Affixus Hip Fracture Nail Surgical Technique 2c1z22

Surgical Technique

One Surgeon. One Patient.

Over 1 million times per year, Biomet helps one surgeon provide personalized care to one patient. The science and art of medical care is to provide the right solution for each individual patient. This requires clinical mastery, a human connection between the surgeon and the patient, and the right tools for each situation. At Biomet, we strive to view our work through the eyes of one surgeon and one patient. We treat every solution we provide as if it’s meant for a family member. Our approach to innovation creates real solutions that assist each surgeon in the delivery of durable personalized care to each patient, whether that solution requires a minimally invasive surgical technique, advanced biomaterials or a patient-matched implant. When one surgeon connects with one patient to provide personalized care, the promise of medicine is fulfilled.

AFFIXUS Hip Fracture Nail Contents

Features and Benefits..........................................................................................................................................................................................................3 Indications and Pre-op Planning.....................................................................................................................................................................................7 Patient Positioning and Reduction.................................................................................................................................................................................8 Entry and Canal Preparation.............................................................................................................................................................................................9 Nail Insertion........................................................................................................................................................................................................................ 12 Proximal Locking................................................................................................................................................................................................................ 15 Distal Locking...................................................................................................................................................................................................................... 23 End Cap Placement........................................................................................................................................................................................................... 25 Implant Removal................................................................................................................................................................................................................ 26 Implant Diagrams.............................................................................................................................................................................................................. 27 Product Ordering Information...................................................................................................................................................................................... 28

US Surgeon Design Team George J. Haidukewych, MD Orlando, FL Daniel S. Horwitz, MD Salt Lake City, UT Frank A. Liporace, MD Newark, NJ S. Andrew Sems, MD Rochester, MN

International Surgeon Designer Peter Giannoudis, MD Leeds, UK

1

2

AFFIXUS Hip Fracture Nail

Strength and Stability in the Proximal Femur • Optimal lag screw design for resistance to cut-out • Easy-to-use instrumentation and targeting jig, which includes Goal Post technology, aids in lag screw placement • Extensive range of neck/shaft angles, distal diameters, and nail lengths – combined with a small proximal nail diameter – allows the surgeon to achieve a close match for each patient’s anatomy • Unique distal bend facilitates entry through the proximal 1/3 of the femur and reduces potential for anterior cortex penetration

3

AFFIXUS Hip Fracture Nail A system of choices for effective treatment of proximal femoral fractures

• Short (180 mm) and long (260 - 460 mm) nail options treat a wide range of proximal fracture indications using a single set of -friendly instruments • 15.6 mm proximal nail diameter • Proximal 4˚ lateral bend allows for greater trochanteric entry site • 125˚ and 130˚ neck angles provide a range of anatomical options

• 3° distal bend facilitates ease of insertion through the proximal intertrochanteric/subtrochanteric region • Pre-loaded set screw for ease of use • 5.0 mm anti-rotation (AR) screw for rotational control (optional) • Shouldered lag screw and AR screw help prevent medial screw disengagement

• 10˚ of proximal anteversion built into the nails

• Long nail maintains a 1.8 M radius of curvature to closely match the femoral anatomy

• 10.5 mm diameter cannulated lag screw for bone preservation

• 5.0 mm diameter distal interlocking screws have a large core diameter for strong fixation

• Unique thread spacing and design of the lag screw helps to resist displacement and cut-out

• Static or dynamic distal locking options with a 6 mm dynamization range

• Chamfer on the front distal tip helps facilitate insertion and minimizes risk of stress on the anterior cortex in the distal femur

4

Multiple locking options for optimal implant stability

The AFFIXUS Hip Fracture Nail System, comprised of short and long nails, provides surgeons with an intramedullary hip screw to stabilize fractures of the proximal femur. The AFFIXUS Hip Fracture Nail combines the principles of a compression hip screw with the biomechanical advantages of an intramedullary nail.

5

AFFIXUS Hip Fracture Nail

Figure 1

6

6

AFFIXUS Hip Fracture Nail

Figure 1

AFFIXUS Hip Fracture Nail Short – (180 mm)

AFFIXUS Hip Fracture Nail Long – (260 - 460 mm)

Indications and Pre-op Planning The AFFIXUS Hip Fracture Nail System* is designed for antegrade trochanteric insertion to treat the following fractures (Figure 1): The AFFIXUS Hip Fracture Nail System is intended to treat stable and unstable proximal fractures of the femur including pertrochanteric fractures, intertrochanteric fractures, high subtrochanteric fractures and combinations of these fractures, including non-union, malunion and tumor resections. The Long Nail system is additionally indicated to treat pertrochanteric fractures associated with shaft fractures, pathologic fractures in osteoporotic bone (including prophylactic use) of the trochanteric and diaphyseal areas, impending pathological fractures, long subtrochanteric fractures, ipsilateral femoral fractures, proximal or distal non-unions, malunions, revision procedures and tumor resections.

Note: Bone screws referenced in this material are not intended for screw attachment or fixation to the posterior elements (pedicles) of the cervical thoracic or lumbar spine. * System includes short (180 mm) and long (260-460 mm) nails, in 20 mm increments.

7

AFFIXUS Hip Fracture Nail

Figure 2

Patient Positioning and Reduction Place the patient in the supine or lateral position on a fracture table or radiolucent imaging table. Lateral access to the proximal femur is required. Intraoperative image intensification with a C-arm is required to obtain AP and lateral imaging of the operative area during preoperative preparation (reduction) and throughout the procedure for nail insertion, nail locking, and anteversion alignment. Avoid excessive abduction of the hip during reduction as the access to the starting point and nail insertion may be impeded. The trunk may be laterally flexed away from the operative side to improve access to the starting point. The contralateral leg may be flexed at the hip or scissored below the affected leg in the supine position (Figure 2).

Closed Fracture Reduction Fluoroscopy must be used to proper fracture reduction. 8

• Acceptable fracture alignment must be obtained prior to implant insertion • Surgeon must avoid varus malreductions • Use a combination of traction, rotation, adduction, and flexion/extension of the leg to obtain an acceptable reduction • Open reductions may be required for more complicated fracture patterns and should be used when an acceptable closed reduction cannot be obtained (see page 10)

Initial Incision Make an incision proximal to the tip of the greater trochanter in line with the femoral axis. Divide the fascia lata in line with its fibers and access the tip of the greater trochanter.

Trochanteric entry point

Figure 3 Entry reamer shape matches proximal nail shape

Awl

Figure 4 Figure 5

Figure 6

Entry and Canal Preparation Femoral Entry Preparation Attach the standard 3.2 mm guide pin to the pistol guidewire gripper or power source and it through the tip of the greater trochanter into the center of the femoral canal. Position the entry on the tip of the greater trochanter (Figure 3). Confirm on AP and lateral fluoroscopy views that the entry pin is centered on the trochanter.

Option 1: Cannulated Entry Reamer (One-step 16.6 mm) Attach the cannulated entry reamer to the power source and it over the guide pin through the entry portal (Figure 4). It is essential to ream until the reamer’s proximal shaft es with the greater trochanter’s cortical bone as the shape of the entry reamer matches the nail shape and the top of the cylindrical segment of the reamer corresponds to the top of the nail (Figure 4). Reaming should continue until the tip of the entry reamer is at the level of the lesser trochanter and not beyond.

Option 2: Cannulated Awl the cannulated awl over the guide pin and introduce with a rotation motion until the awl is buried to at least half its blade length (Figure 5 & 6). 9

AFFIXUS Hip Fracture Nail

Figure 7

Figure 8

Open Fracture Reduction Once access to the femoral canal has been gained, place the ball nose guide wire into the entry site utilizing the pistol guide wire gripper (Figure 7). Obtain appropriate anatomic reduction in order to restore length, anatomic axis alignment, and rotation of the injured limb. Reduction can be achieved through the surgeon’s preferred method such as traction, external fixator, external aids, or joysticks. To aid in manipulating the fracture fragments and ing the ball nose guide wire, long (7.5 mm diameter) and short (6.5 mm diameter) reduction tools are available.

10

Insert the reduction tool into the medullary canal, past the fracture site. Once the fracture is in alignment, the ball nose guide wire, available in both 80 cm and 100 cm lengths, across the fracture site. Remove the reduction tool (Figure 8).

Figure 9

Figure 10

Canal Preparation Short Nail

Nail Length Selection

Confirm that the femoral diaphysis is wide enough and long enough to allow the selected nail diameter to . Ream as necessary to enlarge the diaphysis to accept the selected nail.

With the tip of the ball nose guide wire at the level of the desired depth of nail insertion, slide or snap the nail depth gauge onto the ball nose guide wire until it s the bone, ensuring that the tip does not fall into the existing trochanteric entry canal, thus providing an inaccurate measurement. To obtain the appropriate nail length, read the measurement mark on the nail depth gauge that is closest to the beginning of the black transition area on the guide wire (Figure 10). If a nail of the exact measured length is not available, choose a shorter nail of the next closest available length. A direct measurement can also be taken of the uninjured extremity using either radiographs with magnification markers, or directly on the uninjured limb.

Long Nail Achieve proper alignment of the injured limb prior to reaming. Maintain alignment throughout the reaming process to avoid eccentric reaming. Commence reaming by placing the flexible reamer over the ball nose guide wire (Figure 9). Ream the medullary canal in millimeter increments until cortical bone is reached and in half-millimeter increments thereafter. Surgeon preference should dictate the actual extent of intramedullary reaming. Monitor the reaming procedure using image intensification to avoid eccentric or excessive cortical reaming. Note: It is recommended to over-ream the diaphysis by 2 mm.

11

AFFIXUS Hip Fracture Nail

Al ig nm

en to f rg et pro xim in g

ta

al

Figure 11

Figure 12

Nail Insertion Jig Assembly Select the appropriate targeting jig that corresponds to the neck shaft angle of the implant selected. Insert the jig bolt through the targeting jig using the jig bolt driver (Figure 11).

12

Note: 130º neck angle is most commonly used (Figure 12).

Jig Tab Nail Slot

Alignment of distal targeting

Figure 13A

When assembling the nail to the insertion jig, ensure that the jig tabs align with the slots on the nail so that the nail fully seats in the targeting jig (Figure 13A). Once the nail is fully seated, securely tighten the jig bolt using the jig bolt driver

Note: If it is difficult to attach the nail to the jig, doublecheck that the nail and jig are identified with the same angle. The nail will only align with the jig if they have the same neck-shaft angle.

Figure 13B

Check the assembly prior to nail introduction. the lag screw sheath through the targeting jig. A properly assebled nail and jig will allow the lag screw drill to be directed through the sleeve and through the center of the lag screw hole in the nail. When using a short (180 mm) nail, confirm the targeting alignment of the distal interlocking screws using the green sheaths and drill bits in the same manner (Figure 13B).

13

AFFIXUS Hip Fracture Nail

Figure 14

Figure 15

Insert the nail by hand over the 3 mm ball nose guide wire into the medullary canal. Take care not to strike the jig or targeting arm with the mallet. A curved impaction tool is included in the set and is meant to be used for gentle taps of the mallet to fine tune the final seating of the nail.

As the nail es the medial cortex of the proximal fragment, slowly derotate the jig handle into the usual lateral position, so that the anterior bow of the nail now corresponds with the anterior bow of the femur (Figure 14). If the nail requires substantial force to advance, remove it and ream an additional millimeter. Avoid excessive force when inserting the nail. Advance the nail until the lag screw aligns to the desired position into the femoral head and neck to allow ideal placement of the lag screw (Figure 15).

Nail Insertion

Note: The insertion jig should not be hammered on.

It may be helpful to preliminarily insert the trochanteric nail utilizing its bow to facilitate clearance of the medial femoral cortex of the proximal fragment. To do this, rotate the insertion jig anteriorly (toward the ceiling). In this position the distal bend in the nail will be angled laterally to aid in ing the nail through the greater trochanteric entry site, and avoid medial cortical penetration.

14

Maintenance of reduction must be confirmed prior to lag screw insertion. If the reduction has shifted to a suboptimal position, further hip adduction, traction, and rotational adjustments can be made prior to lag screw placement. Remove the ball nose guide wire.

Lag Screw Sheath Lag Screw 3.2 mm sleeve

Lag Screw Trochar

Figure 16A

Figure 16B

Proximal Locking Lag Screw Guide Pin Introduction Note: At the distal end of the jig assembly, the jig knob can be tightened to secure the position of the lag screw sheath to maintain against the lateral femoral cortex.

Insert the lag screw sheath assembly (lag screw sheath, lag screw trochar, lag screw 3.2 mm sleeve) through the lag screw hole in the jig. the trochar through the sheath and make an appropriate skin incision where the trochar s the skin. Advance the trochar through the tissue until the tip is seated against the lateral femoral cortex and confirm with fluoroscopy. The trochar may be impacted into the lateral cortex with a mallet to create a starting point for the guide pin and minimize migration during insertion (Figure 16A).

Introduce the 3.2 mm guide pin into the 3.2 mm sleeve and drill into position under fluoroscopic guidance. Check the guide pin position within the center of the femoral head and neck in both AP and lateral planes. Advance the guide pin to a distance within 5 mm from the subchondral bone (Figure 16B).

Remove the trochar and maintain the lag screw sheath position against the lateral femoral cortex.

Note: If at any time a guide pin is bent, replace it immediately.

15

AFFIXUS Hip Fracture Nail

Figure 18A

Figure 18B

Figure 17 Fluoroscopic true lateral of the proximal femur with insertion jig

Goal Post Technology

Lag Screw Length Selection

The Goal Post Technology is designed to facilitate visualization of the femoral neck on the lateral view in order to more accurately place the guide pin for the lag screw. The anterior and posterior metal posts on the proximal aspect of the insertion jig allow for an unobstructed fluoroscopic view down to the base of the femoral neck (Figure 17) and assist with fine tuning of the guide pin before it is fully seated in the femoral head.

Before selecting a lag screw length, that the lag screw sheath and 3.2 mm sleeve are in place and fully seated against the lateral femoral cortex. • The depth gauge seats against the lag screw sheath, not the 3.2 mm sleeve • The system measures to the tip of the guide pin • The measurement represents the length of a lag screw that begins at the end of the lag screw sheath and terminates at the tip of the guide pin (Figure 18A and 18B)

16

Notch

Measurements taken here, i.e., 100 mm Lag Screw Drill

Depth Stop

Figure 19A Push button control

Figure 19B

Depth Stop Adjustment

Lag Screw Drilling and Tapping

Adjust the depth stop on the lag screw drill to the desired depth. The measurement on the depth stop should be set to the depth measured by the lag screw depth gauge (Figure 19A).

Advance the lag screw drill over the guide pin and drill to the desired depth. Use fluoroscopy to confirm the position of the lag screw drill and that the guide pin is not advanced into the hip t or acetabulum by the drill.

Adjust the depth stop by pushing in the button and sliding the stop forward or backward until desired depth is seen on the end of the depth stop closest to the gold drill bit tip (Figure 19B).

If the bone is particularly dense, use the cannulated tap to cut a thread for the lag screw.

Note: There is a “notch” on the lag screw drill that is visible under fluoroscopy; this “notch” references 100 mm (Figure 19A).

Note: There is a guide pin repositioning tool to aid inreinserting the guide pin if it backs out with removal of the lag screw drill.

17

AFFIXUS Hip Fracture Nail

Figure 20

Figure 21

Lag Screw Insertion

Fracture Compression

Insert the lag screw coupling rod through the lag screw driver and position the selected lag screw on the end of the lag screw driver. Tighten the coupling rod to secure the lag screw to the driver.

Compression of the intertrochanteric component of the fracture, if desired, can be achieved by utilizing the compression wheel. Once the lag screw has been fully seated, release traction from the leg and firmly seat the lag screw sheath against the lateral cortex. Confirm that the sheath is tightly secured in the jig by tightening the jig knob, and place the compression wheel on the lag screw driver and advance against the lateral side of the sheath. In osteoporotic bone, care should be taken to avoid pulling the lag screw out of the femoral head with this technique (Figure 21).

Advance the lag screw manually into the femoral neck and head over the guide pin. Confirm the terminal position of the lag screw with fluoroscopy, with a goal of seating the screw between 5 and 10 mm from the subchondral bone. The handle of the lag screw driver must be positioned either parallel or perpendicular to the targeting jig when the lag screw has been advanced to the desired depth (Figure 20). This will ensure that the set screw will engage one of the grooves of the lag screw.

18

Note: Hash marks on lag screw driver represent 5 mm intervals. It is recommended that no more than 4-6 mm of compression is applied and should be applied prior to placing the Anti-Rotation (AR) screw.

Figure 22A

Figure 22B Cross section of set screw engaging lag screw

Lag Screw Fixation The set screw is pre-loaded in the nail. Using the 5 mm set screw hex driver, engage the set screw and advance in a clockwise direction 2 to 3 full rotations until the set screw s the lag screw in one of the four lag screw grooves (Figure 22A & 22B). To confirm proper position of the set screw, gently attempt to rotate the lag screw both clockwise and counterclockwise. If there is firm resistance and the lag screw will not rotate, the set screw has properly engaged the lag screw grooves. However, if you are able to rotate the lag screw, the set screw has not engaged a groove and the lag screw handle should be realigned and the set screw tightened again.

The set screw may be backed off one-quarter turn to allow dynamic compression of the lag screw in the nail, while still providing rotational control of the lag screw. Note: The set screw can be engaged before or after inserting the AR screw (if the AR screw is to be used). The AR screw will align through an oblong hole within the set screw.

19

AFFIXUS Hip Fracture Nail

Figure 23

Anti-rotation (AR) Guide Pin and Screw Placement (optional) This system allows multiple techniques for placement of an anti-rotation (AR) screw if desired. • The AR screw may be inserted either before or after the lag screw is placed, based upon surgeon preference and the fracture pattern. • The surgeon has the option to place a guide pin through the AR hole to provisionally stabilize the fracture during lag screw placement, or he/she may choose to use an AR screw. The guide pin used through the AR hole is also useful to assist in stabilizing the femoral neck and head segment during lag screw placement to resist rotation around the axis of the femoral neck. Once the lag screw has been placed and secured, the surgeon may choose to remove the guide pin from the AR hole and place a screw in this position to provide further rotational control.

20

Place the AR screw sheath and trochar through the AR hole in the insertion jig. Make a small incision where the trochar meets the skin and advance the trochar to the lateral aspect of the femoral cortex. Alternatively, in cases where the lag screw has already been inserted, extend the incision for the lag screw proximally to allow the AR screw sheath and trochar to be seated against the femur (Figure 23). Note: When the anti-rotation and lag screw sheaths are seated at the same time, they must be rotated so the groove on the lag screw sheath faces the anti-rotation screw sheath (so the colored handles are 180 degree to each other) in order to allow both sheaths to fully seat (Figure 23).

5 – 10 mm

15 – 20 mm

Figure 24

Figure 25

Remove the trochar and insert the AR 3.2 mm sleeve. Insert the 3.2 mm guide pin and advance into desired position. It is recommended to leave the AR guide pin 15-20 mm from the subchondral bone (Figure 24). Note: In cases where very dense cortical bone is encountered, the cortex may be opened up with the antirotation screw drill prior to advancing the 3.2 mm guide pin to prevent the guide pin from “walking” up the lateral cortex.

Remove the guide pin and 3.2 mm sleeve. Confirm that the screw sheath is advanced against the lateral femoral cortex and use the AR drill to drill to the desired depth. Measure the length of the desired screw by reading the depth of the AR drill against the screw sheath. Note: It is recommended that the tip of the AR screw be 15-20 mm shorter than the lag screw to avoid perforation of the femoral head (Figure 25).

21

AFFIXUS Hip Fracture Nail

Figure 26

Select an AR screw of the desired length. Place the AR screw on the 3.5 mm hex driver and manually insert the screw into the femur through the AR screw sheath. Advance until the tip of the screw reaches the desired depth and confirm with fluoroscopy. The screwdriver and sheath may now be removed.

Securing the AR Screw (optional) The AR screw may be secured with an impinging end cap that is inserted through the end of the nail. Note: The impinging end cap will make the AR screw a static construct and is recommended to only be used when the lag screw is also fixed in a static position (this can be achieved by not backing off the pre-loaded set

22

screw a quarter turn). Otherwise there is risk of creating the Z-effect. It is recommended to only lock the AR screw in instances in which the set screw has been left fully engaged into the lag screw, thus preventing any collapse of the 10.5 mm compression screw (Figure 26). The impinging end cap may be utilized at the end of the case, after the set screw for the lag screw has been tightened, and the insertion jig has been removed.

Figure 27

Figure 28

Distal Locking Distal Locking (short nails) The short nail may be locked either statically, dynamically, or left unlocked based on the particular fracture pattern and stability (Figure 27). the distal screw sheath and trochar through the hole labeled “static” on the insertion jig and advance to the lateral femoral cortex. Remove the trochar and use the distal screw drill sleeve and 4.3 mm graduated drill bit. Drill until the far cortex is either reached or penetrated. The drill is calibrated and may be used to determine screw length by reading the depth off the end of the distal screw drill sleeve (Figure 28). An optional distal screw depth gauge is available to confirm screw length. This gauge measures off of the lateral side of the 4.3 mm distal screw drill sleeve.

Select a 5.0 mm diameter screw of the desired depth and use the 3.5 mm hex driver long to introduce the screw through the screw sheath and advance until it is fully seated against the lateral cortex. Repeat the above steps for dynamic locking, except the distal screw sheath and trochar through the hole labeled “dynamic” on the insertion jig. Note: Maintain of the drill sheath on the lateral femoral cortex to ensure accurate measurement of the distal locking screw. screw position using AP and lateral fluoroscopy imaging. Note: There are two 4.3 mm drill bits available. Use the long bit when drilling through the jig assembly and use the short bit when performing the freehand approach. 23

AFFIXUS Hip Fracture Nail

Figure 30

Figure 29

Distal Locking (long nails)

Option 2

Prior to locking the distal screw(s), check femoral length and rotation under fluoroscopy. Distal locking of long nails should be conducted using the standard image intensification freehand technique.

Using the short 4.3 mm graduated drill, drill until the far cortex is either reached or penetrated. Remove the 4.3 mm graduated drill and measure using the distal screw depth gauge. Ensure that the sheath of the distal screw depth gauge is fully seated on the bone (Figure 30).

Option 1 Using the short 4.3 mm graduated drill and the 4.3 mm drill measuring sleeve, drill until the far cortex is either reached or penetrated. the drill bit position fluoroscopically prior to taking any measurements. Read the calibration directly off of the 4.3 mm graduated drill by using the drill measuring sleeve. The measurement should be taken from the end of the measuring sleeve, closest to the power source (Figure 29).

24

Remove the drill bit and advance the 5.0 mm screw using the solidlok screwdriver or 3.5 mm hex driver. Repeat the above steps for additional screw placement.

Figure 31

End Cap Placement End Cap Placement (optional) Unscrew the jig bolt that connects the insertion jig to the end of the nail using the jig bolt driver. Remove the insertion jig and use fluoroscopy to determine the length of the end cap desired, with a goal of leaving the proximal aspect of the end cap flush with the tip of the greater trochanter.

Attach the end cap to the 5 mm end cap hex driver and insert into the end of the nail. Tighten the end cap by turning clockwise until the end cap fully seats against the top of the nail. If fixation of the AR screw is desired, select the impinging in cap instead of the standard end cap (Figure 31).

25

AFFIXUS Hip Fracture Nail Slotted Hammer

Figure 32

Sliding Hammer

Figure 33

Implant Removal Identify the proximal end of the nail by opening the same incision used for insertion of the implant. Clear bone from the proximal end of nail if necessary or remove the end cap (if present) with the 5 mm end cap hex driver. • Remove the distal screw using the 3.5 mm hex driver after making an incision through the scar site. • If an AR screw is present, use the AR screw removal tool to extract the AR screw prior to loosening the set screw. Reminder: The set screw should NOT be loosened prior to removing the AR screw. • Use the 5 mm set screw hex driver to loosen the set screw. This will allow the lag screw to rotate counterclockwise. Typically 2 to 3 full rotations is all that is necessary. • Attach the lag screw driver and coupling rod to the lateral end of the lag screw and confirm that it will freely rotate in a counterclockwise direction.

• Insert the cannulated extraction bolt into the proximal end of the nail (Figure 32). Note: If the extraction bolt is not threading into the proximal end of the nails, the set screw may have been backed out too far and should be advanced clockwise. • Attach the extraction rod to the extraction bolt. • Remove the lag screw by turning counterclockwise and then remove the distal interlocking screws. • Use the sliding hammer or slotted mallet over the extraction rod and back slap to remove the nail (Figure 33). Note: It is recommended that the extraction rod and bolt be attached to the nail prior to removing the final screw to prevent the nail from being forced down the intramedullary canal. Note: The conical extractor is designed to cross thread onto the nail, and it is recommended that it is tightly secured to the nail before the lag screw is removed to prevent the nail from rotating in the femoral canal.

26

15.6 mm Proximal Diameter

4˚

Implant Diagrams

125˚ & 130˚

12.76 mm

10° Proximal Anteversion

Distal Screw, 20-80 mm Sterile: 8145-50-0XX • Diameter 5.0 mm • 3.5 mm Hex Driver Socket 1.8 M Radius of Curvature

Anti-rotation Screw, 50-110 mm Sterile: 8145-01-XXX • Diameter 5.0 mm • 3.6 mm Hex Driver Socket • 3 mm Inner Thread for Removal • Self Tapping Threads

Lag Screw, 70-130 mm Sterile: 8145-10-XXX • Diameter 10.5 mm • Reverse Buttress Thread • 6.5 mm Square Driver Socket • Self Tapping Threads

25 mm

6 mm Dynamization Range

30 mm Diameter 9.0 mm Diameter 11.0 mm Diameter 13.0 mm Diameter 15.0 mm

3˚

27

AFFIXUS Hip Fracture Nail Product Ordering Information Rights

Lefts

Rights

Long Nails, 9 mm, 125°

Lefts

Long Nails, 9 mm, 130°

8143-09-260

8144-09-260

125° 9 mm X 260 mm

8145-09-260

8146-09-260

130° 9 mm X 260 mm

8143-09-280

8144-09-280

125° 9 mm X 280 mm

8145-09-280

8146-09-280

130° 9 mm X 280 mm

8143-09-300

8144-09-300

125° 9 mm X 300 mm

8145-09-300

8146-09-300

130° 9 mm X 300 mm

8143-09-320

8144-09-320

125° 9 mm X 320 mm

8145-09-320

8146-09-320

130° 9 mm X 320 mm

8143-09-340

8144-09-340

125° 9 mm X 340 mm

8145-09-340

8146-09-340

130° 9 mm X 340 mm

8143-09-360

8144-09-360

125° 9 mm X 360 mm

8145-09-360

8146-09-360

130° 9 mm X 360 mm

8143-09-380

8144-09-380

125° 9 mm X 380 mm

8145-09-380

8146-09-380

130° 9 mm X 380 mm

8143-09-400

8144-09-400

125° 9 mm X 400 mm

8145-09-400

8146-09-400

130° 9 mm X 400 mm

8143-09-420

8144-09-420

125° 9 mm X 420 mm

8145-09-420

8146-09-420

130° 9 mm X 420 mm

8143-09-440

8144-09-440

125° 9 mm X 440 mm

8145-09-440

8146-09-440

130° 9 mm X 440 mm

8143-09-460

8144-09-460

125° 9 mm X 460 mm

8145-09-460

8146-09-460

130° 9 mm X 460 mm

Long Nails, 11 mm, 125°

Long Nails, 11 mm, 130°

8143-11-260

8144-11-260

125° 11 mm X 260 mm

8145-11-260

8146-11-260

130° 11 mm X 260 mm

8143-11-280

8144-11-280

125° 11 mm X 280 mm

8145-11-280

8146-11-280

130° 11 mm X 280 mm

8143-11-300

8144-11-300

125° 11 mm X 300 mm

8145-11-300

8146-11-300

130° 11 mm X 300 mm

8143-11-320

8144-11-320

125° 11 mm X 320 mm

8145-11-320

8146-11-320

130° 11 mm X 320 mm

8143-11-340

8144-11-340

125° 11 mm X 340 mm

8145-11-340

8146-11-340

130° 11 mm X 340 mm

8143-11-360

8144-11-360

125° 11 mm X 360 mm

8145-11-360

8146-11-360

130° 11 mm X 360 mm

8143-11-380

8144-11-380

125° 11 mm X 380 mm

8145-11-380

8146-11-380

130° 11 mm X 380 mm

8143-11-400

8144-11-400

125° 11 mm X 400 mm

8145-11-400

8146-11-400

130° 11 mm X 400 mm

8143-11-420

8144-11-420

125° 11 mm X 420 mm

8145-11-420

8146-11-420

130° 11 mm X 420 mm

8143-11-440

8144-11-440

125° 11 mm X 440 mm

8145-11-440

8146-11-440

130° 11 mm X 440 mm

8143-11-460

8144-11-460

125° 11 mm X 460 mm

8145-11-460

8146-11-460

130° 11 mm X 460 mm

Long Nails, 13 mm, 125°

Long Nails, 13 mm, 130°

8143-13-260

8144-13-260

125° 13 mm X 260 mm

8145-13-260

8146-13-260

130° 13 mm X 260 mm

8143-13-280

8144-13-280

125° 13 mm X 280 mm

8145-13-280

8146-13-280

130° 13 mm X 280 mm

8143-13-300

8144-13-300

125° 13 mm X 300 mm

8145-13-300

8146-13-300

130° 13 mm X 300 mm

8143-13-320

8144-13-320

125° 13 mm X 320 mm

8145-13-320

8146-13-320

130° 13 mm X 320 mm

8143-13-340

8144-13-340

125° 13 mm X 340 mm

8145-13-340

8146-13-340

130° 13 mm X 340 mm

8143-13-360

8144-13-360

125° 13 mm X 360 mm

8145-13-360

8146-13-360

130° 13 mm X 360 mm

8143-13-380

8144-13-380

125° 13 mm X 380 mm

8145-13-380

8146-13-380

130° 13 mm X 380 mm

8143-13-400

8144-13-400

125° 13 mm X 400 mm

8145-13-400

8146-13-400

130° 13 mm X 400 mm

8143-13-420

8144-13-420

125° 13 mm X 420 mm

8145-13-420

8146-13-420

130° 13 mm X 420 mm

8143-13-440

8144-13-440

125° 13 mm X 440 mm

8145-13-440

8146-13-440

130° 13 mm X 440 mm

8143-13-460

8144-13-460

125° 13 mm X 460 mm

8145-13-460

8146-13-460

130° 13 mm X 460 mm

Long Nails, 15 mm, 130°

28

8145-15-320

8146-15-320

130° 15 mm X 320 mm

8145-15-360

8146-15-360

130° 15 mm X 360 mm

8145-15-400

8146-15-400

130° 15 mm X 400 mm

8145-15-440

8146-15-440

130° 15 mm X 440 mm

Short Nails, 125°

Distal Screws

8143-09-180

125° 9 mm X 180 mm

8145-50-020

CORTICAL BONE SCR 5.0 mm X 20 mm

8143-11-180

125° 11 mm X 180 mm

8145-50-022

CORTICAL BONE SCR 5.0 mm X 22 mm

8143-13-180

125° 13 mm X 180 mm

8145-50-024

CORTICAL BONE SCR 5.0 mm X 24 mm

8145-50-026

CORTICAL BONE SCR 5.0 mm X 26 mm

Short Nails, 130°

8145-50-028

CORTICAL BONE SCR 5.0 mm X 28 mm

8145-09-180

130° 9 mm X 180 mm

8145-50-030

CORTICAL BONE SCR 5.0 mm X 30 mm

8145-11-180

130° 11 mm X 180 mm

8145-50-032

CORTICAL BONE SCR 5.0 mm X 32 mm

8145-13-180

130° 13 mm X 180 mm

8145-50-034

CORTICAL BONE SCR 5.0 mm X 34 mm

8145-50-036

CORTICAL BONE SCR 5.0 mm X 36 mm

8145-50-038

CORTICAL BONE SCR 5.0 mm X 38 mm

Lag Screws 8145-10-070

LAG SCREW 10.5 mm X 70 mm

8145-50-040

CORTICAL BONE SCR 5.0 mm X 40 mm

8145-10-075

LAG SCREW 10.5 mm X 75 mm

8145-50-042

CORTICAL BONE SCR 5.0 mm X 42 mm

8145-10-080

LAG SCREW 10.5 mm X 80 mm

8145-50-044

CORTICAL BONE SCR 5.0 mm X 44 mm

8145-10-085

LAG SCREW 10.5 mm X 85 mm

8145-50-046

CORTICAL BONE SCR 5.0 mm X 46 mm

8145-10-090

LAG SCREW 10.5 mm X 90 mm

8145-50-048

CORTICAL BONE SCR 5.0 mm X 48 mm

8145-10-095

LAG SCREW 10.5 mm X 95 mm

8145-50-050

CORTICAL BONE SCR 5.0 mm X 50 mm

8145-10-100

LAG SCREW 10.5 mm X 100 mm

8145-50-052

CORTICAL BONE SCR 5.0 mm X 52 mm

8145-10-105

LAG SCREW 10.5 mm X 105 mm

8145-50-054

CORTICAL BONE SCR 5.0 mm X 54 mm

8145-10-110

LAG SCREW 10.5 mm X 110 mm

8145-50-056

CORTICAL BONE SCR 5.0 mm X 56 mm

8145-10-115

LAG SCREW 10.5 mm X 115 mm

8145-50-058

CORTICAL BONE SCR 5.0 mm X 58 mm

8145-10-120

LAG SCREW 10.5 mm X 120 mm

8145-50-060

CORTICAL BONE SCR 5.0 mm X 60 mm

8145-10-125

LAG SCREW 10.5 mm X 125 mm

8145-50-065

CORTICAL BONE SCR 5.0 mm X 65 mm

8145-10-130

LAG SCREW 10.5 mm X 130 mm

8145-50-070

CORTICAL BONE SCR 5.0 mm X 70 mm

8145-50-075

CORTICAL BONE SCR 5.0 mm X 75 mm

8145-50-080

CORTICAL BONE SCR 5.0 mm X 80 mm

Anti-Rotation Screws 8145-01-050

A/R SCREW 50 mm

8145-01-055

A/R SCREW 55 mm

End Caps

8145-01-060

A/R SCREW 60 mm

8145-03-000

END CAP FLUSH

8145-01-065

A/R SCREW 65 mm

8145-03-005

END CAP 5 mm

8145-01-070

A/R SCREW 70 mm

8145-03-101

IN CAP FLUSH IMPINGING

8145-01-075

A/R SCREW 75 mm

8145-01-080

A/R SCREW 80 mm

8145-01-085

A/R SCREW 85 mm

8145-01-090

A/R SCREW 90 mm

8145-01-095

A/R SCREW 95 mm

8145-01-100

A/R SCREW 100 mm

8145-01-105

A/R SCREW 105 mm

8145-01-110

A/R SCREW 110 mm

29

AFFIXUS Hip Fracture Nail Product Ordering Information

1

2

3

4

8

AFFIXUS Hip Fracture Nail System 2112-01-000 Instrument Case 2 2112-01-001 Instrument Case 1 2112-01-800 Full Anatomy (FA) Instrument Case General 2810-01-004 8261-66-000

T-Handle Hudson Ratchet Screwdriver Handle Small

Entry 2112-01-100 2112-01-102 2112-01-103 2112-01-104 2810-13-004

1 - AWL 2 - Entry Reamer Solid Shaft 3 - Entry Reamer Flexible Shaft 4 - Entry Portal 5 - Entry Portal Trochar

* Products are disposable.

30

5

9

10

6

7

11

Reduction 9030-03-004 2810-01-080 2810-01-100 2810-01-001 2810-01-026 2810-01-007 2142-02-012 2112-01-003 2141-19-000 2810-01-175

Threaded Guide Pin 3.2 mm* Ball Nose Guidewire 80 cm* Ball Nose Guidewire 100 cm* 6 - Pistol Guidewire Gripper 7 - Guidewire Pusher 8 - Long Reduction Tool 9 - Ball Spike Pusher 10 - Bone Hook 11 - Femoral Bone Clamp 3.2 mm x 444 mm Threaded Guide Pin Sterile*

15

16

12

13

18

19

Nail Insertion 2112-01-106 2112-01-200 2112-01-207 2112-01-201 2112-01-208 2112-01-202 2112-01-209 2112-01-205 2112-01-206 2810-13-037 2810-13-006 2112-01-204

20

21

12 - Nail Depth Gauge 13 - Insertion jig 125° FA Insertion jig 125° 14 - Insertion jig 130° FA Insertion jig 130° 15 - Insertion jig bolt FA Insertion jig bolt Jig knob Jig knob retainer 16 - Flexible jig bolt driver 8 mm Jig bolt driver 8 mm 17 - Impaction tool

17

14

22

23

24

25

26

27

28

Lag Screw Placement 2112-01-300 18 - Lag Screw Sheath 2112-01-301 19 - Lag Screw Trochar 2112-01-302 20 - Lag Screw 3.2 mm Sleeve 2112-01-304 21 - Lag Screw Depth Gauge 2112-01-303 22 - Lag Screw Drill 2112-01-310 23 - Lag Screw Tap 2112-01-307 24 - Lag Screw Driver 2112-01-306 25 - Lag Screw Coupling Rod 2112-01-308 26 - Compression Wheel 2112-01-309 27 - 5 mm Hex Driver - Set Screw 2112-01-320 FA 5 mm Hex Driver - Set Screw 2112-01-312 28 - Guide Pin Positioning Tool

31

AFFIXUS Hip Fracture Nail Product Ordering Information

29

30

31

32

37

38

39

40

33

41

34

42

35

43

44

45

36

46

47

AR Screw Placement

Distal Screw Insertion

2112-01-501

29 - A/R Screw Sheath

2112-01-401

37 - Distal Screw Sheath

2112-01-502

30 - A/R Screw Trochar

2112-01-402

38 - Distal Screw Trochar

2112-01-503

31 - A/R Screw 3.2 mm sleeve

2112-01-403

39 - Distal Screw Drill Sleeve

2112-01-505

32 - A/R Screw Drill*

2112-01-404

40 - Distal Screw Depth Gauge

2112-01-504

33 - 3.5 mm Hex Driver Long-A/R Distal Screw

2112-01-406

41 - 4.3 mm Distal Graduated Drill Short*

2112-01-506

34 - A/R Screw Removal Tool

2112-01-405

42 - 4.3 mm Distal Graduated Drill Long*

2112-01-410

43 - 4.3 mm Drill Measuring Sleeve*

End Cap Placement

2112-01-409

44 - 3.5 mm Hex Driver Short - Distal Screw

2112-01-600

2810-01-020

45 - SolidLok Screwdriver Handle

2810-01-021

46 - SolidLok Driver Inner Shaft

2112-01-601 2112-01-602

35 - 5 mm Hex Driver End Cap 5 mm Hex Can Driver End Cap 36 - End Cap Removal Tool

2810-01-019 2112-01-504

* Products are disposable.

32

SolidLok Hex Tip 3.5 mm* 33 - 3.5 mm Hex Driver Long - AR/Distal Screw

50 48

49

52

53

51

Extraction 2112-01-666 1095 1796 1096 2112-01-606 2112-01-605 2810-01-027

48 - Cannulated Extraction Bolt 49 - Extraction Rod 50 - Sliding Hammer Small Sliding Hammer Large 51 - Slotted Mallet 52 - Conical Extractor 53 - 3/4 in Hex Driver

Flexible Reamers 2810-02-400 400 mm Nitinol Modular Reamer Hudson 2810-02-470 470 mm Nitinol Modular Reamer Hudson 2810-02-015 150 mm Reamer Extension 2810-02-081 8 mm MNBLC Endcut Reamer Hudson 2810-02-091 9 mm MNBLC Endcut Reamer Hudson 2810-04-090 9.0 mm Modular Reamer Head 2810-04-095 9.5 mm Modular Reamer Head

2810-04-100 2810-04-105 2810-04-110 2810-04-115 2810-04-120 2810-04-125 2810-04-130 2810-04-135 2810-04-140 2810-04-145 2810-04-150 2810-04-155 2810-04-160 2810-04-165 2810-04-170

10.0 mm Modular Reamer Head 10.5 mm Modular Reamer Head 11.0 mm Modular Reamer Head 11.5 mm Modular Reamer Head 12.0 mm Modular Reamer Head 12.5 mm Modular Reamer Head 13.0 mm Modular Reamer Head 13.5 mm Modular Reamer Head 14.0 mm Modular Reamer Head 14.5 mm Modular Reamer Head 15.0 mm Modular Reamer Head 15.5 mm Modular Reamer Head 16.0 mm Modular Reamer Head 16.5 mm Modular Reamer Head 17.0 mm Modular Reamer Head

33

Important:

Additional Contraindication for Orthopaedic Screws and Plates only:

This Essential Product Information does not include all of the information necessary for selection and use of a device. Please see full labeling for all necessary information.

Cases with malignant primary or metastatic tumors which preclude adequate bone or screw fixations, unless supplemental fixation or stabilization methods are utilized.

The use of metallic surgical appliances (screws, plates, intramedullary nails, compression hip screws, pins and wires) provides the orthopaedic surgeon a means of bone fixation and helps generally in the management of fractures and reconstructive surgeries. These implants are intended as a guide to normal healing, and are NOT intended to replace normal body structure or bear the weight of the body in the presence of incomplete bone healing. Delayed unions or nonunions in the presence of load bearing or weight bearing might eventually cause the implant to break due to metal fatigue. All metal surgical implants are subjected to repeated stress in use, which can result in metal fatigue.

Additional Contraindication for Retrograde Femoral Nailing: A history of septic arthritis of the knee and knee extension contracture with inability to attain at least 45º of flexion. Additional Contraindications for Compression Hip Screws only: Inadequate implant due to the lack of medial buttress. Warnings and Precautions:

Indications The AFFIXUS Hip Fracture Nail is intended to treat stable and unstable proximal fractures of the femur including pertrochanteric fractures, intertrochanteric fractures, high subtrochanteric fractures and combinations of these fractures, including nonunion, malunion and tumor resections. The Long Nail system is additionally indicated to treat pertrochanteric fractures associated with shaft fractures, pathologic fractures in osteoporotic bone (including prophylactic use) of the trochanteric and diaphyseal areas, impending pathological fractures, long subtrochanteric fractures, ipsilateral femoral fractures, proximal or distal non-unions, malunions, revision procedures and tumor resections Contraindications: Screws, plates, intramedullary nails, compression hip screws, pins and wires are contraindicated in: active infection, conditions which tend to retard healing such as blood supply limitations, previous infections, insufficient quantity or quality of bone to permit stabilization of the fracture complex, conditions that restrict the patient’s ability or willingness to follow postoperative instructions during the healing process, foreign body sensitivity, and cases where the implant(s) would cross open epiphyseal plates in skeletally immature patients.

Bone screws and pins are intended for partial weight bearing and non-weight bearing applications. These components cannot be expected to withstand the uned stresses of full weight bearing. Adverse Events: The following are the most frequent adverse events after fixation with orthopaedic screws, plates, intramedullary nails, compression hip screws, pins and wires: loosening, bending, cracking or fracture of the components or loss of fixation in bone attributable to nonunion, osteoporosis, markedly unstable comminuted fractures; loss of anatomic position with nonunion or malunion with rotation or angulation; infection and allergies and adverse reactions to the device material. Surgeons should take care when targeting and drilling for the proximal screws in any tibial nail with oblique proximal screws. Care should be taken as the drill bit is advanced to penetrate the far cortex. Advancing the drill bit too far in this area may cause injury to the deep peroneal nerve. Fluoroscopy should be used to correct positioning of the drill bit. Additional Adverse Events for Compression Hip Screw only: Screw cutout of the femoral head (usually associated with osteoporotic bone).

This material is intended for health care professionals and the Biomet sales force only. Distribution to any other recipient is prohibited. All content herein is protected by copyright, trademarks and other intellectual property rights owned by or licensed to Biomet Inc. or its s unless otherwise indicated. This material must not be redistributed, duplicated or disclosed, in whole or in part, without the express written consent of Biomet. Check for country product clearances and reference product specific instructions for use. For complete product information, including indications, contraindications, warnings, precautions, and potential adverse effects, see the package insert and Biomet’s website. This technique was prepared in conjunction with a licensed health care professional. Biomet does not practice medicine and does not recommend any particular orthopedic implant or surgical technique for use on a specific patient. The surgeon is responsible for determining the appropriate device(s) and technique(s) for each individual patient. Not for distribution in .

Legal Manufacturer Biomet Trauma 56 East Bell Drive P.O. Box 587 Warsaw, Indiana 46581 USA ©2014 Biomet Trauma • Form No. BMET0022.0-GBL • REV0614

www.biomet.com

Authorised Representative Biomet UK Ltd. Waterton Industrial Estate Bridgend, South Wales CF31 3XA UK

0086
