.2.2: menu link, text link on page, and DNS-ACL configuration. – Cisco WLC Release 8.3 or later is required to use the PMS policy uplink bandwidth

enforcement feature available on Cisco CMX Release 10.2.2.

Cisco CMX Compatibility Matrix Table 9

Cisco CMX 10.6.1

Cisco CMX Compatibility Matrix 1

Hardware Platforms Cisco CMX Platforms Cisco 3375 Appliance Cisco USB BLE Beacon

Network Management2 Cisco Prime Infrastructure4 3.5.0.0.550 with Critical Update 02 3.4.0.0.348 3.3.0.0.342

Cisco MSE Platforms

MSE Virtual Appliance MSE 3365

WLC Platforms3 Cisco WLC 8.9.100.0 8.8.125.0 8.8.120.0 8.8.111.0 8.8.100.0 8.7.106.0 8.5 8.3 8.2 8.0 Catalyst 9800 WLC

16.10.1e 10.6.0

Cisco CMX Platforms

Cisco Prime Infrastructure5

Cisco 3375 Appliance Cisco USB BLE Beacon

3.5.0.0.550 with Critical Update 02 8.9.100.0 3.4.0.0.348 8.8.125.0 3.3.0.0.342 8.8.120.0 8.8.111.0 8.8.100.0 8.7.106.0 8.5 8.3 8.2 8.0

Cisco MSE Platforms


Cisco WLC

Catalyst 9800 WLC

16.10.1e


70


Table 9

Cisco CMX 10.5.1

Cisco CMX Compatibility Matrix (continued)1

Hardware Platforms Cisco CMX Platforms Cisco 3375 Appliance Cisco MSE Platforms

Network Management2 Cisco Prime Infrastructure4 3.4.0.0.348 3.3.0.0.342 3.2.0.0.258


WLC Platforms3 Cisco WLC 8.8.100 8.7.106.0 8.5 8.3 8.2 8.0 Catalyst 9800 WLC

10.5.0

10.4.x

10.3.x

4

Cisco MSE Platforms



3.4.0.0.348 3.3.0.0.342 3.2.0.0.258

Cisco MSE Platforms



3.3.0.0.342 3.2.0.0.258 3.1.0.0.132

Cisco MSE Platforms


MSE Virtual Appliance MSE 3365 MSE 3355

3.0 to 3.2 2.2

16.10.1 Cisco WLC 8.7.106.0 8.5 8.3 8.2 8.0 Cisco WLC 8.6 8.5 8.3 8.2 8.0 Cisco WLC 8.5 8.3 8.2 8.0

1. For Cisco CMX compatibility limitations, see the “Important Notes” section on page 68. 2. For complete Cisco DNA Center compatibility information, see the Cisco Digital Network Architecture Center ed Devices matrix and the Cisco Software-Defined Access Hardware and Software Compatibility Matrix matrix. 3. For complete Cisco WLC and Cisco AP compatibility information, see the “ed Access Points in Cisco Wireless Software Releases” section on page 2. 4. For complete Cisco Prime Infrastructure compatibility information, see the “Cisco Prime Infrastructure Compatibility Matrix” section on page 17. 5. For complete Cisco Prime Infrastructure compatibility information, see the “Cisco Prime Infrastructure Compatibility Matrix” section on page 17.


71

Cisco Mobility Services Engine Compatibility Matrixes

Cisco Mobility Services Engine Compatibility Matrixes This section contains the following topics: •

Important Notes, page 72

•

Cisco MSE Compatibility Matrix for Software Versions 7.5.x through 8.x, page 73

•

Cisco MSE Compatibility Matrix for Legacy Software Versions, page 86

Important Notes General: •

ISE 2.x or ISE 1.4 only works with Cisco MSE Release 8.0 or earlier.

•

Cisco MSE release 7.5 or later is not bundled with AeroScout CLE. However, AeroScout CLE is compatible with Cisco MSE Release 7.5 or later, which uses the API interface.

•

This compatibility matrix lists only the compatibility information of Cisco MSE with other Cisco wireless products. This matrix does not reflect compatibility information between Cisco WLC and Cisco Prime Infrastructure or Cisco NCS. For compatibility information about Cisco Prime Infrastructure with Cisco WLC and other wireless products, see the Cisco Prime Infrastructure Release Notes.

•

For information about the Cisco Connected Mobile Experiences (CMX) 10.x solution compatibility matrix, see the “Cisco Connected Mobile Experiences (CMX) Compatibility Matrix” section on page 68.

Cisco Prime Infrastructure •

Cisco MSE Release 8.0.140.x or later is compatible with Cisco Prime Infrastructure Releases 3.1.7, 3.1.6, 3.1.5, 3.1.3, 3.1.1, 3.0.3.1, and 2.2.3.5. If you encounter reachability issues with the Cisco MSE, Prime Infrastructure Release 3.1.3. (CSCuz19013)

•

For Cisco MSE Release 8.0.x HA and WLC Release 8.0 or later, Prime Infrastructure Release 2.2.x is compatible.

•

Cisco MSE 3365 s Cisco Prime Infrastructure 2.1.1 or later. Cisco MSE 3365 does not Cisco Prime Infrastructure 2.1.0.

Cisco Access Points •

Cisco MSE Release 8.0.140.9 and later includes wIPS and CAS for the Cisco Aironet 1800, 2800, and 3800 series.

Catalyst Switches •

Cisco MSE platforms running Cisco MSE Release 8.x are not compatible with the following Cisco switch platforms: – Cisco Catalyst 2960-24TT switch running Cisco Release 15.0(2)SE11 – Cisco Catalyst 2960-48-PST-L switch running Cisco Release 15.0(2)SE11 – Cisco Catalyst 2960X-24PS-L switch running Cisco Release 15.2(2)E7 – Cisco Catalyst 3650-24PS switch running Cisco Release 16.3.5b – Cisco Catalyst 3560-24PS switch running Cisco Release 12.2(55)SE11 – Cisco Catalyst 3850-24XS switch running Cisco Release 16.3.5.b – Cisco Nexus 5596UP switch running Cisco Release 7.1(4)N1(1)


72


Cisco MSE Compatibility Matrix for Software Versions 7.5.x through 8.x Table 10

Cisco MSE Compatibility Matrix for Software Versions 7.5.x through 8.x

MSE 3355

MSE 3365

MSE Virtual Prime Appliance Infrastructure

8.0.150.x

8.0.150.x

8.0.150.x

3.4.x 3.3.1 3.3 3.2.2 3.2.1 3.2 3.1.7 3.1.6 3.1.5 3.1.3 3.1 3.0.3 2.2.3

Converged Access

WLC 8.5.12x.0 8.5.11x.0 8.5.10x.0 8.4.10x.0 8.3.14x.0 8.3.13x.0 8.3.12x.0 8.3.112.0 8.3.111.0 8.3.102.0 8.2.16x.0 8.2.160.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.110.0 8.0.100.0

3.7.x 3.6.x 3.3.5 3.3.4 3.3.3 3.3.2 3.3.0 3.2.3 3.2.2 3.2.0 3.1.6

Remarks * For FIPS compliance, Cisco MSE Release 8.0 works with Cisco Prime Infrastructure 2.2, Cisco WLC 8.0.100.0, and Converged Access 3.6.0. ** The Cisco MSE Release 8.0 wIPS profile cannot be applied to Cisco WLC release 7.5 or prior using Cisco Prime Infrastructure 2.2 *** If you are you are running Analytics and Context Aware Service (Location Service) on different machines and using Cisco Prime Infrastructure 1.4, then additional setup is required. You can the Setup script from this location.


73


Table 10

MSE 3355

Cisco MSE Compatibility Matrix for Software Versions 7.5.x through 8.x (continued)

MSE 3365


WLC 7.6.130.0* 7.6.120.0* 7.6.110.0* 7.6.100.0* 7.5.102.0** 7.4.121.0** 7.4.110.0** 7.4.100.60** 7.4.100.0** 7.3.112.0** 7.3.101.0** 7.2.111.3** 7.2.110.0** 7.2.103.0** 7.0.240.0** 7.0.235.3** 7.0.235.0** 7.0.230.0** 7.1.91.0** 7.0.220.0** 7.0.116.0** 7.0.98.218** 7.0.98.0**


74

Converged Access

Remarks


Table 10


MSE 3355

MSE 3365


8.0.140.x

8.0.140.x

8.0.140.x

3.4.x 3.3.1 3.3 3.2.2 3.2.1 3.2 3.1.7 3.1.6 3.1.5 3.1.3 3.1 3.0.3 2.2.3

Converged Access

WLC 8.5.12x.0 8.5.11x.0 8.5.10x.0 8.4.10x.0 8.3.14x.0 8.3.13x.0 8.3.12x.0 8.3.112.0 8.3.111.0 8.3.102.0 8.2.16x.0 8.2.160.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.110.0 8.0.100.0 7.6.130.0* 7.6.120.0* 7.6.110.0* 7.6.100.0* 7.5.102.0** 7.4.121.0** 7.4.110.0** 7.4.100.60** 7.4.100.0** 7.3.112.0** 7.3.101.0** 7.2.111.3** 7.2.110.0** 7.2.103.0** 7.0.240.0** 7.0.235.3** 7.0.235.0** 7.0.230.0** 7.1.91.0** 7.0.220.0** 7.0.116.0** 7.0.98.218** 7.0.98.0**

3.7.x 3.6.x 3.3.5 3.3.4 3.3.3 3.3.2 3.3.0 3.2.3 3.2.2 3.2.0 3.1.6

Remarks * For FIPS compliance, Cisco MSE Release 8.0 works with Cisco Prime Infrastructure 2.2, Cisco WLC 8.0.100.0, and Converged Access 3.6.0. ** The Cisco MSE Release 8.0 wIPS profile cannot be applied to Cisco WLC release 7.5 or prior using Cisco Prime Infrastructure 2.2 *** If you are you are running Analytics and Context Aware Service (Location Service) on different machines and using Cisco Prime Infrastructure 1.4, then additional setup is required. You can the Setup script from this location.


75


Table 10


MSE 3355

MSE 3365


8.0.130.0

8.0.130.0

8.0.130.0

3.1 3.0.1 3.0 2.2 and later 1.4***


76

WLC 8.3.13x.0 8.3.111.0 8.3.102.0 8.2.16x.0 8.2.151.0 8.2.141.0 8.2.130.0 8.2.121.0 8.2.111.0 8.2.110.0 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.110.0 8.0.100.0 7.6.130.0* 7.6.120.0* 7.6.110.0* 7.6.100.0* 7.5.102.0** 7.4.121.0** 7.4.110.0** 7.4.100.60** 7.4.100.0** 7.3.112.0** 7.3.101.0** 7.2.111.3** 7.2.110.0** 7.2.103.0** 7.0.240.0** 7.0.235.3** 7.0.235.0** 7.0.230.0** 7.1.91.0** 7.0.220.0** 7.0.116.0** 7.0.98.218** 7.0.98.0**

Converged Access 3.7.x 3.6.x 3.3.5 3.3.4 3.3.3 3.3.2 3.2.3 3.2.2

Remarks * For FIPS compliance, Cisco MSE Release 8.0 works with Cisco Prime Infrastructure 2.2, Cisco WLC 8.0.100.0, and Converged Access 3.6.0. ** The Cisco MSE Release 8.0 wIPS44 profile cannot be applied to Cisco WLC release 7.5 or prior using Cisco Prime Infrastructure 2.2 *** If you are you are running Analytics and Context Aware Service (Location Service) on different machines and using Cisco Prime Infrastructure 1.4, then additional setup is required. You can the Setup script from this location.


Table 10


MSE 3355

MSE 3365


8.0.120.7

8.0.120.7

8.0.120.7

3.0.1 3.0 2.2.2*** 2.2.1 2.2 2.1.2*** 2.1.1*** 1.4*****

Converged Access

WLC 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.110.0 8.0.100.0 7.6.130.0 7.6.120.0 7.6.110.0* 7.6.100.0* 7.5.102.0**** 7.4.150.0**** 7.4.140.0**** 7.4.130.0**** 7.4.121.0**** 7.4.110.0**** 7.4.100.60**** 7.4.100.0**** 7.3.112.0**** 7.3.101.0**** 7.2.111.3**** 7.2.110.0**** 7.2.103.0**** 7.0.240.0**** 7.0.235.3**** 7.0.235.0**** 7.0.230.0**** 7.1.91.0**** 7.0.220.0**** 7.0.116.0**** 7.0.98.218**** 7.0.98.0****

3.7.x 3.6.x 3.3.5 3.3.4 3.3.3 3.3.2 3.2.3 3.2.2

Remarks * For FIPS compliance, Cisco MSE Release 8.0 works with Cisco PI 2.2, Cisco WLC 8.0.100.0, and Converged Access 3.6.0. ****With Cisco MSE Release 8.0 wIPS feature: If you are using Cisco Prime Infrastructure 2.2 or later releases with Cisco WLC 7.5 or earlier releases, use Cisco MSE Release 8.0.120 or later. ***** If you are you are running Analytics and Context Aware Service (Location Service) on different machines and using Cisco PI 1.4 release, then additional setup is required. You can the Setup script from this location.


77


Table 10


MSE 3355

MSE 3365


8.0.120.0

8.0.120.0

8.0.120.0

3.0.1 3.0 2.2.2*** 2.2.1 2.2 2.1.2*** 2.1.1*** 1.4*****


78

WLC 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.110.0 8.0.100.0 7.6.130.0 7.6.120.0 7.6.110.0* 7.6.100.0* 7.5.102.0**** 7.4.150.0**** 7.4.140.0**** 7.4.130.0**** 7.4.121.0**** 7.4.110.0**** 7.4.100.60**** 7.4.100.0**** 7.3.112.0**** 7.3.101.0**** 7.2.111.3**** 7.2.110.0**** 7.2.103.0**** 7.0.240.0**** 7.0.235.3**** 7.0.235.0**** 7.0.230.0**** 7.1.91.0**** 7.0.220.0**** 7.0.116.0**** 7.0.98.218**** 7.0.98.0****


Remarks * For FIPS compliance, Cisco MSE Release 8.0 works with Cisco PI 2.2, Cisco WLC 8.0.100.0, and Converged Access 3.6.0. ****With Cisco MSE Release 8.0 wIPS feature: If you are using Cisco Prime Infrastructure 2.2 or later releases with Cisco WLC 7.5 or earlier releases, use Cisco MSE Release 8.0.120 or later. ***** If you are you are running Analytics and Context Aware Service (Location Service) on different machines and using Cisco PI 1.4 release, then additional setup is required. You can the Setup script from this location.


Table 10


MSE 3355

MSE 3365


8.0.110.0

—

8.0.110.0

2.2.1 2.2 2.1.2*** 2.1.1*** 2.1*** 2.0*** 1.4*****

Converged Access

WLC 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.15x.0 8.0.140.0 8.0.13x.0 8.0.121.0 8.0.120.0 8.0.115.0 8.0.110.0 8.0.100.0 7.6.130.0 7.6.120.0 7.6.110.0* 7.6.100.0* 7.5.102.0**** 7.4.150.0**** 7.4.140.0**** 7.4.130.0**** 7.4.121.0**** 7.4.110.0**** 7.4.100.60**** 7.4.100.0**** 7.3.112.0**** 7.3.101.0**** 7.2.111.3**** 7.2.110.0**** 7.2.103.0**** 7.0.240.0**** 7.0.235.3**** 7.0.235.0**** 7.0.230.0**** 7.1.91.0**** 7.0.220.0**** 7.0.116.0**** 7.0.98.218**** 7.0.98.0**** 7.0.250.0 7.0.251.0 7.0.252.0

3.7.x 3.6.x 3.3.x 3.2.x

Remarks * For FIPS compliance, Cisco MSE Release 8.0 works with PI 2.2, Wireless LAN Controller (WLC) 8.0.100.0, and Converged access 3.6.0. ***While using PI 2.1.1 and 2.1.2, the Cisco MSE Release 8.0 wIPS will have Cisco MSE Release 7.4 feature parity. ****With Cisco MSE Release 8.0 wIPS feature: If you are using Cisco Prime Infrastructure 2.2 or later releases with Cisco WLC 7.5 or earlier releases, use Cisco MSE Release 8.0.120 or later. ***** If you are you are running Analytics and Location services on different machines and using Cisco Prime Infrastructure 1.4 Version, then additional setup is required. You can the Setup script from this location.


79


Table 10


MSE 3355

MSE 3365


8.0.100.0*

—

8.0.100.0

2.2.1 2.2 2.1.2 2.1.1*** 2.1 2.0 1.4*****


80

WLC 8.1.131.0 8.1.122.0 8.1.111.0 8.1.102.0 8.0.100.0 7.6.130.0 7.6.120.0 7.6.110.0* 7.6.100.0* 7.5.102.0**** 7.4.150.0**** 7.4.140.0**** 7.4.130.0**** 7.4.121.0**** 7.4.110.0**** 7.4.100.60**** 7.4.100.0**** 7.3.112.0**** 7.3.101.0**** 7.2.111.3**** 7.2.110.0**** 7.2.103.0**** 7.0.240.0**** 7.0.235.3**** 7.0.235.0**** 7.0.230.0**** 7.1.91.0**** 7.0.220.0**** 7.0.116.0**** 7.0.98.218**** 7.0.98.0****


Remarks * For FIPS compliance, Cisco MSE Release 8.0 works with PI 2.2, Wireless LAN Controller (WLC) 8.0.100.0, and Converged access 3.6.0. *** While using PI 2.1.1, the Cisco MSE Release 8.0 wIPS will have Cisco MSE Release 7.4 feature parity. ****With Cisco MSE Release 8.0 wIPS feature: If you are using Cisco Prime Infrastructure 2.2 or later releases with Cisco WLC 7.5 or earlier releases, use Cisco MSE Release 8.0.120 or later. ***** If you are you are running Analytics and Location services on different machines and using Cisco Prime Infrastructure 1.4 Version, then additional setup is required. You can the Setup script from this location.


Table 10


MSE 3355

MSE 3365


7.6.120.0

—

7.6.120.0

2.2.1 2.2 2.1.2 2.1.1** 2.1 2.0 1.4.2

Converged Access

WLC 7.6.120.0 7.6.110.0* 7.6.100.0* 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.111.3 7.2.110.0 7.2.103.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

—

Remarks **Prime Infrastructure 2.1.1 allows you to manage Cisco MSE Releases 7.5.102.101 and 7.6.120.0 with feature compatibility of Cisco MSE Release 7.4.121.0. Prime Infrastructure 2.1.1 does not any new features introduced in Cisco MSE Releases 7.5.102.101 and 7.6.120.0. Note

For PI 2.1.1 to work with Cisco MSE Release 7.6, you need to install a patch for Cisco bug Id CSCup93101. Cisco TAC for a patch.


81


Table 10


MSE 3355

MSE 3365


7.6.132.0

—

7.6.132.0

2.2.1 2.2 2.1.2 2.1.1** 2.1 2.0 1.4.2


82

WLC 7.6.130.0 7.6.120.0 7.6.110.0* 7.6.100.0* 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.111.3 7.2.110.0 7.2.103.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

Converged Access —

Remarks **Prime Infrastructure 2.1.1 allows you to manage Cisco MSE Releases 7.5.102.101 and 7.6.120.0 with feature compatibility of Cisco MSE Release 7.4.121.0. Prime Infrastructure 2.1.1 does not any new features introduced in Cisco MSE Releases 7.5.102.101 and 7.6.120.0. Note

For PI 2.1.1 to work with Cisco MSE Release 7.6, you need to install a patch for Cisco bug Id CSCup93101. Cisco TAC for a patch.


Table 10


MSE 3355

MSE 3365


7.6.100.0

—

7.6.100.0

2.2.1 2.2 2.1.2 2.1.1 2.1 2.0 Update 1 for 1.4.0.45* Update 2 for 1.4.0.45**

Converged Access

WLC 7.6.110.0* 7.6.100.0* 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.111.3 7.2.110.0 7.2.103.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

—

Remarks *The Update 1 for Cisco Prime Infrastructure 1.4.0.45 enables you to manage Cisco WLC 7.6.x with the features of Cisco WLC 7.5.102.0 and earlier releases. This release does not any new features of Cisco WLC 7.6.x including the new access point platforms. **The Update 2 for Cisco Prime Infrastructure 1.4.0.45 enables you to manage Cisco WLC 7.6.x with the features of Cisco WLC 7.5.102.0 and earlier releases. This release does not any new features of Cisco WLC 7.6.x. However, this release s two new AP platforms—Cisco 702w and Cisco 2700.


83


Table 10


MSE 3355

MSE 3365


7.6.100.0

—

7.6.100.0

7.5.102.101

—

2.2.1 2.2 2.1.2 2.1.1 2.1 2.0*

7.5.102.101 2.2.1 2.2 2.1.2 2.1.1 2.1 2.0 Update 1 for 1.4.0.45 1.4.0.45


84

WLC

Converged Access

7.6.110.0** 7.6.100.0** 7.5.102.0** 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.111.3 7.2.110.0 7.2.103.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

3.2.2** 3.3.2**

7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.111.3 7.2.110.0 7.2.103.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

—

Remarks *Cisco Prime Infrastructure 2.0 enables you to manage Cisco WLC 7.5.102.0 with the features of Cisco WLC 7.4.110.0 and earlier releases. Prime Infrastructure 2.0 does not any features that are introduced in Cisco WLC 7.5.102.0 or later releases including the new access point platforms. **s 7.4 MSE feature parity—CAS, Cisco MSE Release 8.0 wIPS, and CMX Analytics service. Note

—

Cisco MSE Release 8.0 wIPS profile cannot be pushed to Cisco Wireless LAN Controller (WLC) Version 7.5 or prior using the Prime Infrastructure 1.4.x or 2.x with Cisco MSE Release 7.6.


Table 10


MSE 3355

MSE 3365

7.5.102.101

—

MSE Virtual Prime Appliance Infrastructure 7.5.102.101 2.2.1 2.2 2.1.2 2.1.1 2.1 2.0*

Converged Access

WLC 7.5.102.0 7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.111.3 7.2.110.0 7.2.103.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

3.2.2** 3.3.2**

Remarks *Cisco Prime Infrastructure 2.0 enables you to manage Cisco WLC 7.5.102.0 with the features of Cisco WLC 7.4.110.0 and earlier releases. Prime Infrastructure 2.0 does not any features that are introduced in Cisco WLC 7.5.102.0 or later releases including the new access point platforms. **s 7.4 MSE feature parity—CAS, Cisco MSE Release 8.0 wIPS, and CMX Analytics service.


85


Cisco MSE Compatibility Matrix for Legacy Software Versions Table 11

Cisco MSE Compatibility Matrix—Legacy Software Versions

MSE 3355

MSE 3350

MSE Virtual Appliance

AeroScout CLE

7.4.121.0

—

7.4.121.0

7.4.110.0

—

7.4.110.0

WCS

WLC

Prime Infrastructure / NCS

4.5.2.16 4.4.2.11

—

7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.111.3 7.2.110.0 7.2.103.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

2.0 Update 1 for 1.4.0.45 1.4.0.45 Update 4 for 1.3.0.20 Update 1 for 1.3.0.20 1.3.0.20

4.4.2.11

—

7.4.110.0 7.4.100.60 7.4.100.0 7.3.112.0 7.3.101.0 7.2.111.3 7.2.110.0 7.2.103.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

2.0 Update 1 for 1.4.0.45 1.4.0.45 Update 4 for 1.3.0.20 Update 1 for 1.3.0.20 1.3.0.20


86


Table 11

Cisco MSE Compatibility Matrix—Legacy Software Versions (continued)

MSE 3355

MSE 3350


AeroScout CLE

7.4.100.0

—

7.4.100.0

7.3.101.0

7.3.101.0

7.2.110.0

7.2.110.0

WCS

WLC


4.4.2.11 4.4.2.7

—

7.4.100.0 7.3.112.0 7.3.101.0 7.2.111.3 7.2.110.0 7.2.103.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

Update 1 for 1.4.0.45 1.4.0.45 Update 4 for 1.3.0.20 Update 1 for 1.3.0.20 1.3.0.20

7.3.101.0

4.4.2.4

—

7.4.150.0 7.4.140.0 7.4.130.0 7.4.121.0 7.4.110.0 7.4.100.60 7.4.100.0 7.2.111.3 7.2.110.0 7.2.103.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

Update 4 for 1.3.0.20 Update 1 for 1.3.0.20 1.3.0.20 1.2.1.12

7.2.110.0

4.4.2.4

—

7.2.111.3 7.2.110.0 7.2.103.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

Update 4 for 1.3.0.20 Update 1 for 1.3.0.20 1.3.0.20 1.2.1.12 1.1.1.24 1.1.0.58


87


Table 11


MSE 3355

MSE 3350


AeroScout CLE

WCS

WLC


7.2.103.0

7.2.103.0

7.2.103.0

4.4.1.4

—

7.2.103.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

Update 4 for 1.3.0.20 Update 1 for 1.3.0.20 1.3.0.20 1.2.1.12 1.1.124 1.1.0.58

7.0.240.0

7.0.240.0

—

4.3.1.10

7.0.240.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

Update 4 for 1.3.0.20 Update 1 for 1.3.0.20 1.3.0.20 1.2.1.12 1.1.1.24 1.1.0.58 1.0.2.29

7.0.230.0

7.0.230.0

—

4.3.1.19

7.0.230.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

Update 4 for 1.3.0.20 Update 1 for 1.3.0.20 1.3.0.20 1.2.1.12 1.1.1.24 1.1.0.58 1.0.2.29

7.0.220.0

7.0.220.0

—

4.3.1.19

7.0.220.0 7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

Update 4 for 1.3.0.20 Update 1 for 1.3.0.20 1.3.0.20 1.2.1.12 1.1.1.24 1.1.0.58 1.0.2.29 1.0.1.4

7.0.201.204

7.0.201.204 —

4.2.4.4

7.0.172.0 7.0.116.0 7.0.98.218 7.0.98.0

Update 4 for 1.3.0.20 Update 1 for 1.3.0.20 1.3.0.20 1.2.1.12 1.1.1.24 1.1.0.58 1.0.2.29 1.0.1.4 1.0.0.96


88


Table 11


MSE 3355

MSE 3350


AeroScout CLE

7.0.112.0

7.0.112.0

—

4.2.4.4

7.0.164.3 7.0.98.218 7.0.98.0 7.0.164.0


7.0.105.0

7.0.105.0

—

4.2.4.4

7.0.164.3 7.0.98.218


WCS

WLC



89

Cisco Mobility Express Solution Compatibility Matrix

Cisco Mobility Express Solution Compatibility Matrix This section contains compatibility information about the Cisco Mobility Express Solution.

Note

Table 12

The Cisco Mobility Express solution is not compatible with other Cisco Wireless LAN Controller deployments and Cisco Network Assistant.

Mobility Express Software Compatibility Matrix

Cisco Mobility Express Solution

Access Point Software Access Point Platforms

8.8.125.0 8.8.120.0 8.8.111.0 8.8.100.0

15.3(3)JI5 15.3(3)JI4 15.3(3)JI3 15.3(3)JI1

APs with integrated controller functionality:

Cisco CMX

Cisco ISE

Cisco Prime Infrastructure Remarks

10.2.2 and later 2.2

3.5

2.1

3.4

Cisco Aironet 1540 series, 1560 series, 1815i, 1815m, 1815w,1830 series, 1850 series, 2800 series, 3800 series, and 4800 series.*

3.3 3.2 3.1.6 3.1.5

APs without integrated controller functionality: Cisco Aironet 700i, 700w, 1700 series, 1810w, 2700 series, 3700 series 8.7.102.0

15.3(3)JH

APs with integrated controller functionality: Cisco Aironet 1540 series, 1560 series, 1815i, 1815m, 1815w,1830 series, 1850 series, 2800 series, and 3800 series.* APs without integrated controller functionality: Cisco Aironet 700i, 700w, 1700 series, 1810w, 2700 series, 3700 series


90


3.4

2.1

3.3 3.2 3.1.6 3.1.5


Table 12

Mobility Express Software Compatibility Matrix (continued)



Cisco CMX

8.6.101.0

15.3(3)JG1


3.4

2.1

3.3


Cisco ISE

Cisco Aironet 1540 series, 1560 series, 1815i, 1815m, 1815w,1830 series, 1850 series, 2800 series, and 3800 series.*

Cisco Prime Infrastructure Remarks

3.2 3.1.6 3.1.5

APs without integrated controller functionality: Cisco Aironet 700i, 700w, 1700 series, 1810w, 2700 series, 3700 series 8.5.103.0

15.3(3)JF



3.3

2.1

3.2

Cisco Aironet 1540 series, 1560 series, 1815i, 1815m, 1815w,1830 series, 1850 series, 2800 series, and 3800 series.*

3.1.6 3.1.5

*Cisco Aironet 1560 series, 1815i, and 1815w AP platforms are not ed on Cisco Prime Infrastructure.

APs without integrated controller functionality: Cisco Aironet 700i, 700w, 1600 series, 1700 series, 1810w series, 2600 series, 2700 series, 3500 series, 3600 series, 3700 series 8.4.100.0

15.3(3)JE

APs with integrated controller functionality: Cisco Aironet 1560 series, 1815i, 1815w,1830 series, 1850 series, 2800 series, and 3800 series.* APs without integrated controller functionality:

10.2.2 and later 2.2 2.1

3.2 3.1.6 3.1.5

*Cisco Aironet 1560 series, 1815i, and 1815w AP platforms are not ed on Cisco Prime Infrastructure.

Cisco Aironet 700i, 700w, 1600 series, 1700 series, 1810w series, 2600 series, 2700 series, 3500 series, 3600 series, 3700 series


91


Table 12

Mobility Express Software Compatibility Matrix (continued)



8.3.130.0

15.3(3)JD7, APs with integrated 15.3(3)JDA7 controller functionality:

8.3.122.0 8.3.121.0

15.3(3)JD6 15.3(3)JD5

8.3.112.0

15.3(3)JD4

•

Cisco CMX

Cisco ISE

Cisco Prime Infrastructure Remarks 3.2 3.1.6

– Cisco Aironet 1560, 1830, 1850, 2800, and 3800 series

–

3.1.5

APs without integrated controller functionality: •

8.3.102.0

15.3(3)JD


APs with integrated controller functionality: •

–

–

3.2 3.1.6

Cisco Aironet 1830, 1850, 2800, and 3800 series

3.1.5 3.1.4


8.2.100.0

15.3(3)JC

8.1.122.0

15.3(3)JBB5


APs with integrated controller functionality: •

Cisco Aironet 1850 series, 1830 series


Cisco Aironet 700i, 700w, 1600 series, 1700 series, 2600 series, 2700 series, 3500 series, 3600 series, 3700 series


92

–

1.4

1.4 1.3 1.3

Converged Access Solution Compatibility Matrix

Converged Access Solution Compatibility Matrix Note

Because of SHA-2 certificate implementation, Cisco MSE Release 7.6 is not compatible with Cisco IOS XE Release 3.6E. Therefore, we recommend that you Cisco MSE Release 8.0.

Note

IRCM Feature: Seamless roam between Cisco 5700 WLC/Catalyst 3850 and Cisco 5500 WLC / Cisco WiSM2 with Release 7.3.112.0 using New Mobility.

Note

To see the list of ed Cisco AP models on the Cisco Catalyst 3650 and 3850 Series Switches, see the respective release notes.

Note

Cisco MSE platforms running Cisco MSE Release 8.x are not compatible with the following Cisco switch platforms: —Cisco Catalyst 2960-24TT switch running Cisco Release 15.0(2)SE11 —Cisco Catalyst 2960-48-PST-L switch running Cisco Release 15.0(2)SE11 —Cisco Catalyst 2960X-24PS-L switch running Cisco Release 15.2(2)E7 —Cisco Catalyst 3650-24PS switch running Cisco Release 16.3.5b —Cisco Catalyst 3560-24PS switch running Cisco Release 12.2(55)SE11 —Cisco Catalyst 3850-24XS switch running Cisco Release 16.3.5.b —Cisco Nexus 5596UP switch running Cisco Release 7.1(4)N1(1)


93


Table 13


Catalyst 3850/3650

Cisco 5700 WLC Cisco WLC

Cisco MSE ISE

ACS

Cisco IOS XE Denali 16.3.3

03.07.05E 03.07.04E 03.07.03E 03.07.02E

—

5.3 5.4

Cisco IOS XE Denali 16.3.2 Cisco IOS XE Denali 16.3.1 Cisco IOS XE Denali 16.2.2 Cisco IOS XE Denali 16.2.1

03.06.08E 03.06.07E 03.06.06E 03.06.05aE 03.06.05E 03.06.04E 03.06.03E1

8.5 8.4 8.3 8.2 8.1

2.0 Patch 3 1.4 Patch 7 1.4 (Wireless)

5.5

Cisco Prime Infrastructure 3.1.6 3.1.5 3.1.4 3.1.3

1.3 Patch 6 (Wired and Wireless)

3.1.1 3.1

1.3 Patch 5 (Wired and Wireless)

3.0 Technology Pack

1.3 Patch 3 (Wired)

Cisco IOS XE Denali 16.1.1 03.07.05E 03.07.04E 03.07.03E 03.07.02E 03.07.01E 03.07.00E

03.07.05E 03.07.04E 03.07.03E 03.07.02E 03.07.01E 03.07.00E

8.1 8.0 7.6

8.02

03.06.10E 03.06.09E

03.06.10E 03.06.09E

8.0.x

8.0

2.4

5.2

3.1.4 DP6

03.06.08E

03.06.08E

8.0

3.1.4 DP6

03.06.07E 03.06.06E 03.06.05aE 03.06.05E 03.06.04E 03.06.03E 03.06.02aE 03.06.01E 03.06.00E

1.3 1.2

5.2

03.06.07E 03.06.06E 03.06.05bE 03.06.05E

8.0 7.6

03.06.04E 03.06.03E 03.06.02aE 03.06.01E 03.06.00E 03.03.05SE

03.03.05SE

03.03.04SE

03.03.04SE

03.03.03SE

03.03.03SE

03.03.02SE

03.03.02SE

03.03.01SE

03.03.01SE

03.03.00SE

03.03.00SE

1.3

5.2

2.2

5.3

5.3 2.1.2 or 2.1.1 if Cisco MSE is also deployed3 2.1.0 if MSE is not deployed

7.64 7.55

7.6 7.5

1.2

5.2

2.0

5.3

1. Cisco 5700 (Cisco IOS XE Release 03.06.03E/ 03.07.02E) inter-operates as a Peer MC with Catalyst 3850 running on Cisco IOS XE 03.06.03E/ 03.07.02E releases. 2. Because of SHA-2 certificate implementation, Cisco MSE Release 7.6 is not compatible with Cisco IOS XE Release 3.6E and later. Therefore, we recommend that you Cisco MSE Release 8.0. 3. If Cisco MSE is deployed on your network, we recommend that you Cisco Prime Infrastructure 2.1.2.


94


4. Cisco WLC Release 7.6 is not compatible with Cisco Prime Infrastructure 2.0. 5. Prime Infrastructure 2.0 enables you to manage Cisco WLC 7.5.102.0 with the features of Cisco WLC 7.4.110.0 and earlier releases. Prime Infrastructure 2.0 does not any features of Cisco WLC 7.5.102.0 including the new AP platforms.

Table 14

Converged Access Software Compatibility Matrix

Cisco WLC Release for Cisco 5508 WLC, WiSM2, or Catalyst 4500E with 25041 WLC Cisco Sup 8-E Platforms MSE

Cisco 5700 WLC

Catalyst 3850

Catalyst 3650

03.07.05E 03.07.04E 03.07.03E 03.07.02E 03.07.01E 03.07.00E

03.07.05E 03.07.04E 03.07.03E 03.07.02E 03.07.01E 03.07.00E

03.07.05E 03.07.04E 03.07.03E 03.07.02E 03.07.01E 03.07.00E

03.09.01E 8.3.x 03.09.00E 8.2.x 8.1.x 03.08.03E 8.0 03.08.02E 7.6 03.08.01E 03.08.00E

03.06.09E 03.06.08E

03.06.09E 03.06.08E

03.06.09E 03.06.08E

03.06.07E 03.06.06E 03.06.05aE 03.06.04E 03.06.02aE 03.06.01E 03.06.00E

03.06.07E 03.06.06E 03.06.05bE 03.06.04E 03.06.03E 03.06.02aE 03.06.01E 03.06.00E

03.06.07E 03.06.06E 03.06.05bE 03.06.04E 03.06.03E 03.06.02aE 03.06.01E 03.06.00E

03.07.03E 03.07.02E 03.07.01E 03.07.00E

03.07.05E 03.07.04E 03.07.03E 03.07.02E 03.07.01E 03.07.00E

03.07.05E 03.07.04E 03.07.02E 03.07.01E 03.07.00E

03.07.05E 03.07.04E 03.07.03E 03.07.02E 03.07.01E 03.07.00E

03.06.08E

03.06.08E

03.06.07E

03.06.07E

03.06.06E 03.06.05aE 03.06.05E 03.06.04E 03.06.02aE 03.06.01E 03.06.00E

03.06.06E 03.06.05aE 03.06.05E 03.06.04E 03.06.02aE 03.06.01E 03.06.00E

03.07.03E 8.1.x 03.07.02E 8.0 03.07.01E 7.6 03.07.00E


ISE

ACS

8.0

1.3

5.2 5.3

3.0

8.0

1.3

5.2 5.3

2.2

03.06.08E 03.06.07E 03.06.06E 03.06.05aE 03.06.05E 03.06.04E 03.06.02aE 03.06.01E 03.06.00E


95


Table 14

Cisco 5700 WLC 03.06.05aE 03.06.05E 03.06.04E 03.06.02aE 03.06.01E 03.06.00E

Converged Access Software Compatibility Matrix (continued)

Catalyst 3850

Catalyst 3650

03.06.05bE 03.06.05E 03.06.04E 03.06.03E 03.06.02aE 03.06.01E 03.06.00E

Cisco WLC Release for Cisco 5508 WLC, WiSM2, or Catalyst 4500E with 25041 WLC Cisco Sup 8-E Platforms MSE

03.06.05bE — 03.06.05E 03.06.04E 03.06.03E 03.06.02aE 03.06.01E 03.06.00E

8.0

8.0

2

ISE

ACS

1.2

5.2 5.3

8.0.x 7.6.x

Cisco Prime Infrastructure 2.2 2.1.2 or 2.1.1 if Cisco MSE is also deployed 2.1.0 if Cisco MSE is not deployed3

03.03.03SE 03.03.03SE 03.03.02SE 03.03.02SE 03.03.01SE 03.03.01SE 03.03.00SE 03.03.00SE

03.03.03SE — 03.03.02SE

7.64 7.55

7.6 7.5

1.2

5.2 5.3

2.0

03.03.01SE 03.03.00SE

03.02.03SE 03.02.03SE —

—

7.6.x 7.5 7.3.112.0

7.6 7.5

1.1.3 1.1.2

5.2 5.3

2.0

03.02.02SE 03.02.02SE —

—

7.6.x 7.5 7.3.112.0

7.6 7.5

1.1.3 1.1.2

5.2 5.3

—

03.02.01SE 03.02.01SE —

—

7.3.112.0

—

1.1.3 1.1.2

5.2 5.3

—

03.02.00SE 03.02.00SE —

—

7.3.112.0

—

1.1.1 MR

5.2

—

1. New Mobility is ed on Cisco 2504 WLC in 8.0.x and later releases. 2. Because of SHA-2 certificate implementation, Cisco MSE Release 7.6 is not compatible with Cisco IOS XE Release 3.6E and later. Therefore, we recommend that you Cisco MSE Release 8.0. 3. If Cisco MSE is deployed on your network, we recommend that you Cisco Prime Infrastructure 2.1.2. 4. Cisco WLC Release 7.6 is not compatible with Cisco Prime Infrastructure 2.0. 5. Prime Infrastructure 2.0 enables you to manage Cisco WLC 7.5.102.0 with the features of Cisco WLC 7.4.110.0 and earlier releases. Prime Infrastructure 2.0 does not any features of Cisco WLC 7.5.102.0 including the new AP platforms.

Table 15

Cisco IOS XE to Cisco IOS Version Number Mapping

Cisco IOS XE Version

Cisco IOSd Version

Cisco Wireless Con- Access Point IOS trol Module Version Version

16.4.0

Not applicable

16.4.1.0

15.3(3)JPD

16.3.3

Not applicable

16.3.3.0

15.3(3)JPC3


96


Table 15



Cisco IOSd Version


16.3.2

Not applicable

16.3.2.0

15.3(3)JPC2

16.3.1

Not applicable

16.3.1.1

15.3(3)JPC1

16.3.0

Not applicable

16.3.1.0

15.3(3)JPC

16.2.1

Not applicable

16.2.2.0

15.3(3)JPB1

16.2.0

Not applicable

16.2.1.0

15.3(3)JPB

16.1.2

Not applicable

16.1.3.0

15.3(3)JNP2

16.1.1

Not applicable

16.1.2.0

15.3(3)JNP1

16.1.0

Not applicable

16.1.1.0

15.3(3)JNP

03.09.01E

15.2(5)E1

10.5.110.0

15.3(3)JND1

03.09.00E

15.2(5)E

10.5.100.0

15.3(3)JND

03.08.03E

15.2(4)E3

10.4.130.0

15.3(3)JNC3

03.08.02E

15.2(4)E2

10.4.120.0

15.3(3)JNC2

03.08.01E

15.2(4)E1

10.4.111.0

15.3(3)JNC1

03.08.00E

15.2(3)E

10.3.100.0

15.3(3)JNB

03.07.05E

15.2(3)E5

10.3.150.0

15.3(3)JNB6

03.07.04E

15.2(3)E4

10.3.141.0

15.3(3)JNB5

03.07.03E

15.2(3)E3

10.3.130.0

15.3(3)JNB3

03.07.02E

15.2(3)E2

10.3.120.0

15.3(3)JNB2

03.07.01E

15.2(3)E1

10.3.100.0

15.3(3)JNB1

03.06.10E

15.2(2)E10

10.2.200.0

15.3(3)JN17

03.06.09E

15.2(2)E9

10.2.190.0

15.3(3)JN15

03.06.08E

15.2(2)E8

10.2.180.0

15.3(3)JN14

03.06.07E

15.2(2)E7

10.2.170.0

15.3(3)JN12

03.06.06E

15.2(2)E6

10.2.160.0

15.3(3)JN11

03.06.05aE

15.2(2)E5

10.2.155.0

15.3(3)JN10

03.06.05E

15.2(2)E5

10.2.150.0

15.3(3)JN9

03.06.04E

15.2(2)E4

10.2.140.0

15.3(3)JN8

03.06.03E

15.2(2)E3

10.2.131.0

15.3(3)JN7

03.06.02E

15.2(2)E2

10.2.120.0

15.3(3)JN4

03.06.01E

15.2(2)E1

10.2.111.0

15.3(3)JN3

03.06.00E

15.2(2)E

10.2.102.0

15.3(3)JN

03.03.05SE

15.0(1)EZ5

10.1.150.0

15.2(4)JB7

03.03.04SE

15.0(1)EZ4

10.1.140.0

15.2(4)JB6

03.03.03SE

15.0(1)EZ3

10.1.130.0

15.2(4)JB5h

03.03.02SE

15.0(1)EZ2

10.1.121.0

15.2(4)JB3h


97

ed Converged Access Solution Hardware

Table 15



Cisco IOSd Version


03.03.01SE

15.0(1)EZ1

10.1.110.0

15.2(4)JB2

03.03.00SE

15.0(1)EZ

10.1.100.0

15.2(4)JN

03.02.03SE

15.0(1)EX3

10.0.120.0

15.2(2)JN

03.02.02SE

15.0(1)EX2

10.0.111.0

15.2(2)JN

03.02.01SE

15.0(1)EX1

10.0.101.0

15.2(2)JN

03.02.00SE

15.0(1)EX

10.0.100.0

15.2(2)JN

ed Converged Access Solution Hardware ed Cisco 5760 Wireless Controller Models Table 16

Cisco WLC 5700 Models

Part Number

Description

AIR-CT5760-25-K9

Cisco 5760 Wireless Controller for up to 25 Cisco access points

AIR-CT5760-50-K9


AIR-CT5760-100-K9


AIR-CT5760-250-K9


AIR-CT5760-500-K9


AIR-CT5760-1K-K9


AIR-CT5760-HA-K9

Cisco 5760 Series Wireless Controller for High Availability

ed Cisco Aironet Series Universal Access Points To see the list of ed Cisco Aironet Series Universal Access Points, see the ed Cisco Aironet Series Universal Access Points section of the Cisco Aironet Universal AP Priming and Cisco AirProvision Guide


98

Compatibility Matrix for Legacy Products

ed Catalyst 3850 Switch Models To see the list of ed Cisco Catalyst 3850 Switch models, see the Switch Models section of Catalyst 3850 Switch Hardware Installation Guide.

ed Catalyst 3650 Switch Models To see the list of ed Cisco Catalyst 3650 Switch models, see the Switch Models section of Catalyst 3650 Switch Hardware Installation Guide.

Compatibility Matrix for Legacy Products This section contains the following subsections: •

Cisco Prime Network Control System Compatibility Matrix, page 100

•

Cisco Wireless Control System Compatibility Matrix, page 103

•

Cisco WCS Navigator Compatibility Matrix, page 111


99


Cisco Prime Network Control System Compatibility Matrix Table 17 lists the compatibility matrix of Cisco Prime NCS, controller, access point images, Identity Services Engines (ISE), and Cisco Mobility Services Engine (MSE). Table 17

Cisco Prime Network Control System Compatibility Matrix

Cisco NCS

Cisco WLC

Cisco MSE

ISE

1.1.1.24

7.2.115.2 7.2.111.3 7.2.110.0 7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.01 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

7.2.110.0 7.2.103.0 7.0.240.0 7.0.230.0 7.0.220.0 7.0.201.204 7.0.112.0 7.0.105.0

ISE 1.0 ISE 1.1

1.1.0.58

7.2.103.0 7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.02 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0

7.2.103.0 7.0.240.0 7.0.230.0 7.0.220.0 7.0.201.204 7.0.112.0 7.0.105.0

ISE 1.0 ISE 1.1


100


Table 17

Cisco Prime Network Control System Compatibility Matrix (continued)

Cisco NCS

Cisco WLC

Cisco MSE

ISE

1.0.2.29

7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.1.91.03 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0 6.0.202.0 6.0.199.4 6.0.196.0 6.0.188.0 6.0.182.0 6.0.108.0 4.2.209.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

7.0.240.0 7.0.230.0 7.0.220.0 7.0.201.204 7.0.112.0 7.0.105.0 6.0.202.0 6.0.103.0

ISE 1.0


101


Table 17

Cisco Prime Network Control System Compatibility Matrix (continued)

Cisco NCS

Cisco WLC

Cisco MSE

ISE

1.0.1.4

7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0 6.0.202.0 6.0.199.4 6.0.196.0 6.0.188.0 6.0.182.0 6.0.108.0 4.2.209.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

7.0.220.0 7.0.201.204 7.0.112.0 7.0.105.0 6.0.202.0 6.0.103.0

ISE 1.0

1.0.0.96

7.0.116.0 7.0.98.218 7.0.98.0 6.0.202.0 6.0.199.4 6.0.196.0 6.0.188.0 6.0.182.0 6.0.108.0 4.2.209.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

7.0.201.204 7.0.112.0 7.0.105.0 6.0.202.0 6.0.103.0

ISE 1.0

1. If you the 7.1.91.0 software release of Cisco Wireless LAN Controller from an earlier release, we suggest that you also upgrade Cisco Wireless Control System to 7.0.220.0 and Cisco MSE to 7.0.220.0. This upgrade ensures that you get for the latest 3600i and 3600e lightweight access points. 2. If you the 7.1.91.0 software release of Cisco Wireless LAN Controller from an earlier release, we suggest that you also upgrade Cisco Wireless Control System to 7.0.220.0 and Cisco MSE to 7.0.220.0. This upgrade ensures that you get for the latest 3600i and 3600e lightweight access points. 3. If you the 7.1.91.0 software release of Cisco Wireless LAN Controller from an earlier release, we suggest that you also upgrade Cisco Wireless Control System to 7.0.220.0 and Cisco MSE to 7.0.220.0. This upgrade ensures that you get for the latest 3600i and 3600e lightweight access points.


102


Cisco Wireless Control System Compatibility Matrix Table 18 lists the Cisco Wireless Control System (WCS) compatibility matrix. Table 18

Cisco WCS Compatibility Matrix

WCS Version

Controller Versions

2710 Location Appliance Versions

MSE Versions

Upgrade ed From

7.0.240.0

7.0.252.0 7.0.251.2 7.0.250.0 7.0.240.0 7.0.235.3 7.0.235.0 7.0.230.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0 6.0.202.0 6.0.196.0 6.0.188.0 6.0.182.0 6.0.108.0 5.2.193.0 5.2.178.0 5.2.157.0 4.2.209.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

—

7.0.240.0

7.0.230.0 7.0.220.0 7.0.172.0 7.0.164.3 7.0.164.0 6.0.202.0 6.0.196.0 6.0.181.0 6.0.170.0 6.0.132.0 5.2.148.0 5.2.130.0 5.2.125.0 5.2.110.0


103


Table 18

Cisco WCS Compatibility Matrix (continued)

WCS Version

Controller Versions


MSE Versions

Upgrade ed From

7.0.230.0

7.0.235.3 7.0.235.0 7.0.230.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0 6.0.202.0 6.0.196.0 6.0.188.0 6.0.182.0 6.0.108.0 5.2.193.0 5.2.178.0 5.2.157.0 4.2.209.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

—

7.0.230.0

7.0.220.0 7.0.172.0 7.0.164.3 7.0.164.0 6.0.202.0 6.0.196.0 6.0.181.0 6.0.170.0 6.0.132.0 5.2.148.0 5.2.130.0 5.2.125.0 5.2.110.0

7.0.220.0

7.1.91.0 7.0.220.0 7.0.116.0 7.0.98.218 7.0.98.0 6.0.202.0 6.0.196.0 6.0.188.0 6.0.182.0 6.0.108.0 5.2.193.0 5.2.178.0 5.2.157.0 4.2.209.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

—

7.0.220.0

7.0.172.0 7.0.164.3 7.0.164.0 6.0.202.0 6.0.196.0 6.0.181.0 6.0.170.0 6.0.132.0 5.2.148.0 5.2.130.0 5.2.125.0 5.2.110.0


104


Table 18


WCS Version

Controller Versions


MSE Versions

Upgrade ed From

7.0.172.0

7.0.116.0 7.0.98.218 7.0.98.0 6.0.202.0 6.0.196.0 6.0.188.0 6.0.182.0 6.0.108.0 5.2.193.0 5.2.178.0 5.2.157.0 4.2.209.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

—

7.0.201.204

7.0.164.3 7.0.164.0 6.0.202.0 6.0.196.0 6.0.181.0 6.0.170.0 6.0.132.0 5.2.148.0 5.2.130.0 5.2.125.0 5.2.110.0

7.0.164.3

7.0.98.218 7.0.98.0 6.0.196.0 6.0.188.0 6.0.182.0 6.0.108.0 5.2.193.0 5.2.178.0 5.2.157.0 4.2.209.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

—

7.0.112.0 7.0.105.0

6.0.181.0 6.0.170.0 6.0.132.0 5.2.148.0 5.2.130.0 5.2.125.0 5.2.110.0


105


Table 18


WCS Version

Controller Versions


MSE Versions

Upgrade ed From

7.0.164.0

7.0.98.218 7.0.98.0 6.0.196.0 6.0.188.0 6.0.182.0 6.0.108.0 5.2.193.0 5.2.178.0 5.2.157.0 4.2.209.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

—

7.0.112.0 7.0.105.0

6.0.181.0 6.0.170.0 6.0.132.0 5.2.148.0 5.2.130.0 5.2.125.0 5.2.110.0

6.0.196.0

6.0.199.4 6.0.199.0 (pulled from CCO) 6.0.196.0 6.0.188.0 6.0.182.0 6.0.108.0 5.2.193.0 5.2.178.0 5.2.157.0 5.1.163.0 5.1.151.0 4.2.209.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

6.0.102.0

6.0.105.0

6.0.181.0 6.0.170.0 6.0.132.0 5.2.148.0 5.2.130.0 5.2.125.0 5.2.110.0 5.1.65.4 5.1.64.0 4.2.128.0 4.2.110.0 4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0


106


Table 18


WCS Version

Controller Versions


MSE Versions

Upgrade ed From

6.0.181.0

6.0.199.4 6.0.199.0 6.0.196.159 6.0.196.0 6.0.188.0 6.0.182.0 6.0.108.0 5.2.193.0 5.2.178.0 5.2.157.0 5.1.163.0 5.1.151.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

6.0.101.0

6.0.103.0

6.0.170.0 6.0.132.0 5.2.148.0 5.2.130.0 5.2.125.0 5.2.110.0 5.1.65.4 5.1.64.0 4.2.128.0 4.2.110.0 4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0

6.0.170.0

6.0.188.0 6.0.182.0 6.0.108.0 5.2.193.0 5.2.178.0 5.2.157.0 5.1.163.0 5.1.151.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

6.0.97.0

6.0.97.0

6.0.132.0 5.2.148.0 5.2.130.0 5.2.125.0 5.2.110.0 5.1.65.4 5.1.64.0 4.2.128.0 4.2.110.0 4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0

6.0.132.0

6.0.182.0 6.0.108.0 5.2.178.0 5.2.157.0 5.1.163.0 5.1.151.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

6.0.85.0

6.0.85.0

5.2.130.0 5.2.125.0 5.2.110.0 5.1.65.4 5.1.64.0 4.2.128.0 4.2.110.0 4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0


107


Table 18


WCS Version

Controller Versions


MSE Versions

Upgrade ed From

5.2.148.0

5.2.193.0 5.2.178.0 5.2.157.0 5.1.151.0 5.0.148.2 5.0.148.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

5.2.100.0

5.2.100.0

5.2.130.0 5.2.125.0 5.2.110.0 5.1.65.4 5.1.64.0 5.0.72.0 5.0.56.2 5.0.56.0 4.2.128.0 4.2.110.0 4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0

5.2.130.0

5.2.178.0 5.2.157.0 5.1.151.0 5.0.148.2 5.0.148.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

5.2.91.0

5.2.91.0

5.2.125.0 5.2.110.0 5.1.65.4 5.1.64.0 5.0.72.0 5.0.56.2 5.0.56.0 4.2.110.0 4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0

5.2.125.0 (pulled 5.2.178.0 from CCO) 5.2.157.0 5.1.151.0 5.0.148.2 5.0.148.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

5.2.91.0

5.2.91.0

5.2.110.0 5.1.65.4 5.1.64.0 5.0.72.0 5.0.56.2 5.0.56.0 4.2.110.0 4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0

5.2.110.0

5.2.91.0

5.2.91.0

5.1.64.0 5.0.72.0 5.0.56.2 5.0.56.0 4.2.110.0 4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0

5.2.157.0 5.1.151.0 5.0.148.2 5.0.148.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0


108


Table 18


WCS Version

Controller Versions


MSE Versions

Upgrade ed From

5.1.65.4

5.1.163.0 5.1.151.0 5.0.148.2 5.0.148.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

5.1.35.0

5.1.35.0

5.1.64.0 5.0.72.0 5.0.56.2 5.0.56.0 4.2.110.0 4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0

5.1.64.0

5.1.151.0 5.0.148.2 5.0.148.0 4.2.176.0 4.2.173.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0

5.1.30.0

5.1.30.0

5.0.56.2 5.0.56.0 4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0

5.0.72.0

5.0.148.2 5.0.148.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0 4.1.185.0 4.1.171.0

4.0.38.0

—

5.0.56.2 5.0.56.0 4.2.62.11 4.2.62.0 4.1.91.0 4.1.83.0

5.0.56.2

5.0.148.0 4.2.61.0 4.1.x.x

4.0.33.0

—

5.0.56.0 4.2.62.11 4.2.62.0 4.1.91.0 4.1.83.0

5.0.56.0

5.0.148.0 4.2.61.0 4.1.x.x

4.0.32.0

—

4.2.62.11 4.2.62.0 4.1.91.0 4.1.83.0


109


Table 18


WCS Version

Controller Versions


MSE Versions

Upgrade ed From

4.2.128.0

4.2.209.0 4.2.207.0 4.2.205.0 4.2.176.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0 4.1.185.0 4.1.171.0 4.0.216.0 4.0.206.0 4.0.179.11 4.0.179.8 4.0.155.0

3.1.43.0

—

4.2.110.0 4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0 4.1.91.0 4.1.83.0 4.0.100.0 4.0.97.0 4.0.96.0 4.0.87.0 4.0.81.0 4.0.66.0

4.2.110.0

4.2.176.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0 4.1.185.0 4.1.171.0 4.0.216.0 4.0.206.0 4.0.179.11 4.0.179.8 4.0.155.0

3.1.42.0

—

4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0 4.1.91.0 4.1.83.0 4.0.100.0 4.0.97.0 4.0.96.0 4.0.87.0 4.0.81.0 4.0.66.0

4.2.97.0

4.2.176.0 4.2.130.0 4.2.112.0 4.2.99.0 4.2.61.0 4.1.185.0 4.1.171.0 4.0.216.0 4.0.206.0 4.0.179.11 4.0.179.8 4.0.155.0

3.1.38.0

—

4.2.81.0 4.2.62.11 4.2.62.0 4.1.91.0 4.1.83.0 4.0.100.0 4.0.97.0 4.0.96.0 4.0.87.0 4.0.81.0 4.0.66.0


110


Table 18


WCS Version

Controller Versions


MSE Versions

Upgrade ed From

4.2.81.0

4.2.99.0 4.2.61.0 4.1.185.0 4.1.171.0 4.0.216.0 4.0.206.0 4.0.179.11 4.0.179.8 4.0.155.0

3.1.36.0

—

4.2.62.11 4.2.62.0 4.1.91.0 4.1.83.0 4.0.100.0 4.0.97.0 4.0.96.0 4.0.87.0 4.0.81.0 4.0.66.0

4.2.62.11

4.2.61.0 4.1.185.0 4.1.171.0 4.0.216.0 4.0.206.0 4.0.179.11 4.0.179.8 4.0.155.0

3.1.35.0

—

4.2.62.0 4.1.91.0 4.1.83.0 4.0.100.0 4.0.97.0 4.0.96.0 4.0.87.0 4.0.81.0 4.0.66.0

4.2.62.0

4.2.61.0 4.1.185.0 4.1.171.0 4.0.216.0 4.0.206.0 4.0.179.11 4.0.179.8 4.0.155.0

3.1.35.0

—

4.1.91.0 4.1.83.0 4.0.100.0 4.0.97.0 4.0.96.0 4.0.87.0 4.0.81.0 4.0.66.0

Cisco WCS Navigator Compatibility Matrix Cisco WCS and Cisco WCS Navigator must be from the same release in order to be compatible (see Table 19). Although the release numbers will not be the same, you must whether they were part of the same release. For example, Cisco WCS Navigator 1.0 is compatible with Cisco WCS 4.1, and Cisco WCS Navigator 1.1.x is compatible with any Cisco WCS 4.2.x.

Note

When Cisco WCS Navigator is upgraded to a new version, the corresponding Cisco WCS must also be upgraded to the corresponding new version. For example, if Cisco WCS Navigator is upgraded to version 1.6, Cisco WCS must also be upgraded to the corresponding version 7.0.


111


Table 19

WCS and Navigator Compatibility Matrix

Navigator Release Number

WCS Release Number

Upgrade ed From

1.6.230.0

7.0.240.0 7.0.230.0

1.6.220.0 1.6.172.0 1.6.164.3 1.6.164.0 1.5.202.0 1.5.196.0 1.5.181.0 1.5.170.0 1.5.132.0 1.4.148.0 1.4.130.0 1.4.125.0 1.4.110.0

1.6.220.0

7.0.220.0

1.6.172.0 1.6.164.3 1.6.164.0 1.5.202.0 1.5.196.0 1.5.181.0 1.5.170.0 1.5.132.0 1.4.148.0 1.4.130.0 1.4.125.0 1.4.110.0

1.6.172.0

7.0.172.0

1.6.164.3 1.6.164.0 1.5.202.0 1.5.196.0 1.5.181.0 1.5.170.0 1.5.132.0 1.4.148.0 1.4.130.0 1.4.125.0 1.4.110.0

1.6.164.3

7.0.164.3

1.6.164.0 1.5.202.0 1.5.196.0 1.5.181.0 1.5.170.0 1.5.132.0 1.4.148.0 1.4.130.0 1.4.125.0 1.4.110.0


112


Table 19

WCS and Navigator Compatibility Matrix (continued)


WCS Release Number

Upgrade ed From

1.6.164.0

7.0.164.0 7.0.164.3

6.0.181.0 6.0.170.0 6.0.132.0 5.2.148.0 5.2.130.0 5.2.125.0 5.2.110.0

1.5.202.0

6.0.132.0 6.0.181.0 6.0.202.0

1.5.196.0 1.5.181.0 1.5.170.0 1.5.132.0 1.4.148.0 1.4.130.0 1.4.125.0 1.4.110.0 1.3.65.4 1.3.64.0 1.1.128.0 1.1.110.0 1.1.97.0 1.1.81.0 1.1.62.11 1.1.62.0

1.5.196.0

6.0.196.0

1.5.181.0 1.5.170.0 1.5.132.0 1.4.148.0 1.4.130.0 1.4.125.0 1.4.110.0 1.3.65.4 1.3.64.0 1.1.128.0 1.1.110.0 1.1.97.0 1.1.81.0 1.1.62.11 1.1.62.0


113


Table 19



WCS Release Number

Upgrade ed From

1.5.181.0

6.0.181.0

1.5.170.0 1.5.132.0 1.4.148.0 1.4.130.0 1.4.125.0 1.4.110.0 1.3.65.4 1.3.64.0 1.1.128.0 1.1.110.0 1.1.97.0 1.1.81.0 1.1.62.11 1.1.62.0

1.5.170.0

6.0.132.0

1.5.132.0 1.4.148.0 1.4.130.0 1.4.125.0 1.4.110.0 1.3.65.4 1.3.64.0 1.1.128.0 1.1.110.0 1.1.97.0 1.1.81.0 1.1.62.11 1.1.62.0

1.5.132.0

6.0.132.0

1.4.130.0 1.4.125.0 1.4.110.0 1.3.65.4 1.3.64.0 1.1.128.0 1.1.110.0 1.1.97.0 1.1.81.0 1.1.62.11 1.1.62.0


114


Table 19



WCS Release Number

Upgrade ed From

1.4.148.0

5.2.148.0

1.4.130.0 1.4.125.0 1.4.110.0 1.3.65.4 1.3.64.0 1.2.72.0 1.2.56.2 1.2.56.0 1.1.128.0 1.1.110.0 1.1.97.0 1.1.81.0 1.1.62.11 1.1.62.0

1.4.130.0

5.2.130.0 5.2.110.0

1.4.125.0 1.4.110.0 1.3.65.4 1.3.64.0 1.2.72.0 1.2.56.2 1.2.56.0 1.1.128.0 1.1.110.0 1.1.97.0 1.1.81.0 1.1.62.11 1.1.62.0

1.4.110.0

5.2.110.0

1.3.64.0 1.2.72.0 1.2.56.2 1.2.56.0 1.1.128.0 1.1.110.0 1.1.97.0 1.1.81.0 1.1.62.11 1.1.62.0

1.3.64.0

5.1.64.0

1.2.56.2 1.2.56.0 1.1.128.0 1.1.110.0 1.1.97.0 1.1.81.0 1.1.62.11 1.1.62.0


115

Inter-Release Controller Mobility

Table 19



WCS Release Number

Upgrade ed From

1.1.128.0

4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0 4.2.110.0 4.2.128.0

1.1.110.0 1.1.97.0 1.1.81.0 1.1.62.11 1.1.62.0 1.0.91.0 1.0.83.0

1.1.110.0

4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0 4.2.110.0

1.1.97.0 1.1.81.0 1.1.62.11 1.1.62.0 1.0.91.0 1.0.83.0

1.1.97.0

4.2.97.0 4.2.81.0 4.2.62.11 4.2.62.0

1.1.81.0 1.1.62.11 1.1.62.0 1.0.91.0 1.0.83.0

1.1.62.11

4.2.62.11 4.2.62.0

1.1.62.0 1.0.91.0 1.0.83.0

1.1.62.0

4.2.62.0

1.0.91.0 1.0.83.0

1.0.91.0

4.1.91.0 4.1.83.0

1.0.83.0

1.0.83.0

4.1.83.0

—

Inter-Release Controller Mobility This section contains the following Inter-Release Controller Mobility (IRCM) topics: •

IRCM Compatibility Matrix, page 117

•

CUWN Converged Access Solution Components and New (Hierarchical) Mobility IRCM Compatibility Matrix, page 118


116


IRCM Compatibility Matrix Table 20

IRCM Compatibility Matrix: 4.2.x to 7.6.x Releases

CUWN Service

4.2.x

5.0.x

5.1.x

6.0.x

7.0.x

7.2.x

7.3.x

7.4.x

7.6.x

Layer 2 and Layer 3 Roaming Y

—

—

Y

Y

Y

Y

Y

Y

Wireless Guest Access/Termination

Y

Y

Y

Y

Y

Y

Y

Y

Y

Cisco MSE Release 8.0 wIPS and AwIPS Rogue Detection

Y

—

—

Y

Y

Y

Y

Y

Y

Fast Roaming (CCKM) in a mobility group

Y

—

—

Y

Y

Y

Y

Y

Y

Location Services

Y

—

—

Y

Y

Y

Y

Y

Y

Y

Y 1

2

Radio Resource Management (RRM)

Y

—

—

Y

Y

Y

Management Frame Protection (MFP)

Y

—

—

Y

Y

Y

Y

Y

Y

AP Failover

Y

—

—

Y

Y

Y

Y

Y

Y

Y

1. In the 7.2.x.x release, RF Groups and Profiles were introduced. RRM for 7.2.x.x and later releases is not compatible with RRM for any previous release. 2. In the 7.3.101.0 release, changes were made to RF profiles that are not backwardly compatible with 7.2.

Table 21

IRCM Compatibility Matrix: 7.0.x to 8.0.x Releases

CUWN Service

7.0.x

7.2.x

7.3.x

7.4.x

7.6.x

8.0.x


Y

Y

Y

Y

Y


Y

Y

Y

Y

Y

Y


Y

Y

Y

Y

Y

Y


Y

Y

Y

Y

Y

Y

Location Services

Y

Y

Y

Y

Y

Y

Y

Y

Y 1

2


Y

Y


Y

Y

Y

Y

Y

Y

AP Failover

Y

Y

Y

Y

Y

Y

Y

1. In the 7.2.x.x release, RF Groups and Profiles were introduced. RRM for 7.2.x.x and later releases is not compatible with RRM for any previous release. 2. In the 7.3.101.0 release, changes were made to RF profiles that are not backwardly compatible with 7.2.


117


Table 22

IRCM Compatibility Matrix: 7.4.x to 8.1.x and Later Releases

CUWN Service

7.4.x

7.6.x

8.0.x

8.1.x

8.2.x

8.3.x

8.4.x

8.5.x

8.6.x

8.7.x

8.8.x


Y

Y

Y

Y

Y

Y

Y

Y

Y

Y


Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y


Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y


Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Location Services

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y


Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y


Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

AP Failover

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

CUWN Converged Access Solution Components and New (Hierarchical) Mobility IRCM Compatibility Matrix Table 23

CUWN Converged Access Solution Components and New (Hierarchical) Mobility IRCM Compatibility Matrix

7.3.112.0 7.5 and later releases

Service Layer 2 and Layer 3 Roaming

IOS XE 3.2.0SE and later releases

Y

Y

Y

Y

Cisco MSE Release 8.0 wIPS and AwIPS Rogue Detection2

Y

Y


Y

Y

Location Services

Y

Y

Radio Resource Management (RRM)3

Y

Y


Y

Y

Y

Y

Wireless Guest Anchor/Termination

AP Failover and SSO

4

1

1. Guest Anchor Termination is only ed on Cisco 2500 Series, 5700 Series, 5500 Series, 8500 Series, and Cisco WiSM2 platforms. The Cisco 2500 Series, 5700 Series, 5500 Series, 8500 Series, Cisco WiSM2, and Catalyst 3650 and 3850 are all ed as foreign controllers. 2. Rogue Detector Mode is not ed on Catalyst 3650 and 3850. 3. In Release 7.2, RF profiles and groups feature was introduced. RRM for Release 7.2 and later is not backward compatible with the earlier releases. RRM Converged Access is compatible with the controller software 7.6 and later releases but does not RF Profiles and Groups feature that was introduced in Release 7.2. 4. AP SSO for Cisco 5700 series controllers is ed in IOS XE 3.3.0SE release. AP Intra-OS Platform Fast Failover ed. AP Inter-OS Platform Image and Reboot performed.


118

New Mobility Matrix

New Mobility Matrix This section lists the New Mobility matrix for Cisco WLC platforms per various Cisco Wireless releases:

Note

•

Cisco 2504 and 5508 Wireless Controller and WiSM2, page 119

•

Cisco 8510 Wireless Controllers, page 120

•

Cisco 3504, 5520, and 8540 Wireless Controllers, page 120

New Mobility is not ed on Cisco Flex 7510 WLC and Cisco Virtual Wireless Controller (vWLC).

Cisco 2504 and 5508 Wireless Controller and WiSM2 Table 24

New Mobility Matrix for Cisco 2504 and 5508 WLCs and WiSM2

Feature

7.3.112.0

7.4

7.5

7.6

8.0

8.1

8.2

8.3

8.4

8.5

New Mobility—Guest Anchor Controller

Y

N

Y

Y

Y

Y

Y

Y

Y

Y

New Mobility—Mobility Controller

Y

N

Y

Y

Y

N

N

N

N

N

New Mobility—Mobility Controller SPG

Y

N

Y

Y

Y

N

N

N

N

N

Native IPv6

N

N

N

N

N

N

N

N

N

N

HA AP SSO

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

HA Client SSO

N

N

N

N

N

N

N

N

N

N

Sleeping Clients

N

N

N

Y

Y

Y

Y

Y

Y

Y

Mobility Statistics

Y

N

Y

Y

Y

Y

Y

Y

Y

Y

Mobility Oracle configuration

N

N

Y

Y

Y

Y

Y

Y

Y

Y

EoGRE Tunnel

N

N

N

N

N

N

N

N

N

N

Mobility for Microsoft Lync calls

N

N

N

N

N

N

N

N

N

N

Mesh RAP channel synchronization across mobility groups

N

N

N

N

N

N

N

N

N

N

AVC Profile

N

N

Y

Y

Y

Y

Y

Y

Y

Y

Internal DH

N

N

N

N

N

N

N

N

N

N

PMIPv6

N

N

N

N

N

N

N

N

N

N

Fast SSID Switching

N

N

N

Y

Y

Y

Y

Y

Y

Y

802.11r

N

N

N

N

Y

Y

Y

Y

Y

Y

802.11k

N

N

N

N

Y

Y

Y

Y

Y

Y

802.11v

N

N

N

N

Y

Y

Y

Y

Y

Y


119

New Mobility Matrix

Cisco 8510 Wireless Controllers Table 25

New Mobility Matrix for Cisco 8510 WLCs

Feature

8.0

8.1

8.2

8.3

8.4

8.5

New Mobility—Guest Anchor Controller Y

Y

Y

Y

Y

Y


Y

Y

Y

Y

N

N

New Mobility—Mobility Controller SPG N

N

N

N

N

N

Native IPv6

N

N

N

N

N

N

HA AP SSO

Y

Y

Y

Y

Y

Y

HA Client SSO

N

N

N

N

N

N

Y

Y

Y

Y

Y

1

Sleeping Clients

Y

Mobility Statistics

Y

Y

Y

Y

Y

Y


N

N

N

N

N

N

EoGRE Tunnel

N

N

N

N

N

N

Fast SSID Switching

Y

Y

Y

Y

Y

Y

802.11r

Y

Y

Y

Y

Y

Y

802.11k

Y

Y

Y

Y

Y

Y

802.11v

Y

Y

Y

Y

Y

Y

1. ed from Release 8.0.140.0 onwards.

Cisco 3504, 5520, and 8540 Wireless Controllers Table 26

New Mobility Matrix for Cisco 3504, 5520, and 8540 WLCs

Feature

8.1

8.2

8.3

8.4

8.5

New Mobility—Guest Anchor Controller Y

Y

Y

Y

Y


Y

Y

Y

N

N

New Mobility—Mobility Controller SPG N

N

N

N

N

Native IPv6

N

N

N

N

N

HA AP SSO

Y

Y

Y

Y

Y

HA Client SSO

N

N

N

N

N

Sleeping Clients

Y

Y

Y

Y

Y

Mobility Statistics

Y

Y

Y

Y

Y


N

N

N

N

N

EoGRE Tunnel

N

N

N

N

N

Mobility for Microsoft Lync calls

N

N

N

N

N

Mesh RAP channel synchronization across mobility groups

N

N

N

N

N


120

Cisco Community

Table 26

New Mobility Matrix for Cisco 3504, 5520, and 8540 WLCs

Feature

8.1

8.2

8.3

8.4

8.5

AVC Profile

Y

Y

Y

Y

Y

Internal DH

N

N

N

N

N

PMIPv6

N

N

N

N

N

Fast SSID Switching

Y

Y

Y

Y

Y

802.11r

Y

Y

Y

Y

Y

802.11k

Y

Y

Y

Y

Y

802.11v

Y

Y

Y

Y

Y

Cisco Community Cisco Community is a forum for you to ask and answer questions, share suggestions, and collaborate with your peers. the forum at https://forums.cisco.com/index.jspa.

Communications, Services, and Additional Information To receive timely, relevant information from Cisco, sign up at Cisco Profile Manager. To get the business impact you’re looking for with the technologies that matter, visit Cisco Services. To submit a service request, visit Cisco . To discover and browse secure, validated enterprise-class apps, products, solutions and services, visit Cisco Marketplace. To obtain general networking, training, and certification titles, visit Cisco Press. To find warranty information for a specific product or product family, access Cisco Warranty Finder.

Cisco Bug Search Tool Cisco Bug Search Tool (BST) is a web-based tool that acts as a gateway to the Cisco bug tracking system that maintains a comprehensive list of defects and vulnerabilities in Cisco products and software. BST provides you with detailed defect information about your products and software.

Cisco and the Cisco logo are trademarks or ed trademarks of Cisco and/or its s in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (1721R)

Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples, command display output, network topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in illustrative content is unintentional and coincidental. © 2017-2019 Cisco Systems, Inc. All rights reserved.


121

Cisco Bug Search Tool


122

Compatibility Matrix 3bk2l

Overview 3z723u

More details 2i4a6q

Related Documents g842

Compatibility Matrix 3bk2l

Compatibility Matrix 3bk2l

Ccm Compatibility Matrix 472n22

Ppm Compatibility Matrix 7238

Compatibility Matrix Wlc 6a1c2b

Wonder Ware Compatibility Matrix 3q1i5l

More Documents from "Marcos Tapia" 533a1d

Compatibility Matrix 3bk2l

Isildur 2cyu

Cultura Chupicuaro 4t5c1n

Manual De Procedimientos De Liderazgo Imcol.doc 3tz2k

929

Una Disciplina Segmentada-gabriel Almond 1s6tm
