Bt 136 ivated triacs in a plastic envelope, SYMBOL PARAMETER MAX. UNIT intended for use in applications requiring high bidirectional transient and blocking BT136- 600 voltage capability and high thermal cycling BT136- 600F performance. Typical applications include motor control, industrial and domestic VDRM Repetitive peak off-state 600 V lighting, heating and static switching.

PINNING - TO220AB PIN CONFIGURATION SYMBOL PIN DESCRIPTION 1 main terminal 1 2 main terminal 2 3 gate tab main terminal 2

LIMITING VALUES Limiting values in accordance with the Absolute Maximum System (IEC 134). SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT VDRM Repetitive peak off-state - 6001 V voltages IT(RMS) RMS on-state current full sine wave; Tmb  107 °C - 4 A ITSM Non-repetitive peak full sine wave; Tj = 25 °C prior to on-state current surge t = 20 ms - 25 A t = 16.7 ms - 27 A I2t I2t for fusing t = 10 ms - 3.1 A2s dIT/dt Repetitive rate of rise of ITM = 6 A; IG = 0.2 A; on-state current after dIG/dt = 0.2 A/ s triggering T2+ G+ - 50 A/ s T2+ G- - 50 A/ s T2- G- - 50 A/ s T2- G+ - 10 A/ s IGM Peak gate current - 2 A VGM Peak gate voltage - 5 V PGM Peak gate power - 5 W PG(AV) Average gate power over any 20 ms period - 0.5 W Tstg Storage temperature -40 150 °C Tj Operating junction - 125 °C temperature T2 T1 123G tab
