Barracuda Link Balancer

BARRACUDA LINK BALANCER

Aggregates multiple Internet connections Designed to scale for high bandwidth requirements and provide business continuity for an organization of any size, the Barracuda Link Balancer optimizes the use of multiple Internet links, such as T1s, T3s, DSL and cable connections. By combining links from one or multiple Internet service providers, organizations reduce the need to purchase high cost links to handle daily Internet usage. By providing automatic failover in the event of link failure, the Barracuda Link Balancer helps ensure that an organization’s network is always connected to the Internet. Simple Bandwidth Management for High Availability In today’s organizations, Internet bandwidth and availability is missioncritical for day-to-day operations. The Barracuda Link Balancer aggregates client and server Internet bandwidth to provide optimal access to multiple high speed connections. With bandwidth management and Quality of Service (QoS) features, the Barracuda Link Balancer prioritizes bandwidth to mission-critical applications. The Barracuda Link Balancer provides s with tools to automatically prioritize critical Internet applications. For example, Web browsing and email can be guaranteed bandwidth while peer-to-peer applications and media streaming can be assigned a lower priority. The flexibility to manage priority of Internet usage ensures low-priority bandwidth-intensive applications never interfere with business-critical operations. The Barracuda Link Balancer also includes a network firewall capable of enforcing access control lists (ACLs), port forwarding, NAT and DNS forwarding. Further, DH and DNS caching services are provided and site-to-site VPN connections are enabled. Easy-to-Use and Maintain Installed at the network perimeter, s can deploy the Barracuda Link Balancer with or without a separate network firewall to consolidate the management of network security and traffic aggregation. With an easy-to-use Web interface, the Barracuda Link Balancer allows s to easily define, manage and control Internet links.

The Barracuda Link Balancer displays statistics on incoming and outgoing traffic.

Barracuda Link Balancer Architecture Barracuda Link Balancer Link Load Balancer

DH Server DNS Caching Server SNMP and Traffic Statistics Clients / Servers

LAN

Bandwidth Management (QoS)

T1

Cable Modem DSL

Site-to-Site VPN Firewall Internet

MODEL

T1 Router

Cable Modem DSL Server

Typical Deployment

Client

Client

Server

Client

Internet Barracuda Link Balancer

Switch

TECHNICAL SPECIFICATIONS

BARRACUDA LINK BALANCER

Security Features

MODEL

LINK BALANCING • WAN and Internet connection link balancing • Inbound link balancing • Traffic aggregation • Automated link detection and failover • Link health monitoring - DNS - Ping - HTTP - T port checking • Link speed assignment and weighting

Bandwidth Management and Quality of Service (QoS) • Application-based priority assignments • Custom port-based application definition • Preconfigured protocols: - Web - Network Authentication - Email - Terminal Services - FTP - SIP - DNS

TRADITIONAL FIREWALL • Network Address Translation (NAT) • 1:1 NAT • Port forwarding • Firewall IP Access Control Lists (ACLs) and rules • DDoS protection • Firewall transparency

System Features

CAPACITY* Internet Link Connections Maximum Throughput HARDWARE Rackmount Chassis Dimensions (in) Dimensions (cm) Weight (lbs/kg) Ethernet Ethernet through AC Input Current (Amps) FEATURES Link Balancing Link Health Monitoring Link Failover Traffic Aggregation Network Traffic Firewall Local DH and DNS Traffic Monitoring SNMP Automated WAN Provisioning Site-to-Site VPN Bandwidth Management and QoS Ethernet By Hardware Clustering/High Availability Reporting Customizable Branding API

CONNECTORS • Standard VGA • PS/2 keyboard/mouse • Ethernet (see chart below) • Serial port (DB-9) POWER REQUIREMENTS • AC input voltage 100-240 volts • Frequency 50/60 Hz

Options

S • Web-based interface • Traffic and performance monitoring • Event logging • SNMP • Secure remote istration • Reporting

ENERGIZE UPDATES SUBSCRIPTION • Standard technical • Firmware maintenance • Security updates INSTANT REPLACEMENT SUBSCRIPTION • Replacement unit shipped next business day • 24x7 technical

NETWORK SERVICES • DH server • DNS caching server • DNS request forwarding • Site-to-site VPN • Outbound Source NAT • VLAN Model comparison

Hardware Features

Model 230

Model 330

Model 430

2 35 Mbps

3 65 Mbps

7 250 Mbps

1U Mini 16.8 x 1.7 x 9 42.7 x 4.3 x 23 8 / 3.6 3 x 10/100

1U Mini 16.8 x 1.7 x 14 42.7 x 4.3 x 35.6 12 / 5.4 2 x 10/100 3 x 1 Gigabit 1 x Gigabit 1.2

1U Mini 16.8 x 1.7 x 14 42.7 x 4.3 x 35.6 12 / 5.4 6 x 10/100 3 x 1 Gigabit 1 x Gigabit 1.2

P P P P P P P P P P P P P P

P P P P P P P P P P P P P P P P

1.0 P P P P P P P P P P P

US 16.1 Specifications subject to change without notice. *Capacity depends on environment and selected options. Copyright © 2011 Barracuda Networks Inc. • 3175 S. Winchester Blvd., Campbell, CA 95008 • 1-888-ANTI-SPAM (1-888-268-4772) • www.barracuda.com
