Color PTZ Video Conference Camera KT-D848 Product Overview KT-D848 is a color video communication camera which designed for videoconferencing business, adopt SONY FCB48 18X optical zoom lens, build in high speed PTZ, making s can see tiny or long distance object clearly. Integration design, refined aesthetic shape, operation smoothly, without noise, accurate location, high reliability and long-term stability run, no need for maintenance. Use RS232 multi protocol communication, desktop and ceiling mount at the same time, qualified for video conferencing , CCTV remote monitor, etc.

Main Application Widely used in video conferencing, remote teaching, enterprise training, remote medical, church, accident, court, multimedia, chain store, transportation, airport and other monitor area.

Features Integration

design, refined aesthetic shape Build in SONY 550TVL CCD module 216X zoom (18 optical*12 digital) Precision & constant speed step motor drive, outstanding agile, precise location(±0.1°) 360 degrees Pan, 210 degrees Tilt With OSD,VISCA, Pelco P&D protocols, IR Control Speed, Camera Parameters settable. 9 preset positions by remote commander, 255 preset positions by PC or keyboard controller, memory auto store when power off Enter in and out menu by remote commander directly 255 address settable (7 camera setting synchronously Via VISCA) Multiple control: IR remote control, RS-232C/422 control Video output: CVBS &S-VIDEO Desktop, Tripod and Ceiling mount

Information

automatically  Preset positions autocorrect  Perfect compatible with SONY Terminals

Specification Item No.

KT-D848

Image Sensor

SONY 1/4 Exwave HAD CCD

Effective Pixel

752 (H) x 582 (V)

Signal System

NTSC/PAL

Horizontal Resolution

550 TVL

Synchronizati on

Internal & External

Lens

18X Optical，F=4.1mm(tele)～73.8mm(wide)，F1.4～F3.0

Angle of View (H)

48°(wide-angle)～2.8°(far-end)

Min. object distance

290mm(wide-angle)～800mm(far-end)

Minimum Illumination

0.4lux (F1.4, 50IRE)

Auto exposure

Auto/Manual/AE priority, exposure compensation, backlight compensation

Shutter Speed

1/3～1/10000S,22 shelves

Gain

Auto/Manual (-3 ~ +28dB, 2 dB step)

White Balance

Auto/ATW/Indoor/Outdoor/One push WB/Manual WB

S/N Ratio

more than 50dB

Pan/Tilt

Pan: +/- 360° (max. speed: 80°/s) Tilt: -30° to + 90° (max. speed: 60°/s)

Preset Position

9 by remote commander, 256 by keyboard controller

Picture effect

E-Flip, Invert, Mirror

Analog Output

VIDEO and S-VIDEO VBS 1.0VP-P

Camera Control

RS-232C(8-pin DIN)/(VISCA)/RS-422(9-pin) (VISCA)

Baud rate

9600bps、38400bps

Power

10.8V～13.2V

Operating Temperature

0℃～50℃

Storage

-20℃～+60℃

Temperature Consumption

12W

Dimensions

(L)153×(W)×134×(H)×153mm

Weight

1200g

Color

black

Supplied accessories

12 DV AC power adapter，IR controller，RS232C cable, Ceiling bracket, Operation menu
