TrueAlarm Analog Sensing UL, ULC, CSFM Listed; FM Approved; MEA (NYC) Acceptance*

TrueAlarm Analog Sensors – Photoelectric and Heat; Standard Bases and Accessories

Features TrueAlarm analog sensing provides:  Digital transmission of analog sensor values via IDNet or MAPNET II two-wire communications For use with the following Simplex® products:  4007ES, 4010, 4010ES, 4100ES, and 4100U Series control s; and 4008 Series control s with reduced feature set (refer to data sheet S4008-0001 for details)  4020, 4100, and 4120 Series control s, Universal Transponders, and 2120 TrueAlarm CDTs equipped for MAPNET II operation Fire alarm control provides:  Peak value logging allowing accurate analysis of each sensor for individual sensitivity selection  Sensitivity monitoring satisfying NFPA 72 sensitivity testing requirements; automatic individual sensor calibration check verifies sensor integrity  Automatic environmental compensation, multi-stage alarm operation, and display of sensitivity directly in percent per foot  Ability to display and print detailed sensor information in plain English language Photoelectric smoke sensors provide:  Seven levels of sensitivity from 0.2% to 3.7% (refer to additional information on page 3) Heat sensors provide:  Fixed temperature sensing  Rate-of-rise temperature sensing  Utility temperature sensing  Listed to UL 521 and ULC-S530 General features:  Operation is for ceiling or wall mounting  Listed to UL 268 and ULC-S529  Louvered smoke sensor design enhances smoke capture by directing flow to chamber; entrance areas are minimally visible when ceiling mounted  Designed for EMI compatibility  Magnetic test feature is provided  Different bases are available to a supervised or unsupervised output relay, and/or a remote LED alarm indicator Additional base reference:  For isolator bases, refer to data sheet S4098-0025  For sounder bases, refer to data sheet S4098-0028  For photo/heat sensors, refer to data sheet S4098-0024 (single address) and S4098-0033 (dual address) * These products have been approved by the California State Fire Marshal (CSFM) pursuant to Section 13144.1 of the California Health and Safety Code. See CSFM Listings 7272-0026:218, 7271-0026:231, 7270-0026:216, and 7300-0026:217 for allowable values and/or conditions concerning material presented in this document. Accepted for use – City of New York Department of Buildings – MEA35-93E. Additional listings may be applicable, your local Simplex product supplier for the latest status. Listings and approvals under Simplex Time Recorder Co. are the property of Tyco Fire Protection Products.

4098-9714 TrueAlarm Photoelectric Sensor Mounted in Base

Description Digital Communication of Analog Sensing. TrueAlarm analog sensors provide an analog measurement digitally communicated to the host control using Simplex addressable communications. At the control , the data is analyzed and an average value is determined and stored. An alarm or other abnormal condition is determined by comparing the sensor’s present value against its average value and time. Intelligent Data Evaluation. Monitoring each sensor’s average value provides a continuously shifting reference point. This software filtering process compensates for environmental factors (dust, dirt, etc.) and component aging, providing an accurate reference for evaluating new activity. With this filtering, there is a significant reduction in the probability of false or nuisance alarms caused by shifts in sensitivity, either up or down. Control Selection. Peak activity per sensor is stored to assist in evaluating specific locations. The alarm set point for each TrueAlarm sensor is determined at the host control , selectable as more or less sensitive as the individual application requires. Timed/Multi-Stage Selection. Sensor alarm set points can be programmed for timed automatic sensitivity selection (such as more sensitive at night, less sensitive during day). Control programming can also provide multi-stage operation per sensor. For example, a 0.2% level may cause a warning to prompt investigation while a 2.5% level may initiate an alarm. Sensor Alarm and Trouble LED Indication. Each sensor base’s LED pulses to indicate communications with the . If the control determines a sensor is in alarm, or is dirty or has some other type of trouble, the details are annunciated at the control and that sensor base’s LED will be turned on steadily. During a system alarm, the control will control the LEDs such that an LED indicating a trouble will return to pulsing to help identify the alarmed sensors. S4098-0019-22 10/2016

TrueAlarm Sensor Bases and Accessories

Description

Sensor Base Features

TrueAlarm sensor bases contain integral addressable electronics that constantly monitor the status of the detachable photoelectric or heat sensors. Each sensor’s output is digitized and transmitted to the system fire alarm control every four seconds.

Base mounted address selection:

 

Address remains with its programmed location Accessible from front (DIP switch under sensor)

General features:

  

Since TrueAlarm sensors use the same base, different sensor types can be easily interchanged to meet specific location requirements. This feature also allows intentional sensor substitution during building construction. When conditions are temporarily dusty, instead of covering the smoke sensors (causing them to be disabled), heat sensors may be installed without reprogramming the control . Although the control will indicate an incorrect sensor type, the heat sensor will operate at a default sensitivity providing heat detection for building protection at that location.

Automatic identification provides default sensitivity when substituting sensor types Integral red LED for power-on (pulsing), or alarm or trouble (steady on) Locking anti-tamper design mounts on standard outlet box

 Magnetically operated functional test

Sensor Bases 4098-9792, Standard Sensor Base 4098-9789, Sensor Base with wired connections for:



2098-9808 Remote LED alarm indicator or 4098-9822 relay (relay is unsupervised and requires separate 24 VDC)

Mounting Reference

Supervised Relay Bases (not compatible with 2120 CDT):  4098-9791, 4-Wire Sensor Base, use with remote or



 

Electrical Box Requirements: (boxes are by others)

locally mounted 2098-9737 relay, requires separate 24 VDC 4098-9780, 2-Wire Sensor Base, use with remote or locally mounted 4098-9860 relay, no separate power required Supervised relay operation is programmable and can be manually operated from control Includes wired connections for remote LED alarm indicator or 4098-9822 relay (relay is unsupervised and requires separate 24 VDC)

Without relay in the box: 4" octagonal or 4" square, 1-1/2" deep; single gang, 2" deep With relay in the box : 4" octagonal or 4" square, 1-1/2" deep, with 1-1/2" extension ring 4" (102 mm) Square Box

4" (102 mm) Octagonal Box

Surface mount reference

Sensor Base Options 1-1/2" (38 mm) minimum box depth

2098-9737, Remote or local mount supervised relay:



DPDT s for resistive/suppressed loads, power limited rating of 3 A @ 28 VDC; non-power limited rating of 3 A @ 120 VAC (requires external 24 VDC coil power)

2098-9737 Supervised Relay (mounts in base electrical box or remotely)

4098-9860, Remote or local mount supervised relay:



SPDT dry s, power limited rating of 2 A @ 30 VDC, resistive; non-power limited rating of 0.5 A @ 125 VAC, resistive



Activates when base LED is on steady, indicating local alarm or trouble DPDT s for resistive/suppressed loads, power limited rating of 2 A @ 28 VDC; non-power limited rating of 1/2 A @ 120 VAC, (requires external 24 VDC coil power)

4098-9860 Supervised Relay (mounts in base electrical box or remotely; 2-3/8" X 1-1/4" X 11/32" (1 in3 ) (60.4 mm X 31.8 mm X 8.6 mm) NOTE: Review total wire count, wire size, and accessories being wired to determine required box volume.

4098-9832, Adapter plate:

 

Required for surface or semi-flush mounting to 4” square electrical box and for surface mounting to 4” octagonal box Can be used for cosmetic retrofitting to existing 6-3/8” diameter base product

6-3/8" (162 mm)

1/4" (6.4 mm)

2098-9808, Remote red LED Alarm Indicator:



Mounts on single gang box (shown in illustration to right)

4098-9822 Relay (mounts in base electrical box)

Relay Size: 2-1/2" X 1-1/2" X 1" (3.75 in3 ) (64 mm X 38 mm X 25.4 mm)

4098-9822, LED Annunciation Relay:



Flush mount reference, mount even with final surface, or with up to 1/4" (6.4 mm) maximum recess

4098-9832 Adapter Plate, required for mounting to surface mounted boxes and 4" square flush box 4-7/8" (124 mm)

15/16" (24 mm)

ALARM

TrueAlarm Bases 4098-9780, 4098-9789, 4098-9791, & 4098-9792

2

S4098-0019-22 10/2016

TrueAlarm Sensors Features

4098-9733 Heat Sensor

Sealed against rear air flow entry Interchangeable mounting EMI/RFI shielded electronics Heat sensors:

TrueAlarm heat sensors are self-restoring and provide rate compensated, fixed temperature sensing, selectable with or without rate-of-rise temperature sensing. Due to its small thermal mass, the sensor accurately and quickly measures the local temperature for analysis at the fire alarm control .



Selectable rate compensated, fixed temperature sensing with or without rate-of-rise operation  Rated spacing distance between sensors: Fixed Temp. Setting

UL & ULC Spacing

FM Spacing, Either Fixed Temperature Setting

135° F (57.2° C)

60 ft x 60 ft (18.3 m)

20 ft x 20 ft (6.1 m) for fixed temperature only; RTI = Quick

155° F (68° C)

40 ft x 40 ft (12.2 m)

50 ft x 50 ft (15.2 m) for fixed temperature with either rate-of-rise selection; RTI = Ultra Fast

Rate-of-rise temperature detection is selectable at the control for either 15° F (8.3° C) or 20° F (11.1° C) per minute. Fixed temperature sensing is independent of rate-of-rise sensing and programmable to operate at 135° F (57.2° C) or 155° F (68° C). In a slow developing fire, the temperature may not increase rapidly enough to operate the rate-of-rise feature. However, an alarm will be initiated when the temperature reaches its rated fixed temperature setting.

Smoke Sensors:

  

TrueAlarm heat sensors can be programmed as a utility device to monitor for temperature extremes in the range from 32° F to 155° F (0° C to 68° C). This feature can provide freeze warnings or alert to HVAC system problems. Refer to specific s for availability.

Photoelectric technology sensing 360° smoke entry for optimum response Built-in insect screens

4098-9714 Photoelectric Sensor

4-7/8" (124 mm)

TrueAlarm photoelectric sensors use a stable, pulsed infrared LED light source and a silicon photodiode receiver to provide consistent and accurate low power smoke sensing. Seven levels of sensitivity are available for each individual sensor, ranging from 0.2% to 3.7% per foot of smoke obscuration. Sensitivities of 0.2%, 0.5%, and 1% are for special applications in clean areas. Standard sensitivities are 1.5%, 2.0%, 2.5%, 3.0%, and 3.7%. Application type and sensitivity are selected and then monitored at the fire alarm control .*

LED status indicator 2-3/8" (60 mm)

4098-9733 Heat Sensor with Base

The sensor head design provides 360° smoke entry for optimum response to smoke from any direction. Due to its photoelectric operation, air velocity is not normally a factor, except for impact on area smoke flow.

WARNING: In most fires, hazardous levels of smoke and toxic gas can build up before a heat detection device would initiate an alarm. In cases where Life Safety is a factor, the use of smoke detection is highly recommended.

4-7/8" (124 mm) LED status indicator

Application Reference

2-1/8" (54 mm)

Sensor locations should be determined only after careful consideration of the physical layout and contents of the area to be protected. Refer to NFPA 72, the National Fire Alarm and Signaling Code. On smooth ceilings, smoke sensor spacing of 30 ft (9.1 m) may be used as a guide.*

4098-9714 Photoelectric Sensor with Base

* For detailed application information including sensitivity selection, refer to Installation Instructions 574-709.

3

S4098-0019-22 10/2016

TrueAlarm Analog Sensing Product Selection Chart TrueAlarm Sensor Bases (for use with Sensors 4098-9714 and 4098-9733) (Refer to Application Manual 574-709 and Installation Instructions 574-707 for additional information) Model* 4098-9792

Color White

Description

Compatibility

Mounting Requirements

4098-9776

Black

Standard Sensor Base

No options

4” octagonal or 4” square box, 1-1/2” min. depth; or single gang box, 2” min. depth

4098-9789

White

4098-9789 IND

White

Sensor Base with connections for Remote LED Alarm Indicator or Unsupervised Relay

2098-9808 Remote Alarm Indicator or 4098-9822 Unsupervised Relay

4098-9775

Black

4098-9791**

White

4-Wire Sensor Supervised Relay 2098-9737 Supervised Remote Relay Base with connections for LED 2098-9808 Remote Alarm Indicator or Indicator or Unsupervised Relay 4098-9822 Unsupervised Relay

4098-9780**

White

2-Wire Sensor Supervised Relay 4098-9860 Supervised Remote Relay Base with connections for LED 2098-9808 Remote Alarm Indicator or Indicator or Unsupervised Relay 4098-9822 Unsupervised Relay

4” octagonal or 4” square box Note: Box depth requirements depend on total wire count and wire size, refer to accessories list below for reference. ** NOTE: 4098-9791 and 40989780 are NOT compatible with the 2120 CDT

TrueAlarm Sensors Model* 4098-9714 4098-9714 IND 4098-9774 4098-9733 4098-9778

Model* White Black White Black

Description

Compatibility

Mounting Requirements

Photoelectric Smoke Sensor

Bases 4098-9775, 4098-9776, 40989792, 4098-9789, 4098-9791, and 4098-9780

Refer to base requirements

Heat Sensor

TrueAlarm Sensor/Base Accessories Model 2098-9737 4098-9860 2098-9808 4098-9822 4098-9832

Description Supervised Relay, mounts remote or in base electrical box Supervised Relay, mounts remote or in base electrical box Remote Red LED Alarm Indicator on single gang stainless steel plate Unsupervised Relay, tracks base LED status; Note: Mounts only in base electrical box

Compatibility For use with 4098-9791 base For use with 4098-9780 base Bases 4098-9789, 4098-9791, and 4098-9780 Bases 4098-9789, 4098-9791, and 4098-9780 Bases 4098-9792, 4098-9789, 4098-9791, and 4098-9780

Adapter Plate

Mounting Requirements Remote Mounting requires 4” octagonal or 4” square box, 1-1/2” minimum depth Base Mounting requires 4” octagonal box, 2-1/8” deep with 1-1/2” extension ring Single gang box, 1-1/2” minimum depth 4” octagonal box, 2-1/8” deep with 1-1/2” extension ring Required for surface or semi-flush mounted 4” square box and for surface mounted 4” octagonal box

* Note: Model numbers ending in IND are assembled in India.

Specifications General Operating Specifications Communications and Sensor Supervisory Power

IDNet or MAPNET II communications, auto-selected, 1 address per base

Communications Connections Remote LED Alarm Indicator Current Remote LED Alarm Indicator and Relay Connections UL Listed Operating Temperature Range

Screw terminals for in/out wiring, 18 to 14 AWG (0.82 mm2 to 2.08 mm2) 1 mA typical, no impact to alarm current Color coded wire leads, 18 AWG (0.82 mm2 ) 32° to 100° F (0° to 38° C)

Operating Temperature Range

with 4098-9733 Heat Sensor 32° to 122° F (0° to 50° C) with 4098-9714 Smoke Sensor 15° to 122° F (-9° to 50° C)

Storage Temperature Range Humidity Range 4098-9714 Smoke Sensor Air Velocity Rating Housing Color

0° F to 140° F (-18° C to 60° C) 10 to 95% RH 0-4000 ft/min (0-1220 m/min) Frost White or Black

4098-9791 Base With Supervised Remote Relay 2098-9737 (see page 2 for ratings) Externally Supplied Relay Coil Voltage

18-32 VDC (nominal 24 VDC)

Supervisory Current

270 A, from 24 VDC supply 28 mA, from 24 VDC supply

Alarm Current with 2098-9737 Relay

4098-9780 Base With Supervised Remote Relay 4098-9860 (see page 2 for ratings) Power

Supplied from communications

4098-9822 Unsupervised Relay, Requirements for Bases 4098-9789. 4098-9791, and 4098-9780 (see page 2 for ratings) Externally Supplied Relay Coil Voltage Supervisory Current Alarm Current

18-32 VDC (nominal 24 VDC) Supplied from communications 13 mA from separate 24 VDC supply

TYCO, SIMPLEX, and the product names listed in this material are marks and/or ed marks. Unauthorized use is strictly prohibited. NFPA 72 and National Fire Alarm and Signaling Code are trademarks of the National Fire Protection Association (NFPA).
